Timex Group USA TMXM328A M328A User Manual iQ Move USER GUIDE 328 095001 03 EN
Timex Group USA, Inc. M328A iQ Move USER GUIDE 328 095001 03 EN
User Manual
IQ+ Move
328095001-04 7.27.17
Register your product at www.timex.com
Enregistrez votre produit sur www.timex.com
Registre su producto en www.timex.com
Registre o seu produto no site www.timex.com
Registrare il prodotto all’indirizzo www.timex.com
Registrieren Sie Ihr Produkt bei www.timex.com
Registreer uw product bij www.timex.com
请在www.timex.com上注册您的产品
www.timex.com にて製品をご登録ください
Зарегистрируйте свое изделие на сайте www.timex.com
USER GUIDE…..……..……..……..… 1
MODE D’EMPLOI …..……..……..… 3
GUÍA DEL USUARIO ..……..……..… 5
GUIA DO USUÁRIO ..……..……..… 7
GUIDA DELL’UTENTE.……..……..… 9
BENUTZERHANDBUCH …..……..… 11
GEBRUIKERSHANDLEIDING …..… 13
用户指南 ..……..……..……..……..… 15
ユ ー ザ ガ イド …..……..……..……..… 17
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ ..… 19
1
ENGLISH 328-095001-03
Register your product at www.timex.com
10-01-16
TIMEX® iQ+™ MOVE FEATURES
Your Timex® IQ+™ Move timepiece is the best of both worlds. It gives
you the beauty of a classic analog watch, and the ability to track multiple
metrics vital to your fitness and health, including steps, distance, calories
and sleep.
• Classic Analog Design
• Bluetooth® Low Energy (BLE) connection with smartphone app
(iOS and Android OS)
• Activity tracking can be displayed on watch dial in both steps and
distance
• Sleep tracking measures time slept as well as level of sleep displayed
on smartphone app
• Alarm and countdown timer controlled by smartphone app
• Smartphone app retains activity and sleep data and displays it by day,
week, month or year
• INDIGLO® night-light
• Estimated battery life of 1 year
MINIMUM REQUIREMENTS
This watch requires the use of a compatible iOS or Android smartphone,
and the Timex Connected smartphone app.
Go to http://www.timex.com/getstarted and download the Timex
Connected mobile app to your smartphone.
OVERVIEW
HOW TO SET UP YOUR WATCH
NOTE: Pairing your watch and smartphone is performed during the
on-boarding steps below. Do not attempt to pair devices from the
smartphone’s manual Bluetooth® settings.
1. Download the Timex Connected app to your smartphone.
2. Make sure Bluetooth® is turned ON in your smartphone settings.
3. On your watch press and release the crown into the closed (pushed in)
position.
4. On your smartphone, with your watch near your phone, follow the
instructions in the app:
a. Open the Timex Connected app on your smartphone.
b. Accept the user agreement.
c. Select the iQ+ Move watch.
For Android only: give permission and accept device location.
d. Answer user profile questions to set up activity tracking and set
goals.
e. When prompted, press and hold the crown for 5 seconds, until the
melody plays and the hands move. Bluetooth® function is now
turned on.
f. From the list, select the “iQMVxxxxxx” watch.
g. If a watch update is available, it will install automatically.
h. Follow app instructions to calibrate watch hands.
After completing these steps, your watch is synced with your phone and
set to the current phone time with its activity and sleep tracking functions
ready to use.
CHANGING THE TIME
The time displayed on your watch is updated from your smartphone upon
successful initial completion of the setup steps listed above and every
time the watch and phone app are synced.
To manually override the time on your watch, gently pull out crown to
outer position, rotate hands to set time and then push the crown to the
closed position. Following sync, time displayed on watch will return to that
of the smartphone.
WATCH CROWN POSITIONS
The watch crown has four positions.
One is the temporary push position. Push briefly to activate the
INDIGLO® night-light and show the Perfect Date® feature. Push longer
than 5 seconds to activate Bluetooth®.
