HOME CINEMA CATALOGUE 2005-6
TELEVISION PLASMA LCD DVD
Ref: CPBRO2005Eu
This brochure was produced using paper
from a sustainable resource
Toshiba Information Systems (U.K.) Ltd.
Consumer Products Division
Toshiba Court
Weybridge Business Park
Addlestone Road, Weybridge
Surrey. KT15 2UL, U.K.
www.toshiba.co.uk
2
We take great care in manufacturing
our products and pride ourselves on our
quality. That’s why we believe in providing
high levels of customer care, service and
after sales support.
Click on to our website:
www.toshiba.co.uk
Here you will find all the information
you need to help you choose a Toshiba
product, including a product comparison
tool, latest award winners and in-store
offers. You can also download brochures
and user manuals, find your nearest
stockist or register a new product.
Home entertainment products are
accessories designed to complement
and enhance your environment, both
passively and interactively. They are
tools with which you can define your
personality and express your individuality.
They may be dominant or discreet,
blatantly stimulating or subtly enhancing.
Our range reflects this, with a wide
selection of screen shapes and sizes,
from impressive flat panel displays to
compact TV combinations, from versatile
DVD recorders to dynamic portable
music players. Whatever you choose,
Toshiba’s experience will ensure that
you enjoy a superb performance and
truly memorable home entertainment.
Toshiba is a global company with
expertise in a wide variety of fields.
From televisions to laptop computers,
X-ray machines and ultrasound
scanners to air traffic control systems
and pioneering mobile communications,
Toshiba technology is all around you.
This unrivalled pedigree ensures that
Toshiba products will continue to
exceed expectations and set new
standards in an increasingly complex
and competitive world.
We don’t just care about how our
products fit into an individual’s home
environment, we are also committed
to wider environmental concerns such
as recycling. Every product we make
is subject to an eco-efficiency calculation
that balances a product’s value against
the various environmental impacts of its
lifecycle. We are taking a proactive role
in the development of the European
Union’s directives for the recycling of
waste electrical and electronic
equipment (WEEE) and Restriction
of Hazardous Substances (RoHS).
Even our product brochures are
produced using paper from a
sustainable resource, paper that can
be recycled at the end of its use.
Where this symbol appears on
our product it should not be
treated as household waste.
By ensuring this product is
disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health.
For more detailed information about
recycling this product, please contact
Toshiba, your local household waste
disposal service or the shop where you
purchased the product.
contact us
Toshiba home entertainment is an incredible experience where sound
and images combine to stimulate your senses.
true experience
PRODUCT SPECIFICATIONS
39
All details correct at time of going to press. Product design and specification subject to change or modification without notice.
Notes
Widescreen & 4:3 TV
– overview 18
Widescreen Face Flat 50Hz TV 20
Face Flat Nicam 4:3 TV 20
Nicam 4:3 TV 22
Mono 4:3 TV 23
Portable 4:3 TV 23
DVD
Hard Disk DVD Recorders 26
Multi-drive DVD / Video Recorder 26
Multi-drive DVD Recorder 26
DVD / Video Combi 28
Home Cinema DVD 30
Portable DVD 32
Technology Explained
Glossary of Terms 34
Detailed Specifications
LCD & Plasma TV 36
Widescreen & 4:3 TV 37
DVD 38
content 3
Insight
a detailed view of the latest
technological advances
Insight: High Definition TV 4
Insight: Screen Technology 5
Insight: Recordable DVD 24
LCD & PlasmaTV
– overview 6
LCD 16:9 TV 8
LCD 4:3 TV 14
Plasma TV 16
4
Get Ready for HDTV
High Definition TV is coming soon.
For example, in the UK both commercial
broadcasters and the BBC are already
filming some programmes in High
Definition. BSkyB has announced plans
to start HD broadcasts in 2006 while
many movie studios have committed to
producing movies on HD DVD. You will
need an HDTV receiver or HD DVD
player, but most importantly, you will
need a High Definition compatible TV.
What is HDTV?
Very simply, High Definition Television
is a digital system that gives you picture
quality that is vastly superior to current
broadcast systems. The improvement
in clarity, depth and sharpness of
images is instantly visible.
HDTV provides an average of eight
times more data on a display screen
than a standard definition broadcast
thanks to the increased picture
resolution that HD broadcasts deliver.
The Technical Bit
•Current digital TV broadcast system
(PAL) offers 576 active lines of
picture information, sent as an
interlaced signal, reproducing around
210,000 pixels.
•There are three main HDTV
standards: 720p, which offers 720
lines of image, progressively scanned;
1080i, providing 1080 lines of
interlaced image; and 1080p, which
provides 1080 lines of progressively
scanned lines.
•High Definition broadcasts carry two
million pixels of data signal - that’s
around eight times more picture detail
on the HDTV screen versus current
Digital broadcasts.
A new European industry-wide technical
standard has been defined for products
which will be able to display High
Definition images.
Any product featuring this logo
guarantees:
•A minimum native resolution of the
display or display engine (in the case
of DLP projectors, for example) is 720
lines in widescreen format.
•The display will accept HD signals
via component video and DVI or
HDMI interface.
•HD component inputs that will accept
the following video formats:
a) 1280 x 720p and b) 1920x1080i
(at 50 and 60Hz).
•A DVI or HDMI input with HDCP
copy protection support.
Available Now!
Toshiba already has a range of TVs and
projectors capable of displaying High
Definition broadcasts in all their glory
when they are available. In the
meantime, you can make the most of
the products’ high specifications and
their benefits.
High Resolution
The resolution of a screen dictates
the amount of picture information you
will see. The more image data available,
the more detail in the display and the
greater your viewing experience. That’s
why all the widescreen LCD TVs in this
brochure have a minimum panel
resolution of 1280 x 720 (almost 1
million pixels). Potentially each pixel
can display different information,
so enhancing the colour, tone and
ultimately, the three-dimensionality of
the image displayed.
Insight: High Definition TV
INSIGHT: HDTV & SCREEN TECHNOLOGY
5
HD Ready: three high-spec LCD TVs
with high resolution screens, 2x HDMI
and Component Video inputs, plus
integrated digital receivers (p.8)
HD Ready: three striking LCD TVs
with high resolution screens and HDMI
input (p.10)
An industry standard for connecting
high definition components, High
Definition Multimedia Interface™
transmits uncompressed digital video
and audio content over a single cable,
replacing the multiple cables required
with analogue AV connections.
As there is no conversion from digital
to analogue and back again (as with a
SCART lead for example), the original
digital quality is upheld.
