O

WNER'S

M

ANUAL

LCD Color Television

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

Owner's Record

The model number and serial number are on the

back of your TV. Record these numbers in the

spaces below. Refer to these numbers whenever

you communicate with your Toshiba dealer about

this TV.

Model number:

© 2006 TOSHIBA CORPORATION

All Rights Reserved

Serial number:

20DL76 20DL76

2

Dear Customer,

Thank you for purchasing this Toshiba LCD TV. This manual

will help you use many exciting features of your new LCD TV.

Before operating the TV, please read this manual

completely, and keep it nearby for future reference.

FCC Declaration of Conformity

Compliance Statement (Part 15):

The Toshiba 20DL76 LCD Color Televisions comply with

Part 15 of the FCC rules.

Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this

device must accept any interference that may cause

undesired operation.

The party responsible for compliance to these rules is:

Toshiba America Consumer Products, L.L.C.

82 Totowa Rd. Wayne, NJ 07470.

Ph: (973) 628-8000

Note: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part 15

of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

removing and applying power to the equipment, the user is

encouraged to try to correct the interference by one or more

of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and the

receiver.

- Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for

help.

CAUTION: Changes or modifications to this equipment not

expressly approved by Toshiba could void the user's authority

to operate this equipment.

Safety Precautions

WARNING: TO REDUCE THE RISK OF FIRE OR

ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

WARNING

To prevent injury, this apparatus must be securely attached to

the floor/wall in accordance with the installation instructions.

(See item 20 on page 4.)

NOTE TO CATV INSTALLERS

This is a reminder to call the CATV system installer's attention

to Article 820-40 of the NEC, which provides guidelines for

proper grounding and, in particular, specifies that the cable

ground shall be connected to the grounding system of the

building, as close to the point of cable entry as practical. For

additional antenna grounding information, see items 26 and

27 on page 4.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING

WARNING: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning symbol in the triangle tells you that

the voltage inside this product may be strong

enough to cause an electric shock. DO NOT TRY

TO SERVICE THIS PRODUCT YOURSELF.

The exclamation mark in the triangle tells you

that important operating and maintenance

instructions follow this symbol.

3

Child Safety

It Makes A Difference

Where

Your TV Stands

Congratulations on your purchase! As you enjoy your

new TV, keep these safety tips in mind:

The Issue

o If you are like most consumers, you have a TV in your

home. Many homes, in fact, have more than one TV.

o The home theater entertainment experience is a growing

trend, and larger TVs are popular purchases; however,

they are not always supported on the proper TV stands.

o Sometimes TVs are improperly secured or inappropriately

situated on dressers, bookcases, shelves, desks, audio

speakers, chests, or carts. As a result, TVs may fall over,

causing unnecessary injury.

Important Safety Instructions

1) Read these

instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in

accordance with the manufacturer's instructions.

8Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus

(including amplifiers) that produce heat.

9) Do not defeat the safety purpose

of the polarized or grounding

type plug. A polarized plug has two

blades with one wider than the

other. A grounding type plug has

two blades and a third grounding

prong. The wide blade or the third prong are provided

for your safety. If the provided plug does not fit into your

outlet, consult an electrician for replacement of the

obsolete outlet.

10) Protect the power cord from being

walked on or pinched, particularly at

plugs, convenience receptacles, and

the point where they exit from the

apparatus.

11) Only use attachments/accessories

specified by the manufacturer.

12) Use only with the cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the

apparatus. When a cart is used, use

caution when moving the cart/

apparatus combination to avoid injury

from tip-over.

13) Unplug this apparatus during

lightning storms or when

unused for long periods of

time.

14) Refer all servicing to qualified

service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug

is damaged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally,

or has been dropped.

15) The apparatus shall not be exposed to dripping or

splashing and that no objects filled with liquids, such as

vases, shall be placed on the apparatus.

16) CAUTION: To reduce the risk of electric shock, do not

use the polarized plug with an extension cord,

receptacle, or other outlet unless the blades can be

inserted completely to prevent blade exposure.

Toshiba Cares!

o The consumer electronics industry is

committed to making home

entertainment enjoyable and

safe.

o The Consumer Electronics

Association formed the Home

Entertainment Support Safety

Committee, comprised of TV

and consumer electronics

furniture manufacturers, to

advocate children's safety and

educate consumers and their

families about television safety.

Tune Into Safety

o One size does NOT fit all! Use

appropriate furniture large enough to

support the weight of your TV (and other

electronic components).

o Use appropriate angle braces, straps, and anchors to

secure your furniture to the wall (but never screw anything

directly into the TV).

o Carefully read and understand the other enclosed

instructions for proper use of this product.

o Do not allow children to climb on or play with furniture and

TVs.

o Avoid placing any item on top of your TV (such as a VCR,

remote control, or toy) that a curious child may reach for.

o Remember that children can become excited while watching

a program and can potentially push or pull a TV over.

o Share our safety message about this hidden hazard of the

home with your family and friends. Thank you!

2500 Wilson Blvd.

Arlington, VA 22201 U.S.A.

Tel. 703-907-7600 Fax 703-907-7690

www.CE.org

CEA is the Sponsor, Producer and

Manager of the International CES®

Wide plug

4

Installation, Care, and Service

Installation

Follow these recommendations and precautions and heed all

warnings when installing your TV:

17) Never modify this equipment. Changes or modifications

may void: a) the warranty, and b) the user's authority to

operate this equipment under the rules of the Federal

Communications Commission.

18)

19) Never place or store the TV in direct sunlight; hot, humid

areas; or areas subject to excessive dust or vibration.

20) Always place

the TV on the

floor or a sturdy,

level, stable

surface that can

support the

weight of the

unit. To secure

the TV, use a

sturdy tie from the hooks on the rear of the TV pedestal

to a wall, pillar, or other immovable structure. Make sure

the tie is tight, secure, and parallel to the floor. Leave a

space of at least 4 inches around the TV.

Make sure the surface is wide enough so that the TV’s

width and depth don’t exceed the surface’s edges.

If not, the TV may lean or fall over and cause an injury.

21) Never expose the apparatus to dripping or splashing

liquid or place items such as vases, aquariums, any

other item filled with liquid, or candles on top of the TV.

22) Never block or cover the

slots or openings in the TV

cabinet back, bottom, and

sides.

Never place the TV:

• on a bed, sofa, rug, or

similar surface;

• too close to drapes,

curtains, or walls; or

• in a confined space such as a bookcase, built-in

cabinet, or any other place with poor ventilation.

The slots and openings are provided to protect the TV

from overheating and to help maintain reliable operation

of the TV.

23) Never allow anything to rest on or roll over the power

cord, and never place the TV where the power cord is

subject to wear or abuse.

24) Never overload wall outlets and extension cords.

25) Always operate the TV with a 120 V

AC, 60Hz power source only.

26) Always make sure the antenna system is properly

grounded to provide adequate protection against voltage

surges and built-up static charges (see Section 810 of

the National Electric Code).

27) DANGER: RISK OF SERIOUS

PERSONAL INJURY OR DEATH!

• Use extreme care to make sure you

are never in a position where your

body (or any item you are in contact

with, such as a ladder or

screwdriver) can accidentally touch

overhead power lines. Never locate

the antenna near overhead power

lines or other electrical circuits.

• Never attempt to install any of the following during

lightning activity:

a) an antenna system; or b) cables, wires, or any home

theater component connected to an antenna or phone

system.

Care

For better performance and safer operation of your TOSHIBA

TV, follow these recommendations and precautions:

28) If you use the TV in a room whose temperature is 32 °F

(0°C) or below, the picture brightness may vary until the

LCD warms up. This is not a sign of malfunction.

DANGER: RISK OF SERIOUS PERSONAL

INJURY, DEATH, OR EQUIPMENT

DAMAGE! Never place the TV on

an unstable cart, stand, or table.

The TV may fall, causing serious personal

injury, death, or serious damage to the TV.

Sturdy tie (as short as possible)

Hooks

Clip TV topTV side

Clip

Screw

120 V AC

Ground clamp

Ground clamps

Antenna lead-in wire

Antenna discharge unit

(NEC Section 810-20)

Grounding conductors

(NEC Section 810-21)

Power service grounding

electrode system (NEC Art 250

Part H)

Electric service equipment

5

29) Always unplug the TV before

cleaning. Wipe the display

panel surface gently using

only a soft cloth (cotton,

flannel, etc.). A hard cloth

may damage the surface of

the panel. Avoid contact with

alcohol, thinner, benzene, acidic or alkaline solvent

cleaners, abrasive cleaners, or chemical cloths, which

may damage the surface. Do not spray volatile

compounds such as insecticide on the cabinet. This may

cause a discoloration or damage the cabinet.

30) WARNING: RISK OF ELECTRIC SHOCK!

Never spill liquids or push objects of any

kind into the TV cabinet slots.

31) While it is thundering, do not touch the connecting

cables or apparatus. Failure to follow this instruction

may result in electric shock.

32) For added protection of your TV from lightning and

power surges, always unplug the power cord and

disconnect the antenna from the TV if you leave the TV

unattended or unused for long periods of time.

33) During normal use, the TV may make occasional

snapping or popping sounds. This is normal, especially

when the unit is being turned on or off. If these sounds

become frequent or continuous, unplug the power cord

and contact a Toshiba Authorized Service Center.

34)

Never strike the screen with a sharp or heavy object.

35) The LCD screen of this product can be damaged by

Ultraviolet Radiation from the sun. When selecting a

location for the television, avoid locations where the

screen may be exposed to direct sunlight, such as in

front of a window.

Never touch, press, or place anything on the LCD

screen. These actions will damage the LCD screen. If

you need to clean the LCD screen, follow the

instructions in item 29 on page 5.

Service

36)

WARNING: RISK OF ELECTRIC SHOCK!

Never attempt to service the TV yourself.

Opening and removing the covers may

expose you to dangerous voltage or other

hazards. Refer all servicing to a Toshiba Authorized

Service Center.

37) If you have the TV serviced:

• Ask the service technician to use only replacement

parts specified by the manufacturer.

• Upon completion of service, ask the service

technician to perform routine safety checks to

determine that the TV is in safe operating condition.

38) The cold cathode fluorescent lamp in the LCD panel

contains a small amount of mercury.

When the TV reaches the end of its useful life, dispose

of the used TV by the approved method for your area, or

ask a qualified service technician to properly dispose of

the TV.

Important notes about your

LCD TV

The following symptoms are technical limitations of LCD

Display technology and are not an indication of malfunction.

Therefore, TACP/TCL is not responsible for perceived defects

resulting from these symptoms.

1) An afterimage (ghost) may appear on the screen if a

fixed non-moving image is displayed for a long period

of time. The afterimage is not permanent and will

disappear in a short period of time.

