Users Manual

5.8 GHz Call Waiting
Cordless Telephone
User's Guide
We bring good things to life.
25828
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in
compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone
Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and
Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information
to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still
have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum
of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone
from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company may
temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC Rules
and Regulations. If these changes are expected to affect the use or performance of your telephone equipment,
the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
• Put the battery compartment door back on.
3. Plug one end of the telephone line cord into the TEL LINE jack on the back of
the base and the other end into a modular jack.
4. Set the RINGER switch (on the handset) to ON.
5. Plug the AC power converter into the electrical outlet and the DC connector into
the jack on the back of the base.
6. Place the handset in the base cradle. The charge/in use indicator turns on,
verifying the battery is charging.
7. Allow the phone to charge for 12 hours prior to first use. If you don't properly
charge the phone, battery performance is compromised.
CAUTION: Use only the ATLINKS USA, Inc. 5-2629 (gray) or 52501
(black) power converter that came with this unit. Using other power
converters may damage the unit.
NOTE : The phone is shipped in tone dialing mode from the manufacturer.
WALL MOUNTING
NOTE: For best results, charge the phone on a flat surface before you mount
it on the wall.
1. Slip the mounting holes (on the back of the base) over the wall plate posts, and
slide the unit down into place. (Wall plate not included.)
2. Place the handset on the base cradle.
CORDLESS PHONE BASICS
CHARGE/IN USE INDICATOR
The phone is ON when the talk/end indicator on the handset and the charge/in use
indicator on the base is lit. The handset and base indicators flash when you
receive a call.
ANSWERING A CALL
1. When the phone rings, pick up the handset and press the talk/end button.
2. When finished, press the talk/end button or place the handset on the base
cradle to hang up.
MAKING A CALL
1. Pick up the handset and press the talk/end button. Wait for the dial tone. The
call timer starts counting minutes and seconds in the display.
2. Dial a telephone number.
3. When finished, press the talk/end button again or place the handset on the
base cradle to hang up.
REDIAL
While the phone is ON (in TALK mode), press the redial button to redial the last
number you dialed (up to 32 digits).
FLASH
Use the flash button to activate custom calling services such as call waiting, which
are available through your local phone company.
TIP: Don’t use the talk/end button to activate custom calling services such as
call waiting, or you’ll hang up the phone.
CHANNEL BUTTON
While talking on the phone, it may be necessary for you to manually change the
channel to improve reception and reduce noise or static on the line. Press and
release the channel button to move to the next clear channel.
FINDING THE HANDSET
This feature helps locate a misplaced handset.
Press the page button on the base. The handset beeps continuously for about 2
minutes until you press the talk/callback button on the handset or the page button
on the base.
NOTE: You may still page the handset when the ringer is off.
RINGTONE
1. Make sure the phone is OFF (not in TALK mode).
2. Press the ringtone button.
3. Use touch-tone pad 1, 2 or 3 to select the ring tone 1, 2 or 3. You will hear
selected ring tone.
4. Press ringtone to confirm the selection. You will hear a confirmation tone.
RINGER SWITCH
Set the RINGER switch on the handset to choose the ring level of the handset. You
may choose ON or OFF.
VOLUME
When the phone is ON (in TALK mode) press the volume (- or +) button to adjust
the listening level. Choose from four volume settings. VOL 1 is the lowest volume
and VOL 4 is the highest volume.
MUTE
Use mute during a phone conversation to speak privately and off-line with a third
party.
1. Press the mute button.
The talk/end indicator will blink, and the party on the
telephone will no longer be able to hear you.
2. Press the mute button when finished.
MEMORY
Store up to ten 20-digit numbers in memory for quick dialing.
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button again.
5. Use the touch-tone pad to enter the telephone number you want to store (up to
20 digits).
6. Press memory again to store the number. You will hear a confirmation tone.
CHANGING A STORED NUMBER
Use the same procedure to change a stored number as you do to store a number,
just replace the old phone number with a new one.
STORING A REDIAL NUMBER
1. Repeat steps 1 through 4 in Storing a Name and Number in Memory.
2. Press the redial button.
3. Press the memory button to store the number. You will hear a confirmation
tone.
DIALING A STORED NUMBER
1. Make sure the phone is ON by pressing the talk/endbutton.
2. Press the memory button.
3. Press the memory location (0-9). The number dials automatically.
INSERTING A PAUSE IN THE DIALING SEQUENCE OF A
STORED NUMBER
If a pause is needed to wait for a dial or access tone, press the # pause button to
insert a delay in dialing sequence of a stored number (for example, after you dial
9 for an outside line, or to wait for a computer access tone.) pause shows in the
display as a
P
, and each pause counts as one digit in the dialing sequence.
DELETING STORED NUMBERS
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button twice.
CHAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, such as
calling card calls to a frequently called long distance number. Each part of the
sequence is dialed from memory. The following example shows you how to use
chain dialing to make a call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is ON (in TALK mode).
2. Press memory and then press 7.
3. When you hear the access tone, press memory and then press 8.
4. At the next access tone, press memory and then 9.
TIP: Wait for the access tones before pressing the next memory button, or your
call might not go through.
CHANGING THE BATTERY
Make sure the telephone is OFF (not in TALK mode) before
you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack and
remove the battery pack from the handset.
3. Insert the new battery pack and connect the cord to the
jack inside the battery compartment.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. Allow the handset battery
to properly charge (for 12 hours) prior to first use or when you
install a new battery pack. If you do not properly charge the phone,
battery performance will be compromised.
CAUTION: To reduce the risk of fire or personal
injury, use only the battery listed in the instruction book.
NOTE: If the battery is not properly installed in the handset, or if the battery pack
is not properly connected to the jack inside the battery compartment, the TALK
indicator on the handset blinks when the handset is placed in the base cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this
type, toxic materials could be released which can cause injury.
• To reduce the risk of fire or personal injury, use only the battery listed in the
User’s Guide.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone Signals an incoming call
(with ringer on)
Three short beeps Page signal
(several times)
One beep every 7 seconds Low battery warning
TROUBLESHOOTING TIPS
TELEPHONE SOLUTIONS
No dial tone
• Check or repeat installation steps
• Make sure the base power cord is connected to a working electrical outlet.
• Make sure the telephone line cord is connected to the base unit and the
modular phone jack?
• Disconnect the base from the wall phone jack and connect another phone to
the same jack. If there is no dial tone on the second phone, the problem might
be your wiring or local service.
• The handset might be out of range of the base. Move closer to the base.
• Make sure the battery is properly charged (for 12 hours).
• Ensure the battery pack is installed correctly.
• Did the handset beep when you pressed the talk/callback button? Did the in use
indicator come on? The battery may need to be charged.
Handset does not ring
• Make sure the RINGER switch on the handset is turned to ON.
• You may have too many extension phones on your line. Try unplugging
some phones.
• See solutions for “No dial tone.”
You experience static, noise, or fading in and out
• Change channels
• The handset maybe out of range. Move closer to the base.
• Relocate the base.
• Charge the battery.
• Make sure base is not plugged into an electrical outlet with another
household appliance.
Unit beeps
• Place handset in base cradle for 20 seconds to reset the security code. If that
doesn’t work, charge the battery for 12 hours.
• See solutions for “No dial tone.”
• Replace the battery.
Memory dialing
• Make sure you correctly program the memory location keys.
• Make sure you follow the proper dialing sequence.
• You must reprogram numbers into memory after a power outage or
battery replacement?
Out of range
• Move closer to the base.
• Reset the battery. Unplug the battery and plug it in again after five seconds.
• Reset the power supply. Unplug the supply and plug it in again after five
seconds.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction can shield radio signals.
• You’re too close to appliances such as microwaves, stoves, computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into an AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
GENERAL PRODUCT CARE
To keep your telephone working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that generate
electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the phone.
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them
for future reference.
Your cordless telephone is designed to give you flexibility in use and high quality
performance. To get the most from your cordless telephone, we suggest that you
take a few minutes right now to read through this instruction manual.
