Toshiba 42Xv550A 560A Users Manual

2014-12-13

: Toshiba Toshiba-42Xv550A-560A-Users-Manual-129404 toshiba-42xv550a-560a-users-manual-129404 toshiba pdf

Open the PDF directly: View PDF .
Page Count: 54

Integrated Digital LCD TV

OWNER'S MANUAL

Owner's Record

You will find the model number and serial number on

the back of the TV. Record these numbers in the spaces

provided below. Refer to them whenever you call upon

your TOSHIBA dealer regarding this product.

Model number:

Serial number:

42XV550A_560A

46XV550A_560A

VX1A00121000

2008

Trademark of the DVB

Digital Video Broadcasting Project

Toshiba 42/46XV550A

Asia_4246XV550A.book Page 1 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Contents

Introduction

Welcome to Toshiba . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Important Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Important information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Getting started

Connecting an aerial. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Exploring your new TV. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

TV front and side panel controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

TV back panel connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Learning about the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Turning the TV on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Tuning the TV for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Learning about the menu system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Programming channels into the TV’s channel memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Watching TV programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Using the TV’s features (General)

Picture adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Sound adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Other feature settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

The timers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Confirming Software Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Resetting the TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Using REGZA-LINK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Teletext in Analogue TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Teletext in Digital TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Subtitles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Other Digital TV features and settings

Using the EPG (Electronic Programme Guide) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Favourite Channel Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Digital settings - Channel Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Digital settings - Parental Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Local Time Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Digital Output Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

Connecting your TV

Back connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32

Side connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Connecting an HDMI or a DVI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

Selecting the PC/HDMI1 audio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Setting the HDMI1 audio mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Using the PC Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

REGZA-LINK connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Reference section

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Broadcast system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Asia_4246XV550A.book Page 2 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Introduction

Welcome to Toshiba

•Thank you for purchasing this Toshiba LCD Colour

Television. This manual will help you use the exciting

features of your new TV.

•Instructions in this manual are based on using the remote

control.

• Please read all safety and operating instructions in this

manual carefully, and keep this manual for future reference.

Important Safety Instructions

Be sure to observe the following instructions and precautions

to ensure safe use of this TV.

Installation

1) Always connect the power plug to an appropriate

electrical outlet equipped with 220-240V, AC 50Hz.

Never use the TV outside the specified voltage range. It

may cause a fire or an electric shock.

2) Never insert or remove the power plug with wet

hands.

This may cause an electric shock.

3) Never place the TV in an unstabilized location such

as on a shaky table, incline or location subject to

vibration.

The TV may drop or fall off which may cause injury or

damage.

4) Never block or cover the slots and openings in the

cabinet.

• Never place the TV so that it is facing upward or on

its side.

• Never place the TV in a closet, bookcase or other

similar area where the ventilation is poor.

• Never drape a newspaper, tablecloth or curtain on the

TV.

• When installing the TV against a wall, always keep

the TV at least 10 cm away from the wall.

• Never place the TV on a soft unstable surface, such

as a carpet, or a cushion.

The inside of this TV will overheat if the ventilation holes

are covered, blocked or sealed, which may result in a

fire.

5) Never place the TV near a heater or in direct

sunlight.

The surface of the cabinet or power cord may melt and

result in a fire or an electric shock.

6) Never place the TV in an area exposed to high

humidity levels, such as in a bathroom or close to a

humidifier.

This may cause a fire or an electric shock.

7) Never place the TV next to a stove where it will be

exposed to oil, smoke, or steam, or in a location

where there is a large quantity of dust.

This may cause a fire or an electric shock.

220-240V AC, 50Hz

Check!

Asia_4246XV550A.book Page 3 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Introduction

8) Install the TV in a horizontal, stable location.

Connect between two clips on the back of the TV

and a wall, pillar, etc., with a sturdy tie and clip of

supplied accessories (- page 42).

• Use as short a tie as possible to ensure the TV is

stable.

• If the TV is not installed securely, it may lean or fall

over and cause an injury.

• To prevent injury, use the exclusive optional stand or

wall-hanging bracket to install this TV on the floor or

wall securely in accordance with a qualified

technician.

9) Precautions for moving the TV

• When moving the TV, be sure to remove the plug

from the wall outlet and disconnect the aerial cable

and audio/video cables, any steady ties. Fire or

electric shock may result if the power cord is

damaged.

• When carrying the TV, at least two people are

needed. Be sure to carry it upright.

• Never carry the TV with the screen facing up or down.

10) Precautions for installing on outdoor aerial

An outside aerial system should not be located in the

vicinity of overhead power lines, or other electric light or

power circuits.

If the aerial falls down or drops, it may cause injury or

electric shock.

Use

1) Never place hot objects or open flame sources,

such as lighted candles or nightlights, on or close

to the TV.

High temperatures can melt plastic and lead to fires.

2) The apparatus shall not be exposed to dripping or

splashing and that no objects filled with liquids,

such as vases, shall be placed on the apparatus.

When liquids are spilled or small items are dropped

inside the TV, this may cause a fire or an electric shock.

If small objects drop inside the TV, turn off the TV and

remove the power plug from the outlet immediately and

contact a service technician.

3) Never insert objects (metal or paper) or pour water

inside the TV through ventilation holes and other

openings.

These items may cause a fire or an electric shock.

If these objects are inserted inside the TV, turn off the

TV and remove the power plug from the outlet

immediately and contact a service technician. Be

especially careful that children do not insert objects in

the TV.

4) Never stand or climb on the TV.

Be especially careful in households with children to

prevent them through climbing on top of the TV.

It may move, fall over, break, become damaged or

cause an injury.

Top view

Sturdy tie

(as short as possible)

Clip

Side view

Clip

Asia_4246XV550A.book Page 4 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Introduction

5) When the TV will not be used for a long period of

time, such as during vacation or travel, remove the

power plug from the wall outlet for safety.

• The TV is not completely disconnected from the

power supply line, as minute current is consumed

even when the ! Power switch is turned off.

• The Mains plug or an appliance coupler is used as the

disconnect device, therefore the disconnect device

shall remain readily operable.

6) Never pull on the power cord when removing the

plug from the wall outlet.

Always hold the plug firmly when removing it. If the

power cord is yanked, the cord may become damaged

and a fire or an electric shock may occur.

7) Never cut, break, modify, twist, bunch up or bent the

cord or apply excessive force or tension to it.

Never place heavy objects on the cord or allow it to

overheat as this may cause damage, a fire or an electric

shock. Contact a service technician if the power cord is

damaged.

8) If there is thunder or lightning, never touch the

aerial cable or other connected cables.

You may suffer an electric shock.

Service

1) Never repair, modify or disassemble the TV by

yourself.

It may cause a fire or an electric shock. Consult a

service technician for inspection and repairs.

2) When a malfunction occurs, or if smoke or an

unusual odor comes from the TV, turn off the TV

and remove the power plug from the outlet

immediately.

Make sure that the smoke or smell has stopped, then

contact a service technician. If the TV is still used in this

condition, it may cause a fire or an electric shock.

3) If the TV is dropped or the cabinet is broken, turn off

the TV and remove the power plug from the outlet

immediately.

If the TV has power in this condition, it may cause a fire

or an electric shock. If the cabinet is broken, be careful

when handling the TV to prevent an injury. Contact a

service technician for inspection and repair.

4) When the TV reaches the end of its useful life, ask a

qualified service technician to properly dispose of

the TV.

Note:

The lamp unit contains a small amount of mercury.

Disposal of mercury may be regulated due to

environmental considerations.

Dispose of the used lamp unit by the approved method

for your area. For disposal or recycling information,

please contact your local authorities.

Asia_4246XV550A.book Page 5 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Introduction

Cleaning

1) Remove the power plug before cleaning.

Never use solvents such as benzine or thinner to clean

the TV.

• These solvents may distort the cabinet or damage its

finish.

• If rubber or vinyl products remain in contact with the

TV for a long time, a stain may result.

If the cabinet becomes dirty, clean it with a soft, dry

cloth.

When cleaning the surface of the LCD display, wipe the

panel surface gently with a soft, dry cloth.

2) Periodically disconnect the power plug from the

outlet and check it.

If dust has collected on the power plug connectors,

clean off the dust with dry cloth.

This dust may cause a fire due to reduced insulation on

the plug.

Important information

1) LCD screen

• If you have the LCD screen facing to the sun, the LCD

screen will be damaged. Be aware of locating the TV

close to a window or outdoors.

• Never press the LCD screen strongly or scratch it,

and never put anything on it. These actions will

damage the LCD screen.

2) Cabinet and LCD screen

Never spray volatile compounds such as insecticide on

the cabinet and LCD screen.

This may cause a discoloration or damage the cabinet

and LCD screen.

3) Some pixels of the screen do not light up

The LCD display panel is manufactured using an

extremely high level of precision technology; however,

sometimes some pixels of the screen may be missing

picture elements or have luminous spots. This is not a

sign of malfunction.

4) Interference

The LCD display may cause interference in image,

sound, etc. of other electronic equipment that receives

electromagnetic waves (e.g. AM radios and video

equipment).

5) Using in low temperature areas

If you use the TV in the room of 0°C or less, the picture

brightness may vary until the LCD monitor warms up.

This is not a sign of malfunction.

6) Afterimages

If a still picture is displayed, an afterimage may remain

on the screen; however, it will disappear.

This is not a sign of malfunction.

Exemptions

• Toshiba is not liable for any damage caused by fires, natural

disaster (such as thunder, earthquake, etc.), acts by third

parties, accidents, owner's misuse, or uses in other improper

conditions.

• Toshiba is not liable for incidental damages (such as profit

loss or interruption in business, modification or erasure of

record data, etc.) caused by use or inability to use product.

• Toshiba is not liable for any damage caused by neglect of

the instructions described in the owner's manual.

• Toshiba is not liable for any damage caused by misuse or

malfunction through simultaneous use of this product and

the connected equipment.

Clean here

Asia_4246XV550A.book Page 6 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Connecting an aerial

Optimum reception of colour requires a good signal and will

generally mean that an outdoor aerial must be used.

The exact type and positioning of the aerial will depend upon

your particular area.

Your Toshiba dealer or service personnel can best advise you

on which aerial to use in your area.

Before connecting the aerial cable, turn off all main power

switches.

Exploring your new TV

Installing the remote control batteries

Remove the battery cover.

Insert two R03 (AAA) batteries matching the –/+ polarities of

the battery to the –/+ marks inside the battery compartment.

Cautions:

•Dispose of batteries in a designated disposal area. Batteries

must not be exposed to excessive heat such as sunshine,

fire or the like.

•Attention should be drawn to the environmental aspects of

battery disposal.

•Never mix battery types or combine used batteries with new

ones.

Notes:

•If the remote control does not operate correctly, or if the

operating range becomes reduced, replace both batteries

with new ones.

•If the batteries are dead or if you will not use the remote

control for a long time, remove the batteries to prevent

battery acid from leaking into the battery compartment.

Effective range

OUT

VHF UHF

300 7 twin-lead feeder

75 7

aerial

terminal

Aerial adaptor

Aerial cable (75 7 coaxial)

(not supplied)

Outdoor aerial

Mixer

(not supplied)

(not supplied) 75 7 aerial

terminal

75 7 coaxial cable

Plug

Decoder

Media Recorder

TV back view

within 5 m

Asia_4246XV550A.book Page 7 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

TV front and side panel controls

•You can operate your TV using the buttons on the side panel or the remote control. The back and side of the panel provide the

terminal connections to connect other equipment to your TV (- “Connecting your TV” pages 32 - 38).

•For the use of each control, see the pages in brackets.

TV top view TV front view Right side view

You can swivel the TV screen.

(Only 46XV550A model)

Swivel angle: 15 degrees to left and right.

Headphones

(Not supplied)

1(Remote sensor) — Point the remote control toward

this remote sensor (- page 7).

2 (DTV timer LED) — Digital TV timer Indicator

(- page 23).

3! (Power LED) — Power indicator (- page 12).

4! (Power on/Standby) — Press to turn the TV on/

standby (- page 12).

5pBb (Programme position) — When no menu is on-

screen, these buttons select the programme position.

(- page 16).

Uu (MENU up/down) — When a TV menu is on-

screen, these buttons function as up/down menu

navigation buttons (- page 12).

62 – + (Volume) — When no menu is on-screen, these

buttons adjust the volume level (- page 10).

I i (MENU left/right) — When a TV menu is on-screen,

these buttons are used for left/right menu navigation and

to adjust settings (- page 12).

7MENU — Press to access the TV SETUP menu

(- page 12).

8o (Input source selection) — When no menu is on-

screen, this button selects the input source (- page 24).

OK — When a TV menu is on-screen, this button

functions as the next menu navigation button (- page

12, 24).

9o HDMI4 (input terminal) — High-Definition

Multimedia Interface input receives digital audio and

uncompressed digital video from an HDMI device (-

page 34).

10 o (2) (Video 2 input terminals) — Optional S-video

or standard video and standard audio inputs (- page 33).

11 D (Headphone jack) — For use with headphones.

Note:

When the Headphone jack is being used, the sound from

all speakers will be muted, and normal sound will be

output to the headphones only.

Asia_4246XV550A.book Page 8 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

TV back panel connections

TV back view

Cable holder*

Power cord

* You can use the cable holder to

hold aerial cable, video and audio

cables etc.

When moving the TV, never

hold this holder.

12 o HDMI2 and o HDMI3 (input terminals) — High-

Definition Multimedia Interface input receives digital

audio and uncompressed digital video from an HDMI

device (- page 35).

13 O DIGITAL AUDIO (OPTICAL) (output terminal)

— For use when connecting an amplifier with optical type

digital audio input (- page 32).

14 o HDMI1 (input terminal) — High-Definition

Multimedia Interface input receives digital audio and

uncompressed digital video from an HDMI device or

uncompressed digital video from a DVI device

(- page 34).

15 o (4) (Video 4 input terminals) — High-definition

component video and standard (analogue) stereo audio

inputs (- page 33).

16 o (3) (Video 3 input terminals) — High-definition

component video and standard (analogue) stereo audio

inputs (- page 32).

17 o (1) (Video 1 input terminals) — Standard

(composite) video and standard (analogue) stereo audio

inputs (- page 32).

18 o PC/HDMI1 (AUDIO) (input terminal) — PC audio

input terminal is shared with HDMI-1 analogue audio

input terminal, and their use can be configured in the

SETUP menu. (- page 34, 36).

19 o RGB/PC (input terminal) — For use when

connecting a personal computer (PC) (- page 36).

20 O MONITOR (output terminals) — Standard video

and standard audio outputs (- page 33).

No On-Screen-Display will output from these terminals.

21 A (Aerial input terminal) — Aerial signal input

(- page 7).

Asia_4246XV550A.book Page 9 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Learning about the remote control

Location of controls

* For REGZA-LINK remote control functions, please refer to “Location of controls for REGZA-LINK mode” (- page 11).

To switch between Analogue and

Digital TV

To return to the previous programme

(- page 16)

To display digital on-screen

information (- page 29)

MENU (- page 12)

• Menu  (- page 12)

• OK (- page 12)

Position U u

(- page 16)

Volume – +

(These buttons adjust the volume level.)

Number buttons (0-9)

(- pages 16, 23)

Input source selection

(DTV, o1 – o4, HDMI1 – HDMI4, PC, ATV)

(- page 24)

Sound mute (This button turns

the sound off/on.)

EXIT (- page 13)

To display the Channel Lists

(- page 29)

Teletext on/Superimpose Teletext/off

(- page 27)

• / To display on-screen

information (- page 16)

• Initial/index function for Teletext

- analogue only - (- page 27)

Picture mode selection (- page 19)

Picture size selection (- page 17)

Digital subtitle on/off

(- page 28)

Stereo/bilingual selection

page 21

)

To display the Audio Track menu

- digital only-

To access sub-pages

when in teletext - analogue only -

(- page 27)

Picture still (- page 18)

When in TV mode:

Teletext function - analogue only -

To reveal concealed text

(- page 27)

To hold a wanted page

(- page 27)

To enlarge teletext display size

(- page 27)

To select a page while viewing

a normal picture (- page 27)

To select the time display

(- page 27)

Power on/Standby (- page 12)

Teletext control buttons

(Four coloured buttons : Red, Green,

Yellow, Blue) (- page 27)

To selectTV, REGZA-LINK

or DVD mode

When using Toshiba DVD,

press to EJECT

press to STOP

press to PLAY

press to PAUSE

press to SKIP REVERSE

press to REVERSE

press to FORWARD

press to SKIP FORWARD

Press DVD MENU to display the

menu of DVD disc.

