Tomy TFY7648P Talk and Soothe Video Monitor User Manual Manual

TOMY International, Inc. Talk and Soothe Video Monitor Manual

Manual

Before returning this product to the store for any reason,
please contact our Customer Care at
1-800-704-8697 or www.thefirstyears.com
Often, we can provide helpful tips and instructions to resolve
your problem quickly over the phone.
Y7648
Please retain this instruction sheet for future reference as it contains important information.
Talk & Soothe™
Digital Video Monitor
Check our website: www.thefirstyears.com for the most up-to-date
instruction manual as well as tips and troubleshooting advice.
BC
2 get ready for thefirstyears.com™
Talk & Soothe™ Digital Video Monitor
SAFETY INSTRUCTIONS
This symbol is intended to warn the user of potential safety hazards.
This symbol is intended to alert the user to a potential risk of
electric shock and other electrical safety issues.
WARNING: Strangulation Hazard:
• Children have STRANGLED in cords. Keep cord out of the
reach of children (more than 3 ft (0.9m) away).
• This product is not a toy. Do not allow children to play with it.
• The product is a monitoring device designed to assist in the monitoring
of children, not as a prevention for injury to or loss of a child.
• This product is not a substitute for proper adult supervision. All children
should be supervised at all times by responsible adults.
WARNING:
• To prevent electric shock, KEEP OUT OF CHILD’S REACH. Never place
monitor cord within 3 feet (0.9m) of child or attach to a crib or playpen.
Toreducetheriskofreorelectricalshock,donotopenthisproductor
expose the product to:
• Water and Moisture: This product should not be used near water,
for example, near a bathtub or sink, in a wet basement or near a
swimming pool.
• Heat: This product should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances that produce heat.
IMPORTANT
• The user should not attempt to service this product. Read all safety and
operating instructions before operating this product.
• Retain these instructions for future reference.
• Observe all warnings.
get ready for thefirstyears.com™ 3
English
• Follow all operating instructions.
• Do not tamper with the plug under any circumstances.
• Power Source – This product should be connected only to the power
supply provided.
• Cleaning – Before cleaning, be sure to unplug. Clean only as
recommended in these instructions.
• Object and Liquid Entry – Care should be taken so that objects do not
fall and liquids are not spilled into the enclosure through the openings.
• Damage or Malfunction – Please contact our Customer Care at
800-704-8697orwww.therstyears.comif:
a. The power supply cord or plug has been damaged
b. Objects have fallen or liquid has been spilled into it
c. The product has been exposed to rain
d. The product does not appear to operate normally or exhibits a
marked change in its performance
e. The product has been dropped or the enclosure damaged.
Wall Mounting – The Child Unit should be mounted to a wall only as
recommended in these instructions.
WARNING:
Do not mount the Child Unit in a location where the unit or the adapter cord
is within the child’s reach. Never place monitor or cord within 3 feet (0.9m)
of child or attach to a crib or playpen.
To prevent injury, this apparatus must be securely attached to the wall in
accordance with the installation instructions.
4 get ready for thefirstyears.com™
Talk & Soothe™ Digital Video Monitor
Talkback
On/O Button
Parts Diagram
Parent Unit
Child Unit
Lullabies
Nightlight
Battery Level
Zoom (2x)
Menu/Select
Zoom (-2)
Signal
Sound Level Display
Volume
Volume
Volume Display
On/O & Pager
Button
Nightlight
Button
Sound Activation
get ready for thefirstyears.com™ 5
English
Lullabies
Nightlight
Battery Level
Zoom (2x)
Menu/Select
Zoom (-2)
Nightlight
Button
Monitor Setup
Parent Unit(s)
Battery insertion and charging:
Child Unit
WARNING:
• Children have STRANGLED in cords. Keep cord out of the
reach of children (more than 3 ft (0.9m) away).
(To prevent heat build-up, place on an open surface away from heat sources;
do not place in an enclosed space.)