The other three are closed, middle and outer. Observe how the watch
hands change as you move the crown: First extend the crown to its outer
position, and then push the crown very lightly until you feel it click into the
middle position, before pushing it to closed.
ACTIVATING THE INDIGLO® NIGHT-LIGHT
Press and hold the crown to activate the INDIGLO® night-light. The light
will stay on for 2–3 seconds after the crown is released. Pressing the
crown for longer than 5 seconds will activate sync mode and hands will
move to the 12 o’clock positions.
SYNCHRONIZING WATCH AND SMARTPHONE
Synchronization, or sync, does the following:
• Transfers the previous 7 calendar days’ worth of activity and sleep
tracking data from your watch to your phone.
• Updates the watch time to match the smartphone time.
• Sends other app settings, such as alarm, to watch.
• Sends other watch information, such as low battery, to smartphone.
• Does not delete activity data, either during or after synchronization.
• Checks for watch updates, and updates automatically.
NOTE: To prevent data loss, synchronize the watch to the
smartphone app, a minimum of every six days.
NOTE: The watch must be within 2 meters (6.5 feet) distance of your
smartphone for optimal communication.
To synchronize the watch and the smartphone:
1. Open the Timex Connected app on your smartphone.
2. On your watch, push and hold the crown for 5 seconds until a melody
sounds and the hands move to 12 o’clock position.
3. Immediately tap the sync icon on the lower right on the app.
4. Listen for the melody that indicates the watch has completed
Bluetooth® synchronization with the smartphone app.
NOTE: If the Bluetooth® connection between the smartphone app
and the watch is disrupted, re-pair the watch and smartphone as
follows:
1. Tell your smartphone to “forget” the watch:
a. In your smartphone’s settings (not the Timex app), view
Bluetooth® devices.
b. Have your smartphone un-pair (“forget” or disconnect) your
iQ+ Move watch.
c. Exit the Bluetooth® settings.
d. Open the Timex Connected app and sync watch and
smartphone.
VIEWING GOALS
Use the smartphone app to choose goals for steps or distance to be
displayed on your watch sub-dial. To view other goals on your watch’s
sub-dial, gently pull crown out to middle position.
SHOWING SECONDS, DATE, DISTANCE, STEPS
By default, the second hand shows seconds as on any analog watch.
When the second hand is set to show seconds, pressing the crown
temporarily causes the second hand to point to the current day of the
month; for example, at 23 seconds past the minute, pressing the crown
would cause the second hand to point to 10 on the tenth day of the
month.
You can set the second hand to show, instead of seconds, the number of
steps, distance, or day of the month. These settings are in the
smartphone app.
ALARM
Set and turn on daily alarm on smartphone app. Sync to send alarm
setting to watch. When alarm sounds, night-light flashes on watch. Press
crown to silence, if crown is not pressed, alarm will sound for 20 seconds.
2
ENGLISH 328-095001-03
Register your product at www.timex.com
10-01-16
COUNTDOWN TIMER
Set and start Countdown Timer on smartphone app. Sync to send to
watch. Watch beeps and night-light flashes when countdown ends. Press
crown to silence, if crown is not pressed, alert will sound for 20 seconds.
ADJUSTING STRIDE LENGTH
The Timex IQ+ Move uses an algorithm for distance measurement which
automatically determines your stride based on your height and speed. If
you find the distance reported does not match your actual walking or
running distance, you can calibrate the distance by up to +/- 25% via the
smartphone app. You can do this through the distance-adjustment option
on the watch section of the app.
LOW BATTERY POWER
The watch indicates when you need to replace the battery:
• During synchronization of the watch with the smartphone, the app will
alert you if the battery needs to be replaced soon.
• The watch second hand will begin to move every 2 seconds in
2-second increments until the battery is replaced.
When battery power is low:
• To conserve power, the INDIGLO® night-light will not function until the
battery has been replaced.
• The watch and smartphone will not communicate.
