42SL417U
46SL417U
55SL417U
Integrated High Definition
LCD Television
© 2011 TOSHIBA CORPORATION
All Rights Reserved
Owner’s Record
The model number and serial number are on the back
and side of your TV. Record these numbers in the
spaces below. Refer to these numbers whenever you
communicate with your Toshiba dealer about this TV.
www.support.toshiba.com
For an overview of steps for setting up your new TV, see page 11.
Note: To display a High Definition picture, the TV must be receiving a
High Definition signal (such as an over-the-air High Definition TV
broadcast, a High Definition digital cable program, or a High
Definition digital satellite program). For details, please contact your
TV antenna installer, cable provider, or satellite provider.
VX1A00205000
TD/M
Model number:
Serial number:
2
Dear Customer,
Thank you for purchasing this Toshiba LCD TV. This
manual will help you use the many exciting features of your
new LCD TV. Before operating your LCD TV, please
read this manual completely, and keep it nearby for
future reference.
WARNING
To prevent injury, this apparatus must be securely
attached to the floor/wall in accordance with the
installation instructions. See item 26 on p. 4 and
instructions on p. 5.
If television is not positioned in a sufficiently stable
location, it can be potentially hazardous due to falling.
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer’s
attention to Article 820-40 of the U.S. NEC, which provides
guidelines for proper grounding and, in particular, specifies
that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry
as practical. For additional antenna grounding information,
see items 34 and 35 on p. 4.
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
WARNING: If you decide to wall mount this
television, always use a UL Listed wall bracket
appropriate for the size and weight of this television.
The use of any wall bracket other than a UL Listed wall
bracket appropriate for the size and weight of this
television for wall mounting this television could result
in serious bodily injury and/or property damage. See
“Removing the Pedestal Stand” (- p. 6).
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Congratulations on your purchase! As you enjoy your
new product, please keep these safety tips in mind:
The Issue
• The home theater entertainment experience is a growing trend
and larger flat panel displays are popular purchases. However,
flat panel displays are not always supported on the proper stands
or installed according to the manufacturer’s recommendations.
• Flat panel displays that are inappropriately
situated on dressers, bookcases,
shelves, desks, speakers, chests or
carts may fall over and cause
injury.
TOSHIBA Cares!
• The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
Tune Into Safety
•
One size does NOT fit all. Follow the manufacturer’s recommendations
for the safe installation and use of your flat panel display.
• Carefully read and understand all enclosed instructions for
proper use of this product.
• Don’t allow children to climb on or play with furniture and
television sets.
• Don’t place flat panel displays on furniture
that can easily be used as steps, such
as a chest of drawers.
• Remember that children can
become excited while watching a
program, especially on a “larger
than life” flat panel display. Care
should be taken to place or install
the display where it cannot be
pushed, pulled over, or knocked down.
• Care should be taken to route all cords and
cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
Wall Mounting: If you decide to wall mount your
flat panel display, always:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory (such
as UL, CSA, ETL).
• Follow all instructions supplied by the display and wall mount
manufacturers.
• If you have any doubts about your ability to safely install your
flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction. If you
are unsure, contact a professional installer.
• A minimum of two people are
required for installation. Flat panel
displays can be heavy.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat
Panel Display
3
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of
the polarized or grounding type
plug. A polarized plug has two blades
with one wider than the other.
A grounding type plug has two blades
and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or
when unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
Additional Safety Precautions
14a) CAUTION: If the TV is dropped and the cabinet or
enclosure surface has been damaged or the TV does
not operate normally, take the following precautions:
• ALWAYS turn off the TV and unplug the power cord
to avoid possible electric shock or fire.
• NEVER allow your body to come in contact with any
broken glass or liquid from the damaged television.
The LCD panel inside the TV contains glass and a
toxic liquid. If the liquid comes in contact with your
mouth or eyes, or your skin is cut by broken glass,
rinse the affected area thoroughly with water and
consult your doctor.
• ALWAYS contact a service technician to inspect the
TV any time it has been damaged or dropped.
15) CAUTION:
• To reduce the risk of electric shock, do not use the
polarized plug with an extension cord, receptacle, or
other outlet unless the blades can be inserted
completely to prevent blade exposure.
• To prevent electric shock, match wide blade of plug
to wide slot; fully insert.
16) CAUTION:
Do not let children swallow the product or play with the
plastic bag. Keep the product and the plastic bag out of
the reach of children.
17) CAUTION:
Do not let water or other liquids come into contact with
the product, as it may result in damage.
18) WARNING:
• To prevent the spread of fire, keep candles or other
open flames away from this product at all times.
• Keep the product away from direct sunlight, fire or a
heat source such as a heater. This may reduce the
product lifetime or result in fire.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and heed
all warnings when installing your TV:
19) WARNING: NEVER expose batteries to
excessive heat such as sunshine, fire, or
the like.
20) ALWAYS plug the product into an outlet that is located in
such a manner that it can be easily unplugged in case the
product requires service.
21) NEVER route the product’s power cord inside a wall or
similar enclosed area.
22) Never modify this equipment. Changes or modifications
may void: a) the warranty, and b) the user’s authority to
operate this equipment under the rules of the Federal
Communications Commission.
23) DANGER: RISK OF SERIOUS
PERSONAL INJURY,
DEATH, OR EQUIPMENT
DAMAGE!
Never place the TV on an unstable cart,
stand, or table. The TV may fall, causing
serious personal injury, death, or serious damage to the
TV.
24) To avoid damage to this product, never place or store the
TV in direct sunlight; hot, humid areas; or areas subject to
excessive dust or vibration.
25) Never place the TV in an unstabilized location such as on
a shaky table, incline or location subject to vibration.
• Only use cabinets fit for such purpose or stands
recommended by the manufacturer of the TV.
• Only use furniture that can safely support the TV.
Wide blade
4
• Ensure that the TV is not hanging over the edge of the
supporting furniture.
• Never place the TV on tall furniture (for example,
cupboards or bookcases) without anchoring both the
furniture and the TV to a suitable support
• Never stand the TV on cloth or other material placed
between the TV and supporting furniture.
The TV may drop or fall off which may cause an injury or
damage.
26) Always place the TV on the floor or a sturdy, level, stable
surface that can support the weight of the unit. In order to
maintain stability and prevent the TV from falling over,
secure the TV by either of the methods below:
• Secure the TV with the supplied mounting screw.
(recommended)
Place the TV on a sturdy surface that has a sufficient
thickness and screw the unit on the surface securely
by using the mounting screw and the fall-prevention
screw hole.
• Secure the TV with the securement clip and a sturdy
strap from the hooks on the rear of the TV pedestal
to a wall stud, pillar, or other immovable structure.
Make sure the strap is tight, secure, and parallel to
the floor.
27) Never stand or climb on the TV.
• Educate children about the dangers
of climbing on furniture to reach the
TV or its controls.
Be especially careful in households
with children to prevent them from
climbing on top of the TV. It may move,
fall over, break, become damaged or cause an injury.
28) The apparatus shall not be exposed to dripping or
splashing, and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
29) Never block or cover the slots or openings in the TV
cabinet back, bottom, and sides. Never place the TV:
• on a bed, sofa, rug, or similar
surface;
• too close to drapes, curtains,
or walls; or
• in a confined space such as a
bookcase, built-in cabinet, or
any other place with poor
ventilation.
The slots and openings are provided to protect the TV
from overheating and to help maintain reliable operation
of the TV. Leave a space of at least 4 (four) inches
around the TV.
30) Always place the back of the television at least 4 (four)
inches away from any vertical surface (such as a wall) to
allow proper ventilation.
31) Never allow anything to rest on or roll over the power
cord, and never place the TV where the power cord is
subject to wear or abuse.
32) Never overload wall outlets and extension cords.
33) Always operate this equipment from a 120 VAC, 60 Hz
power source only.
34) Always make sure the antenna system is properly
grounded to provide adequate protection against voltage
surges and built-up static charges (see Section 810 of the
National Electric Code).
35)
• Use extreme care to make sure you are never in a
position where your body (or any item you are in
contact with, such as a ladder or screwdriver) can
accidentally touch overhead power lines. Never
locate the antenna near overhead power lines or
other electrical circuits.
• Never attempt to install any of the following during
lightning activity: a) an antenna system; or b) cables,
wires, or any home theater component connected to
an antenna or phone system.
Care
For better performance and safer operation of your TOSHIBA
TV, follow these recommendations and precautions:
36) If you use the TV in a room whose temperature is 32 °F
(0 °C) or below, the picture brightness may vary until the
LCD warms up. This is not a sign of malfunction.
37) Always unplug the TV before
cleaning. When cleaning your
TV, please first remove any dirt or
dust from the surface. Gently
wipe the cabinet and the display
panel surface (the TV screen)
with a dry, soft cloth (cotton, flannel, etc.). Harsh rubbing
or use of a dirty or stiff cloth will scratch the TV surface.
Avoid contact with alcohol, thinner, benzene, acidic or
alkaline solvent cleaners, abrasive cleaners, or chemical
cloths, which may damage the TV surface. Never spray
TV back
Mounting screw
(supplied)
Screw hole
TV side TV top
4"
min.
Securement
Clip (supplied)
Sturdy strap (as short as possible)
Hooks
Securement
Clip (supplied)
Ground clamp
Antenna discharge unit
(NEC Section 810-20)
Grounding conductors
(NEC Section 810-21)
Power service grounding
electrode system (NEC Art 250 Part-H)
Ground clamps
Antenna lead-in wire
Electric service equipment
DANGER: RISK OF SERIOUS
PERSONAL INJURY OR DEATH!
5
volatile compounds such as insecticide on the TV
surface. Such products may damage or discolor the TV.
38) Never hit, press, or place anything on the back cover.
These actions will damage internal parts.
39)
Never spill liquids or push objects of any kind into the TV
cabinet slots.
40) During a lightning storm, do not touch the connecting
cables or TV set.
41) For added protection of your TV from lightning and power
surges, always unplug the power cord and disconnect
the antenna from the TV if you leave the TV unattended or
unused for long periods of time.
42) ALWAYS unplug the TV to completely disconnect from
main power. When the TV is turned off using the on/off
switch, it is not completely disconnected from power and
a minute amount of current is still consumed.
43) During normal use, the TV may make occasional
snapping or popping sounds. This is normal, especially
when the unit is being turned on or off. If these sounds
become frequent or continuous, unplug the power cord
and contact a Toshiba Authorized Service Provider.
44) WARNING: RISK OF
SERIOUS PERSONAL
INJURY OR EQUIPMENT
DAMAGE!
Never strike the screen with a sharp
or heavy object.
45) • The LCD screen of this product can be damaged by
ultraviolet radiation from the sun. When selecting a
location for the television, avoid locations where the
screen may be exposed to direct sunlight, such as in
front of a window.
• Never touch, press, or place anything on the LCD
screen. These actions will damage the LCD screen. If
you need to clean the LCD screen, follow the
instructions in item 37 on p. 4.
Service
46)
Never attempt to service the TV yourself. Opening and
removing the covers may expose you to dangerous
voltage or other hazards. Failure to follow this
WARNING may result in death or serious injury. Refer all
servicing not specified in this manual to a Toshiba
Authorized Service Provider.
47) If you have the TV serviced:
• Ask the service technician to use only replacement
parts specified by the manufacturer.
• Upon completion of service, ask the service
technician to perform routine safety checks to
determine that the TV is in safe operating condition.
Choosing a location for your LCD TV
To Display your LCD TV on the included Pedestal
Stand:
Observe the following safety precautions:
1) Read and Follow the pedestal assembly instructions
included with the pedestal.
CAUTION: Before beginning pedestal assembly,
carefully lay the front of the LCD Panel face down on a
flat, cushioned surface such as a quilt or blanket.
Leave the bottom of the unit protruding over the edge
of the surface and assemble the pedestal as indicated
below.
Note: Extreme care should always be used when
attaching the pedestal stand to avoid damage to the
LCD panel.
2) Place the TV on a sturdy, level surface that can support
the weight of the TV.
3) Be sure to secure the TV to a wall stud, pillar, surface,
or other immovable structure. To secure the TV in this
manner: (1) attach the provided securement clip to an
immovable structure, then (2) pass a sturdy strap
through the securement clip and attach each end to
the hooks located on the back of the TV. Be sure to
leave at least 4 inches between the TV and the wall or
similar structure for ventilation. See item 26, p. 4 for
additional details.
To Display your LCD TV using a Wall Bracket:
If you decide to wall mount your LCD TV, always use a UL
Listed wall bracket appropriate for the size and weight of
the LCD TV (- p. 2) :
CAUTION:
1. Two people are required for installation.
2. Never use the screws attached to the TV.
3. To install a wall-mount from another manufacturer, use
the enclosed SPACERS.
1) Unplug and remove any cables and/or other
component connectors from the rear of the TV.
2) Carefully lay the front of the unit face down on a flat,
cushioned surface such as a quilt or blanket.
3) Follow the instructions provided with your wall
bracket. Before proceeding, make sure the
appropriate bracket(s) are attached to the wall and the
back of the TV as described in the instructions
provided with the wall bracket.
4) Make sure to place the spacers provided with the TV
between the bracket and the back of the TV.
5) Always use the screws supplied or recommended by
the wall mount manufacturer.
WARNING:
RISK OF ELECTRIC SHOCK!
WARNING:
RISK OF ELECTRIC SHOCK!
6
Removing the Pedestal Stand
1) Carefully lay the front of the unit face down on a flat,
cushioned surface such as a quilt or blanket. Leave the
stand protruding over the edge of the surface.
Note: Extreme care should always be used when
removing the pedestal stand to avoid damage to the
LCD panel.
2) Remove the seven screws.
3) Once you have removed all
seven screws holding the
pedestal stand in place, remove
the pedestal stand from the TV
by sliding the pedestal stand
away from the TV.
USA - Federal Communications
Commission Statement
FCC Compliance Statement
Toshiba television models 42SL417U, 46SL417U, and
55SL417U comply with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
The party responsible for compliance to these rules is:
Toshiba America Information Systems, Inc.
9740 Irvine Blvd., Irvine, CA 92618.
Ph: 1-800-631-3811
Interference: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
Wireless Radio
For product available in the USA/Canada market, only
channel 1–11 can be operated. Selection of other channels is
not possible.
The device could automatically discontinue transmission
in case of absence of information to transmit, or operational
failure. Note that this is not intended to prohibit
transmission of control or signaling information or the use
of repetitive codes where required by the technology.
If this device is going to be operated in 5.15–5.25GHz
frequency range, then it is restricted to an indoor
environment only.
Important: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or
transmitter.
FCC Radiation Exposure Statement: This equipment
complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be
installed and operated with minimum distance 20 cm
between the radiator & your body.
1. Remove the four screws.
(Do not use these for attaching
a wall bracket.)
2. Place the four spacers (supplied).
Screw
Wall bracket
Spacer (supplied)
TV back panel
Seven screws
7
Canada - Industry Canada Statement
This device complies with RSS-210.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation
of the device.
This device and its antenna(s) must not be co-located or
operating in conjunction with any other antenna or
transmitter.
Wireless Radio
For product available in the USA/Canada market, only
channel 1–11 can be operated. Selection of other channels is
not possible.
The device could automatically discontinue transmission
in case of absence of information to transmit, or operational
failure. Note that this is not intended to prohibit
transmission of control or signaling information or the use
of repetitive codes where required by the technology.
Important: Any changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate this equipment.
IMPORTANT NOTE:
IC Radiation Exposure Statement: This equipment
complies with IC RSS-102 radiation exposure limits set
forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance
20 cm between the radiator & your body.
ENERGY STAR® User Information
ENERGY STAR User Information Statement: the factory
default settings of this television meet ENERGY STAR®
requirements. Enabling or changing certain features and
functionality (e.g. Picture Settings, Auto Brightness Sensor)
may increase energy consumption, possibly beyond the
limits required for ENERGY STAR qualification.
To ensure your television is operating at optimal energy
efficiency, select [Home] mode during initial activation. To
return to [Home] mode settings, select [AutoView] picture
mode, and set Auto Brightness Sensor to [On] mode.
[AutoView] mode is recommended for normal home use.
For more information, see p. 48.
Important notes about your LCD TV
The following symptoms are technical limitations of
LCD Display technology and are not an indication of
malfunction; therefore, Toshiba is not responsible for
perceived issues resulting from these symptoms.
1) An afterimage (ghost) may appear on the screen if a
fixed, non-moving image is displayed for a long period
of time. The afterimage is not permanent and will
disappear in a short period of time.
2) The LCD panel contained in this TV is manufactured
using an extremely high level of precision technology;
however, there may be an occasional pixel (dot of light)
that does not operate properly (does not light, remains
constantly lit, etc.). This is a structural property of LCD
technology, is not a sign of malfunction, and is not
covered under your warranty. Such pixels are not
visible when the picture is viewed from a normal
viewing distance.
Note: Interactive video games that involve shooting a
“gun” type of joystick at an on-screen target may not work
with this TV.
ENERGY STAR® qualified TV. Products that
earn the ENERGY STAR prevent green house
gas emissions by meeting strict guidelines set
by the U.S. Environmental Protection Agency.
ENERGY STAR and the ENERGY STAR mark
are registered U.S. marks.
8
Trademark Information
• Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are registered
trademarks of Dolby Laboratories.
• Audyssey Dynamic Volume® controls volume
levels to eliminate loud spikes and raise soft
dialog for more enjoyable television and movie
viewing. Audyssey EQ® provides clear,
accurate and natural sound right out of the
box. Together, these technologies ensure you
enjoy your audio experience as much as your
video.
• Manufactured under license from Audyssey Laboratories.
U.S. and foreign patents pending. Audyssey EQ and
Audyssey Dynamic Volume are registered trademarks of
Audyssey Laboratories.
• HDMI, the HDMI Logo, and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and
other countries.
• Blu-ray Disc™, Blu-ray™, and the logos are trademarks of
the Blu-ray Disc Association.
• INSTAPORT™ and INSTAPORT logo are trademarks of
Silicon Image, Inc. in the United States and other countries.
• MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
•DLNA
®, DLNA® Certification Logo, and DLNA CERTIFIED™
are registered trademarks, trademarks, service marks, or
certification marks of the Digital Living Network Alliance.
• VUDU is a trademark of VUDU, Inc .
• YouTube is a registered trademark of Google, Inc.
• Netflix is a registered trademark of Netflix, Inc.
• Yahoo! is a registered trademark of Yahoo! Inc.
• CinemaNow is a registered trademark of Best Buy, Inc.
• Pandora is a registered trademark of Pandora Media, Inc.
• Blockbuster is a registered trademark of Blockbuster, Inc.
• This product contains Adobe® Flash® Player software
under license from Adobe Systems Incorporated. Copyright
© 1995-2009 Adobe Systems Incorporated. All rights
reserved. Adobe and Flash are trademarks of Adobe
Systems Incorporated.
• This product contains technology subject to certain
intellectual property rights of Microsoft. Use or distribution
of this technology outside of this product is prohibited
without the appropriate license(s) from Microsoft.
• This product includes technology owned by Microsoft
Corporation and can not be used or distributed without a
license from Microsoft Licensing, GP.
• THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD
(“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR
SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA,LLC.
SEE HTTP://WWW.MPEGLA.COM
• THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE
VIDEO IN COMPLIANCE WITH THE VC-1 STANDARD
(“VC-1 VIDEO”) AND/OR (ii) DECODE VC-1 VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR
SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA,LLC.
SEE HTTP://WWW.MPEGLA.COM
• THIS PRODUCT IS LICENSED UNDER THE MPEG-4
VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A
CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE
WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4
VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED
BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE
IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION INCLUDING THAT
RELATING TO PROMOTIONAL,INTERNAL AND
COMMERCIAL USES AND LICENSING MAY BE
OBTAINED FROM MPEG LA,LLC. SEE HTTP://
WWW.MPEGLA.COM
9
Contents
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 3
Installation, Care, and Service . . . . . . . . . . . . . . . . . . . . . 3
Choosing a location for your LCD TV . . . . . . . . . . . . . . . . . 5
Chapter 1: Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . .11
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Overview of installation, setup, and use . . . . . . . . . . . . 11
Front panel control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Back panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Bundling the cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 2: Connecting your TV . . . . . . . . . . . . . . . . . . . . .14
Overview of cable types . . . . . . . . . . . . . . . . . . . . . . . . . . 14
About the illustrations . . . . . . . . . . . . . . . . . . . . . . . . . 14
Connecting to a Satellite dish, an Antenna, or Cable
TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Connecting an HDMI® or DVI device to the HDMI
input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting a VCR or DVD player with ColorStream®
(component video) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting a digital audio system . . . . . . . . . . . . . . . . . 18
Using the TV remote and HDMI® CEC Control to
control other devices. . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting an HDMI audio system . . . . . . . . . . . . . . . . 19
Connecting a PC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connecting to a home network . . . . . . . . . . . . . . . . . . . . 21
Chapter 3: Using the remote control . . . . . . . . . . . . . . . . . .22
Controlling other devices . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installing batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Learning about the Remote Control . . . . . . . . . . . . . . . . 23
Chapter 4: Initial Setup and Menu . . . . . . . . . . . . . . . . . . .24
Initial Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Navigating the menu system . . . . . . . . . . . . . . . . . . . . . . 25
Main menu layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Quick menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 5: Setting up your TV . . . . . . . . . . . . . . . . . . . . . .28
Changing Initial settings. . . . . . . . . . . . . . . . . . . . . . . . . . 28
Menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Local Time Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
ANT/CABLE IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Storing channels in memory (optional) . . . . . . . . . . . . . 28
Auto Tuning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Manual Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Skipping channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Skipping video inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Labeling channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Labeling video inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Configuring shared inputs . . . . . . . . . . . . . . . . . . . . . . . . 30
Setting the Auto Input feature . . . . . . . . . . . . . . . . . . . . . 31
Chapter 6: Basic features . . . . . . . . . . . . . . . . . . . . . . . . .32
Tuning channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setting the Channel Tuning Mode . . . . . . . . . . . . . . . 32
Tuning in to the next programmed channel . . . . . . . 32
Tuning in to a specific channel
(programmed or unprogrammed). . . . . . . . . . . 32
Using the Channel Browser™ . . . . . . . . . . . . . . . . . . . 32
Using Channel Return . . . . . . . . . . . . . . . . . . . . . . . . . 34
Using SurfLock™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Selecting the video input to view . . . . . . . . . . . . . . . . . . 34
Using closed captions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Analog CC mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Digital CC settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setting the PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Entering a new PIN code . . . . . . . . . . . . . . . . . . . . . . . 36
Changing or deleting your PIN code . . . . . . . . . . . . . 36
Forgotten PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Blocking TV programs and movies by rating
(V-Chip) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Downloading an additional rating system . . . . . . . . 37
Displaying ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Unlocking programs . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Locking specific channels . . . . . . . . . . . . . . . . . . . . . . . . . 38
Locking video input . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting a time limit for games . . . . . . . . . . . . . . . . . . . 39
Locking the control panel . . . . . . . . . . . . . . . . . . . . . . . 39
Using HDMI® CEC Control . . . . . . . . . . . . . . . . . . . . . . . 39
Controlling HDMI® CEC playback devices. . . . . . . . 40
HDMI® CEC Control input source selection . . . . . . . 40
Adjusting the amplifier’s audio. . . . . . . . . . . . . . . . . . 41
Other HDMI® CEC Control functions . . . . . . . . . . . . 41
Using the HDMI® settings feature. . . . . . . . . . . . . . . . . . 41
Viewing the HDMI® signal information. . . . . . . . . . . . . 41
Using your PC with the TV . . . . . . . . . . . . . . . . . . . . . . . 42
Adjusting the image . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setting the PC audio . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setting the timer to turn on the TV . . . . . . . . . . . . . . . . . 42
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting Automatic Power Down . . . . . . . . . . . . . . . . . . . 43
Setting No Signal Power Down . . . . . . . . . . . . . . . . . . . . 43
Displaying TV status information . . . . . . . . . . . . . . . . . . 44
Viewing support information. . . . . . . . . . . . . . . . . . . . . . 44
Resetting to Factory Defaults . . . . . . . . . . . . . . . . . . . . . . 44
Power failure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 7: Picture and sound controls . . . . . . . . . . . . . . . .45
Selecting the picture size. . . . . . . . . . . . . . . . . . . . . . . . . . 45
Scrolling the picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Using the Auto Aspect feature . . . . . . . . . . . . . . . . . . . . . 47
Using the 4:3 Stretch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Freezing the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Adjusting the picture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Selecting the picture mode . . . . . . . . . . . . . . . . . . . . . . 48
Adjusting the picture quality. . . . . . . . . . . . . . . . . . . . 48
Using the advanced picture settings features . . . . . . . . 49
Edge Enhancer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Dynamic Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
DynaLight™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Static Gamma . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Film Stabilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
ClearFrame™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
MPEG NR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
DNR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Auto Brightness Sensor. . . . . . . . . . . . . . . . . . . . . . . . . 50
Backlight Adjustment Pro . . . . . . . . . . . . . . . . . . . . . . 50
ColorMaster™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Base Color Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . 51
Color temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Resetting to the factory default . . . . . . . . . . . . . . . . . . 51
Setting the Expert Picture Settings . . . . . . . . . . . . . . . . . 51
Test Pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
RGB Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
White Balance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Resetting to the factory default . . . . . . . . . . . . . . . . . . 52
Locking the picture settings . . . . . . . . . . . . . . . . . . . . . . . 52
Adjusting the audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Muting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
10
Selecting stereo/SAP broadcasts . . . . . . . . . . . . . . . . 52
Adjusting the audio balance . . . . . . . . . . . . . . . . . . . . 53
Adjusting the range . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Selecting the optical audio output format . . . . . . . . . 53
Using the Dolby® Digital Dynamic Range Control
feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Using Audyssey Dynamic Volume® . . . . . . . . . . . . . 53
Using advanced sound features . . . . . . . . . . . . . . . . . . . 54
Using surround sound . . . . . . . . . . . . . . . . . . . . . . . . . 54
Chapter 8: Advanced features . . . . . . . . . . . . . . . . . . . . . .55
Using your home network . . . . . . . . . . . . . . . . . . . . . . . . 55
Setting up the Network. . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Wireless Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Advanced Network Setup . . . . . . . . . . . . . . . . . . . . . . 58
Network Connection Test . . . . . . . . . . . . . . . . . . . . . . 59
Using the software keyboard . . . . . . . . . . . . . . . . . . . . . . 59
Performing a Software Upgrade . . . . . . . . . . . . . . . . . . . 60
Viewing the Software Licenses . . . . . . . . . . . . . . . . . . . . 60
Using the NET TV™ feature . . . . . . . . . . . . . . . . . . . . . . . 60
NET TV menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Netflix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
VUDU™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
YouTube™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
CinemaNow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Blockbuster. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Pandora. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Yahoo!® TV Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Using the Media Player. . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Media Player Specifications. . . . . . . . . . . . . . . . . . . . . 64
Basic operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Viewing Movie files . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Playing Music files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Viewing Photo files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Using the Wallpaper feature . . . . . . . . . . . . . . . . . . . . . . 69
Chapter 9: Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . .70
General troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 70
LED indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Chapter 10: Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Acceptable signal formats for PC IN and HDMI
terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
PC IN signal formats. . . . . . . . . . . . . . . . . . . . . . . . . . . 75
HDMI signal formats . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Remote control functional key chart. . . . . . . . . . . . . . . . 77
Operating other devices . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Programming the remote to operate other devices . . . 79
Device code setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Searching for a device code . . . . . . . . . . . . . . . . . . . . . 80
Locking the volume keys . . . . . . . . . . . . . . . . . . . . . . . 80
Clearing the remote’s programming . . . . . . . . . . . . . 80
Resetting to the factory default . . . . . . . . . . . . . . . . . . 80
Operating the TV with combination buttons. . . . . . . . . 81
Remote control codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Limited United States Warranty
for LCD Televisions . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Limited Canadian Warranty
for Toshiba Brand Flat Panel Televisions . . . . . . . . . 89
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
11
Chapter 1: Introduction
Features
•Integrated digital tuning (8VSB ATSC and QAM)
eliminates the need for a separate digital converter
set-top box (in most cases).
•1080p output resolution.
•Four HDMI® digital, High-Definition Multimedia
Interfaces with 1080p input support (- p. 16).
•HDMI capabilities
ARC (Audio Return Channel) enables the audio
signal of the TV to be sent to an AV amplifier via an
HDMI cable.
HDMI INSTAPORT™ technology reduces lag time
when switching HDMI sources.
RGB Range adjusts RGB full range signal
automatically.
•HDMI® CEC Control allows control of external
devices from the TV remote via HDMI connection (-
p. 39).
•ColorStream® HD high-resolution component video
input.
•Digital Audio Out optical audio connection with
Dolby® Digital optical output format (- p. 53).
•PC IN (Analog RGB) computer terminal (- p. 20).
•Built-in WLAN Allows the television to access your
home wireless network without an external Dual
Band WLAN Adapter.
•Yahoo!® TV Widgets are Internet applications
designed to run on your TV (- p. 62).
•ColorMaster™ lets you adjust the TV’s standard colors
(- p. 51).
•ClearFrame™ 120 Hz anti-blur feature (-p. 50).
•AutoView® lets you automatically adjust picture
settings based on ambient light conditions and input
signal content (- p. 48).
•Dynamic Volume (Audyssey Dynamic Volume®)
eliminates inconsistent TV volume when changing
channels or viewing commercials (- p. 53).
•Media Player lets you view photo files and play music
or movie files (- p. 64).
•ENERGY STAR® qualified
Overview of installation, setup,
and use
Follow these steps to set up your TV and begin using its
many exciting features.
1To choose a location for the TV:
•Read “Important notes about your LCD TV”
(- p. 7).
•Place the TV in an appropriate location (- p. 2–6).
2Do not plug in any power cords until AFTER you
have connected all cables and devices to your TV.
3BEFORE connecting cables or devices to the TV,
learn the functions of the TV’s connections and
controls (- p. 12).
4Connect your other electronic device(s) to the TV
(- p. 14–21).
5See “Chapter 3: Using the remote control” (- p. 22)
for an overview of the buttons on the remote
control, installing the batteries, and preparing to
operate your other device(s).
6AFTER connecting all cables and devices, plug in
the power cords for your TV and other devices.
When you turn on the TV, the Initial Setup menu
appears.
7See “Chapter 4: Initial Setup and Menu” for a quick
overview of navigating the TV’s menu system (-
p. 24).
8Program channels into the TV’s channel memory
(- p. 28).
9See Chapters 6, 7 and 8, for details on using the TV’s
features.
10 For help, refer to “Chapter 9: Troubleshooting” (-
p. 70).
11 See “Chapter 10: Appendix”, for technical
specifications and warranty information (- p. 73).
12
Chapter 1: Introduction
Front panel control
Examples show Model 42SL417U.
Back panel connections
For explanations of cable types and connections, see p. 14–21.
TV front
Brightness Sensor
This sensor will detect the ambient light conditions to optimize the
backlighting levels (- p. 50).
Touch Sensor
Effective range: 16.4 ft (5m)
Remote Sensor
Power LED
(- p. 72)
Touch key function:
– These are available when touched.
•POWER – To turn the TV on and off.
•B b – To change the channel. When a
menu is onscreen, these keys function
as up/down menu navigation
buttons.
•+ - – To adjust the volume level. When
a menu is onscreen, these keys
function as left/right menu
navigation buttons.
•MENU – To access the menu. When a
menu is onscreen, the MENU key on
the TV’s control panel functions as the
RETURN button.
•INPUT – To change the source you are
viewing. When a menu is onscreen,
the INPUT key on the TV's control
panel functions as the OK button.
Service LED
(- p. 72)
TV back
Power cord
VIDEO 1 IN**
To configure for use, see “Side
Shared Audio” (- p. 30).
COLORSTREAM HD1 IN**
To configure for use (for audio), see
“Side Shared Audio” (- p. 30).
HDMI® IN
DIGITAL AUDIO OUT
See “Connecting a digital audio system” (- p. 18).
ANT/CABLE
* To use PC/
COLORSTREAM HD2 IN,
an appropriate adapter
(not supplied) is
necessary.
** To use COLORSTREAM
HD1 IN, VIDEO 1 IN, or
VIDEO 2 IN, an
appropriate adapter
(supplied) is necessary.
PC/COLORSTREAM HD2/
HDMI 4 IN (Audio input)
To configure for use, see
“Rear Shared Audio”
(- p. 30).
PC/COLORSTREAM HD2 IN* (Video input)
To configure for use, see “Shared PC Input” (- p. 30).
USB
terminal
LAN port
VIDEO 2 IN**
FIXED AUDIO
13
Chapter 1: Introduction
Bundling the cables
Install the cable clamps and bundle the cables in them.
Stand type
Wall Mount type
Cable Clamps
Cable Clamps
14
Chapter 2: Connecting your TV
Overview of cable types
Before purchasing cables, know the connector types
your devices require.
You can purchase cables from most stores that sell
audio/video devices.
Coaxial cable (F-type)
(F-type) Connects your antenna, cable TV service, or
cable converter box to your TV.
Standard A/V cables (composite video)
Use with video devices with analog audio and
composite video output. These cables (and the related
inputs on your TV) are often color-coded.
Component video cables
Use with video devices with component video output.
Separate audio cables are required. (ColorStream® is a
Toshiba brand.)
Note: Component video cables provide better picture
quality than composite video cables.
HDMI® cable ( )
Use it with devices built-in HDMI output. An HDMI
cable delivers digital audio and video in its native
format. Separate audio cables are not required
(- p. 16, 19–20).
Note: HDMI cables provide the best audio and picture
quality.
Optical audio cable
Connects receivers with Dolby Digital or PCM (pulse-
code modulation) optical audio input to the TV’s
DIGITAL AUDIO OUT terminal (- p. 18).
Analog RGB (15-pin) computer cable
Connects a PC to the TV’s PC IN terminal (- p. 20).
Note: Separate audio cables are required.
Standard/Crossover LAN cable
Standard LAN cable is used to connect the TV to your
home network (- p. 21).
Crossover LAN cable is used to connect the TV directly
to a PC (- p. 21).
About the illustrations
Note: The connection illustrations shown are
representative of typical device connections only. The
input/output terminals on your devices may differ. See
each device’s owner’s manual.
VIDEO AUDIO
LR
Red
White
Yellow
P
B
PR
Y
Red
Blue
Green
15
Chapter 2: Connecting your TV
Connecting to a Satellite dish, an Antenna, or Cable TV
IN OUT
CH 3
CH 4
VIDEO
OUT
AUDIO
OUT
COMPONENT VIDEO
L
R
Satellite
IN
P
B
P
R
Y
TV back panel
VHF/UHF Antenna
Cable TV
Satellite dish
Cable box Coaxial cable
Component adapter
cable (supplied)
Component
video cable
Standard audio
cable
Satellite receiver with component video
AV adapter
cable
(supplied)
You will need:
•Coaxial cables
•AV adapter cable (supplied)
•Standard audio cable
•Component adapter cable (supplied)
•Component video cable
To view satellite programs using the component video
connections:
Turn on the satellite receiver. Press and B or b to
select ColorStream HD1. Use the satellite receiver’s
controls to change channels.
To view the antenna or cable signal:
Press and B or b to select ANT/CABLE.
To view basic and premium cable channels:
Turn on the cable box. Press and B or b to select
ANT/CABLE. Tune the TV to channel 3 or 4 (the
channel the cable box output is set to). Use the cable
box’s controls to change channels.
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs, and
other materials are prohibited under the Copyright
Laws of the United States and other countries, and may
subject you to civil and criminal liability.
INPUT
INPUT
INPUT
16
Chapter 2: Connecting your TV
Connecting an HDMI® or DVI device to the HDMI input
HDMI OUT
DVI/HDCP
OUT
AUDIO
R
L
OUT
TV back panel
HDMI device
HDMI cable
DVI device
HDMI-to-DVI adapter cable
Analog audio cable
The HDMI input on your TV receives digital audio and
uncompressed digital video from an HDMI device, or
uncompressed digital video from a DVI (Digital Visual
Interface) device.
This input is designed to accept HDCP (High-
Bandwidth Digital-Content Protection) program
material in digital form from EIA/CEA-861-D
compliant[1] consumer electronic devices (such as a set-
top box or DVD player with HDMI or DVI output).
Supported signal formats: VGA, SVGA, XGA, WXGA,
SXGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i
(60Hz), and 1080p (24Hz/60Hz). For signal
specifications, see p. 76.
Supported Audio format: Linear PCM, sampling rate
32/44.1/48 kHz.
Note:
•For connecting a PC to the HDMI input, see p. 20.
•Some legacy HDMI sources may not work properly with
your HDMI TV due to the adoption of new standards. Try
disabling the options in HDMI Settings. (- p. 41).
To connect an HDMI device, you will need:
•One HDMI cable per HDMI device
– Recommendation: For proper operation, use an
HDMI cable with the HDMI Logo ( ).
– To display an 1080p/60 Hz signal format, you need a
High Speed HDMI cable. A conventional HDMI/DVI
cable may not work properly.
– An HDMI cable transfers video and audio. Separate
analog audio cables are not required.
To view the HDMI device video:
Press and B or b to select HDMI 1, HDMI 2, HDMI
3, or HDMI 4.
Note: For programming the TV remote control to operate
other devices, see p. 79.
To connect a DVI device, you will need:
•HDMI-to-DVI adapter cable
– For proper operation, the length of the HDMI-to-DVI
adapter cable must not exceed 9.8 ft (3 m).
Recomended length: 6.6 ft (2 m).
•3.5mm Stereo to RCA Y-Cable
– An HDMI-to-DVI adapter cable transfers video only.
Separate analog audio cables are required.
Note: To ensure that the HDMI or DVI device is reset
properly:
•When turning on electronic components, turn on the TV
first and then the HDMI or DVI device.
•When turning off electronic components, turn off the
HDMI or DVI device first and then the TV.
[1] EIA/CEA-861-D compliance covers the transmission of
uncompressed digital video with high-bandwidth digital
content protection, which is being standardized for
reception of high-definition video signals. Because this is
an evolving technology, it is possible that some devices
may not operate properly with the TV.
INPUT
17
Chapter 2: Connecting your TV
Connecting a VCR or DVD player with ColorStream® (component video)
VIDEO AUDIO
LR
COMPONENT VIDEO
P
B
P
R
Y
AUDIO OUT
LR
R
W
YGB
R
W
Y
RW
RB
R
W
YR
W
R
GB
G
W
TV back panel
DVD player
Component adapter
cable (supplied)
Standard
audio cable
Component
video cable
VCR
Standard
A/V cable
AV
adapter
cable
(supplied)
Light green
Light yellow
Yellow White Red Green Blue
AV adapter cable
(supplied)
Light yellow
You will need:
•Standard A/V cable
•AV adapter cable (supplied)
•Standard audio cable
•Component adapter cable (supplied)
•Component video cable
– You can connect the component video cables from
the DVD player to the ColorStream HD1 terminal on
the TV. Separate audio cables are required. You can
use the ColorStream HD1 terminal to display
Progressive (480p, 720p, 1080p) and Interlaced
(480i, 1080i) video. Check the owner’s manual of the
DVD player in order to determine the best output
signal available (1080p 24 Hz/30 Hz/50 Hz/25 Hz are
not supported).
– If your DVD player does not have component video,
connect a composite video cable to VIDEO 2 on the
side panel. If your DVD player has HDMI video, see
p. 16.
To view the DVD player:
Turn on the DVD player. Press and B or b to select
ColorStream HD1. Audio configuration is required.
See “Side Shared Audio” (- p. 30), and select
ColorStream HD1.
To view the VCR or view and record antenna-sourced:
Turn on the VCR. Tune the VCR to the channel you
want to watch. Press and B or b to select Video 2.
Note: For programming the TV remote control to operate
other devices, see p. 79.
The unauthorized recording, use, distribution, or
revision of television programs, videotapes, DVDs, and
other materials are prohibited under the Copyright
Laws of the United States and other countries, and
may subject you to civil and criminal liability.
INPUT
INPUT
18
Chapter 2: Connecting your TV
Connecting a digital audio system
The TV’s DIGITAL AUDIO OUT terminal outputs a
Dolby® Digital or 2-channel down-mixed PCM (pulse-
code modulation) signal for use with an external Dolby
Digital decoder or other external audio systems with
optical audio input.
You will need:
•Optical audio cable (Use an optical audio cable that
has the larger TosLink connector, not the smaller
mini-optical connector.)
Before controlling the audio:
•See “Selecting the optical audio output format”
(- p. 53).
Note:
•Some audio systems may not be compatible with Dolby
Digital bitstream signals. Older audio systems that are
not compatible with standard optical out signals may not
work properly, creating a high noise level that may
damage speakers or headphones. THIS DAMAGE IS
NOT COVERED BY YOUR WARRANTY.
•The DIGITAL AUDIO OUT terminal may not output some
digital audio sources due to copy restrictions.
•The Dolby Digital format is available in the following
situations:
-When tuned to a digital RF channel.
-When an HDMI input is used.
-When DLNA Certified products or widgets are used.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are registered trademarks of
Dolby Laboratories.
LINE IN
Optical
Audio IN
LR
Dolby Digital decoder or other
digital audio system
TV back panel
Optical
audio
cable
19
Chapter 2: Connecting your TV
Using the TV remote and HDMI® CEC Control to control other devices
To control the basic functions of connected audio/video devices using the TV’s remote control, connect an HDMI®
CEC compatible audio receiver or playback device. The HDMI® CEC Control feature uses CEC technology as
regulated by the HDMI standard.
To connect an audio receiver and playback devices, you will need:
•HDMI cables (- p. 14)
Note:
•If several devices are connected, the HDMI® CEC Control feature may not operate properly.
•For proper operation, it is recommended that you use HDMI cables with the HDMI Logo ( ).
Before controlling the devices:
•For an explanation of setup and operations, see “Using HDMI® CEC Control” (- p. 39).
•Configure the connected devices. See each device’s operation manual.
Note: This feature is limited to models incorporating Toshiba’s HDMI® CEC Control feature. However, Toshiba is not liable
for those operations. See the individual instruction manuals for compatibility information.
When using an external AV amplifier:
The picture and sound may not be properly synchronized. In this case, adjust the delay time of the sound on the AV
amplifier.
Note: The control range of the delay time differs according to the device you use.
Connecting an HDMI audio system
If your HDMI amplifier supports ARC, audio from the TV can be sent to the amplifier via an existing HDMI cable.
You will need:
•HDMI cable
HDMI
OUT HDMI
IN
HDMI
OUT
HDMI
OUT
TV back panel
Audio receiver
Playback device
(HDMI® CEC DVD player,etc.)
Playback device
(HDMI® CEC DVD player,etc.)
HDMI cable
HDMI cable
TV back panel
HDMI
cable
AV amplifier that
supports ARC
HDMI's ARC (Audio Return Channel) feature
This feature enables the audio signal of the TV to
be sent to an AV amplifier via the HDMI cable.
It will not be necessary to connect a cable from
the audio output of the TV to the audio input of
the AV amplifier to reproduce the audio
received from the tuner of the TV through the
AV amplifier.
Note: Only HDMI 1 supports ARC.
20
Chapter 2: Connecting your TV
Connecting a PC
You can view your PC’s display on the TV and hear the
sound from the TV’s speakers.
Connecting to the TV’s PC IN terminal
You will need:
•Analog RGB (15-pin) computer cable
•Analog audio cable
Before using the PC:
See “Using your PC with the TV” (- p. 42).
To use a PC:
• Set the monitor output resolution on the PC before
connecting it to the TV.
•Supported signal formats: VGA, SVGA, XGA, WXGA,
and SXGA. For signal specifications, see p. 75.
Note:
•The PC audio input terminal on the TV is shared with the
HDMI 4 and ColorStream HD2 terminal. For
configuration, see “Setting the PC audio” (- p. 42).
•Some PC models cannot be connected to this TV.
•If the PC has a compatible mini D-sub15-pin terminal, an
adapter is not required.
•Depending on the content's title and the PC’s
specifications, some scenes may be skipped or you may
not be able to pause during multi-angle scenes.
Signal names for mini D-sub 15-pin connector
*NC=Not connected
Connection to the TV’s HDMI terminal
You will need:
If your PC has DVI terminal:
•HDMI-to-DVI adapter cable
•Analog audio cable
If your PC has an HDMI terminal:
•HDMI cable
Supported signal formats: VGA, SVGA, XGA, WXGA,
SXGA, 480i (60Hz), 480p (60Hz), 720p (60Hz), 1080i
(60Hz), and 1080p (24Hz/60Hz). For signal
specifications, see p. 76.
Note:
•The edges of the picture may be hidden.
•The PC audio input terminal on the TV is shared with the
HDMI 4 and ColorStream HD2 terminal. For
configuration, see “Setting the PC audio” (- p. 42).
TV back panel
PC
PC audio
output
Analog
audio
cable
Conversion adapter
(if necessary)
Analog
RGB
computer
cable
Pin
No.
Signal
name
Pin
No.
Signal
name
Pin
No.
Signal
name
1R 6Ground11NC
2G 7Ground12NC
3B 8Ground13H-sync
4NC * 9NC 14V-sync
5 NC 10Ground15NC
TV back panel
PC
Analog
audio
cable
PC audio
output
HDMI-to-
DVI
adapter
cable
21
Chapter 2: Connecting your TV
Connecting to a home network
The LAN port allows your Toshiba TV to connect to
your home network.
You can use this home network to access photos,
movies, and music files that are stored on a DLNA
CERTIFIED™ Server and play them on your TV.
Connecting the TV directly to a PC without an
Internet connection
You will need:
•Crossover LAN cable
Connecting the TV to a home network without an
Internet connection
You will need:
•Standard LAN cables
•Router with Hub
Connecting the TV to a home network with an
Internet connection - Wired
You will need:
•Coaxial or telephone cable (depending on your
modem type)
•Standard LAN cables
•Router with Hub
•Modem (DSL or cable)
[1] Coaxial or telephone cable (depending on your modem
type)
[2] Standard LAN cable
[3] Do NOT connect a phone jack directly to the TV's LAN port.
Connecting the TV to a home network with an
Internet connection - Wireless
You will need:
•Coaxial or telephone cable (depending on your
modem type)
•Standard LAN cables
•Wireless LAN access point
•Modem (DSL or cable)
The transmission speed over the wireless LAN and the
distance over which wireless LAN can reach may vary
depending on surrounding electromagnetic
environment, obstacles, access point design and
configuration, and client design and software/
hardware configurations. The actual transmission
speed will be lower than the theoretical maximum
speed.
[1] Coaxial or telephone cable (depending on your modem
type)
[2] Standard LAN cable
TV back panel
PC
Router with Hub TV back panel
PC
NAS
Modem (DSL or cable) Router with Hub
Cable or
phone jack
TV back panel
PC
[1] [2]
[2]
[2]
[3]
Wireless LAN access point
PC
Modem (DSL or cable)
Cable or
phone jack
[1] [2]
[2]
Built-in WLAN system:
It is not necessary to
connect an adapter to
the TV.
22
Chapter 3: Using the remote control
Controlling other devices
The TV’s remote control can operate other devices such
as cable converter boxes, satellite receivers, VCRs, DVD
players, and HTIBs (home theater in a box).
Toshiba devices:
The remote is programmed to operate a variety of
devices (- p. 79).
Non-Toshiba devices or Toshiba devices that the remote
control is not programmed to operate:
Program the remote (- p. 79).
Installing batteries
1Pull up to open the cover.
2Install two AA size batteries.
Note: Use carbon zinc batteries or alkaline batteries.
3Slide on the cover.
Caution: Do not expose batteries to excessive heat such
as sunshine, fire, or the like.
Note:
•Every time you change the batteries, you must
reprogram the remote.
•Dispose of batteries in a designated disposal area.
•Always consider the environment when disposing of
batteries. Always follow applicable laws and regulations.
•If the remote does not operate correctly, or if the
operating range is reduced, replace the batteries.
•Always replace both batteries with new ones. Never mix
battery types or use new and used batteries together.
•Always remove batteries from the remote if they are dead
or if the remote control is not to be used for an extended
period of time. This prevents battery acid from leaking
into the battery compartment.
23
Chapter 3: Using the remote control
Learning about the Remote Control
The buttons described in this section operate the TV only.
For the HDMI® CEC Control functions, see “Using HDMI® CEC Control” (- p. 39).
For a complete list of the remote’s functions, see “Remote control functional key chart” (- p. 77–78).
Note: The error message “NOT AVAILABLE” may appear if you press a key for a function that is not available.
Changes the picture mode to Game
when the input mode is ColorStream
HD, PC, Video, or HDMI® (- p. 48).
Sets the remote control mode to
control the device: TV, CABLE/SAT,
BD/DVD, or AUX. To control the TV,
press TV.
When the Auto Input feature is set, you
can use these keys to change inputs
on the TV (- p. 31).
Accesses the sleep timer (- p. 43)
Directly tune channels. The “-” button
is used to enter 2-part channel
numbers (- p. 32) or edit the Favorites
List (- p. 33).
Selects the video input source
(- p. 34).
Displays/hides the Yahoo!® TV Widgets
user interface (- p. 62).
When a menu is onscreen, these
buttons select or adjust programming
menus.
Cycles through programmed channels.
Closes onscreen menus.
Displays TV status information as well
as program details, when available
(- p. 44).
Selects the audio mode.
Opens the closed caption selector
(- p. 35).
Displays the NET TV™ menu (- p. 60).
Activates highlighted items in the
main menu system.
Adjusts the volume level.
Accesses the Quick menu.
Selects the picture size (- p. 45).
Freezes the picture (- p. 47).
Turns the TV on and off.
Accesses the main TV menu system
(- p. 25–27).
Reduces or turns off the sound
(- p. 52). Returns to the last viewed channel or
source (- p. 34).
Returns to the previous menu.
Accesses Netflix (- p. 61).
Displays Favorite Browser (- p. 33).
/ Scrolls to right.
Displays Channel Browser™ (-p. 32).
/ Scrolls to left.
Moves to the previous/next page.
These buttons are used for BD/DVD,
CABLE/SAT, and VCR mode.
24
Chapter 4: Initial Setup and Menu
Initial Setup
When you first turn on or reset the TV, the Initial Setup
window will appear.
Note:
•You can stop Initial Setup by pressing . However, if
you do not finish Initial Setup, the Initial Setup screen will
appear every time you turn on your TV. To finish Initial
Setup, see “Changing Initial settings” (- p. 28).
• does not work until Menu Language, Time Zone,
and Location have been set.
1Menu Language
2Time Zone
3Daylight Saving Time
4Location
5ANT/CABLE
To select Antenna:
To select Cable:
Note: If you do not want to scan channels, you do not
need to make a selection for ANT/CABLE. Select
Next and press to skip this step.
Menu Language English
Quick Setup
Select a language.
Time Zone
Daylight Saving Time
Eastern
Off
Local Time Setting
Select a time zone.
Time Zone
Daylight Saving Time
Eastern
Off
Local Time Setting
Select On or Off. Press .
OK
To use the TV for displaying in a store showroom, please
select [Store]. [Home] mode is recommended for normal use.
(ENERGY STAR® qualified)
Home
Location
Select Home for normal home use. Press .
OK
Antenna
Next
ANT/CABLE In
Please confirm the connection with Tuner Input.
Cable
First, select
Antenna.
Then, select Next. Press .
OK
Auto
Channel Tuning Mode
Select Auto, Digital, or Standard (- “Setting
the Channel Tuning Mode” on p. 32). Press .
OK
Antenna
Next
ANT/CABLE In
Please confirm the connection with Tuner Input.
Cable
First, select
Cable.
Then, select Next. Press .
OK
OK
25
Chapter 4: Initial Setup and Menu
6Start Scan
Note: If you want to stop scanning, press while
scanning.
•After scanning is complete, a channel list screen
(such as the one below) will appear. Press or
.
Note: Encrypted channels cannot be registered
though these are displayed in the above list.
If some channels are not found after scanning:
•Check the antenna/cable connections, and scan
again.
•Connect the TV to the antenna or cable box
directly and scan again.
1 > Settings > SETUP > Quick Setup > .
2A confirmation message appears. Press C or c
to select Yes. Press .
3Repeat set up to Step 6.
•If you selected Antenna previously, select
Cable.
•If you selected Cable previously, select
Antenna.
4Scan again.
7Support Information
The Support Information screen appears. Press .
Note: Refer to this information if there is any problem
and you need to contact Customer Support. This can
be confirmed from the following operation at any time.
> Settings > SETUP > System Information >
.
Navigating the menu system
•To open the main menu, press on the remote
control or TV control panel.
•Press B, b, C, or c on the remote control or TV control
panel to navigate and make selections.
•To select a menu option, press .
•To move to the next menu layer, press or B.
•To return to the previous menu layer, press or b.
•To close a menu instantly, press or .
•All menus will close automatically if you do not make
a selection within 60 seconds.
Start Scan
Auto Tuning
Press .
OK
OK
DTV
ATV
ATV
ATV
ATV
ATV
DTV
ATV
Antenna Channels Found: 14
Auto Tuning (Antenna)
Ch. Type RF Ch.
2
4-1
4-2
6
11
13
18
31
2
4
4
6
11
13
18
31
OK
OK
OK
OK
Settings
Timer
Wallpaper
Network
Media Player
OK
OK
26
Chapter 4: Initial Setup and Menu
Main menu layout
To open the main menus (illustrated below), press
on the remote control or TV control panel.
1st Layer2nd Layer3rd LayerPage
Network NET TV 60
Network Setup 56
Wireless
Information 57
Media
Player
Photo (Device select) 67
Movie (Device select) 65
Music (Device select) 66
Wallpaper 69
Timer On Timer 42
Sleep Timer 43
Game Timer 39
Settings PICTURE Picture Mode 48
Reset 48
Backlight 48
Contrast 48
Brightness 48
Color 48
Tint 48
Sharpness 48
Advanced
Picture Settings 49
Expert Picture
Settings 51
TheaterLock 52
SOUND MTS 52
Balance 53
Bass 53
Treble 53
Advanced
Sound Settings 54
Dynamic
Volume
(Audyssey
Dynamic
Volume®)
53
Dynamic
Range Control 53
Settings
APPLICATIONS
Widgets 62
NET TV 60
Media Player 64
Channel
Browser 32
Favorites
Browser 33
On Timer 42
Sleep Timer 43
PREFERENCES
HDMI-CEC
Control Setup 39
Network Setup 56
Netflix Setup 61
VUDU
Deactivation 61
Reset Yahoo!
TV Widgets 63
Wallpaper
Setup 69
Channel
Browser Setup 32
PIN Setting 36
Parental
Control and
Locks
36
Display
Settings
42,
47
AV Connection
29,
30,
41,
53
Auto Input 31
Energy Saving
Settings 43
HDMI
Information
Display
41
1st Layer2nd Layer3rd LayerPage
27
Chapter 4: Initial Setup and Menu
Quick menu
Quick menu helps you access some options more
quickly.
Press to display the Quick menu and press B or b
to select an option.
Note: Quick menu items differ depending on the current
mode.
Settings SETUP Menu
Language 28
ANT/CABLE
In 28
Auto Tuning 28
Manual Tuning 29
TV Settings
28,
29,
32,
35,
38
Quick Setup 28
Location 28
Software
Upgrade 60
Software
Licenses 60
System
Information 44
Reset TV 44
1st Layer2nd Layer3rd LayerPage
Quick menu Item Page
PICTURE 45–52
Picture Mode 48
Repeat 66, 67, 68
SOUND 52–54
Background Music 68
Speakers 41
HDMI-CEC Player Control 40
Interval Time 68
Device Information 65
Wireless Information 57
QUICK
28
Chapter 5: Setting up your TV
How to navigate the menu:
> Settings > Main menu > Submenu >
Changing Initial settings
From Quick Setup:
1 > Settings > SETUP > Quick Setup > .
2A confirmation message appears. Press C or c to
select Yes. Press .
3For changing settings, see “Initial Setup” (- p. 24).
From individual settings:
Menu language
You can choose from three different language settings
(English, Français, and Español) for menus and
messages
1 > Settings > SETUP > Menu Language.
2Press C or c to select your preferred language. Press
.
Local Time Setting
This setting allows you to specify the correct time zone
for your region.
1 > Settings > SETUP > TV Settings > .
2Press B or b to select Local Time Setting. Press .
3Select an option:
• Time Zone
• Daylight Saving Time
4Press C or c to select your time zone or to select On
to activate Daylight Saving Time. Press .
Location
You can select Home or Store for the TV location. For
normal home use, select Home.
1 > Settings > SETUP > Location.
2Press C or c to select Home. Press .
ANT/CABLE IN
This setting configures the antenna input source for the
ANT/CABLE terminal.
1 > Settings > SETUP > ANT/CABLE In.
2Press C or c to select the input source (Antenna or
Cable) for the ANT/CABLE input. Press .
Storing channels in memory
(optional)
To make sure your TV stops only on the channels you
want when you press or on the remote control or
the control panel, store those channels in the TV’s
memory.
Auto Tuning
Note: You must set up the antenna/cable input source first.
See “Initial Setup” (-p. 24).
You can set up the TV to detect all active channels in
your area and store them in its memory. Then you can
manually store or skip individual channels from
memory.
Note: To tune channels not stored in memory, use buttons
0–9 and on the remote control.
Format Description
Press the MENU button.
Settings Press C or c to select Settings.
> Main menu
Press C or c to select a menu
icon (PICTURE, SOUND,
APPLICATIONS,
PREFERENCES, SETUP)
> Submenu Press B or b to select a menu.
> Press the OK button
OK
OK
OK
OK
OK
OK
Option Description
Cable
Note: If you select Cable, auto tuning
deletes previously stored channels from
memory.
This setup requires some time, but you
do not need to repeat the setup unless
your cable TV service’s lineup changes
significantly.
Antenna
Auto tuning retains stored channels and
stores newly found channels into
memory.
To skip an antenna source channel from
memory, set the channel to be skipped.
See “Skipping channels”.
CH
CH
-
29
Chapter 5: Setting up your TV
1 > Settings > SETUP > Auto Tuning > .
A confirmation screen appears.
2Press to start Auto Tuning or to abort.
The TV cycles through all the channels and stores all
active channels in memory.
To view the programmed channels, press or .
Manual Tuning
After storing channels in memory, you can manually
enter channels if the channel number is known.
1 > Settings > SETUP > Manual Tuning > .
2Use buttons 0–9 on the remote control to enter the
channel number (for example, 56). Press .
3Press to start Manual Tuning.
The channels found are listed at the center of the screen.
Skipping channels
To prevent a channel from being viewed, you can set it
to be skipped.
1 > Settings > SETUP > TV Settings > .
2Press B or b to select Channel Options. Press .
The list of channels appears.
3Move to the 8 column. Press B or b to select a
channel to skip. Press . The box is selected. To
clear the selection, press .
Note: You cannot tune skipped channels using or .
Use buttons 0–9 and on the remote control.
Skipping video inputs
You can set video inputs to be skipped when selecting
inputs in the Input selection window.
To turn on skip:
1 > Settings > PREFERENCES > AV
Connection > .
2Press B or b to select Input Labeling. Press .
3Press B or b to select the item you want to be
skipped. Press the RED button to turn on Skip.
To turn off skip:
Press again the RED button to turn off Skip.
Type Description
ATV Analog channel
DTV Digital channel
OK
OK
CH
CH
OK
OK
OK
OK
OK
DTV
ATV
DTV
ATV
ATV
ATV
ATV
ATV
6
5-1
6-1
8
9
10
11
12
Ch. Type Label
Channel Options
OK
OK
CH
CH
-
OK
OK
30
Chapter 5: Setting up your TV
Labeling channels
You can label analog TV channels.
1 > Settings > SETUP > TV Settings > .
2Press B or b to select Channel Options. Press .
The list of channels appears.
3Press B or b to select a channel to label.
4Press . The Software Keyboard window appears.
5Input a name using the Software Keyboard
(- p. 59).
6Press the BLUE button.
Note: Input the desired analog channel label up to 7
characters.
Labeling video inputs
The input labels are shown in the input selector, and in
the Channel Browser and banner displays. You can
label video inputs according to the devices you have
connected to the TV.
1 > Settings > PREFERENCES > AV
Connection > .
2Press B or b to select Input Labeling. Press .
3Press B or b to select the item you want to label.
Press C or c to select --, Amplifier, Cable, DVD,
Game, PC, Recorder, Satellite, or VCR or press
the GREEN button to select User Input.
Note: When User Input is selected by pressing the
GREEN button, the Software Keyboard window will
appear. Input the desired characters (up to 10
characters) using the Software Keyboard (- p. 59) or
the number buttons for a number input. To save your
settings, press the BLUE button.
4Repeat Step 3 for other video inputs.
Configuring shared inputs
Side Shared Audio
1 > Settings > PREFERENCES > AV
Connection > .
2Press B or b to select Side Shared Audio.
3Press C or c to select ColorStream HD1, Video 1,
or HDMI 3.
Rear Shared Audio
1 > Settings > PREFERENCES > AV
Connection > .
2Press B or b to select Rear Shared Audio.
3Press C or c to select PC (ColorStream HD2) or
HDMI 4.
Shared PC Input
1 > Settings > PREFERENCES > AV
Connection > .
2Press B or b to select Shared PC Input.
3Press C or c to select PC or ColorStream HD2.
OK
OK
DTV
ATV
DTV
ATV
ATV
ATV
ATV
ATV
6
5-1
6-1
8
9
10
11
12
Ch. Type Label
Channel Options
OK
OK
OK
OK
OK
OK
31
Chapter 5: Setting up your TV
Setting the Auto Input feature
You can change TV inputs using the MODE SELECT
buttons on the remote control: TV, CABLE/SAT, BD/
DVD, AUX. After setting an input for a specific MODE
SELECT button, the TV automatically switches to the
input when you press and hold the MODE SELECT
button for about 3 seconds and release it.
Auto Input settings options for each MODE SELECT
button:
Note: The TV mode select button will be restricted to the
ANT/CABLE input.
To set Auto Input:
1 > Settings > PREFERENCES > Auto Input >
.
2Set Enable Auto Input to On.
3Press B or b to select the mode you want to set.
4Press C or c to select an input source for that mode.
5Repeat the procedure for other modes.
To turn off Auto Input:
Select Off in Step 2.
To reset Auto Input:
Select Reset. Press .
Mode Inputs
TV ANT/CABLE
CABLE/SAT
ANT/CABLE, Video 1, Video 2,
ColorStream HD1, HDMI 1, HDMI 2,
HDMI 3, HDMI 4, PC (ColorStream
HD2)
BD/DVD
Video 1, Video 2, ColorStream HD1,
HDMI 1, HDMI 2, HDMI 3, HDMI 4,
PC (ColorStream HD2)
AUX
ANT/CABLE, Video 1, Video 2,
ColorStream HD1, HDMI 1, HDMI 2,
HDMI 3, HDMI 4, PC (ColorStream
HD2)
OK
OK
32
Chapter 6: Basic features
Tuning channels
Setting the Channel Tuning Mode
You can select how tuning is handled for analog and
digital channels when the TV is in Antenna mode.
Note: To use this feature, ANT/CABLE In must be set to
Antenna (-p. 28).
1 > Settings > SETUP > TV Settings > .
2Press B or b to highlight Channel Tuning Mode.
3Press C or c to select a mode. Press .
Note: The Channel Options screen and the Channel
Browser ANT/CABLE List are updated when you change
the mode. The History List is cleared, but the Favorites List
is saved.
Tuning in to the next programmed
channel
Press or on the remote control or TV control
panel.
Note: This feature does not work unless you store
channels in the TV’s channel memory (-p. 28).
Tuning in to a specific channel
(programmed or unprogrammed)
Using the Channel Browser™
The Channel Browser™ is a helpful navigational
interface for all of your channels and inputs.
Features:
•Navigate the contents of all of your inputs.
•Keep a list of your favorite channels.
•Keep a history of the last 32 channels or inputs
viewed.
•Quickly surf and tune to your recently viewed
channels/inputs from the Channel Browser™ History
List.
•Surf via Browse mode (to immediately tune to
channels as you highlight them in the
Channel Browser™) or Select mode (to surf channels
in the Channel Browser™ before you select one to tune
to).
•Quickly change inputs from the Inputs List.
•Quickly select HDMI® CEC devices from the HDMI-
CEC List.
To set up the Channel Browser™:
1 > Settings > PREFERENCES > Channel
Browser Setup > .
2Press b or B to highlight Navigation.
3Press C or c to select Select Mode or Browse
Mode.
4Select a list.
•History List
•ANT/CABLE List
•Inputs List
•Favorites List
•HDMI-CEC List
Note:
•The History List will be cleared every time the TV is
powered off.
•The HDMI-CEC List is not available when Enable
HDMI-CEC Control is set to Off (- p. 39).
5Select On or Off.
6To return to factory defaults, highlight Reset and
press .
To open the Channel Browser™:
• > APPLICATIONS > Channel Browser > .
•Press or .
Mode Description
Standard You can tune both analog and digital
channels normally.
Auto
(default)
Digital channels have priority when
manually entering a channel number
using the 0-9 buttons on the remote. To
tune analog channels, use / if
available.
Digital You can only tune digital channels.
Channel Description
Analog
Use the 0–9 buttons on the remote
control. (For example, to select
channel 125, press 1, 2, 5.) Press .
Digital
Use the 0–9 buttons on the remote
control to enter the major channel
number. Press the dash ( ) button.
Enter the sub-channel number. (For
example, to select digital channel 125-
1, press 1, 2, 5, –, 1.) Press .
OK
CH
CH
CH
CH
OK
-
OK
OK
OK
OK
33
Chapter 6: Basic features
Elements of the Channel Browser™
1Channels stored in the current list
2Channel or input that is currently highlighted in the
browser
3Inputs or channels labels
4Input type
5Current list (History, ANT/CABLE, Inputs,
Favorites, or HDMI-CEC)
6Channel or input currently being viewed
To cycle through the available lists:
1Open the Channel Browser™.
2Press B or b.
Note:
•The History List opens by default. After selecting
another list, the Channel Browser™ will open in the last
selected list.
•If all lists are turned off, or will not display the
Channel Browser™. If Favorites List is turned off,
pressing will not display the Favorites Browser.
•Pressing opens the Channel Browser™ Favorites
list regardless of the last selected list in the Channel
Browser™.
To tune to a channel or input in Browse mode:
1Highlight an item. The TV tunes to the channel or
input.
2Press to close the Channel Browser™.
To tune to a channel or input in Select mode:
1Highlight the item you want to tune to.
2Press .
3Press to close the Channel Browser™.
Favorites Browser
You can quickly create a favorite channels/inputs list
that is integrated into the Channel Browser™.
To add a favorite channel or input:
1Tune to the channel or input.
2Press and hold for 3 seconds.
Note: Additions are added to the beginning of the
Favorites list on the left side of the Channel Browser™.
To delete a favorite channel or input:
1Press . The Favorites Browser list appears.
2Select a channel or input by pressing C or c.
3Press and hold for 3 seconds.
Adding and clearing channels and inputs in the
History List
Adding channels to the History List:
As a channel or input is tuned, the Channel Browser™
adds it to the History List and displays it on the right
side of the Channel Browser™.
Previously tuned channels and inputs shift to the left.
Press C to surf back through the previously tuned
channels and inputs.
The Channel Browser™ stores these channels:
•Channels that are tuned using the numeric buttons on
the remote control.
•Channels that are tuned for at least 5 seconds using
or .
To clear channels from the History List:
•Reconfigure the ANT/CABLE input.
•Turn off the TV.
ANT/CABLE
History List
Channel Browser
Video 2
Video 1 ColorStream HD HDMI 1 88
abs
9
ANT
1080i
VCR
5
1
24
3
6
OK
-
CH
CH
34
Chapter 6: Basic features
Using Channel Return
You can switch between two channels without entering
a channel number each time. This feature also works for
external inputs.
1Select the first channel you want to view.
2Select a second channel using the Channel Number
buttons (and the dash ( ) button if needed).
3Each time you press , the TV switches back
and forth between the last two channels that were
tuned.
Using SurfLock™
The SurfLock™ feature temporarily memorizes one
channel to the button, so it can be quickly
returned to from any other channel. This feature also
works for external inputs.
To memorize a channel to the button:
1Tune to the channel you want to program to the
button.
2Press and hold for about 2 seconds until the
message “Memorized” appears. The channel has
been programmed to the button.
3You can then change channels repeatedly, and
when you press , the memorized channel will
be tuned.
After pressing and then changing channels again,
the memory is cleared and the button functions as
Channel Return.
Selecting the video input to view
To select the video input to view:
1Press on the remote control or TV control
panel.
2Change the input:
•Press 0–8.
•Repeatedly press B or b. Press .
•Repeatedly press .
Note:
•You can label the video input sources according to the
specific devices you have connected to the TV
(- “Labeling video inputs” on p. 30).
•You can skip sources (- “Skipping video inputs” on p.
29).
•Inputs that are set to be skipped will not be available and
will be skipped when selecting inputs by repeatedly
pressing or B or b.
•You can select inputs that are set to be skipped using the
number buttons.
•If one or more HDMI® CEC devices are connected to an
HDMI input, the icon ( ) appears in the input selector.
In this case, the label (- p. 30) will not appear on the
input selector.
•When the Auto Input feature is set, you can select a video
input source with the remote control by pressing and
holding the corresponding MODE SELECT button for 2
seconds (- p. 31).
To select an HDMI® CEC device:
1Press B or b to select an HDMI input.
2Press c. The list of HDMI® CEC devices for that
input appears.
3If the input has multiple HDMI® CEC devices, use
B or b to select a device.
4Press .
-
CH RTN
CH RTN
CH RTN
CH RTN
CH RTN
CH RTN
CH RTN
CH RTN
INPUT
OK
INPUT
Inputs
ANT/CABLEANT/CABLE
0
1Video 1
5HDMI 2
6HDMI 3
3ColorStream HD1
HDMI 1
4
2Video 2
7HDMI 4
8PC
INPUT
OK
35
Chapter 6: Basic features
Using closed captions
To turn on the closed caption mode:
1 > Settings > SETUP > TV Settings > .
2Press b or B to select Closed Captions Settings.
Press .
3Press b or B to select Closed Captions.
4Press C or c to select On.
Note: If Closed Captions is set to Off, Analog CC Mode
and Digital CC Settings will be not available.
Analog CC mode
The closed caption mode has two options:
To view captions or text:
1 > Settings > SETUP > TV Settings > .
2Press b or B to select Closed Captions Settings.
Press .
3Press b or B to select Analog CC Mode.
•To view captions:
Press C or c to highlight CC1, CC2, CC3, or CC4.
Note: If the program or video you have selected is
not closed captioned, no captions will be displayed.
•To view text:
Press C or c to highlight T1, T2, T3, or T4.
Note: If text is not available in your area, a black
rectangle may appear on the screen. You may set
Closed Captions Settings to Off.
Note: A closed caption signal may not display when a
videotape is dubbed, signal reception is weak, or signal
reception is non-standard.
Digital CC settings
You can customize the closed caption display
characteristics.
Note:
•These settings are available for digital channels only.
•You cannot set Caption Text and Background as the
same color.
To customize the closed captions:
1 > Settings > SETUP > TV Settings > .
2Press b or B to select Closed Captions Settings.
Press .
3Press B or b to select Digital CC Settings. Press .
4Press B or b to select a characteristic. Press C or c
to select the format for that characteristic.
Using the Closed Caption button
If you press when an analog channel is tuned or
from an external input (480i signal from the video
input):
•The CC bar will appear and will display CC1-4, T1-4,
and Off as the options.
If you press when a digital channel is tuned:
•The CC bar will appear and will display the available
caption options (available languages) for that channel
or service.
Mode Description
Captions
Displays the dialogue, narration, and sound
effects of TV programs and videos that are
closed captioned (usually marked “CC” in
program guides).
Text
Displays information not related to the
current program, such as weather or stock
data (when provided by individual stations).
OK
OK
OK
OK
Giant pandas eat leaves.
WORLD WEATHER
Temps Current
F C Weather
LONDON 51 11
MOSCOW
PARIS
ROME
TOKYO
57 14
53 12
66 19
65 18
Cloudy
Clear
Cloudy
Rain
Clear
Mode Description
Caption Size Auto, Small, Standard, Large
Caption Text
Type
Auto, Mono w. Serif, Prop. w. Serif,
Mono w/o Serif, Prop. w/o Serif,
Casual, Cursive, Small Capitals
Caption Text
Edge
Auto, None, Raised, Depressed,
Uniform, Left Drop Shadow, Right
Drop shadow
Caption Text
Color
Auto, Black, White, Red, Green, Blue,
Yellow, Magenta, Cyan
Text Foreground
Opacity
Auto, Transparent, Translucent,
Flashing, Solid
Background
Color
Auto, Black, White, Red, Green, Blue,
Yellow, Magenta, Cyan
Text
Background
Opacity
Auto, Transparent, Translucent,
Flashing, Solid
Caption Text
Edge Color
Auto, Black, White, Red, Green, Blue,
Yellow, Magenta, Cyan
OK
OK
OK
CC
CC
36
Chapter 6: Basic features
Setting the PIN code
A PIN code is necessary for some menus.
Note: The Parental Control and Locks menu is grayed
out if no PIN has been set.
Entering a new PIN code
1 > Settings > PREFERENCES > PIN Setting >
.
2Use the number buttons to enter a 4-digit number.
Confirm the code.
Note: The PIN code cannot be set to “0000”.
Changing or deleting your PIN code
1 > Settings > PREFERENCES > PIN Setting >
.
2Use the number buttons to enter your 4-digit PIN
code.
3Select Change PIN or Delete PIN. Press .
Note:
•The PIN code cannot be set to “0000”.
•If you delete the PIN code, the settings of Parental
Controls and Locks are reset.
Forgotten PIN code
1 > Settings > PREFERENCES > PIN Setting >
.
2Press Q 4 times within 5 seconds. The code is
cleared.
3Enter a new PIN code.
Using parental controls
Blocking TV programs and movies by
rating (V-Chip)
Some TV programs and movies include signals that
classify the content of the program as unsuitable for
younger viewers. The V-Chip feature in this TV
detects the signals and blocks the programs according
to the ratings you select.
Note: The V-Chip feature in this TV supports the U.S. V-
Chip system only.
1 > Settings > PREFERENCES > Parental
Control and Locks > .
2Enter your 4-digit PIN code.
3Press B or b to highlight Enable Rating Blocking.
4Press C or c to select On.
5Press b to select Edit Rating Limits. Press .
The Edit Rating Limits screen appears.
6Press B, b, C or c.
7Press to select a level of blocking.
A box with an “5” indicates a rating that will be
blocked. As you highlight a rating, the rating’s
definition appears at the bottom of the screen.
Note: This feature will be not available if no PIN code is
set.
OK
OK
OK
OK
OK
OK
OK
37
Chapter 6: Basic features
Downloading an additional rating
system
In the future, an additional rating system may become
available for use in selectively blocking TV programs and
movies.
Note: The currently tuned station must be receiving a
digital signal before an additional rating system can be
downloaded.
1 > Settings > PREFERENCES > Parental
Control and Locks > .
2Enter your 4-digit PIN code. The Parental Control
and Locks screen appears.
3Press B or b to highlight Enable Rating Blocking.
4Press C or c to select On.
5Press b to select Edit Rating Limits. Press . The
Edit Rating Limits screen appears.
6Select Alt RS. Press . The Edit Alternate Ratings
screen appears.
Note:
•The Alt RS button is only available if an additional
rating system is currently available.
•The download may take several minutes.
•The information displayed on the Alternate Ratings
screen depends on the configuration of the
additional rating system available at the time of
download.
7Press B, b, C, or c.
8Press to select the desired level of blocking. A
box with an “5” indicates the rating that will be
blocked.
Note:
•You can only download the additional rating system
once. You cannot download updates if they become
available.
•The additional rating system is not designed,
transmitted, or controlled by the TV or Toshiba, nor is the
availability of an additional rating system determined or
controlled by Toshiba. Similarly, the rating of programs in
an additional rating system is not determined,
transmitted, or controlled by the TV or Toshiba.
•The additional rating system is an evolving technology;
therefore, availability, content, and format may vary.
Rating system
OK
OK
OK
OK
Independent rating system for broadcasters
Ratings Description and Content themes
TV-MA
Mature Audience Only (This program is
specifically designed to be viewed by
adults and therefore may be unsuitable for
children under 17.)
L) Crude or indecent language S) Explicit
sexual activity V) Graphic violence
TV-14
Parents Strongly Cautioned (This program
contains some material that many parents
would find unsuitable for children under
14 years of age.)
D) Intensely suggestive dialogue L)
Strong, coarse language S) Intense sexual
situations V) Intense violence
TV-PG
Parental Guidance Suggested (This
program contains material parents may
find unsuitable for younger children.)
D) Some suggestive dialogue L)
Infrequent coarse language S) Some
sexual situations V) Moderate violence
TV-GGeneral Audience (Most parents would
find this program suitable for all ages.)
TV-Y7,
TV-Y7FV
Directed to Older Children (This program
is designed for children age 7 and above.
Note: Programs in which fantasy violence
may be more intense or more combative
than other programs in this category are
designated TV-Y7FV.)
TV-Y All Children (This program is designed to
be appropriate for all children.)
Independent rating system for movies
Ratings Description and Content themes
XX-rated (For adults only)
NC-17 Not intended for anyone 17 and under
RRestricted (Under 17 requires
accompanying parent or adult)
PG-13 Parents Strongly Cautioned (Some material
may be inappropriate for children under 13)
PGParental Guidance Suggested (Some
material may not be suitable for children)
GGeneral Audience (Appropriate for all ages)
38
Chapter 6: Basic features
Note:
•If you place an “5” in the box next to “Rated “None””,
programs rated “None” or “Not Rated” will be blocked;
Programs that do not provide any rating information will
not be blocked.
Displaying ratings
To display the rating of the program you are watching,
press Q on the remote control.
Unlocking programs
If you try to tune to a program that exceeds the rating
limits you have set, the TV will enter program lock
mode and a warning message will appear onscreen.
Follow the instructions to temporarily unlock the
program.
Locking specific channels
A channel that is configured as Locked cannot be
viewed unless the PIN code is entered first (- “Setting
the PIN code” on p. 36).
1 > Settings > SETUP > TV Settings > .
2Press B or b to select Channel Options. Press .
The list of channels appears.
3Press c and then B or b to select a channel in the
lock column, then press .
4You must enter your PIN code to be able to lock
channels.
Note: If no PIN code has been set, a warning appears.
5The box is selected. To clear the selection, press .
Locking video input
You can lock video inputs and channels 3 and 4. You
cannot view the input sources or channels until you
unlock the inputs by entering the PIN code.
1 > Settings > PREFERENCES > Parental
Control and Locks > .
2Enter your 4-digit PIN code.
3Press B or b to highlight Input Lock.
4Press C or c to select Video, Video+, or Off.
Indication other than rating system
Display Description
NONE The program is rated None.
(No rating appears) No rating information is
provided.
Mode Description
Video
Locks Video 1, Video 2, ColorStream HD1,
ColorStream HD2, HDMI 1, HDMI 2, HDMI 3,
HDMI 4, and PC.
Video+
Locks Video 1, Video 2, ColorStream HD1,
ColorStream HD2, HDMI 1, HDMI 2, HDMI 3,
HDMI 4, PC, and channels 3 and 4.
• Select Video+ if you are playing video tapes
via the ANT/CABLE input.
Off Unlocks all video inputs and channels 3 and 4.
OK
OK
DTV
ATV
DTV
ATV
ATV
ATV
ATV
ATV
6
5-1
6-1
8
9
10
11
12
Ch. Type Label
Channel Options
OK
OK
OK
39
Chapter 6: Basic features
Setting a time limit for games
You can use the GameTimer® to set a time limit for
playing a video game. When the time expires, the TV
locks all external inputs.
1 > Settings > PREFERENCES > Parental
Control and Locks > .
(Another: > Timer > GameTimer > .)
2Enter your 4-digit PIN code.
3Press B or b to select GameTimer.
4Press C or c to select 30, 60, 90, or 120 minutes.
5To cancel the timer, select Off.
To deactivate the Input Lock once the GameTimer® has
activated it:
Set the Input Lock to Off (- “Locking video input” on
p. 38).
Note:
•A message appears when 10 minutes, 3 minutes, and 1
minute remaining.
•If the TV loses power with time remaining, the TV will
enter Input Lock mode when power is restored (as if the
GameTimer had been activated). You must deactivate
the Input Lock (- “Locking video input”).
Locking the control panel
You can lock the control panel to prevent your settings
from being changed accidentally (by children, for
example). When Panel Lock is set to On, none of the
controls on the control panel operate except POWER.
1 > Settings > PREFERENCES > Parental
Control and Locks > .
2Enter your 4-digit PIN code.
3Press B or b to select Panel Lock.
4Press C or c to select On.
Note: When Panel Lock is set to On, “Panel Lock”
appears onscreen when the buttons on the TV control
panel are pressed. If the POWER button is pressed,
the TV turns off and you must use the remote control to
turn it on.
To unlock the control panel:
Select Off in Step 4 above.
Using HDMI® CEC Control
This feature uses CEC technology and allows you to
control Toshiba HDMI® CEC compatible devices from
the TV remote control via HDMI connection.
When Enable HDMI-CEC Control in the HDMI-CEC
Control Setup menu is set to On, the following HDMI®
CEC Control functions are enabled.
To set HDMI® CEC Control Setup:
1 > Settings > PREFERENCES > HDMI-CEC
Control Setup > .
2Press B or b to highlight Enable HDMI-CEC
Control.
3Press C or c to select On.
Note: If you set Enable HDMI-CEC Control to Off,
the other items under HDMI-CEC Control Setup will be
grayed out.
4Press B or b to select an item. Press C or c to select
On or the desired mode.
•TV Auto Power: On/Off
•Auto Standby: On/Off
•Amplifier Control: On/Off
•Speaker Preference: TV Speakers/Amplifier
Note: These functions depend on the connected devices.
OK
OK
OK
OK
40
Chapter 6: Basic features
Controlling HDMI® CEC playback
devices
With your TV’s remote control, you can control the
connected HDMI® CEC playback device (DVD player,
etc.) you are watching.
Available remote control key functions:
Before using these key functions, set the MODE
SELECT switch on the remote control to TV.
Note: These functions depend on the connected devices.
HDMI® CEC Player Control menu functions:
1Press to open the Quick menu.
2Select HDMI-CEC Player Control. Press .
3Press B or b to select the item you want to control
and press .
Note:
•These functions depend on the connected devices.
•The HDMI-CEC Player Control item is not available under
these conditions:
-A non-HDMI input is selected.
-The Enable HDMI-CEC Control item is set to Off.
-The connected HDMI® CEC device is not a playback or
recording device.
