EUROPEAN UNION ECOLABEL
Awarded to goods or services which meet the environmental
requirements of the EU ecolabelling scheme
WL86* Digital
Series
YL86* Digital
Series
YL87* Digital
Series
2
English
Contents
INSTALLING YOUR TV
Safety Precautions ............................................................................. 5
Installation and important information ..................................... 6
The remote control .........................................................................11
Inserting batteries and effective range ..........................11
CONNECTING YOUR TV
Connecting external equipment ................................................12
Connecting an HDMI® or DVI device to the HDMI input ...13
To connect an HDMI device ...............................................13
To connect a DVI device ......................................................13
HDMI’s ARC (Audio Return Channel) feature ...............13
REGZA-LINK connection ................................................................14
Connecting a computer ................................................................15
To connect a PC to the RGB/PC terminal .......................15
To connect a PC to the HDMI terminal ...........................15
Connecting a home network ......................................................16
To connect the TV to a home network - Wired ...........16
To connect the TV to a home network
with an internet connection - Wireless ......................16
Setting up the USB HDD ...............................................................17
Controls and input connections .................................................18
Switching on ............................................................................18
Using the menu system .......................................................18
Using the TV controls and connections .........................18
MENU structure ................................................................................19
SETTING UP YOUR TV
Startup Application .........................................................................20
Quick Setup ..............................................................................20
Ant/Cable/Satellite (if available) .......................................21
Satellite Settings .....................................................................22
Auto Tuning .............................................................................24
ATV Manual Tuning .........................................................................25
Tuning ........................................................................................25
Skip ..............................................................................................26
Sorting positions ....................................................................26
DTV Manual Tuning ........................................................................27
Manual Tuning ........................................................................27
Manual Tuning for DVB-C ...................................................27
Manual Tuning for DVB-S ....................................................27
DTV Settings ......................................................................................28
Channels (Antenna/Cable) .................................................28
Channels (Satellite) ................................................................29
Standby Channel Update ....................................................29
DVB Character Set ..................................................................29
Dynamic Scan ..........................................................................29
Location setting ......................................................................30
Analogue switch-off ............................................................30
CONTROLS AND FEATURES
General controls ...............................................................................31
Quick Menu ..............................................................................31
Selecting channels ................................................................31
The Time Display – analogue only .................................31
Stereo and Bilingual transmissions .................................31
Using 3D functions .........................................................................32
Using the 3D glasses .............................................................32
Viewing 3D images ...............................................................33
Switching display mode or selecting 3D format ........33
Setting the auto start mode ..............................................35
Setting the 3D PIN code ......................................................35
Setting 3D Start Message ....................................................35
Setting 3D Lock ......................................................................36
Setting 3D Timer Lock ..........................................................36
Setting Enable 3D Timer .....................................................36
Displaying 3D Important Info ............................................36
Adjusting 2D to 3D Depth .................................................. 36
Switching left and right images .......................................36
Sound controls ................................................................................. 37
Volume controls and sound mute ...................................37
Dual .............................................................................................37
Balance ......................................................................................37
Sound Navi ...............................................................................37
Surround Settings ..................................................................37
Dolby Volume® .......................................................................37
Dynamic Range Control ......................................................38
Audio Level Offset .................................................................38
Headphone Settings .............................................................38
Audio Description .................................................................38
Widescreen viewing .......................................................................39
Picture controls ................................................................................ 41
Picture Mode ........................................................................... 41
Picture preferences ...............................................................41
Reset ...........................................................................................41
ColourMaster ...........................................................................41
Base Colour Adjustment .....................................................42
Colour Temperature .............................................................42
Auto Brightness Sensor Settings ......................................42
LED Backlight Control ..........................................................42
Black/White Level ..................................................................43
Static Gamma ..........................................................................43
MPEG NR – Noise Reduction ..............................................43
DNR – Digital Noise Reduction .........................................43
Resolution+ ..............................................................................43
Active Vision M800 ................................................................43
Motion Detection Range .....................................................43
3D Judder Cancellation .......................................................44
Resetting the advanced picture settings ......................44
Expert Picture Settings ........................................................44
Control Visualization ............................................................46
Automatic Format (Widescreen) ......................................46
4:3 Stretch ................................................................................46
3
English
Blue Screen ...............................................................................46
Picture Position .......................................................................46
Picture still ................................................................................47
HDMI Information Display ..................................................47
Wireless LAN Information .............................................................48
Setting up the Network .................................................................49
Wireless Setup .........................................................................49
Advanced Network Setup ...................................................51
DNS Setup .................................................................................52
Network Connection Test ...................................................53
Using the software keyboard ......................................................53
Network Device Setup ...................................................................54
External Control Setup .........................................................54
Media Renderer Setup .........................................................54
Power Control Mode .............................................................55
Device Name Setup ...............................................................55
Using the USB HDD Function ......................................................55
To record DTV programmes
(One Touch Recording) ....................................................56
To schedule programmed recording .............................56
To check, edit or delete scheduling information .......59
To view a recorded programme .......................................59
Operations from the Library screen ................................60
Other useful functions (Time Shift Recording) ............61
Recording Setup .....................................................................61
To disconnect a USB HDD ...................................................62
To confirm/delete Recording Information ...................63
Scheduling priority ................................................................63
Camera Sensor Settings ................................................................64
Using Toshiba Places ......................................................................65
Using YouTube™ ..............................................................................65
Using the Function Menu ...................................................66
Using Hybrid TV Standard (if available) ...................................68
Using the Media Player ..................................................................68
Basic operation .......................................................................69
Viewing photo files
(on a DLNA CERTIFIED™ Server or USB device) .......70
Viewing movie files
(on a DLNA CERTIFIED™ Server or USB device) .......72
Playing music files
(on a DLNA CERTIFIED™ Server or USB device) .......75
Using the Photo Frame feature ..................................................76
To open Photo Frame ...........................................................76
Setting the features ...............................................................77
Other features ...................................................................................78
Panel Lock .................................................................................78
The timers ...........................................................................................79
Programme Timers – digital only ...................................79
On Timer ....................................................................................79
Sleep Timer ..............................................................................80
Energy Saving Settings ..................................................................80
Automatic Power Down ......................................................80
No Signal Power Down ........................................................80
Digital on-screen information and Programme Guide ......81
Information ..............................................................................81
Guide ..........................................................................................82
Genre selection/searching .................................................82
Digital settings – parental control ...........................................83
Parental PIN Setup ................................................................83
Parental Setup ........................................................................83
Network Lock ..........................................................................83
Digital settings – Channel Options ..........................................84
Selecting favourite channels .............................................84
Favourite Channel Lists .......................................................84
Skip channels ..........................................................................84
Locking channels ...................................................................84
Digital settings – other settings ................................................85
Subtitles ....................................................................................85
Audio languages ....................................................................85
Common Interface ................................................................85
Software Upgrade and Licences ................................................86
Auto Upgrade .........................................................................86
Searching for New Software ..............................................86
Network Upgrade ..................................................................86
Software Licences ..................................................................86
System Information and Reset TV .............................................87
System Information ..............................................................87
Reset TV .....................................................................................87
PC Settings .........................................................................................87
Horizontal and Vertical Position .......................................87
Clock Phase ..............................................................................87
Sampling Clock ....................................................................... 88
Reset ...........................................................................................88
Input selection and AV connections ........................................88
Input selection ........................................................................88
External input skip .................................................................89
Labeling video input sources ............................................89
PC Audio ...................................................................................90
Side Shared Audio .................................................................90
HDMI 3 Audio ..........................................................................90
HDMI Settings .........................................................................90
Digital Audio Output ............................................................90
Using Personal TV Mode ...............................................................91
Using REGZA-LINK ...........................................................................93
Enable REGZA-LINK ...............................................................93
TV Auto Power ........................................................................93
Auto Standby ..........................................................................94
Amplifier Control ...................................................................94
Initial Speaker Setting ..........................................................94
Position Key Pass Through .................................................94
REGZA-LINK input source selection ................................94
REGZA-LINK Device Control ...............................................95
REGZA-LINK one touch play ..............................................95
REGZA-LINK system standby .............................................95
REGZA-LINK system audio control ..................................95
Toshiba PC compatible with REGZA-LINK ....................95
4
English
Using MHL TV function ..................................................................96
Connecting an MHL-compatible Device .......................96
Operating an MHL-compatible Device ..........................96
MHL Setup ................................................................................96
TEXT SERVICES
Text services ......................................................................................97
Selecting modes .....................................................................97
Text information .....................................................................97
Navigating pages using Auto ............................................97
Navigating pages using LIST ..............................................97
Control buttons ......................................................................98
PROBLEM SOLVING
Questions and Answers ...............................................................99
INFORMATION
License Information ..................................................................... 102
Information ..................................................................................... 104
Specifications and accessories ................................................. 109
5
English
INSTALLING YOUR TV
Safety Precautions
This equipment has been designed and
manufactured to meet international safety standards
but, like any electrical equipment, care must be taken
to obtain the best results and for safety to be assured.
Please read the points below for your own safety.
They are of a general nature, intended to help with all
electronic consumer products, and some points may
not apply to the goods you have just purchased.
Leave more than 10cm clearance around the
television to allow adequate ventilation. This will
prevent overheating and possible damage to the
television. Dusty places should also be avoided.
Damage may occur if the television is left in direct
sunlight or near a heater. Avoid places subject to
extremely high temperatures or humidity. Place in a
location where the temperature remains between 5°C
(41°F) min. and 35°C (94°F) max.
The mains supply required for this equipment is 220-
240v AC 50/60Hz. Never connect to a DC supply or any
other power source. DO ensure that the television is
not standing on the mains lead. Use only the supplied
lead.
DO NOT cut off the mains plug from this equipment,
this incorporates a special Radio Interference Filter,
the removal of which will impair its performance.
IF IN DOUBT, PLEASE CONSULT A COMPETENT
ELECTRICIAN.
DO read the operating instructions before you
attempt to use the equipment.
DO ensure that all electrical connections (including
the mains plug, extension leads and inter-
connections between pieces of equipment) are
properly made and in accordance with the
manufacturers’ instructions. Switch off and withdraw
the mains plug before making or changing
connections.
DO consult your dealer if you are ever in doubt about
the installation, operation or safety of your equipment.
WARNING: To prevent injury, this apparatus must be
securely attached to the floor/wall in accordance with
the installation instructions. See page 6.
DO be careful with glass panels or doors on
equipment.
DO NOT obstruct the ventilation openings of the
equipment with items such as newspapers,
tablecloths, curtains, etc. Overheating will cause
damage and shorten the life of the equipment.
DO NOT allow electrical equipment to be exposed to
dripping or splashing or objects filled with liquids,
such as vases, to be placed on the equipment.
DO NOT place hot objects or naked flame sources,
such as lighted candles or nightlights on, or close to
equipment. High temperatures can melt plastic and
lead to fires.
DO NOT use makeshift stands and NEVER fix legs with
wood screws. To ensure complete safety, always fit the
manufacturer’s approved stand, bracket or legs with
the fixings provided according to the instructions.
DO NOT leave equipment switched on when it is
unattended, unless it is specifically stated that it is
designed for unattended operation or has a standby
mode. Switch off by withdrawing the plug, and make
sure your family knows how to do this. Special
arrangements may need to be made for people with
disabilities.
DO NOT continue to operate the equipment if you
are in any doubt about it working normally, or it is
damaged in any way – switch off, withdraw the mains
plug and consult your dealer.
WARNING – excessive sound pressure from
earphones or headphones can cause hearing loss.
ABOVE ALL - NEVER let anyone, especially
children, push or hit the screen and cabinet back,
or push anything into holes, slots or any other
openings in the case. These actions will damage
screen or internal parts.
NEVER connect the supplied COMPONENT
Adaptor cable, AV-SCART Adaptor cable or AV
Adaptor cable to a wall outlet. These cables are
ONLY for insertion into the socket provided for the
purpose on the rear/side of the TV.
NEVER guess or take chances with electrical
equipment of any kind - it is better to be safe than
sorry.
Air Circulation
Heat Damage
Mains Supply
Do
DO NOT REMOVE ANY FIXED COVERS AS THIS WILL
EXPOSE DANGEROUS AND ‘LIVE’ PARTS.
THE MAINS PLUG IS USED AS A DISCONNECTING DEVICE
AND THEREFORE SHOULD BE READILY OPERABLE.
Do not
WARNING: To prevent the spread of
fire, keep candles or other open
flames away from this product at all
times.
6
INSTALLING YOUR TV
English
Installation and important information
Locate the television away from direct sunlight and
strong lights. Soft, indirect lighting is recommended
for comfortable viewing. Use curtains or blinds to
prevent direct sunlight falling on the screen.
Place the TV on a stable, level surface that can
support the weight of the TV. In order to prevent
injury and maintain stability of this apparatus,
secure the TV to the level surface using the strap if
fitted, or to a wall using a sturdy tie to the P clips
provided. Otherwise secure the TV on the level
surface using the supplied mounting screw.
The LCD display panels are manufactured using an
extremely high level of precision technology;
however, sometimes some parts of the screen may be
missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Make sure the television is located in a position where
it cannot be pushed or hit by objects, as pressure will
break or damage the screen. Also, please be certain
that small items cannot be inserted into slots or
openings in the case.
When using a Wall Bracket
For 46WL, 55WL, 46YL and 55YL series, always use the
screws recommended by the wall mount
manufacturer.
• Interoperability with MHL devices of other manufacturers is not guaranteed.
• Toshiba does not provide any guarantee, therefore, against operational failure such as that described below when an MHL
source is connected to the TV.
- No picture or sound
- Some of the functions do not work by remote operation from the TV
• If the MHL does not work properly, also contact the manufacturer of the source device for advice on its use.
• Do not disconnect the the power plug when the TV is active and the MHL device is being connected.
• Do not disconnect the the power plug when the TV is in standby mode and the MHL device is being connected.
Where to install
When using MHL (Mobile High-definition Link)
Sturdy tie (as short as possible)
Stand clip
Fixing strap
Screw
(supplied)
Fixing strap
‘P’ Clip
Stand style is dependent on model
Remove four screws.
(Do not reuse these screws for
attaching a wall bracket.)
7
INSTALLING YOUR TV
English
The digital reception function of this television is only effective in the countries listed in the “Country” section of
the “Setup/System Setup” menu. Depending on country/area, some of this television’s functions may not be
available. Reception of future additional or modified services can not be guaranteed with this television.
If stationary images generated by 4:3 broadcasts, text services, channel identification logos, computer displays,
video games, on-screen menus, etc. are left on the television screen for any length of time, they could become
conspicuous. It is always advisable to reduce both the brightness and contrast settings.
Very long, continuous use of the 4:3 picture on a 16:9 screen may result in some retention of the image at the 4:3
outlines. This is not a defect of the LCD TV and is not covered under the manufacturer’s warranty. Regular use of
other size modes (e.g.: Super Live) will prevent permanent retention.
• The recording function has been designed for private
use and entertainment in your home environment.
Please note that any commercial use of the recording
function could lead to copyright infringement of
authors’ rights. Toshiba asks you to respect the
intellectual property rights of third parties.
• Before recording to a device connected to the TV, make
a test recording and check the recording performance.
• Programmes that are prohibited from copying due to
copyright protection cannot be recorded.
• Toshiba shall not be liable for compensation or
incidental damages of any kind whatsoever resulting
from content that was not properly recorded on the
recording device or that was modified or lost.
• Toshiba shall not be liable for damages of any kind
whatsoever (breakdown of the recording device,
modification or loss of the recorded content, etc.)
resulting from malfunction, operating failure or
incorrect operation due to combining with another
connected device.
• If you connect and register a USB HDD that has been
used with a PC or another TV, all the data and recorded
programmes stored on the disk will be deleted.
• To use a USB HDD that has been used with this TV on a
PC, the hard disk must first be formatted with the PC. At
this time, all the data stored using the TV will be
deleted.
• Do not turn off the power supply to the USB HDD or
disconnect the connecting cable while the USB HDD is
operating.
Doing so may result in loss of the recorded data or
malfunction of the USB HDD.
• If you connect a USB bus-powered device to the USB 1
port, it may interfere with recording on the USB HDD.
• The recording function is not available in all countries.
• Please note that recording on the USB HDD is no longer
playable after the TV’s main-board is exchanged during
service.
