TomTom 4PN50 GPS Navigation System User Manual TomTom GO

TomTom International BV GPS Navigation System TomTom GO

[Short-Term Confidential]4PN60_UserManual ver01

TomTom GO
User Manual
16.6
2
Contents
Addendum 3
Copyright notices 9
3
Important Safety Notices and Warnings
Global Positioning System (GPS) and Global Navigation Satellite System (GLONASS)
The Global Positioning System (GPS) and Global Navigation Satellite System (GLONASS) systems are
satellite-based systems that provide location and timing information around the globe. GPS is
operated and controlled by the Government of the United States of America, which is solely
responsible for its availability and accuracy. GLONASS is operated and controlled by the Government
of Russia, which is solely responsible for its availability and accuracy. Changes in GPS or GLONASS
availability and accuracy, or in environmental conditions, may impact the operation of this device.
TomTom disclaims any liability for the availability and accuracy of GPS or GLONASS.
Safety messages
Use with care
It is your responsibility to use best judgment, due care and attention when using this navigation
device. Don't allow interaction with this device to distract you while driving. Minimise the time
spent looking at the device screen while driving. You are responsible for observing laws that limit or
prohibit the use of mobile phones or other electronic devices, for example, the requirement to use
hands-free options for making calls when driving. Always obey applicable laws and road signs
especially those relating to your vehicle's dimensions, weight and payload type. TomTom does not
guarantee the error-free operation of this navigation device nor the accuracy of the route
suggestions provided and shall not be liable for penalties arising from your failure to comply with
applicable laws and regulations.
Notice for oversized/commercial vehicles
If a truck map is not installed on this product then this product is intended for use only on cars and
light commercial vehicles without a trailer, because the product will not provide appropriate routes
for oversized and commercial vehicles, buses, or campers and recreational vehicles. If you are
operating one of those vehicle types, please visit tomtom.com to find an appropriate product with
maps containing height and weight restrictions.
Aircraft and hospitals
Use of devices with an antenna is prohibited on most aircraft, in many hospitals and in many other
locations. This device must not be used in these environments.
Safety messages
Please read and take note of the following important safety advice:
Check your tyre pressures regularly.
Service your vehicle regularly.
Medication can affect your riding or driving ability.
Always use seat belts if available.
Don’t drink and drive.
Most accidents happen less than 5 km / 3 miles from home.
Obey the rules of the road.
Addendum
4
Always use your turn indicators.
Every 2 hours, take a break for at least 10 minutes.
Keep your seat belts on.
Keep a safe distance from the vehicle in front.
Before setting off on a motorbike, fasten your helmet correctly.
When riding a motorbike, always wear protective clothing and equipment.
When riding a motorbike, be extra vigilant and always ride defensively.
Special Note Regarding Driving in California, Minnesota and Other States
California Vehicle Code Section 26708 which applies to those driving within the State of California
restricts the mounting of a navigation device on the windshield to a seven-inch square in the lower
corner of the windshield farthest removed from the driver or in a five-inch square in the lower
corner of the windshield nearest to the driver and outside of an airbag deployment zone, if the
system is used only for door-to-door navigation while the motor vehicle is being operated. Drivers in
California should not mount the device on their side or rear windows.
Minnesota State Legislature Statutes Section 169.71, subdivision 1, section 2 restricts any person
driving within the State of Minnesota from driving with a device suspended between the driver and
the windshield.
Many other states have enacted laws which restrict the placement of any object or material on the
windshield, side or rear window that obstructs a driver's clear view of the road. It is incumbent upon
the driver to be aware of all applicable laws and to place the device in such a manner that will not
interfere with his/her driving.
TomTom Inc. bears no responsibility for and hereby disclaims all liability for any fines, penalties or
damage incurred by a driver for violations of the law. While driving in any state with windshield
mounting restrictions, TomTom recommends using the supplied Adhesive Mounting Disk or
purchasing an alternative mounting system (e.g. dashboard or air vents). See tomtom.com for more
information about these mounting options.
Rating: DC5V, 1.2A
Device and battery safety
Your device
This product uses a Lithium-Ion battery.
Do not disassemble, crush, bend, deform, puncture, or shred your device. Do not use it in a humid,
wet and/or corrosive environment. Do not put, store or leave your product in a high temperature
location, in strong direct sunlight, in or near a heat source in a microwave oven or in a pressurised
container, and do not expose it to temperatures over 122°F / 50°C.
Avoid dropping the device. If the device is dropped, especially on a hard surface and the user
suspects damage, please contact customer support.
Operating temperature
This device will remain fully operational within the temperature range 32°F / 0°C to 113°F / 45°C.
Prolonged exposure to higher or lower temperatures can cause damage to your device and is
therefore advised against.
Temperatures: Standard operation: 32°F / 0°C to 113°F / 45°C; short period storage: -4°F / -20°C
to 122°F / 50°C; long period storage: -4°F / -20°C to 95°F / 35°C.
Important: Before you switch on the device, let the device acclimatise to the standard operation
temperature range for at least 1 hour. Do not use the device outside of this temperature range.
