Toshiba Information Systems CL4-J01 Cellular Mobile Phone User Manual Safety Leaflet
Toshiba Information Systems (UK) Ltd, Mobile Communications Division Cellular Mobile Phone Safety Leaflet
Contents
- 1. Safety Leaflet
- 2. User Manual
Safety Leaflet
830T First Step Guide
Police .............................. 110
Fire & Ambulance............. 119
Coast Guard .................... 118
•
•
•
Support
General Notes
Before Using Handset
830T
First Step Guide
Customer Service
Customer Service
■ SoftBank Customer Centers
From a SoftBank handset,
dial toll free at
• 157 (General Information)
• 113 (Customer Assistance)
■ SoftBank Global Call Center
From outside Japan, dial
+81-3-5351-3491
(International charges will apply.)
Call this number immediately if
handset/USIM Card is lost or
stolen while outside Japan.
■ Call these numbers toll free from landlines.
Subscription
Area
Service Center Phone Number
Hokkaido, Aomori, Akita, Iwate, Yamagata,
Miyagi, Fukushima, Niigata, Tokyo, Kanagawa,
Chiba, Saitama, Ibaraki, Tochigi, Gunma,
Yamanashi, Nagano, Toyama, Ishikawa, Fukui
General Information 0088-240-157
Customer Assistance 0088-240-113
Aichi, Gifu, Mie, Shizuoka General Information 0088-241-157
Customer Assistance 0088-241-113
Osaka, Hyogo, Kyoto, Nara, Shiga, Wakayama General Information 0088-242-157
Customer Assistance 0088-242-113
Hiroshima, Okayama, Yamaguchi, Tottori,
Shimane, Tokushima, Kagawa, Ehime, Kochi,
Fukuoka, Saga, Nagasaki, Oita, Kumamoto,
Miyazaki, Kagoshima, Okinawa
General Information 0088-250-157
Customer Assistance 0088-250-113
■ Handset User Support
Via Yahoo! Keitai Main Menu: From above search field, select
メニューリスト
] English ] User Support
■ Online English Manual
http://mb.softbank.jp/mb/support/3G/product/830t/
May be unavailable at purchase. Call Customer Service or try later.
Emergency Numbers
Using Your Handset
Handset employs radio waves. Signals may be disrupted
even within service areas if you are indoors,
underground, inside a tunnel or inside a vehicle. If you
move to a location with poor signal reception, a call or
the TV image/sound may be suddenly cut off.
When using handset in public places, take care not to
annoy other people around you. Use of handset is
prohibited in some public places such as in theaters or
on buses and trains.
Handset is a radio transceiver under Japanese Radio
Law. You may be requested to submit handset for
inspection based on this law.
Use of handset near a landline phone, TV or radio may
affect the image and sound quality of the equipment.
Handset employs a digital system to maintain a high
level of communication quality even at very low signal
levels. However, calls may be suddenly cut off when the
signal strength becomes too weak.
The digital system provides a high level of privacy
protection. However, the possibility of someone
eavesdropping on your conversation cannot be ruled out
as long as radio waves are used.
•
•
•
•
•
•
Data stored on handset may be corrupted or lost on the
following occasions.
・Handset is used improperly.
・ Handset is exposed to static electricity or electric
noise.
・Handset is turned off during operation.
・The battery is completely discharged.
・Handset malfunctions or is sent for repairs.
SoftBank and Toshiba accept no liability whatsoever for
the corruption or loss of stored data. Be sure to keep a
separate memo of important data to limit damage
caused by data corruption or loss to a minimum.
Be sure to charge the battery before using handset for
the first time or if handset has not been used for a long
time. When the battery is stored for a long time, it
discharges over time even if it is not used.
Before using a memory card, read the instruction
manual of the memory card thoroughly to ensure safe
and proper operation.
When handset is used for extended periods of time,
especially in high temperature conditions, its surface
could become hot. Please use caution when touching
handset under such conditions.
•
•
•
•
When certain items are taken out of the country,
documentation may be required to certify that the
export of the items is not controlled, prohibited, or
restricted by the Export Trade Control Order and Foreign
Exchange Order. Basically, no such documentation is
required if you take handset out of the country and
bring it back for the purpose of personal use when
going on vacations or short business trips. In some
cases, however, an export permit may be required if
handset is to be used by or transferred to anyone else.
