40681504070, 11/2018
UNIVERSAL REMOTE
INSTRUCTIONS
WARNING
!
MOVING DOOR CAN CAUSE SERIOUS INJURY OR DEATH.
•DO NOT install transmitter unless the door operator’s safety device works as required by the door
operator’s manual.
•Wall Console must be mounted in sight of door, at least 5 feet above oor and clear of moving
door parts.
•Keep people clear of opening while door is moving.
•DO NOT allow children to play with the transmitter or door operator.
If safety reverse does not work properly:
•Close door then disconnect opener using the manual release handle.
•DO NOT use transmitter or door operator.
•Refer to Door and Door Opener Owner’s Manuals before attempting any repairs.
FCC Part 15.21 Statement:
Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC / IC Statement:
This device complies with FCC Part 15 and Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation of the device.
For help or answers please contact Customer Care by website chat
(www.geniecompany.com) or by phone at 1-800-354-3643 for programming
assistance.
For Patent Information: www.geniecompany.com/patent,
©2018 GMI Holdings DBA, The Genie Company
STEP 1 - ACTIVATE REMOTE/BUTTON LAYOUT & LED
Activation Tab: Pull tab to activate the remote.
NOT FOR USE WITH ANY GARAGE DOOR OPENER MANUFACTURED PRIOR TO 1993. NON-
CONTACT SAFETY REVERSING SYSTEM (PHOTOCELLS) MUST BE IN PLACE AND OPERATIONAL.
The universal remote can be programmed to operate many brands and types of garage door openers.
Locate the brand and opener specications by consulting the label on the opener head, the instruction manual, the
current remote controls for the opener, or the original manufacturer of the opener.
Below are the brands and specications that this remote is compatible with and the methods that can be used to
program them. Use Chart A below to nd your opener/specication combination and then proceed to an available
programming method. All combinations shown can be programmed using the CLONING METHOD.
OPTION 3: QUICK START METHOD
You may use 1 of the 4 manufacturer pre-set buttons on the remote as indicated below if you have
any of these brands/specications. If you have more than one of the same brand/MHz opener and/
or would prefer to use a dierent button than indicated for your brand by this method, please note
that all 4 buttons can be programmed individually from each other. You may use any combination of
programming methods available for your opener/specication combination to achieve your desired
button setup.
Button 1: Genie Intellicode 1 or Overhead Door CodeDodger I
Button 2: Chamberlain® with a PURPLE LEARN Button
Button 3: Chamberlain® with a ORANGE/RED LEARN Button
Button 4: Chamberlain® with an YELLOW LEARN Button
1. Press the LEARN button on the garage door opener for 2-3 seconds and then release.
2. Press and release the pre-set button on the universal remote that corresponds with your opener
slowly and deliberately several times until the garage door opener operates. If using Chamberlain®
technology with a YELLOW LEARN button, see *ADDITIONAL INSTRUCTIONS. If you are NOT using
Chamberlain® technology with a YELLOW LEARN button, programming for this button is complete.
OPTION 2: LEARN METHOD
PUT THE UNIVERSAL REMOTE INTO LEARN MODE & SELECT A BUTTON
1. Press and hold down the Genie universal remote button #2.
2. While still holding down button #2, press the universal remote button #4 - four times.
3. Release both buttons.
The BLUE LED on the remote will begin ashing. You will have 15 seconds to complete your entry.
4. Press the button of your choice on the universal remote the required number of times indicated
in the LEARN METHOD column next to your opener and specication in Chart A.
Wait the remainder of the 15 seconds. The blue LED will give a long blink and then go out.
PROGRAMMING THE UNIVERSAL REMOTE TO THE OPENER
1. Press the LEARN button on the garage door opener for 2-3 seconds and then release.
2. Press and release the button you just programmed slowly and deliberately several times until
the garage door opener operates. If using Chamberlain® technology with a YELLOW LEARN
button, see *ADDITIONAL INSTRUCTIONS. If you are NOT using Chamberlain® technology with a
YELLOW LEARN button, programming for this button is complete.
