Technical Data Sheet
2/13/2015
Model: AEA2413YXA
Product Description
Type: Reciprocating
Application: LBP - Low Back Pressure
Refrigerant: R-134a
Voltage/Frequency: 115V ~ 60Hz 100V ~ 50Hz
Version: N/A
Product Specifications
Performance
Refrigeration Capacity Input Power Efficiency
Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W
EVAP TEMP COND
TEMP
AMBIENT
TEMP
RETURN
GAS
LIQUID
TEMP
ASHRAE 115V ~ 60HZ 1350 340 396 380 3.55 .9 1.04 -23°C (-10°F) 54°C (130°F) 32°C (90°F) 32°C (90°F) 32°C (90°F)
General
Evaporating Temp. Range: -40°C to -12.2°C (-40°F to 10°F)
Motor Torque: High Start Torque (HST)
Compressor Cooling: Fan
Mechanical
Weight: 27
Weight Unit of Measure: LB
Displacement (cc): 16.077
Oil Type: Polyolester
Viscosity (cSt): 32
Oil Charge (cc): 456
Electrical
Voltage Range (50 Hz): 90-110
Voltage Range (60 Hz): 103-127
Locked Rotor Amps (LRA): 40
Rated Load Amps (RLA 50 Hz): 0
Rated Load Amps (RLA 60 Hz): 5.9
Max. Continuous Current (MCC in Amps): 8
Motor Resistance (Ohm) - Main: 1.13
Motor Resistance (Ohm) - Start: 6.2
Motor Type: CSIR
Overload Type: N/A
Relay Type: N/A
Agency Approval
cURus Recognized
