TeleEpoch CDM2035 CDMA Mobile Phone User Manual CDM2035C User Manual
TeleEpoch Limited CDMA Mobile Phone CDM2035C User Manual
Users Manual
1
USER MANUAL
Table of Contents
USER MANUAL ....................................................................................................................................1
TABLE OF CONTENTS ............................................................................................................................1
1. UNDERSTANDING YOUR PHONE................................................................................................4
1.1 FEATURES OF YOUR PHONE.............................................................................................................4
1.2 SIDE VIEWS OF YOUR PHONE...........................................................................................................5
1.3 FRONT VIEW OF YOUR PHONE.........................................................................................................6
1.4 BACK VIEW OF YOUR PHONE ..........................................................................................................7
2. GETTING STARTED........................................................................................................................8
2.1 INSTALL THE BATTERY ....................................................................................................................8
2.2 BATT ERY COVER .............................................................................................................................8
2.3 INSTALL THE BATTERY ....................................................................................................................8
2.4 REMOVE THE BATTERY....................................................................................................................8
2.5 CHARGING THE BATTERY ................................................................................................................9
3. ESSENTIAL TOPICS ...................................................................................................................10
3.1 COMMUNICATION CONTROL KEYS ................................................................................................10
3.2 FUNCTIONAL KEYS AND SOFT KEYS..............................................................................................10
3.3 STANDARD KEYPAD .......................................................................................................................10
3.4 LANGUAGE AND INPUT METHODS ..................................................................................................10
3.5 SHORT MESSAGE ALERT MODES .....................................................................................................11
3.6 CALL ALERT MODES.......................................................................................................................11
3.7 FIND CONTACTS.............................................................................................................................11
4. BASIC OPERATIONS..................................................................................................................12
4.1 SWITCHING ON ..............................................................................................................................12
4.2 SWITCHING OFF .............................................................................................................................12
4.3 MAKING A CALL ............................................................................................................................12
4.4 ADJUSTING THE VOLUME OF EARPIECE ..........................................................................................12
4.5 ANSWERING A CALL.......................................................................................................................12
5. USING THE MENU.........................................................................................................................13
5.0.1 My Home Screen...............................................................................................................13
5.0.2 Activating Your Phone.......................................................................................................13
5.0.3 Enter the menu ......................................................................................................................14
5.0.4 Navigate the menus ...............................................................................................................14
5.1 RECENT CALLS ..............................................................................................................................15
2
5.1.1 Missed calls...........................................................................................................................15
5.1.2 Received calls........................................................................................................................15
5.1.3 Dialed calls ...........................................................................................................................15
5.1.4 Delete log..............................................................................................................................16
5.1.5 Call time................................................................................................................................16
5.2 MESSAGES.....................................................................................................................................17
5.2.1 To open and read an incoming message................................................................................17
5.2.2.1 New text Message (SMS)...............................................................................................................17
5.2.2.2 Voice Mail......................................................................................................................................18
5.2.2.3 Inbox..............................................................................................................................................18
5.2.2.4 Outbox............................................................................................................................................18
5.2.2.5 Sentbox ..........................................................................................................................................18
5.2.2.6 Draftbox.........................................................................................................................................19
5.2.2.7 Template.........................................................................................................................................19
5.2.2.8 Deferred .........................................................................................................................................19
5.2.2.9 Conversation ..................................................................................................................................19
5.2.2.10 Settings.........................................................................................................................................20
5.2.2.11 Delete...........................................................................................................................................20
5.2.3 Picture Messaging (MMS).................................................................................................20
5.2.3.1 Create a Picture Message (MMS)...................................................................................................20
5.2.3.2 Inbox..............................................................................................................................................21
5.2.3.3 Outbox............................................................................................................................................21
5.2.3.4 Drafts..............................................................................................................................................21
5.2.3.5 Sent ................................................................................................................................................21
5.2.3.6 Templates .......................................................................................................................................22
5.2.3.7 Settings...........................................................................................................................................22
5.3 CONTACTS.....................................................................................................................................23
5.3.0.1 To enter a contact ...........................................................................................................................23
5.3.0.2 To dial from your contacts list........................................................................................................23
5.3.1 Contact list ............................................................................................................................24
5.3.2 Create New Contacts........................................................................................................24
5.3.3 Group...................................................................................................................................24
5.3.4 Set Speed Dial...................................................................................................................24
5.3.5 Memory info........................................................................................................................24
5.4 MULTIMEDIA .................................................................................................................................25
5.4.1 Audio Player .......................................................................................................................25
5.4.2 Camera ...............................................................................................................................25
5.4.3 Recorder .............................................................................................................................26
5.4.4 Gallery.................................................................................................................................26
5.5 BROWSER (WAP) ..........................................................................................................................27
5.6 GAMES & APPS..............................................................................................................................28
5.7 TOOLS & UTILITIES .......................................................................................................................29
5.7.1 Alarm ...................................................................................................................................29
5.7.2 Bluetooth.............................................................................................................................29
3
5.7.3 Calendar .............................................................................................................................29
5.7.4 Schedule.............................................................................................................................29
5.7.5 Notes...................................................................................................................................30
5.7.6 Calculator............................................................................................................................30
5.7.7 Stopwatch...........................................................................................................................30
5.7.8 World Time .........................................................................................................................31
5.7.9 Unit Converter....................................................................................................................31
5.7.10 Ez Tip Calc .......................................................................................................................31
5.8 BLUETOOTH ..................................................................................................................................32
5.8.1 Turn Blue tooth on/off........................................................................................................32
5.8.2 To set up a new Bluetooth device ...................................................................................32
5.8.3 Discoverable.......................................................................................................................32
5.8.4 Found Devices: Display detected devices.....................................................................32
5.8.5 Manage...............................................................................................................................32
5.9 SETTINGS ......................................................................................................................................33
5.9.1 Profiles ................................................................................................................................33
5.9.1.1 Activate ..........................................................................................................................................33
5.9.1.2 Personalize ..................................................................................................................................... 33
5.9.2 Phone Setup.......................................................................................................................34
5.9.3 Display Setup.....................................................................................................................34
5.9.4 Call Setup ...........................................................................................................................34
5.9.5 Security Setup....................................................................................................................35
5.9.6 Phone Info ..........................................................................................................................35
6, SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES
4
1.0 Understanding Your phone
This section outlines some key features of your phone
1.1 Features of Your Phone
QSC6155, BMP
800MHz/1900MHz/AWS
Bluetooth 3.0
1.77”QQVGA LCD
Camera: 0.3M
Text (SMS) Messaging and Picture (MMS) Messaging
WAP (Wireless Application Protocol) Internet Browser
Speakerphone
Note: The phone supports the wireless headset, handsfree , file transfer, and object push
profiles for Bluetooth wireless technology.
5
1.2 Side views of Your Phone
1. Volume Key – In Standby mode, lets
you adjust the ring volume. When
receiving a call, mutes the ringer.
During a call, lets you adjust the voice
volume. In Menu mode, lets you scroll
through the phone menu options.
2. Headset Connector – Used to connect
hands-free headsets to your phone
6
1.3 Front View of Your Phone
1. Earpiece – Lets you hear ringing and alert tones,
alarm tones and the other parties to calls
2. Display – Indicates the status of your phone,
including numbers dialed, feature and function
screens, status icons, message indicators and
contents, signal strength, and so on.
3. Navigation key – In standby mode, launches
selected functions or applications. In Menu mode, lets
you scroll through the phone menu option.
4. Left Soft Key – Used to navigate through menus
and applications and to select the choice indicated at
the bottom left corner of the Display
5. Camera Key – Lets you speed launch camera In
standby mode ,
6. Send Key – Lets you place or receive a call. In
standby mode, press the key once to access the
recent call log.
7. Voicemail Key – Lets you speed dial your
Voicemail account to review your voice messages.
8. Microphone – Lets the other caller hear you clearly
when you are speaking to them.
9. Special Function Keys – Enter special characters.
Perform various functions.
