TopSeed Technology TSAS-402 RF Flex Pointer - FSK User Manual AS User manual revised
TopSeed Technology Corp. RF Flex Pointer - FSK AS User manual revised
users manual
Flex Pointer-TS/AS User Manual
How to use the remote:
1. Plug the receiver unit into any USB port.
1. Your operation system will start to setup the receiver unit. There is no software to load. (Win98/Me may show some dialog boxes during setup process.
Press “Next” on all dialog boxes and then “finish”. During setup process, the O/S may ask you to put Win98 CD into the CD-ROM.)
2. After the setup process finish, the remote will work.
Notice:
1-1.Remote power on : Press and hold the “ “ key and press “ ” buttons more than 3 seconds the remote will be Power ON .
Pic.1 Pic.2
1-2. Use a paper clip to press the receiver unit red button (Stand by to learn the new ID)---Pic.2
1-3. Press any button except “ “ button to operate. (Let receiver unit learn the new ID).
2.If you remove the battery or the remote does not work, repeat the steps 1-1 to 1-3.
2
Symbo
Key definition
Black Display a black screen or return to the slide show
from a black screen
Slide
Forward
Perform the next animation or advance to the
next slide
Slide Back Perform the previous animation or return to the
previous
F5/ESC F5: Running your slide show in full screen mode
ESC:End a Slide show
Mode Key
NOTE:1. If the remote is not working or interference with another:
ID Change : Press Both “ “ and “” buttons simultaneously more than 3 seconds will change the currend ID .
2. Remote Power Off : In the remote ON mode , press and hold the “ “ key and “ ”buttons more than 3 seconds the remote will be
Power Off .
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
You are cautioned that any changes or modifications not expressly approved in this manual
could void your authorization to use the device.
CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