2) The LCD panel contained in this TV is manufactured

using an extremely high level of precision technology;

however, there may be an occasional pixel (dot of light)

that does not operate properly (that does not light, that

remains constantly lit, etc.). This is a structural

property of LCD technology, is not a sign of

malfunction, and is not covered under your

warranty. Such pixels are not visible when the

picture is viewed from a normal viewing distance.

Note: Interactive video games that involve shooting a

"gun" type of joystick at an on-screen target may not

work on this TV.

WARNING: RISK OF

S E R I O U S P E R S O N A L

INJURY OR

EQUIPMENT DAMAGE!

Note: The lamp unit contains mercury, the

disposal of which may be regulated due to

environmental considerations. For disposal

or recycling information, contact your local

authorities or the Electronics Industries Alliance

(www.eiae.org).

WARNING: Do not

swallow the battery.

No eating!

6

Introduction ...................................................................7

Welcome to Toshiba .........................................................7

Supplied accessories ........................................................7

Connecting the power cord ...............................................7

Exploring your new TV ......................................................8

Cable clamper ..........................................................9

Adjusting the TV viewing angle ................................9

Connecting your TV ....................................................10

Connecting an antenna or cable TV ...............................10

Connecting a VCR ..........................................................11

Connecting cable converter box .....................................11

Connecting a cable converter box and a VCR ................12

Connecting a DVD player with ColorStream®

(component video) and a VCR .......................................13

Connecting a DTV receiver/set-top box with

ColorStream® (component video) and a VCR ...............14

Connecting an audio system ...........................................15

Connecting a camcorder .................................................15

Connecting a personal computer (PC) ............................16

Using the remote control ............................................17

Learning about the remote control ..................................17

Installing or replacing the remote control batteries .........18

Remote control effective range .......................................18

Using the remote control to operate your other devices .19

Programming the remote control to operate

your other devices ..........................................................20

Setting up your TV ......................................................23

Learning about the On-Screen Display (OSD)

menu system ..................................................................23

Changing the on-screen display language ......................24

Adding channels to the TV's memory .............................24

Programming channels automatically ....................24

Adding and erasing channels manually .................25

Changing channels .........................................................25

Programming your favorite channels ..............................25

Using the TV's features .............................................. 26

Switching between two channels using

Channel Return ...............................................................26

Using the Blue screen feature ........................................26

Selecting the video input source .....................................26

Selecting the picture size ................................................27

Using the V-Chip menu ...................................................28

V-Chip rating and categories .................................28

V-Chip blocking (Parental control) setup ...............29

Adjusting the picture .......................................................30

Selecting the picture mode ....................................30

Adjusting the picture quality and advanced picture

quality ....................................................................30

Using the Closed Caption feature ...................................31

Setting the sleep timer ....................................................32

Setting the Backlight .......................................................32

Adjusting the sound ........................................................33

Muting the sound ...................................................33

Selecting stereo/SAP broadcasts ..........................33

Selecting the sound mode .....................................34

Adjusting the sound quality ....................................34

Using the AVL

(Automatic Volume Leveler) feature ......................35

Using the Speaker Out feature ..............................35

Using the PC setting feature ...........................................36

Using the Panel Lock feature ..........................................37

Displaying on-screen information ...................................37

Understanding the last mode memory feature ................37

Appendix ..................................................................... 38

Specifications ..................................................................38

Troubleshooting ..............................................................39

Limited United States Warranty ......................................40

Limited Canada Warranty ...............................................41

Index ............................................................................ 42

7

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Supplied accessories

Check that you have the accessories and items shown.

Connecting the power cord

* The power cord supplied with this product is to be used in the United States and Canada only.

Introduction

Welcome to Toshiba

Thank you for purchasing this Toshiba LCD TV. The goal of

this manual is to guide you through setting up and operating

your Toshiba TV as quickly as possible.

The model and serial numbers are on the back of your TV.

Write these numbers in the space provided on the front cover

of this manual for your records.

Instructions in this manual are based on using the remote

control. You also can use the controls on the TV if they have

the same name as those referred to on the remote control.

Please read all the safety and operating instructions carefully,

and keep this manual for future reference.

Owner's Manual

(This book)

Remote control

Battery (AAA) X 2

Power cord

Back of TV

Power cord (supplied)

Wall outlet

120 V AC 60Hz

NOTE: RISK OF

EQUIPMENT DAMAGE!

Never plug in any power

cords until you have finished

connecting all equipment (see page 10).

8

Introduction

Exploring your new TV

You can operate your TV by using the buttons on the right

side panel or the remote control. The A/V terminals for

connecting other equipment to your TV are on the back panel

(see illustrations below). Also see Connecting your TV from

page 10 to page 16.

VOLUME

CHANNEL

POWER

TV front Right side panel

Headphone

jack

Power indicator

Remote sensor

Remote control

Back

Power cord

Cable clamper

RGB/PC IN

PC AUDIO IN

ANT IN

INPUT

MENU

Audio output

VIDEO-2 IN (ColorStream HD)

VIDEO-1 IN (S-video/Video/

Audio input)

9

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Cable clamper

The cable clamper can be used to bundle the connection

cables (see page 10).

Adjusting the TV viewing angle

You can adjust the angle of the TV screen.

Cable clamper

Tilt angle

3° 12°

WARNING: RISK OF

SERIOUS PERSONAL

INJURY OR EQUIPMENT

DAMAGE!

Never grasp the cable clamper when

moving or lifting the TV. The cable

clamper could break, causing the TV

to fall.

10

Connecting your

TV

Connecting your TV

Note: All required cables, if not provided with your other devices, can

be purchased at many electronics accessory suppliers.

•Coaxial (F-type) cable is used for connecting your

antenna, cable TV service, and/or cable converter box to

the ANT 75 Ω RF input on your TV.

•Standard A/V cables (composite video) usually come

in sets of three, and are for use with video devices with

standard audio and standard (composite) video output.

These cables (and the related inputs on your TV) are

typically color-coded according to use: yellow for video,

red for stereo right audio, and white for stereo left (or

mono) audio.

•S-video cable is for use with video devices with S-video

output. Separate audio cables are required for a

complete connection.

Note: An S-video cable provides better picture performance than a

standard (composite) video cable.

•Component video cables come in sets of three and are

for use with video devices with component video output.

These cables are typically color-coded red, green, and

blue. (ColorStream® is Toshiba's brand of component

video.) Separate audio cables are required for a

complete connection.

Note: Component video cables provide better picture performance

than a standard (composite) video or S-video cable.

•Mini D-sub 15-pin cable is for use with a personal

computer with an analog RGB (15-pin) output. A

separate audio cable is required for a complete

connection.

Connecting an antenna or cable TV

This connection allows you to watch TV programs or basic

cable channels.

Back of TV From Antenna or Cable

Coaxial (antenna) cable

S-video cable

Component video cables

Mini D-sub 15-pin cable

Audio cable

Standard A/V cables (red/white/yellow)

NOTE: RISK OF

EQUIPMENT DAMAGE!

Never plug in any power

cords until you have finished

connecting all equipment.

11

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Connecting a VCR

This connection allows you to watch local channels and video

programs, play or record on the VCR while watching TV, and

record from one channel while watching another channel.

Connecting cable converter box

This connection allows you to watch basic and premium cable

channels. Tune the TV to channel 3 or 4 (whichever channel

is vacant in your area), and use the converter box to change

channels.

Note:

If you have a mono VCR, connect L/Mono to

VCR Audio OUT using only one audio cable.

If you have a VCR with S-video, use an S-

video cable (in the S-video jacks) instead of

a standard video cable.

Note:

When you use a converter box with your TV,

the remote control will not operate some

features, such as favorite channel

programming or channel return.

Stereo VCR

Back of TV

From Cable

Box or

Antenna

Back of TV

From cable

12

Connecting your

TV

Connecting a cable converter box and a VCR

This connection allows you to watch and record basic and

premium cable channels, as well as watch videotapes. Set

the TV signal source to VIDEO1 (page 26). Tune the VCR to

channel 3 or 4 (the same channel as the converter box output

switch), and use the cable converter box to change channels.

Note:

When you use a converter box with your TV,

the remote control will not operate some

features, such as favorite channel

programming or channel return.

If you have a mono VCR, connect L/Mono to

VCR Audio OUT using only one audio cable.

If you have a VCR with S-video, use an S-

video cable (in the S-video jacks) instead of

a standard video cable.

Stereo VCR

Back of TV

The unauthorized recording, use,

distribution, or revision of television

programs, videotapes, DVDs, and other

materials is prohibited under the

Copyright Laws of the United States

and other countries, and may subject

you to civil and criminal liability.

13

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Connecting a DVD player with ColorStream®

(component video) and a VCR

This connection allows you to watch DVD, VCR, and TV

programs, and record TV programs.

Your TV has ColorStream® (component video) inputs.

Connecting your TV to a DVD player with component video

can greatly enhance picture quality and realism.

- To record one TV program while watching another TV

program, tune the VCR to the channel to record, and tune

the TV to the channel to watch.

- To record a TV program while watching a DVD, tune the

VCR to the channel to record, and select VIDEO2 on the

TV (see "Selecting the video input source" on page 26).

Note:

For the highest possible picture quality, use

component video cables between the TV

and DVD player.

The ColorStream jacks can be used with

480i and 480p scan system.

Stereo VCR

Back of TV

From Antenna

DVD player with component video

The unauthorized recording, use,

distribution, or revision of television

programs, videotapes, DVDs, and other

materials is prohibited under the

Copyright Laws of the United States

and other countries, and may subject

you to civil and criminal liability.

14

Connecting your

TV

Connecting a DTV receiver/set-top box with

ColorStream® (component video) and a VCR

This connection allows you to watch DTV (digital TV), VCR,

and TV programs, and record DTV (composite video only)

and TV programs.

Your TV has ColorStream® (component video) inputs.

Connecting your TV to a DTV receiver with component video

can greatly enhance picture quality and realism.

- To record and watch a DTV program, select LINE IN on the

VCR, and select VIDEO1 on the TV (see "Selecting the

video input source" on page 26).

- To record a TV program while watching a DTV program,

tune the VCR to the channel to record, and select VIDEO2

on the TV.

- To record and watch the same TV program, tune the VCR

to the channel to record, and select VIDEO1 on the TV.

- To record one TV program while watching another TV

program, tune the VCR to the channel to record, and tune

the TV to the channel to watch.

Note:

For the highest possible picture quality, use

component video cables between the TV

and DTV receiver/set-top box.

The TV side panel can be used to connect a

VCR with S-video.