10. Alpha-numeric Keys – Use these keys to enter
numbers, letters, and characters.
11. End Key – Ends a call. If you press and hold the
End key, the power goes On or Off. When you receive
an incoming call, press to send the call to voicemail.
12. Back Key – Lets you cancel and the upper level
directory.
13. Right Soft Key – Used to navigate through
menus and applications and to select the choice
indicated at the bottom right corner of the main
display.
14. OK Key – In Standby mode, launches the Main
Menu. Pressing when navigating through a menu
accepts the highlighted option.
7
1.4 Back View of Your Phone
1. Camera
2. Speaker
3. Micro-USB
4. T-flash card
8
2.0 Getting Started
This section explains how to install, remove, and charge the battery for your
2.1 Install the Battery
Note: Your phone comes packaged with a partially charged rechargeable standard Li-Ion
Battery and travel adapter.
2.2 Battery Cover
Remove the battery cover to access the battery
To remove the battery cover, slide the battery cover down and lift it away.
To replace the battery cover, press the top end of the battery cover down lightly, and slide it over
the battery until it clicks into place.
2.3 Install the Battery
Insert the top end of the battery first, matching the gold contacts on the inside of the battery to
those on the phone, then press the bottom of the battery down into the phone until it slips into
place.
2.4 Remove the Battery
1. Before removing the battery, turn the phone off, if necessary. To turn the phone off,
Press and hold the Key.
2. Lift the end of the battery up and away from the phone and slide the battery up and out
of the phone.
9
2.5 Charging the Battery
Your phone is powered by a rechargeable standard Li-Ion battery.
Use of other accessories may invalidate your warranty and may cause damage.
Use the Travel Adapter
The travel adapter included with your phone is a convenient, light-weight charger that
rapidly charges your phone from any 110/220 VAC outlet
Important!: For connection to an electrical supply not located in North America, you must
use an adapter of the proper configuration for the power outlet. Use of the wrong adapter
could damage your phone and void your warranty.
1. Plug the large end of the Travel Adapter into a standard 110 VAC or 220 VAC wall
outlet
2. Insert the small end of the Travel Adapter into the charger/accessory connector on the
side of your phone. You must unplug the adapter before removing the battery from the
phone during charging to avoid damage.
10
3. Essential Topics
3.1 Communication Control Keys
The ‘Calling’ key is used for making a call (after a number has been entered); or for
viewing recent call records.
The ‘End’ key is used for ending a call (during dialing and communication state), or for
exiting menu under menu state to return to standby menu. Pressing and holding this key
switch on or off the phone.
3.2 Functional Keys and Soft Keys
Direction keys of up, down, left and right direction are used for browsing menus, lists,
options or content compiled.
Under standby state, the up-direction key is used as shortcut key for Messaging; the
down-direction key is used as shortcut key for Browser; the left/right-direction key is used
as shortcut key for slip page. Under standby state, the left soft key is a shortcut key for
accessing Menu and the right soft key is a shortcut key for Contacts. The functions of the
two soft keys under other states are closely related to the phone’s current state.
Under standby state, you can press and hold the key ‘#’ to switch between Vibrate and
general mode.
3.3 Standard keypad
Keys from ‘0’ to ‘9’, and key ‘＊’ and ‘#’ are used for dialing, inputting password, English
letters, symbols etc and inputting Spanish.
■ Note: After the phone’s standby interface maintains for period of time (time length is set
by the user), the phone will turn off the backlight of the screen for the purpose of power
saving. If the backlight of the screen goes out, you can press any key on the phone’s
keypad to turn on the backlight immediately.
3.4 Language and input methods
Languages supported by this phone are listed under the path [Settings]- [Phone] -
[Language].
11
This handset provides input methods as Spanish, English, Numbers and accustomed
symbols input. Under editing status, you can press the key ‘#’ to switch between input
methods and press the key ‘＊’ to switch to symbol. For detailed operations please refer to
relevant chapters of “Operation of Input Methods”.
3.5 Short message alert modes
You should choose refer to the path:
[Profiles]-[choose one mode]-[Personalize]-[Message alert tone].
3.6 Call alert modes
This handset has ten alert modes of Ring. You should choose refer to the path:
[Profiles]-[choose one mode]-[Personalize]
3.7 Find contacts
This handset provides a way to search for phone number by letters of a name. Under the
contact name list (press the key under main menu to get in), after inputting the letters of a
name to be searched for correctly, the screen will display all the fit records.
12
4. Basic operations
4.1 Switching on
Pressing and holding the ‘power on/off’ key in the standby state may switch on the phone.
It will automatically search the network if the phone has no password protection. Your
phone remains in a searching state if it fails to find the available network system.
If a password for the phone is required after it is switched on, please input the correct one
4.2 Switching off
To switch off the phone, please press and hold the ‘on/off’ key for 3 seconds and more in
the standby state.
Note: If you switch off the phone directly by taking off the battery, some information to be
stored in the phone may possibly get lost, which may cause inconvenience.
4.3 Making a call
Under standby state, input number directly via the keypad. Then press the ‘Calling’ key to
make the call.
4.4 Adjusting the volume of earpiece
During a conversation, you may press the up and down-direction key to adjust the volume
of earpiece.
4.5 Answering a call
When a call is incoming, the phone will prompt you according to the incoming call prompt
mode you have set. To answer a call, press the ‘Call control’ key to answer the call directly
or any key ( If ‘Any Key Answer’ is set on) to answer. To reject a call, press the ‘on/off’ key
and the other party will hear a busy tone.
13
5. Using the menu
5.0.1 My Home Screen
1. Icons that indicate phone and net work status.
2. The center of display shows information such as call progress information, messages ,
and photos.
3. Main Clock shows the day, date, and time.
4. Quick Access Menu contains Widgets that launch phone applications. Press the OK
key to launch the highlighted Widget.
Personalize
My Account
Storefront
Weather
Weblinks
Horoscope
News
Mocospa
5. Current soft key functions.
The sample screen shows that pressing the Left (Menu) soft key launches the Main
menu, and pressing the Right (Contacts) soft key launch the Contacts Find screen.
5.0.2 Activating Your Phone
Contact your wireless Carrier and follow their instructions for obtaining service, if
necessary.
14
5.0.3 Enter the menu
Under the standby state, press the middle of the navigation key to access the main menu
of the phone. Under the main menu interface, press any key to access the corresponding
‘Menu option list’.
The main menu have total 9 options, all menus of the phone have the function of text
prompt for corresponding function. Each set of menu is further divided into multi-item
sub-menu. Menu functions may let you set, check or change the phone’s various
functional settings to meet your personal requirements. Please refer to the following
‘Menu option list’ for selection of the functions you require.
Press the direction keys to select from the menu. Press OK key or left soft key to confirm
or to enter the sub-menu list of the selected menu. Then press up and down-direction key
to select and press the left soft key to confirm or enter into the lower-level menu.
Press the “Back” key to return to higher-level menu. Press the ‘on/off’ key to exit the
menu directly and return to the standby screen.
In editing state, the “Back” key has deleting function. Press it once to delete one
character and hold it to delete all the input characters.
In options, ‘On’ or ‘Activate’ is to enable corresponding function and ‘Off’ or ‘Cancel’ is to
disable corresponding function.
5.0.4 Navigate the menus
The standby screen menu has five options, Menu, Contacts, Messages and Browser and
the 3rd ISC. Press the Navigation key to enter the listed menus.
15
5.1 Recent calls
Call History can be accessed from the menu screen by selecting the Call History icon from
the main menu.
5.1.1 Missed calls
If there are missed calls, you can view the detailed information of the missed calls in the
‘missed calls’ menu. Each record contains the number (and the contact name if number is
already in the phonebook), date, time etc. Press the up and down-navigation key to view
the information of other missed calls. Press the ‘Call control’ key to dial the selected
number and press the right soft key to return to higher-level menu. Missed calls are
divided into the following two situations:
1. If the number is not stored in the phone, the phone number will be displayed in the
missed call list. Select the number and press the left soft/menu key to access the
sub-menu of this missed call, which has the following 5 items:
>Delete: Delete this missed call number record.