HDMI™ dramatically simplifies home
cinema system installation and offers
numerous additional benefits including PC
compatibility, automatic format adjustment,
as well as automatic configuration of the
system to turn on or off the components
necessary to view a DVD, listen to a CD
or watch cable or satellite TV.
As pioneers of DVD and the new HD
DVD technologies, we have shown our
continuing commitment to bringing the
very latest advances in AV technology
into your home for your ultimate
enjoyment. Our latest LCD screens are
packed with image-enhancing
technology such as Active Vision LCD
and Real Digital picture processing, while
our range of DLP™ TVs and projectors
bring the full impact of cinema style
viewing into your living room.
What is Active Vision LCD?
Active Vision is a high performance
picture processing system designed
to produce a stunning picture by
enhancing four core elements of a
television image:
Detail – Active Vision LCD can
reproduce three times more pixels
than a conventional LCD TV.
Colour – Active Vision LCD can
reproduce four times more colour tones
than a conventional LCD TV.
Movement – Using Real Speed
Progressive technology, Active Vision
LCD dramatically reduces jagged
edges on lines and detail during
fast-moving scenes.
Contrast – Active Vision LCD uses a
dynamic contrast enhancer to adjust
contrast levels automatically. While it is
important for an LCD TV to have a high
performance panel, for the best results it
is absolutely essential to have a high
performance picture processing system.
What is Real Digital Picture
Processing?
Real Digital adds yet another dimension
to the picture processing technology by
reducing the number of signal separations
that normally occur in an LCD TV.
Signal processing in current LCD TVs
has to pass through numerous separate
signal conversions before it arrives at
the panel processing chip. This process
dramatically reduces the picture signal
quality of the TV.
Toshiba’s new Real Digital picture
processing reduces the signal
separation stages, therefore
maintaining the original detail of
the signal, and enhancing the
picture performance.
If the HDMI™ interface is used, the
signal is carried directly to the panel
signal processor as a digital signal,
and no picture separation occurs.
Insight:
Screen Technology
Thanks to Digital TV, DVD and High Definition TV, the audio-visual quality of programmes available
is generally far superior to anything we have experienced in the home before. However, you need
to have the right equipment to enjoy this new level of home entertainment.
6
LCD & PLASMA TV
Decorative accessory or television? These flat panel TVs are uniformly stylish,
with a super-slim display designed to fit into any home environment with the
minimum of effort.
42WL58
true vision
7
HDTV Insight p.4 Active Vision Insight p.5
High resolution screens, combined with
Active Vision LCD and Real Digital picture
processing technologies, ensure
astonishingly crisp, vibrant images from
within the minimal Picture Frame screen
surround. Subtly mounted beneath the
screen to enhance the Picture Frame
effect, the integrated stereo speakers
offer a full, rich sound. Selected models
also offer HDMI™ connectivity, in readiness
for High Definition broadcasts.
HDMI™
High-definition Multimedia Interface™
is a new industry standard for
connecting high definition components. HDMI™
transmits uncompressed digital video and audio content
over a single cable, replacing the multiple cables required
with analogue AV connections and ensuring exceptional
digital quality. HDMI™ dramatically simplifies home
cinema system installation and offers numerous
additional benefits including PC compatibility, automatic
format adjustment, and automatic configuration of the
system to turn on or off the components necessary to
view a DVD, listen to a CD or watch cable or satellite TV.
HDTV Insight p.4 Active Vision Insight p.5
8
Product design and specification subject to change or modification without notice.
Screen tint for illustration purposes only. For detailed specifications see page 36.
LCD WIDESCREEN TV
LCD WIDESCREEN TV
42WL58 / 37WL58 / 32WL58
9
(S-VIDEO)
Y
Pa /Cb
Pr/Cr
COMPONENT VIDEO INPUT
MONO
(AUDIO /
VIDEO)
WOOFER OUT
(VARIABLE)
FIXED /
VARIABLE
RGB/PC
HDMI
S-VIDEO
VIDEO
L/MONO
HEADPHONES
(5)
WOOFER
RGB/PC IN
HDMI1
HDMI
HDMI2
AUDIO
AUDIO
AUDIO
AUDIO
DVB COMMON INTERFACE
EJECT
42WL58
94cm
▲
Resolution: WXGA (1366x768 pixels)
Active Vision LCD & Real Digital picture processing
Contrast ratio: 800:1
Brightness: 500cd/m2
SRS®WOW™ sound, Nicam, 20W RMS
2 HDMI™ interfaces
Component video input
Optional accessories
Floor stand
Resolution: WXGA (1366x768 pixels)
Active Vision LCD & Real Digital picture processing
Contrast ratio: 800:1
Brightness: 500cd/m2
SRS®WOW™ sound, Nicam, 20W RMS
2 HDMI™ interfaces
Component video input
Optional accessories
Floor stand
32WL58 - 81cm screen
LCD Widescreen TV
82cm
▲
37WL58 – 94cm screen
LCD Widescreen TV
42WL58 – 107cm screen
LCD Widescreen TV
107cm
▲
Resolution: WXGA (1366x768 pixels)
Active Vision LCD & Real Digital picture
processing
Contrast ratio: 550:1
Brightness: 500cd/m2
SRS®WOW™ sound, Nicam, 20W RMS
2 HDMI™ interfaces
Component video input
Optional accessories
Floor stand
10
LCD WIDESCREEN TV
81cm
▲
LCD WIDESCREEN TV Resolution: WXGA (1366x768 pixels)
Active Vision LCD & Real Digital
picture processing
Contrast ratio: 800:1
Brightness: 500cd/m2
SRS®WOW™ sound, Nicam, 20W RMS
HDMI™ interface
Optional accessories
Floor stand
Resolution: WXGA (1280x720 pixels)
Active Vision LCD & Real Digital
picture processing
Contrast ratio: 900:1
Brightness: 500cd/m2
SRS®WOW™ sound, Nicam, 20W RMS
HDMI™ interface
69cm
▲
37WL56
37WL56 – 94cm screen
LCD Widescreen TV
32WL56 – 81cm screen
LCD Widescreen TV
27WL56 – 69cm screen
LCD Widescreen TV
94cm
▲
Resolution: WXGA (1366x768 pixels)
Active Vision LCD & Real Digital
picture processing
Contrast ratio: 600:1
Brightness: 500cd/m2
SRS®WOW™ sound, Nicam, 20W RMS
HDMI™ interface
Accessories
Floor stand
REAR PANEL SIDE PANEL REAR PANEL SIDE PANEL
37WL56 / 32WL56 27WL56
11
HD Ready
Thanks to the combination of high
resolution screens, HDMI™ and
component video inputs, these televisions are all
set to display the high definition images.