Stereo VCR

Back of TV

From Antenna

DTV Receiver with component video

From DTV Antenna

The unauthorized recording, use,

distribution, or revision of television

programs, videotapes, DVDs, and other

materials is prohibited under the

Copyright Laws of the United States

and other countries, and may subject

you to civil and criminal liability.

15

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Connecting an audio system

This connection allows you to hear the TV sound through

external speakers connected to an audio amplifier. The audio

signal level (fixed) is not affected by pressing the volume

buttons on the TV or the TV's remote control. To control the

audio through the amplifier, use the audio system's remote

control.

Connecting a camcorder

This connection allows you to watch video materials recorded

on a camcorder.

Note:

Set the TV's volume to the minimum level if

necessary.

Note:

If you have a camcorder with S-video, use

an S-video cable instead of a standard video

cable for better picture performance.

Amplifier

Back of TV

Camcorder

Back of TV

16

Connecting your

TV

Connecting a personal computer (PC)

This connection allows you to view the image of a personal

computer (PC) on the TV screen. When connecting a PC to

the TV, use an analog RGB (15-pin) computer cable and a

PC audio cable.

- To use a PC, set the monitor output resolution on the PC

before connecting it to the TV. The following signals can be

displayed.

• SVGA: VESA 800 X 600 @ 60Hz

Other formats or non-standard signals may not be

displayed correctly.

- To display the optimum picture, use the PC setting feature.

(see "Using the PC setting feature" on page 36).

Note:

• Some PC models cannot be connected

to this TV.

• An adapter is not needed for

computers with a DOS/V compatible

mini D-sub 15-pin terminal.

• Depending on the DVD's title and the

specifications of the PC on which you

are playing the DVD-Video, some

scenes may be skipped or you may not

be able to pause during multi-angle

scenes.

Computer

Back of TV

Audio

output

Audio cable

RGB/PC

output

Conversion adapter

(if necessary)

17

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Using the remote control

Learning about the remote control

1. POWER: Turns the TV on and off (standby mode*).

2. MUTE: Turns off the sound (page 33).

3. DISPLAY: Displays TV settings on-screen (page 37) or

closes the on-screen menu.

4. INPUT: Selects the video input source (page 26).

5. Channel Numbers (0-9, 100): Allow direct access to

channels (page 25).

6. CH RTN/ENT: Enacts the selected channel/switches

between the last two viewed channels (page 26).

7. TV: Selects TV mode (page 20).

8. VCR: Selects VCR mode (page 19).

9. CBL/SAT: Selects CBL/SAT mode (page 19).

10. DVD: Selects DVD mode (page 20).

11. VOL (volume) + -: Adjust the volume level.

12. CH (channel) : Cycle through programmed

channels (page 24).

13. PIC SIZE: Cycles through the picture sizes: 4:3, 16:9

(page 27).

14. SLEEP: Sets the TV to turn off at a specific time (page

32).

15. STWX (arrow buttons): Select or adjust menu items

(page 23).

16. FAV ST: Cycle through channels you programmed as

favorite channels (page 25).

17. MENU/ENTER: Accesses the menu system (page 23).

18. EXIT: Returns to the previous On-Screen Display (OSD)

menu, or leaves and saves the menu settings (page 23). * The TV is in standby mode when the

power is OFF but the power cord is still

plugged into an outlet.

First press TV to control the TV.

18

Using the remote

control

Installing or replacing the remote control

batteries

To install the batteries:

1. Open the battery cover on the back of the remote control.

2. Install two batteries (R03 size "AAA"). Match the + and –

signs on the batteries to the signs on the battery

compartment.

3. Replace the battery cover on the remote control until the

lock snaps.

Remote control effective range

Caution:

Never throw batteries into a fire.

Note:

• Be sure to use AAA batteries.

• Dispose of batteries in a designated

disposal area.

• The batteries should always be disposed

of with the environment in mind. Always

dispose of the batteries in accordance

with applicable laws and regulations.

• If the remote control does not operate

correctly, or if the operating range

becomes reduced, replace the batteries

with new ones.

• Always remove the batteries from

remote control if they are dead or if the

remote control is not to be used for an

extended period of time. This will prevent

battery acid from leaking into the battery

compartment.

19

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Using the remote control to operate your

other devices

To control a cable TV converter/satellite receiver:

Program the remote control to recognize the brand of your

cable TV converter/satellite receiver (see "Programming the

remote control to operate your other devices on page 20").

The buttons shown at right will control the cable TV converter/

satellite receiver.

Press CBL/SAT first.

To control a VCR:

Program the remote control to recognize the brand of your

VCR (see "Programming the remote control to operate your

other devices on page 20").

The buttons shown at right will then control the VCR.

Press VCR first.

MUTE

POWER

INPUT

Channel

Numbers

CH RTN/ENT

VOL+-

CH

CBL/SAT

PIC SIZE

TV/VCR

POWER

INPUT

Channel

Numbers

CH RTN/EN

T

VOL+-

CH

VCR

PIC SIZE

VCR

controls

20

Using the remote

control

To control a DVD player:

Program the remote control to recognize the brand of your

DVD player (see Programming the remote control to operate

your other devices below).

The buttons shown at right will then control the DVD player.

Press DVD first.

Programming the remote control to operate

your other devices

This remote control is pre-programmed to operate most

Toshiba satellite receivers, VCRs, and DVD players. To

control a non-Toshiba device (or a Toshiba device that the

remote control is not reprogrammed to operate), you must

follow the steps below to program your remote control.

1. Refer to the code tables (on pages 21 and 22) to find the

corresponding code for your device.

If more than one code is listed, try each one separately

until you find the one that works.

2. If you are programming the remote control to operate

your:

• Cable TV converter/satellite receiver: Press CBL/SAT.

• VCR: Press VCR.

• DVD player: Press DVD.

3. While holding down DISPLAY, press the Channel

Number buttons to enter the three-digit code for your

device within 10 seconds.

Note: If you do not enter the code within 10 seconds from step 3, or if

you enter the wrong code, this operation is canceled.

4. Point the remote control at the cable TV converter/

satellite receiver, VCR or DVD player, and press POWER

to test the code.

• If the device responds, you entered the correct code.

• If the device does not respond, repeat steps 1–4 using

another code.

5. Press TV to control the TV.

For future reference, write down the codes you used:

Cable TV converter/satellite receiver code

VCR code

DVD player code

Note:

• When shipped from the factory, the remote control is set to operate

your TV.

• Each time you replace the batteries, you must reprogram the remote

control.

• Some newer VCRs are capable of working on either of two remote

codes. These VCRs have a switch labeled VCR1/VCR2.

If your VCR has this kind of switch and does not respond to any of the

codes for your VCR, set the switch to the other position (VCR1 or

VCR2) and reprogram the remote control.

MUTE

POWER

INPUT

Number

buttons

VOL+-

DVD

PIC SIZE

STWX

DVD MENU

ENTER

DVD controls

CLEAR

TOP MENU

DISPLAY

Channel

Numbers

DISPLAY

TV

VCR

DVD

CBL/SAT

DVD SKIP/SEARC

H

21

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Cable TV converter/satellite receiver, VCR and DVD player code tables

[For CBL/SAT Mode]

Cable converter

box

ABC: 061, 062, 063, 082,

084, 087, 091, 092,

096, 098

Archer: 065, 092, 097,

099

Cableview: 064, 094

Century: 092

Citizen: 090, 092, 097

Contec: 083, 085, 086,

088, 093, 098

Diamond: 093

Eagle: 091

GE: 061, 062

Gemini: 069, 070, 094

General Instruments: 062,

089, 096

Hamlin: 093

Hitachi: 062, 095, 096

Jasco: 097

Jerrold: 062, 069, 071,

082, 086, 089, 091,

096

Magnavox: 072, 096

Memorex: 091, 092, 104

Multi Canal: 090

Novavision: 101

Panasonic: 081, 083, 085

Philco: 087

Philips: 066, 067, 068,

070, 072, 073, 074,

075, 091, 092

Pioneer: 076, 077

Proscan: 061, 062

Radio Shack: 092, 097,

099

RCA: 064, 081

Realistic: 065

Recoton: 102

Samsung: 077, 090

Scientific Atlanta: 063,

078, 079, 080, 088,

098, 101, 105

Sears: 095

Signature: 062

Signature 2000: 096

Sprucer: 081, 085

Starcom: 069, 082, 087,

096, 103, 104

Stargate: 069, 090

Sylvania: 095, 100

Tel e Vie w : 0 90

Texscan: 100

Tocom: 071, 084, 085

U. S. Electronics: 087,

096, 098

United Cable: 082

Universal: 065, 092, 097,

099, 102, 103

Wards: 096

Satellite

Alphastar: 038, 059

Chaparral: 034

DISH Network: 057

Drake: 020, 040, 044,

046, 050, 053

Echostar: 018, 041, 051

Express Vu: 057

Fujitsu: 027

GE: 008, 009, 013

General Instruments: 010,

011, 012, 022, 023,

031, 049

Hitachi: 033

Hughes: 033

Hughes Network

Systems: 019

Intersat: 048

Janeil: 027

JVC: 017, 057

Kenwood: 029

Magnavox: 060

Optimus: 058

Pansat: 036, 052

Primestar: 015, 042

Proscan: 008, 009, 013

Radio Shack: 022, 023,

030

RCA: 008, 009, 013, 016

Realistic: 030

Samsung: 059

Sony: 014, 055

Star Choice: 057

Star Trak: 025, 026, 037,

054

STS: 024

Toshiba: 000, 001, 002,

003, 004, 005, 006,

007, 020, 031, 056

Uniden: 021, 028, 030,

032, 035, 039, 043,

045, 047, 058

Zenith: 027

[For VCR Mode]

