Technical Data Sheet
2/13/2015
Model: AWA9514ZXT
Product Description
Type: Reciprocating
Application: CBP - Commercial Back
Pressure
Refrigerant: R-404A
Voltage/Frequency: 200-230V 3~ 60Hz 200-220V 3~
50Hz
Version: N/A
Product Specifications
Performance
Refrigeration Capacity Input Power Efficiency
Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W
EVAP TEMP COND
TEMP
AMBIENT
TEMP
RETURN
GAS
LIQUID
TEMP
ARI 230V 3~
60HZ
14300 3604 4190 2480 5.77 1.45 1.69 -6.7°C (20°F) 49°C (120°F) 35°C (95°F) 4.4°C (40°F) 49°C (120°F)
General
Evaporating Temp. Range: N/A
Motor Torque: High Start Torque (HST)
Compressor Cooling: Fan
Mechanical
Weight: 70
Weight Unit of Measure: LB
Displacement (cc): 51.327
Oil Type: Polyolester
Viscosity (cSt): 32
Oil Charge (cc): 1141
Electrical
Voltage Range (50 Hz): 180-242
Voltage Range (60 Hz): 180-254
Locked Rotor Amps (LRA): 63.4
Rated Load Amps (RLA 50 Hz): 0
Rated Load Amps (RLA 60 Hz): 7.3
Max. Continuous Current (MCC in Amps): 15.5
Motor Resistance (Ohm) - Main: 1.28
Motor Resistance (Ohm) - Start: N/A
Motor Type: 3PH
Overload Type: N/A
Relay Type: N/A
Agency Approval
cURus Recognized