HDTV Insight p.4
Active Vision Insight p.5
Product design and specification subject to change or modification without notice.
Screen tint for illustration purposes only. For detailed specifications see page 36.
12
Product design and specification subject to change or modification without notice.
Screen tint for illustration purposes only. For detailed specifications see page 36.
LCD WIDESCREEN TV
58cm
▲
Resolution: WXGA (1366x768 pixels)
Contrast ratio: 800:1
Brightness: 450cd/m2
Mutli-standard tuner
Nicam, 10W RMS
Component video input
51cm
▲
23WL56
27WL54 – 69cm screen
LCD Widescreen TV
23WL56 – 58cm screen
LCD Widescreen TV
20WL56 – 51cm screen
LCD Widescreen TV
69cm
▲
Resolution: WXGA (1280x720 pixels)
Contrast ratio: 900:1
Brightness: 550cd/m2
Multi-standard tuner
Nicam, 16W RMS
RGB COMPONENT INPUT
YPa /Cb Pr/Cr
23WL56 / 20WL56
13
LCD Technology
LCD or Liquid Crystal Display technology uses
liquid crystal movement to produce a high
resolution with superb contrast, brightness and
colour depth in a lightweight, flat panel display.
Clarity and size aren’t the only advantages – LCD
screens also consume around 40 per cent less
power than the cathode ray tube (CRT) in most
conventional TVs.
LCD WIDESCREEN TV Resolution: WXGA (1280x768 pixels)
Contrast ratio: 400:1
Brightness: 450cd/m2
Multi-standard tuner
Nicam, 10W RMS
27WL54
Connection diagram
not available at time
of going to press.
14
LCD TV 4:3 TV
15
Product design and specification subject to change or modification without notice. Screen tint for illustration purposes only.
For detailed specifications see page 36.
Compact LCD Styling
LCD technology (see p.16) has helped to make
TV universally accessible in the home. The super-
slim panel and compact styling with discreetly
mounted tuner and stereo speakers have opened
up every room in the house, even where
space is at a premium, to the possibilities and
pleasures of audio visual entertainment.
51cm
▲
35cm
▲
Resolution: VGA (800x600 pixels)
Contrast ratio: 500:1
Brightness: 450cd/m2
3D digital comb filter
Nicam, 6W RMS
2 SCART
Resolution: VGA (640x480 pixels)
Contrast ratio: 600:1
Brightness: 450cd/m2
Multi-standard tuner
Nicam, 6W RMS
2 SCART
14VL44 – 35cm screen
LCD 4:3 TV
LCD 4:3 TV
20VL55 – 51cm screen
LCD 4:3 TV
20VL56
20VL56
20VL56 – 51cm screen
LCD 4:3 TV
51cm
▲
Resolution: VGA (640x480 pixels)
Contrast ratio: 350:1
Brightness: 450cd/m2
3D digital comb filter
Nicam, 10W RMS
2 SCART
20VL55
14VL44
2216
PLASMA WIDESCREEN TV
REAR PANEL SIDE PANEL
S-VIDEO
VIDEO
L/MONO
FIXED / VARIABLE
RGB/PC
AUDIO
INPUT HEADPHONES
(5)
RGB
42WP56
Product design and specification subject to change or modification without notice. Screen
tint for illustration purposes only. For detailed specifications see page 36.
42WP56
42WP56 – 107cm screen
Plasma Widescreen TV
107cm
▲
Resolution: WVGA (852x480 pixels)
High contrast ratio: 3000:1
High brightness: 1500cd/m2
Real Digital picture processing
Multi-standard tuner
SRS®WOW sound, Nicam, 20W RMS
17
PLASMA WIDESCREEN TV
Plasma Display
Plasma technology uses thousands of tiny
fluorescent lights (phosphors) to create a large
image with minimal screen depth. Picture
performance is impressive with incredibly sharp,
flicker-free images and outstanding bright colours.
A plasma screen with high specifications for
Contrast Ratio, Brightness Level and Resolution
will offer strong images in any lighting environment.
18
WIDESCREEN & 4:3 TV
true image
There’s something for everyone: a
wide selection of widescreen, small
screen and portable TVs, flat screen
or conventional tube, Nicam or mono
sound output. This range offers plenty
of choice, but a singular commitment
to producing an audio-visual experience
that will satisfy and stimulate you.
These sets give a whole new meaning
to everyday television. No matter what
the screen size, the TV is packed with
technology to present a striking image
and accurate sound. Whatever you
choose, rest assured that it brings a
stunning blend of functionality, simplicity
and timeless appeal to your home.
19
Embrace your individuality and express your
freedom to choose, yet without compromising
on a single detail.
32ZH56
20
WIDESCREEN & 4:3 TV
21
32ZH56
32ZH56
DIGITAL AUDIO
OUTPUT/OPTICAL
JACK
Face Flat Screens
A Face Flat TV has a horizontally and vertically flat
TV tube which offers a wider viewing angle along
with enhanced picture linearity to produce
accurate, life-like images. Unlike the curved face
of a conventional tube design, this totally flat
screen minimises reflections from room lighting
and results in a significant improvement in clarity,
contrast and brightness.
50Hz
Nicam, 20W RMS
2 SCART
Accessories
Cabinet Stand
29V53 – 68cm screen
50Hz Face Flat TV
68cm
▲
50Hz
Selectable picture
Text with Fastext
Auto set-up
SCART
15V31 – 36cm screen
Face Flat TV
36cm
▲
Product design and specification subject to change or modification without notice. Screen tint for illustration purposes only.
For detailed specifications see page 37.
29VH56G / 29VH57
32ZH56 – 76cm screen
Widescreen Face Flat TV
76cm
▲
29VH56G – 68cm screen
29VH57 – 68cm screen
100Hz Face Flat TV
68cm
▲
100Hz
Nicam, 20W RMS
3 SCART
Accessories
Cabinet Stand
EXT 2
29V53
WIDESCREEN TV
& 4:3 TV
15V31
50Hz
Nicam, 20W RMS
NTSC video playback
2 SCART
22
WIDESCREEN & 4:3 TV
23
21S53 – 51cm screen
Nicam TV
51cm
▲
50Hz
Auto set-up
Text with Fastext
SCART
21N51 – 51cm screen
Mono/Portable TV
51cm
▲
50Hz
Auto set-up
Text with Fastext
SCART
14N51 – 34cm screen
Mono/Portable TV
34cm
▲
Product design and specification subject to change or modification without notice. Screen tint for illustration purposes only.
For detailed specifications see page 37.
Selectable Picture
Not every room is the same in terms of ambient
light levels so to achieve the best possible picture,
you may want to adjust your TV’s settings. For
simplicity, the Selectable Picture function offers
you three pre-set and one user-adjustable
settings for picture colour, brightness and
contrast, accessed at the press of a
button on the remote control.