OPTION 1: CLONING METHOD
The Genie universal remote can clone an existing operational remote for any of the garage door
opener brands/specication combinations listed in Chart A.
NOTE: During programming, the garage door opener will operate. Ensure that the
garage door opening is clear of personnel or any obstructions.
LED - The LED will light with each button press and
will also light in response to button presses during
dierent programming modes.
PUT THE UNIVERSAL REMOTE INTO CLONING MODE & SELECT A BUTTON
1. Place the original remote and the Genie universal remote within 2” - 4” of each other.
2. Press and hold down the Genie universal remote button #1.
3. While still holding down button #1, press the universal remote button #2 - four times.
4. Release both buttons.
The WHITE LED on the remote will begin ashing. You will have 20 seconds to complete your entry.
5. Hold down the existing operational button on the original remote until the new universal remote
blinks change from slow WHITE BLINKS to rapid BLUE blinks.
6. Once the universal remote BLUE LED is blinking rapidly, press the button of choice on the
universal remote slowly and deliberately. The LED will turn solid and then go out.
PROGRAM THE UNIVERSAL REMOTE TO THE OPENER
1. Press the LEARN button on the garage door opener for 2-3 seconds and then release.
2. Press and release the button you just programmed slowly and deliberately several times until
the garage door opener operates. If using Chamberlain® technology with a YELLOW LEARN
button, see *ADDITIONAL INSTRUCTIONS. If you are NOT using Chamberlain® technology with a
YELLOW LEARN button, programming for this button is complete.
AVAILABLE PROGRAM METHOD QUICK START
METHOD
LEARN METHOD
Brand Name Megahertz
(MHz)
Specication Notes Pre-set Button
Number on
Remote
Number of
Button Presses
*Chamberlain®® 390 Security +®, Orange/Red Learn Button 3 3
*Chamberlain®® 315 Security +®, Purple Learn Button 2 2
*Chamberlain®® 390 Billion Code®, Green Learn Button 5
*Chamberlain®® 390 Security + 2.0®, Yellow Learn Button 4 4
*Chamberlain®® 390 Fixed Dip Switch
FAAC® 433.92 Rolling
Genie® 315/390 Intellicode® I 1 1
Genie® 315/390 Intellicode® II 6
Genie® 390 Fixed Dip Switch
Guardian® 303 Xtreme® brand 11
Linear® 318 MegaCode® 8
Marantec® 315 Fixed Learn 12
NICE® 433.92 Rolling
Overhead Door® 315/390 CodeDodger® I 1 1
Overhead Door® 315/390 CodeDodger® II 6
Overhead Door® 390 Fixed Dip Switch
Ryobi® 372.5 Rolling 10
Sommer® 310 Rolling 7
Stanley® 310 Fixed Dip Switch
Wayne Dalton® 372.5 Rolling 9
Xtreme® brand 303 Fixed Learn 11
FACTORY DEFAULT: If at any time the remote needs to be cleared and returned to its factory default
settings, press and hold down button #3 while pressing button #4 - four times. The blue LED will give
a long blink and then go out. This will clear any existing programming and return the remote to its
original factory default settings.
PROGRAMMING ASSISTANCE: If the opener does not activate after the steps shown, repeat steps or
contact Customer Care by website chat (www.geniecompany.com) or by phone at:
1-800-354-3643 for programming assistance.
Chart A
PARTS
Visor Clip
Dock
Key Chain
*Genie and Intellicode are registered trademarks of The Genie Company. All other listed names
and trademarks are the property of their respective owners.
* ADDITIONAL INSTRUCTIONS:
For use with Chamberlain® technology with a YELLOW LEARN button: At this time, the opener should have
just activated and then stopped. When it stops, press the YELLOW LEARN button on the
garage door opener again for 2-3 seconds and then release. Press the #2 pre-set button again one time or
until the opener activates. Let the opener run until it stops. Programming for this button is complete.
Changing the Battery:
Remove small phillips head backing screw.
Pry case open with small coin or screwdriver.
Replace battery with CR2032 coin cell.
1 2
3 4
