Thomson 2-5250AH DECT 6.0 CORDLESS TWO LINE PHONE W/ ITAD SPEAKERPH User Manual USERS MANUAL
Thomson Inc. DECT 6.0 CORDLESS TWO LINE PHONE W/ ITAD SPEAKERPH USERS MANUAL
Thomson >
USERS MANUAL
2-Line Intercom Speakerphone
1.9 GHz Cordless Handset
Telephone Answering System
User’s Guide
Please read this manual
before operating product
for the first time.
Model 25250
2
Equipment Approval Information
Your telephone equipment is approved for connection to the Public
Switched Telephone Network and is in compliance with parts 15 and 68,
FCC Rules and Regulations and the Technical Requirements for Telephone
Terminal Equipment published by ACTA.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other
information, the US number and Ringer Equivalence Number (REN) for
the equipment. You must, upon request, provide this information to
your telephone company.
The REN is useful in determining the number of devices you may
connect to your telephone line and still have all of these devices ring
when your telephone number is called. In most (but not all) areas, the
sum of the RENs of all devices connected to one line should not exceed
5. To be certain of the number of devices you may connect to your line
as determined by the REN, you should contact your local telephone
company.
A plug and jack used to connect this equipment to the premises wiring
and telephone network must comply with the applicable FCC Part 68
rules and requirements adopted by the ACTA. A compliant telephone
cord and modular plug is provided with this product. It is designed to
be connected to a compatible modular jack that is also compliant. See
installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the
telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be
able to use your own telephone equipment if you are on a party line.
Check with your local telephone company.
• Notice must be given to the telephone company upon permanent
disconnection of your telephone from your line.
• If your home has specially wired alarm equipment connected to the
telephone line, ensure the installation of this product does not disable
your alarm equipment. If you have questions about what will
disable alarm equipment, consult your telephone company or a
qualified installer.
US Number is located on the cabinet bottom
REN number is located on the cabinet bottom
Important Information
3
Important Information
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the
telephone network, the telephone company shall, where practicable,
notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant
such action, the telephone company may temporarily discontinue
service immediately. In case of such temporary discontinuance, the
telephone company must: (1) promptly notify you of such temporary
discontinuance; (2) afford you the opportunity to correct the situation;
and (3) inform you of your right to bring a complaint to the
Commission pursuant to procedures set forth in Subpart E of Part 68,
FCC Rules and Regulations.
The telephone company may make changes in its communications
facilities, equipment, operations or procedures where such action is
required in the operation of its business and not inconsistent with FCC
Rules and Regulations. If these changes are expected to affect the use
or performance of your telephone equipment, the telephone company
must give you adequate notice, in writing, to allow you to maintain
uninterrupted service.
Interference Information
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference; and (2) This device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for
radio or television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit
different from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your
dealer or an experienced radio/television technician for additional
suggestions. Also, the Federal Communications Commission has prepared a
helpful booklet, “How To Identify and Resolve Radio/TV Interference
Problems.” This booklet is available from the U.S. Government Printing
Office, Washington, D.C. 20402. Please specify stock number
004-000-00345-4 when ordering copies.
4
Notice: The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
Licensing
Licensed under US Patent 6,427,009.
Hearing Aid Compatibility
This telephone system meets FCC standards for Hearing Aid Compatibility.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 centimeters between the
radiator and your body. This transmitter must not be co-located or
operated in conjunction with any other antenna or transmitter.”
For body worn operation, this phone has been tested and meets the FCC
RF exposure guidelines when used with the belt clip supplied with this
product. Use of other accessories may not ensure compliance with FCC RF
exposure guidelines.
Important Information
5
EquipmEnt ApprovAl informAtion ....... 2
intErfErEncE informAtion ................... 3
licEnsing .......................................... 4
HEAring Aid compAtibility ................. 4
fcc rf rAdiAtion ExposurE
stAtEmEnt ...................................... 4
introduction ..................................... 7
pArts cHEcklist ................................. 7
tElEpHonE JAck rEquirEmEnts ............. 7
instAllAtion ...................................... 8
Digital Security SyStem .......................8
importAnt instAllAtion guidElinEs ...... 8
HAndsEt lAyout ................................ 9
bAsE lAyout .................................... 10
instAlling tHE pHonE ........................11
inStalling the hanDSet Battery ........11
BaSe Station...................................... 12
progrAmming tHE pHonE ................ 14
StanDBy Screen ................................. 14
Programming FunctionS................... 14
Phone Setting ................................... 14
Date/time .......................................... 15
auto anSwer .................................... 15
auto anSwer intercom .................... 15
Dial moDe ......................................... 16
room monitor .................................. 16
area coDe ......................................... 16
2nD call alert ............................... 16
hanDSet name .................................. 17
regiStration ...................................... 17
regiSter .......................................... 17
De-regiSter (hanDSet) ...................... 18
De-regiSter (BaSe) ............................ 18
DiSPlay Setting .................................. 18
contraSt ............................................ 19
BS Backlight .................................... 19
SounD Setting ................................... 19
ring Volume ..................................... 20
key tone ............................................ 20
anSwer SyStem ................................. 20
meSSage alert .................................. 20
oga PlayBack ...................................21
anSwering SyStem .............................21
ring Delay ........................................ 22
meSSage length ................................ 22
call Screening.................................. 22
remote PaSSworD ............................. 22
work hourS ..................................... 23
aFter hourS ...................................... 23
conFig oga ...................................... 23
memo recorDing .............................. 24
tElEpHonE opErAtion ....................... 24
making callS with the corDleSS
hanDSet ........................................ 24
making callS in the SPeakerPhone
moDe ............................................. 24
making callS with the oPtional
heaDSet ......................................... 25
Pre-Dialing ........................................ 25
anSwering a call ............................. 25
Switching Between the SPeakerPhone,
hanDSet, anD heaDSet moDe ....... 26
BaSe ............................................ 26
corDleSS hanDSet........................ 26
mute .................................................. 26
Do not DiSturB ................................ 26
FlaSh ................................................. 26
inSerting a PauSe in the Dialing
Sequence ...................................... 26
reDial ................................................ 27
reViewing the reDial numBerS ........ 27
Storing a reDial recorD in Phone
Book ............................................. 27
tranSFerring a call to another
extenSion ...................................... 27
receiVing a tranSFerreD call From
another extenSion ....................... 27
ringer on/oFF .................................. 28
SPeakerPhone, hanDSet, anD heaDSet
Volume ......................................... 28
holD .................................................. 28
conFerence callS ............................. 28
intErcom cAlls ............................... 28
one-touch intercom ........................ 28
anSwering an intercom call ........... 29
Page ................................................... 29
auto StanDBy .................................... 29
cAllEr id (cid) ............................ 29
receiVing anD Storing ciD
recorDS ........................................ 30
reViewing ciD recorDS ................... 30
SaVing a ciD recorD to Phone Book
memory ........................................ 30
Deleting a ciD recorD .................... 30
Deleting all call recorDS............... 30
Dialing Back ......................................31
iF you ProgrammeD your local
area coDe .....................................31
iF you DiD not Program your
local area coDe ..........................31
call waiting caller iD ....................31
mEmory log And pHonE book
(dirEctory) mEmory ..................... 32
aDDing Phone Book entrieS............. 32
reViewing Phone Book recorDS ...... 33
eDiting a Phone Book recorD ......... 33
coPy current Directory ................... 33
coPy entire Directory ...................... 33
Deleting a Phone Book recorD ....... 33
Table of Contents
6
Table of Contents
Dialing a Phone Book recorD ......... 34
Dial a Phone Book recorD while in
talk moDe ..................................... 34
Dial a Phone Book recorD while
reViewing it .................................. 34
AnswEring systEm opErAtion........... 34
anSwering SyStem on/oFF .............. 34
recorDing incoming meSSageS ........ 34
monitoring incoming callS ............. 35
memo recorD ................................... 35
icm/memo PlayBack ....................... 35
eraSing meSSageS ........................... 35
to eraSe a meSSage while it iS
Playing ........................................ 35
to eraSe a meSSage aFter it
Playing .......................................... 35
to eraSe all PreViouSly PlayeD
meSSageS in a mailBox ................. 36
remote acceSS From remote
Party ............................................ 36
memory Full ..................................... 36
cHAnging tHE bAttEry ......................37
bAttEry sAfEty prEcAutions .............37
displAy mEssAgEs ........................... 38
HAndsEt sound signAls ................... 38
troublEsHooting guidE ....................39
telePhone SolutionS ......................... 39
caller iD SolutionS ......................... 40
Battery .............................................. 40
gEnErAl product cArE .................... 40
cAusEs of poor rEcEption ............... 40
wArrAnty AssistAncE ...................... 41
limitEd wArrAnty ...........................42
AccEssory informAtion .................... 43
7
Introduction
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them for
future reference.
