The Kroger SZG2ZBNCR1 G2 Zooter ZigBee/2.4GHz and IEEE-802.15.4 Access Point Unit User Manual G2Z CAP User Guide
The Kroger Co. G2 Zooter ZigBee/2.4GHz and IEEE-802.15.4 Access Point Unit G2Z CAP User Guide
Manual
G2Z-NCZGBAP
User Guide
G2Z-NCZGBAP User Guide
Page 2
The Kroger Co.
Release 1.0
Version 1.1
Copyright © 2010, The Kroger Co. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without prior written permission from The Kroger Co.
All copyright, confidential information, patents, design rights and all other intellectual property
rights of whatsoever nature contained herein are and shall remain the sole and exclusive
property of The Kroger Co. The information furnished herein is believed to be accurate and
reliable. However, no responsibility is assumed by The Kroger Co. for its use, or for any
infringements of patents or other rights of third parties resulting from its use.
The Kroger Co. name and The Kroger Co. logo are trademarks or registered trademarks of The
Kroger Co. All other trademarks are the property of their respective owners.
G2Z-NCZGBAP User Guide
Page 3
Table of Content
1 INTRODUCTION .................................................................................................................5
2 G2Z-NCZGBAP SPECIFICATIONS ........................................................................................6
PROCESSING ............................................................................................................................... 6
NETWORK CONNECTIONS .............................................................................................................. 6
POWER ...................................................................................................................................... 6
CUSTOMER APPLICATIONS ............................................................................................................. 6
FIRMWARE UPDATES .................................................................................................................... 6
OPERATING CONDITIONS ............................................................................................................... 6
DIMENSIONS ............................................................................................................................... 6
APPROVALS ................................................................................................................................ 6
INCLUDED ACCESSORIES ................................................................................................................ 7
SAFETY PRECAUTIONS .............................................................................................................. 7
ELECTROSTATIC DISCHARGE ...................................................................................................... 7
3 POWER REQUIREMENTS ...................................................................................................8
4 INTERFACE DETAILS ..........................................................................................................9
RS232 INTERFACE: ...................................................................................................................... 9
ZIGBEE/2.4GHZ AND IEEE-802.15.4 INTERFACE: ............................................................................. 9
5 FCC COMPLIANCE STATEMENTS .....................................................................................10
6 OPERATIONAL INSTRUCTION ..........................................................................................10
Tables
Table 1: RJ45 Connector Pin Assignment: 8
G2Z-NCZGBAP User Guide
Page 4
Revision History
Date
Change Description
Revision
08-JUN-18
Baselined
1.0
G2Z-NCZGBAP User Guide
Page 5
1 Introduction
G2Z-NCZGBAP is a POE powered ZigBee/2.4GHz and IEEE-802.15.4 Access Point device.
Benefits
Supports time synchronization with a Network Time Protocol (NTP) server.
Access point for ZigBee/2.4GHz and IEEE-802.15.4 Infrastructure.
Firmware update via LAN
G2Z-NCZGBAP User Guide
Page 6
2 G2Z-NCZGBAP Specifications
Processing
600Mhz Dual Core SoC
Upto 256MB DDR2 RAM
128MB NAND FLASH
On-Board ZigBee/2.4GHz and IEEE-802.15.4 Modules (4 Nos)
RS232 Interface
Monta Vista Linux Kernel
Network Connections
10/100 Mbps Ethernet
Power
Input Voltage: 48VDC (POE)
Input Current: 0.2A
Customer Applications
Access Point
Firmware Updates
Firmware updates over the LAN network
Operating Conditions
Temperature: 5 to 40º C (41 to 104 ºF)
Humidity: 20 to 80% RHG
Indoor use only
Dimensions
Height: 30 mm
Width: 179 mm
Depth: 179 mm
Approvals
EMI
o FCC
Safety
o UL
G2Z-NCZGBAP User Guide
Page 7
Included Accessories
Adjustable ceiling mount supporting tile mount, through ceiling mount and tear drop
installations.
Safety Precautions
Below is safety precaution that should be observed when installing device.
“ITE is to be connected only to PoE networks without routing to the outside plant.”
Electrostatic Discharge
The device will be installed over ceiling, there will not threat of ESD during normal operation.
The ESD threat will be further reduced due to plastic casing.
The installation of the device will be done through trained person. The person should take care
of ESD precautions while installing device.
G2Z-NCZGBAP User Guide
Page 8
3 Power Requirements
The G2Z-NCZGBAP can be powered through PoE Adapter or PoE Switch through RJ-45 Ethernet
connector. Being 802.3af compliant device, G2Z-NCZGBAP would draw 10W (< 13W as per PoE
standard) power from PoE source.
The PoE Adapter/Switch is not part standard packaging. The power to G2Z-NCZGBAP should be
supplied with UL Listed POE+ Adaptor/Switch marked with LPS. The standard 802.3af
Compliant, FCC/CE/UL certified off-the-shelf devices should be used to avoid interference issues
to G2Z-NCZGBAP.
If multiple G2Z-NCZGBAP will be powered from single multiport Ethernet switch, proper power
rating should be selected to meet individual power requirements of G2Z-NCZGBAP.
Specifications for suitable PoE Injector or Switch are as follows:
o Input Voltages: 90–264 VAC, 60Hz
o Output Voltage (Typ): +48VDC
o Output Current: 0.32A per Port
o Power: 15.36W per Port
POE Injector/Switch
RJ45
RJ45Host Computer
90-264VAC G2Z-NCZGBAP
RJ45
CAT5
CAT5
Standard
Source
Voltage
RJ45 Pin Number
1
2
3
4
5
6
7
8
IEEE 802.3af
using Spare
Data pairs
+48VDC
TX+
TX-
RX+
DC+
DC+
RX-
DC-
DC-
Table 1: RJ45 Connector Pin Assignment:
G2Z-NCZGBAP User Guide
Page 9
4 Interface Details
G2Z-NCZGBAP Device provides RJ45 interface for Network connectivity. The Ethernet interface
is the only available interface to the outside world. Apart from RJ45, G2Z-NCZGBAP provides
ZigBee/2.4GHz and IEEE-802.15.4 wireless connectivity through on-board ZigBee/2.4GHz and
IEEE-802.15.4 modules.
Interfaces available on-board G2Z-NCZGBAP:
RS232 Interface:
On Board RS232 interface is not accessible from outside enclosure.
ZigBee/2.4GHz and IEEE-802.15.4 Interface:
G2Z-NCZGBAP has 4 ZigBee/2.4GHz and IEEE-802.15.4 modules for wireless connectivity.
G2Z-NCZGBAP User Guide
Page 10
5 FCC Compliance Statements
FCC ID: PBR-SZG2ZBNCR1
FCC compliance statements
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including Interference that may
cause undesired operation
FCC Caution!!!
Any changes or modifications not expressly approved by the party Responsible for
compliance could void the user's authority to operate this Equipment.
This equipment should be installed and operated with minimum distance 20 cm
between the radiator & your body.
Part 15B compliance statements for digital devices:
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Snap-On Ferrite Core 28A2025-0A2 (Make: Liard Signal Integrity Products) need to be mounted
on Ethernet Cable near RJ45 connector of G2Z-NCZGBAP. This ferrite core was used during
testing to achieve compliance.
6 Operational Instruction
For G2Z-NCZGBAP operational instruction, please contact Vendor/Manufacturer for latest
updated instruction guide.
