TopSeed Technology TSCK-2401 REMOTE POINTER User Manual USERS MANUAL
TopSeed Technology Corp. REMOTE POINTER USERS MANUAL
USERS MANUAL
TopSeed Technology Corp.
Users Manual for
Remote Pointer-CK type(2.4GHz)
PAGE: 1/3
1. FCC GUIDELINES
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
TopSeed Technology Corp.
Users Manual for
Remote Pointer-CK type(2.4GHz)
PAGE: 2/3
2. Description:
The RF Remote Pointer is a GFSK (Gaussian Frequency Shift Key) Transmitter for the
frequency band 2.4 TO 2.483 GHz ISM band. The Remote Pointer offers a low power
consumption, multi-channel, and data rates up to 250Kbps ,full-integrated Frequency
synthesiser and a high efficiency power amplifier to drive a Patch antenna, A special circuit
design and an unique power amplifier design are used to save current consumption and to
save battery life.
This RF Remote Pointer is a best companion of Projector with Laser pointer designed, FSR
Moues Sensor , gives reliable control and accuracy. Remote Pointer RF's radio frequency
wireless technology solves all of your presentation input needs.
For the Receiver Modular use with USB 1.1 compliant can be easily actuated
Then, it will remember your Frequency ID (16 Frequencys) and Channel ID (512 Channels) .
The Radio Frequency designed in this Version of RF Remote Pointer is GFSK 2.4GHz to
2.483GHz and can be use in a range over 10 Meter from the Receiver at any directions(Free
Space). The Remote Pointer can operate for 3 months with AA X 2 DC 3V batteries
TopSeed Technology Corp.
Users Manual for
Remote Pointer-CK type(2.4GHz)
PAGE: 3/3
3. Physical Description and Specification:
3.1 Dimensions
The approximate dimensions of the Remote pointer is as follows:
Length 166.15 mm
Width 49 mm
Height 29.5 mm
3.2 Weight
Weight of the RF Remote Pointer not to exceed 75 grams (without batteries).