HDMI® CEC Control input source
selection
If an HDMI® CEC device with HDMI switching
capability (e.g. an amplifier) is connected to the HDMI
input, you can select another HDMI® CEC device that is
connected to the master HDMI device.
Use on the remote control or the control panel
(- p. 34).
Button Description
Begins playback.
Stops playback.
Pauses the picture during play or record
mode.
Skips forward.
Skips backward.
Fast-forwards.
Rewinds/reverses.
B b C cNavigates contents menu, etc.
Enters contents menu, etc.
Closes the menu.
RED,
GREEN,
YELLOW,
BLUE
Controls various operations
OK
Item Description
Power Turns the selected device on and off.
Root Menu Accesses the selected device’s top menu.
Contents
Menu
Accesses the contents list when you press
.
Setup Menu Accesses the device’s setup menu.
QUICK
OK
OK
OK
INPUT
41
Chapter 6: Basic features
Adjusting the amplifier’s audio
Using the TV’s remote control, you can adjust or mute
the sound volume of your amplifier.
• adjust the volume level.
• turns off the sound.
Note: This feature is available when Amplifier Control is set
to On.
1 > Settings > PREFERENCES > HDMI-CEC
Control Setup > .
2Press B or b to highlight Speaker Preference.
3Press C or c to select Amplifier.
Note: Confirm that a connected HDMI® CEC device
(such as DVD player, etc.) is selected for the Amplifier
input source.
Note:
•You can also use this function when the amplifier is
connected to the TV’s DIGITAL AUDIO OUT terminal
(not HDMI connection). Select a digital audio input mode
on the amplifier.
•These functions depend on the device connected.
Other HDMI® CEC Control functions
When Enable HDMI-CEC Control and all items in the
HDMI-CEC Control Setup menu are set to On, the
following functions will be enabled.
Note: When you turn on the amplifier, change its input
source, or adjust the sound volume, the sound will be
output from the amplifier’s speakers even if TV Speakers
has been selected. Turn the TV off and on again to output
the sound from the TV speakers.
Using the HDMI® settings feature
Note: If some HDMI legacy sources do not work properly
with your HDMI TV, set INSTAPORT™ to Off. Adjusting this
setting should allow your HDMI legacy source to operate
properly with your TV.
The RGB Range setting requires appropriate HDMI
source devices. If your HDMI source device does not
support this feature, the TV may not work properly
when it is enabled.
Note: If your HDMI connection is capable of 1080p and/or
your TV is capable of refresh rates greater than 60 Hz, you
will need a High Speed HDMI® cable. Conventional HDMI/
DVI cables may not work properly with this mode.
1Select the appropriate HDMI input mode (HDMI 1,
HDMI 2, HDMI 3, or HDMI 4).
2 > Settings > PREFERENCES > AV
Connection > .
3Press B or b to select HDMI Settings. Press .
4Press B or b to select an item.
5Press C or c to select a setting.
Viewing the HDMI® signal
information
1 > Settings > PREFERENCES > HDMI
Information Display.
2Press C or c to select On. Press Q. The normal
banner and signal information banner appear.
Note:
•The signal information banner will appear when this
feature is set to On and you watch an HDMI input.
•If you press Q when this feature is set to Off, only the
normal banner will appear.
Item Description
TV Auto
Power
If a HDMI® CEC device is turned on, the
TV turns on automatically.
Auto Standby
If the TV is turned off, it will send a
message to turn off all of the HDMI® CEC
devices connected to the TV.
Amplifier
Control
If Amplifier Control is set to On, you can
adjust the sound volume or turn off the
sound using the remote control.
Speaker
Preference
From this item, you can set your audio
output preference to the TV speakers or
the amplifier. When this item is set to
Amplifier, the remote control can be used
to adjust or mute the volume of the
audio. This item will not be available and
set to TV Speakers automatically unless
a HDMI® CEC compatible audio receiver
is connected.
VOL
VOL
OK
Mode (default setting) Description
INSTAPORT™: On Reduces the lag time when
switching HDMI sources.
RGB Range: Auto
Adjusts the RGB full range signal
automatically.
When Limited is selected, the RGB
output signal is output in the range
of 16 to 235. When Full is selected,
the RGB output signal is output in
the range of 0 to 255.
OK
OK
42
Chapter 6: Basic features
Using your PC with the TV
Adjusting the image
If the edges of the picture are hidden, readjust
Horizontal Position and Vertical Position. If the
picture is affected by interference, readjust Clock
Phase and Sampling Clock.
1Select PC input mode (- “Selecting the video input
to view” on p. 34).
2 > Settings > PREFERENCES > Display
Settings > .
3Press B or b to select PC Settings. Press .
Note: If a PC is not connected or there is no PC input
signal, this menu will not be available.
4Press B or b to select an item.
5Press C or c to make adjustments.
Note: The screen is disrupted momentarily when
adjusting the PC settings. This is not a sign of
malfunction.
* The default settings and /or adjustment ranges vary
depending on the input signal format.
To reset PC Settings:
Select Reset. Press .
Setting the PC audio
You can output sound from your PC when connecting
it to your TV, using the AUDIO IN terminal and PC
audio cable.
1 > Settings > PREFERENCES > AV
Connection > .
2Press B or b to select Rear Shared Audio.
3Press C or c to select PC.
Note: Set Shared PC Input to PC to make the PC item
selectable (- p. 30).
Setting the timer to turn on the TV
You can set the on timer to turn on the TV to a preset
channel or input at a preset time.
To activate the timer:
1 > Settings > APPLICATIONS > On Timer >
.
(Another: > Timer > On Timer > .)
2Press B or b to select Enable On Timer.
3Press C or c to select On.
Note: If the Enable On Timer is set to Off, other menus
under On Timer cannot be changed.
To set the timer:
1 > Settings > APPLICATIONS > On Timer >
.
2Set these options to your preference:
3Select Done. Press .
Note: If you do not operate the TV for 1 hour after it is
powered on by the On Timer feature, it turns off.
To cancel the timer:
1 > Settings > APPLICATIONS > On Timer >
.
2Press B or b to select Enable On Timer.
3Press C or c to select Off.
Mode Description Adjustment range
Horizontal
Position
Moves the picture left/
right.
within ±10 from
center.*
Vertical
Position
Moves the picture up/
down.
within ±10 from
center.*
Clock Phase Helps to reduce noise
and sharpen the picture.
within ±15 from
center.
Sampling
Clock
Helps to reduce noise
and minimize periodic
vertical stripes on the
screen.
within ±5 from
center.
OK
OK
OK
OK
Item Description
Input Video input source.
Channel Channel to view.
Volume Volume level.
Time until
Power On
Desired length of time until the TV
turns on.
minimum= 00:10, maximum= 12:00
•Press C or c.
•Use the number buttons.
OK
OK
OK
OK
OK
43
Chapter 6: Basic features
Setting the sleep timer
You can set the TV to turn off after a specific amount of
time (maximum = 12 hours).
Using the remote control:
1Press [
2Set the time until the TV turns off.
•Repeatedly press [ to increase the time.
•Press B or b to increase or decrease the time.
Using the onscreen menus:
1 > Settings > APPLICATIONS > Sleep Timer.
(Another: > Timer > Sleep Timer > .)
2Enter the time until the TV turns off.
•Use the number buttons.
•Press C or c to increase or decrease the time.
Note: If a power failure occurs, the sleep timer setting may
be cleared.
To display the time remaining until the TV turns off:
Press [.
To cancel the sleep timer:
Press [ repeatedly or press B or b until it is set to 0
minutes.
Setting Automatic Power Down
The TV can be configured to automatically turn itself off
after 4 hours if you do not operate the TV either from
the remote control or the TV control panel.
1 > Settings > PREFERENCES > Energy
Saving Settings > .
2Press B or b to select Automatic Power Down.
3Press C or c to select On. Press .
Note: When the following features are set, the feature that
is set for the nearest time will function.
– Automatic Power Down
– Sleep Timer
– Wallpaper/Auto Power Off
– Auto shutdown after 1 hour of inactivity (after powering
on by On Timer)
– No signal auto power off (after 14 minutes of no signal)
Setting No Signal Power Down
When an input's setting in this feature is set to On, The
TV will automatically turn itself off after 14 minutes if
no signal is detected.
You can change each input's setting to Off: ANT/
CABLE, Video 1, Video 2, ColorStream HD1,
ColorStream HD2, HDMI 1, HDMI 2, HDMI 3, HDMI 4,
PC
1 > Settings > PREFERENCES > Energy
Saving Settings. Press .
2Press B or b to select No Signal Power Down.
Press .
3Press B or b to highlight the item you want to
change.
4Press C or c to select On or Off. Press .
Note:
•Default setting for each input is On.
•A warning message will appear 1 minute before turning
off.
OK
OK
OK
OK
44
Chapter 6: Basic features
Displaying TV status information
To display TV status information:
Press Q.
The following information will be displayed
(if applicable):
•Current input (ANT/CABLE, Video, etc.)
•Either “CABLE” (for cable TV) or “ANT” (for overthe-
air broadcasts), if ANT/CABLE is the current input.
•Channel number (if in ANT/CABLE mode)
•Input label (if set)
•Digital signal strength indicator (bar graph in lower
right corner of box; for ATSC signals only)
•Stereo, Mono, or SAP audio status (when in HDMI
input mode, PCM)
•Video resolution
•Aspect ratio of incoming video signal (4:3 or 16:9)
•V-Chip rating status (if available)
•GameTimer (if set)
•Channel Label (if set or received)
To close the screen:
Press Q again.
The following additional information (only available
for ANT/CABLE input) will display for off-air digital
channels (if applicable):
•Title
•Duration
•Detailed description
To display the next program's information for digital
channels, press Q again. Pressing Q a third time will
remove the entire banner.
Viewing support information
1 > Settings > SETUP > System Information.
2Press to display support information containing
Web/Customer service numbers for US, Canada,
and Mexico.
Resetting to Factory Defaults
You can reset all settings and channels.
1 > Settings > SETUP > Reset TV > .
2Enter your PIN code (if a PIN code has been set).
3A confirmation screen appears. Select Yes, and
press . The TV will turn off automatically.
To cancel the reset:
Press C or c to select No. Press .
Power failure
If power is lost while you are watching the TV, the
Last Mode Memory feature automatically turns on the
TV when power is restored.
2-2
ANT
Nashville WX Channel
Nashville WX Channel provides Middle Tenessee and Southern Kentucky
weather.
8:59am - 4:59pm EST
480i
4:3
NONE
OK
OK
OK
OK
45
Chapter 7: Picture and sound controls
Selecting the picture size
You can view many program formats in several picture
sizes—Native, 4:3, Full, TheaterWide 1, TheaterWide
2, TheaterWide 3, Normal, and Dot by Dot.
Note: The picture size illustrations are examples only. The
format of the image (in any of the picture sizes) depends
on the format of the signal you are currently watching.
Select the picture size that displays the current program in
the way that looks best to you.
You can save separate picture size preferences for each
input on your TV.
To select the picture size:
1Press I.
2While the Picture Size screen is open, do one of the
following:
•Repeatedly press I.
•Press the corresponding number button.
•Press B or b and .
Note: Some picture sizes may not be available depending
on the format of the signal being received.
Note: If you select a TheaterWide® picture size, the top
and bottom edges of the picture (including subtitles or
captions) may be hidden. To view these edges, adjust the
Picture Position (-”Scrolling the picture” on p. 47) or try
viewing the program in 4:3 or Full.
Using these functions to change the picture size (i.e.,
changing the height/width ratio) for any purpose other
than your private viewing may be prohibited under the
Copyright Laws of the United States and other
countries, and may subject you to civil and criminal
liability.
OK
46
Chapter 7: Picture and sound controls
* To view the hidden areas (such as subtitles or captions), see
“Scrolling the picture” (-p. 47).
Picture Size
Native
(for 480i (HDMI), 480p (HDMI), 720p, 1080i, and 1080p signal
programs)
•If receiving a 1080i, 1080p, 720p, 480i (HDMI), or
480p (HDMI) signal program, the video is scaled to
display the entire picture within the borders of the
screen (i.e. no overscanning).
•This is especially useful for external HD sources
such as DVHS movies, Video Games, or PC
graphics.
•None of the picture is hidden.
Note:
•This mode is supported only for HDMI (1080i, 1080p,
720p, 480i, and 480p), ColorStream® (1080i and
720p), and ANT/CABLE (digital) inputs (1080i, 1080p,
and 720p).
•Depending on the input signal, the picture’s border
may be hidden, displayed in black, or noisy.
4:3
Some program formats will display with sidebars and/or
bars at the top and bottom.
Full
(for 16:9 [480i, 480p] source programs only)
If receiving a squeezed 4:3 format program, the picture is
stretched horizontally to fill the width of the screen but
not stretched vertically.
(for 1080i, 1080p, and 720p program sources)
The edges of the picture may be hidden.
TheaterWide 1
(for 4:3 format programs)
The center of the picture remains close to its original
proportions, but the left and right edges are stretched
horizontally to fill the screen.
TheaterWide 2
(for letter box programs)
The picture’s top and bottom edges may be hidden*.
TheaterWide 3
(for letter box programs with subtitles)
The picture’s top and bottom edges are hidden*.
Normal
(for SVGA, XGA, WXGA, and SXGA sources)
This size is a non-stretched display. Some input signal
formats will display with sidebars and/or bars at the top
and bottom.
Dot by Dot
(for SVGA, XGA, WXGA, and SXGA sources)
“Dot by Dot” is a non-scaling display. Depending on the
input signal format, the picture is displayed with sidebars
and/or bars at the top and bottom. (Example: SVGA
input source)
Picture Size
A B C D E F G - - - - - - - - - - - - - - - -
A B C D E F G - - - - - - - - - - - - - - - -
A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -
47
Chapter 7: Picture and sound controls
Scrolling the picture
If the edges of the picture are hidden, you can adjust the
image’s position.
Note:
•You can adjust the picture position when the picture size
is set to TheaterWide 2 or TheaterWide 3.
•When viewing DTV, NET TV, or Media Player, this feature
is not available.
1 > Settings > PREFERENCES > Display
Settings > .
2Press B or b to select Picture Position. Press .
3Press B or b to select Vertical Position.
4Press C or c to make the appropriate adjustments.
The adjustment range is from -5 to +10. Press .
Using the Auto Aspect feature
When this feature is set to On, the TV will automatically
select the picture size when one of the following input
sources is received:
•A 480i, 480p, 720p, 1080i digital signal from the ANT/
CABLE input
•A 480i signal from the ColorStream HD or Video
input
•A 480i, 480p, 720p, 1080i, 1080p, or VGA (60/72/75
Hz) signal from the HDMI 1/2/3/4 input
Note: The auto aspect ratio feature is not applicable to the
PC input.
1 > Settings > PREFERENCES > Display
Settings > .
2Press B or b to select Auto Aspect.
3Press C or c to select On. Press .
Using the 4:3 Stretch
When 4:3 Stretch is activated, the TV displays 4:3
programs as a full-screen picture.
Note: This feature is available when Auto Aspect is set to
On.
1 > Settings > PREFERENCES > Display
Settings > .
2Press B or b to select 4:3 Stretch.
3Press C or c to select On. Press .
Freezing the picture
1When watching the TV, press B to freeze the
picture.
2To unfreeze the picture, press B again.
Note: After 15 minutes, the picture will unfreeze
automatically.
OK
OK
OK
Using the FREEZE function for any purpose other than
your private viewing may be prohibited under the
Copyright Laws of the United States and other
countries, and may subject you to civil and criminal
liability.
OK
48
Chapter 7: Picture and sound controls
Adjusting the picture
Selecting the picture mode
You can select your desired picture settings from the
modes described below.
Note:
•PC mode is available for HDMI and PC inputs only (not
displayed for other input sources).
•Game mode cannot be turned on when the ANT/CABLE
input is selected.
1 > Settings > PICTURE > Picture Mode.
2Press C or c to select a mode. Press .
Note:
•The picture mode you select affects the current input
only. You can select a different picture mode for each
input.
•The picture mode can be changed to Game mode by
pressing when the input mode is ColorStream HD,
PC, VIDEO, or HDMI.
Adjusting the picture quality
The adjustments you make to picture quality under a
picture mode are saved to that picture mode.
* Backlight: Adjusts the brightness of the entire screen. When
in video mode and no signal is input, this selection is set to 0.
(Settings are stored in memory.)
Note: Some settings cannot be adjusted in any of the
following cases.
• AutoView is selected.
• TheaterLock is set to On.
To adjust the picture quality:
1 > Settings > PICTURE > the setting you
would like to adjust (Backlight, Contrast,
Brightness, Color, Tint, or Sharpness).
2Press C or c to adjust the setting. Press .
Note:
•Any picture settings that you adjust affect the current
input only. You can adjust the picture quality separately
for each input.
•Depending on a Sharpness value, the Edge Enhancer
effect may be reduced.
To reset to the factory defaults:
1Select the picture mode you want to reset.
2 > Settings > PICTURE > Reset > . A
confirmation screen appears.
3Press C or c to select Yes. Press .
Mode Description
AutoView®
Automatically adjusts picture settings
based on ambient light conditions and
input signal content.
Sports Bright and dynamic picture.
Standard Standard picture settings.
Movie 1 Lower contrast for darkened room.
Movie 2
Game
Designed for playing a video game
requiring split-second timing between
the screen display and input from the
controller.
PC Designed for the viewing of PC tables
and documents.
Selection Pressing C Pressing c
Backlight* darker lighter
Contrast lower higher
Brightness darker lighter
Color paler deeper
Tint reddish greenish
Sharpness softer sharper
OK
OK
49
Chapter 7: Picture and sound controls
Using the advanced picture
settings features
Note: Some of the Advanced Picture Settings features will
not be available for adjustment when the Picture Mode is
set to AutoView.
Edge Enhancer
The Edge Enhancer feature lets you adjust the levels for
your desired picture settings and achieve a sharper
picture.
To set Edge Enhancer:
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Edge Enhancer. Press .
3Press C or c to select On.
4Press B or b to highlight Level. Press C or c to
select either 1, 2, 3, 4, or 5. Press .
Note:
•When the Picture Mode is set to AutoView, the level
range is from -2 to +2.
•If the Picture Mode is set to Game or PC, Edge
Enhancer is not available.
•This feature may not work properly depending on the
content.
•Noise may appear on the image depending on the
device connected to the TV (e.g. a device with a specific
enhancer function).
Dynamic Contrast
Dynamic Contrast detects changes in picture quality
that affect the appearance of your contrast settings and
then automatically adjusts the video.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Dynamic Contrast.
3Press C or c to adjust the level. The adjustment
range is from 0 to 10. Press .
Note: When the Picture Mode is set to AutoView, the level
range is from -5 to +5.
DynaLight™
The DynaLight™ feature automatically strengthens the
black coloring of dark areas in the video according to
the level of darkness.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select DynaLight.
3Press C or c to select On or Off. Press .
Static Gamma
The static gamma feature lets you adjust the levels of
black in the picture.
To adjust the static gamma settings:
1Y > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Static Gamma.
3Press C or c to adjust the level. The adjustment
range is within ±15 from center. Press .
Film Stabilization
This feature helps to eliminate video shaking.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Film Stabilization.
3Press C or c to select Smooth, Standard, or Off.
Press .
Note: If the Picture Mode is set to Game, this feature will be
set to Off automatically and grayed out.
OK
OK
OK
OK
OK
OK
50
Chapter 7: Picture and sound controls
ClearFrame™
The ClearFrame 120 Hz anti-blur technology doubles
the frame rate from 60 frames per second to 120 frames
per second, virtually eliminating motion blur without
adding flicker or reducing image brightness.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select ClearFrame.
3Press C or c to select On. Press .
Note: If the Picture Mode is set to Game, this feature is not
available.
MPEG NR
The MPEG noise reduction feature allows you to reduce
visible interference caused by MPEG compression.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Noise Reduction. Press .
3Press B or b to highlight MPEG NR.
4Press C or c to select either Low, Middle, High, or
Off. Press .
Note: If the Picture Mode is set to Game or PC, this feature
is not available.
DNR
DNR lets you soften the screen representation of a weak
signal to reduce the noise effect.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Noise Reduction. Press .
3Press B or b to select DNR.
4Press C or c to select Low, Middle, High, Auto, or
Off. Press .
Note:
•If the Picture Mode is set to Game or PC, this feature is
not available.
•The differences may not always be noticeable. For the
best results, use lower settings, as picture quality may be
greatly reduced if the setting is too high.
Auto Brightness Sensor
When the Auto Brightness function of Auto Brightness
Sensor Settings is set to On, the TV optimizes the
backlighting levels to suit ambient light conditions.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Auto Brightness Sensor
Settings. Press .
3Press B or b to select Auto Brightness Sensor.
4Press C or c to select On or Off. Press .
Note: When the Picture Mode is set to AutoView, this
feature is automatically set to On and will not be available.
Backlight Adjustment Pro
This feature adjusts the backlight so that it can change
to match the ambient light conditions.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Auto Brightness Sensor
Settings. Press .
3Press B or b to select Backlight Adjustment Pro.
Press . The Backlight Control Level screen
appears.
4Press to display the adjustment window. Press C
or c to select the point. Press B or b to adjust the
level. The adjustment range is from 0 to 100.
5Press to fix the adjustment.
To cancel the adjustment when selecting a point,
select Cancel on the screen.
To reset the adjustments of all points to the factory
defaults, select Reset on the screen. Press .
Note: If the Auto Brightness Sensor is set to Off, this
feature will not be available.
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
Backlight Adjustment Pro
100
0
Backlight Control Level
Control
Level
Ambient Light
37
Cancel
Reset
OK
OK
51
Chapter 7: Picture and sound controls
ColorMaster™
The ColorMaster™ feature allows you to adjust
standard colors.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select ColorMaster, press C or c to
select On. Press .
Base Color Adjustment
When ColorMaster™ is set to On, the list of base colors
appears. You can select a base color to adjust.
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Base Color Adjustment.
Press . The Base Color Adjustment screen
appears.
3Press B or b to select a color. Press c.
4Press C or c to select Hue, Saturation, or
Brightness.
5Press B or b to adjust the setting.
6Repeat Steps 3 through 5 to adjust other colors.
To reset the adjustments to the factory defaults,
select Reset on the screen. Press .
Color temperature
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Color Temperature.
3Press C or c to adjust the level. The adjustment
range is 0 (warm) to 10 (cool). Press .
Note: When the Picture Mode is set to AutoView, the
adjustment range is -5 to +5.
Resetting to the factory default
1 > Settings > PICTURE > Advanced Picture
Settings > .
2Press B or b to select Reset. Press .
A confirmation screen appears.
3 Select Yes. Press .
Setting the Expert Picture Settings
Test Pattern
When the test pattern is on screen, you can navigate the
Picture submenus without removing the image. When
you move to a non-Picture menu, or close the menus,
regular video will be restored.
1 > Settings > PICTURE > Expert Picture
Settings > .
2Select Test Pattern.
3Press C or c to select On.
4Adjust picture settings.
RGB Filter
This feature individually enables or disables the red,
green, and blue components of the picture to allow for
more accurate adjustment of each color.
1 > Settings > PICTURE > Expert Picture
Settings > .
2Press B or b to select RGB Filter. Press .
3Press B or b to select Red, Green, or Blue to adjust.
4Press C or c to select On.
5Press b to select Color or Tint, press C or c to
adjust. Press .
Note: It is not possible to turn off all three colors
simultaneously.
White Balance
Window Display
This feature displays the Window Pattern to adjust the
white balance with a measuring device.
1 > Settings > PICTURE > Expert Picture
Settings > .
2Press B or b to select White Balance. Press .
3Press B or b to select Window Display.
4Press C or c to select On.
5Adjust picture settings.
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
52
Chapter 7: Picture and sound controls
Setting Type
You can adjust the white balance setting.
1 > Settings > PICTURE > Expert Picture
Settings > .
2Press B or b to select White Balance. Press .
3Press B or b to select 2P White Balance. Press .
4Press B or b to select Red-Offset, Green-Offset,
Blue-Offset, Red-Gain, Green-Gain, or Blue-
Gain. Press C or c to adjust. Press .
Copy to All Inputs
This feature copies White Balance on the current input
to all other inputs. Individual settings that are not
allowed for a specific input will not be copied.
1 > Settings > PICTURE > Expert Picture
Settings > .
2Press B or b to select White Balance. Press .
3Press B or b to select Copy to All Inputs. Press .
A confirmation screen appears.
4Select Yes. Press .
Resetting to the factory default
1 > Settings > PICTURE > Expert Picture
Settings > .
2Press B or b to select Reset. Press .
A confirmation screen appears.
3 Select Yes. Press .
Locking the picture settings
The TheaterLock™ feature lets you lock items in the
PICTURE menu that affect the picture’s display. These
items cannot be modified when TheaterLock is set to
On.
1 > Settings > PICTURE > TheaterLock.
2Press C or c to select On. Press .
Adjusting the audio
Muting the sound
Press to partially reduce (1/2 Mute) or turn off
(Mute) the sound. Each time you press , the mute
mode changes in the following order:
If the closed caption mode is set to Off when you select
MUTE mode, the closed caption feature becomes active
if the TV program is closed-captioned. To mute the
audio without activating the closed captioning, press
to set the volume to 0.
Note: If you modify items in the SOUND menu while Mute
is active, Mute is cancelled.
Selecting stereo/SAP broadcasts
The MTS (multi-channel TV sound) feature is only
available for analog signals on the ANT/CABLE input.
When the TV receives a stereo or SAP (second audio
program) broadcast, the icon STEREO or SAP appears
onscreen when Q is pressed.
To listen in stereo sound:
1 > Settings > SOUND > MTS.
2Press C or c to select Stereo. Press .
Note:
•You can typically leave the TV in Stereo mode because
it outputs the type of sound being broadcast (stereo or
monaural).
•If the sound is noisy, select Mono.
To listen to a second audio program on an analog
station (if available):
If provided by individual analog stations, you can listen
to a second audio program containing another
language, music, or other audio information.
For example, you will hear the other language instead
of the program’s normal audio.
1 > Settings > SOUND > MTS.
2Press C or c to select SAP. Press .
Note: If there is no sound in SAP mode, select Stereo.
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
Volume1/2 Mute Mute
VOL
53
Chapter 7: Picture and sound controls
Using the MTS button
If you press when an analog channel is tuned:
•The Analog Audio bar will appear and display Stereo,
SAP, Mono as the options.
If you press when a digital channel is tuned:
•The Digital Audio bar will appear and offer different
audio choices for the digital channel.
If you press when an external input is selected:
•No Audio bar is displayed.
Adjusting the audio balance
You can adjust the audio balance.
1 > Settings > SOUND > Balance.
2Press C or c to adjust. Press .
Adjusting the range
You can adjust bass and treble.
1 > Settings > SOUND > Bass or Treble.
2Press C or c to adjust. Press .
Selecting the optical audio output
format
You can select the optical audio output format when
you connect a Dolby Digital decoder or other digital
audio systems to the TV’s DIGITAL AUDIO OUT
terminal.
1Tune to a digital source on the ANT/CABLE input.
2 > Settings > PREFERENCES > AV
Connection > .
3Press B or b to select Digital Audio Output.
4Press C or c to select Auto or PCM. Press .
Using the Dolby® Digital Dynamic
Range Control feature
You can further compress Dolby Digital and Dolby
Digital Plus dynamic range so you can switch from
digital to analog broadcasts at the same dynamic range.
1 > Settings > SOUND > Dynamic Range
Control.
2Press C or c to select On.
Note:
•This feature is available when Dolby Digital or Dolby
Digital Plus is input to the TV in the following situations:
-When tuned to a digital RF channel.
-When an HDMI input is used.
-When DLNA Certified products or widgets are used.
•This feature is automatically set to Off when Dynamic
Volume (Audyssey Dynamic Volume®) is set to Low or
High.