>Save to Contacts
>Dial
>Send message: Send text message /MMS message to this missed call number.
2. If this number is already stored in the phone, the caller’s name will be displayed in the
missed call list.
5.1.2 Received calls
The phone saves the 20 most recently received calls automatically. Functional operation
and display mode is the same as those of missed calls.
5.1.3 Dialed calls
The phone saves the 20 most recently dialed calls automatically. Functional operation and
display mode is the same as those of missed calls.
16
5.1.4 Delete log
Delete Missed Calls: Delete all records of missed calls.
Delete Received Calls: Delete all records of received calls.
Delete Dialed Calls: Delete all records of dialed calls.
Delete All: Delete all records of recent calls.
5.1.5 Call time
Last Call Time
Total Dialed: Total of all dialed calls time since the timer was reset last time.
Total Received: Total of all received calls time since the timer was reset last time.
Total Call Time
Total L i f e Time
Reset All Time
17
5.2 Messages
Messaging is a network service. You may be required to subscribe to the service from
your network operator prior to sending and receiving text messages.
A message is sent to the messages center of the network, then to the targeted user by the
network. If the targeted user’s phone is off or out of network area, the network will store
the message temporarily.
When the phone receives a new text message, you will be prompted according to setting
and the Unread Messages icon will appear at the top of the main screen to indicate
unread text message.
5.2.1 To open and read an incoming message
1. Select the Messages Icon, then
2. Select the type of Message
a. Select Text Messaging (for simple text messages, up to 515 characters), then select
Inbox
b. Select Picture Messaging (for attached, multimedia files (photos, audio, etc), then
select Inbox
5.2.2.1 New text Message (SMS)
You can create a text message in this menu. Every text message has a capacity of 515
characters. To create a new text message
1. Select Messages icon
2. Select Text Messaging
3. Select New Text Message
4. Use the key pad and type your message
Once the text has been entered, the following options are available, by pressing the left
soft key.
>Send to: send text message
>Insert:
1. Insert Contact info: Insert contact number.
2. Insert text template: Insert common phrase in the text message. It provides you with
12 common phrases.
>Sending Options: Set delivery priority, delivery report, immediate/schedule delivery
>Text Entry: Select input method (see Text Input Method section)
>Save to Drafts: Save to Draftboxs.
Cancel Message: Return to information list interface
18
5.2.2.2 Voice Mail
By selecting the Voice Mail menu, the phone will automatically access the Voice Mail
service. The Voice Mail service can also be accessed by holding the “1” key in standby
mode.
5.2.2.3 Inbox
The Inbox is used for reading text messages received. In the inbox, the phone can store
up to 50 text messages. You may press up and down-navigation key to browse the
message list. In the message Read mode, the following options are available.
1. Reply: Reply to the text message you are currently reading.
2. Reply with Content: Reply with the text message you are currently reading and can
re-edit it ；
3. Delete: Delete the text message you are currently reading.
4. Call: Call current text message’s number；
5. Forward: Forward the text message you are currently reading to others.
6. Lock: When in locked mode, message cannot be deleted.
7. Use Number: use current selected phone number；
8. Delete Multiple: Delete multiple items.
9. Clean up Message: Delete all inbox messages.
10. New Text Message: Create a new text message.
5.2.2.4 Outbox
This feature is used to store sent and failed messages. In the message Read mode, the
following options are available.
1. Send: Send the message currently being read.
2. Forward: Forward the message currently being read (it can be edited).
3. Delete: Delete the message currently being read.
4. Delete Multiple: Delete multiple items.
5. Clean up Message: Delete all Outbox messages.
6. New Text Message: Create a new text message.
5.2.2.5 Sentbox
The Sentbox is used for storing the text messages you have sent and selected the Save
and Send option in the Send to menu.
19
1. Delete: Delete the message currently being read.
2. Delete Multiple: Delete multiple items.
3. Clean up Message: Delete all Outbox messages.
4. New Text Message: Create a new text message.
5.2.2.6 Draftbox
After editing a new text message, choose “Save”. The message will be saved into the draft
box.
1. Delete: Delete the message currently being read.
2. Delete Multiple: Delete multiple items.
3. Clean up Message: Delete all Outbox messages.
4. New Text Message: Create a new text message.
5.2.2.7 Template
There are 12 common short phrases stored in the phone. You can add, then edit or delete
your own common phrases.
5.2.2.8 Deferred
Lists messages that have been deferred sending.
5.2.2.9 Conversation
1. Scroll to the message sender you want.
When a message sender is highlighted, you see the date, time, status and priority of the
last message you received from the sender.
2.Press confirmation key to select the highlighted sender.
You see a partial view of the last message you received from the sender, above that is a
partial view of the previous message.
3.Press confirmation key to open and view a highlighted message.
Scroll down to the entry area at the bottom of the screen to enter a reply, press send to
send the reply.
4.Press “on/off “key to return to the home screen.
20
5.2.2.10 Settings
Auto Delete: On/Off
Memory Status: Displays the amount of memory being used for Contacts and text
messages.
Signature: Set signature information.
Callback Number
CMAS Alert: Set Commercial mobile alert system emergency alert.
5.2.2.11 Delete
ALL: Delete all text messages stored in the outbox, inbox, sentbox, Draftbox, Voice Mail.
Inbox: Delete all text messages in the inbox in the phone.
Outbox: Delete all text messages stored in the outbox.
Sentbox: Delete all text messages in the sentbox in the phone.
Draftbox: Delete all text messages in the draftbox in the phone.
Voice Mail: Delete all messages in voicemail.
5.2.3 Picture Messaging (MMS)
Your cell phone can also send and receive MMS. This means you can send messages
that contain photos, sounds, and text through a MMS service.
When sending a MMS message, the receiver must be using a MMS compatible cell phone
in order for them to view your message.
Note: This feature can only be used with a network provider or service that supports
MMS. MMS messages can only be received and viewed by devices with MMS
compatibility or e-mail features. Please contact your local network operator for setting up
MMS messaging.
5.2.3.1 Create a Picture Message (MMS)
To create a Picture Message
1. Select Messages icon
2. Select Picture Messaging
3. Select Create Picture Messaging
Within Create Picture Messaging, you can enter the following fields:
i. Receiver: Set the number or e-mail address of the receiver.
ii. Edit Content: Edit the content of the MMS. Press “Edit” to enter the following options.
21
Insert: You can insert images, sounds or other elements using the cell phone or T-FLASH.
Preview: Preview the inserted multimedia elements.
Add: You can add a new page, theme, number to CC, number to BCC, or Slideshow Time:
Set the time when the images change in the previewed multimedia message.
Slide timing：You can edit slide time;
4. Press the Left Soft key for the options to Send, Add, Save as draft, Save as
Template.
5.2.3.2 Inbox
This menu allows you to review your received MMS messages.
Open: View the content of a MMS message.
Reply: Reply to the sender with a MMS, text, or e-mail message.
Forward: Forward the selected MMS message to another person.
Delete: Delete the current MMS message.
Delete All: Delete all the MMS messages in the Inbox.
Lock/Unlock: When in locked mode, message cannot be deleted.
5.2.3.3 Outbox
MMS messages that failed to send or are being sent are stored in the Outbox. The
following operations can be performed on the messages in the Outbox:
Resend: Resend the selected MMS message.
Delete: Delete the current MMS message.
Delete All: Delete all the MMS messages in the outbox.
Lock/Unlock: When in locked mode, message cannot be deleted.
5.2.3.4 Drafts
MMS messages can be optionally stored in Drafts after being edited. The following
operations can be performed on messages in Drafts:
Forward: Forward the selected message.
Delete: Delete the current MMS message.
Delete All: Delete all the MMS messages in the Drafts.
Lock/Unlock: When in locked mode, message cannot be deleted.