Press RETURN to return to the

previous menu accessed.

Press TOP MENU to display the

title menu on DVD disc.

Press SET UP to access the

on-screen Setup menu for setting

adjustment.

Press AUDIO to toggle between

different audio modes.

Asia_4246XV550A.book Page 10 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Location of controls for REGZA-LINK mode

The REGZA-LINK mode switch on the TV remote control allows control of the connected REGZA-LINK device being watched.

(- page 25)

Note:

These functions are dependent on the connected device. Not all of the remote control buttons may be available. Please refer to

the owner’s manuals of the connected devices.

Set to REGZA-LINK

Number buttons for device

To display content menu

To change volume of the AV

amplifier

To operate menu

To display DVD menu

To display Top Menu

To work interactive

service control on device

Picture mode selection

Picture size selection

To turn the device On/Off

To select input from external source

Position U / u

To exit menu or return to previous

menu accessed

To Mute AV amplifier

To display Set Up Menu

To display information

To select audio mode

press to EJECT

press to STOP

press to PLAY

press to PAUSE

press to SKIP REWIND

press to REWIND

press to FAST FORWARD

press to SKIP FORWARD

Asia_4246XV550A.book Page 11 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Turning the TV on

Switching on the TV

Connect the power cord to a wall outlet. The ! power

indicator light should be red (standby mode).

1Press on the remote control or ! on the TV right

side panel. The ! power indicator light should be green.

Note:

If you watch black and white programmes when the colour

system mode is set to Auto, colour noise may appear on the

screen. In this case select the appropriate Colour system (For

the system of each country or region, refer to pages 14 and

41).

Switching off the TV

1Press on the remote control or ! on the TV right side

panel to switch to the standby mode.

Notes:

•The TV is not fully disconnected from the main supply, as

minute current is consumed even when ! is turned off.

When the TV will not be used for a long period of time, such

as during vacation or travel, remove the power plug from the

wall outlet.

•The TV will automatically turn itself off after approximately 15

minutes if it is tuned to a vacant channel or a station that

completes its broadcast for the day. This function does not

work for external inputs or if Blue Screen mode is set to 'Off'.

•If power is cut off while you are viewing the TV, the Last

Mode Memory function turns on the TV automatically when

power is applied again. If power is going to be off for a long

time and you are going to be away from your TV, unplug the

power cord to prevent the TV from turning on in your

absence.

Tuning the TV for the first time

Before switching on the TV, put your decoder and media

recorder to Standby, if they are connected, and ensure the

aerial is connected. To setup the TV, use the buttons on the

remote control as detailed on page 10.

1Press the button. The Quick Setup screen will

appear. This screen will appear the first time that the TV

is switched on and each time “Reset TV” (- page 24)

is executed.

2Press Y or Z to select the menu language English or

Français.

3Press V to select Time Zone, then press Y or Z to select

the item you want to set. (New South Wales, Northern

Territory, Queensland, South Australia, Tasmania,

Victoria, Western Australia or Australian Capital

Territory)

4Press Q to display the Auto Tuning startup screen. Use

Y or Z to select DTV and ATV, DTV or ATV. Then

press V to select Start Scan and press Q.

You must allow the TV to complete the search.

When the search is complete, the TV will automatically

select position one.

The Auto Tuning results screen will display the services

that are found.

5Press Y or Z to view the DTV (digital channel) or ATV

(analogue channel) lists.

6Use V or U to move through the list to select a channel

then press Q to view.

Notes:

•The time will be set automatically by transmission but can be

advanced or decreased by up to 3 hours using Local Time

Setting.

•The Quick Setup menu can also be displayed at any time

from the SETUP menu.

Learning about the menu system

We suggest you familiarize yourself with the display charts

before using the menu system:

• Press M to display menu, then press Y or Z to select main

menu headings.

• Press V or U to select an item.

• Press Y or Z to select or adjust setting.

• Press Q to display the next menu.

Quick Setup

Time Zone New South Wales

Menu Language English

Auto Tuning

Progress Found

ATV Tune Waiting...

Channel: 10

DTV Tune 3% 2

Pos. Name Ch.Type

DTV

DTV Services Found :77 ATV Services Found: 12

ATV

Auto Tuning

Pos. Name Ch.

DTV

DTV Services Found :77 ATV Services Found: 12

ATV

Auto Tuning

Asia_4246XV550A.book Page 12 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Displaying the menu chart

Note:

The same menu is displayed in DTV (Digital TV) and ATV

(Analogue TV) modes; however some items are greyed out in

each case.

Notes for menu system:

•In the video input mode (o1 - o4), Auto Tuning, ATV

Manual Tuning, DTV Manual Tuning and DTV Settings

are not available. Instead, Manual Settings appears in the

SETUP menu (- page 24).

•If you connect external equipment via component video

source, Colour system selection in the Manual Settings

menu is not available.

•If you do not make a selection for a while, the menu display

disappears automatically.

•If you want to close the menu display instantly, press P.

•To return to the previous menu, press M.

•In the PC input mode, PC Settings appears in the SETUP

menu (- page 37).

•In the 480i, 576i or 1080i input signal mode, you can select

the Cinema Mode in the Picture Settings menu (- page

19).

•When the 3D colour management function is set to on (-

page 20), you can select Base Colour Adjustment in the

PICTURE menu.


SOUND

SETUP

TIMERS

FUNCTION

REGZA-LINK


Picture Settings

Active Backlight Control

Auto Contrast

x.v.Colour Selection

3D Colour Management

MPEG NR

Base Colour Adjustment

Off

Auto

Off

Low

AutoDNR


Picture Settings

Active Backlight Control

Auto Contrast

x.v.Colour Selection

3D Colour Management

MPEG NR

Base Colour Adjustment

Off

Auto

Off

Low

AutoDNR

SOUND

MTS

Bass

Dual

Treble

Balance

Stable Sound

Dynamic Range Control

WOW

Off

Auto

Dual 1

SOUND

Bass

Balance

Treble

WOW

Stable Sound

Bass Boost

Bass Boost Level

Dynamic Range Control

Off

SETUP

Menu LanguageEnglish

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

AV Connection

DTV Settings

Quick Setup

Picture Position

SETUP

ATV Manual Tuning English

DTV Manual Tuning

DTV Settings

AV Connection

Quick Setup

Picture Position

Reset TV

System Information

REGZA-LINK

Enable REGZA-LINK On

TV Auto Power On

Auto Standby

Amplifier Control

Speaker Preference

TV Speakers

REGZA-LINK

Enable REGZA-LINK On

TV Auto Power On

Auto Standby

Amplifier Control

Speaker Preference

TV Speakers

TIMERS

Sleep Timer 00:00

Programme Timers

TIMERS

Sleep Timer 00:00

Programme Timers

FUNCTION

Teletext

Auto Format

Panel Lock

4:3 Stretch

Blue Screen

Side Panel

Auto

Off

FUNCTION

Teletext

Auto Format

Panel Lock

4:3 Stretch

Blue Screen

Side Panel

Auto

Off

SOUND

MTS

Bass

Dual

Treble

Balance

Stable Sound

Dynamic Range Control

WOW

Off

Auto

Dual 1

SETUP

Menu LanguageEnglish

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

AV Connection

DTV Settings

Quick Setup

Picture Position

Asia_4246XV550A.book Page 13 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Programming channels into the

TV’s channel memory

Auto Tuning

Auto Tuning will completely re-tune the TV and can be used

to up-date the channel list.

It is recommended that Auto Tuning is run periodically to

ensure that all new services are added. All current channels and

settings, i.e. favourites and locked channels, will be lost.

Note:

As new services are broadcast, it will be necessary to retune

the TV in order to view them.

1Press M, and then press Y or Z to display the SETUP

menu.

2Press V to select Auto Tuning, and then press Q.

3A screen will appear warning that previous settings will

be deleted.

Use Y or Z to select DTV and ATV, DTV or ATV.

Then, press V to select Start Scan and press Q to

continue with the Auto Tuning.

The TV will start to search for all available DTV and/or

ATV services.

You must allow the TV to complete the search.

When the search is complete, the Auto Tuning screen

will display the services found.

4Use V or U to move through the list to select a channel,

and then press Q to view.

ATV Manual Tuning - analogue only -

Use the Manual tuning operation if desired channels cannot be

preset by Auto Tuning or if you would like to preset channels

to specific position numbers one by one.

1From the SETUP menu, press V or U to select ATV

Manual Tuning.

2Press Q to display the ATV Manual Tuning menu.

Press V or U to select the position you want to arrange.

3Press Q to display the settings menu.

Press Y or Z to select an item, then press V or U to set

the item as shown below.

A. Position selection

B. Sound system (- page 41)

C. Colour system (- page 41)

A : Automatic (factory set), P : PAL, S : SECAM

N4 : NTSC 4.43 (MHz), N3 : NTSC 3.58 (MHz)

If the colour of a certain channel is abnormal, the

automatic colour system selection (A) may have

malfunctioned, or sound system selection is wrong. In

such a case, select another colour and/or sound system

(- page 41).

D. Position skip selection

Press V or U to turn the position skip option on “8”

or off “(”.

The position will then be skipped when you select

channels with PU or Pu.

The “8” mark will appear beside the position

number when you use the Number button on the

remote control.

E. Channel search operation

Press U to search up the band or V to search down the

band.

Press V or U repeatedly until your desired channel is

displayed.

When a station/satellite is found, it will be displayed.

NEVER PRESS ANY OTHER BUTTONS WHILE

THE SET IS TUNING.

F. Auto Fine Tuning

Press V or U to turn the Auto Fine Tuning option on

“” or off “0”.

The Auto Fine Tuning function automatically corrects

slight fluctuations when receiving signals.

Manual Fine Tuning

With the Auto Fine Tuning set to “0”, press V or U

until the better picture and sound are obtained.

G. Label

Station labels appear beside the position display each

time you turn on the TV, select a channel, or press k.

To change or create station labels:

1) Press V or U repeatedly to select a character for

the first space, then press Z.

SETUP

Menu Language English

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

Picture Position

AV Connection

Quick Setup

Auto Tuning

Previous settings will be lost! Press EXIT for

no change.

DTV and ATVTuning Mode

Start Scan

Pos. Station

ATV Manual Tuning

Position: 1

ATV Manual Tuning

1B/G A

ACE

BD F

*(blank space)

Asia_4246XV550A.book Page 14 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

2) Repeat step 1) to enter the rest of the characters. If

you would like a blank space in the label name, you

must choose a blank space from the list of

characters.

Press Q to store your settings.

Sorting positions - analogue -

ATV channels may be moved and stored to the position of your

choice.

1From the SETUP menu, press V or U to select ATV

Manual Tuning.

2With the list of channels now showing, press V or U to

select the channel you want to move and press Z.

3Use V or U to move through the list to your preferred

position. As you do so, the other channels will move to

make room.

4Press Y to store your move.

Repeat as necessary, then press P.

DTV Manual Tuning - digital only -

This feature is available for service engineers or can be used

for direct channel entry if the multiplex channel is known.

1Press M, then press Y or Z to display the SETUP menu.

2Press V or U to select DTV Manual Tuning, then press

3Enter the multiplex number using the number buttons or

use Y or Z to adjust the number up or down and then

press Q. The TV will start to search for that multiplex.

When the multiplex is found, any channels that are not

currently in the channel list will be added and the channel

information will be updated.

4Repeat as necessary. Press P to finish.

Channels

The DTV channel order may be changed to suit your personal

preference.

1From the SETUP menu, press V or U to select DTV

Settings and press Q.

2Press V or U to select Channels, then press Q.

3With the list of channels showing, press V or U to select

the channel you want to move, then press Q.

4Use V or U to move through the list to your preferred

position. As you do so, the other channels will move to

make room.

5Press Q to store your move. Repeat as necessary,

then press P.

The Skip setting for the highlighted channel can be

switched between “Set/Not Set” by pressing the RED

button on the remote control. This feature allows you to

set channels that will be skipped when Pu or PU are used

to tune. However, these channels will still be available by

direct number entry (when tuned a 8 icon will be

displayed in the banner to indicate as a skipped channel).

Pos. Station

ATV Manual Tuning

ABCD

EFGH

IJKL

MNOP

SETUP

Menu Language English

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

Picture Position

AV Connection

Quick Setup

Pos.New Name

16 New channels - Total 26

WEAK STRONG

Signal Strength

Quality

Type

DTV Manual Tuning

832

831

833

834

UHF

835

GOOD

DTV Settings

Channels

TV/Radio Mode

Channel Options

PIN Setting

Parental Control

Local Time Setting

All Channels

Pos. Name Type

Channels

Pos. Name Type

Channels

806

805

807

808

809

810

811

812

Asia_4246XV550A.book Page 15 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Getting started

Watching TV programmes

Viewing Digital programmes - digital only -

After you have tuned the TV, you have several ways to

navigate through all programmes:

•Press the Number buttons. You may omit the leading

zeroes, which will be appended automatically.

•Press PU / Pu to view the previous and next position. The

channels are arranged in ascending order according to the

channel number.

• Press to display the Channel Lists and press V or U

to select a channel, then press Q to view the channel. See

page 29 for more details.

Changing the position - analogue only -

1Enter the desired position number using the Number

buttons on the remote control.

For positions below 10, use 0 and the required number

e.g., for position 1.

2You can also change the position by using PU or Pu.

Note:

Position selection change between different format channels

takes several seconds.

Switching between positions

You can switch positions without entering an actual position

number each time.

1Select the first position you want to view.

2Select the second position with the Number buttons (0-

9).

3Press :. The previous position will be displayed.

Each time you press :, the TV will switch back and forth

between the two positions.

Selecting the menu language

Choose from 2 different languages (English or French) for the

On-Screen-Display.

1Press M, and then press Y or Z to display SETUP

menu.

2Press V or U to select Menu Language.

3Press Y or Z to select the desired language.

Displaying the on-screen information

- analogue only -

1Press k to display the following on-screen information.

The information will disappear in 6 seconds.

• Position or external input mode selected

• Position skip on/off information

• Label (if set)

• Mono/Stereo/Dual audio status

2To close the display instantly, press k again.

On-screen information - digital only -

When viewing in Digital TV, the on-screen information will

give the details of the programme currently being viewed.

1Press , to display the on-screen information.

On-screen information contains the following

information:

•Current Channel Number

• Channel Name

• Skip (if set) (8)

•Now and Next Programme Names

•Current date and time

• Received programme video format (SD/HD)

• Teletext availability ()

•Subtitle (closed-caption) availability (indicated by CC)

• Parental rating (PG, MA, G, R, etc.)

•Dolby® Digital audio track availability (indicated by

Dolby D)

•Programme Timer (if set) (4)

2Press V or U to select the “Now” or “Next” information

guide.

3To record the following programme, select “Next” and,

press Q. The SET TIMER screen will appear.

4The details of the programme will have been added to the

timer. Press Q to save.

To indicate that a timer has been set, a clock icon will be

displayed in the Next field of the information screen (4).

SETUP

Menu Language English

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

Picture Position

AV Connection

Quick Setup

ABCD4

Stereo

11:00 - 12:00

12:00 - 12:59

Now

Change EXIT Watch TV

Comprehensive coverage of local, national and international news

with analysis of the key stories of the day and a strong focus on

health, social and environmental issues.

