Stay Alert FeatureThe Stay Alert Feature is designed to test a driver’salertness. To engage (when unit is not alarming) :• Press and hold City for approximately 2seconds. Release button during or immediatelyafter the alert is given. Display shows: –XTR-325 only: The “H“or “C“will flashWithin 30-60 seconds two beeps are sounded; toshow alertness, the driver must press either theCity, Volume, or Quiet buttons within 3-5 seconds. Ifabutton is not pressed within 3-5 seconds, thecycle is repeated.If a button was not pressed within 3-5 secondsalarm sounds and the display shows: All LEDs flash for XTR-325• Press Power to exit.WARNING!!! Stay Alert is NOT intended as asubstitute for adequate rest. You should NOT operateavehicle if you are drowsy. During extended periods ofvehicle operation, you should take frequent breaks.Improper reliance on the Stay Alert feature may resultinvehicle damage, personal injury or death. NEVEROPERATE A VEHICLE IF YOU ARE DROWSY.SWSSafety Warning System™In communities where transmitters are located,the Safety Warning System™displays over 60text messages. When Safety Radar is detectedthe audio alert is geiger counter-like.NNoottee:: Safety Warning System™is labeled “SR”in Option Select Mode.Safety Warning System Text Example: Poor - Road - Surface.XTR-325 displays an “S.”Note: Not all areas have Safety Warning System™transmitters.OPERATIONPOP™ Mode AlertsBecause POP™ Mode travels on regular radar bandwidth, there is no particular alert for POP™Mode transmissions. POP™ Mode alerts will be displayed as a regular radar alert.LASER/RADAR ALERTSSpeed Radar Audio/Visual AlertsWhen X, K, Ka, or Ku is detected, the band IDand signal strength are displayed. The audioalert is continuous and has a geiger counter-like pattern. The faster the beep, the closer orstronger the radar source.Note: Geiger not available when custom tonesare selectedLaser Audio/Visual AlertsWhen a laser signal is detected, the audio alert is continuous for a minimum of 3 seconds. • The Displays Shows:The more “|||”, the closer the laser source.XTR-325 displays an “L”Pulse Protection®Pulse (or instant-on) radar is more difficult todetect than conventional radar because itremains ‘off’ until activated to measure thespeed of a targeted vehicle.When a pulse type transmission is detected, yourWhistler detector sounds an urgent 3-secondaudio warning and the display shows: XTR-325 displays an “P”After the 3-second pulse alert, the standard alertpattern continues for as long as the signal ispresent.It is important to respond promptly to a pulsealert, since warning time may be minimal.POP MODE ALERTSVG-2 Audio/Visual AlertsNote: You must turn this feature on before it willdetect VG-2.When a VG-2 signal is detected, the detector ‘hides’ itsown radiated signal and becomes undetectable bythe VG-2. Once VG-2 is detected, every 30 seconds,the detector checks for a VG-2 signal. If a VG-2signal is still present, the unit continues to hideand repeats the VG-2 alert. If no signal is detected,two beeps are provided, indicating an ‘all clear’condition. During a VG-2 Alert X, K, and Ka bandsignals cannot be received (Reference page 21 forVG-2 information).Alert PriorityWhen two or more signals are received at thesame time, the alert priority is:1. Laser 2. VG-2 3. Speed Radar 4. Safety RadarExample: If X band is alerting, then suddenly a VG-2 signal is detected, the VG-2 warning will overridethe X band alert.Reset FeaturesAll user features can be reset to factory settings.•Unplug Power Cord from unit.•Plug Power Cord into unit.Unit is now reset to the following features and settings.Default factory settings are:1. Audio to level (5).2. Display shows Highway.3. Auto Quiet Mode OFF.4. VG-2 Detection Mode OFF.5. Safety Radar OFF.6. Vehicle Battery Saver ON.7. Full Power Up sequence.8. Default TONE 3.9. POP ON. 10. Backlighting Dim/Bright11. Dim/Dark to Full BrightVG-2 ALERTSYour Whistler detector is expertly engineered anddesigned to exacting quality standards to provide youwith reliable, trouble-free operation. If your unit hasbeen correctly installed following the guidelines in thismanual, but is not operating optimally, please refer tothe troubleshooting guide below.PROBLEM: No display or audio.• Check fuse in Whistler plug; replace if necessary with a 2 amp 3AG type.• Check fuse for lighter socket; replace if necessary.• Make sure lighter socket is clean.PROBLEM: Unit alarms when using vehicleelectrical accessories (brakes, power mirrors,power windows, turn signals, horn, etc.)when unit is connected to the power cord.