5.2.3.5 Sent
MMS messages there were successfully sent are stored in Sent. The following operations
can be performed on messages in Sent
22
Send Again: Resend the selected MMS message.
Forward: Forward the selected message.
Delete: Delete the current MMS message.
Delete All: Delete all the MMS messages in the Inbox.
Lock/Unlock: When in locked mode, message cannot be deleted.
5.2.3.6 Templates
Edited MMS messages can be stored in Templates.
5.2.3.7 Settings
This menu allows you to make the following settings to the configuration for sending and
receiving messages.
1. Profile: Select a USCC Primary or USCC Secondary Network.
2. Send:
2.1 Deliver Report：Set the deliver Report to ON or OFF.
2.2 Save sent items: Set the save sent items to ON or OFF.
2.3 Priority: Select a low ,Normal or high the priority.
2.4 Validity period: Set the validity period as Maximum,1 week,2 days,1 day,12 hours,1
hours;
2.5 Delivery time: Set the delivery time as Immediate, 1 hour, 3 hours, 6 hours, or 12
hours.
2.6 Auto-deletion: Set the auto deletion to ON or OFF.
2.7 Message class: Set to Personal, Auto, Advertisement or Information the Message
class.
2.8 Retry times: You can edit retry time ( 0-3).
3. Receive:
3.1 Send Delivery Report: Set the Send Delivery Report to ON or OFF.
3.2 Retrieval Mode: Set the retrieval mode as automatic or manual.
4. Edit Settings:
4.1 Signature: Set to ON or OFF the signature.
4.2 Slide Time: Set the switch time when previewing MMS message slideshows to 2
seconds, 5 seconds, 8 seconds, or 10 seconds.
5. View Mode: Set the preview time to manual or automatic.
6. Memory Status: Display the use rate and storage space of received and sent MMS
messages.
7. Restore default: Restore settings to their defaults.
8. Save Picture Messages: Select the storage location as internal memory card or cell
phone.
9. Version : Display the MMS version.
23
5.3 Contacts
5.3.0.1 To enter a contact
1. From the Main Menu select the Contacts Icon
2. Select Create New Contact
3. Enter the contact information in the various fields
4. Select Save to store the contact information
5.3.0.2 To dial from your contacts list
1. From the Main Menu or Standby screen select the Contacts Icon
2. Select Contact List
3. Select the contact
4. Highlight the contact’s phone number you would like to dial
5. Press Answer/Send key to dial the phone number
24
In the Contacts menu from the Menu screen the following options are available:
5.3.1 Contact list
Display all contacts.
5.3.2 Create New Contacts
Allows the user to create new contacts in the contract book
5.3.3 Group
You can set 10 different groups.
5.3.4 Set Speed Dial
Enables the user to assign speed dial keys to a phone number in the contact list. Speed
dial number 1 is reserved for voice mail; 2 through 9 can be set by the user.
5.3.5 Memory info
Display the memory status of the phonebook in the phone.
25
5.4 Multimedia
Multimedia features can be accessed by selecting the Multimedia Icon.
5.4.1 Audio Player
The music player is provided for you to play all music file types stored on the cell phone or
storage card. Supported music file formats include: MP3, MIDI, AMR, AAC, WAV, and
QCP.
The music player interface icons are sequentially: Previous, Pause, Play, Stop, and Next.
You can move the cursor using the left and right keypad and then press the “OK” key to
perform an operation.
Press the left keypad to enter to options. The functions for the “Options” provided are as
follows:
• Hide Audio player：Lets you back to audio menu while the music playing
• Add To play List：Lets you add currents music to play list.
• Listen By Bluetooth： Lets you hear the music from BT handsfree device if connected,
• Send：Lets you send to other device by bluetooth
• Set To：You will set current playing music to ringtone.
• Manager：Lets you delete current music
• File Attributes：Lets you view the file detail
• Play Mode：You may set Repeat and Random to on/off
Note: When adding new music to the phone, select “Update Playlist” at the first “Option”
screen.)
When the Audio player is active, the buttons on the left side of the phone provide
Rewind/Previous Selection, Pause/Play and Forward/next Selection choices.
5.4.2 Camera
The camera is also accessible within this menu screen. See the section on Camera for
further details.
To activate the camera (from the standby mode) press the Camera key at the left
keyboard of the phone.
The camera can also be accessed from the menu screen by selecting the Camera Icon.
The camera can be accessed in either of three ways: simply by pressing the button on the
left of the phone, thru the main menu or thru the multimedia menu. Once you are in the
camera interface, you can use this feature to take pictures as you wish.
Select “Camera” to enter the interface.
Note: Please follow local laws and regulations when using this cell phone to take pictures.
26
5.4.3 Recorder
This feature allows the recording of voice through the phone’s microphone. The files will
be stored in the phone’s memory and the size of the file depends upon the amount of
memory available.
Standard functions in this feature are:
• Record
• Play
• Pause
• Stop
• Rewind
• Fast Forward
Note: Please obey all applicable laws when recording conversations.
5.4.4 Gallery
This phone provides memory space for use by the user. SD Micro cards (of optional
capacity) are also supported. You can use these features to easily manage the directories
and files of all forms stored on the cell phone or SD Micro card.
1. Enter Gallery
2. Go to “Phone” (or “Card” if available)
3. Select Open: Use this function to enter the root directory of the memory. Default
system directories, created data directories, and account files will be listed at the root
directory (the root directory will only contain system folders the first time the phone is
turned on or if the user has yet to create any directories).
4. Or click “Options” to access the following operations:
• Manage: The following actions can be performed on the files listed: copy, move,
delete, rename, and view properties. Add Option in the Manage menu:
• Mark
• New Directory
• Memory Status: Display available space and total capacity.
27
5.5 Browser
To access the Internet, Select WAP Icon from the main menu.
This feature allows your phone to browse the internet.
Home Page: A home page can be saved with each mode. When using WAP to browse,
the home page for this mode will first be accessed.
Enter URL: Enter the URL for the website to be connected.
Search: Highlight to select a search engine to perform searches, then enter text criteria To
search on and Enter key search words。
History: You can review the latest accessed web pages.
Bookmarks: Multiple bookmarks can be created. Enter the Options menu and you can
perform the following operations on Bookmarks:
Open: Log in to the selected web address.
Add bookmark: Add a new bookmark.
Delete bookmark: Delete the selected bookmark.
Delete all bookmarks: Delete all the bookmarks.
Edit bookmark: Edit the name and web address of the selected bookmark.
Lock bookmark: Lock the bookmark.
Details: View the details on the selected bookmark.
Reset: Restore default settings.
• Push Box: Store information on messages to notify the user about WAP site
messages.
• Save web pages: Use to save a page for reviewing the web page later.
• Advanced Options: Advanced options are primarily used to configure certain internet
parameters and information.
• About: Display browser and platform version numbers.
• Exit Browser: Exit the browser and return to the menu interface.
28
5.6 Games & Apps
Easyedge
This phone provides access to the BREW ™ (binary runtime environment for wireless)
catalogue downloading feature. The BREW Shop lets users browse the carrier's
Application Download Server to see what applications are available for purchase or trial.
From the main menu screen, select the Download Icon.
Within the Download menu, there are two options:brew and My apps feature.
Within the Downloads, you can select Browse catalog or Search.
Within the Settings menu, you can select Order Apps, Move Apps, Manage Apps, Main
Menu View, Screen Savers or View Log.
29
5.7 Tools & Utilities
Select the Tools & Utilities Icon from the main menu, and then select Tools or Utilities.
5.7.1 Alarm
You may set up to 6 alarms.
1. Press the up and down-navigation key in the tools main menu and select Alarm.
2. Press the up and down-navigation key to select one of the alarms and press the left
soft key to access the alarm setting.
3. Press the left and right-navigation key in the alarm clock setting interface to select
alarm clock setting content. You may set the alarm clock using State (On/Off), Time, Mode
and Prompt.