Please take note
EXCLUSION CLAUSE
Toshiba shall under no circumstances be liable for loss and/or damage to the product caused by:
i) Fire;
ii) Earthquake;
iii) Accidental damage;
iv) Intentional misuse of the product;
v) Use of the product in improper conditions;
vi) Loss and/or damage caused to the product whilst in the possession of a third party;
vii) Any damage or loss caused as a result of the owner’s failure and/or neglect to follow the instructions set out in the owner’s manual;
viii) Any loss or damage caused directly as a result of misuse or malfunction of the product when used simultaneously with
associated equipment;
Furthermore, under no circumstances shall Toshiba be liable for any consequential loss and/or damage including but not
limited to the following: loss of profit, interruption of business, the loss of recorded data whether caused during normal
operation or misuse of the product.
When Using a USB HDD (not supplied)
8
INSTALLING YOUR TV
English
Available 3D glasses: Toshiba FPT-AG02G
YL86 and YL87 series : Supplied
WL86 series : Not supplied
• The 3D function has been designed for private use and
entertainment in your home environment.
Please note that any commercial use of the 3D function
could lead to copyright infringement of authors’ rights.
Toshiba asks you to respect the intellectual property
rights of third parties.
About handling the 3D glasses
• Do not leave the 3D glasses or the accessories within the
reach of small children.
Inhaling or swallowing them may cause suffocation or
lesions in the stomach wall.
If swallowed, consult a doctor immediately.
• Do not repair, modify, or disassemble the 3D glasses by
yourself.
Doing so may cause a fire or cause you to become
indisposed while viewing 3D images.
Contact the Toshiba Call Center for repair of your 3D
glasses.
• Do not expose the glasses to excessive heat such as
sunshine, fire, or the like.
About the 3D glasses
• Do not use the 3D glasses if they are not working
properly or broken.
Continuing to use them in such a state may cause injury, eye
strain, or indisposition.
Do not use the 3D glasses if they are broken or have any
cracks.
• Do not stand or walk while wearing 3D glasses.
You may lose your balance which could result in falls or
other accidents.
• Do not wear the 3D glasses for any purpose other than
viewing 3D programming.
3D glasses do not function as sunglasses.
• Do not drop, exert pressure on, or step on the 3D
glasses.
Doing so may damage the glass section, which may result in
injury.
Exposing the 3D glasses to liquid or excessive heat may
damage the liquid crystal shutter function.
• If your nose or temple turns red, or you feel pain or
discomfort, stop using the 3D glasses.
Such symptoms as above may occur if you keep wearing
them for a long time, which may also cause indisposition.
• Be careful not to pinch your fingers in the hinge of the
3D glasses.
Cautions on watching 3D images
• Some viewers may experience a seizure or blackout
when exposed to certain flashing images or lights
contained in certain 3D television pictures or video
games.
Anyone who has had a seizure, loss of awareness, or other
symptoms linked to an epileptic condition, or has a family
history of epilepsy, should contact a health care provider
before using the 3D function.
• Avoid use of the 3D function when under the influence
of alcohol.
• If you are ill or feel ill, you should refrain from viewing
3D images, and consult your health care provider as
may be appropriate.
• If you experience any of the following symptoms when
viewing 3D video images, stop viewing and contact
your health care provider:
Convulsions, eye or muscle twitching, loss of awareness,
altered vision, involuntary movements, disorientation, eye
strain, nausea/vomiting, dizziness, headaches.
• If you feel eye fatigue or other discomfort from viewing
3D video images, remove the 3D glasses and
discontinue use until the condition is eliminated.
• Viewing in 3D may cause dizziness and/or
disorientation for some viewers.
Therefore, to avoid injury do not place your TV near open
stairwells, balconies, or wires.
Also do not sit near objects that could be broken if
accidentally hit.
• When viewing 3D images, always wear 3D glasses.
Watching 3D images without 3D glasses may cause eye
strain.
Use specified 3D glasses.
• When watching 3D images, do not wear 3D glasses at an
angle and do not lie down.
If you watch while lying down or with the glasses tilted, the
3D effect is lost and it may cause eye strain.
• It is recommended that the viewer’s eyes and 3D glasses
are level with the screen.
• If you have prescription eye glasses or contact lenses,
wear the 3D glasses over them.
Watching 3D images without appropriate eyewear may
cause eye strain.
• If 3D images often appear in double or if you cannot see
the images in 3D, stop viewing.
Continuous viewing may cause eye strain.
• Due to the possible impact on vision development,
viewers of 3D video images should be age 6 or above.
Children and teenagers may be more susceptible to health
issues associated with viewing in 3D and should be closely
supervised to avoid prolonged viewing without rest.
When using the 3D glasses
9
INSTALLING YOUR TV
English
• Watching TV while sitting too close to the screen for an
extended period of time may cause eye strain.
The ideal viewing distance should be at least three times
the screen height.
• Watch the TV within effective viewing angle.
Otherwise, you may not see the correct 3D image. Effective
viewing angle:
- Within 30° horizontal, 20° vertical
Notes on handling the 3D glasses’ liquid crystal
shutter lenses
• Do not put excessive force on the lenses.
• Do not scratch the surface of the lenses with sharp
objects.
• Do not drop or bend the 3D glasses.
Notes on IR communication
• Do not block the IR sensor for 3D glasses on the TV by
placing objects in front of it.
• Do not cover the IR sensor on the 3D glasses with
stickers or labels.
• Keep the IR sensor on the 3D glasses clean.
• The use of 3D glasses could interfere with other IR
communication devices. Other IR communication
devices may cause the 3D glasses not to work correctly.
Use the TV and 3D glasses in a place where they will not
interfere with other devices or products.
Notes on watching the TV
• 3D effect and image quality may vary depending upon
content quality and display device capability/
functionality/settings.
• If you use any device, such as a mobile phone or mobile
wireless device, near the 3D glasses, the 3D glasses may
not work correctly.
• Use the product in the following temperature range;
otherwise, the quality of the 3D image or the reliability
of the product cannot be guaranteed.
- 3D glasses: 0°C - 40°C (32°F - 104°F)
- TV: 0°C - 35°C (32°F - 95°F)
• If you use a fluorescent light, it may flicker depending
on the frequency of the light. In this case, reduce the
brightness of the fluorescent light, or use another light.
(It is not recommended to watch the TV in a dark room,
especially for children.)
• Wear the 3D glasses properly, otherwise you may not
see the correct 3D image.
• When not viewing 3D images on this unit, take off the
3D glasses; otherwise, it may be difficult to see the
display on other products such as PC, digital clock or
calculator, etc.
About the connecting cable
• Use a high-speed and high-quality HDMI cable when
you connect a device such as 3D compatible BD player
or PC to the TV. When you use a standard HDMI cable,
3D images may not be shown.
About the lithium-ion polymer rechargeable
battery
• Do not nail, hammer, or step on the battery.
Doing so may cause a short circuit, leading to overheating,
cracking, or fire.
• Do not overheat, disassemble, or short-circuit the
battery, or throw it into fire.
Doing so may cause cracking or fire.
• Do not connect the battery cord with metal items such
as wires. Also, do not carry or store the battery with
metal items such as necklaces or hairpins.
Doing so may cause a short circuit, leading to overheating,
cracking, or fire.
Screen height
If the 3D PIN number has been forgotten:
Use the Master PIN code of 1276, and then change to a
number of your choice. Select 3D PIN Setup from the
Preferences / 3D Setup menu to enter PIN.
10
INSTALLING YOUR TV
English
The camera sensor installed in this TV can detect a person’s
face or movement and identify individuals by their registered
faces. Please note that certain factors can affect the
performance of the sensor function as set out below.
General Sensor Function
• For the sensor to operate (for each function) you will need
to be within the sensor detection range as set out below.
• The approximate effective detection range of the camera
sensor is as shown below. (Note: The distance and angle of
the detection range are based on a standard viewing
environment and conditions).
– Horizontal angle: approx. 58° (approx. 29° × 2)
– Vertical angle: approx. 34° (upward approx. 27°,
downward approx. 7°)
–Distance: approx. 50 cm to 500 cm (Personal Identification
Function: approx. 50 cm to 400 cm)
• Do not place anything in front of the TV that may
obstruct detection or reduce the sensor detection
range.
Motion Detection Function
• Motion detection may be affected by the surrounding
environment, such as the brightness of the room. In
addition, very slight, small or momentary movement may
be undetected.
• Sensor performance can be enhanced by making sure the
room is brightly lit and using prolonged and obvious
movements.
• Billowing curtains, a pet or variations in illumination in the
detection range may be detected as motion, even if there is
no person there.
• You can use the camera sensor confirmation menu to check
that no movement made by other persons is being
detected.
Face Detection Function
• The sensor can detect up to eight persons.
• Face Detection may be affected if:
– Your face is obstructed or partially hidden, for example,
by your hair, a mask or a hat,
– Your head is tilted or turned to one side, or
– You are wearing dark glasses or the light is reflected in
your glasses.
• You can use the camera sensor confirmation menu to check
whether your face is detected.
• The camera sensor may detect background images such as
a picture portrait or the pattern on the wall as eyes or nose
even if there is no person there. You can use the
confirmation screen to check whether any such object in
the detection range is being incorrectly detected as a face.
• Face Detection can be less effective on darker complexions
and in darker environments.
• Face Detection can be enhanced by making sure your face
is clearly visible and evenly lit. If the room is dark, Face
Detection can be enhanced by making sure the room is
brightly lit. If the lighting environment creates a shadow on
your face, Face Detection can be enhanced by adjusting the
lighting to prevent shadows.
Personal Identification Function
• The Personal Identification Function is part of the Face
Detection Function. The factors affecting the Face
Detection Function set out above also apply to the Personal
Identification Function.
• Personal Identification may in addition be affected by:
– A different shadow pattern from that when your face was
registered. Personal Identification accuracy can be
enhanced by registering additional facial images under
different conditions.
– A different lighting environment from when your face was
registered, such as during the day and at night. Personal
Identification accuracy can be enhanced by registering
your face under various lighting environments.
– Whether or not you are wearing glasses. If you wear
glasses, we recommend that you register your face both
with and without glasses.
– A different facial expression. Personal Identification accuracy
can be enhanced by registering different facial expressions.
• Personal Identification may be affected when faces have
similar characteristics (e.g. brothers, sisters, twins).
• Personal Identification is less effective on the faces of young
children.
Face Registration Function
• Up to four people can be registered under the Personal
Identification Function. The same person cannot be
registered twice.
• A maximum of 10 different facial images per person can be
registered. Personal identification accuracy can be enhanced
by registering different facial images as set out above.
• It is advisable to register your face in your usual viewing
position and with your natural facial expression. Registering
your face too near to or too far from the screen may hinder
identification performance.
About the Camera Sensor
27°
7°
Face Detection (50 ~ 500cm)
Personal
Identication
(50 ~ 400cm)
11
INSTALLING YOUR TV
English
The remote control
Simple at-a-glance reference of your remote control.
1For On/Standby mode
2To select external input sources
3To select TV Mode
4To access Quick Menu
5To access the “TOSHIBA PLACES” Top Page
When network is not connected, an error message will be
displayed.
6To access the analogue or digital Channel List
7To alter the TV volume
8Switch the Audio Description On/Off
9To mute the TV sound
10 To change programme positions
To change TEXT pages
11 On-screen Menus
12 To display the digital on-screen Programme Guide
13 When using menus, the arrows move the cursor on the
screen up, down, left or right
14 Press OK to confirm your selection
15 To return to previous Menu
16 To exit menus
17 Colour buttons: Text and interactive service control
buttons
18 Number buttons
19 To display on-screen information
To access the index page in Text mode
20 To return to previous programme position
22 To record TV programmes
23 To call up text services
24 To switch between 2D and 3D mode
25 Picture still
26 To access Media Player Menu
27 Selectable Picture preferences
28 Widescreen viewing
29 s Stereo/bilingual transmissions
30 To access More Information Menu
31 Digital Subtitles or Analogue TEXT Subtitle pages if
available
Remove the back cover to
reveal the battery
compartment and make sure
the batteries are inserted the
proper way. Suitable battery
types for this remote are AAA,
IEC R03 1.5V.
Do not combine a used, old
battery with a new one or mix
battery types. Remove dead
batteries immediately to prevent acid from leaking into the
battery compartment. Dispose of them in accordance with
instructions on page 103 of this manual.
Warning: Batteries must not be exposed to excessive heat
such as sunshine, fire or the like.
The performance of the remote control will deteriorate
beyond a distance of five metres or outside an angle of 30
degrees from the centre of the television. If the operating
range becomes reduced, the batteries may need replacing.
16
20
31
30
24
19
17
15
13
11
7
5
4
2
1
18
25
28
27 29
26
14
12
9
10
8
6
3
21
22 23
21 When in TV mode:
DAnalogue time
display
When in Text mode:
ATo reveal concealed
text
BTo hold a page
CTo enlarge text
display size
DTo select a page
while viewing a
normal picture
When using Programme
Guide:
Z –24 hours
z +24 hours
CC –1 page
cc +1 page
During Playback:
c
To PLAY
vTo STOP
W/wTo PAUSE/STEP
To start Time Shift
Recording
ZTo SKIP-BACK
CC To REWIND
cc To FAST FORWARD
zTo SKIP-FORWARD
Inserting batteries and effective range
12
English
CONNECTING YOUR TV
Connecting external equipment
Before connecting any external equipment, turn off all main power switches. If there is no switch,
remove the mains plug from the wall socket.
Aerial cables:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the aerial to the socket on the rear of the television.
If you use a decoder and/or a media recorder, it is essential
that the aerial cable is connected through the decoder and/or
through the media recorder to the television.
Satellite cable: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the LNB from the satellite dish to the SATELLITE
ANTENNA socket on the TV. You can receive TV, radio,
interactive TV, and HD TV with clear reception.
SCART leads: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the media recorder IN/OUT socket to the television.
Connect the decoder TV socket to the television.
Before running Auto Tuning, put your decoder and media
recorder to Standby.
The Digital Audio Output socket enables the connection of a
suitable surround sound system.
NOTE: This output is always active.
HDMI® (High-Definition Multimedia Interface) is for use with a
DVD decoder or electrical equipment with digital audio and
video output. For acceptable video or PC signal formats
through the HDMI terminals, see page 105.
NOTE: Although this television is able to connect to HDMI
equipment, it is possible that some equipment may not
operate correctly.
LAN port is used to connect the TV to your home network.
This TV can play digital content stored on a DLNA CERTIFIED™
product with server function.
A wide variety of external equipment can be connected to
the back of the television; therefore, the relevant owner’s
manuals for all additional equipment must be referred to
for exact instructions.
If the television automatically switches over to monitor
external equipment, return to normal television by pressing
the desired programme position button. To recall external
equipment, press o to select between DTV, EXT 1, EXT 2,
EXT 3, HDMI 1, HDMI 2, HDMI 3, HDMI 4, PC or ATV.
When the external input mode is selected while viewing DTV
mode, the SCART socket does not output video/audio signals.
Cable clamps (for Stand type)
Cable clamps
(for Wall Mount type)
RGB/PC INPUT
EXT 1
*
HEADPHONE jack
LAN port
HDMI 1/2/3/4 INPUTS
COMPONENT
VIDEO INPUT
(EXT 2)
* When using the COMPONENT VIDEO INPUT (EXT 2), also connect
the AV Adaptor cable ② (RED and WHITE plugs) as Audio cables
to the VIDEO/AUDIO INPUT (EXT 3). EXT 3 Audio is shared.
VIDEO/AUDIO INPUT (EXT 3)
DIGITAL AUDIO
OUTPUT (OPTICAL)
Satellite dish
Media Recorder
Aerial Cable
“F-type”
13
CONNECTING YOUR TV
English
Connecting an HDMI® or DVI
device to the HDMI input
The HDMI input on your television receives digital
audio and uncompressed digital video from an
HDMI source device or uncompressed digital
video from a DVI (Digital Visual Interface) source
device.
This input is designed to accept HDCP (High-Bandwidth
Digital-Content Protection) programme material in digital
form from EIA/CEA-861-D–compliant consumer electronic
devices (such as a set-top box or DVD player with HDMI or DVI
output). For acceptable video signal formats, see page 105.
NOTE:
• Some early HDMI equipment may not work properly with
your latest HDMI TV, due to the adoption of a new standard.
Please unplug your HDMI cable first and then try setting the
INSTAPORT™ and Enable Content Type options to “Off”.
Your early HDMI source should operate properly with your
television. See page 90.
• Supported Audio format: Linear PCM, Dolby Digital (AC-3),
sampling rate 32/44.1/48kHz.
Connect an HDMI cable (type A connector) to the HDMI
terminal.
For proper operation, it is recommended that you use an
HDMI cable with the HDMI Logo ( ).
• If your HDMI connection is capable of 1080p and/or your
television is capable of refresh rates greater than 50Hz, you
will need a Category 2 cable. Conventional HDMI/DVI cable
may not work properly with this model.
• HDMI cable transfers both video and audio. Separate
analogue audio cables are not required (see illustration).