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
HANDSET AND BASE LAYOUT
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2004 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Model 25828
00001830 (Rev. 0 Dom E/S)
04-33
Printed in China
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a modular
jack, call your local phone company to find out how to get
one installed.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After
power outage or battery replacement, you should place the handset in the base
for about 20 seconds to reset the code.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If
such interference continues, move the cordless telephone farther away from
these appliances.
Certain other communications devices may also use the 5.8 GHz frequency for
communication, and, if not properly set, these devices may interfere with each
other and/or your new telephone. If you are concerned with interference, please
refer to the owner’s manual for these devices on how to properly set channels to
avoid interference. Typical devices that may use the 5.8 GHz frequency for
communication include wireless audio/video senders, wireless computer
networks, multi-handset cordless telephone systems, and some long-range
cordless telephone systems.
INSTALLATION
IMPORTANT INSTALLATION GUIDELINES
• Avoid sources of noise and heat, such as motors, fluorescent lighting,
microwave ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid other cordless telephones or personal computers.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone
line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
INSTALLING THE PHONE
Base Handset
Belt clip
Line cord AC power
converter
Handset
battery
Modular
telephone
line jack
Wall plate
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
Battery
compartment
door
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
PAGE
charge
in use
volume
-/+ arrow
(button)
redial
(button)
channel
(button) flash
(button)
*exit
(button)
#pause
(button)
ringtone
(button)
PAG E
charge
in use
page
(button)
charge/in use
(indicator)
memory
(button)
mute
(button)
talk/end
(button)
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here. 1. Choose an area near an electrical outlet and a telephone wall jack (RJ11C), and
place your cordless telephone on a level surface, such as a desktop or
tabletop, or you may mount it on the wall.
2. Install the handset battery.
CAUTION: To reduce the risk of fire or personal injury, use only the
battery 5-2548, which is compatible with this unit.
NOTE: You must connect the handset battery before use.
NOTE: If the battery is not properly installed in the handset, or if the battery
pack is not properly connected to the jack inside the battery compartment,
the TALK indicator on the handset blinks when the handset is placed in the
base cradle.
• Plug the battery pack cord into the jack located inside the battery compartment,
then place the battery pack inside the battery compartment.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we are
participating in a program to collect and recycle Nickel
Cadmium batteries throughout the United States.
Please call 1-800-8-BATTERY for information or contact
your local recycling center.
Ni-Cd
RBRC
RBRC
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a later date.
SERVICE
If trouble is experienced with this equipment, for repair or warranty information,
please contact customer service at 1-800-448-0329. If the equipment is causing
harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service
agents. Changes or modifications not expressly approved by ATLINKS USA, Inc.
could void the user’s authority to operate this product. For instructions on how to
obtain service, refer to the warranty included in this guide or call customer
service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date
this product was purchased or received as a gift. This information will be valuable
if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different
from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or
an experienced radio/television technician for additional suggestions. Also, the
Federal Communications Commission has prepared a helpful booklet, “How To
Identify and Resolve Radio/TV Interference Problems.” This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit
is under warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally
provided with the product. We recommend using the original carton and
packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period, must be presented to
obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via
standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no liability in case
of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information regarding
operating instructions and user controls. Any additional information, should be
obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit.
It will make it easier to contact you should it ever be necessary. The return of
the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO
THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING
ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. ATLINKS USA, INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts
so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each individual state,
country, and locality to which the merchandise is being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION MODEL NO. PRICE*
25838GE1-A 25838GE-3 25828GE6-A
Belt Clip 5-2622 (gray) 5-2621 (blue) 5-2656 (lt. gray) $4.95
Headset 5-2444 (white) 5-2425 (black 5-2425 (black $36.35
Replacement Battery 5-2458 5-2458 5-2458 $14.95
Power converter 5-2629 (gray) 5-2501 (black) 5-2501 (black) $15.50
5.8 GHz Call Waiting
Cordless Telephone
User's Guide
We bring good things to life.
25828
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in
compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone
Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and
Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information
to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still
have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum
of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone
from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company may
temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC Rules
and Regulations. If these changes are expected to affect the use or performance of your telephone equipment,
the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
• Put the battery compartment door back on.
3. Plug one end of the telephone line cord into the TEL LINE jack on the back of
the base and the other end into a modular jack.
4. Set the RINGER switch (on the handset) to ON.
5. Plug the AC power converter into the electrical outlet and the DC connector into
the jack on the back of the base.
6. Place the handset in the base cradle. The charge/in use indicator turns on,
verifying the battery is charging.
7. Allow the phone to charge for 12 hours prior to first use. If you don't properly
charge the phone, battery performance is compromised.
CAUTION: Use only the ATLINKS USA, Inc. 5-2629 (gray) or 52501
(black) power converter that came with this unit. Using other power
converters may damage the unit.
NOTE : The phone is shipped in tone dialing mode from the manufacturer.
WALL MOUNTING
NOTE: For best results, charge the phone on a flat surface before you mount
it on the wall.
1. Slip the mounting holes (on the back of the base) over the wall plate posts, and
slide the unit down into place. (Wall plate not included.)
2. Place the handset on the base cradle.
CORDLESS PHONE BASICS
CHARGE/IN USE INDICATOR
The phone is ON when the talk/end indicator on the handset and the charge/in use
indicator on the base is lit. The handset and base indicators flash when you
receive a call.
ANSWERING A CALL
1. When the phone rings, pick up the handset and press the talk/end button.
2. When finished, press the talk/end button or place the handset on the base
cradle to hang up.
MAKING A CALL
1. Pick up the handset and press the talk/end button. Wait for the dial tone. The
call timer starts counting minutes and seconds in the display.
2. Dial a telephone number.
3. When finished, press the talk/end button again or place the handset on the
base cradle to hang up.
REDIAL
While the phone is ON (in TALK mode), press the redial button to redial the last
number you dialed (up to 32 digits).
FLASH
Use the flash button to activate custom calling services such as call waiting, which
are available through your local phone company.
TIP: Don’t use the talk/end button to activate custom calling services such as
call waiting, or you’ll hang up the phone.
CHANNEL BUTTON
While talking on the phone, it may be necessary for you to manually change the
channel to improve reception and reduce noise or static on the line. Press and
release the channel button to move to the next clear channel.
FINDING THE HANDSET
This feature helps locate a misplaced handset.
Press the page button on the base. The handset beeps continuously for about 2
minutes until you press the talk/callback button on the handset or the page button
on the base.
NOTE: You may still page the handset when the ringer is off.
RINGTONE
1. Make sure the phone is OFF (not in TALK mode).
2. Press the ringtone button.
3. Use touch-tone pad 1, 2 or 3 to select the ring tone 1, 2 or 3. You will hear
selected ring tone.
4. Press ringtone to confirm the selection. You will hear a confirmation tone.
RINGER SWITCH
Set the RINGER switch on the handset to choose the ring level of the handset. You
may choose ON or OFF.
VOLUME
When the phone is ON (in TALK mode) press the volume (- or +) button to adjust
the listening level. Choose from four volume settings. VOL 1 is the lowest volume
and VOL 4 is the highest volume.
MUTE
Use mute during a phone conversation to speak privately and off-line with a third
party.
1. Press the mute button.
The talk/end indicator will blink, and the party on the
telephone will no longer be able to hear you.
2. Press the mute button when finished.
MEMORY
Store up to ten 20-digit numbers in memory for quick dialing.
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button again.
5. Use the touch-tone pad to enter the telephone number you want to store (up to
20 digits).
6. Press memory again to store the number. You will hear a confirmation tone.
CHANGING A STORED NUMBER
Use the same procedure to change a stored number as you do to store a number,
just replace the old phone number with a new one.
STORING A REDIAL NUMBER
1. Repeat steps 1 through 4 in Storing a Name and Number in Memory.
2. Press the redial button.
3. Press the memory button to store the number. You will hear a confirmation
tone.
