The House of Marley EMDA001RG Bluetooth Speaker User Manual
The House of Marley.LLC Bluetooth Speaker
User Manual
One Foundation Digital Audio System
Product Name: Bluetooth Speaker
Model: EM-DA001-RG
Welcome to the House of Marley
We are honored you have selected One Foundation to become part of your music
experience. The One Foundation is a two-way, stereo sound system which works
with Bluetooth® devices connected wirelessly and hundreds of other devices via
the auxiliary, digital, or analog inputs. One Foundation fuses striking aesthetics with
a powerful audio engine and brings realism and detail to your music collection.
High-definition, long-throw, wood-fiber impregnated, 5.25-inch woofers in a tuned,
bass-reflex enclosure, Danish designed 1-inch tweeters and over 200 watts come
together in this beautifully engineered work of sonic beauty.
Everything You Need
One Foundation comes with the following items:
• Sound System [Ill. 1]
• Remote [Ill. 2]
• Power Cord for Wall Outlet [Ill. 3]
• 3.5mm Stereo Cable [Ill. 4]
Powering One Foundation
Your One Foundation uses a built-in, 100-120 VAC 50/60Hz or 220-240 VAC
50/60Hz 200W (depending on the country where the product was purchased)
power supply and is powered by a standard wall outlet.
1. Insert the AC power cord into One Foundation. [Ill. 5]
2. Insert wall plug into an appropriate wall outlet. [Ill. 6]
Inputs/Output
One Foundation uses automatic signal detection and will only access the inputs from
devices that are plugged into the audio system. One Foundation will automatically
revert to the last used input when powered “On”.
[ILLUSTRATION OF REAR INPUT PANEL – Ill. 7]
- [WHITE CIRCLE] RCA Analog Input: For use with analog sources.
- Pre-Out: Recommended for use with active subwoofer (not included). See
Fig. # for using One Foundation with a subwoofer.
- [RED CIRCLE] Digital Audio (Optical) Input: Recommended for use with
digital peripherals. Peripheral must be connected and turned on in order to
cycle to this input.
- [BLUE CIRCLE] Bluetooth Pairing Button: This mode can also be initiated by
pressing and holding the [INPUT] button on the remote.
[ILLUSTRATION OF SIDE PANEL]
- [GREEN] 3.5mm Auxiliary Input: This input will be triggered automatically
when a 3.5mm auxiliary cable (included) is plugged into One Foundation.
- USB-A Port: 2.1A Charging Port
Easy To Use
[ILLUSTRATION OF ROTARY DIAL – Ill. 8]
One Foundation uses one convenient control dial to operate power, volume, and
input selection.
- Press the control dial once to turn One Foundation on
- Press the control dial again while One Foundation is on to cycle through
active inputs
- Turn the control dial to adjust volume
- Press and hold the rotary dial to turn One Foundation off
Remote
[ILLUSTRATION OF REMOTE – Ill. 2]
- Input: Cycle through connected inputs or press and hold to engage Bluetooth
Pairing Mode.
- Power: On/Off
- FF: Press for next track, press and hold for fast forward
- RW: Press for previous track, press and hold for rewind
- Play/Pause: Play/Pause track
Connecting Your Device via Bluetooth®
Pairing Mode (Blinking Blue LED)
One Foundation automatically goes into Bluetooth Reconnect Mode for 10 seconds
as soon as you turn it on (fast flashing BLUE led). It then switches to Pairing Mode
(slow flashing BLUE led). You can pair a new device to One Foundation when in
Pairing Mode.
Note: Holding the [INPUT BUTTON] on the One Foundation remote for 3 seconds
will disconnect the device currently connected and go into Pairing Mode. Pairing
mode can also be engaged by disconnecting a connected device or by pressing the
[BT PAIR] on the back of One Foundation.
Connected Mode (Solid Blue LED)
Use your Bluetooth-enabled device to pair to One Foundation. One Foundation does
not require a pairing password. Once paired, the LED will glow solid blue.
Note: One Foundation will automatically pair with the last device connected to it
when turned ON (when the device is available).
Connecting other devices
The various inputs on the back of One Foundation allow you to connect other
devices to the system.
For connecting analog devices, use the RCA input on the back or the auxiliary input
on the side.
For connecting digital devices we recommend using the digital audio (optical) input
for the highest sound quality.
USB Charging Port
Use this port for charging up your iPod®, smartphone, or tablet. The port is always
active when One Foundation is plugged into a wall outlet.
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plug,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the
art/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods
of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. The MAINS plug or an appliance coupler is used as the disconnected device, the
disconnect device shall remain readily operable.
16. The apparatus shall not be exposed to dripping or splashing
- This lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of non-insulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock.
- The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the literature
accompanying the appliance.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture.
CAUTION: Please keep the unit in a good ventilation environment. Do not install the
equipment in a confined space, such as a book case or similar unit.
WEEE EXPLANATION
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmental safe recycling.
BATTERY DIRECTIVE
This symbol indicates that batteries must not be disposed of in the domestic waste
as they contain substances which can be damaging to the environment and health.
Please dispose of batteries in designated collection points.
CAUTION：
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
WARNING
DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD
This product contains a coin/button cell battery. If the coin/ button cell battery is
swallowed, it can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used batteries away from children. If the battery compartment does
not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the
body, seek immediate medical attention.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC RADIATION EXPOSURE STATEMENT
This device complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
CAUTION
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
CANADA STATEMENT
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of
RSS 102 and compliance with RSS-102 RF exposure, users can obtain Canadian
information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la
section 2.5 de RSS 102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut
obtenir l'information canadienne sur l'exposition et la conformité de rf.
