PartsCatalog
FormNo.3371-846RevA
22inRecycler®LawnMower
ModelNo.20332—SerialNo.312000001andUp
Registeratwww.Toro.com.OriginalInstructions(EN)
OrderingReplacementParts
Toorderreplacementparts,pleasesupplythepartnumber,
thequantity,andthedescriptionofeachpartdesired.
UnderstandingReferenceNumbers
Eachidentiedpartinanillustrationhasareference
number.Thereferencenumberforapartalsoappearsin
thepartslist,alongwithotherinformationaboutthepart.
Thiscatalogusestwospecialreferencenumberformats,
onetoindicatepartsinaserviceassemblyandanotherto
indicatethequantityofagivenpartinanillustration.
ServiceAssemblyReferenceNumbers
Partsinserviceassemblieshavereferencenumbersinthe
forma:b.Thearepresentsthereferencenumberofthe
entireserviceassemblyandthebrepresentsasequential
numberuniquetoeachpartwithintheserviceassembly.
Forexample,awheelassemblymightbeidentiedby
referencenumber6,thetireby6:1,thevalveby6:2,and
thewheelby6:3.Whenyouordertheassemblyidentied
byreferencenumber6,youreceiveallpartsidentiedby
referencenumbers6:1,6:2,and6:3.However,youmay
alsoorderanypartindividually.Referencenumbersofthis
typeappearinillustrationandinpartslists.
ReferenceNumbersIndicatingQuantity
Inanillustration,ifareferencenumberindicatesmorethan
onepart,thereferencenumberhastheformnXy.Then
representsthequantityofthepart,theXisthemultiplication
symbol,andtheyrepresentsthereferencenumber.
Forexample,inanillustration,thereferencenumber2X37
meansthattwoofthepartsidentiedbyreferencenumber
37areindicated.
ListofAbbreviations
AR:asrequired
ASM:assembly
BBC:bladebrakecontrol
BHTF:buttonheadthreadforming
CARR:carriage
CCW:counterclockwise
CW:clockwise
DEG:degrees
DPA:DualPointAdjustment
ECM:electroniccontrolmodule
EXT:external
FH:athead
GA:gauge
HD:heavy-duty
HF:hexange
HH:hexhead
HHF:hexheadange
HHFTF:hexheadangethread
forming
HJ:hexjam
HLH:hexlaghead
HOC:height-of-cut
HSBH:hexsocketbuttonhead
HSFH:hexsocketathead
HSH:hexsockethead
HWH:hexwasherhead
HWHTF:hexwasherheadthread
forming
HYD:hydraulic
LH:lefthand
LP:LiquidPropane
NI:nyloninsert
NPTF:nationalpipethreadne
PFH:phillipsathead
PPH:phillipspanhead
PPHTF:phillipspanheadthread
forming
PRH:phillipsroundhead
PTH:phillipstrusshead
PTO:power-take-off
RH:righthand
ROPS:roll-overprotectionsystem
RRB:rearrollerbrush
SFH:slottedllisterhead
SHH:slottedhexhead
SHWH:slottedhexwasherhead
SPH:slottedpanhead
SQH:squarehead
SRH:slottedroundhead
STD:standard
TAP:selftapping
TTH:torxtrusshead
2
Contents
Deck,SideChuteandRearDoorAssembly....................................................................4
RearBagAssembly.........................................................................................5
EngineandBladeAssembly..................................................................................6
FrontWheelandHeight-of-CutAssembly......................................................................7
TransmissionandRearWheelDriveAssembly..................................................................8
HandleAssembly...........................................................................................9
AttachmentsandAccessories...............................................................................10
©2011—TheToro®Company
8111LyndaleAvenueSouth
3
Contactusatwww.Toro.com.
PrintedintheUSA.
AllRightsReserved
Deck,SideChuteandRearDoorAssembly
Ref.PartNumberQty.Description
1117-10841HousingASM
1:294-80721Decal-Danger
1:3115-46761Decal-Recycler
1:4112-88671Decal-Port,Washout
2114-7963-011Bafe-Front
5114-79611Bafe-Rear
6115-46771Chute-Recycle
746-80919Screw-HWH
8112-64161Bracket-Cover
999-84452Screw-HWH,Taptite
1099-52911Rod-Cover
1199-52931Spring-Torsion
12115-84491Deector-Side
13115-84471Chute-Discharge,Side
14114-79601Deector-Recycle
15114-79581Knob-Recycle
Ref.PartNumberQty.Description
16114-79591Latch-Recycle
17117-10311Spring-Compression
1832104-1202Screw-PPH
19121-57761RearDoorASM
19:2114-79821Decal-Warning
20115-28591Spring-Torsion
21114-79241Spring-Torsion
22112-64001Port-Washout
23112-64011Coupling-Hose,Washout
Port
25112-64381Washer-Seal,WashoutPort
263254-51Washer-Tooth,Internal
273218-61Nut-Jam
29114-79871Bumper
30105-68492Screw-ThreadForming
34117-59281Decal-BagOnDemand
3371-846A 4A2
TransmissionandRearWheelDriveAssembly
Ref.PartNumberQty.Description
1114-7955-031Plate-Rear,LH(HOC)
2114-7956-031Plate-Rear,RH(HOC)
3322-34Screw-HH
43296-294Nut-Lock,NI
5108-97792Retainer-Bushing,HOC
6104-86992Bearing-Ball
7108-97822Bushing-Sleeve
8108-97812Arm-Pivot,Rear
9108-97802Arm-Spring
10110-05492Knob-HOC
11115-46521Transmission
12115-46691Belt-V
13114-7977-031Bracket-Transmission
Ref.PartNumberQty.Description
14108-74763Screw-Plastite
15110-71912Washer-Thrust
16115-46682Gear-Pinion,12T
1732151-612Ring-Retaining
18110-17922WheelCoverASM
18:26144261Washer-Stepped
196146502Bolt-Shoulder
20115-469528InchWheelGearASM
21115-84062Anchor-Bag
22105-94372Screw-PPH
23115-28931Shield-Trailing
24117-10922Screw-PTH
3371-846A 8C3
HandleAssembly
Ref.PartNumberQty.Description
1119-3810-051Handle
23230-62Screw-CARR
3117-59762Knob-Handle,Locking
4114-79881Guide-Cable
586-96711Guide-Rope
63296-732Nut-Lock,NI
73256-11Washer-Flat
8105-68421Guide-LH
9105-68411Guide-RH
12104-86781Handle-Control
Ref.PartNumberQty.Description
13117-10191Decal
1499-15881Bar-Control,Traction
153256-231Washer-Flat
1699-15891Lever-Traction
17104-86901Spring-Torsion
18104-8679-031Bail-Brake
1995-44531Screw
2099-52391Anchor-Cable
21115-84351Cable-Traction
22115-84371Cable-Brake
D3 93371-846A
AttachmentsandAccessories
For2033222inRecyclerLawnMower
ProductNameModel/Part
TractionAssistHandleKit................................................................................................................108-8120
LoosePartsKit.................................................................................................................................117-4133
ReplacementBag.................................................................................................................................59310
ReplacementFrameandBagKit..........................................................................................................59312
22inBladeKit........................................................................................................................................59534
10
Notes:
