Timecode Systems TCB11 TSC11 Modular RF Board User Manual Statements that apply to every device

Timecode Systems Limited TSC11 Modular RF Board Statements that apply to every device

Contents

User Instructions

INDUSTRY CANADA STATEMENTS
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
This radio transmitter 10427A-TCB11 and AYV-TCB11(TCS11) has been approved by
Industry Canada & FCC to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for each antenna type
indicated. Antenna types not included in this list, having a gain greater than the
maximum gain indicated for that type, are strictly prohibited for use with this device.
Name / Model
Gain
Impedance
Taoglas/TG.09.0113
2.0dBi
50 ohm
FCC Warning Statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that
may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment
OEM Responsibilities
The TCS11 Module has been certified for integration into products only by OEM integrators
under the following conditions:
1. The antenna(s) must be installed such that a minimum separation distance of
20cm is maintained between the radiator (antenna) and all persons at all times.
2. The transmitter module must not be co-located or operating in conjunction with
any other antenna or transmitter.
As long as the two conditions above are met, further transmitter testing will not be
required. However, the OEM integrator is still responsible for testing their end-product for
any additional compliance requirements required with this module installed (for example,
digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for certain
configurations or co-location with another transmitter), then Industry Canada and
FCC certification is no longer considered valid and the IC & FCC Certification
Numbers cannot be used on the final product. In these circumstances, the OEM
integrator will be responsible for re-evaluating the end product (including the
transmitter) and obtaining a separate Industry Canada authorization.
End Product Labeling
The TCS11 Module is labeled with its own IC and FCC Certification Numbers. If the Certification
Numbers are not visible when the module is installed inside another device, then the outside of
the device into which the module is installed must also display a label referring to the enclosed
module. In that case, the final end product must be labeled in a visible area with the following:
“Contains Transmitter Module IC:10427A-TCB11
Contains Transmitter Module FCC ID:AYV-TCB11
or
“Contains IC: 10427A-TCB11
“Contains FCC ID: AYV-TCB11
The OEM of the TCS11 Module must only use the approved antenna(s) listed above, which
have been certified with this module.
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remove this RF module or change RF related parameters in the user’s
manual of the end product.
The user’s manual for the end product must include the following information in a
prominent location:
“To comply with Industry Canada and FCC RF radiation exposure limits for general
population, the antenna(s) used for this transmitter must be installed such that a minimum
separation distance of 20cm is maintained between the radiator (antenna) and all
persons at all times and must not be co-located or operating in conjunction with any
other antenna or transmitter.”
