USERS MANUAL
The telephone company may make changes in its communications facilities, equipment,
operations or procedures where such action is required in the operation of its business and
not inconsistent with FCC Rules and Regulations. If these changes are expected to affect the
use or performance of your telephone equipment, the telephone company must give you
adequate notice, in writing, to allow you to maintain uninterrupted service.
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference; and (2) This device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.
Privacy of Communications may not be ensured when using this product.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or television
that is “receiving” the interference).
• Reorient or relocate and increase the separation between the telecommunications
equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that
to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an
experienced radio/television technician for additional suggestions. Also, the Federal
Communications Commission has prepared a helpful booklet, “How To Identify and Resolve
Radio/TV Interference Problems.” This booklet is available from the U.S. Government Printing
Of-ce, W ashington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering
copies.
Notice: The changes or modi-cations not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
EQUIPMENT APPROVAL INFORMATION
Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network,
the telephone company shall, where practicable, notify you that temporary discontinuance
of service may be required. Where prior notice is not practicable and the circumstances
warrant such action, the telephone company may temporarily discontinue service
immediately. In case of such temporary discontinuance, the telephone company must: (1)
promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission
pursuant to procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
FCC RF RADIATION EXPOSURE STATEMENT
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body. This transmitter must not be co-located or
operated in conjunction with any other antenna or transmitter.”
For body worn operation, this phone has been tested and meets the FCC RF exposure
guidelines when used with the belt clip supplied with this product. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines.
SE E MAR KI NG ON B OTTOM / B ACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PRE VENT FIRE OR
ELECTRICAL S HOCK
HAZARD, DO NOT
EXPOS E THIS
PRODUCT TO R AIN
OR MOIS TUR E.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING S IGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
GE-21518XX-A
BLUETOOTH
TELEPHONE ADAPTOR
USER'S GUIDE
INTRODUCTION
CAUTION: When using telephone equipment, there are basic
safety instructions that should always be followed. Refer to the
IMPORTANT SAFETY INSTRUCTIONS provided with this product
and save them for future reference.
BEFORE YOU BEGIN
Parts Checklist
Make sure your package includes the items shown here.
TELEPHONE JACK REQUIREMENTS
To use this phone, y ou need an RJ11C type modular telephone
jack, which might look lik e the one pictur ed here, installed in
your home. If you don’t have a modular jack , call your local
phone company to -nd out how to get one installed.
Modular
telephone
line jack
Wall plate
IMPORTANT INSTALLATION GUIDELINES
• Avoid sources of noise and heat , such as motors, fluorescent lighting, microwave
ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid cordless telephones or personal computers.
• Never install 21518 wiring during a lightning storm.
• Never install telephone jacks in w et locations unless the jack is speci-cally
designed for w et locations.
• Never touch non-insulated telephone wir es or terminals, unless the telephone line
has been disconnected at the netw ork inter face.
• Use caution when installing or modif ying telephone lines.
BASE LAYOUT
Installation
1. Chose an area near an electrical outlet and a telephone wall jack (RJ11), and
place GE-21518XX-A on a level surface, such as a desktop or tabletop.
2. Connect one end of telephone line cord it into GE-21518XX-A LINE jack
and the other end into telephone wall jack.
3. Connect line cord of home phone to PHONE jack of GE-21518XX-A.
4. Plug AC power converter into electrical outlet and L plug into the power jack
of 21518.
5. Red LED of GE-21518XX-A will be on.
Pair and Connect
GE-21518XX-A supports a maximum of two Bluetooth phone devices.
1) Press and hold CELL 1 button until LED flashing, GE-21518XX-A is entered to
pairing mode. To stop pairing, press CELL 1 again.
2) Refer to instruction manual of cell phone on proper procedure to add and pair
a new device.
3) Use the number keys to enter the default PIN 0000 on Bluetooth cell phone
device. When the device is paired and connected successfully, CELL 1 LED of
GE-21518XX-A will be on continuously.
To pair and connect the other cell phone with GE-21518XX-A, use CELL 2 button
with same procedure as above.
Disconnect
Press and release CELL 1button, CELL 1 LED will be off, GE-21518XX-A will
disconnect cell 1 with cell phone. Press CELL 1 again, cell 1 connection will be
resumed.
To disconnect cell 2, use CELL 2 button with same procedure as above.
Cancel pairing
Press and hold CELL 1 button for 5 seconds to cancel cell 1 pairing, CELL 1 LED
will be off.
To cancel cell 2 pairing, use CELL 2 button with same procedure as above.
Making A Call Via Telephone Line
Pick up handset of land phone, a dial tone will be heard. Dial the desire number.
If telephone line is unplugged or in-used by other phones, three beep warning tone
will be heard. If you want to mark call via cell, refer below.