21N51 / 14N51
EXT 2
21S53
50Hz
Nicam, 20W RMS
Selectable picture
2 SCART
Image shows optional floor stand
28N53 – 66cm screen
Nicam TV
66cm
▲
28N53
50Hz
Nicam, 10W RMS
2 SCART
EXT 2
28N53
WIDESCREEN
& 4:3 TV
24
Toshiba’s DVD recorders are multi-
drive so you can choose the media
(disc type) you want to record onto –
integrated hard disk, or removable
DVD-RAM, DVD-RW or DVD-R
(depending on the model).
What is recordable DVD?
A DVD recorder allows you to record,
edit and play back material with
astonishing ease and absolutely no
loss of quality. Before recordable
DVD, if you wanted to record a
programme or home movie, you
were expected to compromise on
quality, with a tape of limited capacity
and susceptible to long-term
deterioration. Not to mention the
hassle of searching for a blank
cassette at the last moment, or the
risk of recording over something you
wanted to keep.
All that has changed. Recordable
DVD offers durable discs of varying
format and capacity capable of
storing great quantities of digital
information for your enjoyment.
A DVD recorder isn’t just about
recording programmes from TV,
or even digital images from
camcorders and cameras. It also
gives you complete control to edit
the bits you want, then archive the
final version on a permanent disc or
give copies to friends.
Which format?
There are several different recording
formats. A DVD recorder records
video and audio optically onto discs.
Discs are available in different formats
and can be either ‘re-writable’ (DVD-
RAM, DVD-RW) or used only once
(DVD-R). A DVD hard disk recorder
offers the added benefit of a built-in
hard disk drive (HDD), as well as a
removable disc option.
Hard Disk Drive
The most obvious benefits of a hard
disk are the capacity* and simple
editing/dubbing capabilities. You can
use the HDD for everyday recordings,
then edit and dub to disc if you want
to keep them or pass them on to
someone else.
*(up to 206 hours on the RD-XS64)
DVD-RAM
A DVD-RAM disc is ideal for
recordings you want to edit and
archive. The disc may be single or
double-sided and is re-writable up to
100,000 times meaning the content
can be erased and the disc can be
reused with no risk of deterioration in
quality. For added durability, some
DVD-RAM discs are encased in a
plastic caddy, protecting them from
fingerprints and scratches.
The main advantages of DVD-RAM
are the recording and editing
versatility. With the Random Access
Memory (RAM) format, all available
space on a disc can be used,
unwanted sections of programmes
can be simply edited or deleted, and
new recordings made without
accidentally recording over
something you wanted to keep.
DVD-RW
A DVD-RW disc is also re-writable,
up to a maximum of 1,000 times.
However, recording is linear, just like
on a VHS tape, so although
recordings can be deleted and
replaced, they cannot be edited. This
means that there is greater risk of
over-recording and wasted space
than with a DVD-RAM disc.
DVD-R
Like CD-R, a write-once DVD-R
disc can only be used to record once
and the recording cannot be deleted.
The main advantage is that they are
cheap to buy and compatible with
most DVD players, recorders or
DVD drives, making them ideal
for loans to friends and multiple
copying (for example, a wedding
or holiday video).
Insight: DVD Recorders
A DVD Recorder is little short of the ultimate in digital entertainment versatility. TV, home video, family photos,
music, movies wherever and whenever you want... with a DVD recorder the choice is yours.
INSIGHT: DVD RECORDERS
25
20:00
Start recording a
real-time broadcast
The recording
is completed
20:15 20:30 21:00
You come home and watch
the recorded footage using
‘chase play’
Picture from
the real-time
TV broadcast
Picture in Picture feature
Timeslip feature
Picture being
played back
Edit menu DV
recording window
Instant connection
via DV input
20:15 20:30 21:00 21:15
Timeslip
Now you can make the TV schedule
fit in with your own schedule thanks
to the brilliant Timeslip feature that
gives you the option to ‘Chase’ or
‘Pause’ TV.
Chase TV means you can watch the
start of a programme at any time,
while it is being recorded. For
instance, watch the start of the
Grand Prix before waiting for the end
of the race.
Easy Navi*
With so many features and functions
on our Hard Disk Recorders, it would
be natural to feel daunted at the
prospect of finding your way around.
However, our HDD recorders* feature
a simplified Easy Navi menu option
which gives you easy access to
recordings and key features. Simply
press the Easy Navi button on the
remote control while watching TV or
playing recorded footage to display
the navigation menu on the screen.
From there it’s just one press of the
button to access all the operations
you need to playback, record or edit.
*(RD-XS24).
Hard Disk models also allow you to
pause a live programme at the touch
of a button, then continue from that
point when you are ready.
Meanwhile, you can keep an eye on
the real-time broadcast with the
‘Picture in Picture’ feature which
opens a small picture box showing
the live programme.
The menus are completely intuitive,
aided by thumbnail visuals of
programme content. The recorder
even recognises when a camcorder
is connected, automatically providing
the appropriate on screen menu to
download footage using the
recorder’s remote control.
Satellite Box Control
Multiple recordings from satellite
is just as easy. You simply select
the appropriate channel in the
programming window and be sure
to leave the satellite box switched
on. The recorder will automatically
switch the satellite receiver to
the appropriate channel for
each recording.
DVD RECORDER
26
DVD RECORDER
27
Product design and specification subject to change or modification without notice. For detailed specifications see page 38.
RD-XS64 - Back Panel Connections
Easy Navi
Easy Navi is a navigation menu
option giving easy access to
recordings and key features. When
the Easy Navi button on the remote
control is pressed while watching
TV or playing recorded footage,
the appropriate navigation menu
appears on the
screen. From there just one press
of the button enables access to all
the operations needed to
playback, record or edit.