News 31 min left

HD 16:9

SET TIMER 11:20 Tue, 6 Dec

Tue, 06 Dec 12:00 - 12:59

Start Time

End Time

Repeat

12:00

12:59

Once

Asia_4246XV550A.book Page 16 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Picture adjustment

Selecting the picture size

1Press O to display the picture size list, and then press V

or U to select the appropriate picture size (or press O

repeatedly to select required picture size directly).

2Press Q.

Wide

Use this setting when watching a wide-screen DVD, wide-

screen video tape or a 16:9 broadcast (when available). Due to

the range of wide-screen formats (16:9, 14:9, 20:9 etc.), you

may see bars on the top and bottom of the screen.

Super Live 2

When receiving “side panel format” signal, this setting will

enlarge the image to fit the screen by stretching the image

vertically and horizontally, holding the better proportions at

the centre of the image. Also the black bars on the both sides

of the screen will eliminate or reduce.

Cinema 2

When watching “all sides panel format” films/video tapes, this

setting will eliminate or reduce the black bars on all the sides of the

screen by zooming in and selecting the image without distortion.

4:3

Use this setting to view a true 4:3 broadcast.

Super Live 1

When receiving “4:3 format” signal, this setting will enlarge

the image to fit the screen by stretching the image vertically

and horizontally, holding the better proportions at the centre of

the image.

Cinema 1

When watching “letterbox format” films/video tapes, this

setting will eliminate or reduce the black bars at the top and

bottom of the screen by zooming in and selecting the image

without distortion.

Subtitle

When subtitles are included on a letterbox format broadcast,

this setting will raise the picture so that the most of the text is

displayed.

14:9

Use this setting when watching a 14:9 broadcast.

Exact Scan

When receiving 1080i or 1080p signal format, this setting will

display the image corrrectly without distortion or picture clipping.

Native

Use this setting for PC connected via HDMI. When receiving

video signal source via HDMI input, this setting will display

the image correctly without distortion or picture clipping.

Picture Size

Wide

Super Live 2

Cinema 2

Exact Scan

Native

4:3

Cinema 1

Super Live 1

Ex. HDMI 1080i input signal

Subtitle

Asia_4246XV550A.book Page 17 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

PC Normal

Use this setting for PC connected via HDMI or RGB/PC terminal

when receiving PC signal format. This setting will display the

image correctly without distortion or picture clipping.

PC Wide

Use this setting for PC connected via HDMI or RGB/PC

terminal when receiving PC signal format. This setting will

display the image without picture clipping.

Notes:

•Using the special functions to change the size of the

displayed image (e.g. changing the height/width ratio) for

the purpose of public display or commercial gain may

infringe on copyright laws.

•

If the aspect ratio of the selected format is different from the one

of the TV transmission or video programme, it can cause a

difference in display. Change to the correct aspect ratio picture

size to fix this.

•

For a PC connected via HDMI or RGB/PC terminal (

page 36),

the picture size selection is

PC Wide

PC Normal

only.

•When using a PC connected via HDMI or RGB/PC terminal,

moving image quality may deteriorate.

•In 720p input signal mode, the picture size options are

Native, Wide, Super Live 2, Cinema 2, 4:3, Super Live 1

and Cinema 1.

•In Digital TV, the picture size options are Super Live 1,

Cinema 1, Wide, Super Live 2, Cinema 2 and 4:3.

When receiving 1080i or 1080p signal, you can additionally

choose Exact Scan.

•When using a Exact Scan you may observe a shift in picture

position. This is due to the signal source and is not a defect

of the TV.

•When DTV teletext (- page 28) or Subtitle (- page 28) is

displayed, picture size selection is not available.

Using the picture still

•Press R to freeze the picture.

Even if an image is frozen on the TV screen, the pictures are

running on the input source. Audio continues to be output as well.

To return to a moving picture, press R again.

Notes:

•If you use this function except for the purpose of your private

viewing and listening, it may infringe upon copyrights

protected by copyright laws.

•

In PC input mode (

page 24), this function is not available.

Adjusting the picture position - analogue only -

Adjustment to the position of the picture may be made to suit

your viewing preferences.

1From the SETUP menu, press V or U to select Picture

Position.

2Press Q, then press V or U to select an item you want

to adjust.

3Press Y or Z to adjust the settings as required.

Notes:

•When the picture size is in Wide or 4:3 mode, only the

Horizontal Position can be adjusted.

•When the picture size is in Native, PC Wide, PC Normal

mode, this function will not be available.

•When the picture size is in Exact Scan mode, this function

will not be available.

Resetting the picture position - analogue only -

This function resets your picture position settings to the factory

settings.

1From the Picture Position menu, press V or U to

select Reset.

2Press Q.

(Moving) (Still)

SETUP

Menu Language English

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

Picture Position

AV Connection

Quick Setup

Picture Position

Horizontal Position

Reset

Vertical Position

Horizontal Position

Asia_4246XV550A.book Page 18 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Activating picture preferences

•The picture modes of this TV are customizable. Press q

to view the different modes available.

The preset modes are: Dynamic, Standard, Movie,

Game and PC (PC Fine). These modes affect many

functions/settings of the TV. You can customize the settings

of the current picture mode as desired. For example, if you

select Dynamic, you can adjust the following settings:

Backlight, Contrast, Brightness, Colour, Tint,

Sharpness, Black/White Level, Cinema Mode, and

Colour Temperature. Your new customized settings are

stored as User setting.

Notes:

•Game mode is only available in external input mode (other

than aerial input). When you select Game mode, a suitable

widescreen format will be selected.

•PC mode is only available in RGB/PC input mode or HDMI

input mode.

•PC Fine mode is only available for a TOSHIBA PC (REGZA-

LINK type) on an HDMI input with the Enable REGZA-LINK

option in the REGZA-LINK menu set to “On”. If both of these

conditions are fulfilled, then “Auto” will appear for Black/

White Level, Cinema Mode, Film Stabilization, and

ClearFrame.

1Select Picture Settings from the PICTURE menu.

2Use Y and Z to adjust the Backlight, Contrast,

Brightness, Colour, Tint, and Sharpness.

Setting the Black/White Level

Black/White Level improves the definition of dark areas of

the picture.

1From the Picture Settings menu, press V or U to

select Black/White Level.

2Press Y or Z to select Off, Low, Middle or High.

Using the Cinema Mode

A movie film’s picture runs at 24 frames a second, whereas

movie software such as DVD, etc., that you enjoy watching on

your television at home runs at 30 (NTSC) or 25 (PAL) frames

a second. To convert this signal to reproduce smooth motion

and picture quality, select the On mode.

Effective signal and setup conditions:

•Video input mode is selected.

•Input signal format is 480i, 576i or 1080i signals.

1From the Picture Settings menu, press V or U to

select Cinema Mode.

2Press Y or Z to select On or Off.

Note:

When a DVD movie with subtitle is being played, this mode

may not work correctly.

Adjusting Film Stabilization

The Film Stabilization function allows the adjustment and

improvement of motion smoothness.

1From the Picture Settings menu, press V or U until

Film Stabilization is selected.

2Press Y or Z to select Off, Smooth or Standard.

Using ClearFrame

This function eliminates motion blur without adding flicker or

reducing image brightness and improves the viewing quality of

a motion picture.

1From the Picture Settings menu, press V or U until

ClearFrame is selected.

2Press Y or Z to select On or Off.

Adjusting the Colour Temperature

Colour Temperature increases the warmth or coolness of

the picture by increasing the red or blue tint.

1From the Picture Settings menu, press V or U until

Colour Temperature is selected, and then press Q.

2Press Y or Z to select Cool, Natural, or Warm to suit

your preference.

Using the Active Backlight Control

In order to improve screen visibility, the active backlight

control sets the screen brightness automatically during dark

scenes.

1From the PICTURE menu, press V or U to select

Active Backlight Control.

2Press Y or Z to select On or Off.

Note:

In PC input mode (- page 24), this function is not available.

100

Picture Settings

Backlight

Brightness

Contrast

Colour

Tint

Black/White Level

Cinema Mode

Sharpness

High

Off

100

Picture Settings

Backlight

Brightness

Contrast

Colour

Tint

Black/White Level

Cinema Mode

Sharpness

High

Off

Picture Settings

Colour

Tint

Sharpness

Cinema Mode

Colour Temperature

Black/White Level

ClearFrame

Film Stabilization

High

Smooth

Cool

Asia_4246XV550A.book Page 19 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Activating Auto Contrast

When Auto Contrast is activated, it will automatically

optimize the backlighting levels to suit ambient light

conditions.

1From the PICTURE menu, press V or U to select Auto

Contrast.

2Press Y or Z to select On or Off.

Setting x.v.Colour Selection

The colour range of x.v.Colour (- page 35) is an international

standard and enables a wider colour range than conventional

video applications. If the x.v.Colour Selection is set to

Auto, your TV will automatically detect images supporting

x.v.Colour.

1From the PICTURE menu, press V or U to select

x.v.Colour Selection.

2Press Y or Z to select Auto, On or Off.

Note:

If a non-HDMI input is selected or the x.v.Colour setting in the

HDMI Settings menu is set to Off, this function is not available.

Adjusting 3D Colour Management

You can adjust picture colour quality by selecting from 6 base

colour adjustments : Red, Green, Blue, Yellow, Magenta

and Cyan.

1Press M, then press Y or Z to display the PICTURE

menu.

2Press V or U to select 3D Colour Management, then

press Y or Z to select On.

3Press V or U to select Base Colour Adjustment.

4Press Q, then press V or U to select the item you want

to adjust.

5Press Z, then press Y or Z to select Hue, Saturation or

Brightness.

6Press V or U to adjust the settings as required.

Notes:

•If you set 3D Colour Management to Off, this feature will not

be available.

•In PC input mode (- page 24), this feature is not available.

Resetting the Base Colour Adjustment

The reset function returns the base colour adjustment to the

factory settings.

1From the Base Colour Adjustment menu, press V or

U to select Reset.

2Press Q.

Note:

In PC input mode (- page 24), this function is not available.

Activating MPEG NR (Noise Reduction)

If the incoming MPEG signal exhibits noise (is grainy),

depending on the compression and conversion, the noise may

be reduced when using this function.

1From the PICTURE menu, press V or U to select

MPEG NR.

2Press Y or Z to select Off, Low, Middle or High.

Note:

In PC input mode (- page 24), this feature is not available.

Activating DNR (Digital Noise Reduction)

- analogue only -

If the incoming signal is weak and the picture is blurry, the

picture may be improved when using this function.

1From the PICTURE menu, press V or U to select DNR.

2Press Y or Z to select Auto, Off, Low, Middle or High.

Note:

In PC input mode (- page 24), this function is not available.

Using Auto Format

When the TV receives a true HDMI signal picture and Auto

Format is On, the picture will automatically be displayed in

HDMI signal format, irrespective of the TV’s previous setting.

When in Digital TV, the display format will follow the

broadcasted format.

1Press M, then press Y or Z to display the FUNCTION

menu.

2Press V or U to select Auto Format, then press Y or Z

to select On or Off.

3D Colour Management

Hue Saturation

Reset

Brightness

0Red

Green

Blue

Yellow

Magenta

Cyan

000

Base Colour Adjustment

Hue Saturation Brightness

0Red 0 0

MPEG NR

Low

DNR

High

FUNCTION

Teletext

Auto Format

Panel Lock

4:3 Stretch

Blue Screen

Side Panel

Auto

Off

Asia_4246XV550A.book Page 20 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Sound adjustment

Setting the MTS (Multi-channel TV Sound)

- analogue only -

Auto mode

The MTS Auto mode automatically recognizes stereo/

bilingual programmes depending on the broadcast signal.

1Press M, and then press Y or Z to display the SOUND

menu.

2Press V or U to select MTS, and then press Y or Z to

select Auto or Mono.

Mono mode

If you experience noise or poor reception of any stereo/

bilingual programme, set the MTS mode to Mono.

Noise will be reduced and reception may improve.

Note:

If you experience noise with a particular programme whose

channel reception is usually good, try setting MTS mode to

Auto, then switch S to e Mono (monaural) (- page 21).

Selecting Dual 1 or Dual 2 mode - analogue only -

You can hear only Dual 1 or Dual 2 sound, when bilingual

programmes are received.

1Press M, and then press Y or Z to display the SOUND

menu.

2Press V or U to select Dual, and then press Y or Z to

select Dual 1 or Dual 2.

Notes:

•When the MTS setting is in Mono mode, the Dual menu is

not selectable.

•The Dual menu setting status remains even if the TV is

turned off.

Stereo and Bilingual transmissions

For ATV programmes

If stereo or dual language broadcasts are transmitted, the word

Stereo or Dual will appear on the screen each time positions

are changed, disappearing after a few seconds. If the broadcast

is not in stereo, the word Mono will appear.

Stereo… Press S to select Stereo or Mono.

Bilingual… Bilingual transmissions are rare. If they are

transmitted, the word Dual will display. Choose the desired

channel number, and if the word Dual appears, press S to

select Dual 1, Dual 2, Mono (NICAM) or Dual 1 or Dual 2

(German stereo/bilingual broadcast).

For DTV programmes

For stereo or dual mono broadcasts, press S and use Y or Z

to select settings.

Adjusting the sound quality

1From the SOUND menu, press V or U to select the item

you want to adjust.

2Press Y or Z to adjust the settings as desired.

Using SRS WOW® surround sound

SRS WOW® is a special combination of SRS Labs audio

technologies that creates a thrilling surround sound experience

with deep, rich bass from stereo sound sources. Your TV’s

audio will sound fuller, richer and wider.

WOW® consists of three features; SRS® 3D, SRS FOCUS™,

and SRS TruBass®.

1From the SOUND menu, press V or U to select WOW,

and then press Q.

2Press V or U to select an item you want to adjust, and

then press Y or Z to adjust the settings as required.

SRS 3D:To turn the surround effect On or Off.

FOCUS:To turn the vocal emphasis effect On or Off.

TruBass:To select the desired bass expansion level

(Off, Low or High).

SOUND

Dual

MTS

Treble

Bass

Balance

WOW

Dynamic Range Control

Stable Sound

Dual 1

Auto

Off

SOUND

Dual

MTS

Treble

Bass

Balance

WOW

Dynamic Range Control

Stable Sound

Dual 1

Auto

Off

Mode Display Pressing Z

d Stereo Stereo S Left S Right

j Dual mono Dual 1 S Dual 2 S Dual

e Mono —

Surround —

Selection YPressing Z

Bass weaker stronger

Treble weaker stronger

Balance decreases the right

channel decreases the left

channel

WOW

SRS 3D

TruBass

FOCUS

Off

High

Asia_4246XV550A.book Page 21 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Notes:

•If the broadcast is monaural, the SRS® 3D effect does not

work.

•WOW, SRS and l symbols are trademarks of SRS Labs,

Inc.

•WOW technology is incorporated under license from SRS

Labs, Inc.

•The SRS WOW® effect is active only when the sound outputs

from the speaker.

Using Stable Sound

The Stable Sound function limits the highest volume level to

prevent extreme changes in volume when the signal source

changes (for example, to prevent the sudden increase in

volume that often happens when a TV programme switches to

a commercial).

1From the SOUND menu, press V or U to select Stable

Sound.

2Press Y or Z to select On or Off.

Note:

The Stable Sound effect is active only when the sound outputs

from the speaker.

Using the Bass Boost

1From the SOUND menu, press V or U until Bass

Boost is selected.

2Press Y or Z to select On.

3Press V to select Bass Boost Level.

4Press Y or Z to adjust the Bass Boost Level.

5To turn off the Bass Boost, press V or U to display Bass

Boost, then press Y or Z to select Off.

Note:

The Bass Boost effect is active only when the sound outputs

from the speaker.

Other feature settings

Activating Blue Screen

With the Blue Screen function On, the screen will

automatically turn blue and the sound will be muted when no

signal is being received.

1Press M, then press Y or Z to display the FUNCTION

menu.

2Press V or U to select Blue Screen.

3Press Y or Z to select On or Off.

Note:

In PC input mode (- page 24), this function is not available.

Activating 4:3 Stretch

When 4:3 Stretch is activated, this function will switch 4:3

format programmes into a full screen picture.