• See “HDMI 3 Audio” section on page 90.
To view the HDMI device video, press the o button to select
HDMI 1, HDMI 2, HDMI 3 or HDMI 4 mode.
Connect an HDMI-to-DVI adaptor cable (HDMI type A
connector) to the HDMI 3 terminal and audio cables to the PC/
HDMI 3 (AUDIO) socket (see illustration).
• The recommended HDMI-to-DVI adaptor cable length is
6.6 ft (2m).
• An HDMI-to-DVI adaptor cable transfers video only.
Separate analogue audio cables are required.
• See “HDMI 3 Audio” section on page 90.
NOTE:
To ensure that the HDMI or DVI device is reset properly, it is
recommended that you follow these procedures:
• When turning on your electronic components, turn on the
television first, and then the HDMI or DVI device.
• When turning off your electronic components, turn off the
HDMI or DVI device first, and then the television.
This feature enables the audio signal of the TV to be sent to
the AV amplifier via the HDMI cable. It will not be necessary to
connect a cable from the audio output of the TV to the audio
input of the AV amplifier to reproduce the audio received
from the tuner of the TV through the AV amplifier.
To connect an HDMI device
the back of your television
HDMI device
HDMI cable
To connect a DVI device
HDMI’s ARC (Audio Return Channel)
feature
Audio cable for HDMI to television
connection (not supplied)
HDMI-to- DVI adaptor Cable
DVI device
the back of your television
the back of your television
AV amplier that supports ARC
HDMI cable
14
CONNECTING YOUR TV
English
REGZA-LINK connection
You can control the basic functions of connected audio/video devices using the television’s remote
control if you connect a REGZA-LINK compatible AV amplifier or playback device. For an explanation of
setup and operations, see pages 93–95.
For the setup shown above, you will need three HDMI cables.
NOTE:
• If several devices are connected, the REGZA-LINK feature
may not operate properly.
• For proper operation, it is recommended that you use HDMI
cables with the HDMI Logo ( ).
• This function is available when one PC and one AV amplifier
are connected separately. However, it may not operate
properly if the PC is connected via the AV amplifier.
Before controlling the device(s):
• After completing the above connections, set the REGZA-
LINK Setup menu as you desire (see page 93).
• The connected devices must also be set. For details, see the
operation manual for each device.
• The REGZA-LINK feature uses CEC technology as regulated
by the HDMI standard.
• This feature is limited to models incorporating Toshiba’s
REGZA-LINK. However, Toshiba is not liable for those
operations. Refer to individual instruction manuals for
compatibility information.
the back of your television
AV amplier Playback device
Playback device
15
CONNECTING YOUR TV
English
Connecting a computer
With either an RGB/PC or an HDMI connection, you
can watch your computer’s display on the
television and hear the sound from the television’s
speakers.
When connecting a PC to the RGB/PC terminal on the
television, use an analogue RGB (15-pin) computer cable and
a PC audio cable for the PC/HDMI 3 (AUDIO) socket. Select PC
from the PC/HDMI 3 Audio options in the AV Connection
menu located in the Preferences menu.
To use a PC, set the monitor output resolution on the PC
before connecting it to the television. For acceptable PC
signal formats, see page 104.
To display the optimum picture, use the PC setting feature
(see page 87).
NOTE:
• The PC audio input terminal on the television is shared with
the HDMI 3 analogue audio input terminal (see page 90).
• Some PC models cannot be connected to this television.
• An adaptor is not needed for computers with a compatible
mini D-sub15-pin terminal.
• Depending on the DVD’s title and the specifications of the
PC on which you are playing the DVD-Video, some scenes
may be skipped or you may not be able to pause during
multi-angle scenes.
• A band may appear at the edges of the screen or parts of the
picture may be obscured. This is due to scaling of the
picture by the set, it is not a malfunction.
• When PC input mode is selected, some of the television’s
features will be unavailable e.g. Colour System in the
Setup/System Setup menu.
• Some PC models may output unique signals that the
television may be unable to detect (see page 104).
• If connecting a certain PC model with a unique PC signal,
the PC signal may not be detected correctly.
When connecting a PC to the HDMI terminal on the television,
use an HDMI-to-DVI adaptor cable and an analogue audio
cable.
If connecting a PC with an HDMI terminal, use an HDMI cable
(type A connector). A separate analogue cable is not
necessary.
For acceptable PC and video signal formats, see page 105.
NOTE:
• The edges of the images may be hidden.
• If connecting a certain PC model with a unique PC signal,
the PC signal may not be detected correctly.
To connect a PC to the RGB/PC terminal
Computer
Audio cable for PC to television
connection (not supplied)
the back of your television
Conversion adaptor
if required
(not supplied)
Mini D-sub
15 pin connector
RGB PC cable
(not supplied)
To connect a PC to the HDMI terminal
Computer
Audio cable for PC to
television connection (not
supplied)
HDMI-to- DVI
adaptor Cable
the back of your television
16
CONNECTING YOUR TV
English
Connecting a home network
The LAN port allows your Toshiba TV to connect to
your home network. You can use this revolutionary
home entertainment networking system to access
photo, video and audio files that are stored on a
DLNA CERTIFIED™ server and play/display them on
your TV.
NOTE:
• If you connect to a shared network outside your home, it is
advisable to use a router. Always use DLNA CERTIFIED™
products in private network environments.
• If you use a hub or switch to connect the TV to your home
network, you may not be able to use the automatic setup
and will have to manually set up the network address. See
page 52.
• If you use a router with built-in DHCP functionality, use the
automatic setup. Manual setup may not work.
• If you connect the TV and PC directly, use a crossover LAN
cable.
[1] Coaxial or telephone cable (depending on your modem type)
[2] Standard LAN cable
[3] Do NOT connect a phone jack directly to the TV’s LAN port.
Please refer to “Wireless Setup” section on page 49.
To connect the TV to a home network -
Wired
Modem (if available)
Server PC
Router with Hub
the back of your television
Cable or Phone jack
[1] [2]
[2]
[3][2]
To connect the TV to a home network
with an internet connection - Wireless
Access point (AP)
Wireless LAN router
Modem
TV (Built-In WLAN system)
Computer
17
CONNECTING YOUR TV
English
Setting up the USB HDD
To connect an USB HDD (not supplied)
NOTE: For available USB HDD information, see "Product Information" on the website.
To register an USB HDD
When you connect a new USB HDD to the USB 2 port on the
TV, the following screen will appear.
aPress C or c to select Yes and press OK.
The formatting confirmation window will appear.
bPress C or c to select Yes and press OK.
Registration will start.
cIf you want to name the USB HDD, press C or c to
select Yes and press OK.
See page 53 to input characters.
The maximum number of characters is 10.
If you prefer the default name ”USB HDD X,” select No
and press OK.
dThe Device List will appear.
You can now use registered USB HDDs.
While in the list mode, the following key operations
are available:
OK button................. To register/remove
RED button .............. To disconnect
GREEN button ........ To change Device Name
YELLOW button..... To test
BLUE button............ To format
NOTE:
• To disconnect a USB HDD from the TV, follow the
procedures for “To disconnect a USB HDD” section
(page 62).
• When using a USB HDD, if necessary, perform the settings
and operations shown in “Using the USB HDD Function”
section (see page 55).
• Connect the USB HDD to the USB 2 port.
Recording and playback cannot be performed if connected
to the USB 1 port.
• Up to 8 USB HDDs can be registered to this TV.
• Recorded programmes saved on the USB HDD can only be
viewed on this TV. They cannot be viewed when connected
to another TV (including the same model of TV), a PC, or
other device.
• If an HDD is re-registered, it will not be formatted.
• When the USB HDD is formatted, all the data stored on the
HDD will be deleted.
USB2
USB cable
(not supplied)
USB HDD
An unregistered USB HDD has been detected.
Register the USB HDD?
Yes
Device Name Registered Connected
USB HDD 1
USB HDD 2
USB HDD 3
Device List
18
CONNECTING YOUR TV
English
Controls and input connections
A wide variety of external equipment can be connected to the input sockets on the side of the television.
While all the necessary adjustments and controls for the television are made using the remote control, the
buttons on the television may be used for some functions.
If the RED LED is not lit, check that the mains plug is
connected to the power supply and press 1 on the remote
control; it may take a few moments. The BLUE LED will be lit.
To put the television into Standby, press 1 on the remote
control. To view the television, press 1 again. The picture may
take a few seconds to appear.
Press MENU on the remote control to display the menu.
The five initial topics icons will appear. As each symbol is
selected by pressing C or c on the remote control.
Press Bb C c to enter a sub menu and then enter a further
sub menu to see any options.
NOTE: The same menu is displayed in DTV (Digital TV) and
ATV (Analogue TV) modes; however, where some items are
not available in a mode, they will appear grayed out.
To use the option, press B and b on the remote control to
move up and down and press C or c to select your desired
setting. Follow the on-screen instructions. The functions of
each menu are described in detail throughout the manual.
To alter the volume gently touch – 2 +.
To alter the programme position touch b p B.
Touch MENU and b p B, – 2 + to control the sound and
picture options.
Touch MENU to finish.
To select an external input, touch o until the appropriate
input source is selected.
The Media Player feature provides access to photo, movie and
music files stored on a USB storage device that is connected
via the USB 1 or USB 2 port or on a network device.
The USB 2 port has to be used with a USB HDD (not supplied)
in order to record/playback TV programmes.
NOTE: The USB socket has limited functionality and Toshiba
can take no responsibility for damage to other connected
equipment.
Please always refer to the owner’s manual of the equipment to be
connected for full details.
NOTE: Interactive video games that involve shooting a “gun”
at an on-screen target may not work with this TV.
Ambient Light Sensor
Camera Sensor
Control panel (touch sensor)
3D IR
• RED (in 3D mode)
ORANGE LED – Programme timer
set (digital only)
RED LED – Programme timer
Active (digital only)
RED LED – Standby
BLUE LED – Power on
COMMON INTERFACE
The Common Interface is for a
Conditional Access Module (CAM).
Contact a service provider.
The software updating of CI Plus
CAM may be automatically
executed. At this time, your
Recording/Reminder program-
ming will be canceled.
USB 1 port
Media Player
USB 2 port
Media Player/
USB HDD connection port
Switching on
For energy saving:
We recommend that you use the television with the factory
settings. The factory settings are for energy saving.
Unplugging the mains plug will cut energy use to zero for
all televisions. This is recommended when the television is
not being used for a long time, e.g. when on holiday.
Reducing the brightness of the screen will reduce energy use.
Energy efficiency cuts energy consumption and thus saves
money by reducing electricity bills.
NOTE: Putting the television into standby mode will reduce
energy consumption, but will still draw some power.
Using the menu system
Using the TV controls and connections
19
CONNECTING YOUR TV
English
MENU structure
To open the main menu (illustration below) , press MENU on the remote control or on the TV control panel.
1st Layer 2nd Layer 3rd Layer
Press MENU. Press C c / B. Press C c.Press OK. Press BbC c.
TV Programmes
Guide
Genre Search
Programme Timers
Library
Jump to Programme Guide (EPG)
Jump to Genre Search
Jump to Programme Timers
Jump to Library
Media Player
Movie
Music
Media Player Setup
Device Select or Photo Viewer
Device Select or Movie Viewer
Device Select or Music Viewer
Media Player Setup Menu
Connected TV
Toshiba Places
YouTube
Jump to Toshiba Places
Jump to YouTube
Function
Photo Frame
On Timer
Sleep Timer
Jump to Photo Frame
On Timer Menu
Sleep Timer Menu
Setup
Sound
Preferences
System Setup
Picture Menu
Sound Menu
Preferences Menu
System Setup Menu
TV Programmes
Media Player Connected TV
Setup
Function
Programme
Timers
Genre Search Library
Guide
20
English
SETTING UP YOUR TV
Startup Application
Before switching on the television, set your
decoder and media recorder, if applicable, to
Standby. To set up the television, use the buttons
on the remote control as detailed on page 11.
aPress the 1 button. The Menu Language screen will
appear. This screen will appear the first time that the
television is switched on and each time Reset TV is
selected.
bPress B b C c to select the menu language and
press OK.
cHighlight Country and press C or c to select. The
television is now set to tune the stations for your
country.
NOTE:
• The following display menus will differ slightly
according to the country you selected.
• If there is not a country that you want to select in the
list, select Others.
dPress OK, and the Location screen will appear.
ePress C or c to select Home or Store. For normal
home use, select Home.
fPress OK, and the TV Mounting screen will appear,
press C or c to select Stand or Wall.
gPress OK, and the AutoView screen will appear. Press
C or c to select Yes or No.
hPress OK. If the Ant/Cable/Satellite screen appears,
press B or b to select Antenna, Cable or Satellite
and press OK to check ( ).
If DVB-C is not supported in your area, Cable will not
be displayed.
• When you select Antenna or Cable, follow steps 9
to 12.
• When you select Satellite, skip to step 13.
• When you select Antenna (or Cable) and Satellite,
the Satellite Settings startup screen will appear
automatically after completing the Antenna (or
Cable) scan and pressing OK.
iSelect Next and press OK. The Auto Tuning start up
screen will appear with the option to select between
DTV and ATV, DTV or ATV if available. Use C or c to
select the appropriate mode.
jPress B or b to highlight Start Scan and press OK.
The television will start to search for available DTV
and/or ATV channels. The progress bar will indicate
the scan status.
You must allow the television to complete the
search.
When the search is complete, the television will
automatically select position one.
The Auto Tuning screen will display the total number
of services found.
NOTE: If there are multiple channels with the same
channel number, a confirmation window will appear.
Press C or c to select the one you prefer.
Quick Setup
Quick Setup
Country
Germany
Primary Subtitle Language
German
English
English
English
Secondary Subtitle Language
Primary Audio Language
Secondary Audio Language
Location
Home
To use the TV for displaying in a store showroom, please
select [Store]. [Home] mode is recommended for normal
use.
TV Mounting
Stand
If you are mounting the TV on a wall please select [Wall].
[Stand] is recommended for other uses.
This setting may be modified later under Sound Navi in the
Sound menu.
AutoView
No
AutoView mode automatically adjusts picture settings
to suit ambient light conditions.
Do you wish to enable AutoView mode?
Ant/Cable/Satellite
Satellite
Cable
Next
Antenna
Auto Tuning
Progress Found
ATV Tune Waiting...
Channel: C7
DTV Tune 3% 2
21
SETTING UP YOUR TV
English
kPress C or c to view the DTV (digital channel) or ATV
(analogue channel) lists.
lPress B or b to move through the list to select a
channel and press OK to view.
In ATV mode, some areas may receive duplicate
stations. There may not be a clear picture or the signal
may be weak, so the station order can be changed
using ATV Manual Tuning.
REMEMBER: Press TV at any time to select between
ATV and DTV (DTV Ant TV/Radio/Text, DTV Cable TV/
Radio/Text, DTV Sat TV/Radio/Text if available)
modes.
NOTE: The time will be set automatically by
transmission but can be advanced or decreased by
using Local Time Setting in the DTV Settings screen.
mSelect Next and press OK. The Satellite Settings
screen will appear. From this window, you can add the
satellites that you wish to tune and configure detailed
settings for each one individually. See “Satellite
Settings” on page 22.
Highlight Done and press OK.
nIf your satellite dish is movable, the following
Positioning screen will appear.
Press B or b to highlight Positioning and press C or
c to find the dish position with the strongest signal
level.
Press B or b to highlight Store Position and press
OK to store the dish position. Repeat steps 13 and 14
for the next satellite as necessary.
If your satellite dish is not movable, the Positioning
screen will not appear.
Adjust the dish position manually for the maximum
Signal Level strength.
Highlight Done and press OK.
oIf the reception testing completes successfully, the
Auto Tuning startup screen will display.
You can select Scan Option from Free to Air and All.
pPress B or b to highlight Start Scan and press OK.
The television will start to search for available DVB-S
channels. The progress bar will indicate the scan
status.
When the search is complete, the Auto Tuning results
screen will display the total number of services found.
qPress B or b to move through the list to select a
channel and press OK to view.
From this menu, you can set the RF input configuration.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight System Setup icon.
cPress OK to display System Setup menu.
dPress B or b to select Ant/Cable/Satellite and press
C or c to select Antenna, Cable or Satellite.
NOTE: When you attempt to change the Ant/Cable/
Satellite setting, a warning message will appear
followed by PIN entry (if PIN has been set) and a
prompt for Auto Tuning.