VCR

Admiral: 049

Aiko: 019

Aiwa: 018

Akai: 003, 004, 037, 038,

039, 058, 069

Audiovox: 010

Bell & Howell: 007, 068

Broksonic: 008, 017

Calix: 010

Carver: 026

CCE: 019

Citizen: 009, 010, 011,

012, 013, 014,

015,019, 057, 073

Colortyme: 005

Craig: 009, 010, 016, 061,

065, 079

Curtis Mathes: 001, 005,

009, 012, 014, 040,

048, 053, 056, 057

Daewoo: 011, 013, 015,

017, 018, 019, 057,

078

Daytron: 078

Denon: 063

Dimensia: 001, 048

Electrohome: 010, 020,

065

Emerson: 003, 008, 010,

011, 017, 018, 020,

028, 039, 054, 057,

062, 065, 068, 072

Fisher: 007, 016, 021,

022, 023, 057, 064,

068, 070, 071, 079

Fuji: 004, 041

Funai: 018, 073

Garrard: 018

GE: 001, 002, 009, 040,

042, 048, 056

Go Video: 056, 059,

061, 081

Goldstar: 005, 010, 014,

054, 056, 065, 067

Gradiente: 018, 065

Harman Kardon: 005

Hitachi: 024, 025, 035,

037, 042, 063, 070,

080

JBL: 076

JC Penney: 005, 006,

007, 008, 009, 010,

023, 024, 025, 026,

035, 056, 061, 063,

065

Jensen: 024, 025, 037

JVC: 005, 006, 007, 014,

037, 043, 062, 063,

068, 082

Kenwood: 005, 006, 007,

012, 014, 037, 043,

053, 068, 071

Kodak: 010

LG: 010

Lloyds: 053, 073, 079

Logik: 061

LXI: 010

Magnasonic: 061, 065,

078

Magnavox: 026, 027, 034,

044, 057, 061, 072

Marantz: 005, 006, 007,

012, 014, 026, 053,

067

Memorex: 007, 009, 010,

016, 018, 034, 049,

063, 065, 066, 068,

075, 079

MGA: 020, 028, 039

MGN: 056

Minolta: 024, 025, 035,

063

Mitsubishi: 020, 024, 025,

028, 039, 043, 065

Montgomery Ward: 049

Motorola: 049

MTC: 009, 046, 061

Multitech: 009, 012, 018

NEC: 005, 006, 007, 012,

014, 037, 043, 053,

054, 067, 070

Nikko: 010

Noblex: 009

Optimus: 010, 049, 065

Optonica: 031

Orion: 054, 057, 062, 065,

068, 072

Panasonic: 036, 045, 046,

057, 061, 072, 079

Pentax: 012, 024, 025,

035, 042, 053, 063

Pentex Research: 014

Philco: 026, 027, 063

Philips: 026, 031, 044,

057

Pioneer: 006, 024, 043,

055

Portland: 012, 013, 015

Proscan: 001, 002, 048

Proton: 061

Quasar: 045

Radio Shack: 010, 031,

065

Radio Shack/Realistic:

007, 009, 010, 016,

018, 020, 021, 022,

031, 049

Radix: 010

RCA: 001, 002, 003, 009,

024, 025, 029, 035,

040, 042, 045, 048,

055, 056, 063, 071,

083

Realistic: 007, 009, 010,

011, 016, 018, 020,

021, 022, 031, 049,

051, 056, 060, 065,

075, 079

Ricoh: 047

Runco: 034

Samsung: 009, 011, 038,

056, 073, 084

Sansui: 006, 037, 043,

061

Sanyo: 007, 009, 016,

054, 064, 068, 071,

075, 079, 085

Scott: 008, 011, 017, 028,

030, 057, 065, 072

Sears: 007, 010, 016,

021, 022, 023, 024,

025, 035, 053, 057,

063, 064, 065, 068,

071, 075, 079

Sharp: 013, 020, 031,

049, 051, 060, 066

Shintom: 004, 025, 032,

061

Signature: 049

Signature 2000: 075

Singer: 047, 061

Sony: 004, 032, 033, 041,

052, 058, 070, 074,

076, 077, 080

STS: 035

Sylvania: 018, 026, 027,

028, 044, 072

Symphonic: 018, 051,

053, 073, 079

Tan d y : 0 07

Tashiko: 010

Tatung: 037

Teac: 018, 029, 037

Technics: 036

Teknika: 010, 018, 065

Toshiba: 000, 011, 021,

023, 024, 028, 030,

039, 057, 074, 078,

079

Totevision: 009, 010, 065

Unitec: 073

Unitech: 009

Vector Research: 005,

006, 011, 012, 053

Video Concepts: 005,

006, 011, 012, 039,

053

Wards: 009, 010, 011,

016, 018, 020, 024,

025, 031, 035, 049,

051, 056, 057, 060,

065, 066, 079

White Westinghouse: 073

XR-1000: 018

Yamaha: 005, 006, 007,

014, 037, 053

Zenith: 004, 032, 034,

041, 047, 069, 086

TV/VCR Combo

Action: 078

GE: 059, 062

Goldstar: 065

Panasonic: 065

Precision: 078

Quasar: 065

Realistic: 079

Sony: 074

Tos hi b a : 0 57

Totevision 009, 010, 065

Zenith: 065

22

Using the remote

control

[For DVD Mode]

DVD

Aiwa: 006, 015

Apex: 016, 017

BOSE: 097

Broksonic: 018

Clarion: 019

Classic: 020

Daewoo: 021

Denon: 022, 023, 024,

025

Emerson: 026, 027

Fisher: 028

Funai: 027

GE: 001, 029, 030

Go Video: 087

GPX: 031

Hitachi: 005, 032, 033,

034, 035

JVC: 003, 007, 036, 042,

088

Kenwood: 037

Konka: 008, 009

Magnavox: 004, 038

Memorex: 039

Mintek: 040

NAD: 026

Nakamichi: 041

Norcent: 043

Onkyo: 044

Oritron: 058

Panasonic: 010, 045, 046,

047, 048, 049, 050

Philips: 004, 051

Pioneer: 052, 053, 054,

055

Proscan: 001, 056

Qwestar: 057, 058

RCA: 001, 002, 059, 089

Sampo: 060

Samsung: 061, 062, 086,

090

Sansui: 073

Sanyo: 063, 091

Sharp: 064, 067

Sherwood: 074

Sony: 011, 012, 065, 066,

068, 069, 070

Sylvania: 027

Teac: 071

Technics: 072

Techwood: 075

Toshiba: 000, 013, 076,

077, 078

Yamaha: 079, 080, 081

Zenith: 014, 082, 092

Portable DVD

player

Aiwa: 093

Audiovox: 094, 095

Panasonic: 024, 096, 099

RCA: 098

HTIB

Lasonic: 083

Panasonic: 084

Venturer: 085

[For VCR and DVD Mode]

DVD/VCR Combo

Go Video:

DVD=087, VCR=081

JVC:

DVD=088, VCR=082

RCA:

DVD=089, VCR=083

Samsung:

DVD=090, VCR=084

Sanyo:

DVD=091, VCR=085

Zenith:

DVD=092, VCR=086

23

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Setting up your TV

Learning about the On-Screen Display (OSD)

menu system

After you have installed the batteries, you will need to set

some preferences on the TV by using the OSD menu system.

You can access the system using the buttons on the TV or

remote control.

1. Press MENU/ENTER to display the OSD menu.

2. Press W or X to select a menu.

3. Press S or T to select an item.

4. Press W or X to adjust a setting, or press X to display the

next page of menu and repeat step 3-4.

5. To return to the previous menu, or leave and save your

menu settings, press EXIT.

Note:

The PC mode is selectable only when the

TV is in PC input mode and active picture is

on-screen (see "Selecting the video input

source" on page 26).

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT


Contrast

Brightness

Color

Sharpness

Tint

Picture Advanced Setting >

56

32

32

0

0

Picture Mode Dynamic

CH Program

TV/CATV TV

CH PROGRAM

Add/Erase

Blue Screen

Add

On

Favorite Channel >

100%

MENU/ENTER EXIT

PC Setting

Frequency

Phase

H. Position

V. P os iti on

0

0

Auto

MENU/ENTER EXIT

MENU/ENTER EXIT

Balance

AVL Off

Audio Advanced Setting >

0

Sound Mode Flat

Speaker Out On

MTS Stereo

MENU/ENTER EXIT

Audio

0 minutes

STW X

MENU/

ENTER

EXIT

24

Setting up your

TV

Changing the on-screen display language

You can choose from three different languages (English, Spanish,

and French) for the on-screen display of adjustment menus and

messages.

To select a language:

1. Press MENU/ENTER, and then press W or X until the Special

menu appears.

2. Press S or T to highlight Language.

3. Press W or X to select your desired language.

Adding channels to the TV's memory

When you press CH or CH , your TV will stop only on the

channels you program into the TV's channel memory.

Follow the steps below and on the next page to program all active

channels into the TV's memory.

Programming channels automatically

Your TV can automatically detect all active channels in your area

and store them in the channel memory. After the channels are

programmed automatically, you can manually add or erase

individual channels (see page 25).

To program channels automatically:

1. Press MENU/ENTER, and then press W or X until the CH

Program menu appears.

2. Press T to highlight TV/CATV. Select the system (CATV or

TV) that you want to program the channels.

3. Press S or T to highlight CH PROGRAM.

4. Press X or MENU/ENTER to start auto-programming. The TV

will automatically cycle through all the TV and Cable

channels, and store all active channels in the channel

memory.

5. Press EXIT to close the OSD menu and press CH or CH

to view the programmed channels.

Note:

• To tune the TV to a channel not

programmed in the channel

memory, you must use the Channel

Number buttons on the remote

control.

• If you press EXIT during auto-

programming, the function will stop

and only the channels programmed

up to that time will be stored in the

channel memory.

0 minutes

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT

Special

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT

Language English

0 minutes

CH Program

TV/CATV TV

CH PROGRAM

Add/Erase

Blue Screen

Add

On

Favorite Channel >

100%

MENU/ENTER EXIT

CH Program

CH PROGRAM

Add/Erase

Blue Screen

Add

On

Favorite Channel >

100%

MENU/ENTER EXIT

TV/CATV TV

CH Program

TV/CATV TV

Add/Erase

Blue Screen

Add

On

Favorite Channel >

MENU/ENTER EXIT

CH PROGRAM 100%

STW X

MENU/

ENTER

CH

STW X

MENU/

ENTER

EXIT

25

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Adding and erasing channels manually

After you have automatically programmed the active

channels into the TV's channel memory, you can manually

add or erase specific channels.

To add or erase channels:

1. Tune your TV to the channel you want to add or erase.

2. Press MENU/ENTER, and then press W or X until the CH

Program menu appears.

3. Press S or T to highlight Add/Erase.

4. Press W or X to select Add or Erase.

5. Press EXIT to leave and save the setting. The current

channel is added to the TV’s memory or erased from the

channel list.

Changing channels

To change to a specific channel (programmed or

unprogrammed):

Press the Channel Number buttons (0–9 and 100).

For channels 100 and higher, press the 100 button, and

then the next two numbers. For example, to select

channel 125, press 100, 2, 5.

To change to the next programmed channel:

Press CH or CH on the TV or remote control.

Programming your favorite channels

You can preset up to 5 of your favorite channels using the

Favorite Channel Programming feature. Because this feature

scans through only your favorite channels, it allows you to

skip other channels you do not normally watch.

To program your favorite channels:

1. Press MENU/ENTER, and then press W or X until the CH

Program menu appears.

2. Press S or T to highlight Favorite Channel >.

3. Press X or MENU/ENTER to display the Favorite

Channel page.

4. Press S or T to select the first

favorite channel position.