DVD Recorder Insight p.24
RD-XS64 - Front Panel Connections
RD-XS24 - Back Panel Connections
RD-XS24 - Front Panel Connections
RD-XS64
Multi-drive HDD, DVD-RAM, DVD-R, DVD-RW recorder
160GB hard disk drive – up to 206 hours of recording
PAL progressive & component video output
Timeslip recording: Chase TV / Pause TV
DV Input
Set top box control
RGB recording
RD-XS64
HDD Recorder
RD-XS24
HDD Recorder
Mulit-drive DVD-RAM, DVD-R,
DVD-RW, VHS recorder
Timeslip recording: Chase TV or
Pause TV
Simultaneous record & play
PAL progressive & component
video output
Editing features
DivX®, JPEG, MP3 compatible
D-VR30
Combi DVD / Video Recorder
Multi-drive DVD-RAM, DVD-R, DVD-
RW recorder
Timeslip recording: Chase TV or
Pause TV
Simultaneous record & play
DV input
PAL progressive & component video
output
DivX®, JPEG, MP3 compatible
D-R255
DVD Recorder
Multi-drive HDD, DVD-RAM, DVD-R,
DVD-RW recorder
160GB hard disk drive – up to 206
hours of recording
PAL progressive & component video
output
Timeslip recording: Chase TV or
Pause TV
DV Input
DV-IN
R
LVIDEO
AV3
R L VIDEO
S-VIDEO
LR
AV1 (TV)
AV2 ( EX T)
DIGITAL AUDIO
OUTPUT/COAXIAL
JACK
RLS-VIDEO
RLVIDEO
COMPONENT
OUTPUT JACKS
AV2 (EXT)
AV1 (TV)
VHF/UHF RF IN
(FROM ANT.)
SOCKET
ANALOGUE
AUDIO INPUT
D-VR30 - Front Panel Connections
R L VIDEO
S-VIDEO
LR
AV1 (TV)
AV2 (EXT)
D-R255 - Front Panel Connections
DV-IN R
LVIDEO
AV3
AV1 (TV)
AV2 (EXT)
D-VR30 - Back Panel Connections D-R255 - Front Panel Connections
COMBI DVD / VCR
COMBI DVD/VCR
29
Product design and specification subject to change or modification without notice.
For detailed specifications see page 38.
DVD player with Nicam VCR
PAL progressive & component video output
Simultaneous record & play
PDC
DivX®, JPEG, MP3 compatible
SD-36VE
Combi DVD / Video
SD-26VE
Combi DVD / Video
DVD video player with Nicam VCR
PAL progressive & component video output
Simultaneous record & play
PDC
7 event, 1 month timer
JPEG, MP3 compatible
Component Video
To make the most of the incredible picture quality
from DVD, Toshiba has included a Component
Video Input on all of its Home Cinema televisions,
display panels and projectors.
This input option is typically found on professional
broadcasting equipment and gives you far greater
flexibility to adjust the brightness and contrast
balance than via a conventional RGB
interconnection.
SD-26VE
SD-36VE SD-26VE
28
DVD VIDEO
30
DVD VIDEO
31
Product design and specification subject to change or modification without notice.
For detailed specifications see page 38.
HDMI™ Up Conversion
High Definition displays require a minimum resolution
of 1280x720p. However, existing DVD videos have a
native resolution of 480p. An up conversion DVD player
is capable of upgrading a current DVD‘s resolution to
high resolution 1080i or 720p signals. Therefore, if you
have, or are considering purchasing an HD Ready TV
in anticipation of forthcoming High Definition
programming (broadcast or HD DVD), a DVD player
with up conversion capability will enable you to view
your existing DVD videos with the higher resolution.
As the up-conversion process is completely digital,
there is no loss of data or quality, as there would be
with a digital-analogue conversion.
HDTV Insight p.4
DVD video player
HDMI™ up conversion (720p/1080i)
Optical & component video output
Dolby®Digital & DTS®compatible
DivX®playback
JPEG, MP3 compatible
SD-152E
DVD Video
DVD video player
PAL progressive & component video output
Dolby®Digital & DTS®compatible
JPEG, MP3 compatible
SD-350E
DVD Video
SD-350E
SD-350E
DVD video player
PAL progressive & component video output
Dolby®Digital & DTS®compatible
DivX®, JPEG, MP3 compatible
SD-250E
DVD Video
SD-250E / SD-151E
COAXIAL
DVD OUT
SD-152E
COAXIAL
DVD OUT
PORTABLE DVD VIDEO
32
PORTABLE DVD VIDEO
33
Product design and specification subject to change or modification without notice.
For detailed specifications see page 38.
Resolution: WSVGA
3.5 hour rechargeable battery
Dual headphone outputs
DivX®, JPEG, MP3 compatible
SD-P2700 – 23cm screen
Portable DVD Video
SD-P1610 – 17cm screen
Portable DVD Video
Resolution: QVGA
3 hour rechargeable battery
Dual headphone outputs
DivX®, JPEG, MP3 compatible
SD-P2700
17cm
▲
23cm
▲
DC IN
HEADPHONE
1
VOLUME CONTROL
HEADPHONE
2
OFF
POWER
ON
COMPONENT
VIDEO
CONNECTOR
MEMORY CARD SLOT
S-VIDEO
OUTPUT
BITSTREAM
PCM
AV OUT AV IN
SIDE VIEW 1 SIDE VIEW 2
REAR VIEW
SD-P2700
DC IN
HEADPHONE
1
VOLUME CONTROL HEADPHONE
2
BITSTREAM
PCM
AV OUT AV IN OFF
POWER
O
SD-P1610
DivX®
DivX®is a video compression software
which enables high quality video to be
compressed into very small files, then downloaded
onto CD-R or CD-RW and played back with very
little loss of quality.
MP3 and WMA
MP3 and WMA (Windows Media®Audio) are both
audio compression formats used for downloading
music files from the internet, then decompressed
and stored on disc. A DVD video player
compatible with these formats will then be able to
play back the music files from CD-R or CD-ROM.
100Hz DFS (Digital Frame Scan)
Picture processing system offering two picture modes:
Natural Mode and 100Hz
Active Mode
Picture processing system offering exceptionally smooth
movement by maximising the use of the 360∞motion
estimation. Any jitter on line detail and text is eliminated by
altering the sequence of line scanning down the screen
Active Sub Woofer
Low frequency effects (bass) speaker driven by its own
internal amplification source
Active Vision
High performance and flexible picture processing system
offering different picture modes: Active, Natural, Progressive
Scan, 100Hz (see p.5)
Advanced Editing Features
DV editing suite for recordings or home movies, including
high-speed dubbing, multiple recording deletions or
transfers and DVD-R creation
ANSI Lumens
Standard for measuring light output, used for comparing
projectors
Aspect Ratio
Width to height ratio defining the screen or image,
conventional widescreen being 16:9 (16 units wide by 9
units high)
Auto Set-up
Automatically tunes in all channels in the correct order on
TVs and VCRs
Bass Boost
Enhances low-frequency sound without a separate sub
woofer
Brightness Level
A high luminance rating ensures a brilliant, clear image even
in bright light conditions
CD Text
Displays on the TV screen any formatted CD text data
available on the disc, eg song titles
Chase TV
Watch the start of a programme before the DVD recorder has
finished recording the end
Co-axial Audio Terminal.
Enables digital audio connection between a DVD player and
decoder or digital playback equipment.