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power
in your home goes out.
Connections & Setup
Parts Checklist
Make sure your package includes the following items:
Base
Handset
Handset battery
pack
Telephone
2- Line cords
AC power
adaptor
L1
NEW
FORMAT
DELETE STORE
LINE1 LINE2
L1
PLAY
Battery
Compartment
Cover
Wall mount
bracket
Telephone Jack Requirements
To use this phone, you will need an RJ11C (for
a single line) or a RJ14C (for two lines) type
modular phone jack, which might look like the
one pictured here, installed in your home or
office. If you don’t have either modular jack,
call your local phone company to find out how
to get one installed.
Modular
telephone line
jack
Wall plate
8
Connections & Setup
Installation
Digital Security System
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
INSTALLATION NOTE: Some cordless telephones operate at frequencies that
may cause or receive interference with nearby TVs, microwave ovens, and
VCRs. To minimize or prevent such interference, the base of the cordless
telephone should not be placed near or on top of a TV, microwave ovens,
or VCR. If such interference continues, move the cordless telephone farther
away from these appliances.
Certain other communications devices may also use the 1.9 GHz frequency
for communication, and, if not properly set, these devices may interfere
with each other and/or your new telephone. If you are concerned with
interference, please refer to the owner’s manual for these devices on how to
properly set channels to avoid interference. Typical devices that may use the
1.9 GHz frequency for communication include wireless audio/video senders,
wireless computer networks, multi-handset cordless telephone systems, and
some long-range cordless telephone systems.
Important Installation Guidelines
• Avoid sources of noise and heat, such as motors, fluorescent lighting,
microwave ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid other cordless telephones or personal computers.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the
telephone line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
9
Connections & Setup
Handset Layout
LINE1 LINE2
L1
PLAY
display
DND/Privacy
(button) Spk
(Speaker button)
DIR
(button)
CID
(button)
3 Soft keys
VOL +/-
(buttons)
Talk
(button)
Off
(button)
Redial
(button)
Menu/Flash
(button)
Exit
(button)
Int/Hold
(button)
Mute/Del
(button)
10
Base Layout
Connections & Setup
DND/Privacy
(button)
L1
NEW
FORMAT
DELETE STORE
Delete
(button)
Exit
(button) 3 Soft Keys
Play/Stop
(button)
Memo
(button)
Ans Sys
(button)
DIR
(button)
CID
(button)
Vol +/-
(buttons)
Line 1 & 2
(buttons)
Intercom
(button)
Page
(button)
Redial
(button)
Hold
(button)
Headset
(button)
Flash
(button)
Mute
(button)
Speaker
(button)
Charge
LED
One Touch
(1-10)
buttons
11
Connections & Setup
Installing the Phone
Installing the Handset Battery
NOTE: You must connect the handset battery before use.
CAUTION: To reduce the risk of fire or personal injury, use only the
Thomson Inc. approved Nickel-metal Hydride (Ni-MH) battery model
5-2734, which is compatible with this unit.
1. Locate battery which is packaged inside a plastic bag and is separate
from the handset.
2. Locate the battery compartment on the back of the handset.
3. Plug the battery pack cord into the jack inside the compartment.
NOTE: To ensure proper battery installation, the connector is keyed and can
be inserted only one way.
4. Insert the battery pack.
5. Close the battery compartment by placing the handset back cover
slightly higher than the handset and then sliding the cover down into
position.
BATTERY
BLACK WIRE
RED WIRE
PRESS DOWN FIRMLY
12
Base Station
The phone may be connected to two line (RJ14C) wall jacks to
accommodate all two lines.
1. Choose an area near an electrical outlet and a telephone wall jack
(RJ11C), and place your cordless telephone on a level surface, such as a
desktop or tabletop, or you may mount it on the wall.
2. Plug the power supply cord into the power jack on the back of the base
and the other end into an electrical outlet.
3. Connect the telephone line cords:
If you have 2 single-line wall jacks installed in your home or office, you
can use adaptors/couplers (not included) to combine the 2 single
telephone lines into 1 dual lines. The adaptor/coupler may look similar
to the one pictured here and can be purchased from your local
telephone products retailer.
Or , you can use the 2 single telephone lines plug into the 2 jacks on
the back of the telephone.
Connections & Setup
13
4. If you wants to mount the telephone on the wall, you can plug the 2
lines such as the below drawing;
Connections & Setup
OR
5. Place the handset in the base cradle. The charge/in use indicator turns
on, verifying the battery is charging.
6. Allow the phone to charge for 14 hours prior to first use. If you don’t
properly charge the phone, battery performance is compromised.
CAUTION: Use only the Thomson Inc. 5-2735 power adaptor that
came with this unit. Using other power adaptors may damage the
unit.
14
Programming the Phone
Standby Screen
The handset displays the handset name, date, time, and battery status and
the three soft keys.
The base displays the current date, time and the three soft keys.
NOTE: The three soft keys will change according to the status of the unit.
Programming Functions
The system uses a menu structure to give you access to all of the built-in
features. You may program the following items in main menu: Phone
Setting, Display Setting, Sound Settings, Answering System and Load
Default.
NOTE: During programming, you may press the back Soft key (left) at any
time to exit the sub-menu and return to the main menu, or press Exit key to
exit programming and return to standby screen.