• Vehicle’s electrical system, including battery and alternator, may have electrical noise. Install a filter capacitor (470mfd. 25 volt or larger capacitance value) on the back of the lighter socket.PROBLEM: Unit alarms when vehicle hitsbumps.•Check for loose lighter socket; tighten and clean.• Check connections at both ends of power cord. Substitute another cord to determine if cord is defective. Return defective cord to the factory.PROBLEM: Audio alerts are not loud enough.•Cancel Auto Quiet Mode or City Mode.• Check audio level setting (see page 8).PROBLEM: Unit turns itself off• See battery saver feature on page 12If difficulties occur which cannot be solved by information in this Troubleshooting Guide, pleasecall Whistler Customer Service at 1-800-531-0004or visit our FAQ page atwww.whistlergroup.com/faq-detectors.asp,before returning your unit for service.TROUBLESHOOTINGCare And MaintenanceDuring the summer months, avoid prolongedexposure to direct sunlight by removing your unitfrom the dash when your vehicle is parked for anextended period of time. Do not spray water,cleaners, or polishes directly onto the unit. Thespray may penetrate through the openings anddamage the unit. Also, do not use any abrasivecleaners on the unit’s exterior.As with all battery operated devices remove thebatteries when this unit will not be used for anextended period of time. Damage caused byleaky or improperly charged batteries are notcovered under warranty. Check with the batterymanufacturer about the specific battery warranty.ARE DETECTORS LEGAL?In Most States YES!Laser-Radar detectors are legal in every state(with the exception of Virginia and Washington,D.C., which have local regulations restricting theuse of radar receivers in any vehicle) when usedin automobiles or light trucks (under 10,000 lbs.). Concerning trucks over 10,000 lbs., the FederalHighway Administration (FHWA) issued a regulation, effective January, 1994 which prohibitsradar and laser detector use in these types ofvehicles nationally. Prior to the FHWA regulation,laws existed in the state of New York restrictingthe use of radar detectors in trucks over 18,000lbs. and in Illinois in trucks over 26,000 lbs.CARE AND MAINTENANCEFCC ID: HSXWH16This device complies with part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and(2) this device must accept any interference received,including interference that may cause undesired operation.Important: FCC requirements state thatchanges or modifications not expressly approvedby Whistler could void the user’s authority tooperate the equipment.SPEED MONITORINGRadar FactsA radar gun operates by transmitting radiowaves at certain frequencies which reflect offobjects and are picked up by the radar gun’sreceiving section. When a radar beam reflectsoff a moving target, a measurable frequency shiftoccurs. The radar unit converts this shift into milesper hour to determine your vehicle’s speed.Currently, the FCC (Federal CommunicationsCommission) permits operation of traffic radarguns at X Band (10.500 - 10.550 GHz), K Band(24.050 - 24.250 GHz), Ka Band (33.400 - 36.000GHz) and Ku Band (13.425 - 13.475 GHz).Note: A radar detector will not alarm if anofficer is not transmitting on any one of theabove radar bands.POP™ ModePOP™Mode is a feature on some newer radarguns operating on K and Ka bands. When thegun is in POP™Mode and activated, a brief burstof energy, less that 1/15 of a second, istransmitted and the vehicle’s speed is quicklyacquired. A detector without POP™Modedetection capability cannot respond to this brieftransmission. FCC INFORMATIONTotal Band Protection™ PLUS KuComplete Band Coverage that detects laser,radar including Ku, VG-2 and safety radar bands.Laser FactsIt’s well documented that many radar guns cannot reliably provide the speed of a targetedvehicle that is traveling in a group of vehicles. Incontrast, a laser gun can target a specific vehicleout of a line of traffic and determine its speed.The advantage of laser over radar in terms of target identification is the result of the laser gun’snarrow beam. A radar gun’s transmission cancover more than a four-lane highway at adistance of 1,000 feet, compared with a lasergun’s transmission which covers about 3 feet atthe same distance. For best protection, keepthese points in mind: •Because the vehicle’s license plate or headlights are the laser gun’s primary targets,mounting the Whistler detector on the dashboard can improve laser detection at shortrange.