5. Press the Channel Number

buttons to set the desired channel

number for the first favorite

channel position.

Note: If the channel number you want to

set is below 10, press 0 and then the

number.

6. Repeat steps 4 and 5 to program

other channels.

To select your favorite channels:

Repeatedly press FAV S or T on the

remote control.

CH Program

TV/CATV TV

CH PROGRAM

Add/Erase

Blue Screen

Add

On

Favorite Channel >

100%

MENU/ENTER EXIT

CH Program

TV/CATV TV

Blue Screen On

Favorite Channel >

MENU/ENTER EXIT

CH PROGRAM 100%

Add/Erase Add

CH Program

TV/CATV TV

CH PROGRAM

Add/Erase

Blue Screen

Add

On

Favorite Channel >

100%

MENU/ENTER EXIT

CH Program

TV/CATV TV

Blue Screen On

MENU/ENTER EXIT

CH PROGRAM 100%

Add/Erase Add

Favorite Channel >

Favorite Channel

Favorite 2

Favorite 3

Favorite 4

Favorite 5

- - -

- - -

- - -

- - -

Favorite 1 - - -

0-9 100 EXIT

STW X

FAV ST

CH

Channel

Numbers

CHANNEL

TV side panel

MENU/

ENTER

EXIT

26

Using the TV's

features

Using the TV's features

Switching between two channels using

Channel Return

The Channel Return feature allows you to switch between

two channels without entering an actual channel number

each time.

To switch between two channels:

1. Select the first channel you want to view.

2. Select a second channel using the Channel Number

buttons (0–9, 100).

3. Press CH RTN/ENT. The previous channel will be

displayed.

Each time you press CH RTN/ENT, the TV will switch back

and forth between the last two channels that were selected.

Using the Blue screen feature

With the Blue screen function On, the screen will

automatically turn blue and the sound will be muted when no

signal is received.

To turn on the Blue screen feature:

1. Press MENU/ENTER, and then press W or X until the CH

Program menu appears.

2. Press S or T to highlight Blue Screen.

3. Press W or X to select On.

Note: If the Blue screen appears repeatedly because of poor signal

strength, select Off in step 3.

Selecting the video input source

Press INPUT on the remote control or on the TV side panel to

view a signal from another device connected to your TV, such

as a VCR or DVD player. You can select VIDEO1, VIDEO2

(including ColorStream), or PC depending on which input

jacks are used for connecting the devices (see "Connecting

your TV" on page 10).

CH Program

TV/CATV TV

CH PROGRAM

Add/Erase Add

Favorite Channel >

100%

Blue Screen On

MENU/ENTER EXIT

CH Program

TV/CATV TV

CH PROGRAM

Add/Erase

Blue Screen

Add

On

Favorite Channel >

100%

MENU/ENTER EXIT

VIDEO1 VIDEO2

PC

TV channel

STW X

MENU/

ENTER

Channel

Numbers

INPUT

CH RTN/

ENT

TV side panel

INPUT

27

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Selecting the picture size

You can select a desired picture size either directly on the

remote control or in the On-Screen Display (OSD) menu.

• Using the remote control

Repeatedly press PIC SIZE on the remote control to select

the desired picture size.

• Using the OSD menu

1. Press MENU/ENTER and press W or X to highlight the

Special menu.

2. Press S or T to highlight Picture Size, then press W or X

to select a desired picture size.

4:3

16:9

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT

Special

Language English

Off

Bright

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT

4:3Picture Size

0 minutes 0 minutes

Item Pressing W or X

4:3 Scales an image so that it is displayed in the center

of the screen with a 4:3 aspect ratio. This is most

suitable for 4:3 images like computer monitors,

standard definition TV and 4:3 aspect DVD movies,

as it displays them without aspect alteration.

16:9 Scales an image so that it is displayed in the center

of the screen with a 16:9 aspect ratio. This is most

suitable for images which are already in a 16:9

aspect, like high definition TV, as it displays them

without aspect alteration.

PIC SIZE

STW X

MENU/

ENTER

28

Using the TV's

features

Using the V-Chip menu

Some TV programs and movies include signals that classify

the content of the program (violence, sex, dialog, language).

The V-Chip control feature in this TV detects the signals and

blocks the programs according to your selections. To use this

feature, perform the following setup.

1. Enable the Lock.

2. Set a four-digit password.

3. Select the ratings and categories you want to block.

V-Chip rating and categories

Rating guidelines are provided by broadcast stations. Most

television programs and television movies can be blocked by

TV rating and/or category. Movies that have been shown at

the theaters and direct-to-video movies use the MPAA movie

rating system instead.

For Movies previously shown in theaters:

Movie Ratings:

• Unblocked

• G & above (general audience)

• PG & above (parental guidance suggested)

• PG-13 & above (13 years and older)

• R & above (restricted)

• NC-17 & above (18 years and older)

• X (adult)

If you select "PG-13 & above," all G and PG rated movies will

be available, and all PG-13, R, NC-17 and X rated movies will

be blocked.

For Television programs including made-for-TV movies:

General TV Ratings:

• Unblocked

• TV-G & above (general audience)

(individual categories do not apply)

• TV-PG & above (parental guidance suggested)

• TV-14 & above (14 years and older)

• TV-MA (mature audience)

Children TV Ratings:

• Unblocked

• TV-Y & above (youth)

(individual content categories do not

apply)

• TV-Y7 (youth, 7 years and up)

Content Categories:

• Dialog - sexual dialogue (applies to TV-PG & above,

TV-14)

• Language - adult language (applies to TV-PG & above,

TV-14 & above, TV-MA)

• Sex - sexual situations (applies to TV-PG & above,

TV-14 & above, TV-MA)

• Violence (applies to TV-PG & above,

TV-14 & above, TV-MA)

• F. Violence - fantasy violence (applies only to TV-Y7)

• No Rating (blocks all viewing)

Note:

The V-Chip function is available for the U.S.

V-Chip system.

29

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

V-Chip blocking (Parental control) setup

1. Press MENU/ENTER, and then press W or X until the

Special menu appears.

2. Press S or T to highlight Block Setting >. Press X to

enter the Block Setting page.

• If you already set a password, enter your four-digit

password.

• If you have not created a password, the TV is initially

set up with the password "0000".

• If you cannot remember your password, press "7777".

3. Should you need to change the password:

Press S or T to highlight Change Password >.

Press X to display the Change Password page and then

enter a four-digit new password.

Enter it again when requested.

4. To set the type of blocking:

Press S or T to highlight V-Chip Blocking Setting >.

Press X to display the V-Chip Blocking Setting page.

Press S or T to select the type of rating to be set.

For USA TV Ratings, press X to display the next page

and select the rate to be set. For Moive Ratings, press W

or X to select an item to be set.

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT

0 minutes Special

Language English

Off

Bright

Closed Caption

Backlight

Sleep Timer

MENU/ENTER EXIT

4:3

Picture Size

Block Setting >

0 minutes Block Setting

Enter Password: - - - -

Change Password >

V-Chip Blocking Setting >

Panel Lock Off

: Please enter 4 characters password

Block Setting

V-Chip Blocking Setting >

Enter Password: - - - -

Panel Lock Off

Change Password >

Change Password

: Please enter 4 characters password

New Password: - - - -

MENU/ENTER EXIT

Block Setting

Enter Password: - - - -

Panel Lock Off

Change Password >

V-Chip Blocking Setting >

V-Chip Blocking Setting

Moive Ratings N/A

MENU/ENTER EXIT

USA TV Ratings >

MENU/ENTER EXIT

STW X

Number

MENU/

ENTER

If you try to watch a TV program that

exceeds the rating limits you set, the TV

enters program lock mode.

To unlock the program, press T and enter

the password you set.

To skip this program, press channel

number buttons or CH to select

other channel.

VIDEO1

BLOCKED

****

30

Using the TV's

features

Adjusting the picture

Selecting the picture mode

You can select your desired picture type from four picture

modes: Dynamic, Standard, Movie, or Memory.

To select the picture mode:

1. Press MENU/ENTER, and then

press W or X until the Picture

menu appears.

2. Press T or S to highlight Picture

Mode.

3. Press W or X to select the mode

you prefer.

Adjusting the picture quality and advanced picture

quality

You can adjust the picture quality to your personal

preferences, including Contrast, Brightness, Color,

Sharpness, and Tint.

To adjust the picture quality and advanced picture quality:

1. Press MENU/ENTER, and

then press W or X until the

Picture menu appears.

2. Press S or T until the item

you want to adjust is

highlighted.

3. Press W or X to adjust the

level.

4. To continue adjusting the

other items, repeat step 2-3.

The picture qualities you adjusted can be saved in the TV's

Memory mode.

Note:

If you select one of the factory-set picture

modes (Dynamic, Standard, or Movie) and

then adjust a picture quality setting (for

example, increase the contrast), the picture

mode automatically changes to Memory in

the Picture menu.

Note:

When the selected input signal is PC, the

following functions will not be available:

Color, Sharpness, Tint, NTSC Setup, Black

Stretch, and Noise Reduction.

Mode Picture quality

Dynamic Bright and dynamic picture (factory setting)

Standard Standard picture setting (factory setting)

Movie Movie-like picture setting (factory setting)

Memory Your personal preference


Brightness

Color

Sharpness

Tint

Picture Advanced Setting >

32

32

0

0

Contrast 56

MENU/ENTER EXIT

Picture Mode Dynamic

Selection WPressing X

Contrast lower higher

Brightness darker lighter

Color paler deeper

Sharpness softer sharper

Tint reddish greenish

Contrast 56


Brightness

Color

Sharpness

Tint

Picture Advanced Setting >

32

32

0

0

Picture Mode Dynamic

Contrast 56

MENU/ENTER EXIT

STW X

MENU/ENTER

31

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

To adjust the advanced picture quality (continued):

5. Press S or T to highlight

Picture Advanced Setting >

and press X to display the

Picture Advanced Setting

page.

6. Press S or T until the item you

want to adjust is highlighted

and press W or X to adjust the

level.

Using the Closed Caption feature

The Closed Caption feature has two options:

• Captions–An on-screen display of the dialogue,

narration, and sound effects of TV programs and

videos that are closed captioned (usually marked as

"CC" in TV listings).

• Text–An on-screen display of information not related to

the current program, such as weather or stock data

(when provided by individual stations).

To select captions or text:

1. Tune the TV to the desired program.

2. Press MENU/ENTER, and then press W or X to display

the Special menu.

3. Press S or T to highlight Closed Caption.

4. Press W or X to select the Caption or Text mode you

prefer.

• To view captions, select CC1, CC2, CC3, or CC4 (CC1

displays captions in the primary language in your area).

Note: If the program or video you selected is not closed captioned,

the captions will not display on the screen.