NOTE: If no key is pressed for 30 seconds, the handset will automatically exit
programming and return to standby screen.
Phone Setting
1. Make sure your phone is OFF (not in talk mode).
2. Press the Menu button on HS or the Menu left soft key on BS to go to
the main menu.
3. Press VOL (- or +) button to scroll to Phone Setting.
4. Press Select (right soft key) to confirm and you may program the
following items:
Date/Time (base only),
Auto Answer (handset only),
Auto Answer Intercom (both base and handset),
Dial mode (base only),
Room Monitor (both base and handset),
Area Code,
Registration (handset only),
De-registration (Base only),
2nd Call Alert (Both base and handset),
Handset Name (handset only).
Programming the Telephone
15
Date/Time
From the Phone Setting Menu
1. Press the VOL (- or +) button to scroll to Date/Time sub-menu.
2. Press Select soft key to enter the menu. Year 2007 shows in the display.
3. Use the touch-tone pad to enter the last two digits of the current year
(range: 00 to 99).
4. Press Select soft key to save the year setting and proceed to date
setting.
5. Date 01/01 shows in the display. Use the touch-tone pad to enter two
digits for current month and day respectively.
6. Press Select soft key to save the month/date setting and proceed to
time setting.
7. Time 12:01p shows in the display. Use the touch-tone pad to enter four
digits for current time and use soft key AM/PM to toggle between “P”
(pm) and “A” (am).
8. Press Select soft key to save the setting. Saved shows in the display.
NOTE: If you subscribe to Caller ID service, the current Date/Time is set
automatically when you receive your first CID record and will override
manually set Date/Time.
NOTE: The Date/Time setting item only exists in base menu, handset Date/
Time should update automatically after it is set in the base.
Auto Answer (only applicable for handset)
This option allows you to pick up the handset from base to answer an
incoming call without pressing the Talk/Speaker/L 1/L2 button.
When it is set to off, this function is disabled in this handset.
From the Phone Setting Menu:
1. Press the VOL (- or +) button to scroll to the Auto Answer sub-menu.
2. Press Select soft key to enter the menu. Use the VOL (- or +) button to
scroll to your selection. The default setting is On.
3. Press Select soft key to save your selection and Saved shows in the
display.
Auto Answer Intercom
If it is set to on, this handset or base will auto answer the intercom call
when it receives an intercom call.
From the Phone Setting Menu
1. Press the VOL (- or +) button to scroll to Auto Answer Int. sub-menu.
2. Press Select soft key to enter the menu. Use the VOL (- or +) button to
scroll to your selection. The default setting is Off.
3. Press Select soft key to save your selection and Saved shows in the
display.
Programming the Telephone
16
Dial Mode
The Dial Mode of Line 1 and Line 2 can be set separately.
From the Phone Setting Menu:
1. Press the VOL (- or +) button to scroll to the Dial mode sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to select Tone or Pulse and use the DIR or
CID button to select L1 or L2.
4. Press Select soft key to save your selection and Saved shows in the
display.
NOTE: The Dial mode only can be set in the base menu.
Room Monitor
If the room monitor is set to “On” in this handset, for example handset #1,
when a handset or a base makes an intercom call to HS#1, the HS#1 will
answer the call and go to room monitor mode. The microphone of HS#1
will be on, but the speaker is kept to Off.
From the Phone setting menu:
1. Press the VOL (- or +) button to scroll to the Room Monitor sub-menu.
2. Press Select soft key to enter the menu and use the VOL (- or +) button
to scroll to your selection. The default setting is Off.
3. Press Select soft key to save your selection and Saved shows in the
display.
Area Code
The telephone uses the pre-programmed area code to determine the
number format to display when a valid Caller ID record is received. The
pre-programmed area code is also used for the Dialback feature.
From the Phone setting Menu:
1. Press the VOL (- or +) button to scroll to the Area code sub-menu.
2. Press Select soft key to enter the menu. Enter area code shows in the
display.
3. Use the touch-tone pad to enter your 3-digit area code.
4. Press Select soft key to save your selection and Saved shows in the
display.
2nd Call Alert
If it is set to On, you will hear the alert tone when you are in conversation
and there is an incoming call from another line
From the Phone Setting Menu
1. Press the VOL (- or +) button to scroll to 2ND Call Alert sub-menu.
2. Press Select soft key to enter the menu. Use the VOL (- or +) button to
scroll to your selection. The default setting is On.
3. Press Select soft key to save your selection and Saved shows in the
display.
Programming the Telephone
17
Handset Name (only applicable for handset)
From the Phone Setting Menu:
1. Press the VOL (- or +) button to scroll to the Handset name sub-menu.
2. Press Select soft key to enter the menu. The default setting is
Handset xx.
3. Use the touch-tone pad to enter a name (up to 13 characters). More
than one letter is stored in each of the number keys. For example, to
enter Bill Smith, press the 2 key twice for the letter B. Press the 4 key 3
times for the letter I. Press the 5 key 3 times for the letter L. Press the 5
key 3 times for the second letter L, and press the 1 key to insert a space
between the first and last name. Press the 7 key 4 times for the letter
S; press the 6 key once for the letter M; press the 4 key 3 times for the
letter I; press the 8 key for the letter T; press the 4 key twice for the
letter H.
NOTE: If you make a mistake, press CID/VOL (- or +) button to move the
cursor forward or backward, and then use the mute/del button to backspace
and delete one character at a time.
NOTE: To avoid confusion, * key is a function key to switch/toggle between
the upper case & low case of characters during text edit.
4. Press the Menu button to save your name. You will hear a confirmation
tone and the display shows Saved.
Registration
A cordless handset will not operate until it is registered to the base. During
the registration process, keep the handset near the base. Up to 10 cordless
handsets can be registered to one base.
NOTE: If a handset is not registered; Not Register flashes on the display and
if the Talkbutton on the handset is pressed, it will display Unavailable.
From the Phone Setting Menu:
1. Press the VOL (- or +) button to scroll to the Registration sub-menu.
2. Press Select soft key to enter the menu and you may program the
following items: Register and Remove handset.
Register
From the Registration Menu:
1. Press the VOL (- or +) button to scroll to the Register sub-menu.
2. Press Select soft key to enter the menu. “Press base unit page button
until beep” shows in the display
3. Press and hold the Page button on base for 5 seconds.
4. “Registration” displays in shows the base is in registration mode.
5. If the registration is successful, the handset shows Registration
complete for 2 seconds and emits a confirmation tone.
5. If the registration is failed (i.e. timeout), the handset shows
“REGISTRATION FAILED!” for 2 seconds and then returns to the idle
mode base and emits an error tone.
Programming the Telephone
18
De-Register (applicable for handset)
Deregistration cancels registration. During the deregistration process, keep
the handset near the base.
WARNING: It is not recommended that a handset be deregistered
unless absolutely necessary because once a handset is deregistered,
that handset’s telephone features cannot be used until the handset is
re-registered.
From the Registration Menu:
1. Press the VOL (- or +) button to scroll to the Remove handset
sub-menu.