SatelliteNo. Dish LNB
ASTRA 19.2˚E
Satellite Settings
1
4
3
2
11
Transponder : 1/83 (10743 MHz)
Dish Type : Fixed
Lower LOF (MHz) : 9600
Upper LOF (MHz) : 10600
Switch Type None
LNB Power On
Done
Positioning
Signal Level 30%
Go to Stored Position
Store Position
Transponder
1/83 (10743 MHz H)
Positioning
WE
Go to 0
Satellite : ASTRA 19.2°E
Step Size
1
PLEASE NOTE
The Quick Setup menu can also be accessed at any
time from the Setup/System Setup menu.
Ant/Cable/Satellite (if available)
Auto Tuning - Satellite
Start Scan
Satellite
Free to Air
ASTRA(19.2°E)
Scan Option
22
SETTING UP YOUR TV
English
eWhen Ant/Cable/Satellite is set to Cable, the
following setting options will be provided in the Auto
Tuning screen.
Press B or b to select an item and press C or c to
select your desired option.
With the exception of DTV Scan Type and DTV Modulation
items, all of the following items will have 2 operating modes.
The first is Auto where the values for each item are preset by
the system. The second is an Input mode where you will be
able to enter a single value in place of the pre-set value. If no
channel is currently tuned and the Input state is chosen, a
system default value will be shown. However, if a channel is
currently tuned when the item is accessed, the value of the
current channel will be displayed.
DTV Scan Type:
This item determines whether a Quick Scan or a Full Scan will
be executed.
The Quick Scan is a simplified version of the Full Scan that is
designed to complete in less time.
DTV Start Frequency:
This sets the frequency from which the scan will begin.
DTV End Frequency:
This sets the frequency at which the scan will end.
DTV Modulation:
You can choose from five QAM modulation settings.
DTV Symbol Rate:
This is the baud rate (KS/s) of the scan.
DTV Network ID:
This is the Network ID to be utilized for the scan. This item is
grayed out when DTV Scan Type is set to “Full Scan”.
From the System Setup menu, you can add the satellites that you
wish to tune and configure detailed settings for each one
individually.
To add a satellite:
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight System Setup icon.
cPress OK to display System Setup menu.
dPress B or b to select Satellite Settings and press
OK.
ePress b to highlight a new line to add an another
satellite and press OK.
fPress b until the required satellite is displayed and
press OK.
To delete a satellite:
aIn the Satellite Settings menu, press B or b to select
the satellite you want to delete.
bPress the RED button. A confirmation window will
appear.
cPress C or c to select Yes and press OK.
NOTE: It is not possible to delete position No.1.
Auto Tuning
DTV and ATVTuning Mode
DTV
Quick ScanScan Type
AutoStart Frequency
AutoEnd Frequency
AutoModulation
AutoSymbol Rate
AutoNetwork ID
Start Scan
Satellite Settings
SatelliteNo. Dish LNB
ASTRA 19.2˚E
Satellite Settings
1
4
3
2
11
Transponder : 1/83 (10743 MHz)
Dish Type : Fixed
Lower LOF (MHz) : 9600
Upper LOF (MHz) : 10600
Switch Type None
LNB Power On
Done
23
SETTING UP YOUR TV
English
To edit the satellite settings:
aIn the Satellite Settings menu, press B to highlight
Switch Type.
bPress C or c to select None, ToneBurst, DiSEqC
2way or DiSEqC 4way as your satellite switch type.
cPress b to highlight LNB Power and press C or c to
select On or Off.
To add a transponder:
aIn the Satellite Settings menu, press B or b to
highlight the line you want to edit and press OK.
bPress the GREEN button. The Transponder Settings
screen will appear.
cPress B to highlight a new line.
dPress OK.
eEdit each parameter as required and press OK.
To delete a transponder:
aIn the Transponder Settings menu, press B or b to
highlight the line you want to delete.
bPress the RED button.
To edit the Transponder Settings:
aIn the Transponder Settings menu, press B or b to
highlight the line you want to edit and press OK.
bPress C or c to select Frequency, Polarisation,
Symbol Rate or S/S2, and set the item using the
number buttons if necessary.
cPress OK to save your settings.
dRepeat steps 1 through 3 for other lines.
ePress the BLUE button to finish editing and return to
Satellite Settings.
Press the GREEN button to cancel any edits that were
made.
Press the YELLOW button to reset all transponder
settings to their initial default settings.
To select the Dish Type:
aIn the Satellite Settings menu, press B or b to select
the required satellite line and press OK.
bPress C or c to highlight Dish and press the GREEN
button.
cPress C or c to select Dish Type. You can select
Movable or Fixed as the Dish Type.
ASTRA 19.2˚E
111
Transponder Settings
1 10743 H
Frequency Polarisation Symbol Rate S/S2
7 10861
8 10876
2 10773
3 10788
4 10817
5 10832
6 10847
H
V
H
V
V
H
V
22000
22000
22000
22000
22000
22000
22000
22000
S
S
S
S
S
S
S
S
Transponder Settings
76 12640 V
Frequency Polarisation Symbol Rate S/S2
82 12728
83
77 12662
78 12669
79 12692
80 12699
81 12721
V
H
V
H
V
H
22000
22000
22000
22000
22000
22000
22000
S
S
S
S
S
S
S
83 0H0S
83 12731 H 22000 S2
Dish Settings
Dish Type
Fixed
Dish : 1
24
SETTING UP YOUR TV
English
To select the LNB Settings:
aIn the Satellite Settings menu, press B or b to select
the required satellite line and press OK.
bPress C or c to highlight LNB and press the GREEN
button.
cPress B or b to select Lower LOF or Upper LOF and
input the appropriate frequencies.
NOTE: As new services are broadcast, it will be necessary to
re-tune the television in order to view them.
Auto Tuning will completely re-tune the television and can be
used to update the channel list. It is recommended that Auto
Tuning is run periodically to ensure that all new services are
added. All current channels and settings, i.e. locked channels,
will be lost.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight System Setup icon.
cPress OK to display System Setup menu.
dPress B or b to select Auto Tuning and press OK.
eFor DTV/ATV Tuning:
A screen will appear warning that previous
programmes and settings will be deleted.
Press C or c to select DTV and ATV, DTV or ATV, if
available, then highlight Start Scan and press OK to
continue with the Auto Tuning.
NOTE: If you have selected “Others” for the Country
field in the System Setup menu, and selected a
tuning mode other than “DTV” , choose the optimum
ATV broadcasting system (B/G, I, D/K or L).
The television will start to search for all available DTV
and/or ATV services.
You must allow the television to complete the
search.
When the search is complete, the Auto Tuning screen
will display the services found.
For Satellite Tuning:
A screen will appear warning that previous programmes
and settings will be deleted.
Press B or b to highlight Satellite and press C or c to
select the desired satellite (No.1 Sat ~ No.4 Sat or
All).
You can select Free to Air or All as the Search Option.
Highlight Start Scan and press OK to continue with
the Auto Tuning.
When the search is complete, the Auto Tuning screen
will display the services found.
fPress B or b to move through the list to select a
channel and press OK to view.
Auto Tuning
LNB Settings
Lower LOF
9750
LNB : 1
Upper LOF
10600
System Setup
Menu Language English
Country
Ant/Cable/Satellite
Auto Tuning
ATV Manual Tuning
DTV Settings
DTV Manual Tuning
Satellite Settings
Germany
Auto Tuning
DTV and ATVTuning Mode
Start Scan
Previous settings will be lost!
Press EXIT for no change.
Auto Tuning
Previous settings will be lost! Press EXIT for no
change.
AllSatellite
Free to AirSearch Option
Start Scan
25
SETTING UP YOUR TV
English
ATV Manual Tuning
The television can be tuned-in manually using ATV Manual
Tuning. For example, you might use the feature if the television
cannot be connected to a media recorder/decoder with a SCART
lead or when you want to tune-in a station on another System.
Use C and c to move across the screen and select any of the
ATV Manual Tuning options.Then use B or b to adjust the
settings.
1Position
The number to be pressed on the remote control to tune
the channel.
2System
Specific to certain areas.
3Colour System
Factory set to Auto, should only be changed if problems
are experienced, i.e. NTSC input from external source.
4Skip
Set Skip to On (8) or Off (() for the selected channel.
See page 26.
5Signal Class
The channel classification.
6Channel
The channel number on which a station is being
broadcast.
7Search
Search up and down for a signal.
8Manual Fine Tuning
Only used if interference/weak signal is experienced. See
page 99.
9Station
Station identification. Use the B b and C c buttons to
enter up to seven characters.
To allocate a position on the television for a decoder and
media recorder: turn the decoder on, insert a pre-recorded
film in the media recorder, press PLAY and manually tune.
aIn the System Setup menu, press b to select ATV
Manual Tuning and press OK.
bUse B or b to select the desired position. We suggest
Pos. 0 for a media recorder.
cPress OK to select. If the channel chosen for the media
recorder is set to skip, Skip should be removed before
storing.
dPress c to select System and press B or b to change
if required.
eThen press c to select Search.
fPress B or b to begin the search. The search symbol
will flash.
Tuning
ATV Manual Tuning
System
1 A C 2 0 V C R
I
123 4 65 7 8 9
Different Channel numbers may be displayed.
System Setup
Menu Language English
Country
Ant/Cable/Satellite
Auto Tuning
ATV Manual Tuning
DTV Settings
DTV Manual Tuning
Satellite Settings
Germany
Pos. Channel Station
ATV Manual Tuning
1
2
3
4
6
7
8
C2
C7
S10
S40
C22
5
C25
C28
C30
ATV Manual Tuning
System
1 A C 2 0
I
ATV Manual Tuning
Search
1 C 2 0 IA
26
SETTING UP YOUR TV
English
gEach signal will show on the television. If it is not your
media recorder, press B or b again to restart the
search.
hWhen your media recorder signal is found, press c to
move along to Station. Use B, b, C and c to put in
the required characters, e.g. VCR.
iPress OK to save.
jRepeat for each position you want to tune, or press
BACK to return to the list of channels and select the
next number to tune.
kPress EXIT when you have finished.
To prevent certain channels from being viewed, positions can be
skipped.
aSelect ATV Manual Tuning from the System Setup
menu.
bUse B or b to highlight the position to be skipped
and press OK to select.
cPress c to select Skip.
dUse B or b to turn Skip on.
Press OK.
8 on the screen indicates a skipped position.
ePress BACK and repeat from Step 2 or press EXIT.
Each position has to be individually selected. To turn
Skip off, repeat the procedure for each position.
Skipped positions cannot be selected by PU and Pu
or by the controls on the television but can still be
accessed by the number buttons on the remote
control.
Channels may be moved and saved to the position of your
choice.
aSelect ATV Manual Tuning from the System Setup
menu.
bWith the list of channels showing, use B or b to
highlight the channel you want to move and press c.
cUse B or b to move through the list to your preferred
position. As you do so, the other channels will move
to make room.
dPress C to save your move.
Repeat as necessary and press EXIT.
PLEASE NOTE
This television has direct channel entry if the
channel numbers are known.
Select the ATV Manual Tuning screen in Step 3.
Enter the Position number, the System, then C for
standard (terrestrial) channels or S for cable
channels and the Channel number. Press OK to
save.
Skip
ATV Manual Tuning
Station
1 A C 2 0 V C R I
Pos. Channel Station
ATV Manual Tuning
1
2
3
4
6
7
8
C2
C7
S10
S40 ABC1
ABC1C22
5
C25
C28
C30
Sorting positions
ATV Manual Tuning
Skip: On
1 A C 2 0 I
Pos. Channel Station
ATV Manual Tuning
2
3
4
5
6
7
8
S10
C7
C40
C22
1
C2
C25
C28
C30
ABC1
ABC1
27
SETTING UP YOUR TV
English
DTV Manual Tuning
NOTE: The content of this menu varies depending on the DTV
input (Antenna, Cable, or Satellite) that is currently selected.
This feature is available for service engineers or can be used for
direct channel entry if the multiplex channel is known.
aSelect DTV Manual Tuning from the System Setup
menu and press OK.
bEnter the multiplex number using the number
buttons or use C or c to adjust the number up or
down.
cHighlight Start Scan and press OK. The television will
automatically search for that multiplex.
When the multiplex is found, any channels that are
not currently in the channel list will be added and the
channel information at the top of the screen will be
updated.
dRepeat as necessary. Press EXIT to finish.
When Ant/Cable/Satellite is set to Cable, DTV Manual
Tuning items are as follows:
Frequency – input a specific frequency to be scanned
Modulation – choose from one of five QAM modulation
options
Symbol Rate – input a specific baud rate (KS/s) to be used for
the manual scan
Highlight Start Scan and press OK.
When Ant/Cable/Satellite is set to Satellite, DTV Manual
Tuning items are as follows:
Press B or b to highlight an item (Satellite, Transponder,
Frequency, Symbol Rate, Polarisation or Search Option)
and press C or c to select the required option.
Highlight Start Scan and press OK.
Manual Tuning
DTV Manual Tuning
WEAK
Signal Strength
Quality
Channel
GOOD
Start Scan
STRONGAVERAGE
13
Pos.New TypeName
ABC ONE
0 New Channels - Total 6
ABC TWO
ABC THREE
ABC NEWS 24
DTV Manual Tuning
2
1
7
40
ABCi
51
Manual Tuning for DVB-C
Manual Tuning for DVB-S
DTV Manual Tuning - Satellite
WEAK
Signal Strength
Quality
Satellite
POOR
Start Scan
STRONGAVERAGE
ASTRA 28.2°E
Transponder 1/83
Frequency 10714 MHz
Symbol Rate 22000 KS/s
Polarisation H
Search Option Free to Air
28
SETTING UP YOUR TV
English
DTV Settings
The channel order may be changed to suit your personal
preference.
aSelect DTV Settings from the System Setup menu
and press OK.
bSelect Channels and press OK.
cFor your convenience, you can jump to specific places
in the list by one of two methods.
Line Number Jump —Use the number buttons
(0-9) to input the line number you want to select and
press OK.
Name Jump —Press CC or cc to jump to the
next station name with a different initial letter.
It is also possible to change the Position number of a
particular channel.
Renumber — Press the RED button to renumber
the highlighted channel. Edit the channel number
using the number buttons and press OK. If the
position number you input already exists, a
confirmation window will appear.
Move — Press the GREEN button to activate the
Move feature. Press the B or b buttons to select the
channel you wish to move and press OK to check.
If you wish to move multiple channels at once, select
another channel and check in the same way. Repeat
as necessary.
Once all desired channels have been checked, press
the B or b buttons to place the focus at the position
to which you wish to move the channels. The
channels will be inserted above the highlighted
channel. Press the GREEN button to execute the
move.
Sort — Press the YELLOW button. A confirmation
window will appear. Press C or c to select Yes and
press OK.
The Sorting Type selection window will appear.
Press C or c to set the sorting type.
A-Z Sort Station name order (A to Z)
Number Position No. order (numerical sequence)
Press b to highlight Sort and press OK.
Channels (Antenna/Cable)
DTV Settings
Channels
Parental PIN Setup
Subtitle and Audio
Parental Control
Local Time Setting
DVB Character Set
Dynamic Scan
Standby Channel Update
Standard
Off
On
Channels
Line No. 1/10
TV
Sort: A-Z Sort
1 ABC ONE
2 ABC TWO
Pos. Name
7 ABC THREE
30 CABC Channel
40 ABC NEWS 24
51 ABCi
822 AA
823 AC
ABC ONE
Pos.
----
Name
Channels
Line No. 1/10
TV
1 ABC ONE
Pos. Name
822 AA
823 AC
2 ABC TWO
7 ABC THREE
30 CABC Channel
40 ABC NEWS 24
51 ABCi
Sort: A-Z Sort
Sort
Your existing channel order will be lost. Do you wish to
continue?
Yes
Sorting Type Number
Sort
Sort
29
SETTING UP YOUR TV
English
aSelect DTV Settings from the System Setup menu
and press OK.
bSelect Channels and press OK.
The satellite channel list will appear.
cFor your convenience, you can edit and sort your
channel list.
Line Number Jump — Press the number buttons
(0-9) to input the line number you want to select and
then press OK.
Station Letter Jump — Press CC or cc to jump
to the next station name with a different initial letter.
Satellite Jump —Press Z or z to jump to the
next channel on a different Satellite.
Renumber — Same as Antenna/Cable channels.
See page 28.
Move — Same as Antenna/Cable channels. See
page 28.
Sort — Press the YELLOW button. A confirmation
window will appear. Press C or c to select Yes and
press OK.
The Sort menu will appear.
Group —Press C or c to select All or By Satellite.
Sorting Type — Press C or c to set the sorting type.
A-Z Sort Station name order (A to Z)
Number Position No. order (numerical sequence)
Preset Order — Press C or c to set Yes or No.
This item is displayed when Country is set to
Germany, and only applies to the Astra 19.2°E
satellite.