4. The AM/PM is set by pressing the center of the navigation keys.
5. When you have selected and set each item, press the up and down-navigation key to
select the next line; when you have selected time, you can input the time directly.
5.7.2 Bluetooth
Please See 5.8
5.7.3 Calendar
You can view the current date or scroll the calendar to view other months.
You can also view weekly or daily calendar entries, by going to:
1. Select “Option”
2. Select Week View or Day View
5.7.4 Schedule
You may schedule an event into the calendar, with date, time and an alarm to notify you
of that event, by going to:
1. Scrolling to a date,
2. Select “Option”
3. Select “Make a note”
30
a. Type of event: Meeting, Birthday, Memo, etc.
b. Entering Subject, Location, Time, etc
c. Repeat, Alarm, Alarm Date
d. Done
e. Save
5.7.5 Notes
Lets you create, edit, delete, mark, note.
1. At the UI of new notes，the above textbox used for input content of note, the below info
item used for modify mark and types of notes, when under unmark mode, use Enter
button to switch. when under mark mode, use left/right key to modify the type of note,
use up/down key to modify the mark of note.
2. When input content, press left soft key then select “Advanced input”, you can select
much more input method, including Intelligent English input method.
3.In All Notes option you can select ：Create Note, This note (including Edit, Delete, Mark,
Send via Bluetooth, Mark mode，Memory status；
5.7.6 Calculator
The Calculator can perform four standard operations (add, subtract, multiply, divide). Use
0-9 keys to input a value.
The layout of the calculator matches the keypad, so that multiplication is shown with the
“*” key, the enter key is the Left Soft Key sign, addition is with the “+” key and so on. You
can also press the navigation keys to select one of the four operations: add, subtract,
multiply and divide.
1. Press the number keys to enter a value
2. Select an operation
3. Press numeric keys to input the second operation value
4. Select the = key. The result will be displayed on the screen.
To perform multiple mathematical operations, you must press equal (=) after each
operation.
5.7.7 Stopwatch
This unit provides two stopwatch functions: common mode and loop mode.
The Common Mode is a simple stopwatch, on/off and reset.
1. Press “Select” to start timing.
2. Press Select or left soft key to stop.
3. Press again to continue timing. If there is a time noted, press the right soft key to
clear.
The Loop Mode is so that additional time segments can be added, started and stopped to
31
record various activities within the event. The “add” button adds another loop while
recording the previous loop’s time.
5.7.8 World Time
To view the time in different locations of the world, scroll right/left across the map.
5.7.9 Unit Converter
Unit Converters lets you easily convert between different units of measurement
5.7.10 Ez Tip Calc
Ez Tip Calc allows you to split your bill.
there is a somewhat easy way to calculate the tip.
15% = 10% + 5%. So what you need to do is figure out 10% then add half (5%).
10% is very easy to calculate, you just move the decimal place one to the left. For
example, if the bill is $25.00 then 10% would be $2.50.
Then to figure out 5%, just take half of that, which would be $1.25.
Now you have 10% which is $2.50 and 5% which is $1.25, add them together for a total of
$3.75.
Often, the bill ends up at some obscure value such as $17.73, which may be a bit difficult
to calculate using the above method. In cases like that, just round it to the nearest dollar. It
would be much easier to calculate the tip for $18.00.
32
5.8 Bluetooth
The Bluetooth features of the phone can be accessed by selecting the Bluetooth Icon from the
menu screen.
5.8.1 Turn Blue tooth on/off
1. Select Turn blue tooth on/off: Enable/Disable Bluetooth..
5.8.2 To set up a new Bluetooth device
1. Select Device Search: When a Bluetooth device is enabled, all Bluetooth hands free
devices and Bluetooth devices will be searched for. Bluetooth devices are then added and
paired.
2. After detecting a Bluetooth hands free device, a Bluetooth password must be entered
to perform the pairing. (Bluetooth passwords are set by other Bluetooth devices.)
3. Once pairing completes, it will connect with the device.
5.8.3 Discoverable
Enable this function find devices within three minutes.
5.8.4 Found Devices: Display detected devices.
5.8.5 Manage
List the devices connect to the cell phone. Bluetooth hands free devices and Bluetooth
devices can be deleted and configured.
Pair: Pair with the device selected.
Remove: Remove the selected device from the list.
Browse Files: When browsing files, the selected device must be successfully paired.
Setup Bluetooth: Enable and disable Bluetooth, rename, and device status.
33
5.9 Settings
Settings features can be accessed from the menu screen by selecting the Settings icon
from the main menu.
5.9.1 Profiles
The Profiles setting is used to customize the phone’s alerts and ringtones. To select and
personalize the Profile settings, select the Profiles icon from the main menu.
There are five predefined profile settings which can be customized: Normal, Loud, Vibrate,
Silent, and Airplane Mode.
Note: in Airplane Mode, please consult airline staff about the use of Airplane Mode in flight.
Turn off your phone whenever instructed to do so by airline staff. Airplane Mode turns off
your phone’s calling features in locations where wireless phone use is prohibited. You
cannnot make or receive calls in Airplane Mode, but you can use your phone’s other
non-calling features
5.9.1.1 Activate
Set to be current active profile.
5.9.1.2 Personalize
You are able to customize the following settings for each of the above choices:
Incoming call alert: Alert method for incoming calls.
Voice volume: Set the speaker volume.
Ringtone: Select the incoming ring tone.
Ring volume: Set the ring volume for incoming calls.
Vibrating alert: Select whether or not to enable vibration.
Message alert tone: Select the text message alert tone.
Roaming Ringtone
Keypad tone: Set the keypad tone.
Auto Answer: Set auto answer time.
Speakerphone: Select whether or not to enable the speaker.
34
5.9.2 Phone Setup
Language: Choose English or French
Greeting: Switch between Enable and Disable. The greeting is shown when the phone is
powered on and can be edited by highlighting the current greeting and pressing the left
soft/menu
Clock Format: Set between 12 hour (w/AM and PM) or 24 hour..
Location: Select Location on or 911 Only
USB Disk Mode: Enables the transfer of date between a PC and the installed microSD
card on the phone using the data cable.
5.9.3 Display Setup
Wallpaper: Select a picture as the background image on the phone.
LCD Backlight: The backlight time can be set to turn off after 10, 20, or 30 seconds. It
can also be set to always on, however the longer a backlight is on the faster the battery
will drain.
Brightness: You can select the brightness level of the LCD backlight using the left/right
navigation key.
Main Menu: You can set the main menu Icon or List mode.
Themes: The unit provides three themes.
5.9.4 Call Setup
Answer Options: You can select Flip Open, Any Key or Send Only to answer a call.
Emergency Alert: You can select Ring& Vibrate mode or Vibrate Only mode.
Call Duration Reminder: Set the reminder to sound during calls at 5 seconds, 30 seconds,
60seconds, or off.
Call Connect Notification: If this feature is turned on, then a notification will sound each
time a call is connected.
Blacklist: You can set up a blacklist. After enabling the blacklist, the phone numbers listed
in the blacklist will not be able to call this phone.
o Status: Disable/Enable.
o Blacklist List: Up to nine blacklisted entries can be added. You can edit the list
through this menu.
TTY Mode: This menu lists as TTY Off, TTY Full, TTY VCO,TTY HCO,TTY Debug.
35
5.9.5 Security Setup
To make changes in the Security menu, you must correctly input the phone password.
The initial password is 1234.
Phone Lock: If “Enabled”, when the phone is powered on you will be prompted to enter the
phone’s password correctly to use the phone.
Keypad Lock: The keypad lock can be set to be enabled after 5 seconds, 30 seconds, 60
seconds, or 5 minutes. To unlock the keypad, press “*” then the Answer/Send key.
Even when locked, you may answer an incoming call.
Call History Lock: If enabled the phone will require the password to be entered each time
you access the phone’s Call History.
Phonebook Lock: If enabled, the phonebook cannot be viewed until the password is
entered.