Making A Call Via Cell
Pick up handset of land phone, a dial tone will be heard (If telephone line is
unplugged or in-used by other phones, three beep warning tone will be heard).
Dial *1# (or *2#) following the desire number then # to make call via cell 1 (or cell2).
Answering A Call
Pick up handset of land phone.
Parallel Phone Operationc
If telephone line is in-used by other phone, pick up handset of land phone, three
beep warning tone will be heard, dial *0# to connect land phone with telephone
line for parallel phone operation.
Trouble Shooting Guide
No dial tone
* Ensure the AC adapter is plug in to a working electrical outlet.
* Check and repeat installation steps:
Ensure the AC adapter is plug in to a working electrical outlet.
Ensure the telephone line cord is connected to the LINE jack of
GE-21518XX-A and the wall jack.
* Connect another phone to same wall jack, if there is still no dial tone, the
problem might be your wiring or local service.
You experience static, noise, or fading and out
* The CELL phone may be out of range from GE-21518XX-A. Move it to a
distance of 2 feet to 10 feet from GE-21518XX-A.
* The CELL phone may be too closely from GE-21518XX-A. . Move it to a
distance of 2 feet to 10 feet from GE-21518XX-A.
* Make sure GE-21518XX-A is not plugged into an outlet with another
household appliance. If necessary, relocate GE-21518XX-A.
* The CELL phone may be too closely from home phone. Move it to a
distance of 2 feet to 10 feet from home phone.
Unit lock up
* Unplug the AC power adapter from the wall outlet and back of unit. Wait
for 5 seconds and plug the power adapter back into the unit and wall outlet.
Model 21518
XXXXXXXX (Rev. X Dom E/S)
XX-XX
Printed in China
Thomson Inc.
101 West 103rd St.
Indianapolis, IN 46290-1102
© 2007 Thomson Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Visit the GE website at: www.GE.com/phones
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction that can shield radio signals.
• You’re too close to appliances such as microwaves, stoves, computers, etc.
• Atmospheric conditions, such as strong storms.
• Unit is installed in the basement or low er oor of the house.
• Unit is plugged into A C outlet with other electronic devices.
GENERAL PRODUCT CARE
To keep your unit working and looking good, follow these guidelines:
• Clean the unit with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the -nish.
• Retain the original packaging, if need to ship the phone at a later date arises.
WARRANTY ASSISTANCE
If trouble is experienced with this equipment, for warranty information, please contact
customer service at 1-800-448-0329. If the equipment is causing harm to the telephone
network, the telephone company may require that you disconnect the equipment until the
problem is resolved.
Any unauthorized repairs, changes or modi-cations not expr essly approved by Thomson Inc.
could void the user’s authority to operate this product. For instructions on how to obtain a
replacement unit, refer to the warranty included in this guide or call customer service at
1-800-448-0329.
Or refer inquiries to:
Thomson Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to this booklet for future reference or jot down the date this product
was purchased or received as a gift. This information will be valuable if service should be
required during the warranty period.
Purchase date
Name of store
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the -r st rental or 45 days from date of
shipment to the rental -rm, whichev er comes -r st.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit is under
warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally provided with the
product. We recommend using the original carton and packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that
the product is within the warranty period, must be presented to obtain warranty service.”
For rental -rms, pr oof of -r st rental is also r equired. Also print y our name and addr ess and
a description of the defect . Send via standar d UPS or its equiv alent to:
Thomson Inc.
11721 B Alameda Ave.
Socorro, Texas 79927
• Insure your shipment for loss or damage. Thomson Inc. accepts no liability in case of
damage or loss.
• A new or refurbished unit will be shipped to y ou freight prepaid.
What your warranty does not cover:
• Customer instr uction. (Y our Owner’s Manual pr ovides information r egarding operating
instructions and user contr ols. Any additional information, should be obtained fr om your
dealer.)
• Installation and setup ser vice adjustments.
• Batteries.
• Damage from misuse or neglect .
• Products which hav e been modi-ed or incorporated into other pr oducts.
• Products purchased or ser viced outside the US A.
• Acts of natur e, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Pr oduct Registration Car d packed with your unit . It will mak e
it easier to contact y ou should it ev er be necessar y. The return of the car d is not r equired
for warranty cov erage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT.
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY
DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION GIVEN BY THOMSON INC., ITS
AGENTS, OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE
SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING
OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS
DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts so the above limitations or
exclusions may not apply to you.
• This warranty gives you speci-c legal rights, and y ou also may have other rights that vary
from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
Telephone
line cord
Base AC power
adaptor
Cell 1
Cell 2
Power
Notice: The changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority 10 operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no
change to the antenna or the device is permitted. Any change to the antenna or the
device could result in the device exceeding the RF exposure requirements and void
user's authority to operate the device.