2. Press Menu button to enter the menu. Remove handset? shows on the
display.
3. Press Yes soft key to confirm de-registration. Saved shows in the display
and then shows “Press “REG” to initiate registration” in the handset.
4. Press Reg soft key to enter register mode.
De-Register (applicable for base)
From the Phone Setting Menu:
1. Press the VOL (- or +) button to scroll to the Deregistration sub-menu.
2. Press Select soft key to enter the menu. All handsets registered on the
base display and use the VOL (- or +) button to scroll to your selection.
3. Press the Select soft key to save your selection. Remove handset? shows
on the display.
4. Press Yes soft key to confirm de-registration. Saved shows in the display
and then shows “Press “REG” to initiate registration” in the handset.
Display Setting
1. Make sure your phone is OFF (not in talk mode).
2. Press the Menu button on HS or the Menu soft key on BS to go to the
main menu.
3. Press VOL (- or +) button to scroll to Display Setting.
4. Press Select soft key to confirm and you may program the following
items: Language, Contrast and Backlight (base only).
Language
From the Display Setting Menu:
1. Press the VOL (- or +) button to scroll to the Language sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to select English, Francais or Espanol. The
default setting is English.
4. Press Select soft key to save your selection.
Programming the Telephone
19
Contrast
From the Display Setting Menu
1. Press the VOL (- or +) button to scroll to the Contrast sub-menu.
2. Press Select soft key to enter the menu. The MIN and MAX contrast
scale shows on the display.
3. Use the VOL (- or +) button to adjust the contrast. The display instantly
adjusts with each press of the VOL (- or +) button.
4. Press Select soft key to save the desired contrast level.
BS Backlight
From the Display Setting Menu:
1. Press the VOL (- or +) button to scroll to the Backlight sub-menu.
2. Press Select soft key to enter the menu and use the VOL (- or +) button
to select Always On or Automatic.
3. Press Select soft key to save your selection.
Sound Setting
1. Make sure your phone is OFF (not in talk mode).
2. Press the Menu button on HS or the Menu soft key on BS to go to the
main menu.
3. Press VOL (- or +) button to scroll to Sound Setting.
4. Press Select soft key to confirm and you may program the following
items in base and handset: Ring Tone, Ring Volume and Key Tone.
Ring Tone
There are 8 tone levels for your selection. They are Melody 1 to 8 for line 1
and line 2 respectively.
From the Sound Setting Menu:
1. Press the VOL (- or +) button to scroll to the Ring Tone sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to scroll to your selection and use the DIR
or CID button to toggle between L 1 and L 2. The default setting is
Melody 1 for both line.
4. Press Select soft key to save your selection and Saved shows in the
display.
Programming the Telephone
20
Ring Volume
There are 5 volume levels and OFF for your selection. The Ring volume can
be set individually for each line.
From the Setup HS Menu:
1. Press the VOL (- or +) button to scroll to the Ring Volume sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to scroll to your selection and use the DIR
or CID button to toggle between L 1 and L 2. The default setting is
VOL 3.
4. Press Select soft key to save your selection and Saved shows in the
display.
Key Tone
From the Sound Setting Menu:
1. Press the VOL (- or +) button to scroll to the Key Tone sub-menu.
2. Press Select soft key to enter the menu. Use the VOL (- or +) button to
select On or Off.
3. Press Select soft key to save your selection and Saved shows in the
display.
Answer System
1. Make sure your phone is OFF (not in talk mode).
2. Press the Menu soft key on BS to go to the main menu.
3. Press VOL (- or +) button to scroll to Answer Sys.
4. Press Select soft key to confirm. You may program the following items
in base: Message Alert, OGA Playback, OGA Record, Answering System,
Ring Delay, Message Length, Call Screening, Remote Password, Work
Hours, After Hours and Config OGA.
Message Alert
This feature set your answering system to give an alert tone every 10
seconds when there are new messages.
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Message Alert sub-menu.
2. Press Select soft key to enter the menu. Use the VOL (- or +) button to
select On or Off. Default is Off.
3. Press the Select soft key to save your selection and Saved shows in the
display.
Programming the Telephone
21
OGA Playback
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the OGA Playback sub-menu.
2. Press Select soft key to enter the OGA playback sub-menu.
3. Use left and right button to toggle between Line 1 and Line 2 and use
VOL (- or +) button to scroll to your selection.
4. Press Select soft key to play the selected OGA, if the selected OGA is
empty, EMPTY shows in the display.
OGA Record
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the OGA Record sub-menu.
2. Press Select soft key to enter the OGA Record sub-menu.
3. Use left and right button to toggle between Line 1 and Line 2 and use
VOL (- or +) button to scroll to the selection you want to record.
4. Press the Select soft key. After “Please record the message after the
beep” is announced, you can start to record.
5. Press Finish soft key to end the recording.
6. After recorded, the unit will automatically play the OGA once.
Answering System
This is used to set the answering system On or Off for each telephone line
individually.
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Ans. Sys. sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to select On or Off and use the DIR or CID
button to toggle between L 1 and L 2.
4. Press the Select soft key to save your selection and Saved shows in the
display.
Programming the Telephone
22
Ring Delay
This feature lets you select the number of times you want the phone to ring
before the answering system answers a call.
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Ring Delay sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to scroll to your selection, from 2 rings to 6
rings or toll saver, and use the DIR or CID button to toggle between L1
and L 2.
4. Press the Select soft key to save your selection and Saved shows in the
display.
NOTE: When the Toll saver is selected, the unit will answer the incoming call
after 3 rings if there is new message. Otherwise, the unit will answer the
incoming call after 5 rings.
Message Length
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Message Length
sub-menu.
2. Press Select soft key to enter the menu.
3. Use the VOL (- or +) button to scroll to your selection, from 1 to 3
minutes, and use the DIR or CID button to toggle between L 1 and L 2.
4. Press the Select soft key to save your selection and Saved shows in the
display.
Call Screening
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Call Screening sub-menu.
2. Press Select soft key to enter the menu. Use the VOL (- or +) button to
select On or Off.
3. Press the Select soft key to save your selection and Saved shows in the
display.
Remote Password
You can access the answering system from a tone dialing telephone in
another (remote) location. The security code is required for remote access,
and it prevents unauthorized access to your answering system.
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Remote Password
sub-menu.
2. Press Select soft key to enter the menu. The current Remote password
000 shows in the display.
3. Use the touch-tone pad to enter your 3-digit security code.
4. Press Select soft key to save the setting.
Programming the Telephone
23
Work Hours
This will allow you to program the start time for the working hour.
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Work Hours sub-menu.
2. Press Select soft key to enter the menu.
3. Use the touch-tone pad to set the time, and use AM/PM soft key to
select AM or PM.
4. Press the Select soft key to save the time.
5. Use the VOL (- or +) button to select Yes or No for the Announce Only.
6. Press the Select soft key to save your selection and Saved shows in the
display.
NOTE: If you select Yes for Announce Only, the unit will hang up the call after
announce the greeting when answering the call in answering mode.