Message Lock: If enabled, the phone will require the password to be entered to access
messages.
Change Password: Change the password using this option. The Old Password must be
entered before a new one is accepted. Enter the same new password twice and press the
left soft/menu key to confirm. The new password will then become effective. During this
course you may press the right soft key to discard the change at any time and return to
higher-level menu. You can create separate passwords for the phone lock, the call history
lock, the phonebook lock, and the message lock.
Restore Factory Settings: This function is used for restoring to the default factory settings.
5.9.6 Phone Info
Displays the information about the phone.
1. Base Phone Information.
2. Icon Glossary
3. Operating System
4. Warranty Code
5. Refurbish
6 SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
READ THIS INFORMATION BEFORE USING YOUR
36
HANDHELDPORTABLE CELLULAR TELEPHONE
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio transmitter and receiver.
When it is ON, it receives and also sends out radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC) adopted RF
exposure guidelines with safety levels for handheld wireless phones. Those guidelines
are consistent with the safety standards previously set by both U.S. and international
standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations of the relevant
scientific literature. For example, over 120 scientists, engineers, and physicians from
universities, government health agencies, and industry reviewed the availablebody of
research to develop the ANSI Standard (C951).
The design of your phone complies with the FCC guidelines (and those standards).
1*: American National Standards Institute.
2*: National Council on Radiation protection and measurements.
3*: International Commission on Nonionizing Radiation Protection.
ANTENNA SAFETY
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could impair call quality, damage the phone, or result in
violation of FCC regulations. Please contact your local dealer for replacement antenna.
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact
with the skin, a minor burn may result. Please contact your local dealer for replacement
antenna.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in some states.
Remember, safety comes first. Check the laws and regulations on the use of phones in
the areas where you drive. Always obey them. Also, if using your phone while driving,
please:
Give full attention to driving. Driving safely is your first responsibility.
Use hands-free operation, if available.
Pull off the road and park before making or answering a call, if driving conditions so
require.
If you must use the phone while driving, please use one-touch, speed dialing, and auto
37
answer
modes. An airbag inflates with great force. DO NOT place objects, including both installed
or portable wireless equipment, in the area over the airbag or in the air bag deployment
area. If in-vehicle wireless equipment is improperly installed and the air bag inflates,
serious injury could result.
WARNING: Failure to follow these instructions may lead to serious personal injury and
possible property damage.
ELECTRONIC DEVICES
Your wireless handheld portable telephone is a low power radio transmitter and receiver.
When it is
ON, it receives and also sends out radio frequency (RF) signals.Most modern electronic
equipment is shielded from RF energy. However, certain electronic equipment may not be
shielded against the RF signals from your wireless phone. Therefore, use of your phone
must be restricted in certain situations.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a minimum separation
of six (6”) inches be maintained between a handheld wireless phone and a pacemaker to
avoid potential interference with the pacemaker. These recommendations are consistent
with the independent research by and recommendations of Wireless Technology
Research. Persons with pacemakers:
Always keep the phone more than six inches from your pacemaker when the phone is
turned on.
Do not carry the phone in a breast pocket.
Use the ear opposite the pacemaker to minimize the potential for interference.
If you have any reason to suspect that interference is taking place, turn your phone OFF
immediately.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of such
interference, you may want to consult your service provider (or call the customer service
line to discuss alternatives).
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of your device to
determine if they are adequately shielded from external RF energy. Your physician may be
able to assist you in obtaining this information.
Turn your phone OFF in healthcare facilities when any regulations posted in these areas
instruct you to do so. Hospitals or healthcare facilities may be using equipment that could
be sensitive to external RF energy.
38
VEHICLES
RF signals may affect improperly installed or inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or its representative regarding your vehicle.
You should also consult the manufacturer of any equipment that has been added to your
vehicle.
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC regulations prohibit using your phone while in the air. Turn your phone OFF before
boarding an aircraft. Always request and obtain prior consent and approval of an
authorized airline representative before using your phone aboard an aircraft. Always
follow the instructions of the airline representative whenever using your phone aboard an
aircraft, to prevent any possible interference with airborne electronic equipment.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF when in a “blasting
area” or in areas posted: “Turn off two-way radio.” Obey all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive atmosphere and obey
all signs and instructions. Sparks in such areas could cause an explosion or fire resulting
in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked.
They include fueling areas such as gas stations; below deck on boats; fuel or chemical
transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as grain, dust, or metal
powders; and any other area where you would normally be advised to turn off your
vehicle’s engine.
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of equipment. Before operating,
read all instructions and cautionary markings on (1) AC/DC Travel Adaptor (2) Battery and
(3) Product Using Battery.
Failure to follow the directions below could result in serious bodily injury and/or property
damage due to battery liquid leakage, fire or rupture.
DO NOT use this equipment in an extreme environment where high temperature or high
humidity exists.
39
DO NOT abuse the equipment. Avoid striking, shaking or shocking. When not using, lay
down the unit to avoid possible damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the phone or its accessories. If service or repair is required, return
unit to an authorized PCD cellular service center. If unit is disassembled, the risk of
electric shock or fire may result.
DO NOT short-circuit the battery terminals with metal items etc.
6.1 SAFETY INFORMATION FOR FCC RF EXPOSURE
WARNING! READ THIS INFORMATION BEFORE USING
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of the United States
with its action in Report and Order FCC 96-326 adopted an updated safety standard for
human exposure to radio frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard previously set by
both U.S. and international standards bodies. The design of this phone complies with the
FCC guidelines and these international standards.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the back of the phone kept
1.5 cm. from the body. To maintain compliance requirements, use only belt-clips,
holsters or similar accessories that maintain a 1.5 cm separation distance between the
user’s Body and the back of the phone, including the antenna. The use of belt-clips,
holsters and similar accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may not comply with FCC
RF exposure requirements, and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov.
6.2 SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the
40
Federal Communications Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6
W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station antenna, the lower the power
output. Before a phone model is available for sale to the public, it must be tested and
certified to the FCC that it does not exceed the limit established by the government
adopted requirement for safe exposure. The tests are performed in positions and
locations (e.g., at the ear and worn on the body) as required by the FCC for each model.
The highest SAR value for this model phone when tested for use at the ear is 0.95 W/Kg
and when worn on the body, as described in this user guide, is 0.66 W/ Kg. (Body-worn
measurements differ among phone models, depending upon available accessories and
FCC requirements). While there may be differences between the SAR levels of various
phones and at various positions, they all meet the government requirement for safe
exposure.
The SAR testing for Body-worn operation was performed with a belt clip that provided a
15mm separation. The User’s Manual indicates that any holsters/clips used with this
device should contain no metallic components.
The FCC has granted an Equipment Authorization for this model phone with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and can be found under the
Display Grant section of http://www.fcc.gov/oet/ea after searching on U46-CDM2035.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular
Telecommunications Industry Association (CTIA) web-site at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones used by the public is
1.6 W/kg (W/kg) averaged over one gram of tissue. The standard incorporates a
sub-stantial margin of safety to give additional protection for the public and to account
for any variations in measurements.
41
6.3 HEARING AID COMPATIBILITY HAC FOR WIRELESS
TELECOMMUNICATIONS DEVICES
PCD’S COMMITMENT
PCD believes that all of our customers should be able to enjoy the benefits of digital
wireless technologies. We are committed to providing a selection of compatible devices
for our customers who wear hearing aids.
THIS PHONE HAS A HAC RATING OF M3/T3 WHAT IS
HEARING AID COMPATIBILITY?
The Federal Communications Commission has implemented rules and a rating system
designed to enable people who wear hearing aids to more effectively use these wireless
telecommunications devices. The standard for compatibility of digital wireless phones
with hearing aids is set forth in American National Standard Institute (ANSI) standard
C63.19. There are two sets of ANSI standards with ratings from one to four (four being
the best rating): an “M” rating for reduced interference making it easier to hear
conversations on the phone when using the hearing aid microphone, and a “T” rating
that enables the phone to be used with hearing aids operating in the telecoil mode thus
reducing unwanted background noise.