•Do not follow closely behind any vehicle youcannot see through. If you can’t see past a vehicle ahead of you, chances are your detectorwon’t either.• The receiving range of your laser detector willnot be the same as a radar detector. Laser gunsare most often used at short range.Whistler Laser-Radar detectors receive all currentlaser guns which operate at a laser wavelength of 905+/- 10mm.•Pro Laser™I II III •LT1 20-20 •Ultra LyteSPEED MONITORINGLaser TipsIf you are the targeted vehicle, a laser gun canoften determine your speed within a few seconds after you receive an alert. In thissituation there is generally no time to safelyadjust your speed. However, if you are travelingnear or behind the targeted vehicle and receivean alert, response time should be sufficient. Anylaser alert, regardless of duration, requiresimmediate action!Other Speed Detection SystemsSeveral techniques other than radar or laser areused to measure vehicle speeds. When thesemethods are being used, no detector can providea warning. These techniques include:• PPaacciinngg- A patrol car drives behind you and matches your driving speed.•VVaassccaarr//AAiirrccrraafftt- The time it takes a vehicle to travel a known distance is measured.Radar Detector Detectors: VG-2,SpectreThe Interceptor VG-2 or simply VG-2, is one type ofmicrowave receiver used by Police to detect signals radiated by the local oscillator of a radar detector.Because it purpose is to identify persons driving withradar detectors, these devices are known as a “radar detector detector” (RDD).An RDD is the primary tool used by the police toidentify radar detector equipped vehicles. If caughtin a state or country where detectors are illegal (seepage 18). drivers risk losing their radar detector andreceiving a fine. In addition, instant-on radar isalmost always used in combination with a RDD, leaving unsuspecting motorists vulnerable to receivetwo tickets - one potentially for speeding, the otherfor possession of a detector.SPEED MONITORINGNNoottee:: HHaavviinngg aa rraaddaarr ddeetteeccttoorr ccaappaabbllee ooffddeetteeccttiinngg tthhee VVGG--22 mmaayy aalleerrtt yyoouu ttoo tthheepprreesseennccee ooff aa ssppeeeedd ttrraapp.. AAss ooff tthhiiss pprriinnttiinngg,, tthheenneewweesstt ttooooll PPoolliiccee hhaavvee ttoo ddeetteecctt rraaddaarr ddeetteeccttoorrssiiss ccaalllleedd SSppeeccttrree.. AAss ooff tthhiiss pprriinnttiinngg.. SSppeeccttrree ccaannddeetteecctt aallll uunnddeetteeccttaabbllee ((VVGG--22)) llaasseerr//rraaddaarrddeetteeccttoorrss oonn tthhee mmaarrkkeett..It is the responsibility of the individual radar detectoroperator to know and understand the laws in yourarea regarding the legality of the use of radardetectors.WARRANTY INFORMATIONConsumer WarrantyThis Whistler Laser-Radar detector is warranted tothe original purchaser for a period of one year fromthe date of original purchase against all defects inmaterials and workmanship. This limited warrantyis void if the unit is abused, modified, installedimproperly, if the housing and/or serial numbers havebeen removed. There are no express warrantiescovering this product other than those set forth inthis warranty. All express or implied warranties for thisproduct are limited to the above time. Whistler isnot liable for damages arising from the use, misuse,or operation of this product.SPEED MONITORINGService Under WarrantyDuring the warranty period, defective units willbe repaired without charge when returned with adated store receipt to the address below. Unitsreturned without a dated store receipt will behandled as described in section“Service Out Of Warranty.” Due to the specialized equipment necessary fortesting a Laser-Radar receiver, there are noauthorized service stations for Whistler branddetectors other than Whistler.When returning a unit for service, please followthese instructions:1. Ship the unit in the original carton or in a suitable sturdy equivalent, fully insured, with return receipt requested to:Whistler Repair Dept.1201 North Dixieland RdRogers, AR. 72756Please allow 3 weeks turnaround time.Important: Whistler will not assumeresponsibility for loss or damage incurred inshipping. Therefore, please ship your unitinsured with return receipt requested. CODswill not be accepted!2. Include with your unit the following information, clearly printed:•Your name and street address (for shipping via UPS), a daytime telephone number and an email address, if applicable.