5
Device battery
Do not modify or re-manufacture the battery. Do not attempt to insert foreign objects into the
battery, or immerse or expose to water or other liquids. Do not expose the battery to fire, explosion
or other hazard.
Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.
Only use the battery for a system for which it is specified.
Caution: Risk of explosion if battery is replaced by an incorrect type.
Do not remove or attempt to remove the non-user-replaceable battery. If you have a problem with
the battery, please contact TomTom customer support.
THE BATTERY CONTAINED IN THE PRODUCT MUST BE RECYCLED OR DISPOSED OF PROPERLY
ACCORDING TO THE LOCAL LAWS AND REGULATIONS AND ALWAYS KEPT SEPARATE FROM HOUSEHOLD
WASTE. BY DOING THIS YOU WILL HELP CONSERVE THE ENVIRONMENT. USE YOUR TOMTOM DEVICE
ONLY WITH THE SUPPLIED DC POWER LEAD (CAR CHARGER/BATTERY CABLE), AC ADAPTER (HOME
CHARGER), IN AN APPROVED CRADLE OR USING THE SUPPLIED USB CABLE TO CONNECT TO A
COMPUTER FOR BATTERY CHARGING.
If your device requires a charger, please use this device with the charger provided. For replacement
chargers, go to tomtom.com for information about approved chargers for your device.
The stated battery life is a maximum possible battery life. The maximum battery life will only be
achieved under specific atmospheric conditions. The estimated maximum battery life is based on an
average usage profile.
For tips on extending the battery life, see this FAQ: tomtom.com/batterytips.
Failure to follow these guidelines may cause the battery to leak acid, become hot, explode or ignite
and cause injury and/or damage. Do not pierce, open or disassemble the battery. If the battery
leaks and you come into contact with the leaked fluids, rinse thoroughly with water and seek
medical attention immediately. For safety reasons, and to prolong the lifetime of the battery,
remove your product from your vehicle when you are not driving and keep in a cool, dry place.
Charging will not occur at low (below 32°F / 0°C) or high (over 113°F / 45°C) temperatures.
WEEE e-waste disposal
This product is marked with the wheelie bin symbol on its body and/or packaging to show that it
shall not be treated as household waste or be disposed of as unsorted municipal waste. Please
dispose of this product by making use of local e-waste collection point or other recycling facility or
by returning it to the point of sale. More information about national recycling options can be
requested from the responsible local authority in your country.
USA Specific Absorption Rate (SAR) compliance
THIS WIRELESS DEVICE MODEL MEETS GOVERNMENT REQUIREMENTS FOR EXPOSURE TO RADIO WAVES
WHEN USED AS DIRECTED IN THIS SECTION
6
This GPS Navigation System is a radio transmitter and receiver. It is designed and manufactured not
to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government, Industry Canada of the Canadian
Government (IC).
The SAR limit recommended by the Federal Communications Commission (FCC) of the U.S.
Government, Industry Canada of the Canadian Government (IC) is 1.6W/kg averaged over 1 gram of
tissue for the body (4.0 W/kg averaged over 10 grams of tissue for the extremities - hands, wrists,
ankles and feet). Tests for SAR are conducted using standard operating positions specified by FCC/IC
with the device transmitting at its highest certified power level in all tested frequency bands.
FCC information for the user
THE DEVICE COMPLIES WITH PART 15 OF THE FCC RULES
Federal Communications Commission (FCC) Statement
This equipment radiates radio frequency energy and if not used properly - that is, in strict
accordance with the instructions in this manual - may cause interference to radio communications
and television reception.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
Important
This equipment was tested for FCC compliance under conditions that included the use of shielded
cables and connectors between it and the peripherals. It is important that you use shielded cable
and connectors to reduce the possibility of causing radio and television interference. Shielded
cables, suitable for the product range, can be obtained from an authorized dealer. If the user
modifies the equipment or its peripherals in any way, and these modifications are not approved by
TomTom, the FCC may withdraw the user’s right to operate the equipment. For customers in the
USA, the following booklet prepared by the Federal Communications Commission may be of help:
"How to Identify and Resolve Radio-TV Interference Problems". This booklet is available from the US
Government Printing Office, Washington, DC 20402. Stock No 004-000-00345-4.
FCC ID: S4L4PN50, S4L4PN60
7
IC ID: 5767A-4PN50, 5767A-4PN60
FCC RF Radiation Exposure Statement
The transmitters within this device must not be co-located or operating in conjunction with any
other antenna or transmitter.
FCC Country Code Selection
The Country Code Selection feature is disabled for products marketed in the US or Canada. Per FCC
regulations, all Wi-Fi products marketed in US must be fixed to US operation channels only.
Location of FCC ID and IC ID information on your device
The FCC ID and IC ID can be found next to the memory slot on your device.
Pacemakers
Pacemaker manufacturers recommend that a minimum of 15 cm / 6 inches be maintained between
a handheld wireless device and a pacemaker to avoid potential interference with the pacemaker.
These recommendations are consistent with independent research and recommendations by
Wireless Technology Research.