Furthermore, a US government export permit may be
required when taking handset to countries for which the
US government has imposed export restrictions (Cuba,
North Korea, Iran, Sudan, Syria).
For details on export laws, regulations and procedures,
refer to the Web page of the Security Export Control
Policy Division of the Ministry of Economy, Trade and
Industry.
If you use a hearing aid, handset usage may interfere
with hearing aid performance. If there is any
interference, consult with the manufacturer or distributor
of the hearing aid.
•
•
Inside Vehicles
Do not use handset while driving. Use of handset while
driving is prohibited by law.
Talking on handset using Stereo Earphone-Microphone
(sold separately) while driving may be subject to
penalties in some prefectures.
Before using handset, stop the vehicle in a safe area
where parking or stopping is permitted.
Aboard Aircraft
Do not use handset on an aircraft. Do not turn handset
on while you are on an aircraft.
Read “Safety Precautions” in the Japanese User Guide,
prior to handset use.
•
•
•
• Handset*1 • Battery (TSBBM1) • Battery Cover
• Start Book (Japanese) • User Guide (Japanese) • First Step Guide
• Outer Jacket*2 • Inner Sheet*2 • Jacket Cover Remover*2
Manner Mode
■ Minding Mobile Manners
Please use your handset responsibly. Inappropriate handset use can be both dangerous
and bothersome. Please take care not to disturb others when using your handset.
Adjust handset use according to your surroundings.
■ Activating/Canceling Manner Mode
Press and hold ;
USIM Card Installation
USIM Card must be inserted to use this handset. Turn
handset power off and remove the battery before
inserting/removing USIM Card.
Insert USIM (IC facing down) as pictured NotchNotch
Battery Installation
USIM PINs
■ PIN
A four- to eight-digit code to prevent unauthorized
handset use. The default setting is 9999.
■ PIN2
A four- to eight-digit code required to reset Call
Time&Cost. The default setting is 9999.
■ PIN Lock & PUK Codes
PIN Lock or PIN2 Lock is activated when PIN or PIN2 is
incorrectly entered three times. PUK (Personal
Unblocking Key) codes are required to cancel PIN Lock/
PIN2 Lock. For details, contact SoftBank General
Information.
Charging
1 Open Port Cover to connect Charger
2 Plug Charger into an AC outlet
Charging Indicator lights red while charging;
may take up to approximately ••• minutes.
3 Unplug Charger, then disconnect
handset
Press Release Buttons when disconnecting
Connector.
Security Codes
■ Handset Code
A four-digit code (9999 by default), required to use
various handset functions. Change the code from
handset as needed.
■ Center Access Code
Four-digit code assigned at initial subscription. Use the
code to access Optional Services via landlines or to
subscribe to fee-based content.
■ Call Barring Service Code
Four-digit code assigned at initial subscription; required
to set Call Barring.
If the code is incorrectly entered three times, Call
Barring settings lock. Call Barring Service Code and
Center Access Code must be changed. Contact
SoftBank General Information for details.
■ Internet Security Code
It is required to set Internet security.
Specifications
1 Press and slide battery
cover (①), then lift out (②)2 Align terminals and insert
battery
To remove: Pull tab (above ).
3 Slide battery cover shut
Notch
②
①
Notch
②
①Tab Tab
*AC Charger is sold separately.
Charging
Indicator
Connector
Release
Buttons
Plug
AC Charger*
AC Outlet
External Device
Port
Port Cover
Charging
Indicator
Connector
Release
Buttons
Plug
AC Charger*
AC Outlet
External Device
Port
Port Cover
More Information
Continuous Talk Time Approx. ••• min. (3G)
Approx. ••• min. (Video Call)
Approx. ••• min. (GSM)
Continuous Standby
Time Approx. ••• hrs (3G)
Approx. ••• hrs (GSM)
Charging Time Approx. ••• min.
Weight (with battery) Approx. ••• g
Dimensions (W×H×D)
(handset closed) Approx. • × • × • mm
Maximum Output
Class 3 0.25 W (3G)
Class 4 2 W (GSM900)
Class 1 1 W (DCS1800)
Class 1 1 W (PCS1900)
Package Contents
More Information
Emergency Numbers
Use English Interface
Global Roaming
Customize Handset Address
and more...