Component Video
Connection found on selected Toshiba TVs, DVD players
and projectors, for optimum picture quality. Allows the
brightness and contrast of the picture to be adjusted to suit
room conditions
Composite Video
Standard video signal used to send pictures eg from a VCR
to a TV
Contrast Ratio
Ratio between white and black. The greater the contrast ratio,
the greater the ability to show subtle colour details
Dark Tint
Treatment of the front panel of the CRT to absorb ambient light,
enhance black reproduction and provide increased contrast
Digital Comb Filter
Reduces the moiré effect sometimes caused by fine lines or
checked patterns and maximises the resolution from high
quality image sources such as DVD
Digital Picture Processing
Processes which improve TV picture quality, brightness and
colour
DivX®
Video compression software which enables high quality
video to be compressed into very small files then
downloaded onto CD-R or CD-RW and played back with
very little loss of quality
DivX®Playback
Allows DivX®encoded video tracks to be played back via
CD-R or CD-RW
DNR
Ensures superior picture quality by ‘cleaning’ images and
reducing picture ‘noise’. Particularly useful for older movies
where the source master has picture noise
Dolby®Digital 5.1 Surround
Six totally independent channels of digital sound: stereo
front left and right, centre dialogue and stereo rear, plus
dedicated sub woofer
Dolby®Pro Logic®II
Enhanced surround sound system offering a virtual stereo
rear channel
Dolby®Pro Logic®Surround
Four-channel surround sound: S tereo front left and right,
centre dialogue and mono rear
DTS®(Digital Theatre System)
Alternative system of encoding six channel digital surround
sound, used in some cinemas and on some DVD discs
DVD-R
A write-once disc which cannot be deleted
DVD-RAM
Re-recordable disc, sometimes encased in a protective
caddy. It can be single or double-sided, and can be reused
up to 100,000 times
DVD Text
Displays on the TV screen any formatted DVD text data
available on the disc
DVI (Digital Video Interface)
Industry standard digital interface for transferring high
quality computer graphics or video content (eg from a digital
camcorder) to a display screen with no loss of quality
Easy Navi
Button on remote control of some Toshiba DVD Recorders
offering simplified menu access to recordings and key
features
Enhanced Audio Mode (EAM)
Allows different audio channels on DVD to be enhanced
separately, i.e. dialogue or surround sound
Enhanced Picture Mode (EPM)
Allows selection of three different colour and contrast
settings to suit movies, animation, etc
Enhanced Video Amplifier
Ensures superior picture quality by making whites even
whiter
Face Flat
Horizontally and vertically flat TV tube technology which
offers a wider viewing angle and reduced reflection
Fastext
Enables quick access to key TV text pages using the red,
green, yellow and blue buttons on the remote control
HDD (Hard Disk Drive)
High-capacity digital storage device
HDMI™ (High-definition Multimedia Interface)
New industry standard digital interface for connecting high
definition components in a home cinema system, and
transferring uncompressed digital video and multi-channel
audio content via a single cable
HD DVD
High capacity DVD video format offering very high picture
resolution
HD TV (High Definition Television)
A digital system that produces picture quality vastly superior
to current broadcast systems
Icon On-screen Display (OSD)
On-screen menus illustrated by icons, to enable simple
operation of equipment and guide you through various
setting and programming functions
Index Search
Makes it easy to find the beginning of any item recorded on
a video tape
Invar Mask
Displays purer whites on the TV screen
Jitter Reduction
Technology to minimise fluctuations in the digital signal to
enhance video and audio quality and ensure the picture has
no ‘wobble’
JPEG Viewer
Enables viewing of digital camera images through a DVD
player via CD-R/DVD-R or CD-RW (model dependent)
Liquid Crystal Display (LCD)
Screen technology using liquid crystal movement to
produce a high resolution with superb contrast, brightness
and colour depth
Luminous Remote
Luminous buttons on the remote control for easy operation
in a darkened room
MP3 Playback
Technology which allows MP3 encoded music tracks to be
played back via CD-R
Multiple Camera Angles
Scenes shot from up to nine different camera angles at the
director’s discretion may be stored and viewed no DVD
(software dependent)
Multiple Language Tracks
Up to eight different language soundtracks may be recorded
on a single disc and up to 32 different language subtitles
(software dependent). Nearly all DVDs carry English subtitles
Multi-standard Tuner/Video Playback
Able to display images from all world broadcast standards
(NTSC, PAL, SECAM)
NICAM
Sound broadcasting system capable of delivering CD-
quality digital stereo sound or mono sound, and of carrying
a Dolby®Pro Logic®or Dolby®Digital soundtrack.
NTSC
TV broadcast system used primarily in the USA and Japan
NTSC Video Playback
TV technology which enables NTSC tapes to be viewed
when played back on an NTSC video recorder
Off Timer
Switches the TV to standby mode at a pre-determined time
One-touch Front panel Operation
Buttons on the DVD players giving instant access to audio
and picture setting menus
Optical Audio Terminal
Enables digital audio signals to be sent from digital sources
such as DVD and laser disc players to digital playback
equipment via a fibre-optic connection
PAL I
TV broadcast system used in UK and some other countries.