Press b to highlight Sort and press OK.
If the Standby Channel Update is set to On, when the TV is in
standby mode, Digital Tuning is automatically executed and any
new channels are saved.
aSelect DTV Settings from the System Setup menu
and press OK.
bPress b to select Standby Channel Update and
press C or c to select On.
This feature allows you to manually select the character set
(Standard = Table 0, West = Table 5 or Latin alphabet 9) to
be used for DVB-C or DVB-T channels.
aSelect DTV Settings from the System Setup menu
and press OK.
bPress b to select DVB Character Set and press C or
c to select Standard, West or Latin alphabet 9.
If the broadcast information has changed in your DVB-T
receiving area, the TV screen will display the message
“Broadcast information has changed. Would you like to
rescan now?”. Select Yes or No. If you do not wish for the TV to
detect changes and prompt you to rescan, you should set this
feature to “Off”.
aSelect DTV Settings from the System Setup menu
and press OK.
bPress b to select Dynamic Scan and press C or c to
select On.
Channels (Satellite)
Channels
Line No. 3/1200
Satellite TV
1 DDD 19.2°E
Pos. Station Satellite
822 AA
823 AC
2AB
3E
801 BBC
802 BB
803 BA
25.6°E
25.6°E
19.2°E
19.2°E
22.5°E
22.5°E
22.5°E
Group By Satellite
Sorting Type Number
Preset Order Yes
Sort
Sort
Standby Channel Update
DVB Character Set
Dynamic Scan
30
SETTING UP YOUR TV
English
You can select either Home or Store mode. Home is
recommended for normal home use. Select Store when using
the television for displaying in a shop, etc.
aSelect Location from the System Setup menu.
bPress C or c to select Home or Store.
This is a digital television which is integrated to allow the use
of both digital and analogue services. However, during the
lifetime of this set it is very likely that analogue services will
be switched off to allow for more new digital services.
This ‘switch-off’ will happen in a number of phases, which will
be advertised in your area well in advance. It is recommended
that at each phase the television is re-tuned to ensure that
existing and new digital services can be viewed without
disruption.
Location setting
Analogue switch-off
31
English
CONTROLS AND FEATURES
General controls
Quick Menu helps you access some options quickly, such as
Picture Mode, Picture Size, Personal Mode, More
Information, Sleep Timer etc.
Press QUICK to display the Quick Menu and use B or b to
select the option.
NOTE: Quick Menu items are different depending on the
current mode.
Quick menu item example
To select a channel, use the numbered buttons on the remote
control.
Channels can also be selected using PU and Pu.
To display on-screen information such as channel, input
mode or stereo/mono signal, press . Press again to
cancel.
The time display facility allows the current (text service) time to
be seen on the television screen.
Press D whilst watching a normal television broadcast
to see the time display from the broadcaster. It will remain on
screen for about 5 seconds.
NOTE: This display may not be available in some cases.
For DTV programmes
For stereo or dual mono broadcasts, press s and use C or
c to select settings.
For multi-audio track broadcasts, press s repeatedly to
change the audio language (see “Audio languages” on
page 85).
For ATV programmes
If stereo or dual language broadcasts are transmitted, the
word Stereo or Dual will appear on the screen each time
positions are changed, disappearing after a few seconds. If
the broadcast is not in stereo, the word Mono will appear.
Stereo… Press s to select Stereo or Mono.
Bilingual… Bilingual transmissions are rare. If they are
transmitted, the word Dual will be displayed. Choose the
required programme number, and if the word Dual appears,
press s to select Dual 1, Dual 2 or Mono.
Quick Menu
Mode Quick menu item Description
When viewing a TV
programme or
pictures from the
external input
Single Window or
3D Single Window
Picture Mode See page 41.
Picture Size See page 39.
3D Settings See page 34.
Personal Mode See page 91.
More Information See page 81.
Channel Options See page 84.
Sleep Timer See page 80.
REGZA-LINK Device
Control
See page 95.
Speakers See page 94.
Headphone Level See page 38.
Wireless Information See page 51.
Recording
Information
See page 63.
When using EPG Genre Colour See page 82.
EPG Update/
Cancel EPG Update
See page 82.
Media Player
(Photo Multi View,
List View)
Sort See page 71.
Playback Mode See page 72.
Interval Time See page 71.
Repeat See page 71.
Shuffle See page 75.
Device Information See page 72.
Wireless Information See page 51.
50
Quick Menu
Picture Size
Picture Mode AutoView
Super Live
More Information
3D Settings
Personal Mode
Sleep Timer
Channel Options
TV Speakers
Headphone Level
REGZA-LINK Device Control
Wireless Information
Recording Information
Speakers
00:00
Photo Frame
(Full Screen)
Picture See page 41.
Picture Size See page 39.
3D Settings See page 34.
Personal Mode See page 91.
Selecting channels
The Time Display – analogue only
Stereo and Bilingual transmissions
Mode Display Pressing c
Stereo Stereo S Left S Right
Dual mono Dual 1 S Dual 2 S Dual
Mono –
Multichannel –
Mode Quick menu item Description
32
CONTROLS AND FEATURES
English
Using 3D functions
Before using 3D programming, see and follow
“When using the 3D glasses” section on page 8.
Viewing 3D programming requires the following:
• TOSHIBA 3D Glasses FPT-AG02G
YL86 and YL87 series : Supplied
WL86 series : Not supplied
• Compatible 3D playback device or 3D source
• 3D capable high quality HDMI cable
Names and functions
To set the 3D glasses:
aWhen you use for the first
time, peel off the
protective films from the
lenses.
bTurn the 3D glasses on
with the power switch.
NOTE: If the infrared data communication between the
television and 3D glasses is lost for 5 minutes, the 3D glasses
turn off automatically to preserve battery life.
To charge the battery:
If the 3D glasses are turned on while the battery power is low,
the power light will blink 5 times. (If the battery is dead, the
power light will not blink or light.)
aTurn the 3D glasses off with the power switch, and
connect to the TV with the battery charge cable.
NOTE:
• If the 3D glasses are turned on, the battery will not
charge.
• When the TV is turned off or in standby mode, the
battery will be not charge.
• When charging the battery, the use of a USB cable
other than the battery charge cable supplied is not
covered by warranty.
bThe power light will Light up.
cWhen the light goes out, the charging is completed.
NOTE:
• It takes approximately two hours to charge the
battery.
• If the usage time is extremely short even after the
battery has been charged fully, the battery may be
worn out. Contact your dealer.
To check the battery level:
When the 3D glasses are turned on, the behaviour of power
light is different.
• Charged: Lights up for 2 seconds
•Low charge:Blinks 5 times
CAUTION: Danger of explosion if battery is incorrectly
disposed of.
Using the 3D glasses
Power switch and
power light
Turns on or off the
power of 3D glasses
with the switch.
– When working, the
power light blinks
once every 2
seconds.
– When the power is
turned off, the power
light goes out.
Power switch
Power light
ON OFF
Protective films
Peel these off before beginning use.
Lens (liquid-crystal
shutter)
A right and left liquid-
crystal shutter opens and
closes alternately with
the images for the left
eye and for the right eye
alternately projected on
the television screen.
In this way, 3D images are
reproduced.
USB terminal
When charging the battery,
connect to the TV with the
battery charge cable.
DC IN
Infrared reception
part
Receives the infrared
signal for the liquid-
crystal shutter
control sent from the
television.
Peel off
USB
33
CONTROLS AND FEATURES
English
Incoming video signals can either be in 2D or 3D format. A 2D
signal can be viewed in either 2D or 3D, and 3D can be viewed in
either 2D or 3D. If the TV can detect the fact that a signal is 3D, it
can change to 3D mode automatically – see “Setting the auto
start mode” (on page 35). Otherwise you can change the viewing
mode using the 3D button. Finally, the format of the 3D signal
can be either Side by Side (SBS) or Top and Bottom (TB). You may
have to choose the correct format if the TV can not detect it
automatically – see “Switching display mode or selecting 3D
format”, below.
Moreover, you can change 2D images to 3D images by pressing
the 3D button when viewing in 2D.
NOTE:
• When 3D format signal is not received, display mode is not
switched to 3D.
• If appropriate mode and format are not selected, 3D image
is not correctly displayed.
• There will be restrictions on the Picture Size settings for 3D
Mode and 2D Mode.
• There are individual differences in perception of 3D images.
• When viewing 3D images, wear the 3D Glasses.
• The 2D to 3D conversion function is activated and
controlled by you according to your personal preferences.
• The 2D to 3D conversion function is meant for enjoyment of
2D home video, and other 2D content you create, in 3D
according to your personal preferences.
• The 2D to 3D conversion function is not intended for use
with pre-recorded 2D copyrighted content owned by a
third-party unless the copyright owner has given direct or
indirect permission, or unless applicable law permits such
use.
There are four modes for watching TV.
3D format select:
If a right and left images are same in Native mode, select SBS.
If a top and bottom images are same in Native mode, select
TB. 3D formats are the following.
* This format cannot be selected manually.
The 3D button's operation:
The behaviour of 3D when viewing in Native mode is different
depending on the input mode.
Depending on the input mode, the screen for selecting 2D or
3D is displayed or the display mode switches between 2D and
3D.
To switch to 3D mode:
•Set Preferences / 3D Setup / 3D Auto Start to 3D.
•Press 3D while viewing 2D mode or Native mode.
* Correct 3D image
Viewing 3D images
Switching display mode or selecting 3D
format
Mode Description
3D Displays 3D images.
2D Changes 3D images to 2D.
2D to 3D Changes 2D images to 3D.
Native Displays a received signal format as it is.
3D format Description
Side by
Side (SBS)
Images for the left and right eyes
are positioned side-by-side.
Top and
Bottom
(TB)
Images for the left and right eyes
are positioned at the top and
bottom of the screen.
Frame
Packing
(FP) *
Image for the left and right eyes for
two frames are positioned at the
top and bottom of the screen.
Trigger of Switching
Display Mode Press 3D button
Input Signal
Type Additional
Information
Format Source
Signal
Select
3D
Select
2D to 3D
3D
Format
Signal
With 3D
Auto Detect
Information
FP *
SBS *
TB *
Without 3D
Auto Detect
Information
SBS *
TB
2D Format Signal *
3D
3D
3D 3D
3D
3D
3D 3D 3D 3D
3D
3D
D
D
3
3
3D
3D
3D
D3
34
CONTROLS AND FEATURES
English
To select 3D format from the Quick menu in 3D
mode:
aPress QUICK to display the Quick Menu.
bPress B or b to select 3D Settings and press OK.
cPress B or b to select 3D Format Select and press
OK.
dPress C or c to select Side by Side or Top and
Bottom.
* Correct 3D image
To switch to 2D mode:
•Set Preferences / 3D Setup / 3D Auto Start to 2D.
• Press 3D while viewing 3D mode or Native mode.
* Correct 2D image
To select 2D format from the Quick menu in 2D
mode:
aPress QUICK to display the Quick Menu.
bPress B or b to select 3D Settings and press OK.
cPress B or b to select 2D Format Select and press
OK.
dPress C or c to select 2D (SBS) or 2D (TB).
* Correct 2D image
NOTE: Take off the 3D Glasses in 2D mode.
To switch to Native mode:
•Press 3D while viewing 3D mode.
•Press 3D while viewing 2D to 3D mode.
NOTE: When 3D format signal with 3D Auto Detect
Information is received, it is not possible to switch to Native.
•From the Quick Menu in 2D mode.
aIn the Quick Menu, press B or b to select 3D
Settings and press OK.
bPress B or b to select 2D Format Select and press
OK.
cPress C or c to select Native.
NOTE: When Frame Packing is input, 2D Format
Select will be grayed out.
To switch to 2D to 3D mode:
Press 3D and select 2D to 3D while viewing 2D or Native
mode.
NOTE: Depending on the input mode, the display mode
switches between 2D and 3D.
Trigger of Switching
Display Mode Quick menu
Input Signal 3D Fomat Select
Type Additional
Info
Format Source
Signal
SBS TB
3D
Format
Signal
With 3D
Auto Detect
Information
FP
SBS
TB
Without 3D
Auto Detect
Information
SBS *
TB *
2D Format Signal
3D
3D
3D 3D
3D
3D
3D 3D
3D
3D 3D
3D
3D
3D
D
D
3
3
3D
D3
3D
3D
Trigger of Switching
Display Mode Press 3D
button
Input Signal
Type Additional
Info
Format Source
Signal
3D
Format
Signal
With 3D Auto
Detect
Information
FP *
SBS *
TB *
Without 3D
Auto Detect
Information
SBS
TB
2D Format Signal *
3D
3D
3D
3D 3D
3D
3D
3D
3D
3D 3D
3D 3D
3D
3D
3D
3D
3D
3D
Trigger of Switching
Display Mode Quick menu
Input Signal 2D Fomat Select
Type
Additional
Info
Format
Source
Signal
SBS TB Native
3D
Format
Signal
With 3D
Auto Detect
Information
FP
SBS
*
TB
*
Without 3D
Auto Detect
Information
SBS
*
TB
*
2D Format Signal
3D
3D
3D 3D
3D
3D 3D
3D
3D
3D
3D
3D
3D 3D
3D
3D 3D
3D
3D
3
3
3D
3D
3D
3D
3
3D
3D
35
CONTROLS AND FEATURES
English
Controls what the TV does when it detects a 3D signal.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Preferences icon and
press OK.
cPress B or b to select 3D Setup and press OK.
dPress B or b to select 3D Auto Start.
ePress C or c to select 3D, 2D, or Off.
A 3D PIN code is necessary for using 3D Safety Settings.
To enter a new PIN code:
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D PIN Setup and press OK.
cPress the number buttons to enter a 4-digit number.
Confirm the code.
NOTE: PIN code cannot be set to “0000”.
To change or delete your PIN code:
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D PIN Setup.
cPress the number buttons to enter your 4-digit PIN
code.
dSelect Change PIN or Delete PIN and press OK.
NOTE:
• PIN code cannot be set to “0000”.
• If PIN is deleted, 3D Safety Settings is grayed out,
and the settings are reset to the factory default.
When this feature is set to On, a message is displayed onscreen
when a 3D signal is received.
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D Safety Settings and press
OK.
cEnter your 4-digit 3D PIN code.
dPress B or b to select 3D Start Message.
ePress C or c to select On or Off.
Setting the auto start mode
Option Description
3D Displays as 3D mode automatically when 3D
format signal is received.
2D Displays as 2D mode automatically when 3D
format signal is received.
Off Displays a screen that allows you to select 3D
or 2D when 3D format signal is received.
Setting the 3D PIN code
Preferences
Personal TV Setup
REGZA-LINK Setup
3D Setup
Media Renderer Setup
Network Setup
Recording Setup
Network Device Setup
Photo Frame Setup
Setting 3D Start Message
36
CONTROLS AND FEATURES
English
When this feature is set to On, you must enter 3D PIN code for
changing display mode.
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D Safety Settings and press
OK.
cEnter your 4-digit 3D PIN code.
dPress B or b to select 3D Lock.
ePress C or c to select On.
When the 3D Timer Lock feature is set to On, neither the PIN input
window nor the 3D start message will be shown while the 3D
Enable timer is active, even if a switch to 3D Mode occurs. This
helps to avoid asking for the 3D Lock PIN and displaying 3D start
message every time when switching to 3D.
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D Safety Settings and press
OK.
cEnter your 4-digit 3D PIN code.
dPress B or b to select 3D Timer Lock.
ePress C or c to select On.
This feature helps to remind you not to watch 3D video for
extended periods of time. Once a set period of time has passed, a
dialogue will be shown asking you if you wish to continue
viewing or not.
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D Safety Settings and press
OK.
cEnter your 4-digit 3D PIN code.
dPress B or b to select Enable 3D Timer.
ePress C or c to select 30, 60, 90, or 120 minutes.
fTo cancel the timer, select Off.
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 3D Important Info and press
OK.
You can adjust the level of 3D.
From the Menu:
aIn the Preferences menu, press B or b to select 3D
Setup and press OK.
bPress B or b to select 2D to 3D Depth and press OK.
cPress C or c to select 1, 2, 3, 4, or 5.
From the Quick Menu:
aPress QUICK on the remote to open the Quick Menu.
bPress B or b to select 2D to 3D Depth and press OK.
cPress C or c to select 1, 2, 3, 4, or 5.
The left and right eye shutter timing of the glasses can be
swapped. If 3D images look blurred, switch the left and right sides
of the 3D image.
aPress QUICK on the remote to open the Quick Menu.
bPress B or b to select 3D Settings and press OK.
cPress B or b to select Left and Right Image.
dPress C or c to select Swapped.