After Hours
This will allow you to program the start time for the after work hour.
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the After Hours sub-menu.
2. Press Select soft key to enter the menu.
3. Use the touch-tone pad to set the time, and use AM/PM soft key to
select AM or PM.
4. Press the Select soft key to save the time.
5. Use the VOL (- or +) button to select Yes or No for the Announce Only.
6. Press the Select soft key to save your selection and Saved shows in the
display.
NOTE: If you select Yes for Announce Only, the unit will hang up the call after
announce the greeting when answering the call in answering mode.
Config OGA
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Config OGA sub-menu.
2. Press Select soft key to enter the menu.
3. Use left and right button to toggle between Line 1 and Line 2 and use
VOL (- or +) button to scroll to your selection.
4. Press the Select soft key to save your selection. If there is not any
message recorded in your selected greeting is, EMPTY shows in the
display and you should select another one. Otherwise, Saved shows in
the display.
Programming the Telephone
24
Memo Recording
From the Answer System Menu:
1. Press the VOL (- or +) button to scroll to the Memo recording
sub-menu.
2. Use VOL (- or +) button to select Mailbox 1 or Mailbox 2 to save the
recording.
3. Press Select soft key to confirm. Record memo after beep shows in the
display.
4. Begin speaking and display Recording.
5. Press the Finish soft key to end the recording.
Telephone Operation
Making Calls with the Cordless Handset
1. Press the Talk button, the unit will pick the available line for you. If
both lines are available, line 1 will be used first.
OR
Press Line 1 or Line 2 soft key to select a line you wanted.
2. Wait for a dial tone then dial the phone number.
3. Press the End button when finished.
Making Calls in the Speakerphone mode
1. Press the Speaker button (in base or handset), the unit will pick the
available line for you. If both lines are available, line 1 will be used first.
OR
Press Line 1 or Line 2 button on the base to select the line, and the
base’s speaker will turn on.
2. Wait for a dial tone then dial a phone number.
3. Press the End button when finished.
NOTE: After pick the line, the call timer starts to run until all the calls are
hung up. The timer serves for both 2 lines.
Telephone Operation
25
Making Calls with the Optional Headset
1. Plug the headset into the Headset jack on the side of the base or side of
the cordless handset.
2. Adjust the headset to rest comfortably on top of your head or over
your ear.
3. Move the microphone to approximately 2 to 3 inches from your mouth.
4. For the base, press the Headset button on base and the phone
automatically selects first available, if both lines are available, Line 1
will be used.
5. For the cordless handset, press the Talk button.
6. Wait for a dial tone, and then dial the phone number.
7. Press Headset button (on base) or End button (on handset) when
finished.
CAUTION: Use only Thomson Inc. 5-2425 headset that is compatible
with this unit.
NOTE: If the headset is not connected (or if not completely inserted into
headset jack), an error tone is heard when the Headset button is pressed.
Pre-dialing
1. With the phone idle, manually enter the telephone number. The
telephone number shows in the display.
2. Press the Dial soft key (on base only), Speaker button, Talk button
(handset only), or Line 1 or line 2 button to take a line, and then the
telephone number will be dialed out.
Answering a Call
1. Press the Talk button to answer the call in handset mode,
OR
2. Press the Speaker button to answer the call in speakerphone mode,
OR
3. Press the Line button to answer the call in the speakerphone mode,
OR
4. Press the Headset button to answer the call in headset mode.
5. When finished, press the Speaker button or press the End button.
NOTE: If you have set the Auto Answer as on in the cordless handset, you
can answer call directly by picking up this handset from the base, without
pressing any buttons.
NOTE: Adjust the volume by pressing the VOL (- or +) button during a call.
Telephone Operation
26
Switching Between the Speakerphone, Handset, and Headset
Mode
Base
To switch to the speakerphone, press Speaker button. The speakerphone
indicator turns On.
To switch to the headset, press the Headset button to enable the headset,
and the headset indicator turns On.
Cordless Handset
To switch to the speakerphone, press Speaker button.
If the headset is plug in, press Talk button to switch to headset.
If the headset is not plug in, press Talk button to switch to cordless
handset’s receiver.
Mute
To have a private, off-line conversation, use the Mute feature. The party on
the other end of the line cannot hear you, but you can still hear them.
1. Press Mute button to activate the mute feature. The mute indicator
turns On.
2. Press Mute button again to turn it Off.
Do Not Disturb
This feature is set at individual telephones to disable (silence) an incoming
ring signal, intercom ring, or page. When there is an incoming call or an
intercom call, the status indicators function as normal but the phone will
not ring.
1. When the unit is idle, press the DND/Privacy button. The Privacy
indicator flashes and the last setting is displayed.
2. Use the VOL (- or +) button to select the duration. You may choose
from 15 minutes, 30 minutes, 45 minutes, 1 hour, or 2 hours and
increase the duration by 1-hour intervals up to 24 hours.
3. Press the Select soft key to confirm. The indicator blinks and the display
shows how long the ringer will be disabled.
4. To cancel, press DND/Privacy button again or hang up the handset.
NOTE: If Intercom Auto Answer is turned ON, the unit automatically answers
the intercom call even if the Do Not Disturb function is activated.
Flash
Use the Flash button to activate custom calling services such as call waiting
or call forwarding, which are available through your local phone company.
Inserting a Pause in the Dialing Sequence
Press the #pause button twice to insert a delay in dialing sequence when a
pause is needed to wait for a dial tone (for example, after you dial 9 for an
outside line, or to wait for a computer access tone.) Each pause counts as
one digit in the dialing sequence, and is shown as P in the display.
Telephone Operation
27
Redial
1. Press the Talk button, or press the Speaker button (speakerphone mode),
or press the Headset button (headset mode) and the first available line
will go off hook. If both lines are available, Line 1 will be used.
OR
Press a Line button to select a line.
2. Press the Redial button.
NOTE: The Redial function will not operate if the number to be redialed
contains more than 32 digits. If the number is longer than that, you will
hear an error tone.
Reviewing the Redial Numbers
Your phone records up to three previously dialed phone numbers.
1. When the phone is idle, press the Redial/Format button.
2. Use the VOL (- or +) button to view the last three previously dialed
numbers.
3. While the preferred number is displayed, press the Speaker, Talk, Dial, or
a Line button to dial the phone number.
NOTE: If you do not select a line button, the line is automatically seized and
the number is dialed accordingly.
Storing a Redial Record in Phone Book
1. Make sure the phone is OFF (not in talk mode).
2. Press the Redial button, then use the VOL (- or +) button to scroll to the
desired redial number.
3. Press the Select soft key.
4. Enter name shows in the display. Input a name. Please refer to section
“Handset Name” for name editing method.
NOTE: A name must be input otherwise the record cannot be stored.
5. Press the Save soft key to enter VIP Tone Melody selection.
6. Use the VOL (- or +) button to scroll to the desired melody.
7. Press Select soft key, Saved shows in the display. Repeat steps 2 through
7 to save other records.
