STX-38 EFI

Stump Grinder

HYDRAULICALLY DRIVEN HEAD

• Eliminates labor of tightening

or replacing costly poly-chain®

belts or clutches

• No need to replace expensive

cogged pulleys

• No worry of customers engaging

grinder head at full throttle

• Eliminates shock loads to the

engine from belts slipping or

head stopping

• Heavy-duty sealed, greaseable

bearing housing and cutter shaft

minimize maintenance

• Intelli-Sweep feature automatically

adjusts sweep speed based on

the load on the wheel to

maintain optimal operation

• Cutter head and guard

design allow for exceptional

below-grade grinding and

chip management

HI-DRIVE TRACK SYSTEM

• Low center of gravity and large

footprint increase stability on

side hills

• Eliminates tire ruts and flat tires

• Operates in soft, wet ground

conditions

• Track design climbs curbs and

allows for zero turn capability

USER-FRIENDLY DESIGN

• Single-cylinder sweep and lift

design delivers a straight cut

• All-hydraulic sweep control valve

facilitates side-to-side feathering

• Kohler® Command PRO®

ECV980cc engine with electronic

fuel injection (EFI) and electric

start delivers reliable power

• 34" machine width — easily fits

through 36" gates

• Frame design provides excellent

cutter wheel visibility

THE TORO® STX-38 EFI STUMP GRINDER is built for outstanding durability in the

toughest conditions. The STX-38 now features an electronic fuel injected engine and a

redesigned cutter head for the best performance and grinding ability on the market. Fully

hydraulic cutting operation means no chance of expensive belts breaking or slipping and no

tension adjustments. The Intelli-Sweep™ feature automatically slows the sweep speed of the

cutting head based on the load of the wheel, so heavy cutting loads won’t bog down the

engine. And with easy-to-use TX-style controls and tracks for maneuverability and stability, the

STX-38 EFI is extremely operator-friendly. Best of all, ground speeds of 4.5 mph allow you to

spend more time grinding — and less time transporting the machine — for greater productivity.

FEATURES

Stump Grinder

STX-38 EFI

STX-38 EFI Sell Sheet.indd 1 3/29/14 10:21 AM

MODEL 23214

Engine Kohler® Command PRO® ECV980 980cc

38 hp 4-cycle gasoline air-cooled engine

Hydraulics

Dual hydrostatic traction drive – 16 cc hydropumps with

15 gpm max flow to each side; 20 gpm gear pump flow to

the piston motor driving the cutter head

Wheel 21.6" diameter to tooth; 1" thick; 16 Greenteeth cutting teeth

Cutter Depth 18" below grade

Cutter Height 35" above grade

Head Swing 52" radius x 60˚ sweep arc

Dimensions 34" (86 cm) W x 95" (241 cm) L (transport) x 51" (130 cm) H

Weight 1750 lb (794 Kg)

Max. Travel Speed 4.5 mph

Compliance CE and EPA compliant

Products depicted in this literature are for demonstration purposes only. Actual products offered for sale may vary in

use, design, required attachments and safety features. We reserve the right to improve our products and make changes

in specifications, designs and standard equipment without notice and without incurring obligation. See your dealer for

details on all of our warranties.

STX CONTROL SYSTEM

OPERATES WITH TWO

EASY CONTROLS

Easy-to-use control system offers

smooth operation and fewer levers/

knobs than conventional stump

grinders. An armrest near the joystick

also reduces operator fatigue.

1 Steering System (forward, reverse,

turn) allows for zero turn capability

2 Sweep, lift/lower and engagement

of grinder head

490-8897

©2014 The Toro Company

All Rights Reserved.

Worldwide Headquarters

The Toro Company

8111 Lyndale Ave. So.

Bloomington, MN 55420

Phone: 1-952-888-8801

toro.com

SPECIFICATIONS

Advanced Performance

& Easy Operation

STX-38 EFI

STX-38 EFI Sell Sheet.indd 2 3/29/14 10:18 AM