• A detailed description of the problem (e.g., “Unit performs self-test but does not respond ` to radar”).•A copy of your dated store receipt or bill of sale.WARRANTY INFORMATION3. Be certain your unit is returned with its serial number. For reference, please write your unit’s serial number in the following space: s/n______________.Units without serial numbers are not covered under warranty.Important: To validate that your unit is withinthe warranty period, make sure you keep acopy of your dated store receipt. You mayregister your warranty online at www.whistlergroup.com, however, for warranty verification purposes, a copy ofyour dated store receipt must accompany anyunit sent in for warranty work.Service Out of WarrantyUnits will be repaired at ‘out of warranty’ servicerates when:• The unit’s original warranty has expired.• A dated store receipt is not supplied.• The unit has been returned without its serial number.•The unit has been abused, modified, installed improperly, or had its housing removed.The minimum out of warranty service fee foryour Whistler detector is $55.00 (U.S.). If yourequire out of warranty service, please returnyour unit as outlined in the section “ServiceUnder Warranty” along with a certified check ormoney order for $55.00. Payment may also bemade by MasterCard, VISA or AmericanExpress; personal checks are not accepted. In the event repairs cannot be covered by theminimum $55.00 service fee, you will becontacted by a Whistler technical servicespecialist who will outline options available toyou.If you elect not to have your unit repaired, it willbe returned to you along with your certifiedcheck or money order.WARRANTY INFORMATIONImportant: When returning your unit for service,be certain to include a daytime telephone number and an email address (if applicable).Customer ServiceIf you have questions concerning the operation of yourWhistler detector, or require service during or after thewarranty period, please call Customer Service at: 1-800-531-0004Representatives are available to answer your questionsMonday - Friday from 8:00 a.m. to 5:00 p.m. (CT) orvisit the FAQ’s at www.whistlergroup.com.SPECI FIC ATIONSLaser Wavelength: 905 + 50 nanometers (nm)Radar Frequencies:10.500 - 10.550 GHz (X Band)24.050 - 24.250 GHz (K Band)33.400 - 36.000 GHz (Ka Superwideband)13.425 - 13.475 GHz (Ku Band)Operating Temperature Range:-20˚ C to +80˚ C (-4˚ F to +176˚ F)Power Requirements:12 volts, center tip positive.One or more U.S. patents may apply:#5,146,227, #5,379,456, #5,666,120, #5,990,821POP™ Mode is a trademark of MPH Industries,Inc. Specifications are subject to changewithout notice.WARRANTY INFORMATIONThese and other accessories can beordered directly from Whistler by calling 1-800-531-0004 or visit our online store atwww.whistlergroup.comOOrrddeerr ##DDeessccrriippttiioonnPPrriiccee 403774 Intellicord™ $27.95202152 Windshield Bracket Kit $ 9.95206552 Straight Power Cord (5’) $ 14.95206553 Coiled Power Cord (7’) $ 15.95206880 Hardwire Kit (10' ) $ 9.95(for wiring to fuse box)206666 Modular Cord Package $ 17.95(includes coiled and straight cords, and power adapter)402081 Non Skid Dash Pad $ 6.95206660 Straight Modular Cord & $ 11.95Socket Multiplier 206661 Coiled Modular Cord & $ 12.95Socket Multiplier 260 05P Replaceable Ring and Insert Set$ 14.95Includes 6 trim rings: metallicblue, metallic gold, metallic red, pink, silver and white and2 inserts: metallic silver and metallic black.* Modular: Interconnecting pieces cord and plug.SShhiippppiinngg aanndd hhaannddlliinngg ((ppeerr oorrddeerr)) $$55..0000 .. PPrriicceess aarree ssuubbjjeecctt ttoo cchhaannggee wwiitthhoouutt nnoottiiccee..ACCESSORIESOWNER’S MANUALThe Whistler Group Corporate Headquarters13016 N. Walton Blvd. • Bentonville, AR 72712Tel 479.273.6012 • Fax 479.273.2927Customer Return Center1201 N. Dixieland Rd. • Rogers, AR 72756Customer Service Tel 800.531.0004www.whistlergroup.comP/N 260015, ©2006 The Whistler Group, Inc.14 15 16 17 18 19 2021 22 23 24 25 26XTR-325/425/560DETECTORLASER-RADARTotal Band Protection™Plus Ku