DIALING A STORED NUMBER
1. Make sure the phone is ON by pressing the talk/endbutton.
2. Press the memory button.
3. Press the memory location (0-9). The number dials automatically.
INSERTING A PAUSE IN THE DIALING SEQUENCE OF A
STORED NUMBER
If a pause is needed to wait for a dial or access tone, press the # pause button to
insert a delay in dialing sequence of a stored number (for example, after you dial
9 for an outside line, or to wait for a computer access tone.) pause shows in the
display as a
P
, and each pause counts as one digit in the dialing sequence.
DELETING STORED NUMBERS
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button twice.
CHAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, such as
calling card calls to a frequently called long distance number. Each part of the
sequence is dialed from memory. The following example shows you how to use
chain dialing to make a call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is ON (in TALK mode).
2. Press memory and then press 7.
3. When you hear the access tone, press memory and then press 8.
4. At the next access tone, press memory and then 9.
TIP: Wait for the access tones before pressing the next memory button, or your
call might not go through.
CHANGING THE BATTERY
Make sure the telephone is OFF (not in TALK mode) before
you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack and
remove the battery pack from the handset.
3. Insert the new battery pack and connect the cord to the
jack inside the battery compartment.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. Allow the handset battery
to properly charge (for 12 hours) prior to first use or when you
install a new battery pack. If you do not properly charge the phone,
battery performance will be compromised.
CAUTION: To reduce the risk of fire or personal
injury, use only the battery listed in the instruction book.
NOTE: If the battery is not properly installed in the handset, or if the battery pack
is not properly connected to the jack inside the battery compartment, the TALK
indicator on the handset blinks when the handset is placed in the base cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this
type, toxic materials could be released which can cause injury.
• To reduce the risk of fire or personal injury, use only the battery listed in the
User’s Guide.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone Signals an incoming call
(with ringer on)
Three short beeps Page signal
(several times)
One beep every 7 seconds Low battery warning
TROUBLESHOOTING TIPS
TELEPHONE SOLUTIONS
No dial tone
• Check or repeat installation steps
• Make sure the base power cord is connected to a working electrical outlet.
• Make sure the telephone line cord is connected to the base unit and the
modular phone jack?
• Disconnect the base from the wall phone jack and connect another phone to
the same jack. If there is no dial tone on the second phone, the problem might
be your wiring or local service.
• The handset might be out of range of the base. Move closer to the base.
• Make sure the battery is properly charged (for 12 hours).
• Ensure the battery pack is installed correctly.
• Did the handset beep when you pressed the talk/callback button? Did the in use
indicator come on? The battery may need to be charged.
Handset does not ring
• Make sure the RINGER switch on the handset is turned to ON.
• You may have too many extension phones on your line. Try unplugging
some phones.
• See solutions for “No dial tone.”
You experience static, noise, or fading in and out
• Change channels
• The handset maybe out of range. Move closer to the base.
• Relocate the base.
• Charge the battery.
• Make sure base is not plugged into an electrical outlet with another
household appliance.
Unit beeps
• Place handset in base cradle for 20 seconds to reset the security code. If that
doesn’t work, charge the battery for 12 hours.
• See solutions for “No dial tone.”
• Replace the battery.
Memory dialing
• Make sure you correctly program the memory location keys.
• Make sure you follow the proper dialing sequence.
• You must reprogram numbers into memory after a power outage or
battery replacement?
Out of range
• Move closer to the base.
• Reset the battery. Unplug the battery and plug it in again after five seconds.
• Reset the power supply. Unplug the supply and plug it in again after five
seconds.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction can shield radio signals.
• You’re too close to appliances such as microwaves, stoves, computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into an AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
GENERAL PRODUCT CARE
To keep your telephone working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that generate
electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the phone.
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them
for future reference.
Your cordless telephone is designed to give you flexibility in use and high quality
performance. To get the most from your cordless telephone, we suggest that you
take a few minutes right now to read through this instruction manual.
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
HANDSET AND BASE LAYOUT
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2004 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Model 25828
00001830 (Rev. 0 Dom E/S)
04-33
Printed in China
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a modular
jack, call your local phone company to find out how to get
one installed.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After
power outage or battery replacement, you should place the handset in the base
for about 20 seconds to reset the code.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If
such interference continues, move the cordless telephone farther away from
these appliances.
Certain other communications devices may also use the 5.8 GHz frequency for
communication, and, if not properly set, these devices may interfere with each
other and/or your new telephone. If you are concerned with interference, please
refer to the owner’s manual for these devices on how to properly set channels to
avoid interference. Typical devices that may use the 5.8 GHz frequency for
communication include wireless audio/video senders, wireless computer
networks, multi-handset cordless telephone systems, and some long-range
cordless telephone systems.
INSTALLATION
IMPORTANT INSTALLATION GUIDELINES
• Avoid sources of noise and heat, such as motors, fluorescent lighting,
microwave ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid other cordless telephones or personal computers.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone
line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
INSTALLING THE PHONE
Base Handset
Belt clip
Line cord AC power
converter
Handset
battery
Modular
telephone
line jack
Wall plate
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
Battery
compartment
door
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
PAGE
charge
in use
volume
-/+ arrow
(button)
redial
(button)
channel
(button) flash
(button)
*exit
(button)
#pause
(button)
ringtone
(button)
PAG E
charge
in use
page
(button)
charge/in use
(indicator)
memory
(button)
mute
(button)
talk/end
(button)
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here. 1. Choose an area near an electrical outlet and a telephone wall jack (RJ11C), and
place your cordless telephone on a level surface, such as a desktop or
tabletop, or you may mount it on the wall.
2. Install the handset battery.
CAUTION: To reduce the risk of fire or personal injury, use only the
battery 5-2548, which is compatible with this unit.
NOTE: You must connect the handset battery before use.
NOTE: If the battery is not properly installed in the handset, or if the battery
pack is not properly connected to the jack inside the battery compartment,
the TALK indicator on the handset blinks when the handset is placed in the
base cradle.
• Plug the battery pack cord into the jack located inside the battery compartment,
then place the battery pack inside the battery compartment.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we are
participating in a program to collect and recycle Nickel
Cadmium batteries throughout the United States.
Please call 1-800-8-BATTERY for information or contact
your local recycling center.
Ni-Cd
RBRC
RBRC
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a later date.
SERVICE
If trouble is experienced with this equipment, for repair or warranty information,
please contact customer service at 1-800-448-0329. If the equipment is causing
harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service
agents. Changes or modifications not expressly approved by ATLINKS USA, Inc.
could void the user’s authority to operate this product. For instructions on how to
obtain service, refer to the warranty included in this guide or call customer
service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date
this product was purchased or received as a gift. This information will be valuable
if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different
from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or
an experienced radio/television technician for additional suggestions. Also, the
Federal Communications Commission has prepared a helpful booklet, “How To
Identify and Resolve Radio/TV Interference Problems.” This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit
is under warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally
provided with the product. We recommend using the original carton and
packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period, must be presented to
obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via
standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no liability in case
of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information regarding
operating instructions and user controls. Any additional information, should be
obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit.
It will make it easier to contact you should it ever be necessary. The return of
the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO
THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING
ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. ATLINKS USA, INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts
so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each individual state,
country, and locality to which the merchandise is being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION MODEL NO. PRICE*
25838GE1-A 25838GE-3 25828GE6-A
Belt Clip 5-2622 (gray) 5-2621 (blue) 5-2656 (lt. gray) $4.95
Headset 5-2444 (white) 5-2425 (black 5-2425 (black $36.35
Replacement Battery 5-2458 5-2458 5-2458 $14.95
Power converter 5-2629 (gray) 5-2501 (black) 5-2501 (black) $15.50
5.8 GHz Call Waiting
Cordless Telephone
User's Guide
We bring good things to life.
25828
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in
compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone
Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and
Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information
to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still
have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum
of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone
from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company may
temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC Rules
and Regulations. If these changes are expected to affect the use or performance of your telephone equipment,
the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
• Put the battery compartment door back on.
3. Plug one end of the telephone line cord into the TEL LINE jack on the back of
the base and the other end into a modular jack.
4. Set the RINGER switch (on the handset) to ON.
5. Plug the AC power converter into the electrical outlet and the DC connector into
the jack on the back of the base.