PAL Progressive
If a TV or projector is capable of reproducing a progressive
image, a progressive output is required from the video
source (eg DVD). Previously only available for NTSC format
material, PAL Progressive offers higher quality picture
reproduction due to the greater number of horizontal lines
that make up the image (540 versus 480 lines in NTSC)
Panel Lock
Locks the controls on the TV to prevent changes to settings
Parental Lock
Allows discretionary ‘locking’ of DVD software using a code
so that undesirable or inappropriate sections are
automatically skipped (software dependent)
Passive Sub Woofer
Low frequency effects (bass) speaker driven by an external
amplification source
Technology Explained
Pause TV
Pause a live TV programme then continue from where you
left off while recording to the end
Picture in Picture
View a second channel in a window on the main screen
Picture Size Adjustment
Adjusts the format of the picture to suit the TV screen
Pixels
Individual dots of information that a display uses to create
an image. The number of pixels is defined by a screen’s
resolution
Plasma
Screen technology using thousands of tiny fluorescent lights
(phosphors), ensuring even brightness and detail across a
large screen
Programme Delivery Control (PDC)
Responds to a broadcast signal which ensures that
recording begins only when the programme actually starts
and stops when the programme ends. Check with your
regional broadcaster for details of PDC availability in your
area. Not available on satellite or digital broadcasts
Progressive Scan
Scans individual picture lines in sequence rather than
alternately, maximising the clarity of digital images from
DVD and enhancing NTSC software playback
RCA Audio
Analogue audio connection, usually for transfer of audio
data to a hi-fi system or PC
Real Digital Picture Processing
Picture processing technology that reduces the number of
signal separations that normally occur in an LCD TV so
maintaining image detail
Resolution
Refers to the number of individual dots that a display uses to
create an image
RGB
Input that accepts computer signals broken down into Red,
Green, Blue, minimising interference
RMS
Standardised unit of power measurement used for audio
performance
Satellite Box Control
Allows DVD recorder to switch channels on the satellite
receiver automatically for each programmed recording
SCART
21-pin cable connector which enables high-quality picture
and stereo sound (including Dolby®Pro Logic®
soundtracks) to be sent between AV equipment
SECAM
TV broadcast system used in France and some other
countries
Selectable Picture
Three pre-set and one user-adjustable settings for picture
colour, brightness and contrast, selected at the press of a
button
SRS®WOW
Enhanced 3-dimensional sound from stereo speakers
Super Scene Control
Process which improves TV picture contrast
S-video
Connection method for high quality video transfer used with
S-VHS video recorders, camcorders, DVD players, etc
Text Sub-page Memory
Allows you to move through text sub-pages at your own
speed using the remote control
Timeslip
Feature which allows you to Chase TV or Pause TV
Twin Tuner
Allows one channel to be viewed while another is being
recorded (on a Combi TV/VCR)
Up Conversion
DVD technology that converts the 480p signal on standard
DVD videos to 720p or 1080i signals for optimum quality
display on High Definition screens
Variable Zoom
DVD technology offering magnification of the on-screen
image, allowing you to zoom in and move around the
picture.
VideoPlus®
Simple way to record TV programmes, using numerical
codes (PlusCodes) shown in many TV listings pages to tell
the VCR when to start and stop recording. Up to six
programmes can be recorded from six different channels.
Virtual Dolby®
Enhances Nicam stereo soundtracks to give a virtual
surround sound using just the stereo speakers.
Visible Screen Size
Measured in centimetres diagonally across the screen.
Widescreen
Cinema-style picture format, also used to describe ‘wide’
images (16 units wide by 9 units high).
WMA
Windows Media®Audio, Microsoft’s own audio
compression method similar to MP3
Zoom Lens
Lens with variable focal length providing the ability to vary
the image size on a screen by adjusting the zoom lens,
instead of having to move the projector closer or further away.
34
TECHNOLOGY EXPLAINED
35
The Copyright, Design and Patent Act 1988: While recording
broadcasts is now permitted, users of sound and video
recording equipment should note that in other circumstances it
may be unlawful to record television programmes, cinematic
films or video recordings without the permission of the relevant
copyright holder.
While every effort has been made to ensure that all details are
correct at the time of going to press, Toshiba Information
Systems (U.K.) Ltd cannot accept any responsibility for any
errors or omissions to the product descriptions or
specifications. Product design and specification subject to
change or modification without notice. Toshiba does not give
any additional warranties in relation to the product beyond those
which are given with the individual product as part of the terms
and conditions of sale, and as otherwise provided by law.
©Toshiba Information Systems (U.K.) Ltd. Dolby and Pro Logic
are registered trademarks of Dolby Laboratories. VideoPlus is a
registered trademark of Gemstar Development Corporation. DTS
is a registered trademark of Digital Theater Systems, Inc. BBE is
a registered trademark of BBE Sound, Inc. SRS is a registered
trademark and WOW is a trademark of SRS Labs, Inc.
TrueVision is a registered trademark of TrueVision Inc. Freeview
is a registered trademark of DTV Services Ltd 2002. Faroudja
and DCDi are registered trademarks of Genesis Microchip, Inc.
Digital Light Processing and DLP are trademarks of Texas
Instruments Incorporated. High Definition Multimedia Interface
and HDMI are trademarks of HDMI Licensing, LLC. DivX is a
registered trademark of DivXNetworks, Inc. Windows Media is a
registered trademark of Microsoft Corporation. Gigabeat is a
