The Ketchum Group Outdoor Technology OT2800 BT SPEAKER User Manual
The Ketchum Group, Inc. dba Outdoor Technology BT SPEAKER
User Manual
TURTLE SHELL® 3.0
Hi.
Good call on picking up the Outdoor
Tech® Turtle Shell® 3.0 wireless boom
box. Your experience of the universe
will soon be enhanced wirelessly and
powerfully. This manual exists to help
make sure that you use it correctly, so
you’re denitely going to want to relax
for a hot second and look through this.
Kisses,
ANATOMY
Power On / Power Off
Multi Function Button
Skip Backward / Volume Down
Skip Forward / Volume Up
Micro USB Charge Port / 3.5 mm Aux Port
USB Output Charge Port
Microphone
Light Indicator
Power On / Power Off
Multi Function Button
Skip Backward / Volume Down
Skip Forward / Volume Up
Micro USB Charge Port / 3.5 mm Aux Port
USB Output Charge Port
Microphone
Light Indicator
POWER UP
TO CHARGE
For best results, fully charge your Turtle Shell®
3.0 before use!
1. Connect the included MIcro USB cord to a
power source and the charging port on the
Turtle Shell® 3.0. When charging, the red LED
light will stay activated. ***Full charge time
is about 4-5 hours.
2. When the Turtle Shell® 3.0 is fully charged,
the RED light will turn off.
The displayed battery meter is supported for
Apple products.
*The Turtle Shell® 3.0’s Bluetooth and music
functions can still operate while charging.
MUSIC FUNCTIONS
Music / Device Controls
MFB
Skip backward
Volume down
Skip forward
Volume up
FUNCTION BUTTON ACTION
Power on Press 3 sec
Power off Press 2 sec
Pairing mode Hold 3 sec
Manual pairing
mode
Hold for 3 sec
Play / Pause Short press once
Volume up Short press once
Volume down Short press once
Skip forward Press & hold for
2 sec
Skip backward Press & hold for
2 sec
PHONE FUNCTIONS
Device Controls
FUNCTION BUTTON ACTION
Answer an
incoming call
Short press once
Reject an
incoming call
Press & hold for
2 sec
End call Short press once
Siri/Voice
activation
Press & hold for 2
sec & release
MFB
Skip backward
Volume down
Skip forward
Volume up
PAIRING TO DEVICE
Enter Pairing Mode
When powered on hold the “+” and “-” at the
simultaneously for 2-3 seconds or until you see the
LED light flash blue 3 times and the voice prompt
states “Pairing.”
Pairing Turtle Shell 3.0 to Device
Open the Bluetooth settings on your device. If you
have put your Turtle Shell® 3.0 into pairing mode,
it should be listed as “ODT Turtle Shell® 3.0” as an
available device to pair. Connect with the Turtle
Shell® 3.0 and enter “0000” if prompted. The voice
prompt will state “Successful” if the Turtle Shell 3.0
and your device connect.
Power On / Off
ON: Hold the Power Button for 2-3 seconds or until
the LED light flashes blue and the voice prompt
states “Power on”
OFF: Hold the Power Button for 3-4 seconds or
until the LED light flashes red and the voice prompt
states “Power off”
SPEAKER TO SPEAKER PAIRING
STEP ONE
Turn on TS3 #1 and wait till the voice prompt states
that the speaker is on. Then press & hold simulta-
neously the MFB button and the “+” button. TS3 #1
will then state that it is in pairing mode.
TS3 #1 TS3 #2
STEP TWO
Turn on TS3 #2 and wait till the voice prompt states
that the speaker is on. Then press & hold simulta-
neously the MFB button and the “-” button. TS3 #2
will then state that it is in pairing mode.
STEP THREE
Once TS3 #1 and TS3#2 are connected, the voice
prompt will state “Successful.”
For more functions, go to outdoortech.com/apps/
to download the Outdoor Tech app.
LISTEN CONTINUED
The built-in microphone means that the Turtle
Shell 3.0 can be used as a wireless headset.
*NOTE: The built-in microphone only works when
connected via Bluetooth.
The following are tips on how to use your Turtle Shell 3.0
to speak on the telephone:
Answer a call......... Press the multifunction button.
End a call............... Press the multifunction button.
Decline a call......... Press and hold the multifuntion
button for two seconds.
Make a call............ Use your phone to dial as usual.
Listen and talk through the
Turtle Shell® 3.0.