Setting 3D Lock
Setting 3D Timer Lock
Setting Enable 3D Timer
Displaying 3D Important Info
Adjusting 2D to 3D Depth
Switching left and right images
37
CONTROLS AND FEATURES
English
Sound controls
Volume
Press y or Y to adjust the volume.
Sound Mute
Press once to turn the sound off and again to cancel.
If a programme or film is being broadcast with a soundtrack in
more than one language, the Dual feature allows selection
between them.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Sound icon and press OK.
cPress B or b to select Dual and press C or c to
choose between Dual 1 or Dual 2.
aIn the Sound menu, press B or b to select Balance
and press C or c to emphasize left or right speaker
balance.
You can customize current sound mode settings. Select the
appropriate mode in accordance with the installation location of
the TV (Stand or Wall) and adjust the equalizer on-screen as
desired.
aIn the Sound menu, press B or b to select Advanced
Sound Settings and press OK.
bPress B or b to select Sound Navi and press OK.
cPress C or c to select either Stand or Wall depending
on how your TV is installed and press the RED button.
dPress C or c to select the frequency range you want
to adjust from the equalizer window and press B or
b to adjust the level.
eRepeat step 4 for other frequencies.
Surround, Voice Enhancement, and Dynamic Bass Boost
help to create an enhanced surround sound experience with
deep, rich bass from stereo sound sources. Your TV’s audio will
sound fuller, richer, and wider.
aIn the Sound menu, press B or b to select Advanced
Sound Settings and press OK.
bPress B or b to select Surround and press C or c to
select Off, Spatial or Cinema.
cPress b to highlight Voice Enhancement and press
C or c to select On.
dPress b to highlight Dynamic Bass Boost and press
C or c to select the desired bass expansion level (Off,
Low or High).
This feature provides a consistent sound volume regardless of
programmes, channels or input sources.
aIn the Sound menu, press B or b to select Dolby
Volume.
bPress C or c to select Low, High or Off.
Volume controls and sound mute
Dual
Balance
Sound Navi
Sound
Dual
Balance
Advanced Sound Settings
Audio Level Offset
Headphone Settings
Audio Description
0
Dual 1
Dolby Volume Low
Dynamic Range Control Off
Surround Off
Voice Enhancement
Sound Navi
On
Dynamic Bass Boost Low
Advanced Sound Settings
Surround Settings
Dolby Volume®
TV Mounting Stand
Sound Navi
+20
0
-20
100 330 1K 3.3K 10K [Hz]
21012[Level]
Equalizer
Surround Off
Voice Enhancement
Sound Navi
On
Dynamic Bass Boost Low
Advanced Sound Settings
38
CONTROLS AND FEATURES
English
NOTE:
•The Dolby Volume setting influences the Dynamic Range
Control and Digital Audio Output settings.
• This feature will automatically switch Off when Dynamic
Range Control is set to On or Digital Audio Output is set
to Auto.
This feature allows control of audio compression for some digital
TV programmes (MPEG-1 and MPEG-2 audio programmes are
not supported).
aIn the Sound menu, press B or b to select Dynamic
Range Control.
bPress C or c to select On or Off.
NOTE: This feature will automatically switch Off when Dolby
Volume is set to Low or High.
Sometimes there can be large changes in volume when
switching from a DTV 5.1ch to a DTV 2ch, an ATV channel, or an
external input. Using the Audio Level Offset feature reduces
these volume differences.
aSet the volume level usually used when watching a
DTV 5.1ch programme.
bTune to a channel which is DTV 2ch, ATV or an
external input.
cIn the Sound menu, press B or b to select Audio
Level Offset and press OK.
dPress B or b to select an option, and then press C or
c to adjust the volume level.
NOTE:
• The available item changes depending on the current input
source. For example, while watching a DTV 2ch programme,
only DTV 2ch is available and the other two items are
grayed out in the menu. This allows you to easily adjust
according to each condition.
• When watching a DTV 5.1ch programme, this feature is not
available.
This setting is used to set the sound output when headphones are
connected.
aIn the Sound menu, press B or b to select
Headphone Settings and press OK.
bPress B or b to select Speaker Link and press C or c
to select On or Off.
cIf you select Off, then highlight Headphone Level
and use C or c to adjust the headphone sound.
Audio Description is an additional narrative sound track for
visually impaired individuals to understand and enjoy the story
line more fully. The letters AD will be displayed in the channel
banner when programmes contain AD content.
aIn the Sound menu, select Audio Description and
press OK.
bPress B or b to select Audio Description and press
C or c to select On.
The AD button on the Remote can also be used to
toggle the Audio Description feature between On
and Off.
cTo adjust the level of the audio description sound to
the main sound, highlight Mixing Level and press C
or c.
Dynamic Range Control
Audio Level Offset
0
0
-5
Audio Level Offset
ATV
DTV 2ch
External Input
Headphone Settings
Speaker
Link Headphone Speakers
On Sound is output
(2 – + is available.)
No sound
Off Sound is output
(Headphone level
menu is available.)
Sound is output
(2 – + is available.)
Audio Description
50
Headphone Settings
Headphone Level
Speaker Link Off
50
Audio Description
Mixing Level
Audio Description On
39
CONTROLS AND FEATURES
English
Widescreen viewing
Depending on the type of broadcast being transmitted, programmes can be viewed in a number of
formats.
SUBTITLE
SUBTITLE
SUPER LIVE
This setting will enlarge a 4:3 image
to fit the screen by stretching the
image horizontally and vertically,
holding better proportions at the
centre of the image. Some distortion
may occur.
When subtitles are included on a
letterbox format broadcast, this
setting will raise the picture to ensure
that all the text is displayed.
CINEMA
When watching ‘all sides panel
format’ films/video tapes, this setting
will eliminate or reduce the black
bars at all sides of the screen by
zooming in and selecting the image
without distortion.
WIDE
Use this setting when watching a
widescreen DVD, widescreen video
tape or a 16:9 broadcast (when
available). Due to the range of
widescreen formats (16:9, 14:9, 20:9
etc.) black bars may be visible on the
top and bottom of the screen.
4:3
Use this setting to view a true 4:3
broadcast.
14:9
Use this setting when watching a
14:9 broadcast.
40
CONTROLS AND FEATURES
English
Press the button on the Remote to display the list of available widescreen formats.
Press the button repeatedly to highlight the required format.
The Quick Menu feature can also be used to select Picture Size.
Using the special functions to change the size of the displayed image (i.e. changing the height/width ratio) for the purposes of public
display or commercial gain may infringe on copyright laws.
Dot by Dot
PC NORMAL
This setting will show the picture
without overscan, i.e. WYSIWYG.
This option is only available when
watching a PC signal source via
HDMI or PC terminal.
PC WIDE
This setting will show the picture
without overscan or side panels.
This option is only available when
watching a PC signal source via
HDMI or PC terminal.
“Dot by Dot” is a non-scaling display.
Depending on the input signal format,
the picture is displayed with side panels
and/or bars at the top and bottom (e.g.
VGA input source).
NATIVE
This setting will show the picture
without overscan, i.e. WYSIWYG.
Picture Size
4:3
Super Live
Wide
Native
Cinema
14:9
Subtitle
Picture Size
PC Wide
Dot by Dot
PC Normal
AV format PC format
41
CONTROLS AND FEATURES
English
Picture controls
Most of the picture controls and functions are
available in both digital and analogue modes.
PLEASE NOTE: Features not available will be grayed
out.
This television offers the choice of personalising the picture style.
AutoView, Dynamic, Standard, Hollywood Night,
Hollywood Day, Hollywood Pro, Store, Game and PC are
preset options and affect many features/settings within the
television.
NOTE:
• Because the AutoView mode automatically adjusts picture
settings based on ambient light conditions and input signal
content, the Auto Brightness Sensor and Expert Mode
menus are grayed out when it is selected.
•Store mode is only available when Location is set to Store.
•Game mode is available in external input mode (other than
aerial input). When you select Game mode, suitable
widescreen formats will be selected.
•PC mode is available in RGB/PC input mode or HDMI input
mode.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Picture icon and press OK
to display Picture menu.
cPress B or b to select Picture Mode.
dPress C or c to select the picture mode you prefer
and press OK.
NOTE: The picture mode you select affects the current input
only. You can select a different picture mode for each input.
You can customize current picture mode settings as desired. For
example, while selecting “Dynamic”, if you change the following
items, such as Backlight, Contrast, Brightness, Colour, Tint,
Sharpness and the Advanced Picture Settings items, your
new settings are saved for “Dynamic” picture mode.
aIn the Picture menu press B or b to select either
Backlight, Contrast, Brightness, Colour, Tint or
Sharpness and press OK.
bPress C or c to adjust the settings.
This feature resets all picture settings to the factory settings
except Picture Mode.
aIn the Picture menu, press B or b to select Reset and
press OK.
bA confirmation message will appear. Press C or c to
select Yes and press OK.
When ColourMaster is set to On, it allows the ‘Base Colour
Adjustment’ feature to become available.
aIn the Picture menu, press B or b to select
Advanced Picture Settings and press OK.
bPress B or b to select ColourMaster.
cPress C or c to select On or Off and press OK.
Picture Mode
Picture Mode
Reset
Backlight
Colour
Tint
Sharpness
100
100
0
0
0
0
Dynamic
Contrast
Brightness
Picture preferences
Reset
ColourMaster
Advanced Picture Settings
ColourMaster
Base Colour Adjustment
Colour Temperature 10
Off
Middle
Auto Brightness Sensor Settings
LED Backlight Control
Black/White Level
Static Gamma
Noise Reduction
10
0
42
CONTROLS AND FEATURES
English
The Base Colour Adjustment feature allows the adjustment of
individual colours to suit personal preference. This can be useful
when using an external source.
aIn the Advanced Picture Settings menu, press B or
b to select Base Colour Adjustment and press OK.
bPress B or b to select an option and press c to move
to the adjustment window.
cPress C or c to select Hue, Saturation or Brightness
and press B or b to adjust the settings as required.
dPress BACK to return to the previous menu.
To return to the factory settings, select Reset and
press OK.
Colour Temperature increases the ‘warmth’ or ‘coolness’ of the
picture by increasing the red or blue tint.
aIn the Advanced Picture Settings menu, press B or
b to select Colour Temperature and press OK.
bPress C or c to adjust the level.
The adjustment range is 0 (warm) to 10 (cool).
NOTE: If Picture Mode is set to AutoView, the adjustment
range is -5 to +5.
When the Auto Brightness Sensor is activated, it will
automatically optimise the backlighting levels to suit ambient
light conditions.
aIn the Advanced Picture Settings menu, press B or
b to select Auto Brightness Sensor Settings and
press OK.
bPress C or c to select On and press OK.
cPress B or b to select Backlight Adjustment Pro
and press OK.
dThe Backlight Adjustment Pro window will appear.
Press OK again to display the adjustment window.
ePress C or c to select a point and press B or b to
adjust the level.
fPress OK to fix the adjustment.
To cancel the adjustment when selecting a point,
select Cancel and press OK.
To return the adjustments of all points to the factory
defaults, select Reset and press OK.
You can adjust the backlighting of the black areas of the image
and enhance the contrast.
aIn the Advanced Picture Settings menu, press B or
b to select LED Backlight Control.
bPress C or c to select Low, Middle, High, Auto or Off.
NOTE: When Picture Mode is set to any mode other than
AutoView, Auto is grayed out.
Base Colour Adjustment
Colour Temperature
Hue Saturation
Reset
Brightness
0Red
Green
Blue
Yellow
Magenta
Cyan
00
000
000
000
000
000
Base Colour Adjustment
Hue Saturation Brightness
0Red 0 -1
Auto Brightness Sensor Settings
LED Backlight Control
Auto Brightness Sensor Settings
Backlight Adjustment Pro
Auto Brightness Sensor On
100
0
Backlight Adjustment Pro
Backlight Control Level
Control
Level
Ambient Light
48
Cancel
Reset
43
CONTROLS AND FEATURES
English
Black/White Level increases the strength of dark areas of the
picture to improve the definition.
aIn the Advanced Picture Settings menu, press B or
b to select Black/White Level.
bPress C or c to adjust the level. The effect depends on
the broadcast and is most noticeable on dark colours.
The static gamma feature allows you to adjust the levels of black
in the picture.
aIn the Advanced Picture Settings menu, press B or
b to select Static Gamma.
bPress C or c to adjust the level.
When watching a DVD, the compression may cause some words
or picture elements to become distorted or pixelated.
Using the MPEG NR feature reduces this effect by smoothing out
the edges.
aIn the Advanced Picture Settings menu, press B or
b to select Noise Reduction and press OK.
bPress b to select MPEG NR.
cPress C or c to select Low, Middle, High or Off to suit
your preference.
DNR allows you to ‘soften’ the screen representation of a weak
signal to reduce the noise effect.
aSelect DNR from the Noise Reduction menu.
bPress C or c to select Low, Middle, High, Auto or Off.
The differences may not always be noticeable (for the
best result use lower settings as picture quality can be
lost if the setting is too high).
The Resolution+ feature allows you to adjust the clarity levels
for your desired picture settings.
aIn the Advanced Picture Settings menu, press B or
b to select Resolution+ and press OK.
bIn the Resolution+ field, select Auto.
cPress B or b to highlight Level and press C or c to
adjust the level.
NOTE:
• This feature may not work properly depending on the
content.
• Adjustable range varies according to the Picture Mode you
set.
• Noise may appear in the picture depending on the device
connected to the TV (e.g. a device with a specific enhancer
function).
This feature will reduce picture blur without decreasing image
brightness or adding flicker.
aIn the Advanced Picture Settings menu, press B or
b to select Active Vision M800.
bPress C or c to select Smooth, Standard or Off.
NOTE: When Picture Mode is set to Game, this feature will be
grayed out and automatically set to Off.
This feature is to set the range of the adjustment of movement in
the double-scan processing. If you feel uncomfortable in motion
picture, select Standard.
aIn the Advanced Picture Settings menu, press B or
b to select Motion Detection Range.
bPress C or c to select Wide or Standard.
Wide—Double-scan effect for higher-speed motion
Standard—Stabilized double-scan effect
NOTE: When Active Vision M800 is set to Off, this feature will
be grayed out.
Black/White Level
Static Gamma
MPEG NR – Noise Reduction
DNR – Digital Noise Reduction
Noise Reduction
DNR
MPEG NR Low
Auto
Resolution+
Active Vision M800
Motion Detection Range
Resolution+
Level
Resolution+ Auto
3
44
CONTROLS AND FEATURES
English
This feature will reduce 3D images blur without adding flicker.
aIn the Advanced Picture Settings menu, press B or
b to elect 3D Judder Cancellation.
b Press C or c to select Auto or Off.
NOTE: When Picture Mode is set to Game, this feature will be
grayed out and automatically set to Off.
This feature allows you to reset the current Advanced Picture
Settings to the default values.
aIn the Advanced Picture Settings menu, press B or
b to select Reset.
bPress OK.
This feature is available when the Picture Mode option is
Standard, Hollywood Day, Hollywood Night, and
Hollywood Pro.
Test Pattern
When the test pattern is on screen, you can navigate in the
Picture submenus and adjust picture settings without
removing the image.
When you move to a non-Picture menu, or close the menus,
regular video will be restored.
aIn the Picture menu, press B or b to select Expert
Picture Settings and press OK to display Expert
Picture Settings menu.
bPress B or b to select Test Pattern.
cPress C or c to select On.
dPress EXIT to close.
RGB Filter
This feature individually enables or disables the red, green,
and blue components of the picture to allow for more
accurate adjustment of each colour.
aIn the Expert Picture Settings menu, press B or b to
select RGB Filter and press OK.
bPress B or b to select Red, Green or Blue to adjust.
cPress C or c to select On.
dPress B or b to select Colour or Tint and press C or
c to adjust.
ePress EXIT.
NOTE: It is not possible to turn off all three colours
simultaneously.
Colour Decoding
If you view DVDs with this TV, the Colour Decoding option
may be set to ensure the colourimetry reproduction.
NOTE: The modes excluding Auto (BT601 and BT709) are to
convert an irregular signal output from the DVD etc. with
incorrect colour to the optimum state. If BT601 or BT709 is
selected with a normal signal received, the colour may not be
correctly displayed. This feature should normally be set to
Auto.
aIn the Expert Picture Settings menu, press B or b to
select Colour Decoding.
bPress C or c to select Auto, BT601 or BT709.
White Balance-Window Display
This feature displays a special Window Pattern to be used
when adjusting white balance with a measuring device.
aIn the Expert Picture Settings menu, press B or b to
select White Balance and press OK.
bPress B or b to select Window Display and press C
or c to select On.
cPress EXIT to close.