Transferring a Call to Another extension
(TBD)
Receiving a Transferred Call from Another extension
(TBD)
Telephone Operation
28
Ringer On/Off
1. Make sure the phone is in idle mode.
2. Press the VOL (- or +) button to enter. Use the VOL (- or +) button to
scroll to your selection and use the DIR or CID button to toggle
between L 1 and L 2. The default setting is VOL 3.
3. Press the Select soft key to save your selection and the new volume
setting shows in the display.
NOTE: If you choose the ringer OFF, L1/L2 RINGER OFF shows in the display.
Speakerphone, Handset, and Headset Volume
While the phone is in use, during the desired mode, press the VOL (+ or -)
buttons until you reach a comfortable listening level. The phone stores the
setting after the last button press.
Hold
(TBD)
Conference Calls
(TBD)
Intercom Calls
One-Touch Intercom
1. Press the Intercom/Memory button (1-10) for the station you want to
intercom with. The Speaker turns On.
OR
You may press the Intercom button, then press the Intercom/Memory
button (1-10) for the stations you want to intercom with. The
speakerphone automatically turns on.
OR
Press the Intercom button, and all the registered handsets and the base
except itself list in the log, use the VOL (- or +) key to scroll to the
station you want to intercom with, and then press select soft key to
confirm. The speakerphone automatically turns On.
NOTE: If you want to switch to the headset, press the Headset button.
NOTE: To abort intercom call, press Speaker button.
2. To end the intercom call, hang up.
NOTE: If the receiving station does not answer within 45 seconds, the
intercom call is cancelled. You will hear an error tone and Page Unavailable
shows in the display.
Intercom Calls
29
Answering an Intercom Call
When you receive an Intercom call, the display shows the Caller’s name and
Phone ID.
NOTE: If you want to answer with the speakerphone, press the Speaker
button. If you want to answer by headset, press the Headset button (the
headset must be connected).
NOTE: Press Speaker to automatically select a party. If you receive an
incoming call and intercom call at the same time the unit automatically
selects the ringing line.
Page
The page feature helps you locate a misplaced handset.
1. Press the Page button on the base. The charge/in use indicator on the
base flashes; the handset beeps and Page from base shows in the
handset display.
2. To cancel the page, press the Page button on the base, or press Stop
soft key on the base, or press Exit key on the base, or press any key on
the handset. Otherwise the paging will last for 2 minutes.
Auto Standby
If you place the handset in the cradle while the handset is off the hook
(during a call), the call is automatically disconnected.
Caller ID (CID)
IMPORTANT: In order to use this unit’s Caller ID features, you must subscribe
to either the standard Name/Number Caller ID Service or Call Waiting Caller
ID Service. To know who is calling while you are on the phone, you must
subscribe to Call Waiting Caller ID Service.
The summary screen shows the current time, current date, number of
new CID records to be reviewed or total number of records saved to CID
memory. It is displayed until any button is pressed. Within 60 seconds of
receiving a new call, the new caller information is displayed.
Caller ID
LINE1 LINE2
L1
PLAY
Base Display
Handset Display
30
Receiving and Storing CID Records
This unit receives and displays information transmitted by your local phone
company. This information can include the phone number, date and time;
or the name, phone number, date and time. The unit can store up to 100
calls for later review. When the memory is full, a new call automatically
replaces the oldest call in memory. NEW appears in the display for calls
received that have not been reviewed. The line number for the call received
is also displayed.
In case multiple incoming calls come in at the same time, the CID
information is displayed according to the unit’s priority line setting.
Example: The priority line is 3.
Reviewing CID Records
• Press the CID button to scroll through the call records.
• When you scroll to the start/end of the list, --START/END-- appears in
the display.
Saving a CID Record to Phone Book Memory
1. While viewing a CID record, press the Store soft key. VIP tone Melody
shows in the display.
2. Use VOL (- or +) button to scroll to your selection, and press Select soft
key to save. Saved shows in the display.
Deleting a CID Record
To delete the record shown in the display, press the Delete button on the
phone or press the Delete soft key.
Deleting All Call Records
This feature allows you to clear all CID records at once.
1. While viewing a CID record, press and hold the Delete button. Delete All
CID Records? shows in the display.
2. Press Yes soft key to confirm. All CID Records Deleted shows for 3
seconds.
Caller ID
31
Dialing Back
When reviewing CID records, you can dial back the numbers showing on the
display by pressing the Headset button, or the Talk button, or the Speaker
button or the Line 1 or Line 2 button.
If You Programmed Your Local Area Code
1. Use the CID button to display the number you want to dial.
2. If you see a number with 7 digits (i.e. 555-1234), then the call was
received from within your area code. However, this does not guarantee
the call is a local call. If you see a number with 11 digits
(i.e.1-234-555-1234), then the call received was not from your area
code.
3. To adjust the phone number format, use the Format soft key. For
instance, a 7-digit local number sometimes cannot be dialed because it
requires a 10-digit or 11-digit format. Use the Format soft key to scroll
through 7, 10 and 11-digit numbers.
Number of digits Explanation Example
7-digits: 7-digit telephone number (i.e.555-5555)
10-digits: 3-digit area code
+7-digit telephone (i.e.425-555-5555)
number
11-digits: long distance code 1 (i.e. 1-425-555-5555)
+3-digit area code
+7-digit telephone number
4. To dial the displayed number, select a Line or press Talk, Speaker, or
Headset button.
If You Did Not Program Your Local Area Code
1. Use the CID button to display the number you want to dial. You will
only see 10-digit numbers (i.e. 234-555-1234).
2. Press Talk, Speaker, Headset button or select a Line to dial back. You
may adjust the number format by pressing the Format soft key before
dialing.
Call Waiting Caller ID
This feature allows you to see who is calling when you hear the call waiting
beep. The caller identification information appears in the display after you
hear the tone.
• Press the Flash button to put the person to whom you’re talking on
hold and answer the incoming call.
IMPORTANT: To use all the features of this unit, you must subscribe to either
the standard Name/Number Caller ID Service or Caller ID with Call Waiting
Service. To know who is calling while you are on the phone, you must
subscribe to Caller ID with Call Waiting Service.
Caller ID
32
Memory Log and Phone Book (Directory) Memory
You may store data in the Phone Book Directory (up to 100 memories) or
an Intercom/Memory (10 buttons located to the right of the number pad
on the base). The Phone Book and each Intercom/Memory Log stores up to
21 characters and 32 digits.
The records are stored by alphabetic ascending order.
Adding Phone Book Entries
1. Make sure the phone is OFF (not in talk mode).
2. Press the DIR button.
3. Press the New soft key. Enter name shows in the display. Please refer to
section “Handset Name” for name editing method.
4. Press Save soft key. Enter number shows in the display.
5. Use the touch-tone pad to input a telephone number.
TIP: Press the #pause button twice to insert a pause in a number if
necessary.
6. Press the Save soft key to enter VIP tone melody selection.
7. Use VOL (- or +) button to scroll to the selection and press Select soft
key to complete.
NOTE: If Memory full shows in the display, you should delete one or more
unnecessary records and repeat above steps to continue the call record
storage.