1From the FUNCTION menu, press V or U to select 4:3

Stretch.

2Press Y or Z to select On or Off.

Adjusting Side Panel

You can adjust the brightness of the side panels in 14:9 or 4:3,

etc. mode.

1From the FUNCTION menu, press V or U to select

Side Panel.

2Press Y or Z to adjust the settings as desired.

Panel Lock

Panel Lock disables the buttons on the TV. All buttons on the

remote control can still be used.

1From the FUNCTION menu, press V or U to select

Panel Lock.

SOUND

Dynamic Range Control

Treble

Bass

Balance

WOW

Bass Boost

Bass Boost Level

Stable Sound

Off

FUNCTION

Teletext

Auto Format

Panel Lock

4:3 Stretch

Blue Screen

Side Panel

Auto

Off

Side Panel

FUNCTION

Teletext

Auto Format

Panel Lock

4:3 Stretch

Blue Screen

Side Panel

Auto

Off

Asia_4246XV550A.book Page 22 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

2Press Y or Z to select On or Off.

Note:

When Panel Lock is On, a reminder will appear when the

buttons on the TV are pressed. If the standby button is

pressed, the TV will switch off and can only be brought out of

standby by using the remote control.

The timers

Programme Timers - digital only -

This feature will set the TV to go to a specific channel at a

certain time. It can be used to view a particular programme, or

by setting the mode to daily or weekly, can be used to view a

series of programmes.

1Press M, then press Y or Z to display the TIMERS

menu.

2Press V to select Programme Timers, and then press

3Press V if necessary to select an open timer position, and

then press Q. The SET TIMER menu will now appear

on screen.

4Press V or U to go through the list adding the details of

the programme by using the number buttons and Y or Z

to make selections.

5When all the details have been entered, press Q to save

the timer.

The Digital TV timer indicator (- page 8) will appear

orange.

When the programme timer activates, the indicator will

change from orange to red.

Note:

When a timed programme is about to start, an information

screen will appear offering the option of watching or cancelling

the timer. The menus and other channels will not be available

during the timed programme unless the programme timer is

cancelled. Programme timers are not performed when the TV

is turned off with the ! POWER switch.

Setting the Sleep Timer

The Sleep Timer is especially useful if you want the TV to turn

itself off after a selected period of time.

1Press M, and then press Y or Z to display the TIMERS

menu.

2Press V or U to select Sleep Timer.

3Press Number buttons (0-9) to set the time period to turn

off the TV. Alternatively, press Y or Z to set the time

period. The timer display will set in blocks of 10 minutes

to 12 hours and 50 minutes.

4Press P to start the timer.

Confirming Software Version

This feature can be used to check the version of software

currently installed.

1Press M, and then press Y or Z to display the SETUP

2Press V or U until System Information is selected.

3Press Q to display the Software Version.

TIMERS

Sleep Timer 00:00

Programme Timers

OK0-9

SET TIMER 11:36 Fri, 1 Aug

Channel

Start Time

Date

End Time

Repeat

Enter Number Save Timer Back

Fri, 1 Aug 2008

11:35

12:35

Once

TIMERS

Sleep Timer 00:00

Programme Timers

SETUP

DTV Manual Tuning

ATV Manual Tuning

DTV Settings

AV Connection

Picture Position

Quick Setup

System Information

Reset TV

SETUP

ATV Manual Tuning

Auto Tuning

DTV Manual Tuning

DTV Settings

AV Connection

Picture Position

Quick Setup

System Information

Software Version

XV550A

1.2.69.0

Aug 20 2008 - 14:55:08

FW: 08

Asia_4246XV550A.book Page 23 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Resetting the TV

Reset TV will reset all TV settings, including stored channels,

to their original factory values.

1From the SETUP menu, press V or U until Reset TV

is selected.

2Press Q to select.

A screen will appear warning that all settings will be lost.

Select Yes and then press Q to continue.

When the set powers back on, the Quick Setup screen

will appear. Press Q to continue, the TV will then

display the Auto Tuning menu (- page 14).

Selecting the video input source

1Press o on the remote control to display the video input

mode list, and then press V or U to select appropriate

input source (or press o on the TV side panel or o on

the remote control repeatedly to select the desired input

source directly).

2Press Q.

DTV (Digital TV),

o 1 (o (1), video 1 input),

o 2 (o (2), video 2 input) or o 2S (S-video input),

o 3 (o 3, component video input),

o 4 (o 4, component video input),

HDMI1, HDMI2, HDMI3, HDMI4 (HDMI input),

PC (o RGB/PC, PC input),

ATV (Analogue TV)

Notes:

•When component video, PC, or HDMI input modes are

selected, the MONITOR terminals (- page 32) output

audio signal only.

•If a REGZA-LINK device is connected to an HDMI input, the

REGZA-LINK icon will appear.

•When the TV is switched on, it will take a few minutes for the

REGZA-LINK icon to appear in the list; when an HDMI cable

is removed, it will take a few minutes for the icon to

disappear.

•If the HDMI cable from a connected device or the HDMI

device settings is changed, Enable REGZA-LINK in the

REGZA-LINK menu may need to be reset to On.

Setting the Manual Settings menu - analogue only -

1Press M, and then press Y or Z to display the SETUP

menu.

2Press V or U to select Manual Settings, and then press

3Press Y or Z to select an item, and then press V or U to

select the item as shown below.

A. Colour System

Confirm that colour system is set to “A” (Auto). If not,

select “A” with V or U.

B. Video label

The video label allows you to label each input source

for your TV.

To change or create video labels:

1) Press V or U repeatedly to select a character for

the first space, and then press Z.

2) Repeat step 1 to enter the rest of the characters.

If you would like a blank space in the label name,

you must choose a blank space from the list of

characters.

3) Press Q to store your settings.

SETUP

DTV Manual Tuning

ATV Manual Tuning

DTV Settings

AV Connection

Picture Position

Quick Setup

System Information

Reset TV

Ex. PC VGA mode

PC VGA

Inputs

DTV

HDMI2

HDMI1

HDMI3

HDMI4

ATV

SETUP

Menu Language English

Auto Tuning

AV Connection

Manual Settings

Picture Position

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

Manual Settings

Colour System: Auto

EXT1 A

*(blank space)

Asia_4246XV550A.book Page 24 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Using REGZA-LINK

This feature uses CEC (Consumer Electronics Controls)

technology and allows the control of Toshiba REGZA-LINK

compatible devices from the TV remote control via HDMI

connection (- page 38).

Note:

Not all Toshiba products currently support REGZA-LINK.

REGZA-LINK Setup

1Press M and Y or Z to select the REGZA-LINK menu.

2Press V or U to select Enable REGZA-LINK, and then

press Y or Z to select On.

Note:

If you set Enable REGZA-LINK to Off, then all other items

will be greyed out.

3Press V or U to select the REGZA-LINK set up item you

want to use, and press Y or Z to select On/Off or the

desired speakers mode.

• TV Auto Power On: On/Off

• Auto Standby: On/Off

• Amplifier Control: On/Off

• Speaker Preference: TV Speakers/Amplifier

REGZA-LINK one touch play

When a connected device is switched on, REGZA-LINK will

automatically switch the TV to the appropriate HDMI input.

Also, if the TV is in standby, it will be switched on

automatically.

These functions can be enabled or disabled from the REGZA-

LINK setup.

Note:

Even if the device is only showing a menu, the TV may

automatically switch to that input source.

REGZA-LINK system standby

This feature automatically puts the connected device into

standby when the TV goes into standby and vice versa.

REGZA-LINK system audio control

Using the Speaker Preference feature allows the TV remote

control to adjust the volume or mute the sound of the speakers

connected to the TV via an AV amplifier.

Ensure that the connected AV amplifier and REGZA-LINK

device are selected in the input source selection and that

Speaker Preference is set to Amplifier in the REGZA-

LINK setup menu.

Notes:

•When you turn on the AV amplifier, change its input source,

or adjust the sound volume, the sound will be output from

the AV amplifier’s speakers even if TV Speakers has been

selected for Speaker Preference. Turn the TV first to

standby and then on again to output the sound from the TV

speakers.

•The proper function may not work when operating the AV

Amplifier.

REGZA-LINK functions

When Enable REGZA-LINK is set to On, the following

functions can be enabled by setting them to On.

TV Auto Power On

The TV Auto Power On setting allows the TV to be

automatically switched on if a REGZA-LINK device is turned

on.

Auto Standby

If Auto Standby is enabled, the TV, when switched off, will

automatically switch off (put into standby mode) all connected

REGZA-LINK devices.

Amplifier Control

When Amplifier Control is set to On, it allows the “Speaker

Preference” feature to become available.

Speaker Preference

This feature allows the Speaker Preference to be set to TV

Speakers or Amplifier. The Amplifier option allows the

remote control to adjust or mute the volume of the external

audio.

Notes:

•When you turn on the Amplifier, change its input source, or

adjust the sound volume, the sound will be output from the

Amplifier’s speakers even if TV Speakers has been

selected. Turn the TV to standby and then on again to output

the sound from the TV speakers.

•The above functions are dependent on the connected

device and TV setting.

REGZA-LINK

Enable REGZA-LINK On

TV Auto Power On

Auto Standby

Amplifier Control

Speaker Preference

TV Speakers

Note:

The above functions are dependent on the connected device

and TV setting.

Asia_4246XV550A.book Page 25 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

REGZA-LINK input source selection

When devices that use CEC technology have been connected,

the REGZA-LINK icon will show in the input source list.

To select the REGZA-LINK input source, refer to “Selecting

the video input source” on page 24.

Notes:

•This function depends on the devices connected.

•If you select the REGZA-LINK input source from the popup

window, some REGZA-LINK devices may automatically turn

on.

•When the TV is switched on, it will take a few minutes for the

REGZA-LINK icon to appear in the list; when an HDMI cable

is removed, it will take a few minutes for the icon to

disappear.

•If the HDMI cable from a connected device or HDMI device

settings are changed, Enable REGZA-LINK in the REGZA-

LINK menu may need to be reset On.

To control the REGZA-LINK device

First, select the HDMI input source with the desired REGZA-

LINK device connected. Then switch the mode on the remote

control to REGZA-LINK and press the available button on the

remote control (- page 11).

The TV features that can be controlled by the connected

device remote control are:

Power standby, Volume, Programme channel, Sound mute,

Input selection, Number buttons, Previous channel.

Note:

These functions are dependent on the connected device. Not

all the remote control buttons may be available. Please refer to

the owner’s manual for all the connected devices.

REGZA-LINK PC link

This feature automatically adjusts the suitable widescreen

formats and picture preferences when connected to a REGZA-

LINK PC.

Note:

This feature depends on the connected equipment.

Teletext in Analogue TV

This TV has a multi-page teletext memory, and it offers two

ways of viewing Teletext Auto and List which are explained

below.

Setting up the teletext mode

To select teletext mode:

Select a channel position with the desired teletext service.

1Press M, and then press Y or Z to display the

FUNCTION menu.

2Press V or U to select Teletext, and then press Y or Z

to select Auto or List mode.

Notes:

•It may take a few moments for the multi-page teletext

memory to load.

•You must exit teletext mode in order to display the main

menu.

Teletext general information

button:

Pressing once will bring up the teletext screen. Press

again to superimpose the teletext over a normal broadcast

picture. Press again to return to normal TV mode. You need to

return to normal viewing if you wish to change channels.

When you first press to access the text service, the first

page you see will be the initial page.

In Auto mode, this displays the main subjects available and

their relevant page numbers.

In List mode, you will see the page numbers currently stored

for each colour button.

Sub-pages:

Once on the chosen page, if there are sub-pages they will

automatically load into memory without affecting the page

currently being viewed. If there are many sub-pages, it may

take some time for them all to load. The length of time will

depend on the speed with which the broadcaster transmits

them.

To access the sub-pages in memory, press l, then use

PU / Pu to view them.

Note:

If you press r while this mode is activated, it will be

cancelled.

Inputs

DTV

HDMI2

HDMI1

HDMI3

HDMI4

ATV

REGZA-LINK

FUNCTION

Teletext

Auto Format

Panel Lock

4:3 Stretch

Blue Screen

Side Panel

Auto

Off

Asia_4246XV550A.book Page 26 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Using Auto mode

There are two Modes: Auto will display FASTEXT. List will

display your four favourite pages. In either mode, as an

alternative to the coloured buttons, you can access a page by

entering a 3-digit number or by using the PU / Pu keys to go

back and forth between pages.

To change between Auto and List, please see “Setting up the

teletext mode” on the previous page.

• Press to access teletext.

If FASTEXT is available, you will see 4 coloured titles at the

bottom of the TV screen. To access any given subject, simply

press the relevant coloured button on the remote control.

If FASTEXT is not available, you can access any page simply

by entering a 3-digit page number or pressing the

corresponding coloured button.

For further information on your particular text system(s), see

the broadcast teletext index page or consult your local Toshiba

dealer.

Using LIST mode

1Press to access teletext.

The four choices at the bottom of the screen are now

number – 100, 200, 300 and 400, which have been

programmed into the TV’s memory.

2To view these pages, use the coloured prompt buttons.

e.g. press the Green button to view page 200.

3If you want to change these stored pages, press the

coloured button for the colour you want to change.

e.g. Press the Green button and enter the 3-digit number.

This number will change in the top left of the screen and

in the coloured highlight.

4Press Q to store your choice.

5You may view other pages by simply entering the 3-digit

page number – but NEVER press Q or you will lose the

favorite already stored.

Teletext buttons on the remote control

Below is an introduction to the teletext buttons on your remote

control and their functions.

k To display an index/initial page:

In Auto-mode

Press k to access the index page. The one displayed is

dependent on the broadcaster.

In LIST-mode

Press k to return to the 100 page or initial page.

A To reveal concealed text:

Some pages cover topics such as quizzes and jokes. To

discover the solutions, press A.

B To hold a wanted page:

At times it is convenient to hold a page of text. Press B and

B will appear in the top left of the screen. The page will be

held on screen until the button is pressed again.

C To enlarge the teletext display size:

Press C once to enlarge the top half of the page, and press

again to enlarge the bottom half of the page. Press again to

revert to the normal size.

D To select a page while viewing normal picture:

When in teletext mode, if a page selection is made and then

D is pressed, normal picture will be displayed. The TV

will indicate when the page is present by displaying the title

bar of the text page at the top of the screen. Press to view

the page.

Note:

It will not be possible to change TV channels while in Teletext

mode. You will have to cancel the teletext first by pressing

to return to normal TV picture.

To select the time display:

If you press D while watching a normal TV broadcast,

you will see a time display from the broadcaster. It will remain

on the screen for about 5 seconds.

Note:

If you press r while this mode is activated, it will be

cancelled.

100 Sport 14:57:55

Swimming Racing Baseball Football

Red

FASTEXT

Green Yellow Blue

Red Green Yellow Blue

100 TEXT M00 14:58:55

100 200 300 400

100 TEXT M00 14:58:59

100 250 300 400

21:56:25

9:56 and 25 seconds p.m.

Asia_4246XV550A.book Page 27 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Using the TV’s features (General)

Teletext in Digital TV

1When on-screen information indicates the presence of

Teletext ( ) in a channel, press to view Teletext.

Press again to superimpose the Teletext over normal

broadcast picture. Press again to close Teletext and watch

TV.

2Press PU and Pu to select Teletext pages. Press the

Number buttons in order to view a Teletext page

directly. If FASTEXT is available,simply press the

relevant coloured button on the remote control.

3Press P to close Teletext and watch TV.

Subtitles

1When on-screen information (- page 16) indicates the

presence of Subtitles (CC) in a channel, press to

display the current Subtitle status. While this status is

displayed, press again to change the setting. Subtitle On

or Off can be selected.

2If you switch off the TV, the Subtitle mode will be

remembered the next time it is switched ON.

Notes :

•If Subtitle is ON, the TV will always display subtitles

whenever such information is available for the channel you

are viewing. You may use on-screen information to check if

subtitles are currently available.