HOW WILL I KNOW WHICH WIRELESS PHONES ARE
HEARING AID COMPATIBLE?
The Hearing Aid Compatibility rating is displayed on the wireless phone box.
A phone is considered Hearing Aid Compatible for acoustic coupling (microphone mode)
if it has an “M3” or “M4” rating. A digital wireless phone is considered Hearing Aid
Compatible for inductive coupling (telecoil mode) if it has a “T3” or “T4” rating.
HOW WILL I KNOW IF MY HEARING AID WILL WORK WITH A
PARTICULAR DIGITAL WIRELESS PHONE?
You’ll want to try a number of wireless phones so that you can decide which works the
best with your hearing aids. You may also want to talk with your hearing aid professional
about the extent to which your hearing aids are immune to interference, if they have
wireless phone shielding, and whether your hearing aid has a HAC rating.
FOR MORE INFORMATION ABOUT HEARING AIDS AND
DIGITAL WIRELESS PHONE
42
FCC Hearing Aid Compatibility and Volume Control –
http://www.fcc.gov/cgb/dro/hearing.html
Hearing Loss Association of America –
http://www.hearingloss.org/learn/cellphonetech.asp
CTIA – http://www.accesswireless.org/hearingaid/
Gallaudet University, RERC – http://tap.gallaudet.edu/voice
6.4 FDA CONSUMER UPDATE
U.S. FOOD AND DRUG ADMINISTRATION - CENTER
FOR DEVICES AND RADIOLOGICAL HEALTH CONSUMER
UPDATE ON WIRELESS PHONES
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are associated
with using wireless phones. There is no proof, however, that wireless phones are
absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the
microwave range while being used. They also emit very low levels of RF when in the
stand-by mode. Whereas high levels of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures have not found any biological
effects. Some studies have suggested that some biological effects may occur, but such
findings have not been confirmed by additional research. In some cases, other
researchers have had difficulty in reproducing those studies, or in determining the reasons
for inconsistent results.
2. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation-emitting consumer products
such as wireless phones before they can be sold, as it does with new drugs or medical
devices. However, the agency has authority to take action if wireless phones are shown to
emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case,
FDA could require the manufacturers of wireless phones to notify users of the health
hazard and to repair, replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions, FDA has urged
the wireless phone industry to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user
43
that is not necessary
for device function; and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that
have responsibility for different aspects of RF safety to ensure coordinated
efforts at the federal level. The following agencies belong to this working
group:
National Institute for Occupational Safety and Health
Environmental Protection Agency
Federal Communications Commission
Occupational Safety and Health Administration
National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group activities,
as well. FDA shares regulatory responsibilities for wireless phones with the Federal
Communications Commission (FCC). All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF exposure. FCC relies on FDA and other
health agencies for safety questions about wireless phones. FCC also regulates the base
stations that the wireless phone networks rely upon. While these base stations operate at
higher power than do the wireless phones themselves, the RF exposures that people get
from these base stations are typically thousands of times lower than those they can get
from wireless phones. Base stations are thus not the subject of the safety questions
discussed in this document.
3. What kinds of phones are the subjects of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell”, “mobile,” or “PCS” phones. These types of wireless phones
can expose the user to measurable radiofrequency energy (RF) because of the short
distance between the phone and the user’s head. These RF exposures are limited by
Federal Communications Commission safety guidelines that were developed with the
advice of FDA and other federal health and safety agencies. When the phone is located
at greater distances from the user, the exposure to RF is drastically lower because a
person’s RF exposure decreases rapidly with increasing distance from the source. The
so-called “cordless phones,” which have a base unit connected to the telephone wiring
in a house, typically operate at far lower power levels, and thus produce RF exposures
far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies have
suffered from flaws in their research methods. Animal experiments investigating the
effects of radiofrequency energy (RF) exposures characteristic of wireless phones have
44
yielded conflicting results that often cannot be repeated in other laboratories. A few
animal studies, however, have suggested that low levels of RF could accelerate the
development of cancer in laboratory animals.
However, many of the studies that showed increased tumor development used animals
that had been genetically engineered or treated with cancer-causing chemicals so as to
be predisposed to develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These conditions are not similar
to the conditions under which people use wireless phones, so we don’t know with
certainty what the results of such studies mean for human health. Three large
epidemiology studies have been published since December 2000. Between them, the
studies investigated any possible association between the use of wireless phones and
primary brain cancer, glioma, meningioma, or acoustic neu-roma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the studies demonstrated the
existence of any harmful health effects from wireless phone RF exposures. However,
none of the studies can answer questions about long-term exposures, since the average
period of phone use in these studies was around three years.
5. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually using
wireless phones would provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years. However, very large numbers of
animals would be needed to provide reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is directly applicable to human
populations, but 10 or more years’ follow-up may be needed to provide answers about
some health effects, such as cancer. This is because the interval between the time of
exposure to a cancer-causing agent and the time tumors develop - if they do -may be
many, many years. The interpretation of epidemiological studies is hampered by
difficulties in measuring actual RF exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the angle at which the phone is held, or
which model of phone is used.
6. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are conducted
to address important questions about the effects of exposure to radiofrequency energy
(RF). FDA has been a leading participant in the World Health Organization International
Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda of research needs that has
45
driven the establishment of new research programs around the world. The Project has
also helped develop a series of public information documents on EMF issues. FDA and
the Cellular Telecommunications & Internet Association (CTIA) have a formal
Cooperative Research and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific oversight, obtaining input from experts
in government, industry, and academic organizations. CTIA-funded research is
conducted through contracts to independent investigators. The initial research will
include both laboratory studies and studies of wireless phone users. The CRADA will
also include a broad assessment of additional research needs in the context of the latest
research developments around the world.
7. How can I find out how much radiofrequency energy
exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health and
safety agencies. The FCC limit for RF exposure from wireless telephones is set at a
Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/ kg). The FCC limit is
consistent with the safety standards developed by the Institute of Electrical and
Electronic Engineering (IEEE) and the National Council on Radiation Protection and
Measurement. The exposure limit takes into consideration the body’s ability to remove
heat from the tissues that absorb energy from the wireless phone and is set well below
levels known to have effects. Manufacturers of wireless phones must report the RF
exposure level for each model of phone to the FCC. The FCC website
(http://www.fcc.gov/oet/rfsafety) gives directions for locating the FCC identification
number on your phone so you can find your phone’s RF exposure level in the online
listing.
8. What has FDA done to measure the radiofrequency energy
coming from wireless phones?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless phones
and other wireless handsets with the participation and leadership of FDA scientists and
engineers. The standard, “Recommended Practice for Determining the Spatial-Peak
Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications
Devices: Experimental Techniques,” sets forth the first consistent test methodology for
measuring the rate at which RF is deposited in the heads of wireless phone users. The
test method uses a tissue-simulating model of the human head. Standardized SAR test
methodology is expected to greatly improve the consistency of measurements made at
46
different laboratories on the same phone. SAR is the measurement of the amount of
energy absorbed in tissue, either by the whole body or a small part of the body. It is
measured in watts/ kg (or milliwatts/g) of matter. This measurement is used to determine
whether a wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products—and at this point we do not know that there is—it is
probably very small. But if you are concerned about avoiding even potential risks, you
can take a few simple steps to minimize your exposure to radiofrequency energy (RF).
Since time is a key factor in how much exposure a person receives, reducing the amount
of time spent using a wireless phone will reduce RF exposure.
• If you must conduct extended conversations by wireless phone every day, you could
place more distance between your body and the source of the RF, since the exposure
level drops off dramatically with distance.
