G2Z-CAP Camera
User Guide
G2Z-CAP User Guide
Page 2
The Kroger Co.
Release 1.0
Version 1.2
Copyright © 2010, The Kroger Co. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without prior written permission from The Kroger Co.
All copyright, confidential information, patents, design rights and all other intellectual property
rights of whatsoever nature contained herein are and shall remain the sole and exclusive
property of The Kroger Co. The information furnished herein is believed to be accurate and
reliable. However, no responsibility is assumed by The Kroger Co. for its use, or for any
infringements of patents or other rights of third parties resulting from its use.
The Kroger Co. name and The Kroger Co. logo are trademarks or registered trademarks of The
Kroger Co. All other trademarks are the property of their respective owners.
G2Z-CAP User Guide
Page 3
Table of Content
1 INTRODUCTION .................................................................................................................5
2 SYSTEM REQUIREMENTS ..................................................................................................6
2.1 SYSTEM REQUIREMENTS ................................................................................................................ 6
3 G2Z-CAP SPECIFICATIONS .................................................................................................7
3.1 PROCESSING ............................................................................................................................... 7
3.2 NETWORK CONNECTIONS .............................................................................................................. 7
3.3 POWER ...................................................................................................................................... 7
3.4 SECURITY ................................................................................................................................... 7
3.5 VIDEO CAPTURE AND ENCODING ..................................................................................................... 7
3.6 CUSTOMER APPLICATIONS ............................................................................................................. 8
3.7 FIRMWARE UPDATES .................................................................................................................... 8
3.8 OPERATING CONDITIONS ............................................................................................................... 8
3.9 DIMENSIONS ............................................................................................................................... 8
3.10 APPROVALS ........................................................................................................................... 8
3.11 INCLUDED ACCESSORIES ........................................................................................................... 8
3.12 SAFETY PRECAUTIONS .............................................................................................................. 8
3.13 ELECTROSTATIC DISCHARGE ...................................................................................................... 8
4 POWER REQUIREMENTS ...................................................................................................9
5 INTERFACE DETAILS ........................................................................................................10
5.1 RS232 INTERFACE: .................................................................................................................... 10
5.2 MICROSD CARD INTERFACE: ........................................................................................................ 10
5.3 USB INTERFACE: ........................................................................................................................ 10
5.4 AUDIO IN/OUT INTERFACE: .......................................................................................................... 10
5.5 ZIGBEE INTERFACE: .................................................................................................................... 10
6 REPLACEABLE BATTERY ...................................................................................................11
7 FCC COMPLIANCE STATEMENTS .....................................................................................11
8 OPERATIONAL INSTRUCTION ..........................................................................................11
Tables
Table 1: RJ45 Connector Pin Assignment: 9
G2Z-CAP User Guide
Page 4
Revision History
Date
Change Description
Revision
19
-
SEP
12
Initial Revision
1.0
29
-
SEP
12
Updated as per Internal Review
1.1
07
-
Nov
-
12
Updated for Compliance statements
1.2
G2Z-CAP User Guide
Page 5
1 Introduction
G2Z-CAP is a PoE powered IP Camera device. It also acts as a wired and wireless access point.
Benefits are as follows:
Benefits
• Built-in Web server that does not require any additional hardware or software to operate
• Supports time synchronization with a Network Time Protocol (NTP) server
• Ability to view and save snapshots
• Ability to Pan/Tilt at 350º and 90º
• Access point for ZigBee Infrastructure
• Embedded Video Analytics
o Customer counting
o Dwell Time
o Occupancy
o Analytics ties in with task management system software.
G2Z-CAP User Guide
Page 6
2 System Requirements
The system requirements for the G2Z-CAP Network Camera include the following for browser-
based viewing.
2.1
2.12.1
2.1 System Requirements
• Microsoft Windows PC
• Microsoft Internet Explorer version 5.x or higher
• Apple Quick Time Player
G2Z-CAP User Guide
Page 7
3 G2Z-CAP Specifications
3.1
3.13.1
3.1 Processing
• 600MHz Dual Core SoC
• Upto 256MB DDR2 RAM
• 128MB NAND FLASH
• 3.1M Pixel CMOS Image Sensor
• On-Board ZigBee Modules (4 Nos)
• microSD Card Socket
• USB Host 2.0 Connectivity (Optional)
• Audio In/Out Connectivity (Not Used)
• Pan/Tilt Motor Interface
• RS232 Interface
• Monta Vista Linux Kernel
• Exended depth of field Lens
3.2
3.23.2
3.2 Network Connections
• 10/100 Mbps Ethernet
3.3
3.33.3
3.3 Power
Input Voltage : 48VDC (POE)
Input Current : 0.2A
3.4
3.43.4
3.4 Security
• Multi-user level password protection to restrict camera access
3.5
3.53.5
3.5 Video Capture and Encoding
• Display in color OR black and white.
• Illumination: 10-10 000 lux.
• Image sensor: 3.1 MPixel 1/4” progressive scan CMOS image sensor
• Image frame rate
o Up to 15 frames per second for QXGA resolutions
o Up to 30 frames per second for XGA capture resolution.