•This feature will also affect Digital Audio Output when
the optical audio output format is set to PCM.
Using Audyssey Dynamic Volume®
This feature provides a consistent sound volume
between television programs, commercials, and
between the loud and soft passages of movies.
1 > Settings > SOUND > Dynamic Volume.
2Press C or c to select Low, High, or Off.
Note:
•If Dynamic Range Control is set to On, this feature is
automatically set to Off.
•This feature does not affect the audio signal output from
the DIGITAL AUDIO OUT terminal.
Option Description
Auto
Outputs Dolby Digital to the digital
audio output if it is being broadcast;
otherwise, it outputs PCM.
PCM Outputs PCM format to the digital audio
output socket.
OK
54
Chapter 7: Picture and sound controls
Using advanced sound features
Using surround sound
Voice Enhancement and Dynamic Bass Boost help to
create a thrilling surround sound experience with deep,
rich bass from stereo sound sources. Your TV’s audio
will sound fuller, richer, and wider.
Note: Surround features are only available for Stereo
mode (- “Selecting stereo/SAP broadcasts” on p. 52).
1 > Settings > SOUND > Advanced Sound
Settings > .
2Press b or B to highlight the feature to adjust. Press
C or c to adjust the item.
Mode Description
Voice
Enhancement
Turns the vocal emphasis effect On or
Off.
Dynamic Bass
Boost
Selects a bass expansion level (Off, Low,
or High).
OK
55
Chapter 8: Advanced features
Using your home network
•This TV is a DLNA CERTIFIED™ Player. It can play
digital content stored on a DLNA CERTIFIED™
product with server functions.
If you want to use this TV as a DLNA CERTIFIED™
Player, you will have to configure the network
settings on your TV (- p. 21).
•If you want to use your home network with an
Internet connection, you will have to configure the
network settings on your TV (- p. 21).
Change the network settings if necessary (- “Setting
up the Network” on p. 56).
If you use Internet services, see the following note
before use.
Third party Internet services are not provided by
Toshiba, may change or be discontinued at any time,
and may be subject to third party restrictions. Toshiba
makes no warranties, representations, or assurances
about the content, availability, or functionality of third
party content or services. Third party internet services
may require the creation of a separate account through
a computer with internet access, and payment of one-
time and/or recurring charges.
Certain features currently not available in Canada/
Mexico.
When using a Wireless network connection:
Wireless LAN and your Health:
Wireless LAN products, like other radio devices, emit radio
frequency electromagnetic energy. However, the level of
energy emitted by Wireless LAN devices is much less than
the electromagnetic energy emitted by wireless devices
like mobile phones.
Because Wireless LAN products operate within the
guidelines found in radio frequency safety standards and
recommendations, Toshiba believes Wireless LAN is safe
for use by consumers. These standards and
recommendations reflect the consensus of the scientific
community and result from deliberations of panels and
committees of scientists who continually review and
interpret the extensive research literature.
In some situations or environments, the use of Wireless
LAN may be restricted by the proprietor of the building or
responsible representatives of the organization. Such
restrictions may apply in environments where the risk of
interference to other devices or services is perceived or
identified as harmful.
If you are uncertain of the policy that applies to the use of
wireless devices in a specific organization or environment,
you are encouraged to ask for authorization to use the
Wireless LAN device prior to turning on the equipment.
Using in a wireless LAN environment:
•It is recommended to use IEEE 802.11a or IEEE
802.11n on 5 GHz for audio and SD video streaming.
•It is recommended to use IEEE 802.11n on 5 GHz for
HD video streaming.
•It is recommended that the encoding rate of video
content be 20 Mbps or less.
•It is not recommended to use 2.4 GHz for audio and
video streaming.
•Content playback may be interrupted by surrounding
interference.
56
Chapter 8: Advanced features
Setting up the Network
You can select the Network Type.
1 > Settings > PREFERENCES > Network
Setup > .
(Another: > Network > Network Setup > .)
2Press B or b to highlight Network Type.
3Press C or c to select Wired or Wireless.
4If you select Wired, see “Advanced Network Setup”
(- p. 58).
If you select Wireless, see the next section.
Wireless Setup
Note:
•Continued AP (Access Point) connection is not
guaranteed. Connection may be lost while watching TV.
There are 3 methods for wireless setup:
•Easy Setup (WPS)
If the AP supports WPS, this can be used.
– WPS is a standard designed to simplify the
connection of wireless LAN equipment and the setup
of network security features.
•Assisted Setup (setup using the AP's notification
information)
Network Name, Authentication, and Encryption are
decided based on information from the AP. You need
to manually set the Security Key.
•Manual Setup (to input all settings)
Easy Setup using PBC (Push Button Configuration)
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Wireless Setup. Press .
3Press B or b to select Easy Setup. Press .
4Press C or c to select PBC.
5Press b to select Start Scan. Press .
6Following the onscreen instructions, push the
appropriate button on your AP.
7When a screen reporting that the setup has
succeeded appears, press .
To cancel searching for the AP:
Press while searching for the AP. A message will
appear. Press C or c to select Yes. Press .
Easy Setup using a PIN (Personal Identification
Number)
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Wireless Setup. Press .
3Press B or b to select Easy Setup. Press .
4Press C or c to select PIN.
5Press b to select Start Scan. Press .
6Scan screen appears. Enter the PIN displayed on
this screen into your PC or AP.
7Press B or b to select the desired AP. Press .
Note: Check the MAC address on the label or in the
manual of the AP and select an AP.
8When a screen reporting that the setup has
succeeded appears, press .
To cancel searching for the AP:
Press while searching for the AP. A message will
appear. Press C or c to select Yes. Press .
Assisted Setup
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Wireless Setup. Press .
3Press B or b to select Assisted Setup. Press .
4Press B or b to select the desired AP. Press .
Note: Check the MAC address on the label or in the
manual of the AP and select an AP.
5Select Security Key. Press . The Software
Keyboard appears.
6Input the Security Key using the Software Keyboard
(- p. 59). To save your settings, press the BLUE
button.
Note: The Security Key must adhere to these
conditions:
-TKIP/AES: 8-63 ASCII or 64 Hex characters
-WEP: 5 or 13 ASCII or 10 or 26 Hex characters
7Select Done. Press .
Note: Settings are not saved if is pressed before
Done is selected.
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
57
Chapter 8: Advanced features
Manual Setup
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Wireless Setup. Press .
3Press B or b to select Manual Setup. Press .
4Press B or b to select Network Name. Press .
The Software Keyboard window appears.
5Input the Network Name using the Software
Keyboard (- p. 59). To save your settings, press
the BLUE button.
6Press B or b to highlight Authentication. Press C
or c to select Open/Shared, WPA-PSK, or WPA2-
PSK.
7Press B or b to highlight Encryption. Press C or c
to select None, WEP, TKIP, or AES.
Note:
•Certain encryption types are only compatible with
specific authentication types.
-When Authentication is Open/Shared, only WEP or
None are compatible.
-When Authentication is WPA-PSK or WPA2-PSK,
only TKIP or AES are compatible.
•When incompatible Authentication/Encryption
pairings are attempted, a warning message will be
displayed, and no connection attempt will be made
until the incompatibility is resolved.
8Press B or b to select Security Key. Press . The
Software Keyboard window appears.
9Input the Security Key using the Software
Keyboard (- p. 59). To save your settings, press
the BLUE button.
Note: This item is grayed out when Encryption is
None.
10 Select Done. Press .
Note: When Encryption is None, a message will
appear. Press C or c to select Yes. Press .
Note: Settings are not saved if is pressed before
Done is selected.
Wireless Information
The settings configured in Wireless Setup can be
confirmed.
1 > Network > Wireless Information > .
2A Wireless Information screen will appear.
Note: Press the RED button to check the availability of
surrounding APs.
Note: This feature is available from the Quick menu while
using Media Player or NET TV feature.
> Wireless Information > .
Note: Even if an AP for IEEE 802.11n is used when
Encryption is set to WEP or TKIP, the Speed value might
be low. We recommend that the Encryption setting be
changed to AES (Under manual setup).
OK
OK
OK
OK
OK
OK
OK
Item Description
Status
Connected is displayed when the TV is
connected to the AP.
Disconnected is displayed when the
TV is disconnected from the AP.
Signal Connection signal strength with the AP
(STRONG/MEDIUM/WEAK)
Speed The link speed with the AP
Mode Working mode (11a, 11b, 11g, 11n)
Channel The channel in use (1-165)
Network Name SSID set
Authentication Authentication set
Encryption Encryption set
Security Key Security Key set
AP MAC
Address
The AP's MAC address is displayed
when the TV is connected to the AP.
TV MAC
Address The TV’s MAC address
DHCP
Enabled is displayed when you use
DHCP.
Disabled is displayed when you do not
use DHCP.
IP Address The TV's IP address
Subnet Mask Value of the Subnet Mask
Default
Gateway Default GATEWAY’s address
DNS DNS’s address
OK
QUICK
OK
58
Chapter 8: Advanced features
Advanced Network Setup
Note:
•When the DHCP function of the router connected to this
TV is On, you can set Auto Setup to On or Off. (Usually
set it to On.)
•When the DHCP function of the router is Off, set Auto
Setup to Off, and manually set the IP Address or DNS
Address.
IP Address Setup
Note: The settings in Auto Setup are linked to those
selected in the DNS Setup menu. If Auto Setup is set to On,
then Auto Setup in the DNS menu will also be set to On.
Auto Setup:
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Advanced Network Setup.
Press .
3Press B or b to select IP Address Setup. Press .
4Select Auto Setup. Press C or c to select On.
Note: Other items will be grayed out when Auto Setup is
set to On.
Manual Setup:
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Advanced Network Setup.
Press .
3Press B or b to select IP Address Setup. Press .
4Select Auto Setup. Press C or c to select Off.
5Press B or b to highlight IP Address.
6Press C or c to highlight the field you want to
change and use the number buttons to input the IP
address. To save the setting, press .
Note:
•IP address field numbers must be between 0 and
255. If you input an incompatible number and press
, the field number will be reset to the previous
value.
7Press B or b to highlight Subnet Mask, and edit in
the same way as IP Address.
8Press B or b to highlight Default Gateway, and
edit in the same way as IP Address.
Note: If you manually set the IP address, you must not use
the same IP address for any other device. The IP address
you use should be a private address. If you do not know
the correct values to use, please contact your network
administrator or internet service provider.
DNS Setup
Note:
•When the DHCP function of the router connected to this
TV is Off, set Auto Setup to Off, and manually set the
DNS address(es). Your internet service provider should
have provided these to you.
•The settings in Auto Setup are linked to those selected in
the IP Address Setup menu. If Auto Setup is set to On,
then Auto Setup in the IP Address Setup menu will also
be set to On.
Auto setup:
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Advanced Network Setup.
Press .
3Press B or b to select DNS Setup. Press .
4Select Auto Setup. Press C or c to select On.
Note: Other items will be grayed out when Auto Setup is
set to On.
Manual setup:
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Advanced Network Setup.
Press .
3Press B or b to select DNS Setup. Press .
4Select Auto Setup. Press C or c to select Off.
5Press B or b to highlight Primary DNS Address.
6Press C or c to highlight the field you want to
change, and then use the number buttons to input
the Primary DNS Address. To save the setting,
press .
Note:
•DNS address field numbers must be between 0 and
255. If you input an incompatible number and press
, the field number will be reset to the previous
value.
7Press B or b to highlight Secondary DNS
Address, and edit in the same way as Primary DNS
Address.
MAC Address
You can view the fixed MAC address for the TV.
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Advanced Network Setup.
Press .
3Press B or b to select MAC Address. Press .
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
59
Chapter 8: Advanced features
Network Connection Test
This function checks Internet connectivity.
1 > Settings > PREFERENCES > Network
Setup > .
2Press B or b to select Network Connection Test.
Press .
Note: A message will appear to indicate whether the
connection was successful or not.
Note: Favorable Network Connection Test results do not
guarantee an Internet Connection. Depending on the
situation, some Internet features may not be available.
To cancel Network Connection Test:
Press while searching for the Internet connection.
Using the software keyboard
You can enter text using the Software Keyboard. The
Software Keyboard window will appear when you
press on a field that accepts character input.
Note: When using the NET TV feature, software keyboard
availability depends on the internet service being
accessed.
To enter text using the software keyboard:
1Highlight the desired character on the onscreen
software keyboard.
2Press .
3Repeat Steps 1 and 2 until you have entered all
desired text.
4Press the BLUE button to save your settings and
return to the previous screen.
Note: If is pressed, changes are not saved and
the software keyboard window is closed.
Input operation on the remote control:
OK
OK
Button Description
Inputs the selected character.
0–9 Inputs the number directly.
B b C c Moves the character highlight.
Moves the cursor.
Moves the cursor to the head of a
character string.
Moves the cursor to the end of a
character string.
RED Deletes 1 character to the left of the
cursor.
GREEN Cycles through upper case, lower case,
numbers, and symbols, if available.
YELLOW Chooses an accented version of the
current letter, if applicable.
BLUE Saves changes and closes the Software
Keyboard window.
Closes the Software Keyboard window
without saving changes.
OK
OK
AB
HIJKLM
UTSRQPO
VWX Y Z
N
CDEFG
Aa1
@
AAA|
OK
60
Chapter 8: Advanced features
Performing a Software Upgrade
TOSHIBA may offer upgrades for the TV's software in
the future. The TV's software is upgraded via Internet
connection.
Before downloading software:
Configure your TV to connect to the Internet.
Note:
•You will not be able to use the TV set while the upgrade
is being performed.
•Do not turn off the TV during the upgrade.
•By upgrading, the factory default values may be
changed.
1 > Settings > SETUP > Software Upgrade >
.
2Network Upgrade is displayed. Press .
Note: If the network is not available, a warning
message will appear.
3After a successful download, the TV software
upgrade will start automatically.
Viewing the Software Licenses
The Licenses for the software used in this TV are
available for viewing.
1 > Settings > SETUP > Software Licenses >
.
A screen will appear displaying all the licensing
information required for the television’s software.
Using the NET TV™ feature
Note:
•You need to connect to the Internet before using this
feature (- p. 21).
•Services may not be currently available in your area.
•User registration or login may be required to use some
services.
• is not available while using the NET TV feature.
NET TV menu
1Press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select an icon. Press .
Note:
•When you access the NET TV menu for the first time, a
welcome screen appears (- “Guided Setup” below).
After setup is complete, this feature is available.
•If the display of the date and time is wrong, turn off the
TV, and turn it on again.
•NET TV menu items may change in the upgrade
process.
Guided Setup
The first time you use Yahoo! TV Widgets this step-by-
step wizard begins with the Welcome Screen.
1Select Let's get started!
If you select Exit Setup now, this step will resume
the next time you press .
2Follow the onscreen instructions.
After completing the Guided Setup:
•When you press or select NET TV from the Menu,
the NET TV menu is displayed.
•When you press or select Widgets from the
Menu, the TV Widgets user interface is displayed.
OK
OK
OK
OK
OK
61
Chapter 8: Advanced features
Netflix
Watching movies with Netflix
1Press (S Step 3) or press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select Netflix icon. Press .
3Follow the onscreen instructions.
After having activated Netflix player and prepared
Instant Queue, movies and TV episodes in your Instant
Queue will appear on the TV screen. Select the desired
content using the remote control.
Note:
•The resolution of video content streamed from Netflix
varies depending on the communication speed and bit-
rate.
•Future upgrades can change the screens and messages
displayed in the Netflix feature.
To close Netflix:
Press .
To confirm the Netflix ESN (Electronic Serial Number):
1 > Settings > PREFERENCES > Netflix Setup
> .
2Press B or b to select ESN. Press .
Netflix ESN is displayed.
To deactivate your device:
1Y > PREFERENCES > Netflix Setup > .
2Press B or b to select Deactivation. Press .
3Press C or c to select Yes. Press .
VUDU™
VUDU™ is an on-demand service that offers high-
definition movies on the Web.
1Press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select VUDU. Press .
Note: Use of VUDU requires a working broadband internet
connection (1 to 2 Mbps for SD video, 2.25 to 4.5 Mbps for
HD video, and 4.5 to 9 Mbps for HDX video).
To close VUDU:
Press .
To deactivate your device:
1 > PREFERENCES > VUDU Deactivation >
.
2Press C or c to select Yes. Press .
YouTube™
YouTube is a video-sharing service managed by
YouTube, LLC.
This TV allows you to view YouTube video content.
1Press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select YouTube. Press .
3Press B, b, C or c to select the file you want to view.
Press .
To close YouTube:
Press .
Note:
•YouTube contents have been independently managed
by YouTube, LLC.
•Not all YouTube contents that can be accessed by
computer may be viewed with this TV.
•This TV may not be able to do some operations that
computer can do.
•Depending on network environment and the use
situation, content may be difficult to view.
•Though the same volume value, an actual volume might
be greatly different depending on contents.
•This TV might take time during start-up and the playback
of contents.
•Content that the user may feel is improper or offensive
may be included in the contents of YouTube.
•We do not assume any responsibility for contents that
YouTube offers.
•If you have any questions about YouTube contents,
please contact YouTube, LLC.
•The content of service and the screen that can be used
may be changed without notice.
•You cannot post videos to YouTube from this TV. Please
use a PC to post videos.
•Not all contents can be viewed normally when you
access websites other than YouTube Leanback through
this TV.
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
62
Chapter 8: Advanced features
CinemaNow
CinemaNow is an on-demand service that offers high
definition movies on the Web.
1Press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select CinemaNow. Press .
To close CinemaNow:
Press .
Blockbuster
Blockbuster is an on-demand service that offers high
definition movies on the Web.
1Press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select Blockbuster. Press .
To close Blockbuster:
Press .
Pandora
Pandora is an on-demand service that offers music on
the Web.
1Press .
(From the Menu: > Network > NET TV > .)
2Press C or c to select Pandora. Press .
To close Pandora:
Press .
Yahoo!® TV Widgets
Yahoo!® TV Widgets provide an integrated Internet and
TV experience powered by the Yahoo! Connected TV
platform. Yahoo!® TV Widgets allow you to:
•Track your stocks and stay current with financial
news.
•Share photos with friends and family.
•Watch your favorite web videos.
1Press .
(From the Menu: > Settings >
APPLICATIONS > Widgets > .)
2Focus is located in the leftmost region (the
highlighted snippet). The dock scrolls snippets
under this focal point. Press C or c to focus on a
snippet. Press to select a snippet.
3The TV Widget sidebar appears. Press B or b to
select a menu item. Press .
OK
OK
OK
OK
OK
OK
OK
The Dock is the horizontal list of snippets
appearing at the bottom of your TV screen.
A snippet is a shortcut which launches
a TV Widget.
OK
OK
The TV Widget logo and
Home button
The currently focused
button is highlighted.
The sidebar's bottom
toolbar includes four
color-coded buttons
that map to the colored
keys on the remote
control.
63
Chapter 8: Advanced features
To close Yahoo!® TV Widgets:
Press .
Note: To use Yahoo!® TV Widgets you must first complete
the “Guided Setup” (- p. 60).
Using the Profile Widget
•The Profile Widget
configures your user
profile.
•You can set up multiple
profiles for multiple users.
•Each profile maintains its
own list of TV Widgets.
•The Switch Profile menu
allows you to switch to a
different user profile.
•The Profile Settings menu
allows you to customize
and protect your profile.
•The System Settings
menu allows you to change
your Location, Repeat
the Tutorial, and Restore Factory Settings, which
deletes all profiles and TV Widget settings (not TV
settings).
•The Administrative Controls menu allows you to set
the Screen Saver timeout, create the Owner PIN, and
to Create a Profile.
•The Sign in to Yahoo! menu allows you to
personalize your experience using your Yahoo! ID.
•Visit http://www.yahoo.com to create a Yahoo! ID.
Using the Widget Gallery
•The Widget Gallery allows you to browse and
discover new TV Widgets.
•The featured TV Widgets are highlighted in the
display case at the top of the sidebar.
•You can also browse available TV Widgets by
category.
•To install a widget, select Add Widget to My Profile
and press .
•The Owner PIN is needed to install widgets for
profiles that have been protected through the Limit
Profile indicator under the Profile Widget S Profile
Settings menu.
•Refer to the Profile Widget S Administrative
Controls menu to set the Owner PIN.
Using other Yahoo! Widgets
•The Yahoo! News Widget provides the latest headline
news for business, entertainment, politics, sports, top
stories, and many other categories.
•The Yahoo! Weather Widget provides updates on
your local and favorite weather locations.
•View the latest stock news with the Yahoo! Finance
Widget.
•The flickr Widget enables slideshows of family and
friends’ photos on your TV.
Resetting Yahoo! TV Widgets
If a message window appears or you can not access
Yahoo! TV Widgets when or is pressed, do
the following:
1 > Settings > PREFERENCES > Reset Yahoo!
TV Widgets.
2Select Yes.
If the message window is displayed or you cannot
access Yahoo! TV Widgets after several attempts, see
p. 72, in the troubleshooting section.
Note:
•Reset Yahoo! TV Widgets deletes all profiles and TV
Widget settings (not TV settings). The settings of Yahoo!
TV Widgets are reset to factory default.
•When Reset Yahoo! TV Widgets is selected, all TV
operations are disabled until the operation is complete.
•After Reset Yahoo! TV Widgets, you must complete the
“Guided Setup” before you can use Yahoo! TV Widgets
again.
•After Yahoo! TV Widgets are reset, all of the widgets
previously downloaded from the Widget Gallery will have
to be downloaded again before they can be used.
Button Description
RED Closes the widget.
GREEN Changes the widget’s settings.
YELLOW Adds or deletes a snippet.
BLUE Resizes the video to fit onscreen, or to
make it fullscreen.
OK
64
Chapter 8: Advanced features
Using the Media Player
This TV allows you to access photos, movies, and music
files stored on a USB device.
Moreover, you can also access photos, movies, and
music files from your TV or PC by connecting the TV to
your home network.
Term meaning:
DMP: DLNA CERTIFIED™ Player
DMS: DLNA CERTIFIED™ Server
•DMP: The TV can control and play content on a DMS.
– DMS is a device with server functions that stores
media content for playback on a DMP.
Note:
•Do not insert/remove USB device while in use.
• is not available while using the Media Player
feature.
Media Player Specifications
Device
USB device:
USB Mass Storage Class devices (MSC)
Note:
•Connectivity is not guaranteed for all devices.
•Incorrect behavior may occur with a USB HUB
connection.
DLNA CERTIFIED™ Server:
NAS, your PC (for example)
Supported file system
FAT12, FAT16 and FAT32
Basic operation
Using Media Player with USB
When Auto Start is enabled, you will be asked if you
want to start the Media Player when a USB device is
inserted. If Auto Start is disabled (or if you want to
connect to a DMS on the network), you must manually
start the Media Player from the menu.
To change the Auto Start setting:
1 > Settings > APPLICATIONS > Media Player
> .
2Press B or b to select Setup. Press .
3Press B or b to highlight USB Auto Start. Press C
or c to select On or Off.
Auto Start:
1Insert a USB device into the USB terminal.
A prompt appears.
2Press C or c to select Yes. Press .
3Press B or b to select Photo, Movie, or Music. Press
. The thumbnail (for Photo) or list of files (for
Movie and Music) appears.
4Press B or b to select the USB device if the selection
screen appears.
Note: If Auto Start is set to Off, you can start the Media
Player manually.
Manual Start:
1Insert a USB device into the USB terminal.
2 > Settings > APPLICATIONS > Media Player
> .
(Another: > Media Player > .)
3Press B or b to select Photo, Movie, or Music.
(When Another in Step 2, press C or c to select
Photo, Movie, or Music.)
Press . The thumbnail (for Photo) or list of files
(for Movie and Music) appears.
4Press B or b to select the USB device if the selection
screen appears.
To select a file in the list of contents:
1Press B, b, C, or c to select a file or folder.
2Press to move to the next layer, or press to
return to the previous layer.
To close the Media Player:
Press . The TV will return to the last-viewed
channel or video input.
You must obtain any required permission from copyright
owners to download or use copyrighted content.
Toshiba cannot and does not grant such permission.
OK
OK
OK
OK
OK
OK
OK
OK
65
Chapter 8: Advanced features
Using Media Player with DLNA CERTIFIED™ Server
You need to configure a home network before using this
feature (- p. 21).
1 > Settings > APPLICATIONS > Media Player
> .
(Another: > Media Player > .)
2Press B or b to select Photo, Movie, or Music.
(When Another in Step 1, press C or c to select
Photo, Movie, or Music.)
Press . The thumbnail (for Photo) or list of files
(for Movie and Music) appears.
3Press B or b to select the server you want to use if
a server list is displayed, and press .
To select a file in the list of contents:
1Press B, b, C, or c to select a file or folder.
2Press to move to the next layer, or press to
return to the previous layer.
To close the Media Player:
Press . The TV will return to the last-viewed
channel or video input.
To display the device information:
1Press to open the Quick menu in list mode or
Multi View mode.
2Press B or b to select Device Information.
Viewing Movie files
Basic Playback:
1Select a file (- “To select a file in the list of
contents” on p. 64). Press or to begin
playback.
Note: Depending on the file size, it may take some
time to start playback.
2Press to stop playback.
3If playback finishes before is pressed, the
screen returns to the list.
Note: When the repeat mode is set to All, the next file
will start playing automatically.
To pause playback:
Press during playback.
To resume normal playback, press .
Note: PAUSE or operations during PAUSE may not be
operable depending on the content or DMS.
To play in fast reverse or fast forward:
Press or during playback. Each time you press
or , the playback speed changes.
• : Fast reverse playback
• : Fast forward playback
To locate a specific file:
Press or repeatedly to access the desired file.
• : Playback starts from the beginning of the current
file or previous file.
• : To locate subsequent files.
Note:
•If the previous or next file is not compatible, it is skipped
automatically.
•These features may not be operable depending on the
content or DMS.
OK
OK
OK
OK
OK
QUICK
OK
66
Chapter 8: Advanced features
To set the repeat mode:
1Press . The current repeat setting appears.
2Press C or c to select Off, All, or 1.
3Press . The setting is effective until the TV is
turned off.
To display the file status information:
1Press Q during playback. The information will be
displayed at the bottom of the screen.
2Press Q again to hide the information.
Note: The information may not be correctly displayed
depending on the content or DMS.
File specifications:
USB use
File format: MPEG2 PS, MPEG2 TS, MP4
Video: MPEG2, MPEG4, H.264
Audio: MPEG1-Layer2 / MPEG1-Layer3 / AC3 /
LPCM
Maximum number of files: 1000 per folder
Content on DLNA CERTIFIED™ Server
File format: MPEG2 PS, MPEG2 TS, MP4, WMV
Video: MPEG2(PS) PAL, MPEG2(TS) PAL,
MPEG2(PS) NTSC, MPEG2(TS) NTSC,
H.264
Audio: LPCM / MPEG1-Layer1 / MPEG1-Layer2 /
MPEG2-Layer2 / AC3 / AAC
Maximum number of files: 1000 per folder
Note: Some files may not be played.
Playing Music files
Basic Playback:
1Select a file (- p. 64). Press or to begin
playback.
Note: Depending on the file size, it may take some
time to start playback.
2Press to stop playback.
If playback finishes before is pressed, the next
file will start playing automatically.
To pause playback:
Press during playback.
To resume normal playback, press .
Note: PAUSE or operations during PAUSE may not be
operable depending on the content or DMS.
To play in fast reverse or fast forward:
Press or during playback. Each time you press
or , the playback speed changes.
• : Fast reverse playback
• : Fast forward playback
Note: These features may not be operable depending on
the content or DMS.
To locate a specific file:
Press or repeatedly to access the desired file.
• : Playback starts from the beginning of the current
file or previous file.
• : To locate subsequent files.
Note: If the previous or next file is not compatible, it is
skipped automatically.
