1. RF UNIT TECHNICAL CHARACTERISTICS
Functional characteristics:
Frequency bands: 380-400, 410-430, 450-470, 764-806, 806-870 MHz.
Transmit offset frequency: -30 MHz for 764-806 MHz band; 45 MHz for 806-870
MHz band; any for other frequency bands.
Channel spacing: 6.25KHz, 12.5Khz or 25KHz.
Frequency Division Multiple Access (FDMA): 1 physical channel per carrier.
Modulation: Analog FM / C4FM.
Emissions Designator:
WB analog: 16K0F3E.
NB analog: 11K0F3E.
Digital: 8K10F1W.
Data bit rate: 9.6 Kbits/s.
Ethernet interface: IEEE 802.3u,x.
RF Unit is hot swap as a unit, but individual modules (RPS, RPA P25, RTX P25,
RRX P25, BSYNC, RCPU P25) are not.
Electrical characteristics:
Nominal voltage: 26,4Vdc (21.1 – 31.7 Vdc).
Consumption: 500 W maximum.
Transmitter:
RF Output Power: 100 Watt (+50dBm). Adjustable in 2dB steps.
Transmitter Frequency Range: 380 - 400, 410 - 430, 450 - 470, 764 - 776,
851 - 870 MHz.
Frequency Accuracy: ±0.1 ppm.
Spurious Emissions: < -70 dBc.
Adjacent Channel Power (ACP) Ratio: > 67dB.
Inter-modulation attenuation: > 40dB.
Modulation Limiting (Analog):
25KHz Channels ±5KHz
12.5KHz Channels ±2.5KHz
Modulation Fidelity (Digital): < 5% (Class A).
Receiver:
Receiver Frequency Range: 380 - 400, 410 - 430, 450 - 470, 764 - 776, 806 -
825 MHz.
Sensitivity: -119dBm (0.25uV) (Class A).
Faded Sensitivity: < -108dBm (Class A).
Selectivity:
25KHz Channels > 75dB (Class A).
12.5KHz Channels > 60dB (Class A).
Co-Channel Rejection: > 9dB.
Spurious response rejection: > 75dB.
Intermodulation response rejection: >75dB.
Unwanted conducted emissions: < -57dBm.
RF Unit
CHARACTERISTICS
Code: D168X01_DDS06
Date: 09/10/08 Page: 5 of 5
01.01.00/1 Rev.1
Data rate:
Ethernet interface: bandwidth for dimensioning WAN link between Master Site
P25 and Repeater Site P25: 40 Kbps.
Ethernet interface: bandwidth for dimensioning Repeater Site P25 LAN: 60 Kbps.
Environmental characteristics:
Operating Temperature Range: -30ºC to +60ºC (-22ºF to +140ºF).
Storage Temperature Range: -40ºC to +85ºC (-40ºF to +185ºF).
Humidity.0 to 90% RH @ 50ºC (122ºF).
Mechanical characteristics:
Dimensions (Length x Height x Width): 379mm x 133mm(3U) x 483mm.
Weight: 10250 gr. (10500 gr. with BSYNC).
RF Unit is assembled in a 19”-wide 3U-high rack.