OR
1. Make sure the phone is OFF (not in talk mode).
2. Press Store soft key.
3. Select Location shows in the display. Press a One-touch button (1-10)
to save the record in that memory location.
NOTE: If there is a record stored in selected memory location. Press Replace
soft key to confirm overwrite or press the Back soft key, then select a new
location.
4. Enter name shows in the display. Please refer to section “Handset
Name” for name editing method.
5. Press Save soft key. Enter number shows in the display.
6. Use the touch-tone pad to input a telephone number.
TIP: Press the #pause button twice to insert a pause in a number if
necessary.
7. Press the Save soft key to enter VIP tone melody selection.
8. Use VOL (- or +) button to scroll to the selection and press Select soft
key to complete.
Memory
33
Reviewing Phone Book Records
1. Make sure the phone is OFF (not in talk mode).
2. Press the DIR button.
3. Press the VOL (- or +) button to scroll through the records,
OR
Press the number keys to go to the name of the records started with
the corresponding character.
Editing a Phone Book Record
1. When reviewing the phone book records, use the VOL (- or +) button or
the number keys to scroll to the desired record.
2. Press Edit soft key to enter edit mode. You may now change the name,
if desired. Please refer to section “Handset Name” for name editing
method.
3. Press Save soft key to proceed to number change. You may now change
the number, if desired.
4. Press Save soft key to proceed to VIP tone Melody selection. You may
use VOL (- or +) key to scroll to the selection you desired.
5. Press Select soft key to complete.
NOTE: Press the Back soft key to keep the previous setting (making no
changes) and return to the standby mode.
Copy Current Directory
(TBD)
Copy Entire Directory
(TBD)
Deleting a Phone Book Record
1. When reviewing the phone book records list, use the VOL (- or +)
button or the number keys to scroll to the desired record.
2. Press Delete soft key or press delete key on the phone to delete the
record.
3. Record Deleted shows in the display.
Memory
34
Dialing a Phone Book Record
Dial a phone book record while in talk mode:
1. Make sure the phone is ON (in talk mode) by pressing the Talk, Speaker
button, or selecting a Line.
2. Press the DIR button to access the phone book.
3. Use the VOL (- or +) button or the number keys to scroll to the desired
record.
4. Press the Dial soft key to dial the number.
OR
Dial a phone book record while reviewing it:
1. Make sure the phone is OFF (not in talk mode).
2. Press the Phonebook button to access the phone book.
3. Use the VOL (- or +) button or the number keys to scroll to the desired
record.
4. Press the Talk, Speaker, Line 1/2 button. The number dials automatically.
Answering System Operation
There are two mailboxes in the system.
Answering System On/Off
Press and hold the base Answering system button for 2 seconds to switch
this function On or Off with voice prompt. The Answering system light is lit
when the function is activated.
If the Answering system button indicator is flashing, pressing it will go to
Play Message display.
Otherwise, pressing the button will display Line 1 and Line 2 On/Off status
for 3 seconds.
Recording Incoming Messages
The unit will answer incoming calls or routed calls after X rings (pickup
delay set in Menu) and play the outgoing greeting. After hearing the
greeting followed by a long beep, the caller can leave a message. If there
is a new message recorded in the unit, the Answering system indicator will
flash, and the envelope icon shows in the LCD.
NOTE: Your unit will record a message up to the maximum length of time
you set as long as the caller continues speaking. To save recording capacity,
your unit will automatically stop recording after 7 seconds of silence or if
there is a steady dial tone for 7 seconds.
Your unit can record up to 60 minutes of incoming messages. The
maximum recording time for each incoming message can be set in Menu.
Answering System Operation
35
Monitoring Incoming Calls
Whenever an incoming message is being recorded you can hear it through
the speaker if Call Screening is On. To take the call, press Talk, Speaker or
Line button and the system stops recording.
Memo Record
You can leave a message by pressing the Memo button on base or selecting
memo recording under handset menu.
1. Press the Memo button on base or handset menu to enter memo record
mode.
2. Use VOL (- or +) button to select Mailbox 1 or Mailbox 2 to save the
recording.
3. Press Select soft key to confirm. Record memo after beep shows in the
display.
4. Begin speaking and display Recording.
5. Press the Finish soft key to end the recording.
NOTE: The maximum duration allowed for memo is 3 minutes.
ICM/Memo Playback
In idle mode, press base Answer system button when flashing or press Play
button on handset or on base. The unit enters the message playback mode,
and the status of messages for each line display. Use left and right key can
toggle between Line 1 and Line 2, press select soft key to play the
messages.
If the unit has new messages, only the new messages will be played,
otherwise all messages will be played. Unit will play messages to the end.
During each message playback, it shows the current message information
on the screen. If it is a ICM message, it shows the message’s CID, including
Date/Time, Name, Number and Line icon. If it is a memo, only Display memo
and Date/Time.
During each message playback, you can press digit 3 for skip the current
message OR press digit 1 to replay the message playing.
If there are no messages, the unit will announce “You have NO messages”.
Erasing Messages
You may erase messages in the following three ways:
To erase a message while it is playing
1. Select and play the message you want to erase.
2. Press the Delete button, the current message is erased, and the next
message plays.
To erase a message after it playing
1. After playing a message to the end, Delete message xx shows in the
display.
2. Press Yes soft key to delete it and “Message Deleted” is announced.
Answering System Operation
36
To erase all previously played messages in a mailbox
1. Play a message.
2. Press and hold the Delete button for 2 seconds, Delete all messages in
line X mailbox? shows in the display.
3. Press Select soft key to delete all the old messages.
Remote Access From Remote Party
1. Dial the telephone number to which the answering system is connected.
2. Enter the security code during the outgoing announcement or after
you hear the tone.
NOTE: The default security code is 000.
3. The following are the voice prompts for the remote menu:
Press two to play messages, press two again to stop
Press zero while playing a message to erase
Press one to review
Press three to skip
Press four to turn Off/On
Press seven to review menu again
4. Enter the remote commands.
5. To exit remote operation, hang up. The system will automatically
disconnect the call if the user does not enter a command within 10
seconds.
NOTE: The Play/Stop, Erase, Review, Skip and Answer On/Off operations are
the same as the corresponding keys on base.
Only the message being played can be erased in remote access mode.
Memory Full
When the answering system memory is full, the system answers after 10
rings. “Memory full” will be announced and waits for you to enter 3-digit
security code. If you don’t enter the security code within 7 seconds, the
phone hangs up.
You should erase some messages so the answering system may record new
messages.
NOTE: The unit also answers after the 10th ring if it is set to Answer Off. To
access the answering system, enter your 3-digit security code.
Answering System Operation
37
Changing the Battery
CAUTION: To reduce the risk of fire or personal injury, use only the
Thomson Inc. approved Nickel-metal Hydride (Ni-MH) battery model
5-2734, which is compatible with this unit.
1. Make sure the telephone is OFF (not in TALK mode) before you replace
battery.
2. Remove the battery compartment door.
3. Disconnect the battery plug from the jack inside the battery
compartment and remove the battery pack from the handset.