Mode Description
Off The content is played back only once.
All Contents in the same folder are repeatedly
played back.
1 The same content is repeatedly played back.
QUICK
OK
67
Chapter 8: Advanced features
To set the repeat mode:
1Press . The current repeat setting appears.
2Press C or c to select Off, All, or 1.
3Press . The setting is effective until the TV is
turned off.
To display the file status information:
1Press Q during playback. The information will be
displayed at the bottom of the screen.
2Press Q again to hide the information.
Note: The information may not be correctly displayed
depending on the content or DMS.
File specifications:
USB use
File format: MP3, MP4 (AAC), LPCM
Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz
Bit rate: from 32 to 320 kbps
Maximum number of files: 1000 per folder
Content on DLNA CERTIFIED™ Server
File format: MP3, LPCM, WMA
Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz
Bit rate: from 32 to 320 kbps
Maximum number of files: 1000 per folder
Note: Some files may not be played.
Viewing Photo files
Multi View mode:
This view mode allows you to search for photos in a
grid format.
These pictures are displayed using thumbnail data in
each image file.
1Press B, b, C, or c to move the highlight by one
window.
•If all of the photos will not fit in one screen, when
pressing C at the top left thumbnail, the screen will
move to the previous page. Similarly, when pressing
c at the bottom right thumbnail, the screen will move
to the next page.
2When you select a folder, press to move to the
next layer. Press to move back to the previous
layer.
3Press to view the selected photo in Single View
mode.
Note: Displaying thumbnail data may take time.
Single View mode:
In this view mode, only files located in the selected
directory are displayed. When moving from Multi
View mode to Single View mode, the currently selected
photo is displayed.
1On Multi view mode, press B, b, C, or c to select a
file. Press .
2Press C or c to view the next or previous file.
Note:
•If the previous or next file is not compatible, it will be
skipped automatically.
•Single view mode is changed to Multi View mode when
is pressed.
Slideshow mode:
This view allows you to watch a slideshow of the
photos. In this mode, only files located in the selected
directory will be displayed.
1To switch to Slideshow mode, press while in
Single View mode.
To return to Single View mode, press again.
2Press C or c to view the next or previous file.
Note: If the previous or next file is not compatible, it is
skipped automatically.
Mode Description
Off Contents in the same folder are played back
once.
All Contents in the same folder are repeatedly
played back.
1 The same content is repeatedly played back.
QUICK
OK
OK
OK
OK
OK
68
Chapter 8: Advanced features
To set the mode settings:
1Press to open the Quick menu while in Single
View mode or Slideshow mode.
2Press B or b to select the item (SOUND, Interval
Time, Repeat, Background Music, or Speakers).
3Press C or c to adjust the setting.
4Press to return to Single View mode or
Slideshow mode.
To set the background Music:
1Press to open the Quick menu while in
Slideshow mode.
2Press B or b to select Background Music. Press .
3Highlight Background Music. Press C or c to
select On.
4Press b to select Select Music. Press .
5Select a music file.
Note:
•The music must be selected from the USB or DMS from
which the picture files will be played.
•This feature is not available when there is no music that
can be selected.
To rotate the image:
While viewing the image in Single View mode or
Slideshow mode, press B or b to rotate the image 90
degrees.
To return to the thumbnail:
Press while in Single View mode or Slide Show
mode.
To display file status information:
1Press Q. The information will be displayed at the
bottom of the screen.
2Press Q again to hide the information.
Note: The information may not be correctly displayed
depending on the content or DMS.
File specifications:
USB use
Data compatibility: JPEG Exif ver 2.2
File format: JPEG
Maximum viewable resolution:
4096 × 4096 (HW decode)
16384 × 16384 (SW decode)
Maximum photo size: 9 MB
Maximum number of files: 2000 per folder
Content on DLNA CERTIFIED™ Server
Data compatibility: JPEG EXIF Ver.1.x or later,
JFIF 1.02a
File format: JPEG
Maximum photo resolution: 4096 x 4096
Maximum photo size: 6 MB
Maximum number of files: 2000 per folder
Note: Some files may not be played.
Item Description
Interval Time
Sets a time interval to view photos at
(3sec, 5sec, 10sec, 15sec, 30sec, 60sec, or
90sec).
Repeat Displays photos in the same directory
repeatedly. On/Off
QUICK
QUICK
OK
OK
69
Chapter 8: Advanced features
Using the Wallpaper feature
This feature allows you to display a photo file stored on
the TV.
•Only one photo file can be stored on the TV.
•The photo file can be overwritten with a file from an
external device (USB, DMS).
1 > Settings > PREFERENCES > Wallpaper
Setup > .
(Another: > Wallpaper > .)
The preview screen will appear.
2Press c to select Start. Press .
To close the Wallpaper:
Press .
Photo Select
1 > Settings > PREFERENCES > Wallpaper
Setup > . The preview screen will appear.
2Press B or b to select Photo Select. Press . The
device selection screen appears.
Note: This screen will not appear when there is only
one device connected.
3Press B or b to select the appropriate device. Press
.
4Press B, b, C, or c to select the photo you want to
copy from the USB or DMS to the TV. Press .
Photo Edit
1 > Settings > PREFERENCES > Wallpaper
Setup > . The preview screen appears.
2Press B or b to select Photo Edit. Press .
3Press B or b to select Rotate or Delete.
4Set the following items as required.
•Rotate - Press to rotate the image 90°clockwise.
•Delete - Press . A confirmation screen appears.
Select YES. Press .
Note: The Factory default image cannot be deleted.
5Press .
Auto Power Off
1 > Settings > PREFERENCES > Wallpaper
Setup > . The preview screen appears.
2Press B or b to highlight Auto Power Off.
3Press C or c to select Off, 00:30, 01:00, 02:00, 04:00,
06:00, or 12:00.
•If the Wallpaper window is left open, the TV will
automatically turn off after the set length of time
(maximum 12 hours).
4Press .
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
OK
70
Chapter 9: Troubleshooting
General troubleshooting
Before calling a service technician, please check this
chapter for a possible cause of the problem and some
solutions you can try.
Black box onscreen
•The closed caption feature is set to one of the Text modes
(T1, T2, T3, or T4). Set the closed caption feature to Off
(-p. 35).
TV stops responding to controls
•If the TV stops responding to the remote control or TV control
panel and you cannot turn off the TV, unplug the power cord
to reset the TV. After 1 minute, plug it in and turn the TV on.
Other problems
•If your TV’s problem is not addressed in this Troubleshooting
section or the recommended solution has not worked, do one
of the following:
1) Turn off your TV. After 30 seconds, turn it on.
2) Turn off the TV and unplug the power cord. After 1 minute,
plug the power cord in and turn on the TV.
3) Perform the Reset Factory Defaults procedure (-p. 44).
TV will not turn on
•Ensure the power cord is plugged in. Press p.
•Replace the remote control’s batteries.
•Try the control panel buttons.
Picture problems
General picture problems
•Check the antenna/cable connections (-p. 15).
•Press on the remote control or on the TV and select a
valid video input source (-p. 34). If no device is connected
to an input on the TV, nopicture appears when you select that
particular input source. Check device connections (- p. 16–
21).
•Antenna reception may be poor. Use a highly directional
outdoor antenna (if applicable).
•The station may be having broadcast difficulties. Try another
channel.
•Adjust the picture quality (-p. 48).
•If the Edge Booster does not achieve a sharper picture,
change the Sharpness value to increase the sharpness level
(- p. 48).
Video Input Selection problems
•If the Input Selection window does not appear when you
press on the remote control or the TV control panel,
press a second time. The TV displays the next video
input source and the Input Selection screen.
Cannot view external signals or channel 3 or 4
•If you cannot view signals from external devices connected to
VIDEO 1, VIDEO 2, ColorStream HD1, ColorStream HD2,
HDMI 1, HDMI 2, HDMI 3, HDMI 4, PC, or from channel 3 or
4, ensure the Input Lock is set to Off (-p. 38).
Poor color or no color
•The station may be having broadcast difficulties. Try another
channel.
•Check the Input mode when you use Shared Inputs
(-p. 30).
•Adjust the Tint and/or Color (-p. 48).
Poor composite picture
•If the TV is connected to an external A/V device (e.g. DVD
player, video game system, set-top box, etc.) try using a
ColorStream or HDMI video connection instead.
Picture and sound are out of sync
•As with all products that contain a digital display, this may
occur in rare instances when viewing certain content (e.g.
television broadcasts, video games, DVDs). Possible causes
may include, without limitation, video processing within the
TV, video processing in an attached gaming system, and
video processing or different compression rates used by
broadcasters in their programming. Try the following
procedures:
– If the TV is connected to an A/V receiver that has a
programmable audio delay feature, use this feature to
help synchronize the sound to the picture.
– If the problem occurs only on certain TV channels, inform
your local broadcast, cable, or satellite provider.
•The settings of Side Shared Audio and Rear Shared Audio
may be not correct. Ensure the settings (- p. 30).
Sound problems
•Check the antenna/cable connections (- p. 15–20).
•The station may be having broadcast difficulties. Try another
channel.
•The sound may be muted. Press VOLUME.
•If you hear no sound, try setting the MTS feature to
Stereo mode (-p. 52).
•If you are not receiving a second audio program from a
known SAP source, make sure the MTS feature is set to SAP
mode (-p. 52).
•If you hear audio that seems incorrect for the program you
are watching (such as music or a foreign language), the SAP
mode may be on. Set the MTS feature to Stereo mode
(-p. 52).
•If you connect a PC using either the PC IN terminal or an
HDMI terminal, ensure that the Rear Shared Audio setting is
properly set (- p. 42).
Remote control problems
•Ensure the remote control is set to the correct device mode
(-p. 79).
•Remove all obstructions between the remote control and the
TV.
•Replace the remote control’s batteries (-p. 22).
•Your TV’s remote control may not operate certain features on
your external device. Refer to the owner’s manual for your
other device to determine its available features. If your TV
remote control does not operate a specific feature on another
device, use the remote control that came with the device
(-p. 82–87).
•If the TV still does not act as expected, perform the Reset
Factory Defaults procedure (-p. 44).
Channel tuning problems
•Ensure the remote control is set to the correct device mode
(-p. 79).
INPUT
INPUT
INPUT
71
Chapter 9: Troubleshooting
•The Auto Tuning feature may have erased the channel from
memory. Add the channel to the channel memory (-p. 28).
•The Lock feature may have blocked the channel. Unblock the
channel (-p. 38).
•If you cannot tune digital channels, check the antenna
configuration (-p. 28). If the problem persists, clear all
channels from the channel list and reprogram channels into
memory (-p. 28). If the problem persists, use the Reset
Factory Defaults procedure (-p. 44). See “TV stops
responding to controls” and “Other problems” (-p. 70).
Closed caption problems
•If the program or video you have selected is not closed-
captioned, no captions appear.
•If text is not available, a black rectangle may appear. If this
happens, turn off the closed-caption feature (-p. 35).
•A closed-caption signal may not display correctly under the
following circumstances: a) the videotape is dubbed; b) the
signal reception is weak; or c) the signal reception is
nonstandard (-p. 35).
Rating blocking (V-Chip) problems
•If you forget your PIN code: While the PIN code entering
screen is displayed, press Q 4 times within 5 seconds. The
old PIN code is cleared (-p. 36).
•The V-Chip feature is available for U.S. V-Chip systems only
(-p. 36).
No HDMI® CEC Control operation
•HDMI® CEC Control feature is available for Toshiba HDMI®
CEC compatible devices.
•Ensure HDMI cables with the HDMI Logo ( ) are
used.
•When the connected HDMI® CEC device does not work
correctly after you have changed the device’s settings, turn
off your TV and unplug the power cord. After 1 minute, plug
it in and turn it on again.
•If several devices are connected, HDMI® CEC Control feature
may not operate properly.
•Read the instruction manual of the connected HDMI® CEC
device.
HDMI problems
For HDMI cables
•Ensure HDMI cables with the HDMI Logo ( ) are
used (- p. 14).
For Legacy HDMI sources
•Some legacy HDMI sources may not work properly with the
latest HDMI TV products due to new standards. Turn off
INSTAPORT™ (- p. 41).
Network problems
Cannot connect to the Internet
•Check the modem and its incoming cable/telephone
connections (- p. 21).
•Confirm your modem’s operation.
•Ensure your IP address is set up correctly.
No network connection
•If using a wired network connection, check to ensure the LAN
cables are connected properly (- p. 21).
•Ensure the modem and router power cords are plugged in
and the devices are operating properly.
•Ensure your IP address is set up correctly. See Section
(- “Setting up the Network”).
•Check to ensure proper operation of other network connected
devices.
Network Setup fails (Auto)
•Check to ensure the LAN cables are connected properly
(- p. 21).
•DHCP is not enabled on the router, or no router is present.
Refer to your router’s documentation for instructions on
enabling DHCP. If your router does not support DHCP, you
must manually set up the IP address.
•Internet service is not available. Check your cable/DSL
modem or contact your ISP for Internet service issues.
Network Setup fails (Manual)
•Ensure the TV IP address is not the same as any other device
on the network.
Example: IP address 192.168.0.100 and IP address
192.168.0.101 are different addresses on the same network.
•Make sure the TV IP address is on the same subnet as the
networked PC.
Example of proper setup: The PC has the IP address
192.168.0.100 with the Subnet mask 255.255.255.0, the TV
has the IP address 192.168.0.101 with the Subnet mask
255.255.255.0; both are on the same subnet.
Example of improper setup: The PC has the IP address
192.168.1.100 with the Subnet mask 255.255.255.0, the TV
has the IP address 192.168.0.101 with the Subnet mask
255.255.253.0; they are on different sub-nets.
Unstable network connection
•When using a wired home-network connection, unplug the
LAN cables, and then reconnect them.
•When using a wireless home-network connection:
– Remove AC power from the router and the television for
1 minute.
•Reconnect AC power to the router.
•Reconnect AC power to the television and turn it
ON. After 2 minutes, check connection stability.
–Connect with LAN cables, if possible, and check
connection stability.
– Repeat the wireless network setup procedure and check
connection stability.
The DMS name is not displayed
•The LAN cables, if used, are not connected properly
(- p. 21).
•The WLAN, if used, is not configured properly.
•The network setup on the Server is incorrect. Make sure both
the DMS and TV are using the same network type (DHCP/
manual) and have compatible network settings.
•Too many DMSs are connected. You cannot connect more
than 32 sharing devices at one time.
•The DMS is not turned ON.
•The “server” is not a DMS device.
•Check the firewall and streaming settings on the DMS.
(continued)
72
Chapter 9: Troubleshooting
Wireless network problems
•Check that the router/AP (Access point) power is ON.
•After starting wireless network setup, confirm that the
network is configured properly by performing the network
connection test (- p. 59).
•Check the router/AP’s connection status (- p. 57).
•If the router/AP does not support PBC or WPS, Easy Setup
(PBC) will not work even if the push-button is pressed.
•If the available router/AP list is not displayed in Easy Setup
(PBC) or Assisted Setup, the power of the router/AP may be
OFF. Check that it is ON, and then try re-starting the scan for
available routers/APs.
•Refer to the router/AP’s instruction manual.
NET TV or Widget problems
•If the date and time display on the NET TV menu is wrong,
turn off the TV, and turn it on again.
•NET TV or Widgets may not be immediately available after
turning the TV on while the system is booting.
•When NET TV or Widgets doesn't operate properly (a
message window is displayed when or is
pressed), do one of the following:
1) Turn off your TV. After 30 seconds, turn it on.
2) Turn off the TV and unplug the power cord. After 1 minute,
plug the power cord in and turn on the TV.
3) Perform the Reset Yahoo! TV Widgets procedure
(-p. 63)
4) Perform the Reset Factory Defaults procedure (-p. 44).
•Content delivered by NET TV or Widgets are the responsibility
of the Content Service Provider. Contact the Service Provider
to discuss any content issues.
Media Player problems
•Ensure that the devices (Display and Server) are connected
correctly.
•Incorrect behavior may occur when using a USB HUB
connection.
•Photo files that were processed and edited using the PC’s
application software may not be viewable.
•When viewing content that supports two or more formats the
display may select one format automatically.
•Copyright protected content stored on the DMS may not be
playable on the display.
•Content playback stability may be affected by heavy network
traffic.
•Content originally recorded on a PC may not play correctly.
•Set the media sharing of the DMS correctly, according to the
DMS instruction manual.
•Confirm that the contents of either the DMS or the USB
storage device are in formats that are supported by this TV
(- p. 66, 67, or 68).
•Depending on the DMS, access may be limited by the MAC
address. Set the server according to the DMS’s instruction
manual. This TV’s MAC Address can be confirmed in the
Network Setup portion of the User Menu (- p. 58).
For DLNA CERTIFIED™ Player
•Depending on the DMS, it may take time to display the list.
LED indications
The POWER and service LED lights on the front of the
TV indicate the TV’s status, as described below.
POWER On/Standby LED
•Green
The TV is operating properly.
• No light
The power is off or standby.
• Green blinks
System booting. After a while, the screen appears.
• Red blinks
Power-On Failure. Turn off the TV and unplug the
power cord. After 1 minute, plug the power cord in
again and turn on the TV.
Service LED
•Green blinks (if applicable)
Abnormal operation of BUS line. Turn off the TV and
unplug the power cord. After 1 minute, plug the
power cord in again and turn on the TV.
If the problem persists after trying the solutions:
•In the U.S., visit TAIS Consumer Solutions on the web
at www.support.toshiba.com or call 1-800-631-3811.
•In Canada, locate the nearest Toshiba authorized
service depot by directing your web browser to
www.toshiba.ca; click “Support,” and then click
“Home Entertainment.”
Power LED Service LED
TV front
73
Chapter 10: Appendix
Specifications
Note:
•This model complies with the specifications listed
below.
•Designs and specifications are subject to change
without notice.
•This model may not be compatible with features and/
or specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear,
unencrypted)
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source
120 V AC, 60 Hz
Power Consumption
42SL417U: 1.1 A (rms) (maximum current)
0.4 W in standby mode
46SL417U: 1.2 A (rms) (maximum current)
0.4 W in standby mode
55SL417U: 1.4 A (rms) (maximum current)
0.4 W in standby mode
Audio Power
Main: 10 W + 10 W
Speaker Type
Main: Four 13/16 × 2-9/16 inches (20 × 65 mm)
Video/Audio Terminals
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 200 mV(rms) (-20dBFS)
ColorStream® (component video) HD INPUT:
VIDEO: Y: 1V(p-p), 75 ohm
PR: 0.7 V(p-p), 75 ohm
PB: 0.7 V(p-p), 75 ohm
Suggested formats: 1080p, 1080i, 720p,
480p, 480i
AUDIO: 200 mV(rms), 22 k ohm or greater
HDMI® INPUT:
HDMI compliant
HDCP compliant
Suggested formats: See table on p. 76.
HDMI Audio: 2-channel Linear-PCM/AC-3; 32/
44.1/48 kHz sampling frequency;
16/20/24 bits per sample
DIGITAL AUDIO OUTPUT:
Optical type
PC INPUT:
15-Pin D-sub Analog RGB
Wireless connection
• Standard: IEEE 802.11a/b/g/n
• Host Interface: USB 2.0 compatible
• Frequency Range: 5.15–5.35 GHz, 5.47–5.725 GHz,
5.725–5.850 GHz, 2.412–2.462 GHz
• Security: WEP64/128, TKIP, AES, WPA/WPA2-
PSK, WPS, None
Ethernet
• IEEE 802.3.
USB
• Universal Serial Bus Specification, Revison 1.1.
• Universal Serial Bus Specification, Revison 2.0.
Dimensions (include foot stand)
42SL417U: Width: 38-15/16 inches (989 mm)
Height: 26-19/32 inches (675 mm)
Depth: 11-5/16 inches (287 mm)
46SL417U: Width: 42-15/32 inches (1,078 mm)
Height: 28-19/32 inches (726 mm)
Depth: 11-5/16 inches (287 mm)
55SL417U: Width: 49-13/16 inches (1,265 mm)
Height: 33-3/32 inches (840 mm)
Depth: 14-7/32 inches (361 mm)
Mass (weight)
42SL417U: 45.2 lbs (20.5 kg)
46SL417U: 49.7 lbs (22.5 kg)
55SL417U: 67.3 lbs (30.5 kg)
Operating conditions
Temperature: 32ºF - 95ºF (0ºC - 35ºC)
Humidity: 20 - 80% (no moisture condensation)
74
Chapter 10: Appendix
Supplied Accessories
• Easy Setup Guide
• Pedestal assembly installation manual
• Stop/Quick set up guide
• Remote control with two “AA” size batteries
•Mounting screw
Use this screw to secure the TV. See item 26 on p. 4.
• Securement Clip
Use this clip to attach the TV to a wall stud, pillar, or
other immovable structure. See item 26 on p. 4 and
instructions on p. 5.
•Tool set
•Four spacers
Use these to attach a wall bracket. See p. 5 and 6.
• Two Cable clamps
• Two AV adapter cables
• Component adapter cable
75
Chapter 10: Appendix
Acceptable signal formats for PC IN and HDMI terminals
PC IN signal formats
Note:
•The PC IN on this TV only accepts signal formats which are compliant with VESA-DMT as in the table below. Since some
PC input signals are different from the resolution and frequency described in the table below, the following problems
may occur: incorrect display, false format detection, picture position failure, blur, or judder. In these cases, set the
monitor output format on your PC to conform to any of the signals in the table below.
•The signals whose vertical frequency is 56 Hz,70 Hz, 72 Hz, or 75 Hz are converted to a 60 Hz signal.
•When you connect a PC to this TV, it is recommended to set the refresh rate of your PC to 60 Hz.
•The PC IN on this TV does not accept the Sync on Green, Composite Sync, and Interlace signals.
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard (DMT)
VGA 640 × 480 59.940/60 Hz 31.469/31.500 kHz 25.175/25.200 MHz
72.809 Hz 37.861 kHz 31.500 MHz
75.000 Hz 37.500 kHz 31.500 MHz
SVGA 800 × 600 56.250 Hz 35.156 kHz 36.000 MHz
60.317 Hz 37.879 kHz 40.000 MHz
72.188 Hz 48.077 kHz 50.000 MHz
75.000 Hz 46.875 kHz 49.500 MHz
XGA 1024 × 768 60.004 Hz 48.363 kHz 65.000 MHz
70.069 Hz 56.476 kHz 75.000 MHz
75.029 Hz 60.023 kHz 78.750 MHz
WXGA 1280 × 768 59.995 Hz 47.396 kHz 68.250 MHz
59.870 Hz 47.776 kHz 79.500 MHz
74.893 Hz 60.289 kHz 102.250 MHz
1360 × 768 60.015 Hz 47.712 kHz 85.500 MHz
SXGA 1280 × 1024 60.020 Hz 63.981 kHz 108.000 MHz
75.025 Hz 79.976 kHz 135.000 MHz
76
Chapter 10: Appendix
HDMI signal formats
Note:
•The HDMI inputs on this TV only accept VGA, SVGA, XGA, WXGA, and SXGA signal formats which are compliant with
VESA-DMT as in the table below. Since some PC, HDMI, or DVI device input signals are different from the resolution and
frequency described in the table below, the following problems may occur: incorrect display, false format detection,
picture position failure, blur, or judder. In these cases, set the monitor output format on your PC, HDMI, or DVI device to
conform to any of the signals in the table below.
•The signals whose vertical frequency is 24 Hz, 56 Hz, 70 Hz, 72 Hz, or 75 Hz are converted to a 60 Hz signal.
•When you connect a PC to this TV, it is recommended to set the refresh rate of your PC to 60 Hz.
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard
VGA 640 × 480 59.940 Hz 31.469 kHz 25.175 MHz
72.809 Hz 37.861 kHz 31.500 MHz
75.000 Hz 37.500 kHz 31.500 MHz
SVGA 800 × 600 56.250 Hz 35.156 kHz 36.000 MHz
60.317 Hz 37.879 kHz 40.000 MHz
72.188 Hz 48.077 kHz 50.000 MHz
75.000 Hz 46.875 kHz 49.500 MHz
XGA 1024 × 768 60.004 Hz 48.363 kHz 65.000 MHz
70.069 Hz 56.476 kHz 75.000 MHz
75.029 Hz 60.023 kHz 78.750 MHz
WXGA 1280 × 768 59.995 Hz 47.396 kHz 68.250 MHz
59.870 Hz 47.776 kHz 79.500 MHz
74.893 Hz 60.289 kHz 102.250 MHz
1360 × 768 60.015 Hz 47.712 kHz 85.500 MHz
SXGA 1280 × 1024 60.020 Hz 63.981 kHz 108.000 MHz
75.000 Hz 79.976 kHz 135.000 MHz
480i 720 × 480i 59.940/60 Hz 15.734/15.750 kHz 27.000/27.027 MHz
480p 720 × 480p 59.940/60 Hz 31.469/31.500 kHz 27.000/27.027 MHz
720p 1280 × 720p 59.940/60 Hz 44.955/45.000 kHz 74.176/74.250 MHz
1080i 1920 × 1080i 59.940/60 Hz 33.716/33.750 kHz 74.176/74.250 MHz
1080p 1920 × 1080p 23.976/24 Hz 26.973/27.000 kHz 74.176/74.250 MHz
59.940/60 Hz 67.433/67.500 kHz 148.352/148.500 MHz
77
Chapter 10: Appendix
Remote control functional key chart
REMOTE
CONTROL KEY Toshiba TV CABLE SAT
(satellite) Blu-ray™ DVD/
DVD-R VCR Reciver/
Amp CD
GAME Game --- --- --- --- --- --- ---
POWER Power Power Power Power Power Power Power Power
FREEZE (TV)Freeze
MODE
SELECT Remote control device mode selection
1 1 11111AV
input 1 1
2 2 22222AV
input 2 2
3 3 33333AV
input 3 3
4 4 44444AV
input 4 4
5 5 55555CD5
6 6 66666Tuner6
7 7 77777Phono7
8 8 88888Cassette8
9 9 99999AUX9
0 0 00000---0
– – (digital
separator) --- +10 +10 +10 +100 --- ---
INPUT (TV) Input Input Input
VOL +/- Volume
up/down
Volume
up/down
*1
Volume
up/down
*1
Volume
up/down
*1
Volume
up/down
*1
Volume
up/down
*1
Volume
up/down
Volume
up/down
QUICK Quick
Menu --- --- --- --- --- --- ---
MUTE Mute Mute*1Mute*1Mute*1Mute*1Mute*1Mute Mute
CH RTN Last
channel
Last
channel
Last
channel --- --- --- --- ---
CHBb Channel
up/down
Channel
up/down
Channel
up/down --- Channel
up/down
Channel
up/down
Channel
up/down ---
NET TV/
POPUP
MENU
NET TV --- --- Popup
Menu Menu --- --- ---
NETFLIX Netflix --- --- --- --- --- --- ---
Y! WIDGETS Yahoo! TV
Widgets --- --- --- --- --- --- ---
INFO (TV) Info
/ Page up/
down --- --- --- --- --- --- ---
Page left/
Channel
Browser
--- --- --- --- --- --- ---
78
Chapter 10: Appendix
Note:
•“---” = key does not send a signal in that remote control mode.
*1 Volume affects the TV by default. When the volume is unlocked, each device has its own volume if its ID has volume
data. The AUDIO modes will have their own volume if volume lock is set on TV, CABLE/SAT, VCR/PVR, or DVD mode.
See “Locking the volume keys” (- p. 80).
*2 This function is available for only HDMI® CEC (- p. 40) and Media Player.
*3 DVD: REC is only for DVD Recorder, no function is selected for DVD Player.