Wall Mounting
Use #8 Pan head screw 3/4 in. long fastened into solid wood. Leave screw head
protruding 1/4 in.
To operate with AC adapter:
Sound Activation
Wall Mount
Cable Wrap
6 get ready for thefirstyears.com™
Talk & Soothe™ Digital Video Monitor
To Use
Child Unit
ON / OFF & Pager
Activate the Camera Unit by pressing and holding the button until it illuminates green.
To locate a lost Parent Unit, activate it’s Pager Alarm by pressing the button 3 times
in quick succession. Its alarm will sound for 60 seconds. Once found, press any button on
your Parent Unit to silence the alarm.
Nightlight
Press the button to activate the Nightlight. When active, the Nightlight brightness
level can be adjusted by pressing and holding the button. Release the button when
you have found your desired brightness level. The Nightlight can be used independently
to the camera function, when the camera unit is powered by switched o press and hold
the button.
Talkback
To talk to your baby press and hold the button.
Zoom (x2) and Pan
Use the button to zoom into your video feed image, once zoomed-in use the
keys to pan around your zoomed image.
get ready for thefirstyears.com™ 7
English
User Display
Main Menu
Enter the main menu from the video screen by pressing the button. Use the arrow keys
to highlight your desired app and press the button again to select / enter.
Exit any menu/sub-menu by highlighting the (return) icon or alternatively press and
hold the button.
Remote Nightlight
Activate Nightlight from afar. Nightlight shall
remain active until selecting the icon within
the menu.
Lullabies
To help calm and soothe baby from a distance,
select and activate one of the following 3
five-minute lullabies; 1. “Sleep-Baby-Sleep”.
2. “Brahm's Lullaby”. 3. “Rock-a-bye Baby”.
LOSS LINK
Continual Beep
Alarm
LOW BATTERY
3x Beep per
Minute Alarm
PAGER
Continual Beep
Alarm
TALKBACK
Remote Lullabies
Remote Nightlight
LCD Screen
Brightness
Return
Sound Activation
Camera Select
Multi-Camera
Monitoring Only
Camera Management
Multi-Camera
Monitoring Only
2 3
OFF
1
8 get ready for thefirstyears.com™
Talk & Soothe™ Digital Video Monitor
Sound Activation
For those quiet moments or when your baby
is a little older you may not want to hear and
see every sound and movement. Your baby
monitor has a Sound Activated Monitoring
mode, a feature that only captures sounds and
movements above a pre-set threshold.
Monitoring will start 15 seconds after your baby
settles. When activated, all sounds will be muted
and the Video screen will turn black. Thereafter
every time your baby’s sounds rise above the
threshold, this feature will be activated instantly
and normal sound and video monitoring will
continue until your baby settles again.
Brightness
Adjust the brightness of your LCD screen by
using the arrow keys. Press the button
to select, confirm and return to live video feed.
Multi-Camera Monitoring
For extra reassurance you can add, monitor and
view up to four camera units from your one parent
unit. With multi-cameras, monitoring can be
set to automatically scroll from camera-to camera
or manual as you so choose. With add/remove
camera you can add up to a total of four
cameras or remove all but one camera.
Additional camera units can be purchased from
www.thefirstyears.com.
get ready for thefirstyears.com™ 9
English
WARNING
Keep batteries away from children. Parents are urged to exercise care in the
storage, use and disposal of all batteries. Do not dispose of batteries in a
re.Theymayexplode.
To avoid battery leakage:
• Donotuserechargeablebatteries;
• Batteriesmustberemovedandinsertedunderadultsupervision;
• Non-rechargeablebatteriesarenottoberecharged;
• Batteriesaretobeinsertedwiththecorrectpolarity;
• Exhaustedbatteriesaretoberemovedfromtheunitanddisposedproperly;
• Supplyterminalsarenottobeshort-circuited;
• Dierenttypesofbatteries(e.g.alkaline,standardcarbon-zincorrechargeable)ornew
and used batteries are not to be mixed;
• Donotdisposeofbatteriesinre,mayexplodeorleak.