4. Insert the new battery pack and connect the cord to the jack inside the
battery compartment.
5. Put the battery compartment door back on.
6. Place handset in the base or handset charge cradle to charge. Allow the
handset battery to properly charge (for 14 hours) prior to first use or
when you install a new battery pack. If you do not properly charge the
phone, battery performance will be compromised.
Battery Safety Precautions
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of
this type, toxic materials could be released which can cause injury.
• To reduce the risk of fire or personal injury, use only the Nickel-metal
Hydride battery listed in the User’s Guide.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
Other Information
NOTE: The RBRC seal on the battery used in your Thomson Inc. product
indicates that we are participating in a program to collect and recycle the
rechargeable battery (or batteries).
For more information go to the RBRC web site at www.rbrc.org
or call 1-800-8-BATTERY or contact a local recycling center.
38
Display Messages
The following messages show the status of the phone, provides Caller ID
information, or helps you set up and use your phone.
BLOCKED Indicates the person is calling from a number which is
blocked from transmission.
DELETE ALL? Prompt asking if you want to erase all records.
DELETE? Prompt asking if you want to erase the current record.
END/ START Indicates that it is the end of the list.
ENTER NAME Prompt telling you to enter a name.
ENTER NUMBER Prompt telling you to enter a telephone number.
NEW CALLS Indicates call or calls which have not been reviewed.
HANDSET NAME Prompt telling you to enter a user name for the hand
set.
UNAVAILABLE The handset is not yet registered or is out of range.
NO LINE Indicates that the telephone line is not connected.
LINE IN USE Display on handset while the line is in use.
EMPTY Indicates there are no CID records in memory.
SEARCHING Indicates handset is too far away from the base, and
the handset is searching for the base.
PAGE FROM BASE Someone pressed the PAGE button on the base.
UNKNOWN Indicates incoming call is from an area not serviced by
CID or the CID information was not sent.
Handset Sound Signals
Signal Meaning
A long warbling tone (with ringer on) Signals an incoming call
Three short beeps (several times) Page signal
One beep every 14 seconds Low battery warning
Other Information
39
Troubleshooting Guide
Telephone Solutions
No dial tone
• Check or repeat installation steps:
Make sure the base power cord is connected to a working electrical
outlet. Make sure the telephone line cord is connected to the base and
the wall jack.
• Connect another phone to the same jack. If it doesn’t work, the
problem might be your wiring or local service.
• The handset may be out of range of the base. Move closer to the base.
• Make sure the battery is properly charged (for 14 hours).
Dial tone is ok, but can’t dial out
• Make sure the type of phone service you are subscribed to is TONE or
PULSE.
Handset does not ring
• Make sure the handset ringer is set to On.
• The handset may be out of range of the base. Move closer to the base.
• You may have too many extension phones on your line. Try unplugging
some extensions.
• Check for a dial tone. If no dial tone is heard, see “No dial tone”.
You experience static, noise, or fading in and out
• The handset may be out of range of the base. Move closer to base.
• Make sure base is not plugged into an electrical outlet with another
household appliance. If necessary, relocate the base.
• Charge the battery (for 14 hours).
Memory dialing doesn’t work
• Did you follow proper dialing sequence?
Unit locks up and no communication between the base and cordless
handset
• Unplug the power adaptor from the electrical outlet and the bottom of
the base. Remove the handset battery. Wait for 30 seconds and plug the
power adaptor back into the base and electrical outlet. Reconnect the
battery and charge for 14 hours.
Searching.... shows in the handset display
• Move the handset closer to the base.
• Make sure the base power cord is connected to a working electrical
outlet.
Date/Time setting is restored to default setting
• May be caused by power failure. Set Date/Time again.
Other Information
40
Caller ID Solutions
No Display
• Charge the battery (for 14 hours). Or replace the battery.
• Make sure the unit is connected to a non-switched electrical outlet.
Disconnect the power adaptor from the base and reconnect it.
No Caller ID
• You must be subscribed to the standard Name/Number Caller ID service
from your local telephone company to receive CID information.
Battery
If you experience any of the following problems, even after recharging the
battery, you may need to replace the battery pack:
• Short talk time
• Poor sound quality
• Limited range
General Product Care
To keep your unit working and looking good, follow these guidelines:
• Avoid dropping the handset, as well as other rough treatment to the
phone.
• Clean the phone with a soft cloth.
• Never use strong cleaning agents, paint thinner, abrasive powder,
alcohol, or other chemical products to clean the unit. Doing so will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a
later date.
• Periodically clean the charge contacts on the handset and base with a
clean pencil eraser.
Causes of Poor Reception
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction that can shield radio
signals.
• You ’re too close to appliances such as microwaves, stoves, computers,
etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
Other Information
41
Warranty Assistance
If trouble is experienced with this equipment, for warranty information,
please contact customer service at 1-800-448-0329. If the equipment
is causing harm to the telephone network, the telephone company may
require that you disconnect the equipment until the problem is resolved.
Any unauthorized repairs, changes or modifications not expressly approved
by Thomson Inc. could void the user’s authority to operate this product.
For instructions on how to obtain a replacement unit, refer to the warranty
included in this guide or call customer service at 1-800-448-0329.
Or refer inquiries to:
Thomson Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to this booklet for future reference or jot down
the date this product was purchased or received as a gift. This information
will be valuable if service should be required during the warranty period.
Purchase Date ______________________________________________________
Name of Store _____________________________________________________
Warranty
42
Limited Warranty
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit
is under warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally provided
with the product. We recommend using the original carton and packing
materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period, must be presented to
obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via
standard UPS or its equivalent to:
Thomson Inc.
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• Insure your shipment for loss or damage. Thomson Inc. accepts no liability in
case of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty does not cover:
• Customer instruction. (Your Owner’s Manual provides information regarding
operating instructions and user controls. Any additional information, should be
obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit.
It will make it easier to contact you should it ever be necessary. The return of
the card is not required for warranty coverage.
Warranty
43
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS
PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION
GIVEN BY THOMSON INC., ITS AGENTS, OR EMPLOYEES SHALL CREATE A
GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE APPLICABLE
WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts so
the above limitations or exclusions may not apply to you.
•This warranty gives you specific legal rights, and you also may have other rights
that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
Accessory Information
Accessory Information
To place order, have your Visa, MasterCard, or Discover Card ready and
call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering. We are required
by law to collect appropriate sales tax for each individual state, country,
and locality to which the merchandise is being sent. Items are subject to
availability. Prices are subject to change without notice.
DESCRIPTION MODEL NO.
Handset Replacement Battery 5-2734
AC power adaptor 5-2735
44
A
TO BE UPDATED!!
Index
45
Index
Visit the RCA web site at: www.rca.com
Please do not send any products to the Indianapolis address listed in this
manual or on the carton. This will only add delays in service for your
product.
Thomson Inc.
101 West 103rd Street
Indianapolis, IN 46290-1102
© 2007 Thomson Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Model 25250
00023265 (Rev. 0 E)
07-35
Printed in China