White Balance-Setting Type
You can choose from two types of White Balance adjustment.
a In the Expert Picture Settings menu, press B or b
to select White Balance and press OK.
bPress B or b to select Setting Type and press C or c
to select 2P or 10P.
White Balance-2P White Balance
aPress b to select 2P White Balance.
bPress B or b to select Red-Offset, Green-Offset,
Blue-Offset, Red-Gain, Green-Gain, or Blue-Gain.
cPress C or c to adjust.
White Balance-10P White Balance
aPress b to select 10P White Balance.
bPress B or b to select IRE, Red, Green, or Blue.
cPress C or c to adjust.
3D Judder Cancellation
Resetting the advanced picture settings
Expert Picture Settings
45
CONTROLS AND FEATURES
English
NOTE: The adjustments made for Red / Green / Blue are
stored separately for each IRE setting. (There are ten IRE
settings from 10 to 100.)
Colour Calibration
The aim of Colour Calibration is to measure and/or adjust the
colour response (White Balance) of your LCD panel.
Colour Calibration is used by various fields, such as gaming,
photography, engineering, medical and more. In order to
calibrate a display correctly, you need a colour analyzer TPA-1
(not supplied).
NOTE: This feature is available when the Picture Mode option
is Hollywood Pro.
Apply Calibration
aIn the Expert Picture Settings menu, press B or b to
select Colour Calibration and press OK.
bPress B or b to select Apply Calibration and press C
or c to select Enabled.
Manual Colour Calibration
aIn the Colour Calibration menu, press B or b to
select Manual Colour Calibration and press OK.
bPlace the probe of the colour analyzer over the square
on screen to measure.
cInput the value measured with the colour analyzer
using the number buttons (0-9).
dPress BbC c and input the values to fill all RGBxy
matrix table.
eHighlight Start and press OK.
Please wait until you see “Manual Colour Calibration
has been completed.” on screen.
To return to factory setting
aHighlight Reset and press OK.
Auto Colour Calibration
aIn the Colour Calibration menu, press B or b to
select Auto Colour Calibration and press OK.
bConnect the USB colour analyzer to the USB 1 or USB
2 port.
cPlace the probe of the USB colour analyzer over the
square on screen and press OK.
Auto Colour Calibration will start.
Please wait until you see “Auto Colour Calibration has
been completed.”.
Gamma Calibration
aIn the Expert Picture Settings menu, press B or b to
select Gamma Calibration and press OK.
bPress B or b to select Apply Calibration and press C
or c to select Enabled.
cPress B or b to select Auto Gamma Calibration and
press OK.
dConnect the USB colour analyzer to the USB 1 or USB
2 port.
eInput the target value and place the USB colour
analyzer over the square on screen.
fHighlight Start and press OK.
Auto Gamma Calibration will start.
Please wait until you see “Auto Gamma Calibration
has been completed.” on screen.
To return to factory setting
aHighlight Reset and press OK.
Resetting to the factory defaults
aIn the Expert Picture Settings menu, press B or b to
select Reset and press OK.
A confirmation screen appears.
bSelect Yes and press OK.
Manual Colour Calibration
Red 0.642
xy
0.277
0.143
0.335
0.603
0.067
Blue
Green
Start Reset
Please input the value measured with the coulour analyser.
Red 0.642
xy
0.277
0.143
0.335
0.603
0.067
Blue
Green
Auto Gamma Calibration
Target Colour Temperature 0.313
xy
2.4
0.329
Target Gamma
Start Reset
Please input the target value and place the USB colour analyser
over the square.
46
CONTROLS AND FEATURES
English
This feature displays the brightness histogram and control curve
of the current video signal.
aIn the Picture menu, press B or b to select Control
Visualization and press OK. The histogram window
will appear.
bPress BACK to return to the previous menu.
When this television receives a true Widescreen picture and Auto
format is On, it will automatically be displayed in Widescreen
format irrespective of the television’s previous setting.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Preferences icon and
press OK.
cPress B or b to select Display Settings and press OK.
dPress B or b to select Auto Format and press C or c
to select On or Off.
When 4:3 Stretch is activated, the size switching system
changes 4:3 programmes into full screen picture.
aIn the Preferences menu, press B or b to select
Display Settings and press OK.
bPress B or b to select 4:3 Stretch and press C or c to
select On or Off.
When Blue Screen is selected, the screen will turn blue and the
sound will be muted on analogue channels and external input
modes when no signal is received.
NOTE: Some external input sounds may not be muted.
aIn the Preferences menu, press B or b to select Blue
Screen.
bPress C or c to select On or Off.
The picture position may be adjusted to suit personal preference
and can be particularly useful for external inputs.
aIn the Preferences menu, press B or b to select
Display Settings and press OK.
bIn the Display Settings menu, press B or b to select
Picture Position.
cPress OK to view the options available for the picture
format that has been selected.
dPress B or b to select an option and press C or c to
adjust the settings.
The options differ depending on the currently
selected widescreen format and the input signal.
To return to the original factory settings, select Reset
in the Picture Position menu and press OK.
Control Visualization
Automatic Format (Widescreen)
Brightness
Number
Of
Pixels
Output
Control Visualization
Distribution
Input
Control Curve
Auto Format On
4:3 Stretch Off
Picture Position
PC Settings
Display Settings
4:3 Stretch
Blue Screen
Picture Position
Auto Format On
4:3 Stretch Off
Picture Position
PC Settings
Display Settings
0
0
Picture Position
Horizontal Position
Reset
Vertical Position
47
CONTROLS AND FEATURES
English
This feature is used to hold a still image on the screen.
aPress r to hold an image on the screen, and press
r again to cancel.
When the HDMI Information Display feature is On and you are
watching an HDMI input source, pressing the button
displays the HDMI signal information banner.
aIn the Preferences menu, press B or b to select
HDMI Information Display.
bPress C or c to select On.
HDMI signal information is as follows:
Resolution, Scan Type, Frame Rate*, Aspect, Bit Depth,
Colour Space, RGB/YUV, Chroma Format, and Content
Type (if available).
* If the HDMI input source is interlaced, “Field Rate”
will be displayed instead of “Frame Rate”.
Picture still
HDMI Information Display
48
CONTROLS AND FEATURES
English
Wireless LAN Information
Bluetooth™ and Wireless LAN devices operate within the
same radio frequency range and may interfere with one
another. If you use Bluetooth™ and Wireless LAN devices
simultaneously, you may occasionally experience a less than
optimal network performance or even lose your network
connection.
If you should experience any such problem, immediately turn
off either your Bluetooth™ or Wireless LAN device.
Actual performance can vary, including lower wireless
network capacity, data throughput rate, range and coverage.
Performance depends on many factors, conditions and
variables, including distance from the access point, volume of
network traffic, building materials and construction,
operating system used, mix of wireless products used,
interference and other adverse conditions.
Wireless LAN and your Health
Wireless LAN products, like other radio devices, emit radio
frequency electromagnetic energy. The level of energy
emitted by Wireless LAN devices, however, is far less than the
electromagnetic energy emitted by wireless devices such as
mobile phones.
Because Wireless LAN products operate within the guidelines
found in radio frequency safety standards and
recommendations, TOSHIBA believes Wireless LAN is safe for
use by consumers. These standards and recommendations
reflect the consensus of the scientific community and result
from deliberations of panels and committees of scientists
who continually review and interpret the extensive research
literature.
In some situations or environments, the use of Wireless LAN
may be restricted by the proprietor of the building or
responsible representatives of the organization. Such
restrictions may apply in environments where the risk of
interference to other devices or services is perceived or
identified as harmful.
If you are uncertain of the policy that applies to the use of
wireless devices in a specific organization or environment,
you are encouraged to ask for authorization to use the
Wireless LAN device prior to turning on the equipment.
When using the TV under wireless LAN
environment:
• The function of all IEEE802.11 is not supported.
• The ad-hoc mode is not supported.
• It is recommended to use IEEE 802.11a or IEEE 802.11n on
5 GHz for audio and SD video streaming.
• It is recommended to use IEEE 802.11n on 5 GHz for HD
video streaming.
• It is recommended that the encoding rate for streaming
video content is 20 Mbps or less.
• It is not recommended to use 2.4 GHz for audio and video
streaming.
• Content playback may be interrupted by various
surrounding interference.
Europe Statement
This built-in WLAN Module may be operated in below
country:
• If this device is going to be operated in the frequency range
of 5.15 GHz to 5.35 GHz, it is restricted to indoor use.
• If this device is going to be operated for 802.11 b/g/n
function in the frequency range of 2.454 GHz to 2.4835 GHz
in France, it is restricted to indoor use.
• A general authorization is required for using this device
outdoors or in public places in Italy.
• This device is NOT ALLOWED to be used in the geographical
area within a radius of 20km from the centre of Ny-Alesund
in Norway.
Ukraine Statement
Contains approved built-in WLAN Module, model name:
WLU5060-D4 (ROHS), approved by CB “UkrCERTRADIO”.
AT Austria IS Iceland
BE Belgium LI Liechtenstein
CH Switzerland LT Lithuania
CY Cyprus LU Luxembourg
CZ Czech Republic LV Latvia
DE Germany MT Malta
DK Denmark NL Netherlands
ES Spain NO Norway
FI Finland PL Poland
FR France PT Portugal
GB United Kingdom SE Sweden
GR Greece SI Slovenia
EE Estonia SK Slovakia
HU Hungary BG Bulgaria
IT Italy RO Romania
IE Ireland TR Turkey
49
CONTROLS AND FEATURES
English
Setting up the Network
You can select the Network Type.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Preferences icon and
press OK.
cPress B or b to select Network Setup and press OK.
dPress B or b to select Network Type and press C or
c to select Wired or Wireless.
eIf you selected Wired, see “Advanced Network Setup”
on page 51.
NOTE: Continued connection of AP (Access Point) is not
guaranteed. The connection may be disconnected while
watching TV.
There are 3 methods for Wireless Setup:
Easy Setup (WPS)
If the AP supports WPS, this method can be used.
• WPS is an industry standard designed to make connection
of wireless LAN equipment and security setup easy. WPS
will automatically configure all wireless settings.
NOTE: WEP encryption may not be able to configured by easy
setup.
Assisted Setup (setup by using the AP’s notification
information)
Network Name, Authentication, and Encryption are decided
based on information from the AP. You will manually set the
Security Key.
Manual Setup (manual input of all settings)
Easy Setup using PBC (Push Button Configuration)
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Wireless Setup and press OK.
cPress B or b to select Easy Setup and press OK.
dPress C or c to select PBC.
ePress b to highlight Start Scan and press OK.
fFollowing the on-screen instructions, push the
appropriate button on your AP.
gWhen a window reporting that the setup is complete
appears, press OK.
To cancel searching for the AP:
Press BACK while searching for the AP. A message will
appear, and then press C or c to select Yes and press
OK.
Easy Setup using PIN (Personal Identification
Number)
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Wireless Setup and press OK.
cPress B or b to select Easy Setup and press OK.
dPress C or c to select PIN.
ePress b to select Start Scan and press OK.
fPress B or b to select the desired AP and press OK.
NOTE: Check the Network Name and/or MAC address
on the label of the AP or in the manual, and select
your AP.
gWhen the PIN code window appears, enter the
displayed PIN into your AP, and then press Next to
continue the PIN Setup. When a message displays to
report that the setup is complete, press OK.
Wireless Setup
Preferences
Personal TV Setup
REGZA-LINK Setup
MHL Setup
Recording Setup
3D Setup
Network Setup
Camera Sensor Setup
Network Device Setup
Network Type Wired
Network Connection Test
Advanced Network Setup
Network Setup
Wireless Setup
Easy Setup On
Enhanced 11n Off
Manual Setup
Wireless Setup
Assisted Setup
50
CONTROLS AND FEATURES
English
To cancel searching for the AP:
Press BACK while searching for the AP. A message will
appear; then, press C or c to select Yes and press OK.
Assisted Setup
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Wireless Setup and press OK.
cPress B or b to select Assisted Setup and press OK.
dPress B or b to select the desired AP and press OK.
NOTE: Check the MAC address on the label of the AP
or in the manual, and select your AP.
eHighlight Security Key and press OK. The Software
Keyboard window will appear.
fInput the Security Key by using the Software
Keyboard (see page 53). To save your setting, press
the BLUE button.
NOTE:
• The Security Key must adhere to these conditions:
- TKIP/AES: 8-63 ASCII or 64 Hex characters
- WEP: 5 or 13 ASCII or 10 or 26 Hex characters
• There is only one key ID to set for WEP encryption.
gHighlight Done and press OK.
NOTE: If Network Name is not displayed, see step 4
and 5 in Manual Setup below to set Network Name
before pressing Done.
NOTE: Settings are not saved if BACK is pressed before Done
is selected.
Manual Setup
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Wireless Setup and press OK.
cPress B or b to select Manual Setup and press OK.
dPress B or b to select Network Name and press OK.
The Software Keyboard window will appear.
eInput the Network Name by using the Software
Keyboard (see page 53). To save your setting, press
the BLUE button.
fPress B or b to select Authentication and press C or
c to select Open System, Shared Key, WPA-PSK or
WPA2-PSK.
gPress B or b to select Encryption and press C or c
to select None, WEP, TKIP or AES.
NOTE:
• Certain encryption types are only compatible with
specific authentication types.
- When Authentication is Open System, only WEP
or None is compatible.
- When Authentication is Shared Key, only WEP is
compatible.
- When Authentication is WPA-PSK or WPA2-PSK,
only TKIP or AES is compatible.
• When incompatible Authentication/Encryption
pairings are detected, a warning message will be
displayed, and no connection attempt will be made
until the incompatibility is resolved.
• There is only one key ID to set for WEP encryption.
hPress B or b to select Security Key and press OK.
iInput the Security Key by using the Software
Keyboard (see page 53). To save your setting, press
the BLUE button.
NOTE: This item is grayed out when Encryption is
None.
jHighlight Done and press OK.
NOTE: When Encryption is None, a message will
appear. Press C or c to select Yes and press OK.
NOTE: Settings are not saved if BACK is pressed before Done
is selected.
Enhanced 11n
When Enhanced 11n is set to On, the Dual Channel (40MHz)
feature is available.
NOTE: In addition, some other optional 11n features will be
enabled.
aIn the Preferences menu, press B or b to select
Network Setup and press OK. Highlight Wireless
Setup and press OK.
bPress B or b to select Enhanced 11n and press C or
c to select On.
51
CONTROLS AND FEATURES
English
Wireless Information
The settings configured in Wireless Setup can be confirmed.
aPress QUICK to open the Quick Menu.
bPress B or b to select Wireless Information and
press OK.
cWhen the Network Type is Wireless, a Wireless
Information window will appear.
NOTE: Press the RED button to scan for all APs.
NOTE: Even if an AP for IEEE 802.11n is used when Encryption
is set to WEP or TKIP, the Speed value might be low. It is
recommended that Encryption be changed to AES (see
“Manual Setup” on page 50).
Notes on wireless LAN environment:
• The function of all IEEE802.11 is not supported.
• The ad-hoc mode is not supported.
• It is recommended to use IEEE 802.11a or IEEE 802.11n on
5 GHz for audio and SD video streaming.
• It is recommended to use IEEE 802.11n on 5 GHz for HD
video streaming.
• It is recommended that the encoding rate for streaming
video content is 20 Mbps or less.
• It is not recommended to use 2.4 GHz for audio and video
streaming.
• Content playback may be interrupted by various
surrounding interference.
NOTE:
• When the DHCP function of the router connected with this
TV is On, you can set Auto Setup to On or Off.
(This should usually be set to On.)
• When the DHCP function of the router is Off, set Auto Setup
to Off, and set the IP Address manually.
IP Address Setup
Auto Setup:
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Advanced Network Setup
and press OK.
cPress B or b to select IP Address Setup and press
OK.
Item Description
Status Connected is displayed when the TV is
connected with the AP.
Disconnected is displayed when the TV is
not connected with the AP.
Signal Connection signal strength with AP
(STRONG/MEDIUM/WEAK)
Speed Link with AP
Mode Working mode (11a, 11b, 11g, 11n)
Channel Channel in use (1-165)
Network Name SSID set
Authentication Authentication set
Encryption Encryption set
Security Key Security Key set
AP MAC
Address
The AP’s MAC address is displayed when
the TV is connected with the AP.
TV MAC
Address
The MAC address of the TV is displayed.
DHCP Enabled is displayed when using DHCP.
Disabled is displayed when not using
DHCP.