*1 Use SoftBank specified AC Charger (sold separately).
*2 Complimentary sample not available for purchase.
830T_FSG.indd 1830T_FSG.indd 1 08.8.25 10:37:12 AM08.8.25 10:37:12 AM
830T First Step Guide
Getting Started
Function List
Basic Operations
Handset Power On/Off
Press and hold O
Network Settings
Before using network-related services, retrieve
network information. The first time you press [,
J or K, a prompt appears.
[, J or K ] YES ] [
Interface Language
[ ]
設定
] [ ]
一般設定
] [ ]
Language ] [ ] Select a setting ] [
自動選択 Language set on USIM Card
日本語 Japanese interface
English English interface
My Phone Number
[ ] Phone Book ] [ ] My Details
] [
Date & Time
[
] Settings ]
[
] Phone Settings
]
[
] Clock ]
[
] Date&Time ]
[
] Enter date and time ]
[
Calls
Voice Call
1 Enter number with area code ] N
2 O to end call
Redialing
1 D ] Select an entry ] N
2 O to end call
Video Call
1 Enter number with area code ] H
2 O to end call
Calling Abroad from Japan
International Call Service may require prior
application. Details and applications are available
online:
http://mb.softbank.jp/mb/en/global_service/
1 Enter number with area code ] K ]
Intl. Calls ] [ ] Select a country ]
[ ] N
2 O to end call
Answering a Call
1 A call arrives ] N
2 O to end call
Answering Machine
■ Activating/Canceling
Press and hold L
■ Playing a Message
L ] Select a message ] [
Answering Machine is unavailable when handset is
off, out-of-range or Offline.
Text Entry
Switching Text Input Modes
In a text entry window, H ] Select a text
input mode ] [
Kanji (hiragana)
Single-bye katakana
Double-byte alphanumerics (upper case)
Double-byte alphanumerics (lower case)
Single-byte alphanumerics (upper case)
Single-byte alphanumerics (lower case)
Double-byte numbers
Single-byte numbers
URL Enter e-mail address and URL extensions
from the address library.
Pict Enter pictographs.
（＾−＾） Enter emoticons.
My Pict Enter pictographs in My Pictograms
folder.
Text Entry Example
Entering “dog”
When appears, 3 ] 6 (three times)
] 4
Messaging
S! Mail/SMS
■ S! Mail
Exchange text messages with e-mail compatible
handsets/devices and PCs. Send images, melodies and
other files as attachments.
■ SMS
Exchange short text messages with SoftBank handsets.
Customizing Handset Address
Change the account name (alphanumerics before @)
of your e-mail address to help reduce spam.
[ ] Messaging ] [ ] Settings ]
[ ] Mail Address ] [ ] Connect
] [ ] English ] [ ] Follow
onscreen instructions
Sending Text Messages
J ] Create New ] [ ] Address ]
[ ] Enter or select an address ] [ ]
Text ] [ ] Enter message ] [ ] J
] OK ] [
Receiving Messages
(J ] Message Box ] [)* ] Select a
folder ] [ ] Select a message ] [
* When Information Prompt appears, select New
Messages ] [
Phone Book
Phone Book Entry Items
■ Phone Number
Save up to five numbers (32 digits each) to Phone
Book; One to USIM Phone Book.
■ Email
Save up to five addresses (128 single-byte
alphanumerics each) to Phone Book; One to USIM
Phone Book.
Creating a New Entry
[ ] Phone Book ] [ ] New Entry
] [ ] Name ] [ ] Last Name ]
[ ]Enter ] [ ] First Name ] [
] Enter ] [ ] J ] Select other items
] [ ] Enter information ] [ ] J
Editing an Entry
B ] Select an entry ] [ ] Select a field
] [ ] Edit field ] [ ] J ] Save or
Save as New ] [
Dialing from Phone Book
B ] Select an entry ] [ ] Select a
phone number ] N
Voice Mail
Activating
[ ] Settings ] [ ] Call Settings
] [ ] Call Services ] [ ] VM/Call
Fwd ] [ ] Voice Mail ON ] [ ]
All Calls or No Answer ] [ ] (Select a
ring time ] [)* ] [
* Perform this step when No Answer is selected.