•In Australia, you may also enter Subtitle mode by directly

entering page 801 in Teletext. However, by doing so, the TV

remains in Teletext mode, and you cannot change the

channels. This is because PU and Pu will change Teletext

pages rather than channels. To view subtitles, it is

recommended that you turn on Subtitle mode.

Asia_4246XV550A.book Page 28 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Other Digital TV features and settings

Using the EPG (Electronic

Programme Guide)

1Display the on-screen guide by pressing . The guide

screen will appear highlighting details of the channel and

programme currently being viewed. This may take a few

moments to appear.

You can switch the time scale to 1.25 or 2.5 hours by

pressing the RED button.

Note:

Channels are displayed based on the current TV/Radio

Mode setting. Skipped channels are not displayed.

2Press Y or Z for information on other programmes

scheduled for the channel selected.

3For details of other programmes currently available, press

V or U to scroll up and down the channel list. As

channels are selected, details of the programme currently

being broadcast will appear. Press Y or Z to view

information for future programmes.

Note:

Press the BULE button to open the Programme Timers

menu.

4For information on a highlighted programme, press .

Note:

In order for the recording operation to work properly, the

media recorder must be set to the same time as the TV.

Regarding the process for recording, please refer to the

owner’s manual of the recording equipment.

5Press z to move the EPG forward by 24 hours, press Z

to go back. Pressing cc or CC will move the EPG

forwards or backwards a page at a time.

Press Pu to advance to the next page, or press PU to go

back to the previous page.

Genre selection/searching

From the guide screen, you can use the genre selection and

search features.

1Press the GREEN button from the guide screen. The

Genre Colour Setup window will appear.

2With the focus on a particular genre, press the desired

colour key to assign. All four colours will be available.

Press M to go back to the guide screen.

3Press the YELLOW button to access the Genre Search

screen.

4Press Y or Z to select the genre. Programmes listed will

change for the new genre. Press V or U to highlight a

particular programme.

5When a current programme is selected, pressing Q will

tune to that programme. When a future programme is

selected, pressing Q will open the SET TIMER menu.

6For information on a highlighted programme, press .

7To exit the Genre Search and go back to the guide

screen, press the YELLOW button.

Favourite Channel Lists

1Press the button. The Channel Lists will appear.

Press Y or Z to select the TV/Radio Mode List or

Favourites 1-4. The number of favourites available

depends on how many favourite lists have been created.

2Press V or U to highlight a channel, and press Q to

watch.

TuneOK More Infoi+ Page Up/Down ViewPWatch TVEXITGenre Colour Timers

11:35 Fri, 1 Aug

Fri

Sat 2 Sun 3 Mon 4 Tue 5 Wed 6 Thu 7 Fri 8

All Channels

11:30 12:00 12:30 13:00 13:30

Genre Colour Setup

Movies

Colour Setup Back

OK i+ PEXIT

Fri,1 Aug 15:59 - 16:00

Fri,1 Aug 21:31 - 23:39

Fri,1 Aug 21:31 - 23:40

Fri,1 Aug 21:31 - 23:39

Fri,1 Aug 23:39 - 1:38

Sat,2 Aug 1:38 - 4:00

Sat,2 Aug 1:38 - 3:39

Sat,2 Aug 1:38 - 4:00

Sat,2 Aug 12:00 - 14:00

Sat,2 Aug 20:30 - 22:30

Genre Serch 11:37 Fri, 1 Aug

Movies

Schedule More Info Page Up/Down Watch TVEPG Timers

Channel Lists

All Channels

Asia_4246XV550A.book Page 29 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Other Digital TV features and settings

Digital settings - Channel Options

Selecting favourite channels

Favourite Channels creates a list of the digital channels that are

watched most. Four lists can be created; these can be a mixture

of TV and radio channels.

1Press M, and then press Y or Z to display the SETUP

menu.

2Press V or U to select DTV Settings, and then press

3Press V to select Channel Options and press Q.

4Use V U Y Z to go through the list of channels. Press

Q to select the ones desired. Ticks will appear in the

boxes as they are selected.

To select all channels in the highlighted column, press the

RED button. To erase all channels in the highlighted

column, press the GREEN button.

Locking channels

Locking Channels stops the viewing of digital channels; they

can only be accessed by entering the PIN.

1From the DTV Settings menu, press V to select

Channel Options, and then press Q.

2Press Z repeatedly to select the Locked Channel list.

3Use V and U to go through the list of channels. Press Q

to select the ones desired. Ticks will appear in the boxes.

If a PIN has already been set, PIN entry will be required

to set the locked channels.

4Press P.

5From this point on, when any of the channels in the

Locked Channel list are selected the PIN must be entered

before they can be accessed.

TV/Radio Mode

This feature determines the channel list profile that will be

applied to regular channel changing, the programme guide,

and the button in digital mode.

1From the DTV Settings menu, press V or U to select

TV/Radio Mode.

2Use Y or Z to select All Channels, TV or RADIO.

Note:

When setting to TV or RADIO, using the Pu and PU button will

now only access that particular type of channel; however,

channels that are not in the currently selected list can still be

selected by direct position number entry.

Digital settings - Parental Control

In order to prevent viewing of unsuitable films and

programmes, channels and menus can be locked. These can

then only be accessed with a security code PIN when in digital

mode.

Setting the PIN

1From the DTV Settings menu, press V or U to select

PIN Setting, and then press Q.

2Using the number buttons, enter a four digit number.

Once entered you will be prompted to confirm by entering

again.

The PIN is now set to Enabled. Press M to go back to

DTV Settings.

If the PIN code has been set, when Auto Tuning and

Reset TV are executed, entering the PIN will be

necessary.

SETUP

Menu Language English

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

Picture Position

AV Connection

Quick Setup

1234

Pos. Type Name Fav.

Channel Options

1234

Pos. Type Name Fav.

Channel Options

DTV Settings

Channels

TV/Radio Mode

Channel Options

PIN Setting

Local Time Setting

Parental Control

All Channels

* * * *

Enter PIN Code:

Confirm PIN Code:

PIN Setting

Asia_4246XV550A.book Page 30 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Other Digital TV features and settings

Parental Setup

The Parental Control feature allows you to block programmes

according to their rating levels. If a PIN has been set, you will

need to enter it before adjusting the level.

1From the DTV Settings menu, press V to select

Parental Control.

2Press Y or Z to choose the Parentat Setup options

(None, Block All, Block G and Above, Block PG

and Above, Block M and Above, Block MA and

Above, Block AV and Above, Block R and

Above).

To view blocked programmes, enter the PIN.

To reactivate the Parental Control, turn the TV off and

then on again.

Local Time Settings

This function allows you to manually set the time zone and

override the location that you have chosen during Auto Scan.

Please note that if you manually change the time zone setting,

all existing entries in the programme timer will become invalid

as they are still based on the old time zone. It is recommended

that you delete all the entries in the programme timer before

proceeding with the steps described below.

1From the DTV Settings menu, press V or U to select

Local Time Setting.

2Press Q, and then press V or U to select Time Zone.

3Press Y or Z to select the item you want to set.

(New South Wales, Northern Territory,

Queensland, South Australia, Tasmania,

Victoria, Western Australia, Australian Capital

Territory)

4Press V to select Time Offset, and then press Y or Z to

set as required.

Digital Output Format

1From the SETUP menu, press V or U to select AV

Connection, and then press Q.

2Press V or U to select Digital Output.

3Press Y or Z to select Auto or PCM

Auto:Select this when an amplifier equipped with a

built-in Dolby Digital or MPEG decoder is

connected to the TV.

PCM: Select this when a 2ch digital stereo amplifier is

connected to the TV. When you select a Dolby

Digital or MPEG audio track, the sound is

converted to the PCM (2ch) format and output.

Note:

Manufactured under license from Dolby Laboratories. “Dolby”

and the double-D symbol are trademarks of Dolby

Laboratories.

Dynamic Range Control

This feature allows control of audio compression for digital

TV programmes excluding those with MPEG-1 and MPEG-2

audio.

When using Dynamic Range Control for Dolby Digital

sound, Audio Level Offset is available to adjust the sound

level. Using this function can reduce the difference in sound

level between MPEG-2 and Dolby Digital audio.

1Press M and press Y or Z to select the SOUND menu.

2Press V or U to select Dynamic Range Control, then

press Y or Z to select On or Off.

3Press V or U to select Audio Level Offset.

4Press Y or Z to adjust the Audio Level Offset from

–11 to 0. This setting will be applicable to Dolby Digital

audio.

Note:

If the Stable Sound and Dynamic Range Control features are

both set to On, the effects of each function may not be

noticeable.

Parental Setup None

Parental Control

Local Time Setting

Time Zone

Time Offset

New South Wales

11:29

AV Connection

PC/HDMI1 Audio

HDMI Settings

HDMI1 Audio

Digital Output

Auto

HDMI1

-5

Dynamic Range Control

Dynamic Range Control On

Audio Level Offset

Asia_4246XV550A.book Page 31 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

Back connections

Connection example

• Before connecting any external equipment, turn off all main

power switches.

•The unauthorized recording of television programmes,

DVDs, video tapes and other materials may infringe upon

the provisions of copyright law.

•The COMPONENT VIDEO INPUT consists of three

component video signals (Y, PB/CB, PR/CR) and provides

better picture performance. These terminals can only be

used with the component video compatible equipment e.g.

DVD video player, etc.

• Additional equipment and cables shown are not supplied

with this TV.

Connecting an audio system - digital only -

You can enjoy high quality dynamic sound by connecting the

TV to an audio system.

Notes:

•DO NOT connect the DIGITAL AUDIO output terminal to the

AC-3 RF input of a Dolby Digital Receiver with a built-in

Dolby Digital decoder.

•Connect the DIGITAL AUDIO output terminal to the

OPTICAL input of a Receiver or Processor.

•Refer to the owner’s manual of the connected equipment as

well.

•When you connect the TV to other equipment, be sure to turn

off the power and unplug all of the equipment from the wall

outlet before making any connections.

•The output sound of the TV has a wide dynamic range. Be

sure to adjust the audio amplifier’s volume to a moderate

listening level before turning on the power. Otherwise, the

speakers and your hearing may be damaged by a sudden

high volume sound.

•Turn off the amplifier before you connect or disconnect the

TV’s power cord. If you leave the amplifier power on, the

speakers may be damaged.

Warning:

When you are connecting (via the DIGITAL AUDIO output

terminal) an AV decoder that does not have Dolby Digital or

MPEG decoding function, be sure to set PCM for Digital Output

(- page 31). Otherwise, the speakers and your hearing may

be damaged by a sudden high volume sound.

Connecting an amplifier equipped with a

Dolby Digital decoder

You can enjoy dynamic realistic sound by connecting the TV

to an amplifier equipped with a Dolby Digital decoder or

Dolby Digital processor. When using this setup, select Auto in

the Digital Output menu.

TV back view

DVD video player

(with component video outputs)

Set Top Box

VCR (Recording)

VCR (Normal)

TO Digital Audio

output terminal

To Optical

type digital

audio input

Optical

digital cable

(not supplied)

Amplifier equipped with

Dolby Digital decoder

Front speaker Surround speaker Sub woofer

Centre speaker Signal flow

TV back view

Asia_4246XV550A.book Page 32 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

Connecting an amplifier equipped with an

MPEG decoder

You can enjoy motion picture with dynamic realistic sound by

connecting the TV to an amplifier equipped with an MPEG

audio decoder or MPEG audio processor. When using this

setup, select Auto in the Digital Output menu.

Connecting an amplifier equipped with a

digital audio (optical) input

You can enjoy dynamic sound of 2-channel digital stereo by

connecting the TV to an amplifier equipped with a digital

audio (optical) input and speaker system (right and left front

speakers). When using this setup, select PCM in the Digital

Output menu.

Side connections

You can connect a wide variety of auxiliary equipment via the

terminals located on the right side of the panel o (2).

Please always refer to the owner’s manual of the equipment to

be connected for full details.

Connection example

• To select the side inputs, press o to display the video input

mode list, press V or U to select o2 (- page 24), and

then press Q.

• Before connecting any external equipment, turn off all main

power switches.

•If you connect to both the S-VIDEO input terminal and

VIDEO input terminal, the S-VIDEO signal will appear on

the screen (display changes to o 2S).

•If you connect mono sound equipment to o (2), connect the

audio output of the equipment to the L/MONO jack on the

TV.

•You can enjoy Video Games with this TV. However

shooting games, where the player shoots at a target on the

TV screen with a light gun, may not work because of the

LCD Colour TV properties.

TO Digital Audio

output terminal

To Optical type

digital audio input

Optical digital cable

(not supplied)

Amplifier equipped with

MPEG decoder

TV back view

Front speaker Surround speaker Sub woofer

Centre speaker Signal flow

TO Digital Audio

output terminal

Optical digital cable

(not supplied)

To Optical type

digital audio input

Amplifier equipped with

digital audio input

Front speaker Signal flow

TV back view

TV right side view

Video Games

Camcorder Camcorder with

S-Video

Asia_4246XV550A.book Page 33 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

Connecting an HDMI or a DVI device

•When turning on your electronic components, turn on the

TV first, and then the HDMI or DVI device.

•When turning off your electronic components, turn off the

HDMI or DVI device first, and then the TV.

•This TV may not be compatible with features and/or

specifications that may be added in the future.

•This TV is only operable with L-PCM on 32/44. 1/48 kHz

and 16/20/24 bits. If there is no sound when using HDMI,

use the analogue audio cables to connect the TV and the

HDMI device and select Analogue for HDMI1 Audio of

the AV Connection menu (- page 35).

Connecting an HDMI or a DVI device

The HDMI input on your TV receives digital audio and

uncompressed digital video from an HDMI device or

uncompressed digital video from a DVI device.

This input is designed to accept HDCP programme material in

digital from CEA-861-D compliant consumer electronic

devices (such as a set top box or DVD player with HDMI or

DVI output).

The HDMI input is designed for best performance with 1080i

(50 Hz/60 Hz), 1080p (24Hz/50Hz/60Hz) high-definition

video signals, but will also accept and display 480i, 480p, 576i,

576p and 720p (50 Hz/60 Hz) signals.

•HDMI: High-Definition Multimedia Interface

•DVI: Digital Video Interface

•HDCP: High-bandwidth Digital Content Protection

• CEA-861-D compliance covers the transmission of

uncompressed digital video with high-bandwidth digital

content protection, which is being standardized for

reception of high-definition video signals. Because this is an

evolving technology, it is possible that some devices may

not operate properly with the TV.

•E-EDID: Enhanced-Extended Display Identification

• Acceptable PC signal format:

VGA: VESA 640 5 480 @ 60/72/75 Hz

S-VGA: VESA 800 5 600 @ 60/72/75 Hz

XGA: VESA 1024 5 768 @ 60/70/75 Hz

W-XGA: VESA 1280 5 768 @ 60/75 Hz

W-XGA: VESA 1360 5 768 @ 60 Hz

S-XGA: VESA 1280 5 1024 @ 60/75 Hz

However, these signal formats are converted to match the

number of pixels of the LCD panel.

Therefore, the TV may not display small text properly.

•L-PCM: Linear-Pulse Code Modulation

Connecting an HDMI device

One HDMI cable (type A connector)

For proper operation, it is recommended that you use a short

HDMI cable.

HDMI cable transfers both video and audio.

Note:

It is possible that some HDMI devices may not operate

properly with this TV.

Connecting a DVI device

One HDMI (type A connector)-to-DVI adapter cable and

audio cables

HDMI (type A connector)-to-DVI adapter cable

For proper operation, the length of an HDMI-to-DVI adapter

cable should not exceed 3m. The recommended length is 2m.

Standard analogue audio cables

An HDMI-to-DVI adapter cable transfers only video.

Separate analogue audio cables are required.

Note:

HDMI, the HDMI logo, and High-Definition Multimedia

Interface are trademarks or registered trademarks of HDMI

Licensing, LLC.