Mute...................... Hold the >> and << buttons for 2
seconds, or until you hear a beep.
FAQ
Hearing Distortion
A. Lower the volume on your Turtle Shell®
3.0® and / or phone /device.
B. Make sure it’s charged up. Check for
low battery, then charge if necessary.
Not Loud Enough
A. Turn up the volume on your phone /
device or your Turtle Shell® 3.0.
B. Make sure it’s charged up.
C. Plug the Turtle Shell in to your phone /
device via 3.5mm stereo cable.
Unable to Pair
A. Conrm your phone / device is Blue
tooth compatible.
B. Re-Pair: Follow pairing instructions in
this guide.
Signal Loss or Dropouts via Bluetooth
A. Move Turtle Shell closer to your phone
/ device.
B. Make sure it’s charged up.
C. Turn off your Turtle Shell® 3.0 and
phone / device, then power up and
reconnect.
SPECS
Rating: IPX7
Bluetooth v 4.2
Bluetooth Profiles: HSP, HFP. A2DP, AVRCP
Capatability: Bluetooth v 1.1 and above
Operating range: 32 ft
Operating range between speakers: 15 ft
Device name: ODT TURTLE SHELL 3.0
Power source: Lithium ion rechargeable
battery cell
Battery capacity: 3600mAh / 13.32 Wh
Charge Output: 5V / 1A
Charge Input: 5V / 2.1A
Playing Time: Up to 20 hrs
Charge Time: ~4.5 hrs
Operating Temperature: 0~45° C
Storage Temperature: -20~60° C
RoHS: Fully RoHS compliant
K, bye.
outdoortech.com
DON’T BE SO ANTISOCIAL
Facebook.com/outdoortech
Twitter & Instagram: @outdoortech
Questions, comments, complaints, secret desires,
or just to say what’s up: email info@outdoortech.com
K bye.
10
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation
between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subjectto the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Radiation Exposure Statement:
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be
in conjunction with any other antenna or transmitter.
Canada Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS-102 RF exposure, users can obtain
Le dispositif rencontre l'exemption des limites courantes d'evaluation dans la section 2.5 de RSS 102 et la conformite a l'exposition de RSS-102 rf, utilisateurs
L’exploitation est autorisee aux deux conditions suivantes :
Canadian information on RF exposure and compliance.
peut obtenir l'information canadienne sur l'exposition et la conformite de rf.
co-located or operating
Important Important Important ImportantSafety Safety Safety Safetyinstructions instructions instructions instructions
1.Readtheseinstructions.
2.Keeptheseinstructions.
3.Heedallwarnings.
4.Followallinstructions.
5.Donotusethisapparatusnearwater.
6.Cleanonlywithdrycloth.
7.Donotblockanyventilationopenings.Installinaccordancewiththemanufacturer’sinstructions.
8.Donotinstallnearanyheatsourcessuchasradiators,heatregisters,stoves,orotherapparatus(includingamplifiers)
thatproduceheat.
9.Onlyuseattachments/accessoriesspecifiedbythemanufacturer.
10.Unplugthisapparatusduringlightningstormsorwhenunusedforlongperiodsoftime.
11.Referallservicingtoqualifiedservicepersonnel.Servicingisrequiredwhentheapparatushasbeendamagedinany
way,suchaspower-supplycordorplugisdamaged,liquidhasbeenspilledorobjectshavefallenintotheapparatus,
theapparatushasbeenexposedtorainormoisture,doesnotoperatenormally,orhasbeendropped.
12.Theapparatusshallbeusedatmaximum45°Cambienttemperature.
13.Themaximumheightabovesealevelis2000m
14.Theuseofapparatusinmoderateclimatesandindooronly
15.Theventilationshouldnotbeimpededbycoveringtheventilationopeningswithitems,suchasnewspapers,table-
cloths,curtains,etc.
16.Nonakedflamesources,suchaslightedcandles,shouldbeplacedontheapparatus.
17.UseonlypowersuppliesprovidedbyKICKER
18.Batterypackshallnotbeexposedtoexcessiveheatsuchassunshine,fireorthelike.
CAUTION CAUTION CAUTION CAUTION
Dangerofexplosionifbatteryisincorrectlyreplaced,Replaceonlywiththesameorequivalenttype.
Symbol
Theapplianceshallnotbedisposedtogetherwiththenormalwaste.Itmustberecycled.
