User Manual
Model 3 Key Fob
User Manual
Declarations of Conformity
FCC Certification
Component
Mfr
Operating
Tested For
FCC ID
Freq (MHz)
Key Fob
Tesla
13.56 and
US
2AEIM-1133148
1133148
2400
Canada
20098-1133148
Per FCC ID 2AEIM-1133148 the Model 3 key fob listed above comply with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by Tesla could void your authority to operate the
equipment.
Important Note:
FCC Radiation Exposure: This equipment complies with FCC radiation exposure limits for an
uncontrolled environment.
Caution: This equipment and its antennas must not be co-located or operated with any other antenna
or transmitter.
IC Certification
The following device components are used in vehicles in Canada:
• Device Component Numbers: 1133148
• Device Manufacturer: Tesla
Per 20098-1133148, this device complies with Industry Canada's license-exempt RSS standard(s). Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause
undesired operation.
IMPORTANT NOTE: IC Radiation Exposure Statement
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment.
Cet équipement est conforme aux limites d’exposition aux rayonnements IC établies pour
unenvironnement non contrôlé.
CAN ICES-3 (B)/NMB-3(B).
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts
de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareilne doit pas produire
de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre lefonctionnement.
156 Model 3 Owner's Manual
Declarations of Conformity
Radio Frequency Information
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Consumer Information 157
This Key fob is used for user that don’t want to use phone nor NFC card to unlock their car.
It contains three bottoms that able to unlock the frunk, door and trunk.
Battery for the key fob is CR 2032
Two Types of Keys
Instead of a key fob, Model 3 supports two
types of keys:
•Authenticated phone - communicates
with Model 3 using Bluetooth. Supports
automatic locking and unlocking as well as
several other functions using the Tesla
mobile app. An authenticated phone is the
preferred key because you never need to
remove it from your pocket or purse.
•Key card - communicates with Model 3
short range radio-frequency identification
(RFID) signals. The key card is used to
"authenticate" your phone to work with
Model 3. In situations where your
authenticated phone has a dead battery,
or is lost or stolen, use your key card to
unlock, drive, and lock Model 3.
Phone
Using your phone is the most convenient way
to access your Model 3. As you approach, your
phone's Bluetooth signal is detected and
doors unlock when you press a door handle.
Likewise, when you exit and walk away with
the phone, doors automatically lock (provided
the Walk Away Lock feature is turned on, as
described in Walk Away Lock on page 10).
Before you can use a phone to access Model 3,
follow these steps to authenticate it:
1. Download the Tesla mobile app to your
phone.
2. Log into the Tesla mobile app using your
Tesla Account user name and password.
Note: You must remain logged in to your
Tesla Account to use your phone to access
Model 3.
3. Ensure that your phone's Bluetooth
setting is turned on.
Note: Model 3 communicates with your
phone using Bluetooth. To authenticate
your phone or use it as a key, the phone
must be powered on and Bluetooth must
be enabled. Keep in mind that your phone
must have enough battery power to run
Bluetooth and that many phones disable
Bluetooth when the battery is low.
4. Ensure that Allow Mobile Access
(Controls > Safety & Security > Settings >
Allow Mobile Access) is enabled.
5. In the Tesla mobile app, touch PHONE
KEY then touch START to search for your
Model 3.
When your Model 3 is detected, the
mobile app asks you to tap your key card.
6. Tap the key card against the Model 3 card
reader on the door pillar or center console
(see Key Card on page 7).
When Model 3 detects your key card, the
mobile app confirms that your phone has
been successfully authenticated. Touch DONE.
If the key card is not successfully scanned
within approximately 30 seconds, the mobile
app displays an error message. Touch PHONE
KEY on the app again to retry.
Model 3 can store up to 19 keys (authenticated
phones or key cards) simultaneously. To view a
list of keys that can currently access Model 3,
or to remove a phone, touch Controls > Locks
(see Managing Keys on page 7).
Note: Authenticating your phone allows you to
use it as a key to access Model 3. To use the
phone hands-free, access your phone's
contacts, play media from it, etc., you must
also pair and connect to it using the Bluetooth
settings (see Phone on page 93).
Note: Model 3 can connect to three phones
simultaneously. Therefore, if more than one
phone is detected and you want to use, or
authenticate, a dierent phone, move the
other connected phone(s) out of range or turn
o its Bluetooth setting.
Note: Unlike the mobile app, once a phone has
been authenticated, it no longer requires an
internet connection to communicate with
Model 3. Authenticated phones communicate
with Model 3 using Bluetooth.
Note: Although Bluetooth typically
communicates over distances of up to
approximately 30 feet (9 meters),
performance can vary based on the phone you
are using, environmental interference, etc.
Note: If multiple vehicles are linked to the
Tesla Account, you must switch the mobile
app to the Model 3 that you want to access
before you can use the phone as a key.