VIDEO AUDIO

OUT

HDMI OUT

TV back view

TV right side view

HDMI device

VIDEO AUDIO

OUT

DVI

OUT

DVI device

TV back view

Asia_4246XV550A.book Page 34 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

Selecting the PC/HDMI1 audio mode

You can select PC audio or HDMI1 audio when using this

function (- page 34).

1Press M, and then press Y or Z to display the SETUP

menu.

2Press V or U to select AV Connection, and then press

Q to display the AV Connection menu.

3Press V or U to select PC/HDMI1 Audio, and then

press Y or Z to select PC or HDMI1.

Setting the HDMI1 audio mode

You can select from three sound modes for an HDMI or DVI

device connected to the HDMI1 input terminals (- page 34):

Auto, Digital or Analogue.

Note:

This function is available only when the PC/HDMI1 Audio mode

is set to HDMI1.

1From the AV Connection menu, press V or U to select

HDMI1 Audio.

2Press Y or Z to select Auto, Digital or Analogue.

Selecting the HDMI setting

The HDMI Settings menu consists of the following 3 items:

Deep Colour, x.v.Colour and Lip Sync. Some early

HDMI equipment may not work properly with your HDMI

TV. If you experience trouble, unplug your HDMI cable first

and then try setting these three options to Off. This should

allow your early HDMI source to operate properly with your

TV.

1From the AV Connection menu, press V or U to select

HDMI Settings, and then press Q.

2Press V or U to select each item, and then press Y or Z

to select the desired setting.

Deep Colour mode

This function increases the available colours from the HDMI

source to increase the boundaries defined by the RGB or

YCbCr colour space.

x.v.Colour

This function expands the acceptable colour range (limits) of

HDMI signals, and allows sending of wider colour signals

from HDMI sources.

Lip Sync mode

This option activates an auto audio/video display timing

adjustment function that allows HDMI source devices to

accurately perform synchronization automatically.

All above HDMI settings require a proper HDMI source

device.

If HDMI source products do not support these functions, the

TV may not work properly by activating these functions.

Notes:

•In non-HDMI signal mode, this function is not available.

•If your HDMI connection is capable of 1080p and/or your TV

is capable of refresh rates greater than 60Hz or supports

Deep Colour, you will need a Category2 cable. Conventional

HDMI/DVI cables may not work properly with this mode.

AV Connection

PC/HDMI1 Audio

HDMI Settings

HDMI1 Audio

Digital Output

Digital

Auto

AV Connection

PC/HDMI1 Audio

HDMI Settings

HDMI1 Audio

Digital Output

Auto

HDMI1

HDMI Settings

x.v.Colour

Deep Colour

Lip Sync

Asia_4246XV550A.book Page 35 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

Connecting a computer

To connect a PC to the RGB/PC terminal on the TV:

An analogue RGB (15 pin) computer cable can be connected.

Connect a PC cable from the computer to the o RGB/PC

terminal on the back of the TV.

The following signals can be displayed:

For acceptable PC signal formats, see page 34.

Notes:

•Some PC models cannot be connected to this TV.

•There is no need to use an adapter for computers with DOS/

V compatible mini D-sub 15 pin terminal.

•A bar may appear in the upper, lower, right or left side of the

screen, or parts of the picture may be obscured depending

on some signals. This is not a malfunction.

•If the edges of the picture are stretched, readjust the picture

position adjustments in the PC Settings menu.

•Depending on the specification of the PC you are playing

the DVD-Video on and the DVD’s title, some scenes may be

skipped, or you may not be able to pause during multi-angle

scenes.

•The PC signal may not be detected correctly for certain PC

models.

Signal names for mini D-sub 15 pin connector

To connect a PC to the HDMI terminal on the TV:

When connecting a PC to the HDMI terminal on the TV, use

an HDMI-to DVI adapter cable and analogue audio cables.

If connecting a PC with an HDMI terminal, use an HDMI cable

(type A connector). Separate analogue cables are not

necessary.

For acceptable PC signal format, see page 34.

Notes:

•The edges of the images may be hidden.

•The PC signal may not be detected correctly for certain PC

models.

Pin No. Signal name Pin No. Signal name

1R9NC

2G10Ground

3B11NC

4NC (not

connected) 12 NC

5NC13H-sync

6Ground 14 V-sync

7Ground 15 NC

8Ground

(if

Computer

Audio cable for PC-to-TV connection

Conversion adapter

necessary)

RGB PC cable

Mini D-sub 15 pin

TV back view

15 11

Pin assignment for RGB/PC terminal

TV back view

Computer Audio cable

for PC-to-TV

connection

Asia_4246XV550A.book Page 36 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

Using the PC Settings

•In PC input mode, you cannot select 3D Colour

Management, Base Colour Adjustment, MPEG NR

and DNR in the PICTURE menu and Colour, Tint,

Sharpness, Black/White Level and Cinema Mode in

the Picture Settings menu (- page 19).

•In PC input mode, Manual Settings (- page 24) is not

displayed.

•First, press o to display the video input mode list, and then

press V or U and Q in order to select the PC input mode

(- page 24).

•This function may not be available for some signals and

when no signal is received.

• In certain cases, it may be difficult to optimally set the clock

phase and sampling clock values depending on the input

signal type.

Adjusting the picture size/position

1Press M, and then press Y or Z to display the SETUP

menu.

2Press V or U to select PC Settings.

3Press Q to display the PC Settings menu.

4Press V or U to select an option you want to adjust. Press

Y or Z to adjust the settings as required.

Adjusting the clock phase of the picture

If the clock phase, which synchronizes the PC signal and LCD

display, is not optimized, the picture will blur.

This function enables you to adjust clock phase and display a

clear picture.

1From the PC Settings menu, press V or U to select

Clock Phase.

2Press Y or Z to obtain a clear picture.

Adjusting the sampling clock

If the sampling clock does not match with the dot clock

frequency of the PC, blurred picture detail will occur, screen

width will change, or drift patterns in vertical lines may be

apparent.

This function enables you to adjust and optimize the picture.

1From the PC Settings menu, press V or U to select

Sampling Clock.

2Press Y or Z to optimize the picture.

Resetting the PC Settings

The Reset function adjusts the PC Settings to the factory

settings.

1From the PC Settings menu, press V or U to select

Reset.

2Press Q.

Note:

When a PC is connected using HDMI, none of these functions

will be available.

SETUP

Menu Language English

Auto Tuning

ATV Manual Tuning

DTV Manual Tuning

DTV Settings

PC Settings

AV Connection

Quick Setup

PC Settings

Horizontal Position

Reset

Sampling Clock

Vertical Position

Clock Phase

Horizontal position 0

Clock phase 0

Sampling clock 0

Asia_4246XV550A.book Page 37 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Connecting your TV

REGZA-LINK connection

You can control the basic functions of connected audio/video devices using the TV’s remote control if you connect a REGZA-

LINK compatible audio receiver or playback device. For an explanation of setup and operations, see pages 26 – 27.

Connection example

AV Amplifier Playback device

Playback device

TV back view

Before controlling the device(s):

• After completing the above connections, set the REGZA-

LINK Setup menu as you desire (- page 25).

• The connected devices must also be set. For details, see the

owner’s manual for each device.

Notes:

•If several devices are connected, the REGZA-Link feature

may not operate properly.

•The REGZA-LINK function uses CEC technology as

regulated by the HDMI standard.

•For proper operation, it is recommended that you use HDMI

cables with the HDMI Logo ( ).

•This function is limited to models incorporating Toshiba’s

REGZA-LINK. However, Toshiba is not liable for those

operations. Refer to the individual owner’s manuals for

compatibility information.

•This function is able to operate one PC and one AV

Amplifier, but the PC may not operate properly with the AV

Amplifier. Some PC models may not be controlled properly

by the TV.

Asia_4246XV550A.book Page 38 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Reference section

Troubleshooting

Before calling a service technician, please check the following

table for a possible cause of the symptom and some solutions.

Symptom and solution

TV will not turn on

•Make sure the power cord is plugged in, and then press

! or 1.

• The remote control batteries may be dead. Replace the

batteries.

No picture, no sound

• Check the aerial connections.

No sound, picture OK

•The sound may be muted. Press 2+, 2– or U.

• The station may have broadcast difficulties. Try another

channel.

Poor sound, picture OK

• The station may have broadcast difficulties. Try another

channel.

Poor picture, sound OK

• Check the aerial connections.

• The station may have broadcast difficulties. Try another

channel.

•Adjust the PICTURE menu.

Poor reception of broadcast channels

• Check the aerial connections.

• The station may have broadcast difficulties. Try another

channel.

•Make sure the Colour system is properly set.

Teletext problems

• Check the aerial connections.

Good performance of text depends on a good strong

broadcast signal.

Multiple images

• The station may have broadcast difficulties. Try another

channel.

• Aerial reception may be poor. Use a high directional

outdoor aerial.

• Check if the direction of the aerial has changed.

Poor colour or no colour

• The station may have broadcast difficulties. Try another

channel.

•Adjust the Tint and/or Colour in the PICTURE menu.

The remote control does not operate

•Remove all obstructions between the remote control and

the remote control sensor on the TV.

• The remote control batteries may be dead. Replace them

with new ones.

• Check that the TV/REGZA-LINK/DVD switch on the

remote control is properly set.

Some pixels of the screen do not light up

•The LCD display panel is manufactured using an

extremely high level of precision technology; however,

sometimes some pixels of the screen may be missing

picture elements or have luminous spots. This is not a sign

of malfunction.

The picture brightness varies when you switch the

TV on.

• If you switch the TV on at 0°C and under, wait until it

warms up.

The screen’s brightness decreases, flicker occurs,

or some parts of the screen do not light up.

• When first start to use this TV, flickering may occur on the

screen. In this case, switch off the TV, and then switch on

it again to resolve this issue.

• The cold cathode fluorescent lamp used for the back light

on this TV has a certain lifespan. When the brightness of

the screen decreases, flickers on the screen occur, or some

parts of the screen do not light up, it may have reached the

end of its life. Contact a service technician.

No REGZA-LINK operation

• The REGZA-LINK feature is available for Toshiba

REGZA-LINK compatible devices.

• Make sure HDMI cables with the HDMI logo are used.

• When connected REGZA-LINK device does not work

correctly after you have changed device settings, turn off

your TV and unplug the power cord. Then plug in and turn

on again.

•If several devices are connected, the REGZA-LINK

feature may not operate properly.

• Read the owner’s manual furnished with the connected

REGZA-LINK device.

Symptom and solution - digital only -

Poor picture

• Check the aerial connections. Make sure it is aligned to

the correct broadcast direction.

• Check the signal level and quality in the DTV Manual

Tuning menu.

•If you use any kind of amplifier to boost the signal level,

check whether it is working correctly, and ask for help

from the aerial installer.

No picture

•Use the DTV Manual Tuning menu to rescan this

channel.

•Try another channel.

•Reduce RF amplifier gain if connected to RF booster.

No sound from DIGITAL AUDIO

•The sound may be muted. Press 2 +, 2 - or U.

•Use the DTV Manual Tuning menu to rescan this

channel.

•Try another channel.

Not all channels are available after Auto Tuning

when tuning the TV for the first time.

•This symptom is caused by unexpected frequency offset.

•Use the DTV Manual Tuning menu to scan for the

missing channels. Once the TV picks up the signal, all the

transmission parameters will be stored in internal

memory.

Cannot lock signal when using Manual Tuning

• Refer to the solutions for “Poor picture”.

No Teletext, no Subtitles

• Make sure the channel that you are watching carries

Teletext/Subtitles information by checking the on-screen

information.

Cannot receive channels after moving the TV

between cities (e.g. from Melbourne to Sydney)

• Refer to page 12 to reset data.

Programme Timer does not operate properly.

• Check the aerial connections.

• Weak signal may cause inaccurate time information.

Do not remember PIN

• Please contact your local dealer.

Asia_4246XV550A.book Page 39 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Reference section

APPENDIX

AUSTRALIAN PARENTAL GUIDANCE CODES (Normative)

Recommended On-Screen-Display for parental guidance codes transmitted within DVB-SI EIT information using the DVB

parental_rating_descriptor.

Receiver Menu Set-up and Suggested OSD wording

for Setting Blocking (Restriction of access)

Resultant receiver action to received hex code

is show programme - is block until PIN entered

Block All

Transmitted

rating

hex code

Australian

parental guide

code

Not Classified

P Pre school

C Children's

G General

Parental Guidance

Recommended

M Mature

Audience 15+

R Restricted 18+

MA Mature Adult

Audience 15+

AV Adult

Audience,

Strong violence

15+

On-Screen-

Display

Block G

and above

(optional)

Block

PG and

above

Block

MA and

above

Block

M and

above

Block

AV and

above

Block

R and

above No Block

Asia_4246XV550A.book Page 40 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Reference section

Broadcast system

Broadcast transmission systems of each

country or region

Asia M.E.

Oceania

Africa

South America

Note:

PAL, SECAM and NTSC 3.58 (MHz) are different colour signal

broadcast transmission systems applicable to different

countries or region. NTSC 4.43 (MHz) is used in special VCRs

to playback NTSC recorded video tapes through PAL

television equipment.

Specifications

Integrated Digital LCD TV

Model

42XV550A,560A, 46XV550A,560A

Power source

220 V-240 V AC, 50 Hz

Power consumption

42XV550A,560A: 221 W, 0.9 W (standby)

46XV550A,560A: 286 W, 0.9 W (standby)

Dimensions

42XV550A,560A: 1,009 mm (W) 689 mm (H) 264 mm (D)

46XV550A,560A: 1,108 mm (W) 746 mm (H) 308 mm (D)

Mass (Weight)

42XV550A,560A: **.* kg

46XV550A,560A: **.* kg

Analogue TV system (Aerial input)

Channel coverage:

Special RF signal:

Digital TV System

Compliant Standard DVB-T

Video DecodingMP @ ML & MP @ HL

Audio DecodingDolby® Digital, MPEG (I & II)

Audio Sampling Rate 32, 44.1, 48 kHz

Digital TV Terrestrial Tuner / Demodulator

Frequency51~858 MHz

Loop Through 51~858 MHz

Bandwidth 6, 7, 8 MHz

Demodulator COFDM

FFT Mode 2K, 8K

Constellation QPSK, 16QAM, 64 QAM

Guard Interval 1/4, 1/8, 1/16, 1/32

Inner Coding Rate 1/2, 2/3, 3/4, 5/6, 7/8

COMPONENT VIDEO INPUT terminals (the signal

format)

480i, 480p, 576i, 576p, 720p (50/60 Hz), 1080i (50/60 Hz)

(These signal formats are converted to match the number of

pixels of the LCD panel.)

Colour system (analogue TV system)

PAL, SECAM, NTSC 3.58/4.43

Aspect ratio

16 : 9

Visible size (diagonal)

42XV550A,560A: * cm

46XV550A,560A: * cm

Country or region Colour Sound

Bahrain, Kuwait, Israel, Oman,

Qatar, United Arab Emirates,

Yemen, etc. Indonesia, Malaysia,

Singapore, Thailand, etc.

PAL B/G

China PAL D/K

China Hong KongPAL I

Iraq, Islamic Republic of Iran,

Lebanon, Saudi Arabia, etc. SECAM B/G

Russian Federation, etc. SECAM D/K

Myanmar, etc. NTSC M

Country or region Colour Sound

Australia, New Zealand, etc. PAL B/G

Country or region Colour Sound

Republic of South Africa, etc. PAL I

Country or region Colour Sound

Argentina, Paraguay, Uruguay, etc. PAL N

Brazil PAL M

Chile, Colombia, etc. NTSC M

PAL B/G (CCIR) VHF 2 - 12

UHF 21 - 69

CATVX - Z+2, S1 - S41

PAL I (UK) VHF -

UHF 21 - 69

CATV-

PAL D/K (CHINA) VHF 1 - 12

UHF 13 - 57

CATVZ1 - Z38

SECAM B/G (CCIR) VHF 2 - 12

UHF 21 - 69

CATVX - Z+2, S1 - S41

SECAM D/K (OIRT) VHF 1 - 12

UHF 21 - 69

CATVX1 - X19

NTSC 4.43 colour system 5.5/6.0/6.5 MHz sound system

PAL 60 Hz colour system 5.5/6.0/6.5 MHz sound system

Asia_4246XV550A.book Page 41 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Reference section

Number of pixels

1,920 (H) dots 5 1,080 (V) dots

Audio power

10 W + 10 W (10 % THD)

Speakers

Main: 35 5 160 mm 2 pcs.