6. Place the handset in the base cradle. The charge/in use indicator turns on,
verifying the battery is charging.
7. Allow the phone to charge for 12 hours prior to first use. If you don't properly
charge the phone, battery performance is compromised.
CAUTION: Use only the ATLINKS USA, Inc. 5-2629 (gray) or 52501
(black) power converter that came with this unit. Using other power
converters may damage the unit.
NOTE : The phone is shipped in tone dialing mode from the manufacturer.
WALL MOUNTING
NOTE: For best results, charge the phone on a flat surface before you mount
it on the wall.
1. Slip the mounting holes (on the back of the base) over the wall plate posts, and
slide the unit down into place. (Wall plate not included.)
2. Place the handset on the base cradle.
CORDLESS PHONE BASICS
CHARGE/IN USE INDICATOR
The phone is ON when the talk/end indicator on the handset and the charge/in use
indicator on the base is lit. The handset and base indicators flash when you
receive a call.
ANSWERING A CALL
1. When the phone rings, pick up the handset and press the talk/end button.
2. When finished, press the talk/end button or place the handset on the base
cradle to hang up.
MAKING A CALL
1. Pick up the handset and press the talk/end button. Wait for the dial tone. The
call timer starts counting minutes and seconds in the display.
2. Dial a telephone number.
3. When finished, press the talk/end button again or place the handset on the
base cradle to hang up.
REDIAL
While the phone is ON (in TALK mode), press the redial button to redial the last
number you dialed (up to 32 digits).
FLASH
Use the flash button to activate custom calling services such as call waiting, which
are available through your local phone company.
TIP: Don’t use the talk/end button to activate custom calling services such as
call waiting, or you’ll hang up the phone.
CHANNEL BUTTON
While talking on the phone, it may be necessary for you to manually change the
channel to improve reception and reduce noise or static on the line. Press and
release the channel button to move to the next clear channel.
FINDING THE HANDSET
This feature helps locate a misplaced handset.
Press the page button on the base. The handset beeps continuously for about 2
minutes until you press the talk/callback button on the handset or the page button
on the base.
NOTE: You may still page the handset when the ringer is off.
RINGTONE
1. Make sure the phone is OFF (not in TALK mode).
2. Press the ringtone button.
3. Use touch-tone pad 1, 2 or 3 to select the ring tone 1, 2 or 3. You will hear
selected ring tone.
4. Press ringtone to confirm the selection. You will hear a confirmation tone.
RINGER SWITCH
Set the RINGER switch on the handset to choose the ring level of the handset. You
may choose ON or OFF.
VOLUME
When the phone is ON (in TALK mode) press the volume (- or +) button to adjust
the listening level. Choose from four volume settings. VOL 1 is the lowest volume
and VOL 4 is the highest volume.
MUTE
Use mute during a phone conversation to speak privately and off-line with a third
party.
1. Press the mute button.
The talk/end indicator will blink, and the party on the
telephone will no longer be able to hear you.
2. Press the mute button when finished.
MEMORY
Store up to ten 20-digit numbers in memory for quick dialing.
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button again.
5. Use the touch-tone pad to enter the telephone number you want to store (up to
20 digits).
6. Press memory again to store the number. You will hear a confirmation tone.
CHANGING A STORED NUMBER
Use the same procedure to change a stored number as you do to store a number,
just replace the old phone number with a new one.
STORING A REDIAL NUMBER
1. Repeat steps 1 through 4 in Storing a Name and Number in Memory.
2. Press the redial button.
3. Press the memory button to store the number. You will hear a confirmation
tone.
DIALING A STORED NUMBER
1. Make sure the phone is ON by pressing the talk/endbutton.
2. Press the memory button.
3. Press the memory location (0-9). The number dials automatically.
INSERTING A PAUSE IN THE DIALING SEQUENCE OF A
STORED NUMBER
If a pause is needed to wait for a dial or access tone, press the # pause button to
insert a delay in dialing sequence of a stored number (for example, after you dial
9 for an outside line, or to wait for a computer access tone.) pause shows in the
display as a
P
, and each pause counts as one digit in the dialing sequence.
DELETING STORED NUMBERS
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button twice.
CHAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, such as
calling card calls to a frequently called long distance number. Each part of the
sequence is dialed from memory. The following example shows you how to use
chain dialing to make a call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is ON (in TALK mode).
2. Press memory and then press 7.
3. When you hear the access tone, press memory and then press 8.
4. At the next access tone, press memory and then 9.
TIP: Wait for the access tones before pressing the next memory button, or your
call might not go through.
CHANGING THE BATTERY
Make sure the telephone is OFF (not in TALK mode) before
you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack and
remove the battery pack from the handset.
3. Insert the new battery pack and connect the cord to the
jack inside the battery compartment.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. Allow the handset battery
to properly charge (for 12 hours) prior to first use or when you
install a new battery pack. If you do not properly charge the phone,
battery performance will be compromised.
CAUTION: To reduce the risk of fire or personal
injury, use only the battery listed in the instruction book.
NOTE: If the battery is not properly installed in the handset, or if the battery pack
is not properly connected to the jack inside the battery compartment, the TALK
indicator on the handset blinks when the handset is placed in the base cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this
type, toxic materials could be released which can cause injury.
• To reduce the risk of fire or personal injury, use only the battery listed in the
User’s Guide.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone Signals an incoming call
(with ringer on)
Three short beeps Page signal
(several times)
One beep every 7 seconds Low battery warning
TROUBLESHOOTING TIPS
TELEPHONE SOLUTIONS
No dial tone
• Check or repeat installation steps
• Make sure the base power cord is connected to a working electrical outlet.
• Make sure the telephone line cord is connected to the base unit and the
modular phone jack?
• Disconnect the base from the wall phone jack and connect another phone to
the same jack. If there is no dial tone on the second phone, the problem might
be your wiring or local service.
• The handset might be out of range of the base. Move closer to the base.
• Make sure the battery is properly charged (for 12 hours).
• Ensure the battery pack is installed correctly.
• Did the handset beep when you pressed the talk/callback button? Did the in use
indicator come on? The battery may need to be charged.
Handset does not ring
• Make sure the RINGER switch on the handset is turned to ON.
• You may have too many extension phones on your line. Try unplugging
some phones.
• See solutions for “No dial tone.”
You experience static, noise, or fading in and out
• Change channels
• The handset maybe out of range. Move closer to the base.
• Relocate the base.
• Charge the battery.
• Make sure base is not plugged into an electrical outlet with another
household appliance.
Unit beeps
• Place handset in base cradle for 20 seconds to reset the security code. If that
doesn’t work, charge the battery for 12 hours.
• See solutions for “No dial tone.”
• Replace the battery.
Memory dialing
• Make sure you correctly program the memory location keys.
• Make sure you follow the proper dialing sequence.
• You must reprogram numbers into memory after a power outage or
battery replacement?
Out of range
• Move closer to the base.
• Reset the battery. Unplug the battery and plug it in again after five seconds.
• Reset the power supply. Unplug the supply and plug it in again after five
seconds.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction can shield radio signals.
• You’re too close to appliances such as microwaves, stoves, computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into an AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
GENERAL PRODUCT CARE
To keep your telephone working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that generate
electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the phone.
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them
for future reference.
Your cordless telephone is designed to give you flexibility in use and high quality
performance. To get the most from your cordless telephone, we suggest that you
take a few minutes right now to read through this instruction manual.
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
HANDSET AND BASE LAYOUT
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2004 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Model 25828
00001830 (Rev. 0 Dom E/S)
04-33
Printed in China
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a modular
jack, call your local phone company to find out how to get
one installed.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After
power outage or battery replacement, you should place the handset in the base
for about 20 seconds to reset the code.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If
such interference continues, move the cordless telephone farther away from
these appliances.
Certain other communications devices may also use the 5.8 GHz frequency for
communication, and, if not properly set, these devices may interfere with each
other and/or your new telephone. If you are concerned with interference, please
refer to the owner’s manual for these devices on how to properly set channels to
avoid interference. Typical devices that may use the 5.8 GHz frequency for
communication include wireless audio/video senders, wireless computer
networks, multi-handset cordless telephone systems, and some long-range
cordless telephone systems.