For example, you could use a headset and carry the wireless phone away from your
body or use a wireless phone connected to a remote antenna. Again, the scientific data
do not demonstrate that wireless phones are harmful. But if you are concerned about the
RF exposure from these products, you can use measures like those described above to
reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones, including
children and teenagers. If you want to take steps to lower exposure to radiofrequency
energy (RF), the measures described above would apply to children and teenagers
using wireless phones. Reducing the time of wireless phone use and increasing the
distance between the user and the RF source will reduce RF exposure. Some groups
sponsored by other national governments have advised that children be discouraged
from using wireless phones at all. For example, the government in the United Kingdom
distributed leaflets containing such a recommendation in December 2000. They noted
that no evidence exists that using a wireless phone causes brain tumors or other ill
effects. Their recommendation to limit wireless phone use by children was strictly
precautionary; it was not based on scientific evidence that any health hazard exists.
11. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can interact with some electronic
47
devices. For this reason, FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators
from wireless telephones. This test method is now part of a standard sponsored by the
Association for the Advancement of Medical instrumentation (AAMI). The final draft, a
joint effort by FDA, medical device manufacturers, and many other groups, was
completed in late 2000. This standard will allow manufacturers to ensure that cardiac
pacemakers and defibrillators are safe from wireless phone EMI. FDA has tested
hearing aids for interference from handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and performance requirements for hearing
aids and wireless phones so that that no interference occurs when a person uses a
“compatible” phone and a “compatible” hearing aid at the same time. This standard was
approved by the IEEE in 2000. FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should harmful interference be found
to occur, FDA will conduct testing to assess the interference and work to resolve the
problem.
12. Where can I find additional information?
For additional information, please refer to the following resources:
FDA web page on wireless phones (http://www.fda.gov/cellphones)
Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
International Commission on Non-Ionizing Radiation Protection
(http://www.icnirp.de)
World Health Organization (WHO) International EMF Project
(http://www.who.int/emf )
Health Protection Agency (UK) (http://www.hpa.org.uk/radiation/)
6.5 AVOID POTENTIAL HEARING LOSS
Prolonged exposure to loud sounds (including music) is the most common cause of
preventable hearing loss. Some scientific research suggests that using portable audio
devices, such as portable music players and cellular telephones, at high volume settings
for long durations may lead to permanent noise-induced hearing loss. This includes the
use of headphones (including headsets, earbuds and Bluetooth® or other wireless
devices). Exposure to very loud sound has also been associated in some studies with
tinnitus (a ringing in the ear), hypersensitivity to sound and distorted hearing. Individual
susceptibility to noise-induced hearing loss and other potential hearing problems varies.
The amount of sound produced by a portable audio device varies depending on the
nature of the sound, the device, the device settings and the headphones. You should
follow some commonsense recommendations when using any portable audio device:
48
Set the volume in a quiet environment and select the lowest volume at which you
can hear adequately.
When using headphones, turn the volume down if you cannot hear the people
speaking near you or if the person sitting next to you can hear what you are
listening to.
Do not turn the volume up to block out noisy surroundings. If you choose to listen
to your portable device in a noisy environment, use noise-cancelling
headphones to block out background environmental noise.
Limit the amount of time you listen. As the volume increases, less time is
required before your hearing could be affected.
Avoid using headphones after exposure to extremely loud noises, such as rock
concerts, that might cause temporary hearing loss. Temporary hearing loss
might cause unsafe volumes to sound normal.
Do not listen at any volume that causes you discomfort. If you experience ringing
in your ears, hear muffled speech or experience any temporary hearing
difficulty after listening to your portable audio device, discontinue use and
consult your doctor.
YOU CAN OBTAIN ADDITIONAL INFORMATION ON THIS
SUBJECT FROM THE FOLLOWING SOURCES:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: 800-AAA-2336
Email: info@audiology.org
Internet: www.audiology.org
National Institute on Deafness and Other Communication Disorders National Institutes of
Health
31 Center Drive, MSC 2320
Bethesda, MD USA 20892-2320
Voice: (301) 496-7243
Email: nidcdinfo@nidcd.nih.gov
Internet: http://www.nidcd.nih.gov/health/hearing
National Institute for Occupational Safety and Health
Hubert H. Humphrey Bldg.
200 Independence Ave., SW
Washington, DC 20201
Voice: 1-800-CDC-INFO (1-800-232-4636)
49
Internet: http://www.cdc.gov/niosh/topics/noise/default.html
6.6 FCC COMPLIANCE INFORMATION
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received. Including interference that
may cause undesired operation.
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful Interference in a residential installation This
equipment generates, uses, and can radiate radio frequency energy and, if Not installed
and used in accordance with the instructions, may cause harmful Interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular Installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna. Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet of a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for assistance.
CAUTION: Changes or modification not expressly approved by the party responsible for
Compliance could void the user’s authority to operate the equipment. Connecting of
peripherals requires the use of grounded shielded signal cables.
6.7 12 MONTH LIMITED WARRANTY
Personal Communications Devices, LLC. (the “Company”) warrants to the original retail
purchaser of this handheld portable cellular telephone, that should this product or any
part thereof during normal consumer usage and conditions, be proven defective in
material or workmanship that results in product failure within the first twelve (12) month
period from the date of purchase, such defect(s) will be repaired or replaced (with new or
rebuilt parts) at the Company’s option, without charge for parts or labor directly related to
50
the defect(s).
The antenna, keypad, display, rechargeable battery and battery charger, if included, are
similarly warranted for twelve (12) months from date of purchase. This Warranty extends
only to consumers who purchase the product in the United States or Canada and it is not
transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident, mishandling, neglect,
unauthorized alteration, misuse, improper installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number has been
removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive temperatures or extreme
environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or other product not
approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such as framing
and non-operative parts;
(f ) Product damaged from external causes such as fire, flooding, dirt, sand, weather
conditions, battery leakage, blown fuse, theft or improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the product, for geographic
coverage, for inadequate signal reception by the antenna or for communications range or
operation of the cellular system as a whole.
When sending your wireless device to Personal Communications Devices for repair or
service, please note that any personal data or software stored on the device may be
inadvertently erased or altered. Therefore, we strongly recommend you make a back up
copy of all data and software contained on your device before submitting it for repair or
service. This includes all contact lists, downloads (i.e. third-party software applications,
ringtones, games and graphics) and any other data added to your device. In addition, if
your wireless device utilizes a SIM or Multimedia card, please remove the card before
submitting the device and store for later use when your device is returned, Personal
Communications Devices is not responsible for and does not guarantee restoration of any
third-party software, personal information or memory data contained in, stored on, or
integrated with any wireless device, whether under warranty or not, returned to Personal
Communications Devices for repair or service.
To obtain repairs or replacement within the terms of this Warranty, the product should be
delivered with proof of Warranty coverage (e.g. dated bill of sale), the consumer’s return
address, daytime phone number and/or fax number and complete description of the
problem, transportation prepaid, to the Company at the address shown below or to the
place of purchase for repair or replacement processing. In addition, for reference to an
authorized Warranty station in your area, you may telephone in the United States (800)
229-1235, and in Canada (800) 465-9672 (in Ontario call 416-695-3060).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED
TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT,
SHALL THE COMPANY’S LAIBILITY EXCEED THE PURCHASE PRICE PAID BY
PURCHASER FOR THE PRODUCT.
51
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE
LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR
BREACH OF ANY WARRANTY MUST BE BROUGHT WITHIN A PERIOD OF 18
MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE
COMPANY BE LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY
IN RENDERING SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE
TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company any liability other
than expressed herein in connection with the sale of this product.
Some states or provinces do not allow limitations on how long an implied warranty lasts
or the exclusion or limitation of incidental or consequential damage so the above
limitation or exclusions may not apply to you. This Warranty gives you specific legal rights,
and you may also have other rights, which vary from state to state or province to
province.
IN USA: Personal Communications Devies,LLC.
555 Wireless Blvd.
Hauppauge,New York 11788
(800)229-1235
IN CANADA: Personal Communications Canada Ltd
5535 Eglinton Avenue West,Suite 234
Toronto, Ontario
M9C 5K5
(800)465-9672
