The Procter and Gamble 416010 Smart Air Freshener User Manual 004 FA Fbrz NT Bklt US
The Procter & Gamble Company Smart Air Freshener 004 FA Fbrz NT Bklt US
Users Manual
MODE LIGHT
Bathroom
Heavy Duty
100%6:14 PM
DISCOVER
R
E
F
I
L
L
TIDE ORIGINAL SCENT Wash
away odors with the revitalizing
scent of aloe and fresh floral notes.
Now you can smell like a laundry
enthusiast --without folding a thing.
SPRING & RENEWAL Its bright,
refreshing scent eliminates odors and
brings those first hints of sunshine
and spring blooms to your home.
CRISP & CLEAN Tell tough odors
to take a hike with the invigorating
blend of lemony verbena, crisp
cucumber, and cool, watery notes.
LINEN & SKY A scent so airy,
your guests will think you live
in a cloud. An odor-eliminating,
noticeably fresh cloud.
MEDITERRANEAN LAVENDER
It'll turn your home into a tranquil
overseas escape --without the jet
lag or the travel-induced odors.
GAIN ORIGINAL SCENT
The just-right floral notes will
have your guests wondering where
you're hiding that flower garden.
MEADOWS & RAIN Enjoy the
fresh, dewy scent of a rainy day
-- without ever getting wet.
LUSH & LUXURIOUS A lush
embrace made of bright flowers,
cedar undertones, and vanilla layers
that transform your room into a
cathedral of haute couture, avant-
garde, and other assorted fancypants
terms of the nouveau riche.
FRESH & FLIRTY Make a scene -
and completely transform the feel
of the room with airy undertones
and crisp vibrant, layers.
SHIMMER & SHINE Enticingly light,
with a fruity, floral freshness.
SCENT REFILLS QUICK START
INSTALLATION / OPERATING INSTRUCTIONS
1. Unscrew both caps on oil refill and discard.
2. Insert oil refill unit completely into the Febreze Home
smart air freshener until you hear a click.
3. Insert smart air freshener upright into outlet.
Rotate plug if necessary. Placing smart air freshener
on its side or upside down will cause leakage.
App Store
Google Play
APP SETUP
1. Download the Febreze Connect app at:
2. Follow prompts in app
3. Add a device:
NOTE: To disconnect from wi-fi, remove the scent cartridge
and press and hold the white button until the blue light glows.
To reset to manufacturer defaults, hold the white button
until the pink light glows.
For additional instructions or troubleshooting,
visit FEBREZEHOME.COM or contact us at:
1 (877) 728 • 8922
*mode resets to your previous settings.
APP
HOME
See scent, temperature and
humidity status of all rooms and
adjust all scent intensities at once.
Additional settings can be found via
button in the top-right corner of Home
screen, including Account and Nest settings.
INTENSITY DIAL
Change the intensity of scent in room
by swiping the white dial up and over.
NEXT/PREVIOUS
Swipe left or right to switch rooms.
SNOOZE allows you to completely
turn off the device for 60 minutes*
BOOST provides a continuous burst of
fragrance and odor fighting protection
on the high setting for 60 minutes*
NORMAL allows you to customize your scent
preferences using the scent intensity dial.
NIGHT LIGHT provides continuous light throughout
the night.
EDIT ROOM
Edit the name, type, scent or remove device.
REFILL LEVEL
Indicates how much scented oil is left.
SCENT DISCOVERY
Explore and discover and order
additional scent refill options.
REFILL
Quick refill order.
LIGHTS
PATH LIGHT turns on the motion sensor to
automatically activate a LED to light your
way for 10 seconds as you walk past.
OFF disables the light mode and turns the LED off.
FAN
BOOST will also activate
the HVAC system fan to
provide better distribution
of the scent throughout
your home when permission
is granted via Nest app.
PROTECT
Flashes red light in the
event your Nest Protect
alarm is activated.
Flashes yellow light when a
heads-up alert is activated.
AWAY
Utilizes the Away Mode
of your Nest Learning
Thermostat to reduce the
scent intensity setting
to more efficiently use
your Febreze scented oil
cartridges and keep things
fresh - and odor free -
when it matters most.
THREAD™ COMPATIBLE
Smart air freshener
HOME with Febreze Connect™
WELCOME HOME
CLEANING INSTRUCTIONS Fragrance oils may collect on the warmer over time. To clean, remove warmer from the outlet and wipe with clean, dry cloth.
USER MAINTENANCE There are no user maintenance parts; Do not open device.
MOVING & STORAGE INSTRUCTIONS Do not place fragrance bottles or caps on finished wood surfaces. Do not use sideways or upside down as the
perfume oils will leak. Discontinue use if the unit is dropped or damaged.
CAUTION: EYE IRRITANT. Avoid contact with eyes and skin. Do not put fingers into product vent. Wash hands after handling. KEEP OUT OF REACH OF
CHILDREN AND PETS. FIRST AID TREATMENT: Contains fragrance oils. IF SWALLOWED, call a physician or poison control center immediately. Do not
induce vomiting. If in eyes, rinse with plenty of water for 20 minutes. If eye irritation persists, consult a physician.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS
IMPORTANT SAFETY INSTRUCTIONS. PLEASE SAVE
WARNING: When using electric products, basic safety precautions should always be followed: Read all instructions before using. To reduce risk of injury, keep
out of reach of children and pets. Product not a toy. Intended for adult use only. Do not put fingers into product vent to avoid contact with wick and minimize
potential for burns.
RISK OF ELECTRICAL SHOCK AND FIRE HAZARD Use only in properly functioning 120-volt electrical outlet. For indoor use only. Do not use with extension
cords. Do not immerse in water or use in damp/wet areas. Do not use around open flame. Keep warmers and refills away from furniture, fabrics, bedding and
other materials which might present a fire hazard. Do not obstruct or block airflow from unit. Use only in areas with at least 30 cm/12” clearance above the unit
to avoid potential discoloration of surrounding surfaces. To reduce the risk of electrical shock, this warmer has a polarized plug (one blade is wider than the
other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet. Do not use in small confined pet areas without adequate ventilation.
FCC NOTIFICATION This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The user is cautioned
that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
FEBREZEHOME.COM · 1 (877) 728 · 8922
FEBREZEHOME.COM · 1 (877) 728 · 8922