WHISTLER FEATURES FEATURE DESCRIPTIONSInstallation•Locate the tab near the button openings and insert this end first into the unit.• Gently snap in the other tabs as you work your way to the back of the unit.Mounting Guidelines•Mount the unit as low as possible near the center of the windshield. • Do not mount your unit behind wipers, ornaments, mirrored sunscreens, etc. These obstructions have metal surfaces which can affect radar and laser signals and reduce critical warningtime. (Regular tinted glass does not affect reception.)• Some windshields have an Instaclear™or Electriclear™type coating, which affect radar signals.Consult your dealer or the vehicle’s owner’s manual todetermine if your windshield has this coating.•Avoid placing unit in direct contact with windshield.• Avoid placing unit in direct sunlight.•To reduce the possibility of theft, conceal your unit when not in use.Windshield Mounting• Install the two suction cups and rubber bumper onto the bracket by fitting them into their holes.•Press the suction cups onto the windshield at the location you have chosen.•Slide the detector onto the bracket until it locks into place.• If necessary, the unit may be leveled by bending the windshield bracket. •Press the bracket release button and remove the detector before bending.INSTALLATIONPower Cord Connection•Plug the small end of the power cord into the unit’s power jack.• Plug the large end into the vehicle’s cigarette lighter.NNoottee::The cord fits tightly into detector. Wheninstalling the cord, expect some resistance. Fuse ReplacementThe lighter socket plug is equipped with areplaceable 2 amp 3AG fuse located behind thesilver tip. To replace the fuse, carefully unscrewthe tip of the plug.IImmppoorrttaanntt::Unscrew slowly. The tip contains aspring which may fly out when disassembling.Insert the new fuse with the spring and screw onthe tip. With use, the screw cap on plug mayloosen. Retighten it occasionally.Unscrew the tip of the lighter socket plug carefully when replacing the 2 amp fuse.OPERATIONProgrammable Text Display (XTR 425/560 only)The above models have the ability to modify thestandard laser/radar detector’s display.“WHISTLER”, “HIGHWAY”, “CITY”, “CITY 1”,and “CITY 2” can be changed to display yourname, or any combination of 8 characters. Forexample, “HIGHWAY” can be changed to “GO4 IT”. Note: A space is counted as a character. WARNING!!! Programming the text display orthe audio is not intended to be done while youare driving. You should not use any device in avehicle that may distract you from observing theroad ahead.INSTALLATIONTo Modify the Text•Press and hold the Quiet button to enter Option mode (see page 13 ). Once “USER TEXT” is displayed simultaneously press and release the VOL UP and VOL DOWN buttons each time to scroll through the text that can be customized. When a text is selected, (use WHISTLER for example) the display will indicate “WHISTLER” with a blinking cursor under the letter “W”. Note: The blinking cursor indicates that this isthe first letter ready to be changed.• Press the Volume Up button to advance to the next letter/character/symbol/space to be displayed.• Press the Volume Down button to select the previous letter/character/symbol/space to be displayed.• Press the Quiet button to advance to the next position in the current word.• Press the City button to go back to the previous position in the current word•Press and hold the City button to change the character set (A, a, 9, ! etc.).• Press PWR to exit User Text Mode and return to OPTION Mode.• Press PWR again to exit OPTION Mode.Programmable Audio Tones (XTR 560 Only)Model XTR 560 also has the ability to modify thestandard laser/radar detector’s audio tones. Audiotones such as “X Band”, “K Band,” “Ka Band” “KuBand” and “Laser” can be changed to play up to 15seconds of a favorite tune, phrase, saying, almostanything you like. When the unit detects K band, forexample, the K band voice will now be followed bywhat was recorded for K band.TIP: Turn off the voice option to have the unitrespond only with the custom recorded alerts.OPERATIONTo Modify the Audio, Part 1•Press and hold the Quiet button to enter Option Mode (see page 13 ). Once “USER TONE” is displayed, simultaneously press and release the VOL UP and VOL DOWN buttons to allow for selection of Normal Tones or Custom Tones. (Display shows “ X - Norm” or “ X - Cust”) The Vol Up button selects Custom Tone and Vol Down button selects Normal Tone. The Quiet button advances the menu to the next band selection. “X - Norm”—› “K - Norm”—› “Ka - Norm” —› “Ku - Norm” —› “L - Norm”The PWR button exits User Tone Mode, but stillremains in Option Mode. Press the PWR buttonagain to exit Option Mode.To Modify the Audio, Part 2IMPORTANT: Unit does not detect radar orlaser signals during recording or while playing atone.To ensure a quality recording, the sourceshould be approximately 1” away from themicrophone.To record or play a message (Record/PlaybackMode):• Press both volume buttons for less than 2 seconds and release. The unit will beep once; this enters Custom Mode. Display shows: CUSTOMThe display shows the word PLAY and REC with accompanying arrows to indicate the buttons to control these functions (Start/Stop Play = PWR and Start/Stop Rec = City). • The display then indicates: CUST--X as X is the first band ready to record up to 15 seconds of audio. • Press and release the Quiet/Record button advances the recording feature to the next band.