Input/Output terminals

Operating condition

Temperature 0 °C - 35 °C

Humidity20 % - 80 % (No moisture condensation)

Supplied accessories

Owner’s manual (1), Remote control (1), Batteries (2),

Clip (1), Cleaning cloth (1)

This is used to fix the TV to a wall, pillar, etc. (- page 4).

•Design and specifications are subject to change without

notice.

•Never service or remodel the TV by yourself. It may expose

you to a fire hazard or dangerous voltages.

o (1) Input

Phono jacks A/V

o (2) Input

4 pin S-video

Phono jacks A/V

o (3) Input

Component video Y, PB/CB, PR/CR

Phono jacks Audio

L/Mono+R

o (4) Input

Component video Y, PB/CB, PR/CR

Phono jacks Audio

L/Mono+R

O MONITOR Output

Phono jacks A/V

o RGB/PC Input

Mini D-sub 15 pin Analogue RGB

o PC/HDMI1

(AUDIO) Input

3.5 mm (Diameter) stereo

o HDMI1 Input (type A)

19 pin A/V Digital

o HDMI2 Input (type A)

19 pin A/V Digital

o HDMI3 Input (type A)

19 pin A/V Digital

o HDMI4 Input (type A)

19 pin A/V Digital

(v.1.3a with Lip Sync, Deep Colour

and x.v.Colour)

O Digital Audio

(optical)

Output

Bitstream/PCM

Headphone jack 3.5 mm (Diameter) stereo

Asia_4246XV550A.book Page 42 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

License Information used with Toshiba Televisions

Information

The software pre-installed in TOSHIBA Digital Televisions consists of multiple, independent software components. Each

software component is copyrighted by TOSHIBA or a third party.

The TOSHIBA Digital Television uses software components that are distributed as freeware under a third-party end-user

license agreement or copyright notice (hereinafter referred to as a “EULA”). Some EULAs require that the source code of the

applicable component be disclosed as the condition for distributing the software component in executable format.

You can check the software components subject to such EULA requirements on the following Home Page:

URL: http://tesc.toshiba.co.uk/Web/Website.nsf/ContentFrameSet?OpenFrameset

In addition, some of the software components which are used in TOSHIBA Digital Televisions include the software that are

made or developed originally by Toshiba. These software and accompanied documents are copyrighted by TOSHIBA, and

protected by Copyright Act, an international treaty’s articles and other governing laws.

The software components which are made or developed originally by TOSHIBA and not subject to EULAs are not a target of

source code offering.

TOSHIBA provides a warranty for the TOSHIBA Digital Television you have purchased under conditions set forth by

TOSHIBA.However, some of the software components distributed under an EULA are made available for use by the user on the

assumption that they are not copyrighted or warranted by TOSHIBA or any third party. These software components are licensed

to the user free of charge and therefore are not covered by a warranty within the scope of the applicable laws. These software

components are not subject to any copyrights or other third-party rights and are provided in “as is” condition without any warranty,

whether express or implied. “Warranty” here includes, but not limited to, an implied warranty for marketability or fitness for

specific uses. All risks associated with the quality or performance of these software components are assumed by the user.

TOSHIBA shall not be liable whatsoever for any cost of repair or correction or other incidental expense incurred in connection

with a defect found in any of these software components. Unless specified under the applicable laws or in a written agreement, a

party who changes or redistributes the software with consent from the copyright holders or based on the aforementioned licenses

shall not be held liable whatsoever for any loss arising from the use of or inability to use such software. The same applies even

when the copyright holders or relevant third parties have been informed of the possibility of such loss. “Loss” here includes normal,

special, incidental and indirect loss (including, but not limited to, the loss of data or its accuracy; loss incurred by the user or any

third party; and interface incompatibility with other software). Please read each EULA for details on the use conditions and items

that must be observed regarding these software components.

The table below lists the software components pre-installed in TOSHIBA Digital Televisions, which are subject to EULAs.

The user should read the applicable EULAs carefully before using these software components. The EULAs are exhibited in their

original text (English) as exactly written by the respective parties other than TOSHIBA.

Pre-Installed Software EULA

Linux Kernel

busybox Exhibit A

glibc

gcc Exhibit B

malloc Exhibit C

JPEG Exhibit D

FreeType Exhibit E

ICU Exhibit F

Asia_4246XV550A.book Page 43 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Exhibit A

GNU GENERAL PUBLIC LICENSE Version 2, June 1991

59 Temple Place, Suite 330, Boston, MA 02111-1307 USA

Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public

License is intended to guarantee your freedom to share and change free software – to make sure the software is free for all its users.

This General Public License applies to most of the Free Software Foundation’s software and to any other program whose authors

commit to using it. (Some other Free Software Foundation software is covered by the GNU Library General Public License

instead.) You can apply it your programs, too.

When we speak of free software, we are referring to freedom, not price. Our General Public Licenses are designed to make sure

that you have the freedom to distribute copies of the free software (and charge for this service if you wish), that you receive source

code or can get it if you want it, that you can change the software or use pieces of it in new free programs; and that you know you

can do these things.

To protect your rights, we need to make restrictions that forbid anyone to deny you these rights or to ask you to surrender the

rights. These restrictions translate to certain responsibilities for you if you distribute copies of the software, or if you modify it.

For example, if you distribute copies of such a program, whether gratis or for a fee, you must give the recipients all the rights

you have. You must make sure that they too, receive or can get the source code. Also you must show them these terms so they

know their rights.

We protect your right with two steps: (1) copyright the software, and (2) offer you this license which gives you legal permission

to copy, distribute and/or modify the software.

Also, for each author’s protection and ours, we want to make certain that everyone understands that there is no warranty for

this free software. If the software is modified by someone else and passed on, we want its recipients to know that what they have

is not the original, so that any problems introduced by others will not reflect on the original authors’ reputations.

Finally, any free program is threatened constantly by software patents. We wish to avoid the danger that redistributors of a free

program will individually obtain patent license, in effect making the program proprietary. To prevent this, we have made it clear

that any patent must be licensed for everyone’s free use or not licensed at all.

The precise terms and conditions for copying, distribution and modification follow.

GNU GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING,

DISTRIBUTION AND MODIFICATION

0. This license applies to any program or other work which contains a notice placed by the copyright holder saying it may be

distributed under the terms of this General Public License. The “Program”, below, refers to any such program or work, and a

“work based on the Program” means either the program or any derivative work under copyright law: that is to say, a work

containing the Program or a portion of it, either verbatim or with modifications and/or translated into another language.

(Hereinafter, translation is included without limitation in the terms “modification”.) Each licensee is addressed as “you”.

Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The

act of running the program is not restricted, and the output from the Program is covered only if its contents constitute a work

based on the Program (independent of having been made by running the program). Whether that is true depends on what the

Program does.

1. You may copy and distribute verbatim copies of the Program’s source code as you receive it, in any medium, provided that

you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of warranty; keep

intact all notices that refer to this License and to the absence of any warranty; and give any other recipients of the Program a

copy of this License along with the Program.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in

exchange for a fee.

Asia_4246XV550A.book Page 44 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

2. You may modify your copy or copies of the program or any portion of it, thus forming a work based on the program, and copy

and distribute such modifications or work under the terms of Section 1 above, provided that you also meet all of these

condition:

a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of any

change.

b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program,

or any part there of, to be licensed as a whole at no charge to all third parties under the terms of the this License.

c) If the modified Program normally reads commands interactively when run, you must cause it, when started running for

such interactive use in the most ordinary way, to print or display an announcement including an appropriate copyright

notice and a notice that there is no warranty (or else, saying that you provide a warranty) and that users may redistribute

the program under these conditions, and telling the user how to view a copy of this License. (Exception: if the program

itself is interactive but does not normally print such an announcement, your work based on the program is not required

to print such an announcement.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the

program, and can be reasonably considered independent and separate works in themselves, then this License, and its terms,

do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part

of a whole which is a work based on the Program, the distribution of the whole must be on terms of this License, whose

permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent

is to exercise the right to control the distribution of derivative and collective works based on the Program.

In addition, mere aggregation of another work not based on the Program with the Program (or with a work based on the

Program) on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

3. You may copy and distribute the program (or a work based on it, under Section 2) in object code or executable form under

the terms of Sections 1 and 2 above provided that you also do one of the following:

a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the

terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,

b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your

cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code,

to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange; or,

c) Accompany it with the information you received as to the offer to distribute corresponding source code. (This

alternative is allowed only for noncommercial distribution and only if you received the program in object code or

executable form with such an offer, in accord with subsection b above.)

The source code for a work means the preferred form of the work for making modifications to it. For an executable work,

complete source code means all the source code for all modules it contains, plus any associated interface definition files, plus

the scripts used to control compilation and installation of the executable. However, as a special exception, the source code

distributes need not include anything that is normally distributed (in either source or binary form) with the major components

(compiler, kernel, and so on) of the operating system on which the executable runs, unless that component itself accompanies

the executable.

If distribution of executable or object code is made by offering access to copy from a designated place, then offering

equivalent access to copy the source code from the same place counts as distribution of the source code, even though third

parties are not compelled to copy the source along with the object code.

4. You many not copy, modify, sublicense, or distribute the program except as expressly provided under this License. Any

attempt otherwise to copy, modify, sublicense or distribute the Program is void, and will automatically terminate your rights

under this License. However, parties who have received copies, or rights, from you under this License will not have their

licenses terminated so long as such parties remain in full compliance.

5. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to

modify or distribute the Program or its derivative works. These actions are prohibited by law if you do not accept this License.

Therefore, by modifying and distributing the Program (or any works based on the Program), you indicate your acceptance of

this License to do so, and all its terms and conditions for copying, distributing or modifying the Program or works based on it.

6. Each time you redistribute the Program (or any works based on the Program), the recipient automatically receives a License

from the original licensor to copy, distribute or modify the Program subject to these terms and conditions. You may not

impose any further restrictions on the recipient’s exercise of the rights granted herein. You are not responsible for enforcing

compliance by third parties to this License.

Asia_4246XV550A.book Page 45 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

7. If as a consequence of a court judgement or allegation of patent infringement or for any other reason (not limited to patent

issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradicts the conditions of the

License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy simultaneously

your obligations under this License and any other pertinent obligations, then as a consequence you may not distribute the

Program at all.

For example, if a patent license would not permit royalty-free redistribution of the Program by all those who receive copies

directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely

from distribution of the Program. If any portion of this section is held invalid or unenforcable under any particular

circumstances, the balance of the section is intended to apply and the section as a whole is intended to apply in other

circumstances. It is not the purpose of this section to induce you to infringe any patent to other property right claims or to

contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution

system, which is implemented by public license practices. Many people have made generous contributions to the wide range

of software distributed through that system in reliance upon consistent application of that system; it is up to the author/donor

to decide if he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

8. If the distribution and/or use of the program is restricted in certain countries either by patents or by copyrighted interfaces,

the original copyright holder who places the Program under this License may add an explicit geographical distribution

limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded. In such

case, this License incorporates the limitation as if written in the body of this License.

9. The Free Software Foundation may publish revised and/or new versions of the general Public License from time to time. Such

new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.

Each version is given a distinguishing version number. If the Program specifies a version number of this License which

applies to it and “any later version”, you have the option of following the terms and conditions either of that version or of any

later version published by the Free Software Foundation. If the Program does not specify a version number of this License,

you may choose any version ever published by the Free Software Foundation.

10. If you wish to incorporate parts of the Program into other free programs whose distribution conditions are different, write to

the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free

Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the

free status of all derivatives of our free software and of promoting the sharing and use of software generally.

NO WARRANTY

11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM,

TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE

OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS

TO THE QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH YOU, SHOULD THE PROGRAM PROVE

DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

12. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY

AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL,

INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE

PROGRAM (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE

OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE PROGRAM TO OPERATE WITH

ANY OTHER PROGRAMS), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS

Asia_4246XV550A.book Page 46 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

How to Apply These Terms to Your New Programs

If you develop a new program, and you want it be of the greatest possible use to the public, the best way to achieve this is to make

it free software which everyone can redistribute and change under these terms.

To do so, attach the following notices to the program. It is safest to attach them to the start of each source file to most effectively

convey the exclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full notice is

found.

This program is free software; you can redistribute it and/or modify is under the terms of the GNU General Public License

as published by the Free Software Foundation; either version 2 of the License, or (at your option) any later version.

This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the

implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General

Public License for more details.

You should have received a copy of the GNU General Public License along with this program; if not, write to the Free

Software Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA

02111-1307 USA.

Also add information on how to contact you by electronic and paper mail.

If the program is interactive, make it output a short notice like this when it starts in an interactive mode.

WARRANTY; for details type "show w". This is free software, and you are welcome to redistribute it under certain

conditions; type "show c" for details.

The hypothetical commands "show w" and "show c" should show the appropriate parts of the General Public License. Of course,

the commands you use may be called something other than "show w" and "show c"; they could even be mouse-clicks or menu

items – whatever suits your program.

You should also get your employer (if you works as a programmer) or your school, if any, to sign a "copyright disclaimer" for the

program; if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright interest in the 'Gnomovision' (which makes passes at compilers) written

by James Hacker.

<signature of Ty Coon>, 1 April 1989

Ty Coon, President of Vice

This General Public License does not permit incorporating your program into proprietary programs. If your program is a subroutine

library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do,

use the GNU Library General Public License instead of this License.

Asia_4246XV550A.book Page 47 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Exhibit B

GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999

59 Temple Place, Suite 330, Boston, MA 02111-1307 USA

Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed.

[This is the first released version of the Lesser GPL. It also counts as the successor of the GNU Library Public License, version 2,

hence the version number 2.1.]

Preamble

The licenses for most software are designed to take away your freedom to share and change it. By contrast, the GNU General Public

Licenses are intended to guarantee your freedom to share and change free software – to make sure the software is free for all its

users.

This License, the Lesser General Public License, applies to some specially designated software packages – typically libraries

– of the Free Software Foundation and other authors who decide to use it. You can use it too, but we suggest you first think carefully

about whether this license or the ordinary General Public License is the better strategy to use in any particular case, based on the

explanations below.

When we speak of free software, we are referring to freedom of use, not price. Our General Public Licenses are designed to

make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish); that you receive

source code or can get it if you want it; that you can change the software or use pieces of it in new free programs; and that you are

informed that you can do these things.

To protect your rights, we need to make restrictions that forbid distributors to deny you these rights or to ask you to surrender

these rights. These restrictions translate to certain responsibilities for you if you distribute copies of the library or if you modify it.

For example, if you distribute copies of the library, whether gratis or for a fee, you must give the recipients all the rights that

we gave you. You must make sure that they, too, receive or can get the source code. If you link other code with the library, you

must provide complete object files to the recipients, so that they can link them with the library after making changes to the library

and recompiling it. Also you must show them these terms so they know their rights.

We protect your rights with a two step method: (1) we copyright the library, and (2) we offer you this license which gives you

legal permission to copy, distribute and/or modify the library.

To protect each distributor, we want to make it very clear that there is no warranty for the free library. Also, if the library is

modified by someone else and passed on, the recipients should know that what they have is not the original version, so that original

authors’ reputation will not be affected by problems that might be introduced by others.

Finally, software patents pose a constant threat to the existence of any free program. We wish to make sure that a company

cannot effectively restrict the users of a free program by obtaining a restrictive license from a patent holder. Therefore, we insist

that any patent license obtained for a version of the library must be consistent with the full freedom of use specified in this license.

Most GNU software, including some libraries, is covered by the ordinary GNU General Public License. This license, the GNU

Lesser General Public License, applies to certain designated libraries, and is quite different from the ordinary General Public

License. We use this license for certain libraries in order to permit linking those libraries into non-free programs.