INSTALLATION
IMPORTANT INSTALLATION GUIDELINES
• Avoid sources of noise and heat, such as motors, fluorescent lighting,
microwave ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid other cordless telephones or personal computers.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone
line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
INSTALLING THE PHONE
Base Handset
Belt clip
Line cord AC power
converter
Handset
battery
Modular
telephone
line jack
Wall plate
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
Battery
compartment
door
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
PAGE
charge
in use
volume
-/+ arrow
(button)
redial
(button)
channel
(button) flash
(button)
*exit
(button)
#pause
(button)
ringtone
(button)
PAG E
charge
in use
page
(button)
charge/in use
(indicator)
memory
(button)
mute
(button)
talk/end
(button)
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here. 1. Choose an area near an electrical outlet and a telephone wall jack (RJ11C), and
place your cordless telephone on a level surface, such as a desktop or
tabletop, or you may mount it on the wall.
2. Install the handset battery.
CAUTION: To reduce the risk of fire or personal injury, use only the
battery 5-2548, which is compatible with this unit.
NOTE: You must connect the handset battery before use.
NOTE: If the battery is not properly installed in the handset, or if the battery
pack is not properly connected to the jack inside the battery compartment,
the TALK indicator on the handset blinks when the handset is placed in the
base cradle.
• Plug the battery pack cord into the jack located inside the battery compartment,
then place the battery pack inside the battery compartment.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we are
participating in a program to collect and recycle Nickel
Cadmium batteries throughout the United States.
Please call 1-800-8-BATTERY for information or contact
your local recycling center.
Ni-Cd
RBRC
RBRC
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a later date.
SERVICE
If trouble is experienced with this equipment, for repair or warranty information,
please contact customer service at 1-800-448-0329. If the equipment is causing
harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service
agents. Changes or modifications not expressly approved by ATLINKS USA, Inc.
could void the user’s authority to operate this product. For instructions on how to
obtain service, refer to the warranty included in this guide or call customer
service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date
this product was purchased or received as a gift. This information will be valuable
if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different
from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or
an experienced radio/television technician for additional suggestions. Also, the
Federal Communications Commission has prepared a helpful booklet, “How To
Identify and Resolve Radio/TV Interference Problems.” This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit
is under warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally
provided with the product. We recommend using the original carton and
packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period, must be presented to
obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via
standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no liability in case
of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information regarding
operating instructions and user controls. Any additional information, should be
obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit.
It will make it easier to contact you should it ever be necessary. The return of
the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO
THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING
ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. ATLINKS USA, INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts
so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each individual state,
country, and locality to which the merchandise is being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION MODEL NO. PRICE*
25838GE1-A 25838GE-3 25828GE6-A
Belt Clip 5-2622 (gray) 5-2621 (blue) 5-2656 (lt. gray) $4.95
Headset 5-2444 (white) 5-2425 (black 5-2425 (black $36.35
Replacement Battery 5-2458 5-2458 5-2458 $14.95
Power converter 5-2629 (gray) 5-2501 (black) 5-2501 (black) $15.50
5.8 GHz Call Waiting
Cordless Telephone
User's Guide
We bring good things to life.
25828
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in
compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone
Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and
Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information
to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still
have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum
of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone
from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company may
temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC Rules
and Regulations. If these changes are expected to affect the use or performance of your telephone equipment,
the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
• Put the battery compartment door back on.
3. Plug one end of the telephone line cord into the TEL LINE jack on the back of
the base and the other end into a modular jack.
4. Set the RINGER switch (on the handset) to ON.
5. Plug the AC power converter into the electrical outlet and the DC connector into
the jack on the back of the base.
6. Place the handset in the base cradle. The charge/in use indicator turns on,
verifying the battery is charging.
7. Allow the phone to charge for 12 hours prior to first use. If you don't properly
charge the phone, battery performance is compromised.
CAUTION: Use only the ATLINKS USA, Inc. 5-2629 (gray) or 52501
(black) power converter that came with this unit. Using other power
converters may damage the unit.
NOTE : The phone is shipped in tone dialing mode from the manufacturer.
WALL MOUNTING
NOTE: For best results, charge the phone on a flat surface before you mount
it on the wall.
1. Slip the mounting holes (on the back of the base) over the wall plate posts, and
slide the unit down into place. (Wall plate not included.)
2. Place the handset on the base cradle.
CORDLESS PHONE BASICS
CHARGE/IN USE INDICATOR
The phone is ON when the talk/end indicator on the handset and the charge/in use
indicator on the base is lit. The handset and base indicators flash when you
receive a call.
ANSWERING A CALL
1. When the phone rings, pick up the handset and press the talk/end button.
2. When finished, press the talk/end button or place the handset on the base
cradle to hang up.
MAKING A CALL
1. Pick up the handset and press the talk/end button. Wait for the dial tone. The
call timer starts counting minutes and seconds in the display.
2. Dial a telephone number.
3. When finished, press the talk/end button again or place the handset on the
base cradle to hang up.
REDIAL
While the phone is ON (in TALK mode), press the redial button to redial the last
number you dialed (up to 32 digits).
FLASH
Use the flash button to activate custom calling services such as call waiting, which
are available through your local phone company.
TIP: Don’t use the talk/end button to activate custom calling services such as
call waiting, or you’ll hang up the phone.
CHANNEL BUTTON
While talking on the phone, it may be necessary for you to manually change the
channel to improve reception and reduce noise or static on the line. Press and
release the channel button to move to the next clear channel.
FINDING THE HANDSET
This feature helps locate a misplaced handset.
Press the page button on the base. The handset beeps continuously for about 2
minutes until you press the talk/callback button on the handset or the page button
on the base.
NOTE: You may still page the handset when the ringer is off.
RINGTONE
1. Make sure the phone is OFF (not in TALK mode).
2. Press the ringtone button.
3. Use touch-tone pad 1, 2 or 3 to select the ring tone 1, 2 or 3. You will hear
selected ring tone.
4. Press ringtone to confirm the selection. You will hear a confirmation tone.
RINGER SWITCH
Set the RINGER switch on the handset to choose the ring level of the handset. You
may choose ON or OFF.
VOLUME
When the phone is ON (in TALK mode) press the volume (- or +) button to adjust
the listening level. Choose from four volume settings. VOL 1 is the lowest volume
and VOL 4 is the highest volume.
MUTE
Use mute during a phone conversation to speak privately and off-line with a third
party.
1. Press the mute button.
The talk/end indicator will blink, and the party on the
telephone will no longer be able to hear you.
2. Press the mute button when finished.
MEMORY
Store up to ten 20-digit numbers in memory for quick dialing.
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button again.
5. Use the touch-tone pad to enter the telephone number you want to store (up to
20 digits).
6. Press memory again to store the number. You will hear a confirmation tone.
CHANGING A STORED NUMBER
Use the same procedure to change a stored number as you do to store a number,
just replace the old phone number with a new one.
STORING A REDIAL NUMBER
1. Repeat steps 1 through 4 in Storing a Name and Number in Memory.
2. Press the redial button.
3. Press the memory button to store the number. You will hear a confirmation
tone.
DIALING A STORED NUMBER
1. Make sure the phone is ON by pressing the talk/endbutton.
2. Press the memory button.
3. Press the memory location (0-9). The number dials automatically.
INSERTING A PAUSE IN THE DIALING SEQUENCE OF A
STORED NUMBER
If a pause is needed to wait for a dial or access tone, press the # pause button to
insert a delay in dialing sequence of a stored number (for example, after you dial
9 for an outside line, or to wait for a computer access tone.) pause shows in the
display as a
P
, and each pause counts as one digit in the dialing sequence.
DELETING STORED NUMBERS
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button twice.
CHAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, such as
calling card calls to a frequently called long distance number. Each part of the
sequence is dialed from memory. The following example shows you how to use
chain dialing to make a call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is ON (in TALK mode).