• Press both volume buttons for less than 2 seconds and release to exit Record/Playback mode.OPERATIONNOTE: Custom Mode automatically exits within 20seconds if a button is not pressed. Messages arekept in memory and are not affected by resettingthe factory features. See “Reset Features” section ofthe manual.To delete a message:• Enter Custom mode and press Volume Up or Volume Down button until selected band appears on the display.• Press the Quiet/Record button twice. TIP: To prevent the recording of the stop buttonpress (click), allow the recording process to continuefor 15sec and automatically time out.Power On and Self-TestEach time your Whistler detector is turned on,an automatic self-test sequence confirms thatthe speaker and visual displays are functional.• Press Power. Display shows in order: 1. WHISTLER 2. X-Band 3. K-Band 4. Ka-Band5. Ku-Band 66.LASER 7. POP ON 8. VG2 OFF9. SR OFF 10. Highway• Display indicators will illuminate in the same order on the XTR-325Setting SaverSetting Saver saves your personalized settingsso that when the detector is turned off and thenon again, you do not have to re-enter them.Feature Engaged ConfirmationEach time a button is pressed, one beep confirmsfeature “on”, two beeps confirm feature “off”.Audio Level AdjustmentThe audio levels can be adjusted high to low orlow to high.• Press Volume up to increase audio level.• Press Volume down to decrease audio level.As audio level is adjusted, beeps are provided and the display indicates volume level.OPERATIONAuto Quiet ModeAuto Quiet reduces the selected audio level tolevel (1) approximately 5 seconds after a radar orsafety radar signal is detected. The alert for anynew signal within 20 seconds will resume at level(1). Auto Quiet does not affect VG-2 or laseralerts.• Press Quiet/Menu (before a signal is detected) to engage Auto Quiet. • Once the Auto Quiet mode is engaged, you may cancel the audio alarm by pressing Quiet.• Press Quiet (when the unit is not alarming) tocancel Auto Quiet mode.Quiet ModeQuiet cancels audio during an alert and any newalert within 20 seconds. After 20 seconds,approximately 2 beeps are provided on any newalert and unit then remains quiet.•Press Quiet to cancel the audio.•Press Quiet a second time during an alert to restore the standard audio alert pattern; or turnthe unit off, then on.Teach/Tutorial ModeProvides simulated alerts for each type of signal.• Press City and Quiet simultaneously and release.• Display Shows: (XTR-425/560 only)• Press Power to exit.Highway ModeHighway mode provides full audio warnings anytime radar (X, K, Ka, Ku, Safety Radar) or lasersignals aredetected, and is recommended foropen road driving.( Highway mode lets every signal in)For more information on City and Highway mode, pleasevisit our FAQ page on our website:www.whistlergroup.comOPERATIONCity/City 1/City 2 ModeWhistler’s Three Stage City Mode is designed toreduce the annoyance of automatic dooropeners, intrusion alarms and other devices whichshare frequencies with police radar. Generally, Xband is used for these devices.• Press City to cancel Highway mode and engage City. • Press City again to enter City 1 Mode - display shows ‘C1 Lo X’. (XTR 425/560)• Press City again to enter City 2 Mode - display shows ‘C2 No X’ (XTR 425/560)• Pressing City a fourth time cancels City 2 Modeand returns the unit to Highway Mode.In City Mode, weak speed/safety radar signalgive an initial alarm of two beeps, and thenremains quiet unless the signal becomes verystrong. When the signal strength increases, twoadditional beeps are provided. City 1 and City 2Modes operate the same as Highway Mode, butin City 1 Mode, only the X band sensitivity islowered. In City 2 Mode, X-band is not detected.Caution: Some towns/small cities may still beusing X band radar. City Modes do not changethe audio alert for