When a program is linked with a library, whether statically or using a shared library, the combination of the two is legally

speaking a combined work, a derivative of the original library. The ordinary General Public License therefore permits such linking

only if the entire combination fits its criteria of freedom. The Lesser General Public License permits more lax criteria for linking

other code with the library.

We call this license the "Lesser" General Public License because it does Less to protect the user’s freedom than the ordinary

General Public License. It also provides other free software developers Less of an advantage over competing non-free programs.

These disadvantages are the reason we use the ordinary General Public License for many libraries. However, the Lesser license

provides advantages in certain special circumstances.

For example, on rare occasions, there may be a special need to encourage the widest possible use of a certain library, so that it

becomes a de-facto standard. To achieve this, non-free programs must be allowed to use the library. A more frequent case is that

a free library does the same job as widely used non-free libraries. In this case, there is little to gain by limiting the free library to

free software only, so we use the Lesser General Public License.

In other cases, permission to use a particular library in non-free programs enables a greater number of people to use a large

body of free software. For example, permission to use the GNU C Library in non-free programs enables many more people to use

the whole GNU operating system, as well as its variant, the GNU/Linux operating system.

Asia_4246XV550A.book Page 48 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Although the Lesser General Public License is Less protective of the users’ freedom, it does ensure that the user of a program

that is linked with the Library has the freedom and the wherewithal to run that program using a modified version of the Library.

The precise terms and conditions for copying, distribution and modification follow. Pay close attention to the difference

between a "work based on the library" and a "work that uses the library". The former contains code derived from the library,

whereas the latter must be combined with the library in order to run.

GNU LESSER GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING,

DISTRIBUTION AND MODIFICATION

0. This License Agreement applies to any software library or other program which contains a notice placed by the copyright

holder or other authorised party saying it may be distributed under the terms of this Lesser General Public License (also called

"this License"). Each licensee is addressed as “you”.

A "library" means a collection of software functions and/or data prepared so as to be conveniently linked with application

programs (which use some of those functions and data) to form executables.

The “Library”, below, refers to any such software library or work which has been distributed under these terms. A “work

based on the library” means either the Library or any derivative work under copyright law: that is to say, a work containing

the Library or a portion of it, either verbatim or with modifications and/or translated straightforwardly into another language.

(Hereinafter, translation is included without limitation in the terms “modification”.)

Each licensee is addressed as “you”.

"Source code" for a work means the preferred form of the work for making modifications to it. For a library, complete source

code means all source code for all modules it contains, plus any associated interface definition files, plus the scripts used to

control compilation and installation of the library.

Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The

act of running a program using a library is not restricted, and output from such a program is covered only if its contents

constitute a work based on the Library (independent of the use of the Library in a tool for writing it). Whether that is true

depends on what the Library does and what the program that uses the Library does.

1. You may copy and distribute verbatim copies of the Library’s complete source code as you receive it, in any medium,

provided that you conspicuously and appropriately publish on each copy an appropriate copyright notice and disclaimer of

warranty; keep intact all notices that refer to this License and to the absence of any warranty; and distribute a copy of this

License along with the Library.

You may charge a fee for the physical act of transferring a copy, and you may at your option offer warranty protection in

exchange for a fee.

2. You may modify your copy or copies of the program or any portion of it, thus forming a work based on the Library, and copy

and distribute such modifications or work under the terms of Section 1 above, provided that you also meet all of these

condition:

a) The modified work must itself be a software library.

b) You must cause the files modified to carry prominent notices stating that you changed the files and the date of any

change.

c) You must cause the whole of the work to be licensed at no charge to all third parties under the terms of this License.

c) If a facility in the modified Library refers to a function or a table of data to be supplied by an application program that

uses the facility, other than as an argument passed when the facility is invoked, then you must make a good faith effort

to ensure that, in the event an application does not supply such function or table, the facility still operates, and performs

whatever part of its purpose remains meaningful.

(For example, a function in a library to compute square roots has a purpose that is entirely well-defined independent of

the application. Therefore, Subsection 2d requires that any application-supplied function or table used by this function

must be optional: if the application does not supply it, the square root function must still compute square roots.)

These requirements apply to the modified work as a whole. If identifiable sections of that work are not derived from the

Library, and can be reasonably considered independent and separate works in themselves, then this License, and its terms, do

not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of

a whole which is a work based on the Library, the distribution of the whole must be on terms of this License, whose

permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.

Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent

is to exercise the right to control the distribution of derivative and collective works based on the Library.

In addition, mere aggregation of another work not based on the Library with the Library (or with a work based on the Library)

on a volume of a storage or distribution medium does not bring the other work under the scope of this License.

3. You may opt to apply the terms of the ordinary GNU General Public License instead of this License to a given copy of the

Library. To do this, you must alter all the notices that refer to this License, so that they refer to the ordinary GNU General

Public License, version 2, instead of to this License. (If a newer version than version 2 of the ordinary GNU General Public

License has appeared, then you can specify that version instead if you wish.) Do not make any other change in these notices.

Asia_4246XV550A.book Page 49 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Once this change is made in a given copy, it is irreversible for that copy, so the ordinary GNU General Public License applies

to all subsequent copies and derivative works made from that copy.

This option is useful when you wish to copy part of the code of the Library into a program that is not a Library.

4. You may copy and distribute the Library (or a portion or derivative of it, under Section 2) in object code or executable form

under the Sections 1 and 2 above provided that you accompany it with the complete corresponding machine readable source

code, which must be distributed under the terms of sections 1 and 2 above on a medium customarily used for software

interchange.

If distribution of object code is made by offering access to copy from a designated place, then offering equivalent access to

copy the source code from the same place satisfies the requirement to distribute the source code, even though third parties are

not compelled to copy the source along with the object code.

5. A program that contains no derivative of any portion of the Library, but is designed to work with the library by being compiled

or linked with it, is called a "work that uses the Library". Such a work, in isolation, is not a derivative work of the Library,

and therefore falls outside the scope of this License.

However, linking "work that uses the Library" with the Library creates an executable that is a derivative of the Library

(because it contains portions of the Library), rather than a "work that uses the Library". The executable is therefore covered

by this License. Section 6 states terms for distribution of such executables.

When a "work that uses the Library" uses material from a header file that is part of the Library, the object code for the work

may be a derivative work of the Library even though the source code is not. Whether this is true is especially significant if

the work can be linked without the Library, or if the work is itself a library. The threshold for this to be true is not precisely

defined by law.

If such an object file uses only numerical parameters, data structure layouts and accessors, and small macros and small inline

functions (ten lines or less in length), then the use of the object file is unrestricted, regardless of whether it is legally a

derivative work. (Executables containing this object code plus portions of the Library will still fall under Section 6.)

Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of Section

6. Any executables containing that work also fall under Section 6, whether or not they are linked directly with the Library

itself.

6. As an exception to the Sections above, you may also combine or link a "work that uses the Library" with the Library to

produce a work containing portions of the Library, and distribute that work under terms of your choice, provided that the terms

permit modification of the work for the customer’s own use and reverse engineering for debugging such modifications.

You must give prominent notice with each copy of the work that the Library is used in it and that the Library and its use are

covered by the License. You must supply a copy of this License. If the work during execution displays copyright notices, you

must include the copyright notice for the Library among them, as well as a reference directing the user to the copy of this

License. Also, you must do one of these things:

a) Accompany the work with the complete corresponding machine-readable source code for the Library including

whatever changes were used in the work (which must be distributed under Sections 1 and 2 above); and, if the work is

an executable linked with the Library, with the complete machine-readable "work that uses the Library", as object code

and/or source code, so that the user can modify the Library and then relink to produce a modified executable containing

the modified Library. (It is understood that the user who changes the contents of definitions files in the Library will not

necessarily be able to recompile the application to use the modified definitions.)

b) Use a suitable shared library mechanism for linking the Library. A suitable mechanism is one that (1) uses at run time

a copy of the library already present on the user’s computer system, rather than copying library functions into the

executable, and (2) will operate properly with a modified version of the library, if the user installs one, as long as the

modified version is interface-compatible with the version that the work was made with.

c) Accompany the work with a written offer, valid for at least three years, to give the same user the materials specified in

Subsection 6a, above, for a charge no more than the cost of performing this distribution.

d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy

the above specified materials from the same place.

e) Verify that the user has already received a copy of these materials or that you have already sent this user a copy.

For an executable, the required form of the "work that uses the Library" must include any data and utility programs needed

for reproducing the executable from it. However, as a special exception, the materials to be distributed need not include

anything that is normally distributed (in either source or binary form) with the major components (compiler, kernel, and so

on) of the operating system on which the executable runs, unless that component itself accompanies the executable.

It may happen that this requirement contradicts the license restrictions of other proprietary libraries that do not normally

accompany the operating system. Such a contradiction means that you cannot use both them and the Library together in an

executable that you distribute.

7. You may place library facilities that are a work based on the Library side-by-side in a single library together with other library

facilities not covered by this License, and distribute such a combined library, provided that the separate distribution of the

work based on the Library and of the other library facilities is otherwise permitted, and provided that you do these two things:

a) Accompany the combined library with a copy of the same work based on the Library, uncombined with any other library

facilities. This must be distributed under the terms of the Sections above.

Asia_4246XV550A.book Page 50 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

b) Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and explaining

where to find the accompanying uncombined form of the same work.

8. You many not copy, modify, sublicense, link with or distribute the Library except as expressly provided under this License.

Any attempt otherwise to copy, modify, sublicense, link with, or distribute the Library is void, and will automatically

terminate your rights under this License. However, parties who have received copies, or rights, from you under this License

will not have their licenses terminated so long as such parties remain in full compliance.

9. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to

modify or distribute the Library or its derivative works. These actions are prohibited by law if you do not accept this License.

Therefore, by modifying and distributing the Library (or any works based on the Library), you indicate your acceptance of

the License to do so, and all its terms and conditions for copying, distributing or modifying the Library or works based on it.

10. Each time you redistribute the Library (or any works based on the Library), the recipient automatically receives a License

from the original licensor to copy, distribute, link with or modify the Library subject to these terms and conditions. You may

not impose any further restrictions on the recipient’s exercise of the rights granted herein. You are not responsible for

enforcing compliance by third parties with this License.

11. If, as a consequence of a court judgement or allegation of patent infringement or for any other reason (not limited to patent

issues), conditions are imposed on you (whether by court order, agreement or otherwise) that contradicts the conditions of

this License, they do not excuse you from the conditions of this License. If you cannot distribute so as to satisfy

simultaneously your obligations under this License and any other pertinent obligations, then as a consequence you may not

distribute the Library at all. For example, if a patent license would not permit royalty-free redistribution of the Library by all

those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would

be to refrain entirely from distribution of the Library.

If any portion of this section is held invalid or unenforcable under any particular circumstances, the balance of the section is

intended to apply and the section as a whole is intended to apply in other circumstances.

It is not the purpose of this section to induce you to infringe any patents to other property right claims or to contest validity

of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system which

is implemented by public license practices. Many people have made generous contributions to the wide range of software

distributed through that system in reliance upon consistent application of that system; it is up to the author/donor to decide if

he or she is willing to distribute software through any other system and a licensee cannot impose that choice.

This section is intended to make thoroughly clear what is believed to be a consequence of the rest of this License.

12. If the distribution and/or use of the program is restricted in certain countries either by patents or by copyrighted interfaces,

the original copyright holder who places the Library under this License may add an explicit geographical distribution

limitation excluding those countries, so that distribution is permitted only in or among countries not thus excluded. In such

case, this License incorporates the limitation as if written in the body of this License.

13. The Free Software Foundation may publish revised and/or new versions of the Lesser General Public License from time to

time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or

concerns. Each version is given a distinguishing version number. If the Library specifies a version number of this License

which applies to it and “any later version”, you have the option of following the terms and conditions either of that version

or of any later version published by the Free Software Foundation. If the Library does not specify a license version number,

you may choose any version ever published by the Free Software Foundation.

14. If you wish to incorporate parts of the Library into other free programs whose distribution conditions are incompatible with

these, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to

the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of

preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.

NO WARRANTY

15. BECAUSE THE LIBRARY IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE LIBRARY, TO

THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE

ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS

TO THE QUALITY AND PERFORMANCE OF THE LIBRARY IS WITH YOU. SHOULD THE LIBRARY PROVE

DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION.

Asia_4246XV550A.book Page 51 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

16. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY

AS PERMITTED ABOVE, BE LIABLE TO YOU FOR DAMAGES, INCLUDING ANY GENERAL, SPECIAL,

INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE

LIBRARY (INCLUDING BUT NOT LIMITED TO LOSS OF DATA OR DATA BEING RENDERED INACCURATE OR

LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE LIBRARY TO OPERATE WITH ANY

OTHER SOFTWARE), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY

OF SUCH DAMAGES.

END OF TERMS AND CONDITIONS

How to Apply These Terms to Your New Libraries

If you develop a new library, and you want it be of the greatest possible use to the public, we recommend making it free software

that everyone can redistribute and change. You can do so by permitting redistribution under these terms (or, alternatively, under

the terms of the ordinary General Public License).

To apply these terms, attach the following notices to the library. It is safest to attach them to the start of each source file to most

effectively convey the exclusion of warranty; and each file should have at least the “copyright” line and a pointer to where the full

notice is found.

This library is free software; you can redistribute it and/or modify is under the terms of the GNU Lesser General Public

License as published by the Free Software Foundation; either version 2 of the License, or (at your option) any later

version.

This library is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied

warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU Lesser General

Public License for more details.

You should have received a copy of the GNU Lesser General Public License along with this library; if not, write to the

Free Software Foundation, Inc., 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA.

Also add any information on how to contact you by electronic and paper mail.

You should also get your employer (if you works as a programmer) or your school, if any, to sign a "copyright disclaimer" for the

library, if necessary. Here is a sample; alter the names:

Yoyodyne, Inc., hereby disclaims all copyright interest in the library 'Frob' (a library for tweaking knobs) written by

James Random Hacker.

<signature of Ty Coon>, 1 April 1990

Ty Coon, President of Vice

That’s all there is to it!

Exhibit C

This is a version (aka dlmalloc) of malloc/free/realloc written by Doug Lea and released to the public domain. Use, modify, and

redistribute this code without permission or acknowledgement in any way you wish. Send questions, comments, complaints,

performance data, etc to dl@cs.oswego.edu

* VERSION 2.7.2 Sat Aug 17 09:07:30 2002 Doug Lea (dl at gee)

NOTE:

There may be an updated version of this malloc obtainable at ftp://gee.cs.oswego.edu/pub/misc/malloc.c

Check before installing!

Asia_4246XV550A.book Page 52 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

Exhibit D

This software is based in part on the work of the Independent JPEG Group.

Exhibit E

Exhibit F

ICU License - ICU 1.8.1 and later

Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files

(the "Software"), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge,

publish, distribute, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, provided

that the above copyright notice(s) and this permission notice appear in all copies of the Software and that both the above copyright

notice(s) and this permission notice appear in supporting documentation.

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING

BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND

NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS

INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL

DAMAGES, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER

IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN

CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

Except as contained in this notice, the name of a copyright holder shall not be used in advertising or otherwise to promote the sale,

use or other dealings in this Software without prior written authorization of the copyright holder.

ICU License - ICU 1.8.1 and later

THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING

BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND

NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL THE COPYRIGHT HOLDER OR HOLDERS

INCLUDED IN THIS NOTICE BE LIABLE FOR ANY CLAIM, OR ANY SPECIAL INDIRECT OR CONSEQUENTIAL

DAMAGES, OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER

IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN

CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

Asia_4246XV550A.book Page 53 Tuesday, September 16, 2008 3:03 PM

Toshiba 42/46XV550A

YC/J

Asia_4246XV550A.book Page 54 Tuesday, September 16, 2008 3:03 PM

Toshiba 42Xv550A 560A Users Manual

Navigation menu

Versions of this User Manual:

Views

Navigation