2. Press memory and then press 7.
3. When you hear the access tone, press memory and then press 8.
4. At the next access tone, press memory and then 9.
TIP: Wait for the access tones before pressing the next memory button, or your
call might not go through.
CHANGING THE BATTERY
Make sure the telephone is OFF (not in TALK mode) before
you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack and
remove the battery pack from the handset.
3. Insert the new battery pack and connect the cord to the
jack inside the battery compartment.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. Allow the handset battery
to properly charge (for 12 hours) prior to first use or when you
install a new battery pack. If you do not properly charge the phone,
battery performance will be compromised.
CAUTION: To reduce the risk of fire or personal
injury, use only the battery listed in the instruction book.
NOTE: If the battery is not properly installed in the handset, or if the battery pack
is not properly connected to the jack inside the battery compartment, the TALK
indicator on the handset blinks when the handset is placed in the base cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this
type, toxic materials could be released which can cause injury.
• To reduce the risk of fire or personal injury, use only the battery listed in the
User’s Guide.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone Signals an incoming call
(with ringer on)
Three short beeps Page signal
(several times)
One beep every 7 seconds Low battery warning
TROUBLESHOOTING TIPS
TELEPHONE SOLUTIONS
No dial tone
• Check or repeat installation steps
• Make sure the base power cord is connected to a working electrical outlet.
• Make sure the telephone line cord is connected to the base unit and the
modular phone jack?
• Disconnect the base from the wall phone jack and connect another phone to
the same jack. If there is no dial tone on the second phone, the problem might
be your wiring or local service.
• The handset might be out of range of the base. Move closer to the base.
• Make sure the battery is properly charged (for 12 hours).
• Ensure the battery pack is installed correctly.
• Did the handset beep when you pressed the talk/callback button? Did the in use
indicator come on? The battery may need to be charged.
Handset does not ring
• Make sure the RINGER switch on the handset is turned to ON.
• You may have too many extension phones on your line. Try unplugging
some phones.
• See solutions for “No dial tone.”
You experience static, noise, or fading in and out
• Change channels
• The handset maybe out of range. Move closer to the base.
• Relocate the base.
• Charge the battery.
• Make sure base is not plugged into an electrical outlet with another
household appliance.
Unit beeps
• Place handset in base cradle for 20 seconds to reset the security code. If that
doesn’t work, charge the battery for 12 hours.
• See solutions for “No dial tone.”
• Replace the battery.
Memory dialing
• Make sure you correctly program the memory location keys.
• Make sure you follow the proper dialing sequence.
• You must reprogram numbers into memory after a power outage or
battery replacement?
Out of range
• Move closer to the base.
• Reset the battery. Unplug the battery and plug it in again after five seconds.
• Reset the power supply. Unplug the supply and plug it in again after five
seconds.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction can shield radio signals.
• You’re too close to appliances such as microwaves, stoves, computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into an AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
GENERAL PRODUCT CARE
To keep your telephone working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that generate
electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the phone.
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them
for future reference.
Your cordless telephone is designed to give you flexibility in use and high quality
performance. To get the most from your cordless telephone, we suggest that you
take a few minutes right now to read through this instruction manual.
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
HANDSET AND BASE LAYOUT
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2004 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Model 25828
00001830 (Rev. 0 Dom E/S)
04-33
Printed in China
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a modular
jack, call your local phone company to find out how to get
one installed.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After
power outage or battery replacement, you should place the handset in the base
for about 20 seconds to reset the code.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If
such interference continues, move the cordless telephone farther away from
these appliances.
Certain other communications devices may also use the 5.8 GHz frequency for
communication, and, if not properly set, these devices may interfere with each
other and/or your new telephone. If you are concerned with interference, please
refer to the owner’s manual for these devices on how to properly set channels to
avoid interference. Typical devices that may use the 5.8 GHz frequency for
communication include wireless audio/video senders, wireless computer
networks, multi-handset cordless telephone systems, and some long-range
cordless telephone systems.
INSTALLATION
IMPORTANT INSTALLATION GUIDELINES
• Avoid sources of noise and heat, such as motors, fluorescent lighting,
microwave ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid other cordless telephones or personal computers.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone
line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
INSTALLING THE PHONE
Base Handset
Belt clip
Line cord AC power
converter
Handset
battery
Modular
telephone
line jack
Wall plate
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
Battery
compartment
door
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
PAGE
charge
in use
volume
-/+ arrow
(button)
redial
(button)
channel
(button) flash
(button)
*exit
(button)
#pause
(button)
ringtone
(button)
PAG E
charge
in use
page
(button)
charge/in use
(indicator)
memory
(button)
mute
(button)
talk/end
(button)
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here. 1. Choose an area near an electrical outlet and a telephone wall jack (RJ11C), and
place your cordless telephone on a level surface, such as a desktop or
tabletop, or you may mount it on the wall.
2. Install the handset battery.
CAUTION: To reduce the risk of fire or personal injury, use only the
battery 5-2548, which is compatible with this unit.
NOTE: You must connect the handset battery before use.
NOTE: If the battery is not properly installed in the handset, or if the battery
pack is not properly connected to the jack inside the battery compartment,
the TALK indicator on the handset blinks when the handset is placed in the
base cradle.
• Plug the battery pack cord into the jack located inside the battery compartment,
then place the battery pack inside the battery compartment.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we are
participating in a program to collect and recycle Nickel
Cadmium batteries throughout the United States.
Please call 1-800-8-BATTERY for information or contact
your local recycling center.
Ni-Cd
RBRC
RBRC
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a later date.
SERVICE
If trouble is experienced with this equipment, for repair or warranty information,
please contact customer service at 1-800-448-0329. If the equipment is causing
harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service
agents. Changes or modifications not expressly approved by ATLINKS USA, Inc.
could void the user’s authority to operate this product. For instructions on how to
obtain service, refer to the warranty included in this guide or call customer
service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date
this product was purchased or received as a gift. This information will be valuable
if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different
from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or
an experienced radio/television technician for additional suggestions. Also, the
Federal Communications Commission has prepared a helpful booklet, “How To
Identify and Resolve Radio/TV Interference Problems.” This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit
is under warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally
provided with the product. We recommend using the original carton and
packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period, must be presented to
obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via
standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no liability in case
of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information regarding
operating instructions and user controls. Any additional information, should be
obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit.
It will make it easier to contact you should it ever be necessary. The return of
the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO
THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING
ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. ATLINKS USA, INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts
so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each individual state,
country, and locality to which the merchandise is being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION MODEL NO. PRICE*
25838GE1-A 25838GE-3 25828GE6-A
Belt Clip 5-2622 (gray) 5-2621 (blue) 5-2656 (lt. gray) $4.95
Headset 5-2444 (white) 5-2425 (black 5-2425 (black $36.35
Replacement Battery 5-2458 5-2458 5-2458 $14.95
Power converter 5-2629 (gray) 5-2501 (black) 5-2501 (black) $15.50
5.8 GHz Call Waiting
Cordless Telephone
User's Guide
We bring good things to life.
25828
EQUIPMENT APPROVAL INFORMATION
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in
compliance with parts 15 and 68, FCC Rules and Regulations and the Technical Requirements for Telephone
Terminal Equipment published by ACTA.
1Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and
Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information
to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still
have all of these devices ring when your telephone number is called. In most (but not all) areas, the sum
of the RENs of all devices connected to one line should not exceed 5. To be certain of the number of
devices you may connect to your line as determined by the REN, you should contact your local
telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must
comply with the applicable FCC Part 68 rules and requirements adopted by the ACTA. A compliant
telephone cord and modular plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions for details.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone
equipment if you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone
from your line.
• If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this product does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.
2Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required.
Where prior notice is not practicable and the circumstances warrant such action, the telephone company may
temporarily discontinue service immediately. In case of such temporary discontinuance, the telephone
company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the opportunity to
correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to
procedures set forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or
procedures where such action is required in the operation of its business and not inconsistent with FCC Rules
and Regulations. If these changes are expected to affect the use or performance of your telephone equipment,
the telephone company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
HEARING AID COMPATIBILITY (HAC)
This telephone system meets FCC standards for Hearing Aid Compatibility.