• Image compression: Motion JPEG, individual JPEG and H.264
• Resolution range:
o 1280 x 1024 , 1280 x 960, 1280 x 720
o 640 x 480, 640 x 360
o 320 x 240
• Network bandwidth usage limitation control based on Variable Bit rate H.264 codec
G2Z-CAP User Guide
Page 8
3.6
3.63.6
3.6 Customer Applications
• Compliance with ONVIF
3.7
3.73.7
3.7 Firmware Updates
• Firmware updates over the LAN network
3.8
3.83.8
3.8 Operating Conditions
• Temperature: 5 to 40º C (41 to 104 ºF)
• Humidity: 20 to 80% RHG
• Indoor use only
3.9
3.93.9
3.9 Dimensions
• Height: 180 mm
• Width: 172 mm
• Depth: 172 mm
3.10
3.103.10
3.10 Approvals
• EMI
o FCC
• Safety
o UL
3.11
3.113.11
3.11 Included Accessories
Adjustable ceiling mount supporting tile mount, through ceiling mount and tear drop
installations.
3.12
3.123.12
3.12 Safety Precautions
Below is safety precaution that should be observed when installing device.
3.13
3.133.13
3.13 Electrostatic Discharge
The device will be installed over ceiling, there will not threat of ESD during normal operation.
The ESD threat will be further reduced due to plastic casing.
The installation of the device will be done through trained person. The person should take care
of ESD precautions while installing device.
G2Z-CAP User Guide
Page 9
4 Power Requirements
The G2Z-CAP Camera can be powered through PoE Adapter or PoE Switch through RJ-45
Ethernet connector. Being 802.3af compliant device, G2Z-CAP would draw 10W (< 13W as per
PoE standard) power from PoE source.
The PoE Adapter/Switch is not part standard packaging. The standard 802.3af Compliant,
FCC/CE/UL certified off-the-shelf devices should be used to avoid interference issues to
G2Z-CAP.
If multiple G2Z-CAP Cameras will be powered from single multiport Ethernet switch, proper
power rating should be selected to meet individual power requirements of G2Z-CAP.
• Specifications for suitable PoE Injector or Switch are as follows:
o Input Voltages: 90–264 VAC, 60Hz
o Output Voltage: 48 VDC
o Output Current: 0.32A per Port
o Power: 15.36W per Port
Standard Source
Voltage
RJ45 Pin Number
1 2 3 4 5 6 7 8
IEEE 802.3af
using Spare
Data pairs
48-56VDC TX+ TX- RX+ DC+ DC+ RX- DC- DC-
Table 1: RJ45 Connector Pin Assignment:
G2Z-CAP User Guide
Page 10
5 Interface Details
G2Z-CAP Device provides RJ45 interface for Network connectivity. The Ethernet interface is the
only available interface to the outside world. Apart from RJ45, G2Z-CAP provides ZigBee
wireless connectivity through on-board ZigBee modules.
Interfaces available on-board G2Z-CAP:
5.1
5.15.1
5.1 RS232 Interface:
On Board RS232 interface is not accessible from outside enclosure.
5.2
5.25.2
5.2 MicroSD Card Interface:
MicroSD card interface on G2Z-CAP Board is used to store data in case of network failure. This
interface is not available to the User. MicroSD is not accessible from outside enclosure.
5.3
5.35.3
5.3 USB Interface:
USB connectivity option is available on G2Z-CAP. USB is not accessible from outside enclosure.
5.4
5.45.4
5.4 Audio In/Out Interface:
Audio In/Out interface is not used in G2Z-CAP Device. Audio Interface is not accessible from
outside enclosure.
5.5
5.55.5
5.5 ZigBee Interface:
G2Z-CAP Camera has 4 ZigBee modules for Wireless Connectivity.
G2Z-CAP User Guide
Page 11
6 Replaceable Battery
G2Z-CAP has a coin battery which is not user replaceable. But the battery can be replaceable by
service person.
CAUTION: The battery must be replaced only by the authorized service person.
7 FCC Compliance Statements
This device complies with Part 15 of the FCC rules. Operation is subject to following
two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference received including interference that may
cause undesired Operation of this device.
FCC Caution: Any changes or modifications not expressly approved by the party responsible
For compliance could void the user's authority to operate this equipment.
To comply with the FCC RF exposure compliance requirements, this device and its antenna
must not be co-located or operating to conjunction with any other antenna or transmitter,
except if installed in compliance with FCC Multi Transmitter procedures.
This equipment should be installed and operated with minimum distance of 20cm between the
radiator and your body.
Snap-On Ferrite Core 28A2025-0A2 (Make: Liard Signal Integrity Products) need to be mounted
on Ethernet Cable near RJ45 connector of G2Z-CAP. This ferrite core was used during testing to
achieve compliance.
8 Operational Instruction
For G2Z-CAP operational instruction, please contact Vendor/Manufacturer for latest updated
instruction guide.