laser or VG-2.Engaging/Disengaging VG-2 See Option Select Mode to turn this featureon/off. When a VG-2 signal is detected, the VG-2alert is sounded and the display flashes “VG-2”.After 3 seconds the audio is canceled and thedisplay no longer flashes. This cycle is repeatedif the VG-2 signal is again detected. During theperiod a VG-2 signal is detected, a radar signalcannot be detected. However, because the VG-2alert has confirmed that a patrol car is nearby,you are already aware of the potential for speedmonitoring and can adjust your speedaccordingly. Laser detection is not affected whilea VG-2 signal is detected.OPERATIONBacklight Setting (XTR 425/560)The backlighting (B/L) can be programmed tobe illuminated all the time, only when alarming,or choices in-between. The options areselectable by pressing and holding thePower/Dim button on the unit. The options are:OFF-OFF = B/L is off at idle and off during an alarm.OFF-DIM = B/L is off at idle and dim during an alarm.OFF-BRT = B/L is off at idle and bright during an alarm.DIM-OFF = B/L is dim at idle and off during an alarm.DIM-BRT = B/L is dim at idle and bright during an alarm.BRT-BRT = B/L remains bright at idle as well as alarming.Backlight will turn on, if selected, while the unitalarms and remain on for 3 seconds after the unitstops alarming. When any button is pressed thebacklight will illuminate at the dim setting andremain on for 3 seconds afterwards. The backlightwill also illuminate while in option mode.Dim/Dark (XTR-325 only)Dim/Dark Mode reduces the illumination of thedisplay.•Press and hold B/L button for 2 seconds to reduce illumination to a Dim setting.• Pressing and holding the B/L button for 2 seconds a second time engages Dark Mode. The display illumination is further reduced.Dim or dark can be engaged during an alert. InDark Mode, the display goes dark for as long asa signal is being detected and for 20 secondsafter, then the display returns to the dimmersetting.•Pressing and holding the B/L button a third time restores full illumination to the display.OPERATION OPERATION OPERATIONDear Whistler Owner,If you have questions concerning the operation ofthis Whistler product please call:CuSTOmer SeRVICE1-800-531-0004Monday - Friday • 8:00 am - 5:00 pm CTor visit our websitewww.whistlergroup.comPlease keep the receipt in a safe place. You mayregister your product online at www.wwhhiissttlleerrggrroouupp..com.For warrantyverification purposes, a copy of your datedstore receipt must still accompany any unit sent in forwarranty work. If the unit is returned without a datedstore receipt an out of warranty service charge applies. Note: YYoouurr wwaarrrraannttyy ppeerriioodd bbeeggiinnss aatt tthhee ttiimmee ooffppuurrcchhaassee.. TThhee wwaarrrraannttyy iiss vvaalliiddaatteedd oonnllyy bbyy tthhee ddaatteeddssttoorree rreecceeiipptt!! Now is the time to record the serialnumber of the unit in the space provided in thewarranty section of the manual.To fully acquaint yourself with the operation of yourWhistler and to better understand the differencesbetween detecting radar, laser and safety radarsignals, we recommend reading this entire manual orvisit our FAQ page on our websitewww.whistlergroup.comEnjoy your Whistler detector and please drive safely.Sincerely,The Whistler Group, Inc.19111026453713Accessories:Windshield Bracket Kit, Straight Power Cord & 2 Trim Rings12aXTR-325/425/5606. Rear Laser Antenna – An integrated optical waveguide provides superior detection of laser signals transmitted from behind.7. City Button - Reduces the annoyance of false alerts typically encountered in urban driving areas.8. Quiet/Menu Button - Pressing QUIET before asignal is detected engages Auto Quiet Mode. Pressing QUIET during a radar/laser encounter silences audio alerts.(Pressing and holding for 2 seconds allows you to enter Option Select Mode—see page 12)9. Power/Dim -Turns unit on/off and engages Backlight settings (press and hold).10. Volume Down Button – Adjust volume down.11. Volume Up Button – Adjust volume up.12a. Blue Backlit LCD Programmable Text Display – Provides distinct visual confirmation of signals detected, signal strength, and indicates engaged modes of operation.12b. Seven Segment Icon Display –Provides band and numeric signal strength indicators13. Power Jack –Provides connection for the power cord.14. Removable Trim Ring –Allows changing the trim ring to one of the other colors.15. External Audio Jack –Permits easy connection of an external speaker/headset to the XTR 560.16. Microphone –Allows recording of audio tones in model XTR-560INSTALLATIONTrim Ring Removal/InstallationTo change the trim ring to another color, followthese simple steps:Removal•Locate the tab on the trim ring at the top of the mounting bracket location.