Thousandshores Technology ICBTS30 Portable Wireless Speaker User Manual
Shenzhen Thousandshores Technology Co., Ltd. Portable Wireless Speaker
User Manual
Wireless Audio to Amplify Your Life!
USER MANUAL
Safety Precautions
Avoid dropping the speaker on the floor.
Do not try to disassemble or repair the speaker
unless you are a technician.
Do not submerge the speaker in water.
Never expose the speaker to extreme high or low
temperatures.
Stop use immediately if thunderstorm happens.
Do not clean its surface with any corrosive cleanser
or other chemical solutions.
Bluetooth version: V4.2
Bluetooth profile: A2DP, AVRCP, HFP, HSP
Driver: 2 x Φ45mm, 2 x Passive radiator
Output power: 2 x 12W
Signal-to-noise ratio ≥ 80dB
Frequency response: 70-20KHz
Battery: 3.7V/5200mAh
Music play time: Up to 20 hours (varies by volume
level and music files)
Charging time: 4 hours @ 5V/2A
Dimensions (H x W x D): 68 x 180 x 68 mm /2.68 x
7.09 x 2.68 in
Weight: 545g /19.2oz
What's in the Box
Specifications Overview Buttons & Indicators
Power Button & Indicator
Volume + Button
MFB Button
Volume - Button
Battery level Indicator
Bluetooth Button
XBASS Button & Indicator
AUX-IN Port
Charging Port
Bluetooth ON
1
Tribit XBOOM
3
AUX-IN
Charging
Connections
Bluetooth Pairing
2
Micro USB Cable
User Manual
Wireless Daisy Chain with Two XBooms
Step 1：Connect the Speaker A and B
Speaker A Speaker B
>5s
Keep Speaker A and B power on
Press the Bluetooth button on Speaker A at least 5s till the
tone comes up
Wait for the Speaker A and B connecting success with tone
Step2: Pair/Connect the Speaker A
Speaker A
Tribit XBOOM
Note: Same as normal Bluetooth pairing
Step3: Enjoy music with two XBooms
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
FCC Statement
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
This device complies with part 15 of the FCC rules. Operation
is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received,
including interference that may cause undesired operation.
(1)
(2)
If this speaker has any problem, you can try to press and
hold Volume + and Volume - buttons simultaneously for
5s to reset this speaker and remove the old pairing in
your Bluetooth device, and then pair again.
Reset
18-month limited warranty
For FAQS and more information, please visit:
Email: support@tribitaudio.com
www.tribitaudio.com
Customer Service
OperationFunction Button
Press the button to manually
enter pairing mode
Pair a Bluetooth
Device
Bluetooth
Button
Press the button to increase
the volume level
Volume Up Volume +
Press the button to decrease
the volume level
Volume Down Volume -
Press once the button Play/pause MFB
Double press the buttonNext track MFB
Press the button for 3 timesPrevious track MFB
Press once the buttonanswer/end the
incoming call
MFB
Press and hold the button for
2s
Reject an
incoming call
MFB
Press and hold the button for
2s to activate (your device must
support this function)
Voice dial
function
MFB
Press the button to switch
Bass and normal mode
XBASS XBASS
Buttons
OperationFunction Button
Press the button to turn
on/off the speaker
Power ON/OFF Power Button
try to correct the interference by one or more of the following
measures:
Indicators
Indicator Status
Power
indicator
Blue indicator flashes slowly Reconnection mode
Blue indicator flashes quickly Bluetooth pairing mode
Blue indicator keeps sturdily on Connected
XBASS
indicator
White indicator lights up Bass mode is activated
Battery
indicator
Four white indicators light up Remaining battery
power: 71% ~ 100%
Three white indicators light up Remaining battery
power: 51% ~ 70%
Two white indicators light up Remaining battery
power: 26% ~ 50%
One white indicator lights up Remaining battery
power: 10% ~ 25%
A red indicator lights up Low battery power
(<10%), Please recharge
the speaker.
Tribit XBOOM
WIRELESS SPEAKER XBOOM
Wireless Audio to Amplify Your Life!
USER MANUAL
IC-BTS30
Portable Wireless Speaker