• Put the battery compartment door back on.
3. Plug one end of the telephone line cord into the TEL LINE jack on the back of
the base and the other end into a modular jack.
4. Set the RINGER switch (on the handset) to ON.
5. Plug the AC power converter into the electrical outlet and the DC connector into
the jack on the back of the base.
6. Place the handset in the base cradle. The charge/in use indicator turns on,
verifying the battery is charging.
7. Allow the phone to charge for 12 hours prior to first use. If you don't properly
charge the phone, battery performance is compromised.
CAUTION: Use only the ATLINKS USA, Inc. 5-2629 (gray) or 52501
(black) power converter that came with this unit. Using other power
converters may damage the unit.
NOTE : The phone is shipped in tone dialing mode from the manufacturer.
WALL MOUNTING
NOTE: For best results, charge the phone on a flat surface before you mount
it on the wall.
1. Slip the mounting holes (on the back of the base) over the wall plate posts, and
slide the unit down into place. (Wall plate not included.)
2. Place the handset on the base cradle.
CORDLESS PHONE BASICS
CHARGE/IN USE INDICATOR
The phone is ON when the talk/end indicator on the handset and the charge/in use
indicator on the base is lit. The handset and base indicators flash when you
receive a call.
ANSWERING A CALL
1. When the phone rings, pick up the handset and press the talk/end button.
2. When finished, press the talk/end button or place the handset on the base
cradle to hang up.
MAKING A CALL
1. Pick up the handset and press the talk/end button. Wait for the dial tone. The
call timer starts counting minutes and seconds in the display.
2. Dial a telephone number.
3. When finished, press the talk/end button again or place the handset on the
base cradle to hang up.
REDIAL
While the phone is ON (in TALK mode), press the redial button to redial the last
number you dialed (up to 32 digits).
FLASH
Use the flash button to activate custom calling services such as call waiting, which
are available through your local phone company.
TIP: Don’t use the talk/end button to activate custom calling services such as
call waiting, or you’ll hang up the phone.
CHANNEL BUTTON
While talking on the phone, it may be necessary for you to manually change the
channel to improve reception and reduce noise or static on the line. Press and
release the channel button to move to the next clear channel.
FINDING THE HANDSET
This feature helps locate a misplaced handset.
Press the page button on the base. The handset beeps continuously for about 2
minutes until you press the talk/callback button on the handset or the page button
on the base.
NOTE: You may still page the handset when the ringer is off.
RINGTONE
1. Make sure the phone is OFF (not in TALK mode).
2. Press the ringtone button.
3. Use touch-tone pad 1, 2 or 3 to select the ring tone 1, 2 or 3. You will hear
selected ring tone.
4. Press ringtone to confirm the selection. You will hear a confirmation tone.
RINGER SWITCH
Set the RINGER switch on the handset to choose the ring level of the handset. You
may choose ON or OFF.
VOLUME
When the phone is ON (in TALK mode) press the volume (- or +) button to adjust
the listening level. Choose from four volume settings. VOL 1 is the lowest volume
and VOL 4 is the highest volume.
MUTE
Use mute during a phone conversation to speak privately and off-line with a third
party.
1. Press the mute button.
The talk/end indicator will blink, and the party on the
telephone will no longer be able to hear you.
2. Press the mute button when finished.
MEMORY
Store up to ten 20-digit numbers in memory for quick dialing.
STORING A NAME AND NUMBER IN MEMORY
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button again.
5. Use the touch-tone pad to enter the telephone number you want to store (up to
20 digits).
6. Press memory again to store the number. You will hear a confirmation tone.
CHANGING A STORED NUMBER
Use the same procedure to change a stored number as you do to store a number,
just replace the old phone number with a new one.
STORING A REDIAL NUMBER
1. Repeat steps 1 through 4 in Storing a Name and Number in Memory.
2. Press the redial button.
3. Press the memory button to store the number. You will hear a confirmation
tone.
DIALING A STORED NUMBER
1. Make sure the phone is ON by pressing the talk/endbutton.
2. Press the memory button.
3. Press the memory location (0-9). The number dials automatically.
INSERTING A PAUSE IN THE DIALING SEQUENCE OF A
STORED NUMBER
If a pause is needed to wait for a dial or access tone, press the # pause button to
insert a delay in dialing sequence of a stored number (for example, after you dial
9 for an outside line, or to wait for a computer access tone.) pause shows in the
display as a
P
, and each pause counts as one digit in the dialing sequence.
DELETING STORED NUMBERS
1. Make sure the phone is OFF (not in TALK mode).
2. Press the memory button.
3. Press the desired memory location (0 through 9).
4. Press the memory button twice.
CHAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, such as
calling card calls to a frequently called long distance number. Each part of the
sequence is dialed from memory. The following example shows you how to use
chain dialing to make a call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1. Make sure the phone is ON (in TALK mode).
2. Press memory and then press 7.
3. When you hear the access tone, press memory and then press 8.
4. At the next access tone, press memory and then 9.
TIP: Wait for the access tones before pressing the next memory button, or your
call might not go through.
CHANGING THE BATTERY
Make sure the telephone is OFF (not in TALK mode) before
you replace battery.
1. Remove the battery compartment door.
2. Disconnect the cord attached to the battery pack and
remove the battery pack from the handset.
3. Insert the new battery pack and connect the cord to the
jack inside the battery compartment.
4. Put the battery compartment door back on.
5. Place handset in the base to charge. Allow the handset battery
to properly charge (for 12 hours) prior to first use or when you
install a new battery pack. If you do not properly charge the phone,
battery performance will be compromised.
CAUTION: To reduce the risk of fire or personal
injury, use only the battery listed in the instruction book.
NOTE: If the battery is not properly installed in the handset, or if the battery pack
is not properly connected to the jack inside the battery compartment, the TALK
indicator on the handset blinks when the handset is placed in the base cradle.
BATTERY SAFETY PRECAUTIONS
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this
type, toxic materials could be released which can cause injury.
• To reduce the risk of fire or personal injury, use only the battery listed in the
User’s Guide.
• Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
HANDSET SOUND SIGNALS
Signal Meaning
A long warbling tone Signals an incoming call
(with ringer on)
Three short beeps Page signal
(several times)
One beep every 7 seconds Low battery warning
TROUBLESHOOTING TIPS
TELEPHONE SOLUTIONS
No dial tone
• Check or repeat installation steps
• Make sure the base power cord is connected to a working electrical outlet.
• Make sure the telephone line cord is connected to the base unit and the
modular phone jack?
• Disconnect the base from the wall phone jack and connect another phone to
the same jack. If there is no dial tone on the second phone, the problem might
be your wiring or local service.
• The handset might be out of range of the base. Move closer to the base.
• Make sure the battery is properly charged (for 12 hours).
• Ensure the battery pack is installed correctly.
• Did the handset beep when you pressed the talk/callback button? Did the in use
indicator come on? The battery may need to be charged.
Handset does not ring
• Make sure the RINGER switch on the handset is turned to ON.
• You may have too many extension phones on your line. Try unplugging
some phones.
• See solutions for “No dial tone.”
You experience static, noise, or fading in and out
• Change channels
• The handset maybe out of range. Move closer to the base.
• Relocate the base.
• Charge the battery.
• Make sure base is not plugged into an electrical outlet with another
household appliance.
Unit beeps
• Place handset in base cradle for 20 seconds to reset the security code. If that
doesn’t work, charge the battery for 12 hours.
• See solutions for “No dial tone.”
• Replace the battery.
Memory dialing
• Make sure you correctly program the memory location keys.
• Make sure you follow the proper dialing sequence.
• You must reprogram numbers into memory after a power outage or
battery replacement?
Out of range
• Move closer to the base.
• Reset the battery. Unplug the battery and plug it in again after five seconds.
• Reset the power supply. Unplug the supply and plug it in again after five
seconds.
CAUSES OF POOR RECEPTION
• Aluminum siding.
