Package Contents
1. Headset Jack
2. Key connector
3. Fan connector
4. 12V DC Jack
5. LCM Convert connector
6. Battery connector
7. General purpose header
8. Touch Panel connector
9. USB 2.0 Type A connector 2
10. USB 2.0 Type A connector 1
11. TF Card
12. MIPI camera connector 0
13. Mini-PCIE connector
14. HDMI OUT connector
15. MIPI camera connector 1
16. HDMI IN connector
17. HDMI IN FPC connector
18. Micro USB3.0 connector
19. USB Type C connector(O)
20. VOL down or Reset button
21. Power button
22. A+G+M IMU
23. WLAN ext. ant. Connector
24. BLSP5 connector
25. BLSP1 connector
26. BLSP6 connector
27. Switch (5V/3.3V change)
28. UART11 connector
29. UART9 connector
30. Micro USB2.0 connector
31. Antenna 0 on board
32. Switch for Power on mode
33. Sensor Core I2C connector
34. MAG Sensor
35. Gesture Sensor
36. Proximity Sensor
37. Analog MICs
38. 720P LCD connector
39. DMICs connector
40. Speakers connector
SOM Board with APQ8096 processor
Carrier Board
AC Power Adaptor
IMX214 camera module(additional accessory)
6
9
10
11 13 14 16
24
25
26
28
29
30
8
12
3137 36 3539 34 3338
23
27
32
5
7
1
3
4
6
9
10
11 13 14 16 18 19
24
25
26
28
29
30
21
20
8
12 15
3137
40 36 3539 34 3338
22
23
27
32
5
2
17
7
Quick Start Guide
Thundersoft TurboX® S820 EVB Setup
Remove Thundersoft TurboX® S820 EVB board carefully from the anti-static bag
Connect SOM board, Carrier board and IMX214 Camera to the corresponding connector
as show below.
Connect Thundersoft TurboX® S820 EVB to a display through HDMI cable.
Connect Thundersoft TurboX® S820 EVB and PC through the USB cable.
Connect the Power Adapter to the Thundersoft TurboX® S820 EVB.
USB connector (18) as the debug interface, when need debugging.
Press power button (21) for 2 seconds the board will boot automatically.
Notes:
All FPC with ‘TEXT’ mark.
‘MB’ connecting to the SOM Board.
‘IO’ connecting to the Carrier Board.
Keep the ‘TEXT’ side up.
SoM
IMX214
Camera
Power
Adapter
HDMI-OUT USB 3.0
Quick Start Guide
Thundersoft TurboX® S820 EVB Support
Download documentation and software
To access the documentation (schematics, user guides, datasheets, programming guides, tech
notes), platform BSP software and more, please registry on www.thundercomm.com.
Should you require more information or assistance, you can contact us at:
https://www.thundercomm.com/contact-support
Thundercomm also provides technical information on Snapdragon processors at:
https://www.thundercomm.com/resources
Should you require additional technical support for your Thundersoft TurboX® S820 EVB you can easily purchase a block
of technical support hours from the thundercomm store:
http://store.thundercomm.com/collections/technical-support-packages
Thank you for purchasing the Thundersoft TurboX® S820 EVB. Any questions, you can send email to contact us.
Email: service@thundercomm.com
The Thundercomm Support Team