registered trademark of Toshiba Corporation. Gigabeat room,
RipRec and Plus Touch are trademarks of Toshiba Corporation.
Napster and Napster To Go are trademarks of Napster LLC.
Other trademarks and trade names may be used in this
document to refer to the entities claiming the marks and names
of the product. Toshiba disclaims proprietary interest in the
marks and names of others.
Plasma and LCD
PRODUCT SPECIFICATIONS
37
36
Model 42WL58 37WL58 32WL58 37WL56 32WL56 27WL56 27WL54 23WL56 20WL56 20VL56 20VL55 14VL44 42WP56
See page 8 9 9 10 11 11 12 13 13 14 15 15 17
Visible screen size (cm) 107 94 81 94 81 68 68 58 51 51 51 35 107
Screen format 16:9 16:9 16:9 16:9 16:9 16:9 16:9 16:9 16:9 4:3 4:3 4:3 16:9
Display technology LCD LCD LCD LCD LCD LCD LCD LCD LCD LCD LCD LCD Plasma
Display resolution W XGA W XGA W XGA W XGA W XGA W XGA W XGA W XGA W XGA VGA VGA VGA W VGA
(1366x768) (1366x768) (1366x768) (1366x768) (1366x768) (1280X720) (1280X720) (1366x768) (1366x768) (640x480) (640x480) (640x480) (852X480)
High Definition ready ■■■■■■■
Contrast ratio 550:1 800:1 550:1 600:1 800:1 900:1 900:1 550:1 800:1 350:1 350:1 600:1 3000:1
Brightness (cd/m2) 500 500 500 500 500 500 550 500 450 450 450 450 1500
Comb filter (3D/Digital) ■■■■■■■■■■■■■
Active Vision LCD ■■■■■■
Progressive scan ■■■■■■■■■■■ ■
DNR ■■■■■■■■■■■■■
Selectable picture format ■■■■■■■■■■■ ■
Auto format (WSS) ■■■■■■■■■ ■
Interactive Features
Fastext ■■■■■■■■■■■■■
Text page memory ■■■■■■■■■■■■■
Audio
NICAM stereo ■■■■■■■■■■■■■
Sound output (RMS) W 20 20 20 20 20 20 16 10 10 10 6 6 20
SRS®WOW™ ■■■■■■■ ■
Bass boost ■■■■■■ ■
Selectable sound ■■■■■■■■■■■■■
Tuni ng
Auto set-up ■■■■■■■■■■■■■
Number of channels (Analogue) 100 100 100 100 100 100 100 100 100 100 100 100 100
Multi-standard tuner ■■■■■■■■■■■■■
NTSC video playback ■■■■■■■■■■■■■
Connections
HDMI 2 2 2 ■■ ■■
Component video ■■■Via PC Input Via PC Input Via PC Input Via PC Input ■■
RGB 2 2 2 1 1 1 2 2 1 1 1 1 1
SCART 3 3 3 2 2 2 2 2 2 2 2 2 2
Front/side AV input ■■■■■■■■■■■■■
PC input ■■■■■■■■■■■■■
S - Video input ■■■■■■■■■■■■■
Rear audio out ■■■ ■
Headphone ■■■■■■■■■■■■■
Other Features
Off timer ■■■■■■■■■■■■■
Panel lock ■■■■■■■■■■■■■
Previous channel return ■■■■■■■■■■■■■
Accessories
Pedestal stand ■■■■■■■■■■■■■
(Optional*)cabinet/ floor stand ■■■■■*■
Dimensions
Width (mm) 1044 915 794 916 794 690 705 619 537 490 487 448 1100
Height without ped. Stand (mm) 708 617 547.5 661 576 516 516 428 383 427 427 740
Height with ped. Stand (mm) 757 667 601 715 629 570 587 470 425 468.2 481 479 779
Depth (mm) 107.5 107 99 109 99 99 109 99 92 67.7 220 225 146.5
Height with floor stand (mm) 1145 1106 1055 1150 1075 N/A N/A N/A N/A N/A N/A N/A N/A
Weight (Kg) without stand 29.4 22 18 24.9 17.6 12.9 12.9 N/A N/A 7.6 8.2 6.8 N/A
Power Consumption (Typical) N/A N/A N/A 180W 155W 130W 130W N/A N/A 65W 65W N/A
Power Consumption (Stand-by) <1W <1W <1W <1W <1W <1W <3W <3W <3W <1W <4W <4W N/A
TV
Model 32ZH56 29VH56 29VH57 29V53 15V31 28N53 21S53 21N51 14N51
See page 20 20 21 21 21 22 23 23 23
Visible Screen Size (CM) 76 68 68 68 36 66 51 51 43
Screen Format 16:9 4:3 4:3 4:3 4:3 4:3 4:3 4:3 4:3
Display Technology CRT CRT CRT CRT CRT CRT CRT CRT CRT
Comb Filter (3D/Digital) ■
100Hz ■■
DNR ■■
Selectable Picture Format ■■■
Auto Format (WSS) ■
Interactive Features
Fastext ■■■■■■■■■
Text page memory ■■■■■■■■■
Audio
NICAM stereo ■■■■ ■■
Sound output (RMS) W 20 20 20 13 5 20 10 5 1
Bass boost ■
Selectable sound ■■ ■
Tuning
Auto set-up ■■■■■■■■■
Number of channels (Analogue) 100 100 100 100 100 100 100 100 100
Multi-standard tuner ■■
NTSC video playback ■■ ■
Connections
RGB 1 1 1 1 1 1 1 1 1
SCART 2 3 3 2 1 2 2 1 1
Front/side AV input ■■■■■■■■■
S - Video Input SCART Only ■SCART only SCART only SCART only
Rear Audio Out ■
Headphone ■■■■■■■■■
Other Features
Off timer ■■■■■■■■■
Panel lock ■■■■■■
Previous Channel Return ■■■
Accessories
(Optional*) Pedestal Stand ■*■*■*
(Optional*) cabinet / Floor Stand ■■*
Dimensions
Width (mm) 903 673 673 N/A 366 742 604 506 376
Height (mm) 557 595 595 N/A 373 576 452 465 346
Depth (mm 545 496 496 N/A 397 480 490 492 374
Height with stand (mm) 1055 N/A N/A N/A N/A 945 818 818 N/A
Weight (Kg) without stand N/A 42 42 N/A 11 33 21 21 9.5
Power Consumption 144W 142W 142W N/A 45W 135W 95W N/A 75W
Power Consumption (Stand-by) <1W <3W <3W N/A <2W <3W <3W N/A <5W
All details correct at time of going to press. Product design and specification subject to change or modification without notice.
*N/A: information not available at time of going to press
*N/A: information not available at time of going to press
38
DVD
Model RD-XS64 RD-XS24 D-VR30 D-R255 SD-36VE SD-26VE SD-350E SD-250E SD-152E SD-P2700 SD-P1610
See page 26 27 27 27 29 29 30 31 31 33 33
DVD Video ■■■■■■■■■■■
Portable DVD ■■
DVD Recorder ■■■■
Hard Disk Drive 160 GB 160 GB
Combi DVD/VCR ■■■
Nicam Stereo ■■■
Number of Heads 6 6 4
Compatibility
CD Audio ■■■■■■■■■■■
Video CD ■■■■■■■■■■■
CD-R ■■■■■■■■■■■
CD-RW ■■■■■■■■■■■
DVD-RAM ■■no cartridge ■
SVCD ■■■■■■■■■
DVD Video ■■■■■■■■■■■
DVD-R ■■■■■■■■■■■
DVD-RW ■■■■■■■■■
JPEG Viewer ■■■■■■■■■■■
MP3 ■■■■■■■■■■■
DivX®■■■■■
NTSC Playback* ■■■
Sound
3D Virtual Surround Sound ■■ ■ ■■
Dolby®Digital Compatible ■■■■■■■■■■■
DTS®Compatible ■■■■■■■■■■■
Enhanced Audio Mode ■■■
NICAM Stereo ■■■■
PAL Progressive ■■■■■
DNR ■■■
Icon on-screen display ■■■■■■■■■■■
Slow Motion ■■■■■■■■■■■
Variable Zoom ■■■■■■■■■■■
Display
Panel Size 8.9" Wide 7" Wide
Resolution 1024x600 480x234
DVD Recording
Simultaneous Record & Play ■■■■
VCR Recording
VideoPlus ■
Digital Auto Tracking ■■
Auto Repeat Playback ■
Interactive Capabilities
Timeslip TV ■■■■
Picture in Picture ■
Connections
Analogue 2 channel audio ■■■■■■■■■■■
Co-axial/Optical audio ■■■■■■■■■■■
Component Video ■■■■ ■■ ■
Composite Video ■■■■■■■■■
SCART (RGB) 2 2 2 2 2 2 1 1 1
S-video ■■■■■■ ■
Headphone Socket 22
Front AV ■■■■■■
HDMI Output ■ ■
Other Features
Easy Navi ■
Dimensions
Width 430 430 430 430 430 430 430 420 420 259 190
Height 79 69 84 59 82 78.5 42 49 49 35 30.5
Depth 272 316 321 272 282 265 200 265 264 193 145
Weight(kg) 4.2 4.3 4.8 2.9 5.4 4.2 1.6 2.3 2.3 1.2 0.69

Navigation menu