• Foil backing on insulation.
• Heating ducts and other metal construction can shield radio signals.
• You’re too close to appliances such as microwaves, stoves, computers, etc.
• Atmospheric conditions, such as strong storms.
• Base is installed in the basement or lower floor of the house.
• Base is plugged into an AC outlet with other electronic devices.
• Baby monitor is using the same frequency.
• Handset battery is low.
• You’re out of range of the base.
GENERAL PRODUCT CARE
To keep your telephone working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that generate
electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping and other rough treatment to the phone.
INTRODUCTION
CAUTION: When using telephone equipment, there are basic safety
instructions that should always be followed. Refer to the IMPORTANT
SAFETY INSTRUCTIONS provided with this product and save them
for future reference.
Your cordless telephone is designed to give you flexibility in use and high quality
performance. To get the most from your cordless telephone, we suggest that you
take a few minutes right now to read through this instruction manual.
IMPORTANT: Because cordless phones operate on electricity, you should
have at least one phone in your home that isn’t cordless, in case the power in
your home goes out.
HANDSET AND BASE LAYOUT
ATLINKS USA, Inc.
101 West 103rd Street
Indianapolis, IN 46290
© 2004 ATLINKS USA, Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Model 25828
00001830 (Rev. 0 Dom E/S)
04-33
Printed in China
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular
telephone jack, which might look like the one pictured
here, installed in your home. If you don’t have a modular
jack, call your local phone company to find out how to get
one installed.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to protect against false
ringing, unauthorized access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After
power outage or battery replacement, you should place the handset in the base
for about 20 seconds to reset the code.
INSTALLATION NOTE: Some cordless telephones operate at frequencies
that may cause interference to nearby TVs microwave ovens, and VCRs. To
minimize or prevent such interference, the base of the cordless telephone
should not be placed near or on top of a TV, microwave ovens, or VCR. If
such interference continues, move the cordless telephone farther away from
these appliances.
Certain other communications devices may also use the 5.8 GHz frequency for
communication, and, if not properly set, these devices may interfere with each
other and/or your new telephone. If you are concerned with interference, please
refer to the owner’s manual for these devices on how to properly set channels to
avoid interference. Typical devices that may use the 5.8 GHz frequency for
communication include wireless audio/video senders, wireless computer
networks, multi-handset cordless telephone systems, and some long-range
cordless telephone systems.
INSTALLATION
IMPORTANT INSTALLATION GUIDELINES
• Avoid sources of noise and heat, such as motors, fluorescent lighting,
microwave ovens, heating appliances and direct sunlight.
• Avoid areas of excessive dust, moisture and low temperature.
• Avoid other cordless telephones or personal computers.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone
line has been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
INSTALLING THE PHONE
Base Handset
Belt clip
Line cord AC power
converter
Handset
battery
Modular
telephone
line jack
Wall plate
SEE MARKING ON BOTTOM / BACK OF PRODUCT
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO
PREVENT FIRE OR
ELECTRICAL SHOCK
HAZARD, DO NOT
EXPOSE THIS
PRODUCT TO RAIN
OR MOISTURE.
THE LIGHTNING
FLASH AND ARROW
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
“DANGEROUS
VOLTAGE” INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR
BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
CAUTION:
Battery
compartment
door
US NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
PAGE
charge
in use
volume
-/+ arrow
(button)
redial
(button)
channel
(button) flash
(button)
*exit
(button)
#pause
(button)
ringtone
(button)
PAG E
charge
in use
page
(button)
charge/in use
(indicator)
memory
(button)
mute
(button)
talk/end
(button)
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here. 1. Choose an area near an electrical outlet and a telephone wall jack (RJ11C), and
place your cordless telephone on a level surface, such as a desktop or
tabletop, or you may mount it on the wall.
2. Install the handset battery.
CAUTION: To reduce the risk of fire or personal injury, use only the
battery 5-2548, which is compatible with this unit.
NOTE: You must connect the handset battery before use.
NOTE: If the battery is not properly installed in the handset, or if the battery
pack is not properly connected to the jack inside the battery compartment,
the TALK indicator on the handset blinks when the handset is placed in the
base cradle.
• Plug the battery pack cord into the jack located inside the battery compartment,
then place the battery pack inside the battery compartment.
NOTE: The RBRC seal on the battery used in your
ATLINKS USA, Inc. product indicates that we are
participating in a program to collect and recycle Nickel
Cadmium batteries throughout the United States.
Please call 1-800-8-BATTERY for information or contact
your local recycling center.
Ni-Cd
RBRC
RBRC
• Clean with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a later date.
SERVICE
If trouble is experienced with this equipment, for repair or warranty information,
please contact customer service at 1-800-448-0329. If the equipment is causing
harm to the telephone network, the telephone company may request that you
disconnect the equipment until the problem is resolved.
This product may be serviced only by the manufacturer or its authorized service
agents. Changes or modifications not expressly approved by ATLINKS USA, Inc.
could void the user’s authority to operate this product. For instructions on how to
obtain service, refer to the warranty included in this guide or call customer
service at 1-800-448-0329.
Or refer inquiries to:
ATLINKS USA, Inc.
Manager, Consumer Relations
P O Box 1976
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date
this product was purchased or received as a gift. This information will be valuable
if service should be required during the warranty period.
Purchase date ________________________________________________
Name of store ________________________________________________
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or
television that is “receiving” the interference).
• Reorient or relocate and increase the separation between the
telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different
from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or
an experienced radio/television technician for additional suggestions. Also, the
Federal Communications Commission has prepared a helpful booklet, “How To
Identify and Resolve Radio/TV Interference Problems.” This booklet is available
from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify
stock number 004-000-00345-4 when ordering copies.
LIMITED WARRANTY
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
• One year, from date of purchase.
(The warranty period for rental units begins with the first rental or 45 days
from date of shipment to the rental firm, whichever comes first.)
What we will do:
• Provide you with a new or, at our option, a refurbished unit. The exchange unit
is under warranty for the remainder of the original product’s warranty period.
How you get service:
• Properly pack your unit. Include any cables, etc., which were originally
provided with the product. We recommend using the original carton and
packing materials.
• ”Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period, must be presented to
obtain warranty service.” For rental firms, proof of first rental is also required.
Also print your name and address and a description of the defect. Send via
standard UPS or its equivalent to:
ATLINKS USA, Inc.
c/o Thomson
11721 B Alameda Ave.
Socorro, Texas 79927
• Pay any charges billed to you by the Exchange Center for service not covered
by the warranty.
• Insure your shipment for loss or damage. ATLINKS accepts no liability in case
of damage or loss.
• A new or refurbished unit will be shipped to you freight prepaid.
What your warranty
does not
cover:
• Customer instruction. (Your Owner’s Manual provides information regarding
operating instructions and user controls. Any additional information, should be
obtained from your dealer.)
• Installation and setup service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit.
It will make it easier to contact you should it ever be necessary. The return of
the card is not required for warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO
THIS PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING
ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN
INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. ATLINKS USA, INC. SHALL NOT BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OF THIS PRODUCT OR ARISING OUT OF ANY BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF
WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or
consequential damages, or limitations on how long an implied warranty lasts
so the above limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other
rights that vary from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
ACCESSORY INFORMATION
To place order, have your Visa, MasterCard, or Discover Card ready
and call toll-free 1-800-338-0376.
A shipping and handling fee will be charged upon ordering.
We are required by law to collect appropriate sales tax for each individual state,
country, and locality to which the merchandise is being sent.
Items are subject to availability.
*Prices are subject to change without notice.
DESCRIPTION MODEL NO. PRICE*
25838GE1-A 25838GE-3 25828GE6-A
Belt Clip 5-2622 (gray) 5-2621 (blue) 5-2656 (lt. gray) $4.95
Headset 5-2444 (white) 5-2425 (black 5-2425 (black $36.35
Replacement Battery 5-2458 5-2458 5-2458 $14.95
Power converter 5-2629 (gray) 5-2501 (black) 5-2501 (black) $15.50

Navigation menu