• To view text, select Text1, Text2, Text3, or Text4.

Note: If text is not available in your area, a black rectangle may

appear on your screen. If this happens, turn the Closed Cap-

tion feature Off.

• To turn off the Closed Caption feature, select Off.

Note:

A closed caption signal may not display in

the following situations:

• When a videotape has been dubbed

• When the signal reception is weak

• When the signal reception is

nonstandard

Picture Advanced Setting

Noise Reduction

Color Temperature

0 IRE

Black Stretch

MENU/ENTER EXIT

Off

Off

Cool

Picture Reset

NTSC Setup

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Sleep Timer

Block Setting >

MENU/ENTER EXIT

Special

Language English

Bright

Backlight

Sleep Timer

MENU/ENTER EXIT

4:3

Picture Size

Block Setting >

OffClosed Caption

0 minutes 0 minutes

Item Options

NTSC Setup 0 IRE, 7.5 IRE

Black Stretch Low, Middle, High, Off

Noise Reduction Low, Middle, High, Off

Color

Temperature

Normal, Warm, Cool

Picture Reset Press OK to reset all of

the functions in the

Picture menu to the

default values of

Dynamic mode.

STW X

MENU/

ENTER

32

Using the TV's

features

Setting the sleep timer

To set the sleep timer to turn off the TV automatically:

• Using the remote control

1. Press SLEEP to display the current setting.

2. Repeatedly press SLEEP to set the length of time before

the TV turns off.

The time length ranges from 0 minutes to 120 minutes.

0 J 15 J 30 J 45 J 60 J 120

• Using the On-Screen Display (OSD) menu

1. Press MENU/ENTER, and then press W or X until the

Special menu appears.

2. Press S or T to highlight Sleep Timer.

3. Press W or X to set the length of time before the TV turns

off.

The time length ranges from 0 minutes to 120 minutes.

0 J 15 J 30 J 45 J 60 J 120

To cancel the sleep timer:

Press SLEEP until "0 minutes" appears.

Setting the Backlight

Your LCD TV set have a bright fluorescent light behind its

LCD panel. The light source, which is called backlight, affects

the brightness of the entire screen. In a darkened room with

proper lighting, we recommend you lower this setting before

you begin adjusting the brightness and contrast. You can

always raise it later if it proves too dim.

To set the Backlight:

1. Press MENU/ENTER, and then press W or X to display

the Special menu.

2. Press S or T to highlight Backlight.

3. Press W or X to select Bright, Normal, or Dark.

Note:

• When an instant power failure occurs,

the sleep timer settings may be

cleared.

• To display the amount of time left until

the TV turns off automatically, press

SLEEP once.

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Block Setting >

MENU/ENTER EXIT

Special

Language English

Off

Bright

Closed Caption

Backlight

MENU/ENTER EXIT

4:3

Picture Size

Block Setting >

Sleep Timer 0 minutes Sleep Timer 0 minutes

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Block Setting >

MENU/ENTER EXIT

Special

Language English

MENU/ENTER EXIT

4:3

Picture Size

Block Setting >

Off

Closed Caption

Backlight Bright

Sleep Timer 0 minutes Sleep Timer 0 minutes

15 minutes

0 minutes

30 minutes

45 minutes

60 minutes

120 minutes

STW X

SLEEP

MENU/

ENTER

33

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Adjusting the sound

Muting the sound

Press MUTE to temporarily turn off the sound. While the

sound is off, the screen will display " " in the upper right

corner.

To restore the sound, press MUTE again.

Selecting stereo/SAP broadcasts

The multi-channel TV sound (MTS) feature allows you to

listen to high-fidelity stereo sound while watching TV. MTS

can also transmit a second audio program (SAP) containing a

second language, music, or other audio information (when

provided by individual stations).

When the TV receives a stereo or SAP broadcast, the word

"ST.SAP", "Stereo" or "SAP" appears on-screen every time

the TV is turned on, the channel is changed, or DISPLAY is

pressed.

When the TV is in VIDEO1, VIDEO2, or PC mode, the options

for MTS feature are L+R, L+L, R+R. Your selection decides

from which speaker the audio is output.

To listen to different sound types:

1. Press MENU/ENTER, and then press W or X until the

Audio menu appears.

2. Press S or T to highlight MTS.

3. Press W or X to select Stereo, SAP, or Mono.

You can leave your TV in Stereo mode because it will

automatically output the type of sound being broadcast

(stereo or monaural).

If the stereo sound is noisy, select Mono to reduce the

noise.

If you select SAP, You will hear the station's second

audio program (if available) from the speakers, while

viewing the original program's picture.

Note:

The operation methods mentioned above can also be applied when the

TV is in VIDEO1, VIDEO2, or PC mode.

Audio

Balance

AVL

0

Off

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MENU/ENTER EXIT

MTS Stereo

Audio

Balance

AVL

0

Off

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MTS Stereo

MENU/ENTER EXIT

MUTE

MENU/

ENTER

STW X

34

Using the TV's

features

Selecting the sound mode

You can select your desired sound type from five sound

modes: Flat, Hall, Theater, News, or Memory.

To select the sound mode:

1. Press MENU/ENTER, and then press W or X until the

Audio menu appears.

2. Press T or S to highlight Sound Mode.

3. Press W or X to select the mode you prefer.

Note:

If you select one of the factory-set audio

modes (Flat, Hall, Theater, or News) and

then change a sound quality setting (for

example, increase the bass), the sound

mode automatically change to Memory

mode.

Mode Sound Quality

Flat

Hall

Theater

News

Memory

flat sound (factory setting)

a concert hall filled with a rich warm sound

(factory setting)

a movie theater filled with a dynamic sound

(factory setting)

news/dialogue (factory setting)

your personal preference

Adjusting the sound quality

You can change the quality of your TV's sound by adjusting

the bass, treble, and balance.

To adjust the sound balance:

1. Press MENU/ENTER, and then press W or X until the

Audio menu appears.

2. Press S or T to highlight Balance.

3. Press W or X to adjust the level.

•W makes the sound quality weaker or increases the

balance in the left channel, depending on the item

selected.

•X makes the sound quality stronger or increases the

balance in the right channel, depending on the item

selected.

Audio

Balance

AVL

0

Off

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MENU/ENTER EXIT

MTS Stereo

Audio

Balance

AVL

0

Off

Audio Advanced Setting >

Speaker Out On

MTS Stereo

MENU/ENTER EXIT

Sound Mode Flat

STW X

MENU/

ENTER

Audio

Balance

AVL

0

Off

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MENU/ENTER EXIT

MTS Stereo

Audio

AVL Off

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MTS Stereo

MENU/ENTER EXIT

Balance 0

35

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

To adjust the sound bass and treble:

4. Press T to highlight Audio Advanced Setting >.

5. Press X to display the Audio Advanced Setting page.

6. Press S or T to highlight one of the items (Treble, Mid

Treble, Middle,Mid Bass, and Bass) you want to adjust.

7. Press W or X to adjust the level.

The sound qualities you adjusted in the Audio Advanced

Setting page can be saved in the Memory mode.

To reset the audio settings:

8. Press T to highlight Audio Reset and press MENU/

ENTER to return all of the audio settings to the default

values of Flat.

Using the AVL

(Automatic Volume Leveler) feature

When the signal source is changed, the AVL feature limits the

highest volume level to prevent extreme changes in volume

(for example, to prevent the sudden increase in volume that

often happens when a TV program switches to a

commercial).

To turn on the AVL feature:

1. Press MENU/ENTER, and then press W or X until the

Audio menu appears.

2. Press S or T to highlight AVL.

3. Press W or X to select On.

To turn off the AVL feature:

Select Off in step 3 above.

Using the Speaker Out feature

Be sure you have correctly connected your TV to an external

audio system, if you want to activate the Speaker Out

function. For connection method, refer to "Connecting an

audio system" on page 15.

To use the Speaker Out function:

1. In the Audio menu, press S or

T to highlight Speaker Out.

2. Press W or X to select On.

Audio

Balance

AVL

0

Off

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MENU/ENTER EXIT

MTS Stereo

Audio

Audio Advanced Setting >

Sound Mode Flat

Speaker Out On

MTS Stereo

MENU/ENTER EXIT

Balance 0

AVL Off

Audio

Audio Advanced Setting >

Sound Mode Flat

MTS Stereo

MENU/ENTER EXIT

Balance 0

AVL Off

OnSpeaker Out

STW X

MENU/

ENTER

Audio Advanced Setting

Mid Bass

Mid Treble 0

0

0

0

Bass

MENU/ENTER EXIT

To adjust the sound bass and treble:

Step 4–6

Audio

AVL Off

Sound Mode Flat

Speaker Out On

MTS Stereo

MENU/ENTER EXIT

Balance 0

Audio Advanced Setting >

Middle

0Treble

Audio Reset

Selection W Pressing X

Treble

Mid Treble

Middle

Mid Bass

Bass

weaker

weaker

weaker

weaker

weaker

stronger

stronger

stronger

stronger

stronger

36

Using the TV's

features

Using the PC setting feature

You can adjust the horizontal/vertical picture position,

frequency (to minimize vertical stripes on the screen), and

phase (to remove horizontal noise and sharpen the picture).

You can auto-configure or set these settings manually.

1. Confirm a PC is connected (see "Connecting a personal

computer (PC)" on page 16).

2. Repeatedly press INPUT on the remote control or on the

TV side panel to select PC input mode. (See "Selecting

the video input source" on page 26.)

3. Press MENU/ENTER, and then press W or X until the PC

Setting menu appears.

4. To automatically adjust the settings, press T to highlight

Auto and then press MENU/ENTER.

To manually make the appropriate adjustments to other

items, press T to highlight the item to be set and then

press W or X.

•Auto

Automatically adjusts the screen position, frequency, and

phase. (The displayed image will disappear for a few

seconds while auto-configuration is in progress.)

• Frequency

Minimizes any vertical bars or stripes appearing on the

screen background. The adjustable range may vary

depending on the input mode.

•Phase

Reduces (or minimizes) any horizontal noise and clears

up or sharpens the character images. The adjustable

range may vary depending on the input mode.

• H. Position/V. Position

Adjusts picture left/right and up/down. The adjustable

range may vary depending on the input mode.

PC Setting

Frequency

Phase

H. Position

V. P osit ion

0

0

Auto

MENU/ENTER EXIT

PC Setting

Frequency

Phase

H. Position

V. P osit ion

0

0

Auto

MENU/ENTER EXIT

STW X

MENU/

ENTER

INPUT

TV side panel

INPUT

37

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Using the Panel Lock feature

1. Press MENU/ENTER, and then press W or X until the

Special menu appears.

2. Press S or T to highlight Block Setting >. Press X to

enter the Block Setting page.