The activity tracking functions will remain functional until the battery has
been completely depleted, but new data will not be stored.
REPLACING THE BATTERY
Before replacing the battery, it is recommended that you synchronize to
the smartphone app to ensure you have retrieved all of the latest activity
and sleep data from the watch. After the battery is replaced, the watch
will need to be re-calibrated with the smartphone.
STORING THE WATCH
You may remove power from the watch for storage. To do this, pull the
crown out to the outer position. With the crown in this position, the hour,
minute and second hands will stop immediately, and the activity- and
sleep-tracking functions will be inactive after 30 minutes.
SMARTPHONE APP UPDATES
As smartphone app updates become available, you will be notified on
your smartphone, in the same way you learn of updates to other
smartphone apps. Update this app using the same process you would to
update any other app. Specific process varies by smartphone.
WATCH UPDATES
As watch updates become available, you will be notified in the Timex
Connected smartphone app. Follow the instructions in the app.
NOTE: Because the update will delete all activity recorded for the
current day, performing the update early in the day will minimize the
loss of recorded activity.
To ensure an uninterrupted connection during the update, place the
watch and smartphone on a flat surface, beside each other, and avoid
moving them until the update completes. During the update, the lower
subdial hand shows progress, from 0 to 100%.
The duration of the update varies, averaging 5 to 10 minutes, but
sometimes lasting up to 30 minutes.
WATER RESISTANCE
WARNING: TO MAINTAIN WATER RESISTANCE, DO NOT
PRESS ANY BUTTONS UNDER WATER.
NOTE: To confirm that your watch is water resistant, check for the
symbol before immersing in water.
Your iQ+ Move watch is water resistant to a depth of 50 meters (164 ft.).
• The watch is water resistant only as long as lens, push buttons and
case remain intact.
• The watch is not a diver watch and should not be used for diving.
• Rinse the watch with fresh water after exposure to salt water.
Water Resistance Depth
p.s.i.a.* Water Pressure Below Surface
30m/98ft
60
50m/164ft
86
100m/328ft
160
200m/656ft
284
* pounds per square inch absolute
TIMEX INTERNATIONAL WARRANTY
http://www.timex.com/productWarranty.html
FCC NOTICE (U.S.) / IC NOTICE (CANADA):
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired
operation.
This device complies with Industry Canada license exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada
applicables aux appareils radio exempts de licence. L’exploitation est
autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada.
Caution–Any user changes/modifications to this device could void the
user’s authority to operate this device.
DECLARATION OF CONFORMITY
Manufacturer’s Name: Timex Group USA, Inc.
Manufacturer’s Address: 555 Christian Road
Middlebury, CT 06762
United States of America
declares that the product:
Product Name: Timex® IQ+™ MOVE
Model Numbers: M328
is in conformity with the relevant EU harmonized legislations.
This declaration is issued under the sole responsibility of the
manufacturer and conforms to the following:
R&TTE: 1999/05/EC – RED Directive 2014/53/EU
Standards:
CENELEC EN 61000-4-2: 2009
CENELEC EN 61000-4-3: 2006+A2:2010
CENELEC EN 55022: 2010
ETSI EN 300 440-1: V1.6.1 (2010-08)
ETSI EN 300 440-2: V1.4.1 (2010-08)
ETSI EN 301 489-1: V1.9.2
ETSI EN 301 489-17: V2.2.1
LVD: 2006/95/EC – 2014/35/EU
Standards:
IEC 60950-1: 2005+A1:A2
CSA C22.2 #60950-1: 2007+A1:A2
CENELEC EN 60950-1: 2006+A11:
Electromagnetic Compatibility (EMC) – Radio Frequency (RF)
Standards:
FCC 47CFR 15, Subpart C
IC RSS 102; Issue 4
IC RSS 210; Issue 8
IC RSS GEN Issue 4
AS/NZS 4268: 2012
Agent:
Sam Everett
Quality Regulatory Engineer
Date: 1 May 2016, Middlebury, Connecticut, U.S.A.