•Neveruseascrewdriveroranyothertooltoprybatteriesfromthecompartment,asthe 
supply terminals could be short-circuited.
•DonotleavebatteriesintheMonitorforlongperiodsofnon-use.
IMPORTANT:
• ALWAYS DISPOSE OF USED BATTERIES IN AN ENVIRONMENTALLY FRIENDLY
MANNER.
Alkaline batteries and Nickel Metal Hydride batteries (Ni-Li or Ni-Hydride), are classified
as non-hazardous waste (except in California) and can be either disposed of in the trash or
e-recycled at a local recycling center. In order to find a center near you, go to www.ehso.
com; using the search function, type in “Batteries” and select the Battery Disposal Guide for
Households. This will provide a link to nearby centers based on zip code.
To Clean Units
Wipe exterior surfaces with a clean, dry cloth.
Maintenance
10 get ready for thefirstyears.com™
Talk & Soothe™ Digital Video Monitor
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdierentfromthattowhich
the receiver is connected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
These devices comply with FCC and Industry Canada RF radiation exposure limits
set forth for the general population. They must not be operated when co-located
with any other antenna or transmitter.
Caution: To maintain the compliance with the FCC’s and Industry Canada’s RF
exposure guideline, place the child unit at least 20 cm (8 inches) from nearby
persons.
* This device complies with RSS-210 of Industry Canada. Operation is subject to
the condition that this device does not cause harmful interference.
WARNING
ChangesormodicationstothisunitnotexpresslyapprovedbyTOMYcould
void the user’s authority to operate the equipment.
get ready for thefirstyears.com™ 11
English
Warranty
Our Limited Warranty and Warranty Period
When we use the terms “we,” “us” and “our,” we are referring to TOMY, and when we
use the terms “you” and “your” we mean the original end-user customer. Our products
are guaranteed to be free from defects in material and workmanship under normal and
intended use for a period of 90 days from the date of your purchase.
Repair/Replacement
If our product fails to meet our limited warranty during the warranty period, we will, at our
option, repair or replace the product free of charge.
What Our Limited Warranty Does Not Cover
We oer this limited warranty only when the product is used by the original end-user cus-
tomer. We oer no other warranty. Additionally, while our warranty is excellent, there are
other limits to it. We oer NO WARRANTY in cases of damage in transit, inadequate care,
abuse, abnormal use, misuse, accidents, normal wear and tear, damage due to environ-
mental or natural elements, failure to follow product instructions, immersion in water (ex-
cept for products specifically identified by us in writing as intended for water use), battery
leakage or improper storage or maintenance of the products.
Disclaimer of Other Warranties
THE EXPRESS WARRANTIES IN THE PRECEDING SECTION ARE EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES. However, to the extent applicable law does not permit disclaim-
ers of certain implied warranties, such warranties are limited to the warranty period identi-
fied above. Some states and countries do not allow limitations on how long an implied
warranty lasts, so the above limitations may not apply to you.
Limitation on Damages
IN NO EVENT SHALL WE BE LIABLE FOR INCIDENTAL, COMPENSATORY, PUNITIVE,
CONSEQUENTIAL, INDIRECT, SPECIAL OR OTHER DAMAGES. OUR AGGREGATE LIABILITY
WITH RESPECT TO DEFECTIVE PRODUCTS IS LIMITED TO THE MONIES PAID TO US FOR
THE DEFECTIVE GOOD. Some states and countries do not allow the exclusion or limitation
of incidental, consequential or other damages, so the above limitation or exclusion may not
apply to you.
State Variations
This warranty gives you specific legal rights, and you may also have other rights which vary
based on state, province or country.
Contact Us
If you have a warranty claim or request, any customer care questions, please contact via our
website www.thefirstyears.com or call us at 1-800-704-8697.
© TOMY
2015 Spring Road
Oak Brook, Illinois 60523 U.S.A.
All Rights Reserved.
Made in China.
Y7648 130513

Navigation menu