Playing Messages
[ ] Settings ] [ ] Call Settings
] [ ] Call Services ] [ ] VM/Call
Fwd ] [ ] Listen VM ] [ ] Follow
voice guidance*
* To switch to English voice guidance, press
212 while Japanese voice guidance is
playing.
Camera
Capturing Still Images
R ] Frame subject ] [ or R ] [
or R
Recording Videos
Press and hold R ] Frame subject ] [
or R ] [ or R to end recording ]
[ or R
Internet
Accessing Yahoo! Keitai
K ]
ﾒﾆｭｰﾘｽﾄ
] [ ] English ] [ ]
Select a menu item ] [
Accessing PC Websites
[ ] Yahoo! Keitai ] [ ] J ]
Homepage ] [ ] Always Ask or Ask
Once Only ] [
Global Roaming
Global Roaming Service may require prior application.
Details and applications are available online:
http://mb.softbank.jp/mb/en/global_service/
Making Calls While Abroad
■ Calls within Visited Country
Enter number with area code ] N
■ Calls to Japan and Other Countries
N ] Press and hold 0 ] Enter country
code, area code* and number ] N
* Omit first 0 from area code, except when calling Italy.
Managing Files
Opening a File
[ ] Data Folder ] [ ] Select a
folder ] [ ] Select a file ] [
Formatting a Memory Card
[ ] Settings ] [ ] Memory ] [
] Format Card ] [ ] Enter Handset
Code ] YES ] [
Software Update
Precaution
Before updating software, turn handset power off
then restart handset.
Updating Software
[ ] Tools ] [ ] Update ] [ ]
YES ] [ ] Agree ] [ (twice) ]
Enter Center Access Code ] [ ] J ]
Follow onscreen instructions
Multi Selector Operations
G: Press A or B.
F: Press D or C.
E: Press A, B, D or C.
Use E to move cursor. Press [ to
open Main Menu, or confirm selection
and perform selected operations.
KAccess Yahoo! Keitai. Execute
right Softkey functions.
SAccess Shortcuts Menu.
OTurn handset power on/off. End
calls/operations and return to
Standby.
Messaging
Message Box
Create New
Retrieve New
Drafts
Templates
Unsent
Server Mail
Settings
Yahoo! Keitai
Yahoo! Keitai
Bookmarks
Screen Memo
Enter URL
History
PC Browser
Settings
Entertainment
S! Quick News
Info Channel
BookSurfing
Handset Functions
e-Book Viewer
Ku-man’s Room
TV
Watch TV
Program Guide
TV Links
Timer
Timer Results
Settings
Camera
Mobile
Digital
Video
Video Mail
Short Video
Scan Data
S! Appli
Library
Settings
Card Sync
Certification
Information
Tools
Alarms
Notepad
Calculator
Dictionary
Calendar
Tasks
Useful Tools
Photo Stand
Osaifu-Keitai
S! GPS Navi
Update
Data Folder
Pictures
Ring Song•Tone
S! Appli
Music
Videos
Lifestyle-Appli
Books
Templates
Flash(R)
Main Menu
Gamendeco
Keitaideco
Mini Tool
Other Documents
Memory Status
Media Player
Audio
Videos
Streaming
Communications
S! Town
S! Loop
Friend Status
Circle Talk
Phone Book
My Details
Phone Book
New Entry
Call Log
Group
Addr. Bkup
Settings
Memory Status
Settings
Sounds
Display
Phone Settings
Security
Call Settings
Connectivity
Idle Screen
Priority
SimpleMode ON
Backup
Memory
Display Indicators & Key Assignments
Signal Strength
Packet Transmission Available
New S! Mail/SMS
Memory Card Inserted
Manner Mode Active
Battery Level
Alarm Set
New Voice Mail Message
JAccess Messaging menu. Execute
left Softkey functions.
HActivate TV. Make/answer video
calls.
LDelete characters. Return to the
previous operation.
NMake/answer calls.
1
;Enter numbers and characters.
830T_FSG.indd 2830T_FSG.indd 2 08.8.25 10:37:16 AM08.8.25 10:37:16 AM