Guidelines for people with pacemakers
You should ALWAYS keep the device more than 15 cm / 6 inches from your pacemaker.
You should not carry the device in a breast pocket.
Other medical devices
Please consult your physician or the manufacturer of the medical device to determine if the
operation of your wireless product may interfere with the medical device.
Emissions information for Canada
Operation is subject to the following two conditions:
This device may not cause interference.
This device must accept any interference, including interference that may cause undesired
operation of the device.
Operation is subject to the condition that this device does not cause harmful interference.
This Class B digital apparatus complies with Canadian ICES-003. CAN ICES-3(B)/NMB-3(B)
The Country Code Selection feature is disabled for products marketed in the US or Canada.
Equipment is certified to the requirements of RSS-247 for 2.4-GHz.
IMPORTANT NOTE
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncon-
trolled environment.
This device and its antenna(s) must not be co-located or operating in conjunction with any
other antenna or transmitter.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environ-
ment. End users must follow the specific operating instructions for satisfying RF exposure
compliance. To maintain with IC RF exposure compliance requirements please follow operation
instruction as documented in this manual.
8
Responsible party in North America
TomTom, Inc., 2400 District Avenue, Burlington, MA 01803
Tel: 866 486-6866 option 1 (1-866-4-TomTom)
TomTom MyDrive app
This device is compatible with the TomTom MyDrive mobile application which may be downloaded
from tomtom.com/mydrive-app. The use of the TomTom MyDrive mobile application on your
smartphone and any integration with your product will require that your smartphone has a wireless
data service plan provided by a third party wireless service carrier. The procurement of and all
charges associated with such a connectivity plan are your responsibility. TomTom shall not be liable
for any costs or expenses associated with such network connectivity plan (such as the data charges
or possible tethering fees which may be imposed by your carrier). Any changes to the availability or
reliability of the network connection may impact the operation of certain TomTom services which
may be offered on this device.
Legal terms
For information regarding how TomTom uses your data and personal information, visit
tomtom.com/privacy. Please see tomtom.com/legal for general terms and conditions including the
limited warranty, end user licence agreements and additional copyrights applying to this product,
embedded software and services. The software included in this product contains copyrighted
software that is licensed under the GPL. A copy of that licence can be viewed in the Third Party
Licences section. You can obtain the complete corresponding source code from us for a period of
three years after our last shipment of this product. For more information, visit tomtom.com/gpl or
contact your local TomTom customer support team at tomtom.com/support. Upon request, we will
send you a CD with the corresponding source code.
Great care was taken in preparing this document. Constant product development may mean that
some information is not entirely up to date. The information in this document is subject to change
without notice. TomTom reserves the right to update, change and improve its products and
materials without obligation of notice. For updated and additional information, please visit the
TomTom website at tomtom.com.
TomTom shall not be liable for technical or editorial errors or omissions contained herein, nor for
incidental or consequential damages resulting from the performance or use of this document.
This document contains information protected by copyright. No part of this document may be
photocopied or reproduced in any form without prior written consent from TomTom N.V.
Model numbers
4PN50, 4PN60
Accessories supplied with this device
Magnetic Mount
Car charger with TMC traffic receiver if applicable to your country
USB cable
Quick Start Guide
9
© 1992 - 2017 TomTom. All rights reserved. TomTom and the "two hands" logo are trademarks or
registered trademarks of TomTom N.V. or one of its subsidiaries. Please see tomtom.com/legal for
limited warranty and end user licence agreements applying to this product.
© 1992 - 2017 TomTom. All rights reserved. This material is proprietary and the subject of copyright
protection and/or database rights protection and/or other intellectual property rights owned by
TomTom or its suppliers. The use of this material is subject to the terms of a licence agreement.
Any unauthorised copying or disclosure of this material will lead to criminal and civil liabilities.
The software included in this product contains copyrighted software that is licensed under the GPL.
A copy of that licence can be viewed in the Licence section. You can obtain the complete
corresponding source code from us for a period of three years after our last shipment of this
product. For more information, visit tomtom.com/gpl or contact your local TomTom customer
support team via tomtom.com/support. Upon request, we will send you a CD with the corresponding
source code.
Bluetooth®
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by TomTom is under license. Other trademarks and trade names are those of
their respective owners.
Wi-Fi®
Wi-Fi® is a registered trademark of Wi-Fi Alliance®. The Wi-Fi CERTIFIED™ Logo is a certification
mark of Wi-Fi Alliance®.
Apple, Mac, iPhone, Siri and the "Download on the App Store" badge
Apple, Mac, iPhone, Siri and the Apple logo are trademarks of Apple Inc., registered in the U.S. and
other countries. App Store is a service mark of Apple Inc.
Android, Google Now, Google Earth and the "Get it on Google Play" badge
Android, Google Now, Google Earth, Google Play, and the Google Play logo are trademarks of
Google Inc.
Windows®
Windows is either a registered trademark or a trademark of Microsoft Corporation in the United
States and/or other countries.
Copyright notices

Navigation menu