Keys
6 Model 3 Owner's Manual
Key Card
Tesla provides you with two Model 3 key
cards, designed to fit in your wallet. Model 3
reads a key card only when placed within very
close proximity (an inch or two) to one of its
card readers. Card readers are located on the
driver's side door pillar and on the center
console.
To use a key card to unlock or lock Model 3,
position the card as illustrated and tap it
against the card reader located below the
Autopilot camera on the driver's side door
pillar. When Model 3 detects the key card, the
exterior lights flash, the mirrors unfold or fold
(if equipped with the premium package and
Fold Mirrors is on), and the doors unlock or
lock.
Note: You may need to physically touch the
driver's side door pillar with the key card, and
you may need to hold it against the
transmitter for one or two seconds.
Once inside, power up Model 3 by pressing the
brake pedal within two minutes of scanning
the key card (see Starting and Powering O
on page 39). If you wait longer than two
minutes, you must re-authenticate by placing
the key card near the card reader located
behind the cup holders on the center console.
When your key card is detected, your two
minute authentication period restarts.
Note: You must position the key card within an
inch or two of a card reader to allow Model 3
to read it. You may need to physically touch
the center console or driver's side door pillar
with the key card, and you may need to hold it
against the transmitter for one or two
seconds.
Note: Walk Away Lock operates only when
using an authenticated phone. When you walk
away from Model 3 carrying only your key
card, Model 3 does not automatically unlock/
lock, even if this feature is turned on (see Walk
Away Lock on page 10).
Caution: Always carry your key card with
you in your purse or wallet to use as a
backup in case your authenticated phone
has a dead battery, or is lost or stolen.
Managing Keys
To display a list of all keys that can access
Model 3, touch Controls > Locks.
When you no longer want a phone to access
Model 3 (for example, you lost it or upgraded
to a new one), touch its associated trash icon
to remove it. When you remove a phone, the
Tesla mobile app displays a notification.
Note: The list of keys is hidden when Model 3
is in Valet mode.
Mobile App
In addition to using the mobile app to
authenticate a phone as your Model 3 key, you
can use it to:
• Lock or unlock Model 3 doors and trunks
remotely.
• Check charging progress and receive
notifications when charging has started,
has been interrupted, is near completion,
or is complete.
Keys
Opening and Closing 7
• Heat or cool Model 3 before driving (even
when it is parked in a garage).
• Locate Model 3 with directions, or monitor
its movement across a map.
• Flash the exterior lights or honk the horn
to find Model 3 when parked.
• Enable/disable Valet mode.
• Start Model 3 remotely.
• Receive notifications if the security alarm
is triggered.
• Receive notifications when a software
update is available or scheduled (see
Software Updates on page 104).
Note: To allow the mobile app to communicate
with Model 3, the phone must be connected to
the internet and mobile access must be
enabled (touch Controls > Safety & Security >
Settings > Allow Mobile Access on the
touchscreen).
Note: If multiple vehicles are linked to the
Tesla Account, you must switch to the Model 3
that you want to access in the mobile app
before the phone can be used as a key.
Note: To take advantage of new and improved
features, download updated versions of the
mobile app as they become available.
Caution: Tesla does not support the use
of third party applications to contact
Model 3.
Keys
8 Model 3 Owner's Manual
Contacting Tesla
For detailed information about your Model 3,
go to www.tesla.com, and log on to your Tesla
Account, or sign up to get an account.
If you have any questions or concerns about
your Model 3, call 1-877-79TESLA
(1-877‑798-3752).
Note: You can also use voice commands to
provide feedback to Tesla. Say "Note",
"Report", "Bug note", or "Bug report" followed
by your brief comments. Model 3 takes a
snapshot of its systems, including your current
location, vehicle diagnostic data, and screen
captures of the touchscreen. Tesla periodically
reviews these notes and uses them to
continue improving Model 3.
Reporting Safety Defects - US
If you believe that Model 3 has a defect which
could cause a crash or could cause injury or
death, you should immediately inform the
National Highway Trac Safety Administration
(NHTSA) in addition to notifying Tesla.
If NHTSA receives similar complaints, it may
open an investigation. If it finds that a safety
defect exists in a group of vehicles, it may
order a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or Tesla.
To contact NHTSA, you may call the Vehicle
Safety Hotline toll-free at 1-888-327-4236
(TTY: 1-800-424-9153); go to
www.safercar.gov; or write to: Administrator,
National Highway Trac Safety, 1200 New
Jersey Avenue SE., Washington, DC 20590.
You can also obtain other information about
motor vehicle safety from www.safercar.gov.
Reporting Safety Defects - Canada
If you believe that your Model 3 has a defect
which could cause a crash or could cause
injury or death, you should immediately inform
Transport Canada, in addition to notifying
Tesla. To contact Transport Canada, call their
toll-free number: 1-800-333-0510.
Reporting Safety Defects
154 Model 3 Owner's Manual