Page right/
Favorite
Browser
--- --- --- --- --- --- ---
MENU Menu
Menu,
Cable
Menu
Menu,
Action
Menu
Top
Menu
Top
Menu --- Menu Menu
GUIDE Guide Guide Guide --- --- --- --- ---
RETURN Return --- --- Return Return --- --- ---
EXIT Exit Exit Exit Clear Clear --- --- ---
B / b Menu select
up/down
Cursor
up/down
Cursor
up/down
Cursor
up/down
Cursor
up/down --- --- ---
C / cMenu select
left/right
Cursor
left/right
Cursor
left/right
Cursor
left/right
Cursor
left/right --- --- ---
OK OK Select Select Select Select --- --- ---
REW
Rewind*
2Rewind Rewind Rewind Rewind Rewind --- Rewind
PLAY Play*2Play Play Play Play Play --- Play
FF
Fast
Forward
*
2
Fast
Forward
Fast
Forward
Fast
Forward
Fast
Forward
Fast
Forward --- Fast
Forward
SKIP Z Skip REW/
DAY–
*
2--- --- Skip
REW
Skip
REW --- --- Skip
REW
STOP Stop*2Stop Stop Stop Stop Stop --- Stop
PAUSE/
STEP Pause*2PausePausePausePausePause--- Pause
SKIP z Skip FWD/
DAY+
*
2--- --- Skip
FWD
Skip
FWD --- --- Skip
FWD
RED Red --- --- Red Red --- --- ---
GREEN Green --- --- Green Green --- --- ---
YELLOW Yellow --- --- Yellow Yellow --- --- ---
BLUE/
HOME Blue/Home --- --- Blue Blue --- --- ---
SLEEP (TV)Sleep
PIC SIZE (TV) Picture size
MTS/AUDIO MTS --- --- Audio Audio --- --- ---
CC/
SUBTITLE
C. Caption
--- --- Subtitle Subtitle --- --- ---
SET UP -- --- --- Setup Setup --- --- ---
REC Record Record Record ---
Record *3
(Double
click)
Record
(Double
click)
--- ---
REMOTE
CONTROL KEY Toshiba TV CABLE SAT
(satellite) Blu-ray™ DVD/
DVD-R VCR Reciver/
Amp CD
79
Chapter 10: Appendix
Operating other devices
Your TV remote control has one dedicated TV mode
and three programmable multi-brand modes: CABLE/
SAT, BD/DVD, and AUX.
Note: To operate a non-Toshiba device or a Toshiba
device that the remote control is not preprogrammed to
operate, you must program the remote.
Note: If you cannot program the TV’s remote to operate
your device or some of its features, use the device’s
remote or the controls on the device.
Programming the remote to
operate other devices
Device code setup
1Find the code for your device brand in the remote
control device code table (- p. 82–87).
If multiple codes are listed, try each one separately
until you find one that works.
2Press a mode select button (CABLE/SAT, BD/DVD,
or AUX).
3While holding down Q, input the 4-digit code for
your device.
4Point the remote at the device. Press to test the
code.
5When programming is complete, test all necessary
keys on the TV’s remote that operate your device. If
some keys are not operational, repeat the device
code setup using another code (if other codes are
listed for your device).
6To control the TV, press TV.
7If your VCR does not respond to the codes for your
VCR brand, and has a switch labeled VCR1/VCR2,
set the switch to the other position, then program
the remote control.
Note: Every time you change the batteries, you must
reprogram the remote.
Mode select Default device mode control (before
programming)
TV Toshiba TV
CABLE/SAT Toshiba Satellite receiver
BD/DVD Toshiba Blu-ray Disc™ player
AUX Onkyo Receiver
Mode select Device mode control (after
programming)
TV Toshiba TV
CABLE/SAT
Multi-brand video/audio devicesBD/DVD
AUX
Result Meaning
The device responds. Valid code
The device does not
respond.
Invalid code
Repeat the procedure, using
another code
POWER
80
Chapter 10: Appendix
Searching for a device code
If you do not know the device code for a particular
device, you can view each available code for that device
mode and sample the functions to find the code that
operates the target device.
1Press a mode select button on the remote.
2 While holding down Q, press 8, 5, 0, 0. The
remote control enters program mode.
3Point the remote at the target device. Press , 1,
, , or , and then press B or b to change a
code.
4If the device responds to the remote control:
Press Q to store the device code. The remote exits
program mode.
5If the device does not respond to the remote control:
Repeat this step until the device responds to the
remote.
When no code is found, exit the program mode by
the following operation:
•Press Q. (current state is stored)
•Press no key for 10 seconds. (current state is not
stored)
Note: When a search cycle is completed, the remote
displays each available code again. If no key is pressed
within 10 seconds, the remote exits program mode and
returns to the previous code.
Locking the volume keys
The remote’s volume keys ( , , and MUTE) are
locked to a device mode.
See “Operating other devices” (- p. 79).
To lock the remote’s volume keys to a specific mode:
Example: CABLE/SAT mode
1Press CABLE/SAT.
2While holding down Q, press 8, 0, 0, 0.
3Press (locked).
The remote’s volume keys now operate the volume
of the device associated with the CABLE/SAT
mode, even when CABLE/SAT is not the current
device mode.
To unlock the remote’s volume keys:
1While holding down Q, press 8, 0, 0, 0.
2Press . The CABLE/SAT mode is unlocked.
Clearing the remote’s programming
You can clear all programmed remote control features
not related to “Device code setup” and reset the volume
lock to the TV device mode.
While holding down Q, press 8, 9, 0, 0.
Resetting to the factory default
You can clear changed manufacturing features.
While holding down Q, press 8, 9, 0, 1.
State Meaning
Locked (default)
The remote operates the TV’s volume
except the AUX mode, even when the
TV is not the current device mode.
Unlocked
The remote operates the volume of
the device associated with the current
device mode.
Each device mode has its own volume
(if the device ID has volume data).
Locked to a
specific device
mode
The remote operates the volume of
the device associated with the locked
mode, even when the locked mode is
not the current device mode.
Note: The AUX mode is not locked to
other device modes.
POWER
VOL
CH
VOL
VOL
VOL
VOL
81
Chapter 10: Appendix
Operating the TV with
combination buttons
You can directly operate the TV power, input switch,
picture size switch, and picture mode switch by
pressing a combination button while holding down a
color button.
Color button Combination
button Behavior/Mode
RED
GAME Power Off
POWER Power On
1 Video 1
2 Video 2
3ColorStream HD1
4ColorStream HD2
5HDMI 1
6HDMI 2
7HDMI 3
8HDMI 4
9PC
0 ANT/CABLE
MUTE Mute On
GREEN
1 Native (Picture Size)
24:3 (Picture Size)
3 TheaterWide 1 (Picture Size)
4 TheaterWide 2 (Picture Size)
5 TheaterWide 3 (Picture Size)
6 Full (Picture Size)
7 Normal (Picture Size)
8 Dot by Dot (Picture Size)
MUTE 1/2 Mute On
YELLOW
1 AutoView (Picture Mode)
2 Sports (Picture Mode)
3 Standard (Picture Mode)
4Movie 1 (Picture Mode)
5Movie 2 (Picture Mode)
6Store (Picture Mode)
7 Game (Picture Mode)
8PC (Picture Mode)
MUTE Mute Off
82
Chapter 10: Appendix
Remote control
codes
In some cases, you may not be able
to operate your device with the TV
remote control. Your device may
use a code that is not recognized
by the TV remote control. If this
happens, use the device’s remote
control.
Satellite
Cable
BrandCode
BELL EXPRESSVU 0009, 0087
CHAPPARAL 0112
COOLSAT 0015, 0109
DIGIWAV 0019
DIRECTV 0020, 0027,
0013, 0018,
0028, 0028,
0027, 0029,
0030, 0090,
0091, 0105,
0107, 0108,
0118, 0119
DISH NETWORK 0009
DRAKE 0025, 0094,
0095
ECHOSTAR 0009, 0008,
0010, 0011,
0012
EXPRESSVU 0087
FORTEC STAR 0016, 0093,
0104, 0113
GE 0092
GENERAL
INSTRUMENT (GI)
0017, 0103
GLOBECAST 0097, 0098
HITACHI 0020, 0105,
0107, 0108
HUGHES
NETWORK
0020, 0115,
0116
LG 0020
MAGNAVOX 0027, 0089
MITSUBISHI 0020, 0105,
0107, 0108
MOTOROLA 0017, 0024,
0103
NEOSAT 0009
NOVAPLEX 0101
NET 0026
PACE 0023, 0024
PANASONIC 0013, 0014,
0016
PANSAT 0016
PHILIPS 0027, 0020,
0089, 0105,
0107, 0108,
0116
PHILIPS-
MAGNAVOX
0027, 0089
PRIMESTAR 0017
SAMSONIC 0114
SAMSUNG 0018
SKY NETWORK 0023, 0024,
0027, 0090,
0091
SONY 0028, 0117
STAR SIGHT 0088
STARCHOICE 0017
STS 0111
SUPER GUIDE 0110
SYLVANIA 0102
THOMSON 0027
TOSHIBA 0020, 0022,
0000, 0001,
0002, 0003,
0004, 0005,
0006, 0007,
0096, 0099,
0105, 0107,
0108
ULTIMATE TV 0028
UNIDEN 0088
VIDEO CIPHER 0025
VISIONTEC 0106
VIEWSAT 0021
ZENITH 0024, 0025,
0094, 0095,
0100
BrandCode
ABC 0081, 0078,
0065, 0079,
0123
ADELPHIA 0045
ALLEGRO 0039, 0059
AMERICAST 0052
ANTRONIX 0033, 0077,
0124
ARCHER 0033, 0077,
0082, 0124
AT&T 0068
BELL 0069
BELL SOUTH 0052
CABLETENNA 0033
CABLEVIEW 0033
CABLEVISION 0045
CENTURY 0082
CHARTER 0045
CITIZEN 0082
CLEARMAX 0042
COLOR VOICE 0040
COMCAST 0045, 0073,
0121
COMTRONICS 0036, 0083,
0122
CONTEC 0064
DIGITAL MUSIC
EXPRESS
0046
EASTERN 0061
EVERQUEST 0036
GARRARD 0082
GC ELECTRONICS 0077, 0124
GE 0038
GEMINI 0074, 0031
GENERAL
INSTRUMENT (GI)
0072, 0081,
0079, 0081,
0046, 0065,
0078, 0123
GOLDSTAR 0041
HAMLIN 0081, 0060,
0066, 0067,
0123
HITACHI 0078
ILLICO 0045
JASCO 0082
JERROLD 0072, 0079,
0081, 0065,
0078, 0076,
0123
MAGNAVOX 0075
MEMOREX 0049
MOTOROLA 0071, 0081,
0070, 0072,
0079, 0076,
0078, 0065
MOVIE TIME 0086
NOVAPLEX 0056
NOWTV 0053
NSC 0086
OAK 0064
PANASONIC 0044
PARAGON 0049
PHILIPS 0082, 0031,
0075, 0084,
0083, 0085
PHILIPS-
MAGNAVOX
0054, 0055
PIONEER 0041, 0043,
0045, 0034
PULSAR 0049
QUASAR 0049
RADIO SHACK 0035, 0054,
0055, 0059
RCA 0082, 0047
REALISTIC 0077, 0124
REGAL 0067
REGENCY 0061
REMBRANDT 0078
ROGERS 0045
RUNCO 0049
SAMSUNG 0041, 0036
83
Chapter 10: Appendix
Blu-ray Disc™
DVD
SCIENTIFIC
ATLANTA
0045, 0063,
0045
SIGNAL 0036
SIGNATURE 0078
SL MARX 0036
STANDARD 0032
STAR SIGHT 0047
STAR TRAK 0058
STARCOM 0081, 0123
STARGATE 0036
TANDY 0080
TELEVIEW 0036
TEXSCAN 0032
TIME WARNER 0045
TOCOM 0065, 0062
TOSHIBA 0049
TV86 0086
UNIKA 0033, 0077,
0082, 0124
UNITED CABLE 0081, 0123
UNIVERSAL 0033, 0039,
0077, 0124
VERIZON 0045, 0121
VIDEO TECH 0037
VIDEOTRON 0045
VIDEOWAY 0048
VIEWSTAR 0083, 0075,
0086, 0080,
0122
VISIONTICS 0057
ZENITH 0050, 0059,
0049, 0051
ZENITH
NETWORK
0052
BrandCode
DENON 1019, 1029,
1030, 1081
HITACHI 1019, 1110,
1111, 1113
INTGERA 1128
JVC 1011, 1012,
1013, 1021,
1022
KENWOOD 1019
LG 1093
MARANTZ 1077, 1078
MITSUBISHI 1034, 1035
ONKYO 1128
PANASONIC 1020, 1019,
1017, 1018
PHILIPS 1133
PIONEER 1069
SAMSUNG 1134
SHARP 1026, 1027,
1028
SONY 1086, 1087,
1088, 1090
TOSHIBA 1000
YAMAHA 1065, 1122
BrandCode
AFREEY 1112
ALLEGRO 1093, 1167
AMES 1100, 1170
AMW 1059
APEX 1051, 1053,
1096, 1094,
1055, 1155
ASPIRE 1036
A-TREND 1112
BLAUPUNKT 1094
BLUESKY 1092, 1053
BLU-RAY 1025, 1137,
1016, 1093,
1069, 1086,
1134, 1145,
1160, 1166,
1167, 1181
BODYSONIC 1112
BOSE 1006
BROKSONIC 1005
CAVS 1043
CENTRIOS 1040, 1066
CHANGHONG 1155
CINEVISION 1093, 1167
CLASSIC 1100, 1155,
1170
COBY 1039, 1042,
1040, 1053,
1097, 1095,
1147
CONCEPT 1094
CONIA 1053
CONTEL 1151
CURTIS
INTERNATIONAL
1097, 1095
CYBERHOME 1063, 1112,
1064
CYTRON 1048, 1092
DAEWOO 1033, 1032
DENON 1025, 1019,
1029, 1030,
1081
DENZEL 1059
DESAY 1152
DIAMOND VISION 1047
DIGITREX 1053
DISNEY 1117
DRIVE 1153
DUAL 1103, 1048,
1059
DURABRAND 1066, 1093,
1048, 1103,
1167
DVD2000 1031
EMERSON 1093, 1117,
1167
ESA 1103
FISHER 1101
FUNAI 1117
GE 1079, 1094
GOLDSTAR 1093, 1167
GO-VIDEO 1100, 1060,
1032, 1009,
1052, 1004,
1007, 1170
GPX 1100
GRADIENTE 1092, 1103,
1040
GREENHILL 1094
HAAZ 1102, 1046
HARMAN
KARDON
1114
HD-DVD 1137, 1016,
1069, 1086,
1129, 1061,
1093, 1145,
1160, 1166,
1167
HITACHI 1070, 1004,
1059, 1019,
1110, 1111,
1113, 1143
HITEKER 1053
HUMAX 1123
ILO 1015, 1094
INFINITY 1112
INITIAL 1094, 1094
INSIGNIA 1117, 1041,
1094, 1091,
1094, 1093,
1093, 1167
INTEGRA 1120
IRT 1095
JBL 1114
JVC 1061, 1014,
1130, 1010,
1011, 1012,
1013, 1021,
1022, 1139,
1140, 1141,
1142, 1158
JWIN 1053, 1047
KAWASAKI 1102, 1066
KENWOOD 1019, 1119
KISS 1059
KLH 1094, 1051,
1154
KONKA 1049, 1045
KOSS 1092, 1092
KXD 1095
LASONIC 1102
LG 1093, 1092,
1093, 1093,
1167, 1168
LINN 1076
84
Chapter 10: Appendix
DVD Recorders
LITEON 1109, 1118,
1015
MAGNAVOX 1061, 1130,
1117, 1131,
1158, 1177,
1178
MARANTZ 1061, 1093,
1130, 1077,
1078, 1157,
1158, 1167,
1176
MEDION 1015, 1048
MEMOREX 1005, 1048
MERIDIAN 1061
MICROSOFT 1079
MINTEK 1094
MITSUBISHI 1094, 1034,
1035
MUSTEK 1100, 1170
MYRON&DAVIS 1040
NAD 1093, 1167
NEC 1093, 1167
NESA 1094, 1040
NEXXTECH 1041, 1091,
1066, 1051,
1059, 1103,
1040, 1099,
1148, 1171
NORCENT 1039, 1109,
1041, 1097
ONKYO 1061, 1120,
1128, 1157
OPTIMUS 1070, 1162
ORION 1005
ORITRON 1092
PACIFIC 1048
PANASONIC 1016, 1020,
1019, 1024,
1023, 1143,
1144, 1145
PHILIPS 1092, 1133,
1117, 1131,
1061, 1130,
1175, 1177,
1178, 1179
PHILIPS-
MAGNAVOX
1061, 1130,
1131, 1178
PIONEER 1069, 1069,
1070, 1071,
1074, 1072,
1123, 1160,
1161, 1162,
1163, 1164,
1165
PIVA 1146
POLAROID 1058, 1121,
1047, 1051,
1095, 1169
POLK AUDIO 1061, 1130
PROLINE 1092
PROSCAN 1079
PROSONIC 1039
PROTRON 1041
RADIO SHACK 1066, 1116
RCA 1079, 1092,
1094, 1066,
1116, 1048
REGENT 1103
REOC 1102
RIO 1093, 1167
RJ TECHNOLOGY 1041, 1038,
1149
ROTEL 1014
SAMSUNG 1134, 1136,
1004, 1009,
1008, 1007,
1134, 1138,
1180, 1181
SAMPO 1112
SANSUI 1005
SANYO 1066, 1101
SEARS 1005
SEG 1059
SELECTRON 1037, 1040
SEMP 1092
SHARP 1137, 1044,
1026, 1027,
1028
SHERWOOD 1115
SHINCO 1094
SHINSONIC 1094
SONIC BLUE 1060
SONY 1083, 1089,
1084, 1082,
1085, 1086,
1087, 1088,
1090, 1166
SUNGALE 1041, 1040,
1147, 1150
SVA 1053, 1044
SYLVANIA 1117
SYMPHONIC 1117
TASCAM 1014
TEAC 1070, 1066,
1093, 1167
TECHNICS 1019
TECHWOOD 1130
TEVION 1092, 1048,
1103, 1102,
1046
THETA DIGITAL 1070
TIVO 1123
TOSHIBA 1129, 1005,
1104, 1061,
1108, 1001,
1002, 1003,
1105, 1106,
1107, 1156,
1172, 1173,
1174
TRUTECH 1063, 1032
UNITED 1066
VENTURER 1104, 1066,
1172
WHARFEDALE 1112
WESTINGHOUSE 1084
WHITE
WESTINGHOUSE
1117
X-BOX 1079
XENIUS 1092
YAMAHA 1130, 1122,
1131, 1158,
1159, 1178
YAMAKAWA 1056, 1059,
1065
ZENITH 1061, 1093,
1167
BrandCode
ASTAR 1050, 1095
APEX 1054
ASPIRE 1057, 1036
BROKSONIC 1067
BUSH 1068
COBY 1095
CYBERHOME 1064
EMERSON 1117
GO-VIDEO 1052, 1098,
1100, 1135
HITACHI 1018, 1113
HUGHES 1117
HUGHES
NETWORK
1117, 1127
HUMAX 1126
ILO 1015
INSIGNIA 1093
JVC 1013, 1012,
1010, 1011
KXD 1095
LG 1093
LITEON 1015, 1098
MAGNAVOX 1131, 1117
MEDION 1015
MEMOREX 1048
MUSTEK 1100
PANASONIC 1018, 1017,
1019, 1020
PHILIPS 1127, 1125,
1075, 1117,
1131, 1132,
1098
PHILIPS-
MAGNAVOX
1131
PIONEER 1070, 1126,
1073, 1074
POLAROID 1095, 1058
RCA 1080, 1079
SAMSUNG 1135, 1004,
1136
Sansui 1068
SANYO 1101
SHARP 1137
85
Chapter 10: Appendix
VCR
SONY 1084, 1083,
1089
SYLVANIA 1117
SYMPHONIC 1117
TIVO 1062, 1125,
1126, 1126
TOSHIBA 1062, 1061,
1106, 1107,
1108
TRUTECH 1063
YAMAHA 1018, 1131
ZENITH 1093
BrandCode
ACCELE 2007
ADMIRAL 2062
ADVENTURA 2000
AIKO 2019
AIWA 2033, 2047,
2001, 2000
AKAI 2047, 2065,
2041, 2040,
2018, 2017,
2048
ALLEGRO 2010, 2090,
2033, 2074
AMERICAN HIGH 2046
ASHA 2007
AUDIO
DYNAMICS
2011, 2012,
2021
AUDIOVOX 2033
BEAUMARK 2007
BELL&HOWELL 2024
BROKSONIC 2003, 2051,
2052, 2005,
2002, 2049,
2081
CALIX 2033
CANDLE 2027, 2033,
2007, 2021,
2039
CANON 2060, 2004,
2046
CAPEHART 2090
CARVER 2056
CCE 2019, 2086
CINEVISION 2033, 2074
CITIZEN 2027, 2033,
2019, 2007,
2021, 2039
COLORTYME 2021
COLT 2086
CRAIG 2033, 2007,
2086, 2023
CURTIS MATHES 2060, 2056,
2047, 2019,
2007, 2021,
2020, 2046
CYBERNEX 2007
DAEWOO 2000, 2027,
2051, 2019,
2039
DBX 2011, 2012,
2021
DENON 2043
DIMENSIA 2060
DURABRAND 2033, 2074
DYNATECH 2047, 2000
ELECTROHOME 2033, 2018
ELECTROPHONIC 2033
EMERSON 2051, 2033,
2019, 2003,
2052, 2015,
2005, 2073,
2007, 2027,
2084, 2047,
2082, 2075,
2024, 2001,
2087, 2088,
2040, 2049,
2020, 2000,
2018, 2035,
2038, 2036,
2091, 2081,
2046, 2034,
2083
FISHER 2022, 2024,
2056, 2021,
2023, 2031,
2032, 2078
FUJI 2065, 2046
FUNAI 2047, 2088,
2087, 2000
GARRARD 2000
GE 2007, 2060,
2061, 2029,
2046
GOLDSTAR 2047, 2033,
2076, 2090,
2021
GO-VIDEO 2019, 2085,
2007
GRADIENTE 2000, 2033
HARLEY
DAVIDSON
2000
HARMAN
KARDON
2021, 2018
HARWOOD 2086
HEADQUARTER 2024
HI-Q 2023
HITACHI 2030, 2047,
2079, 2017,
2077, 2080
INFINITY 2056
INSIGNIA 2033, 2074
INSTANT REPLAY 2047, 2046
INTEO 2033
JC PENNEY 2060, 2033,
2024, 2007,
2030, 2011,
2012, 2046,
2017, 2077,
2044, 2021
JCL 2046
JENSEN 2030, 2017
JVC 2011, 2012,
2024, 2010,
2013, 2021,
2017
KENWOOD 2024, 2011,
2012, 2021,
2017
KLH 2086
KODAK 2033, 2046
LG 2047, 2090,
2076, 2074
LLOYD 2047, 2000
LOGIK 2086
LXI 2047, 2033
MAGNAVOX 2046, 2056,
2090, 2047,
2062, 2060,
2056, 2047,
2088, 2089
MAGNIN 2007
MARANTZ 2056, 2024,
2011, 2012,
2081, 2046,
2004, 2021
MARTA 2033
MATSUSHITA 2046
MEI 2046
MEMOREX 2056, 2033,
2024, 2022,
2005, 2090,
2007, 2062,
2047, 2048,
2023, 2000,
2046
MGA 2015, 2018
MGN
TECHNOLOGY
2007
MIDLAND 2029
MINOLTA 2030, 2077
MITSUBISHI 2015, 2016,
2030, 2011,
2012, 2006,
2018
MONTGOMERY
WARD
2062, 2092
MOTOROLA 2062, 2046
MTC 2047, 2007,
2000
MULTITECH 2047, 2007,
2000, 2029,
2086
86
Chapter 10: Appendix
CD
NEC 2024, 2011,
2012, 2081,
2034, 2050,
2017, 2021,
2020
NEXXTECH 2042
NIKKO 2033
NOBLEX 2007
OLYMPUS 2046
OPTIMUS 2033, 2007,
2014, 2033,
2063, 2014,
2062
OPTONICA 2007, 2092
ORION 2003, 2005
PANASONIC 2014, 2014,
2046, 2060
PENTAX 2030, 2021,
2077
PHILCO 2056, 2060,
2047, 2046
PHILIPS 2056, 2057,
2088, 2056,
2046, 2089
PHILIPS-
MAGNAVOX
2056, 2062
PILOT 2033
PIONEER 2043, 2030,
2011, 2012,
2045, 2044
PORTLAND 2039
PROSCAN 2060, 2059
PROTEC 2086
PULSAR 2090
QUARTER 2024
QUARTZ 2024
QUASAR 2014, 2060,
2014, 2046
RADIO SHACK 2060, 2062,
2047, 2048,
2033, 2024,
2061, 2007,
2063, 2014,
2023, 2000,
2018, 2032,
2046, 2092
RADIX 2033
RANDEX 2033
RCA 2060, 2033,
2059, 2054,
2060, 2053,
2055, 2061,
2007, 2030,
2041, 2029,
2046, 2077,
2058
REALISTIC 2060, 2062,
2047, 2033,
2024, 2007,
2063, 2014,
2023, 2000,
2018, 2032,
2046, 2092,
2048
RICOH 2067
RIO 2033, 2074
RUNCO 2090
SAMSUNG 2008, 2048,
2027, 2030,
2007, 2009
SAMTRON 2007
SANKY 2062, 2090
SANSUI 2005, 2011,
2012, 2002,
2003, 2017
SANYO 2025, 2022,
2024, 2007,
2023, 2078
SCOTT 2027, 2051,
2052, 2015,
2075, 2049,
2036
SEARS 2014, 2033,
2024, 2056,
2030, 2002,
2088, 2023,
2031, 2032,
2046, 2077,
2044, 2039
SHARP 2063, 2062,
2047, 2082,
2018, 2092
SHINTOM 2065, 2067,
2030, 2086,
2037
SHOGUN 2007
SIGNATURE 2047
SINGER 2046, 2086
SONY 2064, 2068,
2065, 2066,
2067, 2070,
2069, 2071,
2072
STS 2030, 2046,
2077
SUPERSCAN 2088
SYLVANIA 2000, 2047,
2056, 2015,
2060, 2088,
2046, 2047,
2087
SYMPHONIC 2047, 2047,
2088, 2000,
2087
TANDY 2047, 2024
TASHIKO 2033
TATUNG 2017
TEAC 2047, 2000,
2017
TECHNICS 2046
TEKNIKA 2047, 2033,
2073, 2000,
2046
TMK 2007, 2020,
2034
TOSHIBA 2027, 2028,
2026, 2056,
2015, 2007,
2030, 2032,
2075
TOTEVISION 2033, 2007
TRUTECH 2019
UNITECH 2007
VECTOR
RESEARCH
2027, 2011,
2012, 2021
VICTOR 2011, 2012
VIDEO CONCEPTS 2027, 2011,
2012, 2021,
2018
VIDEOSONIC 2007
WARDS 2060, 2062,
2047, 2027,
2033, 2007,
2030, 2023,
2000, 2018,
2046, 2092,
2077, 2075,
2086
WHITE
WESTINGHOUSE
2047, 2019,
2087
XR-1000 2000, 2046,
2086
YAMAHA 2021, 2017,
2011, 2012
ZENITH 2090, 2010,
2019, 2082,
2067, 2007,
2033, 2065,
2005, 2025,
2011, 2085,
2090, 2074,
2056, 2062,
2047, 2076,
2079
BrandCode
ADCOM 3018
AIWA 3002, 3047,
3001
AKAI 3025, 3024,
3025
AUDIO TECHNICA 3022
CALIFORNIA
AUDIO LABS
3039
CARVER 3043, 3016,
3017, 3042
CASIO 3000
CITIZEN 3052
CURTIS MATHES 3000
DENON 3045
EMERSON 3018, 3004
FISHER 3016, 3014,
3071, 3073,
3016
GENEXXA 3004, 3037,
3053
87
Chapter 10: Appendix
Receiver & amp
HARMAN
KARDON
3013
HITACHI 3037
INSIGNIA 3078
JC PENNEY 3033, 3000
JVC 3008, 3007
KENWOOD 3046, 3028,
3027, 3026,
3029, 3028
KRELL 3043
LUXMAN 3031, 3059,
3063, 3066
LXI 3000
MAGNAVOX 3043, 3041
MARANTZ 3043, 3061,
3057, 3038
MCS 3033, 3000
MGA 3013
MISSION 3043
MITSUBISHI 3013, 3012
NAD 3067
NEC 3033
NEXXTECH 3050
NIKKO 3022, 3004,
3071
NSM 3043
ONKYO 3032, 3068,
3070, 3069
OPTIMUS 3016, 3017,
3037, 3046,
3064, 3056,
3062, 3058,
3036, 3036,
3035
PANASONIC 3039, 3009,
3010, 3039,
3011
PHILIPS 3043, 3041,
3042
PIONEER 3036, 3037,
3036, 3037,
3053, 3036,
3034, 3036
PROTON 3043
QUASAR 3039
RADIO SHACK 3017, 3062,
3055, 3036,
3050, 0868,
3044, 3036
RCA 3018, 3016,
3040, 3003,
3036, 3044,
3044, 3044,
3044, 3036
REALISTIC 3018, 3016,
3004, 3037,
3057, 0697,
3062
ROTEL 3043
SAE 3043
SAMSUNG 3077
SANSUI 3043, 3038,
3003, 3006
SANYO 3016, 3016,
3016, 3015,
3030
SCOTT 3018, 3004
SEARS 3046, 3057,
3000
SHARP 3046, 3057
SHERWOOD 3005, 3057,
3056, 3055
SHURE 3033
SONY 3075, 3076
SYLVANIA 3043
SYMPHONIC 3048
TEAC 3071, 3057,
3062, 3048,
3065, 3054,
3060
TECHNICS 3039, 3009,
3039, 3011
THETA DIGITAL 3041
TOSHIBA 3067
VICTOR 3008
YAMAHA 3022, 3020,
3021, 3023,
3019
ZENITH 3071, 3049,
3072, 3074,
3051
BrandCode
AIWA 4001, 4003
APEX 4020
APPLE IPOD 4080
BOSE 4007, 4081,
4082
CARVER 4042
CENTRIOS 4021, 4020,
4019
CITIZEN 4069
DELPHI 4044
DENON 4049, 4051,
4050, 4090,
4091
FISHER 4068, 4067
GOLDSTAR 4018
HARMAN
KARDON
4072, 4005
IPOD 4066
JVC 4011, 4010,
4009
KENWOOD 4077, 4032
KOSS 4061
MAGNAVOX 4069, 4068,
4042
MARANTZ 4074, 4042
NAD 4076
NELSON 4019
NEO 4044
NEXXTECH 4020, 4019,
4004
ONKYO 4078, 4079
OPTIMUS 4024, 4035,
4002, 4012,
4034, 4036,
4037
PANASONIC 4093, 4092,
4014, 4043,
4014, 4015,
4016, 4013,
4017
PHILIPS 4061, 4068,
4043, 4042,
4042, 4042,
4083
PIONEER 4036, 4040,
4034, 4041,
4033, 4038,
4037, 4036,
4039
RADIO SHACK 4036, 4037,
4038, 4075,
4073
RCA 4031, 4046,
4023, 4036,
4037, 4038,
4048, 4045,
4047, 4073,
4075
RIO 4063, 4025
SAMSUNG 4008
SANYO 4024
SHARP 4053, 4022,
4052
SHERWOOD 4006
SIRIUS 4022
SKYFI 4044
SONY 4088, 4054,
4055, 4087,
4057, 4058,
4056, 4060,
4089, 4059
TAO 4044
TECHNICS 4093, 4092,
4014, 4043,
4014, 4015
TOSHIBA 4000
WONDER 4021
XM RADIO 4044, 4044
YAMAHA 4030, 4028,
4026, 4027,
4029, 4070,
4071
ZENITH 4084, 4062,
4012, 4085,
4064, 4018,
4086, 4068,
4025, 4065
88
Chapter 10: Appendix
Limited United States Warranty
for LCD Televisions
Toshiba America Information Systems, Inc. (“TAIS”) makes
the following limited warranties to original consumers in the
United States.
THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL
CONSUMER PURCHASER OR ANY PERSON RECEIVING
THIS LCD TELEVISION AS A GIFT FROM THE ORIGINAL
CONSUMER PURCHASER AND TO NO OTHER
PURCHASER OR TRANSFEREE. LCD TELEVISIONS
PURCHASED IN THE U.S.A. OR PUERTO RICO AND USED
ANYWHERE OUTSIDE OF THE U.S.A. OR PUERTO RICO,
INCLUDING, WITHOUT LIMITATION, CANADA AND
MEXICO, ARE NOT COVERED BY THESE WARRANTIES.
LCD TELEVISIONS PURCHASED ANYWHERE OUTSIDE OF
THE U.S.A. OR PUERTO RICO, INCLUDING, WITHOUT
LIMITATION, CANADA AND MEXICO, AND USED IN THE
U.S.A., ARE NOT COVERED BY THESE WARRANTIES.
Limited One (1) Year Warranty on Parts and Labor
TAIS WARRANTS THIS LCD TELEVISION AND ITS PARTS
AGAINST DEFECTS IN MATERIALS OR WORKMANSHIP
FOR A PERIOD OF ONE (1) YEAR FROM THE DATE OF
ORIGINAL RETAIL PURCHASE. DURING THIS PERIOD,
TAIS WILL, AT TAIS' SOLE DESCRETION, REPAIR OR
REPLACE A DEFECTIVE PART/PRODUCT WITH A NEW OR
REFURBISHED PART/PRODUCT WITHOUT CHARGE TO
YOU FOR PARTS OR LABOR. ANY PART OR PRODUCT
REPLACED UNDER THIS LIMITED WARRANTY BECOMES
THE PROPERTY OF TAIS. IN SOME CASES, YOU MAY BE
RESPONSIBLE FOR DELIVERING THE PRODUCT TO A
SERVICE CENTER.
Rental Units
The limited warranty period begins on the date of the first
rental or thirty (30) days after the date of shipment to the rental
firm, whichever comes first.
Your Responsibility
Read the owner’s manual thoroughly before installing or
operating this LCD Television. Complete and mail the
enclosed product registration card (if provided) or register
your LCD Television online at www.support.toshiba.com.
Registration of your LCD Television will enable TAIS to
contact you in the unlikely event a safety notification is
required under the U.S. Consumer Product Safety Act.
Failure to complete and return the product registration card
does not diminish your warranty rights.
THE ABOVE WARRANTIES ARE SUBJECT TO THE
FOLLOWING CONDITIONS:
(1) This Limited Warranty is extended only to the original
purchaser and only covers product purchased as new.
(2) A purchase receipt or other proof of the original purchase
date is required for warranty service.
(3) All warranty servicing of this LCD Television must be
performed by an Authorized TAIS Service Provider.
(4) The warranties from TAIS are effective only if this LCD
Television is purchased and operated in the U.S.A. or
Puerto Rico.
(5) Removal and reinstallation of product that is mounted in
such a manner as to impede normal service is not
covered under these warranties. This includes wall
mounts, custom cabinets and other installation methods
that do not provide for direct and immediate access to the
product for service purposes. Labor service charges for
set installation, setup, adjustment of customer controls,
and installation or repair of antenna, satellite or cable
systems are not covered by this limited warranty.
(6) Reception or other problems caused by inadequate
antenna systems, misaligned satellite dishes, improperly
installed cable drops or use with non-standard signals or
sources are your responsibility and are not covered by
this limited warranty.
(7) This limited warranty is void if the product is used outside
the range of the temperature (heat/cold) and/or moisture
operating conditions as outlined in the product’s
specification listed in the Owner’s manual, or if the
product is exposed to excessive smoke, dust, or other
airborne contaminants or environmental conditions.
(8) Warranties extend only to defects in materials or
workmanship as limited above, and do not extend to any
LCD Television or parts that have been lost or discarded
by you or to damage to the LCD Television or parts
caused by fires, misuse, abuse, accident, Acts of God
(such as lightning or fluctuations in electric power),
improper installation, improper maintenance, or use in
violation of instructions furnished by TAIS; use or
malfunction through simultaneous use of this LCD
Television and connected equipment; or to units that
have been modified or had the serial number removed,
altered, defaced, or rendered illegible.
(9) Product purchased “AS-IS” or “With known faults, defects
or problems” are not covered by this limited warranty.
(10)Product previously owned or registered by a consumer
and resold is not covered by this limited warranty.
(11)Product that is refurbished and resold is not covered
under this limited warranty.
How to Obtain Warranty Service
After following all of the operating instructions in the Owner’s
Manual, review the section entitled "Concierge" located on our
Customer Support Web site at www.support.toshiba.com. If
you find that service is needed, follow the instructions
provided on the web site or please contact TAIS' Consumer
Solution Center toll free at 1-800-631-3811. You must present
upon request your original bill of sale or other proof of
purchase including the serial number for in-warranty service.
ALL WARRANTIES IMPLIED BY THE LAW OF ANY STATE OF
THE U.S.A., INCLUDING THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE EXPRESSLY LIMITED TO THE DURATION
OF THE LIMITED WARRANTIES SET FORTH ABOVE. WITH
89
Chapter 10: Appendix
THE EXCEPTION OF ANY WARRANTIES IMPLIED BY THE
LAW OF ANY STATE OF THE U.S.A. AS HEREBY LIMITED,
THE FOREGOING LIMITED WARRANTY IS EXCLUSIVE AND
IN LIEU OF ALL OTHER WARRANTIES, GUARANTEES,
AGREEMENTS, AND SIMILAR OBLIGATIONS OF TAIS WITH
RESPECT TO THE REPAIR OR REPLACEMENT OF ANY
PARTS. IN NO EVENT SHALL TAIS BE LIABLE FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO, LOST PROFITS,
BUSINESS INTERRUPTION, OR MODIFICATION OR
ERASURE OF RECORDED DATA CAUSED BY USE, MISUSE
OR INABILITY TO USE THIS LCD TELEVISION).
No person, agent, distributor, dealer or company is
authorized to change, modify or extend the terms of these
warranties in any manner whatsoever. The time within which
an action must be commenced to enforce any obligation of
TAIS arising under this limited warranty or under any statute,
or law of the United States or any state thereof, is hereby
limited to ninety (90) days from the date you discover or
should have discovered, the defect. This limitation does not
apply to implied warranties arising under the law of any state
of the U.S.A.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS
WHICH MAY VARY FROM STATE TO STATE IN THE U.S.A.
SOME STATES OF THE U.S.A. DO NOT ALLOW
LIMITATIONS ON THE DURATION OF AN IMPLIED
WARRANTY, WHEN AN ACTION MAY BE BROUGHT, OR
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES. THEREFORE, THE ABOVE
PROVISIONS MAY NOT APPLY TO YOU UNDER SUCH
CIRCUMSTANCES.
Limited Canadian Warranty
for Toshiba Brand Flat Panel Televisions
Toshiba of Canada Limited (“
TCL
”) makes the following
limited warranties to original consumers in Canada.
THESE
LIMITED WARRANTIES EXTEND TO THE ORIGINAL
CONSUMER PURCHASER OR ANY PERSON RECEIVING
THIS TOSHIBA BRAND FLAT PANEL TELEVISION (the
“TELEVISION(S)” or “Television(s)”) AS A GIFT FROM THE
ORIGINAL CONSUMER PURCHASER AND TO NO OTHER
PURCHASER OR TRANSFEREE.
TELEVISIONS PURCHASED IN CANADA, AND USED
ANYWHERE OUTSIDE OF CANADA INCLUDING, WITHOUT
LIMITATION, THE UNITED STATES AND MEXICO, ARE NOT
COVERED BY THESE WARRANTIES.
TELEVISIONS PURCHASED ANYWHERE OUTSIDE OF
CANADA, INCLUDING, WITHOUT LIMITATION, THE UNITED
STATES AND MEXICO, AND USED IN CANADA, ARE NOT
COVERED BY THESE WARRANTIES.
Limited One (1) Year Warranty on Parts and Labour
TCL warrants the Television and its parts against material
defects in materials or workmanship that result in the
Television failing for a period of one (1) year after the date of
original retail purchase.
DURING THIS PERIOD, TCL WILL,
AT TCL'S SOLE OPTION, REPAIR OR REPLACE A
DEFECTIVE PART WITH A NEW OR RECERTIFIED PART
WITHOUT CHARGE TO YOU FOR PARTS OR LABOUR.
Rental Units
The warranty for Television rental units begins with the date of
first rental or thirty (30) days from the date of shipment to the
rental firm, whichever comes first.
Your Responsibility
Read the Owner’s Manual thoroughly before operating this
LCD Television. Register your LCD Television online at http://
support.toshiba.ca/warranty/. Registration of your LCD
Television will enable TCL to contact you in the unlikely event
of a product safety notice. Failure to complete the product
registration does not diminish your warranty rights.
THE ABOVE WARRANTIES ARE SUBJECT TO THE
FOLLOWING CONDITIONS:
(1) You must provide your bill of sale or other proof of
purchase.
(2) All warranty servicing of this Television must be
performed by a Toshiba Authorized Service Provider
(ASP).
(3) The warranties from TCL are effective only if the
Television is (i) purchased as new and unopened from
TCL or from TCL’s authorized distributors, dealers or
resellers (“
ADR’s
”) and (ii) located/operated in Canada.
(4) Removal and reinstallation of product that is mounted in
such a manner as to impede normal service is not
covered under these warranties. This includes wall
mounts, custom cabinets and other installation methods
90
Chapter 10: Appendix
that do not provide for direct and immediate access to the
product for service purposes. Labour charges for set
installation, setup, adjustment of customer controls, and
installation or repair of antenna systems are not covered
by these warranties. Reception problems caused by
inadequate antenna systems are your responsibility.
(5) Warranties extend only to material defects in materials or
workmanship as limited above, and do not extend to:
a. Service, repairs or replacement made necessary by
accident, misuse, abuse, moisture, liquids, dust, dirt,
neglect, accident, damage, 24/7 applications,
improper installation, improper operation, improper
cleaning, improper maintenance, normal wear and
tear, screen burn or image retention caused by
prolonged display of static images and/or phosphor
aging, or any other external cause or event, act or
omission outside the control of TCL, including fire,
theft, acts of God, alteration, power failures, power
surges or power shortages, lightning, other electrical
faults, or repairs, modifications or replacements by
persons other than those authorized by TCL to service
the Television;
b. Replacement of missing, discarded or lost parts, the
provision of retrofits, or preventive maintenance;
c. Repair of damage that is cosmetic only or does not
affect the Television functionality, such as wear and
tear, scratches and dents;
d. Service on Toshiba-branded accessory items (such
accessory items may be covered by their own
warranty);
e. Service on third party products or service made
necessary by use of incompatible third party products;
f. Service made necessary by the simultaneous use of
this Television and connected equipment;
g. Modifications to the Television not approved in writing
by TCL, and service made necessary by the use or
installation of non-Toshiba modifications to the
Television;
h. Service of a Television on which the TOSHIBA label or
logo, rating label or serial number have been defaced
or removed;
i. Damage to the Television caused by failure to follow
the specifications, User manuals or guides as to usage
and/or storage.
Disclaimer and Limitation of Remedy
TO THE EXTENT NOT PRECLUDED BY LAW, ALL OTHER
EXPRESS AND IMPLIED WARRANTIES, CONDITIONS AND
REPRESENTATIONS FOR THIS TELEVISION, INCLUDING
THE IMPLIED WARRANTIES, CONDITIONS AND
REPRESENTATIONS OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED
AND EXCLUDED. IF THE APPLICABLE LAW, STATUTORY
OR OTHERWISE, PRECLUDES THE EXCLUSION OF ANY
IMPLIED WARRANTIES, CONDITIONS AND
REPRESENTATIONS THEN SUCH IMPLIED WARRANTIES,
CONDITIONS AND REPRESENTATIONS ARE OTHERWISE
LIMITED IN DURATION TO THE TERM OF THIS EXPRESS
WRITTEN LIMITED WARRANTY. TO THE EXTENT NOT
PRECLUDED BY LAW, STATUTORY OR OTHERWISE, THIS
WRITTEN WARRANTY SUPERCEDES AND SPECIFICALLY
DISCLAIMS ANY OTHER WARRANTY, CONDITION OR
REPRESENTATION NOT STATED IN THIS WARRANTY,
WHETHER MADE BY TCL, TOSHIBA CORPORATION,
THEIR AFFILIATES, ADRs AND ASPs AND WHETHER MADE
ORALLY OR IN WRITING (INCLUDING ANY STATEMENT IN
ANY BROCHURE, PRESS RELEASE, ANNOUNCEMENT,
ADVERTISEMENT, POINT OF SALE DISPLAY, ETC.).
YOU MUST READ AND FOLLOW ALL SET-UP AND USAGE
INSTRUCTIONS IN THE APPLICABLE USER GUIDES AND/
OR MANUALS. IF YOU FAIL TO DO SO, THIS TELEVISION
MAY NOT FUNCTION PROPERLY AND YOU MAY SUFFER
DAMAGE. THIS WARRANTY WILL NOT COVER ANY
SERVICE THAT IS REQUIRED, IN PART OR IN WHOLE, AS A
RESULT OF ANY FAILURE TO FOLLOW THE SET-UP AND
USAGE INSTRUCTIONS. THIS WARRANTY DOES NOT
APPLY AND SHALL BE VOID AND UNENFORCEABLE IF THE
TELEVISION IS OPENED, SERVICED, OR REPAIRED BY
PERSONS OTHER THAN THOSE AUTHORIZED BY TCL TO
SERVICE OR REPAIR THE TELEVISION.
IF THE TELEVISION FAILS TO WORK AS WARRANTED
ABOVE, YOUR SOLE AND EXCLUSIVE REMEDY SHALL BE
REPAIR OR REPLACEMENT OF THE DEFECTIVE PART. IN
NO EVENT WILL TCL, TOSHIBA CORPORATION, THEIR
AFFILIATES, ADRs OR ASPs (THE “
RELATED PARTIES
”) BE
LIABLE TO YOU OR ANY THIRD PARTY FOR ANY
DAMAGES, MONEY, REIMBURSEMENT, COSTS OR
EXPENSES. THIS LIMITATION APPLIES TO DAMAGES,
MONEY, REIMBURSEMENT, COSTS OR EXPENSES OF ANY
KIND WHATSOEVER INCLUDING ANY DIRECT OR
INDIRECT DAMAGES, DAMAGE TO PROPERTY OR
PERSON, LOST PROFITS, LOST SAVINGS,
INCONVENIENCE OR OTHER SPECIAL, INCIDENTAL,
EXEMPLARY OR CONSEQUENTIAL DAMAGES, WHETHER
FOR BREACH OF WARRANTY, BREACH OF CONTRACT,
TORT (INCLUDING NEGLIGENCE), UNDER A STATUTE OR
UNDER ANY OTHER LAW OR FORM OR ACTION, OR
WHETHER ARISING OUT OF THE USE OF OR INABILITY TO
USE THE TELEVISION, EVEN IF ANY OF THE RELATED
PARTIES HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES OR OF ANY CLAIM BY ANY OTHER
PARTY.
No person, agent, distributor, dealer or company is
authorized to change, modify or extend the terms of these
warranties in any manner whatsoever.
Arbitration and Dispute Resolution
To the extent not precluded by law, any claim, dispute,
controversy or disagreement (whether for breach of warranty,
breach of contract, tort (including negligence), under a
statute or under any other law or form of action) against any
of the Related Parties arising out of, or otherwise relating to:
(i) this warranty; (ii) the Television; (iii) any oral or written
representations, statements, brochures, press releases,
advertising, announcement, point of sale display, or
91
Chapter 10: Appendix
promotional material relating to the Television; (iv) the
relationships that result from this warranty, (the foregoing
claims, disputes controversies and disagreements are
collectively referred to as the “Dispute”), shall be referred to
and resolved by final and binding arbitration (to the exclusion
of the courts). To the extent not precluded by law, you agree
to waive any right that you may have to commence or
participate in any representative or class proceeding against
the Related Parties relating to any Dispute. If and where
applicable and to the extent not precluded by law, you further
agree to opt out of any such representative or class
proceedings. Arbitration of any Dispute will be conducted in
the forum and in the manner as agreed to between you and
TCL. Failing such agreement, the arbitration will be
conducted by one arbitrator pursuant to the laws and rules
relating to arbitration generally in force in the jurisdiction in
which you reside at the time that the Dispute arises. To the
extent not precluded by law, no claim, dispute, controversy or
disagreement of any other person may be joined or combined
with any Dispute by you, without the prior written consent of
TCL.
Critical Applications
The Television you have purchased is not designed for any
“critical applications.” “Critical applications” means life
support systems, medical applications, connections to
implanted medical devices, commercial transportation,
nuclear facilities or systems or any other applications where
Television failure could lead to injury to persons or loss of life
or catastrophic property damage.
IF THE CUSTOMER USES THE TELEVISION IN ANY
CRITICAL APPLICATION, THE CUSTOMER AND NOT TCL,
ITS AFFILIATES, ADRs OR ASPs – ASSUME SOLE AND FULL
RESPONSIBILITY FOR SUCH USE. TCL RESERVES THE
RIGHT TO REFUSE TO SERVICE ANY TELEVISION USED IN
A CRITICAL APPLICATION. TCL, ITS AFFILIATES, ADRs
AND ASPs HEREBY DISCLAIM ANY AND ALL LIABILITY,
DAMAGES AND CONSEQUENCES ARISING OUT OF THE
SERVICE OR REFUSAL TO SERVICE SUCH TELEVISION
AND FURTHER DISCLAIM ANY AND ALL LIABILITY,
CONSEQUENCES AND DAMAGES THAT MAY ARISE OR
RESULT FROM THE USE OF THE TELEVISION IN ANY
CRITICAL APPLICATIONS.
General Provisions
If and to the extent that any provision of this limited warranty
should generally be found to be unenforceable, the
unenforceable provision shall be severed from the warranty
and deemed not to form part of the warranty. The remaining
provisions of this warranty shall be and remain valid and
enforceable. If and to the extent that any provision of this
limited warranty as it relates to any of the Related Parties is
found to be invalid or unenforceable in respect of that party
(the “
Excluded Party
”), the Excluded Party shall be deemed
to be severed or excluded from the provision, and the
provision shall remain valid, enforceable and applicable in
respect of the other or remaining Related Parties.
To the extent permitted by law, this limited warranty shall be
governed and construed in accordance with the laws of
Ontario.
If there is any inconsistency between this limited warranty, on
the one hand, and any statement in the packaging of the
Television or in any other document enclosed with, or used in
the context of the promotion or sale of, the Television, on the
other hand, the provisions of this limited warranty shall
prevail.
How to Obtain Warranty Services
If, after following all of the operating instructions in this
manual, checked the “Troubleshooting” section, and have
visited
www.toshiba.ca/support
for additional
information, you find that service is needed, please contact
TCL Customer Support toll free at 1 800 268-3404.
For at least three (3) years from the date of distribution of
the this product, Toshiba will give to anyone who contacts
Toshiba Consumer Solutions at (800) 631-3811, for a
charge of no more than our cost of physically performing
source code distribution, a complete machine-readable
copy of the complete corresponding GPL and LGPL
source code for the version of the GPL and LGPL code
that we distributed to you in this product.
WMDRM End User Notice
Content owners use Windows Media digital rights
management technology (WMDRM) to protect their
intellectual property, including copyrights. This device
uses WMDRM software to access WMDRM-protected
content. If the WMDRM software fails to protect the
content, content owners may ask Microsoft to revoke the
software’s ability to use WMDRM to play or copy protected
content. Revocation does not affect unprotected content.
When you download licenses for protected content, you
agree that Microsoft may include a revocation list with the
licenses. Content owners may require you to upgrade
WMDRM to access their content. If you decline an
upgrade, you will not be able to access content that
requires the upgrade.
92
Index
A
Auto Aspect.................................... 47
Auto Input ....................................... 31
Auto Tuning .................................... 28
AutoView®....................................... 48
B
Backlight......................................... 48
Backlight Adjustment Pro............... 50
Base Color Adjustment................... 51
C
Channel Browser™.......................... 32
Channel lock................................... 38
Channel Return............................... 34
Channel Tuning Mode .................... 32
ClearFrame™................................... 50
Closed Captions ............................. 35
Color Temperature.......................... 51
ColorMaster™ ................................ 51
D
Daylight Saving Time...................... 28
DIGITAL AUDIO OUT................18, 53
Digital CC Settings ......................... 35
DNR ................................................ 50
DVI connection ............................... 16
DynaLight™..................................... 49
Dynamic Bass Boost ...................... 54
Dynamic Contrast........................... 49
Dynamic Range Control ................. 53
Dynamic Volume (Audyssey
Dynamic Volume®) .................... 53
E
Edge Enhancer ............................... 49
F
Favorites Browser........................... 33
Film Stabilization ............................ 49
FREEZE .......................................... 47
G
GameTimer®................................... 39
H
HDMI connection............................ 16
HDMI settings feature..................... 41
HDMI® CEC Control ....................... 39
I
Initial Setup..................................... 24
Input Lock....................................... 38
INSTAPORT™................................. 41
L
Labeling .......................................... 30
Language........................................ 28
LED Indication................................. 72
Location .......................................... 28
M
Manual Tuning ................................ 29
Media Player ................................... 64
Movie....................................... 65
Music....................................... 66
Photo....................................... 67
MPEG NR........................................50
MTS................................................. 52
MUTE .............................................. 52
N
NET TV™.......................................... 60
Network Setup ................................ 56
O
On Timer ......................................... 42
P
Panel Lock ...................................... 39
PC audio ......................................... 42
PC connection ................................ 20
PC settings......................................42
Picture mode................................... 48
Picture Position............................... 47
Picture quality ................................. 48
Picture size......................................45
PIN code .........................................36
R
Remote control
Battery installation.................... 22
Buttons.................................... 23
Device codes table ................... 82
Functional key chart ................. 77
Programming ........................... 79
Reset TV.......................................... 44
RGB Filter........................................51
RGB Range ..................................... 41
S
SAP ................................................. 52
Shared inputs.................................. 30
Sleep Timer ..................................... 43
Software keyboard.......................... 59
Static Gamma .................................49
Stereo sound...................................52
Support information ........................ 44
SurfLock™....................................... 34
T
Test Pattern..................................... 51
TheaterLock™.................................. 52
TheaterWide® picture size .............. 45
Time Zone ....................................... 28
TV status information ...................... 44
V
V-Chip blocking...............................36
Voice Enhancement.........................54
W
Wallpaper ........................................69
White Balance .................................51
Wireless Information........................57
Corporate Headquarters: 9740 IRVINE BLVD. IRVINE, CA 92618
VISUAL PRODUCTS SERVICE AND SUPPORT: 1420-B TOSHIBA DRIVE, LEBANON, TN 37087, U.S.A.
MANUFACTURED BY
HEAD OFFICE: 191 McNABB STREET, MARKHAM, ONTARIO, L3R 8H2, CANADA
AutoView, ColorStream, GameTimer and TheaterWide are registered trademarks of Toshiba America Information Systems,
Inc.
Channel Browser, ClearFrame, DynaLight, ColorMaster, NET TV, SurfLock and TheaterLock are trademarks of Toshiba
America Information Systems, Inc.

Navigation menu
