ENGLISH 372-095000 7.6.15
Register your product at www.timex.com
METROPOLITAN+
USER GUIDE
2
ENGLISH 052-095000
Register your product at www.timex.com
REVISED 4.24.15
EXTENDED WARRANTY
Available in U.S. only. Extend your warranty for an additional 4 years
from date of purchase for $5. You can pay with AMEX, Discover, Visa or
MasterCard by calling 1 800-448-4639 during normal business hours.
Payment must be made within 30 days of purchase. Name, address,
telephone number, purchase date, and 5-digit model number required. You
can also mail a check for $5 to: Timex Extended Warranty, P.O. Box 1676,
Dept. EF, Little Rock, AR 72203.
Please read instructions carefully to understand how to operate your Timex®
watch. Your model may not have all of the features described in this
booklet.
METROPOLITAN+
Your Metropolitan+ timepiece is the best of both worlds. The beauty of a
classic analog watch with the ability to track your daily activity in both steps
and distance!
FEATURES
• Classic Analog design
• BLE connection with Smartphone application (iOS and Android formats)
• Activity tracking displayed on watch dial in both steps and distance.
• Percent to goal achievement displays on the watch dial in both steps and
distance
• Smartphone application displays actual count and percent to set goal
achieved for Steps, Distance and Calories
• Smartphone application retains activity data and displays activity by day,
week, month or year.
• INDIGLO® night-light
• Estimated battery life of 1.5 years
SMARTPHONE APPLICATION AND
MINIMUM REQUIREMENTS
This watch requires the use of the Smartphone application which is
available in both iOS and Android formats.
iTunes iOS:
https://itunes.apple.com/us/app/timex-connected/id919212774?mt=8
Android Store:
https://play.google.com/store/apps/details?id=com.timex.
TimexConnected&hl=en
These links embedded in the timex.com/classic-50.com page.
Please download the application for use prior to starting the watch.
CURRENT LIST OF RECOMMENDED PHONES:
iPhone:
iPhone 5 and up running iOS 8.1.2 and up.
Android:
Note 3, Note 4, Samsung S4, Samsung S5, Nexus 5, Nexus 6, HTC One M8
and Moto X
HOW TO START YOUR WATCH
To start your watch remove the plastic guard from under the crown, set
the time, and then press the crown in to the closed position. You will need
to synchronize the watch with the Smartphone application to activate the
activity tracking function. Press button A and the upper sub-dial hand will
move to the Bluetooth symbol. Perform the synchronization of the watch and
Smartphone application. Once the watch has been synchronized with the
Smartphone, the activity tracking function is ready for use.
TIME SETTING
NOTE: The watch crown has four positions: one temporary push position
used to activate the INDIGLO® night-light, and three indexing positions:
closed, middle and outer. To familiarize yourself with the difference between
the various positions extend the crown to its outer position and then push
the crown very lightly until you feel it click into the middle position. To set the
time: Pull the crown to its outer position and turn it until the correct time is
shown. Once the dial reflects the correct time, return the crown to the closed
position.
INDIGLO® NIGHT-LIGHT:
Press the crown to activate the INDIGLO® night-light. The light will remain on
for 2-3 seconds after releasing the crown.
4TH CENTER HAND ADJUSTMENT:
To readjust a misaligned 4th center hand:
1. Pull the crown out to the outer position. The upper and lower hands will
move in a counter clock-wise direction and automatically calibrate. The
4th center hand will make up to one revolution and stop at 12 o’clock.
2. If the 4th center hand does not point to 12 o’clock then, press button A
to move the hand in a clockwise direction until it points to 12 o’clock.
Pressing and holding button A will make the hand move at a fast rate.
3. Push crown in to the closed position when finished.
MODE SELECTION
Press button A to advance the upper hand to the desired function. NOTE:
The mode cannot be advanced unless the crown is in the closed position.
Steps / Distance: You may switch between the Steps and Distance modes
by pressing button A.
If the upper sub-dial hand is on “S” the lower sub-dial hand will reflect the
percentage of your daily Steps goal currently achieved and the 4th center
hand will reflect the actual number of steps (in thousands) you have taken
today, when compared against the scale along the outer edge of the dial.
If the upper sub-dial hand is on “D” the lower sub-dial hand will reflect
the percentage of your daily Distance goal currently achieved and the
4th center hand will reflect the actual distance (in Miles or Kilometers as
selected on the Smartphone application) you have achieved, based on
your activity today, when compared against the scale along the outer
edge of the dial.
Bluetooth mode: No pairing is required, but you must prepare the watch for
the sync process.
To enter the Bluetooth mode push and hold button A until the upper hand
points to Bluetooth symbol on the upper dial. The watch is now ready for
Bluetooth synchronization with the Smartphone application. During the
synchronization the lower sub-dial hand and center hand will move to
zero, but the activity tracking is still active (assuming it was not “off” prior
to entering the Bluetooth mode). After completing the sync process on
the Smartphone application, both of the sub-dial hands return to their
positions previous to entering the Bluetooth mode.
OFF mode: If desired you may turn off the activity tracking function. The bat-
tery life is extended, due to less energy demand, when the activity tracking
function is suspended. Please note: the memory holds the activity tracking
data for the last 7 calendar days. When you turn off the activity tracking
mode it is advised that you synchronize the watch and the Smartphone
application to prevent any loss of activity tracking data.
To enter the OFF mode push and hold button A until the upper hand
points to OFF on the upper dial. This mode will suspend the activity
tracking feature until you wish to re-activate this feature. To re-activate
the activity tracking feature, push and hold button A until the upper hand
points to “S” on the upper dial. You are now in the Steps mode with the
activity tracking function active again.