• If you already set a password, enter your four-digit

password.

• If you have not created a password, the TV is initially

set up with the password "0000".

• If you cannot remember your password, press "7777".

3. Press S or T to highlight Panel

Lock. Press W or X to select On

(Lock) or Off (Unlock).

Displaying on-screen information

Press DISPLAY to display the following information on-

screen:

• Channel number or Video mode selected

• Stereo or SAP audio status

Understanding the last mode memory feature

If the power is cut off while you are viewing the TV, the Last

Mode Memory feature turns on the TV automatically when the

power is resupplied.

If the power is going to be off for a long time and you are

going to be away from your TV, unplug the power cord to

prevent the TV from turning on in your absence.

Note:

With the panel locked, you can

prevent your TV settings from being

changed accidentally (by children, for

example).

When the Panel Lock is on, no control

buttons on the TV side panel will

operate except POWER.

Special

Language English

4:3

Off

Bright

Picture Size

Closed Caption

Backlight

Block Setting >

MENU/ENTER EXIT

Sleep Timer 0 minutes Special

Language English

Off

Bright

Closed Caption

Backlight

MENU/ENTER EXIT

4:3Picture Size

Block Setting >

Sleep Timer 0 minutes Block Setting

Enter Password: - - - -

Change Password >

V-Chip Blocking Setting >

Panel Lock Off

: Please enter 4 characters password

Block Setting

Change Password >

V-Chip Blocking Setting

Panel Lock Off

Enter Password: - - - -

MENU/ENTER EXIT

STW X

MENU/

ENTER

DISPLAY

Number

38

Appendix

*E-EDID = Enhanced-Extended Display Identification

Appendix

Specifications

• This model complies with the specifications listed below.

• Designs and specifications are subject to change without notice.

• This model may not be compatible with features and/or specifications that may be added in the

future.

WARNING: RISK OF ELECTRIC SHOCK!

Never attempt to service the TV yourself. Opening and removing the covers may expose you to

dangerous voltage or other hazards. Refer all servicing to a Toshiba Authorized Service Center.

Television System

NTSC standard

Channel Coverage

VHF: 2 through 13

UHF: 14 through 69

Cable TV: Mid band (A-8 through A-1, A through I)

Super band (J through W)

Hyper band (AA through ZZ, AAA, BBB)

Ultra band (65 through 94, 100 through

125)

Power Source

120 V AC, 60 Hz

Power Consumption

70 W

< 1 W in standby mode

Audio Power

2 W + 2 W

Video/Audio Terminals

S-VIDEO INPUT

Y: 1 V(p-p), 75 ohms, negative sync.

C: 0.286 V(p-p) (burst signal), 75 ohms

VIDEO/AUDIO INPUT

VIDEO: 1 V(p-p), 75 ohms, negative sync.

AUDIO: 400 mV(rms) (30% modulation

equivalent, 22k ohms or greater)

ColorStream® (Component video) INPUT

Y: 1V(p-p), 75 ohms

PR: 0.7 V(p-p), 75 ohms

PB: 0.7 V(p-p), 75 ohms

AUDIO: 500 mV(rms), 47k ohms or greater

Suggested resolutions: 1080i, 480p, 480i, 720p

AUDIO OUTPUT

500 mV(rms) (30% modulation equivalent, 2.2k

ohms or less)

HEADPHONE jack

3.5 mm stereo mini jack

PC INPUT

15-pin D-sub Analog RGB

PC AUDIO INPUT

3.5 mm stereo mini jack

Dimensions (Including TV stand)

Width: 18-5/8 inches (474 mm)

Height: 18-5/16 inches (465 mm)

Depth: 9-5/16 inches (236 mm)

Mass (weight)

18.5 lbs (8.4 kg)

Operating conditions

Temperature: 32°F–95°F (0°C–35°C)

Humidity: 20 – 80% (no moisture condensation)

39

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Troubleshooting

Before calling a service technician, please check the following table for a possible cause of the

symptom and some solutions.

Symptom Solution

TV will not turn on • Make sure the power cord is plugged in, then

press POWER.

• The remote control batteries may be dead.

Replace the batteries.

No picture, no sound • Check the antenna/cable connections.

No sound, picture OK • The sound may be muted. Press VOL + –.

• The station may have broadcast difficulties. Try

another channel.

• Make sure the MTS feature is set properly.

Poor picture, sound OK • Check the antenna connections.

• The station may have broadcast difficulties. Try

another channel.

• Adjust the Picture menu.

Poor reception of broadcast channels • The station may have broadcast difficulties. Try

another channel.

• Check the antenna connections.

Black box appears on the screen • The Closed Caption feature may be set to one of

the Text modes (Text1, Text2, Text3, or Text4).

Turn closed captioning Off.

Unable to select a certain channel • The channel may be erased with the manual

programming feature.

Multiple images • The station may have broadcast difficulties. Try

another channel.

• Antenna reception may be poor. Use a highly

directional outdoor antenna.

Poor color or no color • The station may have broadcast difficulties. Try

another channel.

• Adjust the Tint and/or Color in the Picture menu.

No stereo or SAP sound from a known MTS

broadcast

• Make sure the MTS feature is set properly.

The side panel buttons do not operate • Check the Panel Lock feature.

The remote control does not operate • Remove all obstructions between the remote

control and the remote control sensor in the TV.

• The remote control batteries may be dead.

Replace the batteries.

40

Appendix

Limited United States Warranty

for 20" LCD Television

Toshiba America Consumer Products, L.L.C. ("TACP") makes the

following limited warranties to original consumers in the United

States. THESE LIMITED WARRANTIES EXTEND TO THE

ORIGINAL CONSUMER PURCHASER OR ANY PERSON

RECEIVING THIS LCD PRODUCT AS A GIFT FROM THE

ORIGINAL CONSUMER PURCHASER AND TO NO OTHER

PURCHASER OR TRANSFEREE.

LCD PRODUCTS PURCHASED IN THE U.S.A. AND USED

ANYWHERE OUTSIDE OF THE U.S.A., INCLUDING, WITHOUT

LIMITATION, CANADA AND MEXICO, ARE NOT COVERED BY

THESE WARRANTIES.

LCD PRODUCTS PURCHASED ANYWHERE OUTSIDE OF

THE U.S.A., INCLUDING, WITHOUT LIMITATION, CANADA

AND MEXICO, AND USED IN THE U.S.A., ARE NOT COVERED

BY THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labor

TACP warrants this LCD Product and its parts against defects in

materials or workmanship for a period of one (1) year after the

date of original retail purchase. DURING THIS PERIOD, TACP

WILL, AT TACP'S OPTION, REPAIR OR REPLACE A

DEFECTIVE PART WITH A NEW OR REFURBISHED PART

WITHOUT CHARGE TO YOU FOR PARTS OR LABOR.

Rental Units

The warranty for LCD Product rental units begins on the date of

the first rental or thirty (30) days after the date of shipment to the

rental firm, whichever comes first.

Limited Warranty for Commercial Units

TACP warrants LCD Products that are sold and used for

commercial purposes as follows: all parts are warranted against

defects in materials or workmanship for a period of ninety (90)

days after the date of original retail purchase. DURING THIS

PERIOD, TACP WILL, AT TACP'S OPTION, REPAIR OR

REPLACE A DEFECTIVE PART WITH A NEW OR

REFURBISHED PART WITHOUT CHARGE TO YOU.

Owner's Manual and Product Registration Card

Read this owner's manual thoroughly before operating this LCD

Product.

Complete and mail the enclosed product registration card or

register your LCD Product online at www.tacp.toshiba.com/

service as soon as possible. By registering your LCD Product

you will enable TACP to bring you new products specifically

designed to meet your needs and help us to contact you in the

unlikely event a safety notification is required under the U.S.

Consumer Product Safety Act. Failure to complete and return the

product registration card does not diminish your warranty rights.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE

FOLLOWING CONDITIONS:

(1). You must retain your original bill of sale or provide other proof

of purchase.

(2). All warranty servicing of this LCD Product must be performed

by an Authorized TACP Service Station.

(3). The warranties from TACP are effective only if this LCD

Product is purchased and operated in the Continental U.S.A.

or Puerto Rico.

(4). Labor service charges for set installation, setup, adjustment

of customer controls, and installation or repair of antenna

systems are not covered by this warranty. Reception

problems caused by inadequate antenna systems,

misaligned satellite dishes, cable television distribution,

VCRs, DVD players/recorders, personal computer level

IEEE- 1394 devices, and any other connected signal source

device are your responsibility.

(5). Warranties extend only to defects in materials or

workmanship as limited above, and do not extend to any LCD

Product or parts that have been lost or discarded by you or to

damage to the LCD Product or parts caused by fires, misuse,

accident, Acts of God (such as lightning or fluctuations in

electric power), improper installation, improper maintenance,

or use in violation of instructions furnished by TACP; use or

malfunction through simultaneous use of this LCD Product

and connected equipment; or to units that have been modified

or had the serial number removed, altered, defaced, or

rendered illegible.

How to Obtain Warranty Service

If, after following all of the operating instructions in this manual

and reviewing the section entitled "Troubleshooting," you find that

service is needed:

(1). To find the nearest TACP Authorized Service Station, visit

TACP's website at www.tacp.toshiba.com/service or

contact TACP's Consumer Solution Center toll free at 1-800-

575-5469.

(2). You must present your original bill of sale or other proof of

purchase to the TACP Authorized Service Station. You must

deliver the entire LCD Product to a TACP Authorized Service

Station. You must pay for all transportation and insurance

charges for the LCD Product to and from the TACP

Authorized Service Station.

ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF

THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF

THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE

EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF

ANY STATE OF THE U.S.A. AS HEREBY LIMITED, THE

FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL

OTHER WARRANTIES, GUARANTEES, AGREEMENTS, AND

SIMILAR OBLIGATIONS OF TACP WITH RESPECT TO THE

REPAIR OR REPLACEMENT OF ANY PARTS. IN NO EVENT

SHALL TACP BE LIABLE FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,

LOST PROFITS, BUSINESS INTERRUPTION, OR

MODIFICATION OR ERASURE OF RECORDED DATA CAUSED

BY USE, MISUSE OR INABILITY TO USE THIS LCD

PRODUCT).

