Technical Data Sheet
2/13/2015
Model: RKA5512YXA (RK5512Y)
Product Description
Type: Rotary
Application: HBP/AC - Air Conditioning
Refrigerant: R-134a
Voltage/Frequency: 115V ~ 60Hz 100V ~ 50Hz
Version: N/A
Product Specifications
Performance
Refrigeration Capacity Input Power Efficiency
Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W
EVAP TEMP COND
TEMP
AMBIENT
TEMP
RETURN
GAS
LIQUID
TEMP
ARI 115V ~ 60HZ 11700 2948 3428 1064 11 2.77 3.22 7.2°C (45°F) 54°C (130°F) 35°C (95°F) 18.3°C
(65°F)
46°C (115°F)
EN12900
ASERCOM
115V ~ 60HZ 9679 2439 2836 989 9.79 2.47 2.87 5°C (41°F) 50°C (122°F) 32°C (90°F) 15°C (59°F) 50°C (122°F)
EN12900
ASERCOM
100V ~ 50HZ 8208 2068 2405 806 10.18 2.57 2.98 5°C (41°F) 50°C (122°F) 32°C (90°F) 15°C (59°F) 50°C (122°F)
General
Evaporating Temp. Range: -15°C to 15°C (5°F to 59°F)
Motor Torque: Low Start Torque (LST)
Compressor Cooling: Fan
Mechanical
Weight: 28
Weight Unit of Measure: LB
Displacement (cc): 24.369
Oil Type: Polyvinylether
Viscosity (cSt): 69
Oil Charge (cc): 356
Electrical
Voltage Range (50 Hz): 90-110
Voltage Range (60 Hz): 103-127
Locked Rotor Amps (LRA): 57
Rated Load Amps (RLA 50 Hz): 9.6
Rated Load Amps (RLA 60 Hz): 9.8
Max. Continuous Current (MCC in Amps): 15.4
Motor Resistance (Ohm) - Main: .56
Motor Resistance (Ohm) - Start: 3.98
Motor Type: PSC
Overload Type: N/A
Relay Type: N/A
Agency Approval
cURus Recognized