SYNCHRONIZATION OF THE WATCH AND
THE SMARTPHONE APPLICATION
Your watch memory holds the activity tracking data for the last 7 calendar
days. You should plan to synchronize the watch to the Smartphone applica-
tion at a minimum every 7th day to prevent the loss of any data. No tracking
data will be deleted during, or after synchronization with the Smartphone
application.
NOTE: The watch must be within 2 meters distance of your Smartphone
for optimum communication
To start the synchronization, prepare the watch by placing it in Bluetooth
mode. The lower sub-dial hand and center hand will move to zero.
Start the application on your Smartphone and follow the instructions for
synchronization with the mobile phone. You must start the synchronization
process from the Smartphone within 10 seconds, or the Bluetooth on
the watch is switched off and you will need to place the watch back into
Bluetooth mode.
After the synchronization process has completed, the Bluetooth on the
watch is switched off. Both of the sub-dial hands will return to their
positions previous to entering the Bluetooth mode. The Smartphone
application will indicate the success or failure of the synchronization
process.
LOW BATTERY INDICATOR
The watch is equipped with a low voltage detection to indicate when it is
time to replace the battery. During the synchronization of the watch with
the Smartphone, the application will alert the user the battery needs to be
3
ENGLISH 052-095000
Register your product at www.timex.com
REVISED 4.24.15
replaced soon. The watch will also indicate the low battery by the movement
of the second hand. The second hand will move once every 2 seconds in 2
second increments until the battery is replaced. To further save the battery
power until it is replaced the INDIGLO® night-light will not function until the
battery has been replaced. The activity tracking function will remain active
until the battery has been completely depleted, but new data will not be
stored.
BATTERY REPLACEMENT
Before replacing the battery, it is recommended that you synchronize to
the phone to make sure you have retrieved all of the latest activity data
from the watch. After the battery has been replaced, the watch will automat-
ically calibrate the sub-dial hands. Upon completion of the auto-calibration
process, the upper sub-dial hand will point to “OFF” and the lower sub-dial
hand will be positioned at ZERO. The activity tracking function will be off.
You will need to adjust the center hand and synchronize the watch with the
Smartphone application. Press button A and the upper sub-dial hand will
move to the Bluetooth symbol. Perform the synchronization of the watch and
Smartphone application. Once the watch has been synchronized with the
Smartphone, the activity tracking function can be activated.
STORING THE WATCH
The power may be removed from the watch for storage. Pull the crown out
to the outer position. The hour, minute and second hands will immediately
cease to operate and the activity tracking function will be completely inactive
after 30 minutes with the crown in this position.
FIRMWARE UPDATE
As updates for the Smartphone application are published you will receive
notification through your Smartphone application. While the synchronization
is occurring with the update the lower sub-dial hand will indicate the
progress of the download, moving from 0 to 100%.
STRIDE LENGTH ADJUSTMENT
The Metropolitan+ uses an algorithm for distance measurement which
automatically determines your stride, based on your height and speed. If
you find that the distance reported does not match your actual walking or
running distance you can calibrate the distance by up to +/- 25% via the
Smartphone application.This is done by the distance adjustment option on
the watch section of the application.
WATER RESISTANCEWATER RESISTANCE
WARNING: TO MAINTAIN WATER RESISTANCE, DO NOT PRESS ANY
BUTTONS UNDER WATER.
1. Watch is water-resistant only as long as lens, push buttons and case
remain intact.
2. Watch is not a diver watch and should not be used for diving.
3. Rinse watch with fresh water after exposure to salt water.
If your watch is water-resistant, meter marking or (O) is indicated.
Water-Resistance Depth p.s.i.a. * Water Pressure Below Surface
30m/98ft 60
50m/164ft 86
100m/328ft 160
200 m/656ft 284
* pounds per square inch absolute.
FCC NOTICE (U.S.) / IC NOTICE (CANADA):
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage,
et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.
Under Industry Canada regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada.
To reduce potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d’Industrie Canada, le présent émetteur
radio peut fonctionner avec une antenne d’un type et d’un gain maximal
(ou inférieur) approuvé pour l’émetteur par Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l’intention
des autres utilisateurs, il faut choisir le type d’antenne et son gain de sorte
que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l’intensité nécessaire à l’établissement d’une communication satisfaisante.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful inter-
ference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
— Consult the dealer or an experienced radio TV technician for help.
DECLARATION OF CONFORMITY
Manufacturers Name: Timex Group USA, Inc.
Manufacturers Address: 555 Christian Road
Middlebury, CT 06762
United States of America
declares that the product:
Product Name: Timex® Metropolitan+
Model Numbers: M372
conforms to the following specifications:
R&TTE: 1999/05/EC
Standards: CENELEC EN 55022
ETSI EN 301 489-1
ETSI EN 301 489-3
ETSI EN 301 489-17
ETSI EN 300 440-2
LVD: 2006/95/EC
Standards: IEC 60950-1
CENELEC EN 60950-1
Digital Device Emissions
Standards: FCC 47CFR 15C Part 15 Subpart C 15.247 (Bluetooth)
FCC 47CFR 15B clA Part 15 Subpart B Unintentional
Radiators
FCC 47CFR 15B clA Part 15 Subpart C 15.247 (Bluetooth)
IC RSS 210 Issued:2010/12/01
ICES 003
SAI AS/NZS 4268
Agent:
Sam Everett
Quality Regulatory Engineer
Date: 11 July, 2015, Middlebury, Connecticut, U.S.A.

Navigation menu