No person, agent, distributor, dealer, or company is authorized to

change, modify, or extend the terms of these warranties in any

manner whatsoever. The time within which an action must be

commenced to enforce any obligation of TACP arising under the

warranty or under any statute or law of the United States or any

state thereof is hereby limited to ninety (90) days from the date

you discover, or should have discovered, the defect. This

limitation does not apply to implied warranties arising under the

law of any state of the U.S.A.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND

YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY

FROM STATE TO STATE IN THE U.S.A. SOME STATES OF THE

U.S.A. DO NOT ALLOW LIMITATIONS ON THE DURATION OF

AN IMPLIED WARRANTY, WHEN AN ACTION MAY BE

BROUGHT, OR THE EXCLUSION OR LIMITATION OF

INCIDENTAL OR CONSEQUENTIAL DAMAGES. THEREFORE,

THE ABOVE PROVISIONS MAY NOT APPLY TO YOU UNDER

SUCH CIRCUMSTANCES.

For additional information, visit TACP's website:

www.tacp.toshiba.com

41

IntroductionConnecting your

TV

Using the remote

control

Setting up your

TV

Using the TV's

features

AppendixIndex

E

S

F

Limited Canada Warranty

for 20" LCD Television

Toshiba Canada Limited, ("TCL") makes the following limited

warranties to original consumers in Canada. THESE LIMITED

WARRANTIES EXTEND TO THE ORIGINAL CONSUMER

PURCHASER OR ANY PERSON RECEIVING THIS LCD

PRODUCT AS A GIFT FROM THE ORIGINAL CONSUMER

PURCHASER AND TO NO OTHER PURCHASER OR

TRANSFEREE.

LCD PRODUCTS PURCHASED IN CANADA AND USED

ANYWHERE OUTSIDE OF CANADA, INCLUDING, WITHOUT

LIMITATION, THE U.S.A. AND MEXICO, ARE NOT

COVERED BY THESE WARRANTIES.

LCD PRODUCTS PURCHASED ANYWHERE OUTSIDE OF

CANADA, INCLUDING, WITHOUT LIMITATION, THE U.S.A. AND

MEXICO, AND USED IN CANADA ARE NOT COVERED BY

THESE WARRANTIES.

Limited One (1) Year Warranty on Parts and Labour

TCL warrants this LCD Product and its parts against defects in

materials or workmanship for a period of one (1) year after the date

of original retail purchase. DURING THIS PERIOD, TCL WILL, AT

TCL'S OPTION, REPAIR OR REPLACE A DEFECTIVE PART

WITH A NEW OR REFURBISHED PART WITHOUT CHARGE TO

YOU. YOU MUST DELIVER THE ENTIRE TELEVISION TO AN

AUTHORIZED TCL SERVICE DEPOT. YOU MUST PAY FOR ALL

TRANSPORTATION AND INSURANCE CHARGES FOR THE

TELEVISION TO AND FROM THE SERVICE DEPOT.

Rental Units

The warranty for LCD Product rental units begins on the date of the

first rental or thirty (30) days after the date of shipment to the rental

firm, whichever comes first.

Limited Warranty for Commercial Units

TCL warrants LCD Products that are sold and used for commercial

purposes as follows: all parts are warranted against defects in

materials or workmanship for a period of ninety (90) days after the

date of original retail purchase. DURING THIS

PERIOD, TCL WILL, AT TCL'S OPTION, REPAIR OR REPLACE A

DEFECTIVE PART WITH A NEW OR REFURBISHED PART

WITHOUT CHARGE TO YOU. YOU MUST DELIVER THE

ENTIRE TELEVISION TO AN AUTHORIZED TCL SERVICE

DEPOT. YOU MUST PAY FOR ALL TRANSPORTATION AND

INSURANCE CHARGES FOR THE TELEVISION TO AND FROM

THE SERVICE DEPOT.

Owner's Manual and Product Registration

Read this owner's manual thoroughly before operating this LCD

Product.

Register your LCD Product online at www.toshiba.ca as soon as

possible. By registering your LCD Product you will enable TCL to

bring you new products specifically designed to meet your needs

and help us to contact you in the unlikely event a safety notification

is required. Failure to register your LCD Product does not diminish

your warranty rights.

Your Responsibility

THE ABOVE WARRANTIES ARE SUBJECT TO THE

FOLLOWING CONDITIONS:

(1). You must retain your original bill of sale or provide other proof

of purchase.

(2). All warranty servicing of this LCD Product must be made by an

Authorized TCL Service Depot.

(3). The warranties from TCL are effective only if this LCD Product

is purchased in Canada from an authorized TCL dealer and

operated in Canada.

(4). Labour service charges for set installation, setup, adjustment

of customer controls, and installation or repair of antenna

systems are not covered by this warranty. Reception problems

caused by inadequate antenna systems, misaligned satellite

dishes, cable television distribution, VCRs, DVD players/

recorders, personal computer level IEEE-1394 devices, and

any other connected signal source device are your

responsibility.

(5). Warranties extend only to defects in materials or workmanship

as limited above, and do not extend to any LCD Product or

parts that have been lost or discarded by you or to damage to

the LCD Product or parts caused by fires, misuse, accident,

Acts of God (such as lightning or fluctuations in electric power),

improper installation, improper maintenance, or use in violation

of instructions furnished by TCL; use or malfunction through

simultaneous use of this LCD Product and connected

equipment; or to units that have been modified or had the

serial number removed, altered, defaced, or rendered illegible.

How to Obtain Warranty Service

If, after following all of the operating instructions in this manual and

reviewing the section entitled "Troubleshooting," you find that

service is needed:

(1). To find the nearest TCL Authorized Service Depot, visit TCL's

web site at www.toshiba.ca.

(2). You must include the original bill of sale (or a copy thereof) or

other proof of purchase along with the entire LCD Product to

the Authorized Service Depot. You are responsible for all

inbound transportation and insurance charges for the LCD

Product to the Authorized Service Depot.

ALL WARRANTIES IMPLIED BY THE LAW OF ANY PROVINCE

OF CANADA, INCLUDING THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION OF

THE LIMITED WARRANTIES SET FORTH ABOVE. WITH THE

EXCEPTION OF ANY WARRANTIES IMPLIED BY THE LAW OF

ANY PROVINCE OF CANADA AS HEREBY LIMITED, THE

FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL

OTHER WARRANTIES, GUARANTEES, AGREEMENTS, AND

SIMILAR OBLIGATIONS OF TCL WITH RESPECT TO THE

REPAIR OR REPLACEMENT OF ANY PARTS. IN NO EVENT

SHALL TCL BE LIABLE FOR CONSEQUENTIAL OR

INCIDENTAL DAMAGES (INCLUDING, BUT NOT LIMITED TO,

LOST PROFITS, BUSINESS INTERRUPTION, OR

MODIFICATION OR ERASURE OF RECORDED DATA CAUSED

BY USE, MISUSE, OR INABILITY TO USE THIS LCD

PRODUCT).

No person, agent, distributor, dealer, or company is authorized to

change, modify, or extend the terms of these warranties in any

manner whatsoever. The time within which an action must be

commenced to enforce any obligation of TCL arising under the

warranty or under any law of Canada or any province thereof is

hereby limited to ninety (90) days from the date you discover, or

should have discovered, the defect. This limitation does not apply

to implied warranties arising under the law of any province of

Canada.

THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND

YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY

FROM PROVINCE TO PROVINCE IN CANADA. SOME

PROVINCES OF CANADA DO NOT ALLOW LIMITATIONS ON

THE DURATION OF AN IMPLIED WARRANTY, WHEN AN

ACTION MAY BE BROUGHT, OR THE EXCLUSION OR

LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES.

THEREFORE, THE ABOVE PROVISIONS MAY NOT APPLY TO

YOU UNDER SUCH CIRCUMSTANCES. [0305]

For additional information, visit TACP's website:

www.tacp.toshiba.com

42

Index

Index

A

A/V cables .....................................................10

Antenna cables .............................................10

Audio system connection ..............................15

AVL ...............................................................35

B

Back of the TV ................................................8

Blue screen ...................................................26

C

Cable clamper .................................................9

Cable converter box connection .............11, 12

Camcorder connection ..................................15

CBL/SAT button ............................................19

CH or CH buttons ..............................25

CH RTN/ENT button .....................................26

Channel Number buttons ..............................25

Channel programming

Add/Erase ...............................................25

Automatically programming ....................24

CLEAR ..........................................................20

Closed Caption .............................................31

ColorStream® .........................................13, 14

Component video cables ..............................10

D

DISPLAY button ......................................33, 37

DTV receiver connection ...............................14

DVD button ...................................................20

DVD connection ............................................13

DVD MENU button ........................................20

F

FAV ST button .............................................25

Favorite channels ..........................................25

FF button ...............................................19

Front of the TV ................................................8

I

INPUT button ................................................26

L

Language selection .......................................24

Last mode memory .......................................37

M

Menu system .................................................23

MTS ..............................................................33

MUTE button .................................................33

P

Panel Lock ....................................................37

PAUSE button ..........................................19

PC connection ...............................................16

PC settings ....................................................36

PIC SIZE button ............................................27

Picture adjustments

Picture mode ..........................................30

Picture quality ......................................... 30

Picture size selection .................................... 27

PLAY X button .............................................. 19

POWER button ............................................. 17

R

REC .............................................................. 19

Remote control

Battery installation .................................. 18

Learning about the buttons .................... 17

REW button ........................................... 19

S

SAP sound .................................................... 33

Set-top box ................................................... 14

SKIP/SEARCH button ..................... 20

Sleep timer ................................................... 32

Sound mode selection .................................. 34

Sound quality adjustments ........................... 34

Specifications ............................................... 38

Stereo sound ................................................ 33

STOP button ............................................ 19

S-video cable ................................................ 10

T

TOP MENU button ........................................ 20

Troubleshooting ............................................ 39

TV button ...................................................... 20

TV/VCR button ............................................. 19

V

V-Chip

Change Password .................................. 29

Moive Ratings ........................................ 29

Password ............................................... 29

USA TV Ratings ..................................... 29

VCR button ................................................... 19

VCR connection ............................................ 11

VOL button ................................................... 17

W

Warranty .................................................40, 41

HEAD OFFICE:82 TOTOWA ROAD, WAYNE, NEW JERSEY 07470, U.S.A.

NATIONAL SERVICE DIVISION:1420B TOSHIBA DRIVE, LEBANON, TN. 37087, U.S.A.

HEAD OFFICE/191 McNABB STREET MARKHAM, ONTARIO L3R 8H2, CANADA TEL: (905) 470-5400

SERVICE CENTERS:

TORONTO: 191 McNABB STREET MARKHAM, ONTARIO L3R 8H2, CANADA TEL: (905) 470-5400

MONTREAL: 18050 TRANS CANADA, KIRKLAND, QUEBEC, H9J-4A1, CANADA TEL:(514)390-7766

VANCOUVER: 22171 FRASERWOOD WAY, RICHMOND, B.C. V6W 1J5, CANADA TEL: (604) 303-2500

ColorStream is the registered trademark of Toshiba America Consumer Products, L.L.C.