• Using your fore finger, lift up on the trim ring and the ring will pop out.8WindshieldMounting34567 8 9 10 11 12 13Model Features Summary .................... 2 - 3Installation ........................................... 3 - 5•Changing Trim Rings 4•Mounting Guidelines 4•Windshield Mounting 5•Power Connection and Fuse Replacement 5Operation .......................................... 5 - 14•Programmable Text Display 5•Programmable Audio Tones (XTR 560 Only) 6 - 8•Power On and Self-Test 8•Setting Saver 8•Feature Engaged Confirmation 8•Audio Level Adjustment 8•Auto Quiet Mode 9•Quiet Mode 9•Teach/Tutorial Mode 9•Highway Mode 9•City/City 1/ City 2 Mode 10•Engaging/Disengaging VG-2 10•Backlight Setting 11 •Dim/Dark Mode 11•Intelli-cord™ 12•Battery Saver Mode 12•External Audio Jack 12•Option Select Mode 13•Stay Alert Feature 14Safety Warning System™ ......................... 14POP™Mode Alerts ................................. 15Laser/Radar Alerts ................................. 15•Speed Radar Audio/Visual Alerts 15•Laser Audio/Visual Alerts 15•Pulse Protection® 15VG-2 Alerts ............................................ 16•Alert Priority 16Reset Features ....................................... 16Troubleshooting Guide .......................... 17Care and Maintenance ........................... 18Are Detectors Legal? ............................. 18FCC Information ..................................... 19Speed Monitoring ............................ 19 - 22•Radar Facts 19•POP™Mode 19•Total Band Protection™ 20•Laser Facts 20•Other Speed Detection Systems 21 -22Warranty Information ....................... 22 - 25Specifications ......................................... 25Accessories ............................................ 26Rubber BumperOption Select Mode Entering Option Select Mode allows you to customizeoptions such as Tone Select, Abbreviated Power UpSequence and VG-2 Mode. Press and hold quietbutton to enter Option Select Mode. When selectingoptions, the volume up , volume down orQuiet buttons must be pressed within 20 seconds orOptions Mode will automatically be exited. To enter: 2Intelli-Cord™Using Whistler’s optional Intelli-Cord™PowerCable allows some models to control thedetector’s features such as Power On/Off, CityModes, Dim/Dark, and Quiet/Auto Quiet with asimple press of the button on the Power Cable.Two features can be controlled: one by a shortpress of the button (S1), and the second by along press of the button (S2). Option Modeallows the user to program the featureassignments.Vehicle Battery Saver ModeThe Vehicle Battery Saver Mode automaticallyshuts off your detector if you forget to turn it off.The timer is reset if the detector is turned off,unplugged or any button is pressed before thetimer has expired. The detector will alert you withan audible and visual warning before it shuts off. During this warning you can reset the unit bypressing any button. This will reset the timer.If the unit has automatically turned itself off, press thePower button to turn the unit back on. You canmanually engage the Vehicle Battery Saver Modeby pressing and holding the City button until onebeep is heard. (XTR-425/560 Only)Refer to “Option Select Mode” for instructionsfor deactivating battery saver mode feature. (XTR-425/560 Only)XTR-325 Timer = 6 hrs, XTR-425/560 Timer = 3 hrsExternal Audio JackThe External Audio Jack can be used toconnect an external speaker or headphonesin environments with high ambient noise levels.The internal speaker will be disconnected.1412bXTR-325XTR-425/560FEATURE DESCRIPTIONSNOTE: Not all units share all the features listedWhistler’s ergonomic and user-friendly designprovides a new level of operating convenience.Special features include: 1. Bracket Release Button – Provides quick and easy release of the mounting bracket.2. Speaker – Provides distinct audio warnings forX, K, Ka, Ku band radar, safety radar, laser and VG-2.3. Mounting Bracket Location – Slot holds mounting bracket firmly.4. Radar Antenna – Compact, high-efficiency antenna receives radar signals.5. Front Laser Antenna –High gain optical lens provides increased sensitivity and field of view for leading-edge laser detection1615