IP Address The TV’s IP address
Subnet Mask Value of the Subnet Mask
Default
Gateway
Address of the Default GATEWAY
DNS Address of the DNS
Quick Menu
50
Picture Size
Picture Mode AutoView
Super Live
More Information
Personal Mode
3D Settings
Sleep Timer
Channel Options
TV Speakers
Headphone Level
REGZA-LINK Device Control
Wireless Information
Speakers
00:00
Advanced Network Setup
Network Type Wired
Advanced Network Setup
Network Setup
Wireless Setup
Network Connection Test
IP Address Setup Wired
MAC Address
DNS Setup
Advanced Network Setup
52
CONTROLS AND FEATURES
English
dHighlight Auto Setup and press C or c to select On.
NOTE: Other items will be grayed out when Auto Setup is set
to On.
Manual Setup:
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Advanced Network Setup and
press OK.
cPress B or b to select IP Address Setup and press
OK.
dHighlight Auto Setup and press C or c to select Off.
ePress B or b to select IP Address.
fPress C or c to highlight the field you want to
change, and then use the number buttons to input
the IP address. To save the setting, press OK.
NOTE: IP address field numbers must be between 0
and 255. After each field number has been set, press
OK to store the entire address. If the entire IP Address
is invalid, a warning message will appear after OK is
pressed.
gPress B or b to select Subnet Mask, and edit in the
same way as IP Address.
hPress B or b to select Default Gateway, and edit in
the same way as IP Address.
NOTE: If you manually set the IP address, you must not use
the same IP address for any other device. The IP address you
use should be a private address.
NOTE: When the DHCP function of the router connected to
this TV is Off, set Auto Setup to Off, and manually set the DNS
address(es). Your internet service provider should have
provided these to you.
Auto setup:
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Advanced Network Setup and
press OK.
cPress B or b to select DNS Setup and press OK.
dPress B or b to highlight Auto Setup and press C or
c to select On.
NOTE: Other items will be grayed out when Auto Setup is set
to On.
Manual setup:
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Advanced Network Setup and
press OK.
cPress B or b to select DNS Setup and press OK.
dPress B or b to select Auto Setup and press C or c
to select Off.
ePress B or b to select Primary DNS Address.
fPress C or c to highlight the field you want to
change, and then use the number buttons to input
the Primary DNS Address. To save the setting, press
OK.
NOTE: DNS address field numbers must be between 0
and 255. If you input an incompatible number and
press OK, the field number will reset to the previous
value.
gPress B or b to select Secondary DNS Address, and
edit in the same way as Primary DNS Address.
Auto Setup On
Subnet Mask
IP Address Setup
IP Address XXX . XXX . XXX . XXX
255 . 255 . 255 . 0
Default Gateway . . .
Auto Setup Off
Subnet Mask
IP Address Setup
IP Address
255 . 255 . 255 . 0
Default Gateway
. . .
XXX . XXX . XXX . XXX
Auto Setup Off
Subnet Mask
IP Address Setup
IP Address
255 . 255 . 255 . 0
Default Gateway
. . .
XXX . XXX . XXX . XXX
DNS Setup
Auto Setup Off
Secondary DNS Address
DNS Setup
Primary DNS Address
255 . 255 . 255 . 0
XXX . XXX . XXX . XXX
53
CONTROLS AND FEATURES
English
MAC Address
You can view the fixed MAC address for the TV.
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Advanced Network Setup and
press OK.
cPress B or b to select MAC Address and press OK.
This function checks the Internet connectivity.
aIn the Preferences menu, press B or b to select
Network Setup and press OK.
bPress B or b to select Network Connection Test and
press OK.
A message will appear to indicate if the connection
was successful or if it could not be completed.
NOTE: The result of Network Connection Test does
not always guarantee the connection. Depending on
the situation, YouTube may not be able to be used.
To cancel the Network Connection Test:
Press BACK while searching for the Internet connection.
Using the software keyboard
You can enter text by using the Software Keyboard.
The Software Keyboard window will appear when
you press OK on a field that accepts character input.
To enter text using the software keyboard:
aHighlight the desired character on the on-screen
software keyboard.
bPress OK.
cRepeat steps 1 and 2 until you have entered all
desired text.
dPress the BLUE button to close the software keyboard
and return to the previous screen.
NOTE: If BACK is pressed, changes are not saved and
the software keyboard window is closed. The text will
remain as it was before starting the keyboard.
Input operation on the remote control:
Network Connection Test
Button Description
OK Inputs the selected character.
0-9 Inputs the number directly.
B b C cMoves the character highlight.
CC cc Moves the cursor.
ZMoves the cursor to the head of a
character string.
zMoves the cursor to the end of a
character string.
RED Deletes 1 character to the left of
the cursor.
GREEN Cycles through upper case, lower
case, numbers, and symbols, if
available.
YELLOW Chooses an accented version of
the current letter, if applicable.
BLUE Saves changes and closes the
Software Keyboard window.
BACK Closes the Software Keyboard
window without saving changes.
ABC DE F G
Aa1@
AAA|
HIJKLMN
OPQRSTU
VWX Y Z
54
CONTROLS AND FEATURES
English
Network Device Setup
This setup allows you to operate a home network-connected
your TV from an external device.
Media Controller Setup
aIn the Preferences menu, press B or b to select
Network Device Setup and press OK.
bPress B or b to select External Control Setup and
press OK.
cPress B or b to select an option and press OK.
The Software Keyboard window will appear.
User Name — Input the User Name (to control the TV
from the iPhone etc.) by using the on-screen software
keyboard (see page 53). The maximum number of
characters is 16.
Password — Input the Password (to control the TV
from the iPhone etc.) by using the on-screen software
keyboard (see page 53). The maximum number of
characters is 16.
NOTE: Toshiba does not guarantee normal operation with all
connected devices.
Terminology:
DMS: DLNA CERTIFIED™ Server
DMR: DLNA CERTIFIED™ Renderer
DMC: DLNA CERTIFIED™ Controller
The TV can be configured as a DMR. When
operating as a DMR, the TV displays content
provided by a DMS. The selection of the media is
done by the DMC - the TV does not select the input.
The TV can play photo, movie, or audio files when
operating as a DMR.
Media Renderer
aIn the Preferences menu, press B or b to select
Network Device Setup and press OK.
bPress B or b to select Media Renderer Setup and
press OK.
cPress B or b to select Media Renderer, and then
press C or c to select On or Off.
Media Controller Setup
You can limit which DMC can control this TV.
If Access Control is enabled, only those DMCs with a check will
be allowed to control the TV.
aIn the Media Renderer Setup menu, press B or b to
select Media Controller Setup and press OK.
bPress B or b to select Access Control and press C or
c to select On.
cPress B or b to select Select Media Controller and
press OK.
dPress B or b to highlight the item you want to select
and press OK. A check will appear in the box.
To remove the check, press OK again.
ePress c to highlight Done and press OK.
NOTE:
• You can select up to 8 DMC devices.
• If you would not like to limit the DMCs for this TV, set Access
Control to Off.
• Devices other than DMCs may be displayed in the list.
Confirm the MAC address of the DMC and set it.
Maximum Volume Setup
This feature allows you to set the maximum volume of the TV
when it receives volume operation commands from a DMC.
aIn the Media Renderer Setup menu, press B or b to
select Maximum Volume Setup, and press C or c to
adjust to the desired volume.
NOTE:
• The TV’s remote control can set volume regardless of the
value of Maximum Volume Setup.
• When DMR playback ends, the TV volume will return to the
value in effect when DMR playback was started.
External Control Setup
Media Renderer Setup
Preferences
Personal TV Setup
REGZA-LINK Setup
MHL Setup
Recording Setup
3D Setup
Network Setup
Camera Sensor Setup
Network Device Setup
55
CONTROLS AND FEATURES
English
When the TV is connected to the home network via Wireless LAN,
Wake-on-LAN can be received from an external device
connected to the home network to turn on the TV.
aIn the Preferences menu, press B or b to select
Network Device Setup and press OK.
bPress B or b to select Power Control Mode and
press C or c to select On or Off.
NOTE:
• When Wired is selected for the Network type in Network
Setup, this feature will be grayed out.
• Depending on the device connected to the home network,
it may take a while for the TV to turn on.
• Depending on the device connected to the home network,
this feature may not work.
• If the unencrypted Wireless Setup is done, this feature can
not be used.
The TV’s DMR device name can be changed. The device name can
be confirmed from the DMC.
aIn the Preferences menu, press B or b to select
Network Device Setup and press OK.
bPress B or b to highlight Device Name Setup and
press OK.
cHighlight the Device Name field and press OK. The
Software Keyboard window will appear.
dInput the Device Name by using the software
keyboard (see page 53). Press the BLUE button.
NOTE: The Device Name can be up to 15 characters
long.
eHighlight Done and press OK to save your setting.
Using the USB HDD Function
The USB HDD function can be used to record and
view digital broadcast programmes. Read the
precautions below before recording or viewing
programmes using the USB HDD function.
NOTE:
• Recorded programmes saved on the USB HDD can only be
viewed on this TV. They cannot be viewed when connected
to another TV (including the same model of TV), a PC, or
other device.
• You cannot watch one channel while recording another.
• If the recording time to the USB HDD is too short, no data
may be saved.
• You cannot record video input signals on the USB HDD.
• Not all types of broadcast may be recordable.
• After programming the TV to record digital broadcasting,
do not disconnect the power plug before recording starts.
Also, leaving the power switch “ON” until recording is
scheduled to start, may cause the recording to fail.
• Should video or audio recording fail due to malfunction of
the TV or poor reception, no compensation shall be paid.
• You can reserve up to a total of 64 programmes for
recording and viewing.
• If there is a power failure or the power plug is disconnected
during programmed recording, recording will stop and will
not resume when the power returns or the plug is
reconnected.
• Do not disconnect the power plug when the indicator lamp
is lit.
• Any changes implemented by the broadcasting station may
affect programme scheduling.
• Scheduling of multiple consecutive programmes may result
in the beginning of each programme not being recorded.
• When the “Programme Tracking” for programmed
recording is set to “On” and the broadcast time of the
scheduled programme overlaps with the start time of timer
viewing due to delay, extension, or other causes, timer
viewing will be cancelled.
• Depending on the situation at the time, not all items can be
set or changed. (“X” indicates no setting.)
• Programmed recording cannot take place if the power plug
is not connected.
• Disconnecting the power plug during recording may result
in failure to save the recorded programme.
• Changing the USB 2 Port Setup to Media Player will
invalidate all previously made programmed recordings (see
page 70).
Power Control Mode
Device Name Setup
56
CONTROLS AND FEATURES
English
You can easily record the programme currently being viewed.
aPress the ● REC button on the remote control.
Recording for the currently viewing programmes will
start.
The programme indicator (red) will be lit.
To stop recording
aPress the v (stop) button.
A confirmation window “Do you want to stop
Recording” will appear.
bPress C or c to select Yes and press OK.
Recording will stop.
Programmed recording can be scheduled easily using the
Programme Guide or by specifying the date and time.
PLEASE NOTE:
When a timed programme is about to start, an information
screen will appear offering the option of watching or
cancelling the programme. The menus and other channels
will not be available during the timed programme unless the
programme timer is cancelled.
It will only be possible to create or edit programme timers for
the currently tuned DTV input.
To schedule programmed recording using the
Programme Guide
aPress the GUIDE button on the remote control (or
select TV Programmes / Guide menu from the menu
system) to display the EPG screen.
bPress B b C c to highlight the programme you want
to record.
cPress OK. The Set Timer menu will appear.
dPress B or b to highlight Timer Type and press C or
c to select Recording.
ePress B or b to highlight Recording Device and
press C or c to select the connected USB HDD.
fPress B and b to go through the list adding the
details of the programme by using the number
buttons and C and c to make selections.
Programme Tracking:
If information concerning programme delay is sent
from the broadcasting station, Programme Tracking
will link recording with a delay of up to three hours.
Programme Tracking is enabled when On is selected.
(It does not support advancing of the broadcast time.)
Protect:
Select this function when you want to protect a
recorded programme. When On is selected, the
programme will be protected. You can protect and
unprotect recorded programmes afterwards.
Personal Grouping:
Setting Personal Mode for a programme when it is
recorded makes it easier to find later for viewing.
Select your preferred Personal Mode. If you select
None, the programme will be grouped by All in
Library.
NOTE: To change the set Start Time or End Time,
select Change Time and press OK. Change the Start
Time or End Time from the displayed Set Timer
screen.
gPress B or b to highlight Set Timer and press OK.
The ORANGE LED will be lit.
To record DTV programmes
(One Touch Recording)
To schedule programmed recording
Set Timer
The Daily Politics
10:50 Tue, 26 Apr
Timer Type
Recording Device
Programme Tracking
Protect
USB HDD1
2 CABC Channel
11:30
-
12:30 Tue, 26 Apr
Recording
Change Time
On
Off
Off
Subtitle
Personal Grouping None
—
Edit
Set Timer Delete Timer
50
57
CONTROLS AND FEATURES
English
To search for and schedule a programme you want
to record using Genre Search
aIn the Guide screen, press QUICK.
bPress B or b to highlight Genre Colour in the Quick
Menu and press OK.
cWith the focus on a particular genre, press the desired
coloured button to assign. Four colours will be
available to set. Press BACK to go back to the Guide
screen.
dPress the YELLOW button to access the Genre
Search screen.
ePress C or c to select the genre. Programmes listed
will change for the new genre. Press B or b to select
the programme for which you want to schedule
recording.
fPress OK. The Set Timer menu will appear.
gPress B or b to highlight Timer Type and press C or
c to select Recording.
hPress B or b to highlight Recording Device and
press C or c to select the connected USB HDD.
iPress B and b to go through the list adding the
details of the programme by using the number
buttons and C and c to make selections.
Refer to step 6 on page 56 for details.
jPress B or b to highlight Set Timer and press OK.
The ORANGE LED will be lit.
Genre Colour
Movies
Colour Setup
34 AB1
11 NT1
9 W9
34 AB1
11 NT1
31 PARIS PREMIERE
9 W9
11 NT1
31 PARIS PREMIERE
11 NT1
11 NT1
34 AB
31 PARIS PREMIERE
Indiana Jones and the Temple of Doom
Red Corner
The Lawnmower Man
A Vow to Kill
Parenthood
Body and Soul
The Nun’s Story
Red Corner
The Real Blonde
Critters
The jackal
Coup De Ville
Hard Rain
Wed,27 Apr 22:15- 23:55
Wed,27 Apr 0:15- 1:45
Thu,28 Apr 1:20- 3:00
Fri,29 Apr 1:30- 3:00
Sat,30 Apr 0:45- 2:40
Sat,30 Apr 1:15- 3:00
Sat,30 Apr 15:00- 17:30
Sat,30 Apr 23:20- 1:15
Sun,1 May 0:40- 2:00
Sun,1 May 0:40- 2:20
Sun,1 May 21:10- 23:20
Sun,1 May 23:20- 1:15
Mon,1 May 1:10- 3:00
Genre Search
10:50 Tue, 6 Apr
Movies
Set Timer
The Daily Politics
10:50 Tue, 26 Apr
Timer Type
Recording Device
Programme Tracking
Protect
USB HDD1
2 CABC Channel
11:30
-
12:30 Tue, 26 Apr
Recording
Change Time
On
Off
Off
Subtitle
Personal Grouping None
—
Edit
Set Timer Delete Timer
50
58
CONTROLS AND FEATURES
English
To programme the timer
aPress MENU / C c / B / C c to highlight TV
Programmed / Programme Timers icons and press
OK.
bSelect the unprogrammed column (blank column)
and press OK.
The Set Timer menu will appear.
cPress B or b to highlight Timer Type and press C or
c to select Recording.
dPress B and b to go through the list adding the
details of the programme by using the number
buttons and C and c to make selections.
Channel:
Select the channel for programmed recording.
Date:
Select the date for programmed recording.
Start Time:
Select the time to start recording.
End Time:
Select the time to end recording.
Repeat:
Select “Once”, “Daily” or “Weekly”.
Recording Device:
Select the connected USB HDD.
Protect:
Select this function when you want to protect a
recorded programme. When On is selected, the
programme will be protected.
You can protect and unprotect recorded programmes
afterwards.
Personal Grouping:
Select a Personal Mode for the programme to be
recorded to make it easier to find later for viewing.
Select your preferred Personal Mode. If you select
None, the programme will be recorded to All in
Library.
Subtitle:
Select On when you want subtitles to be included in
the recording.
ePress B or b to highlight Set Timer and press OK.
The ORANGE LED will be lit.
To schedule a programme using the information
screen
aPress , the information screen will appear giving
details of the channel and programme currently
being viewed.
bPress B or b to select the Next and press OK. The Set
Timer menu will appear.
Once The selected content is recorded once.
Daily The same time slot on the same channel
is recorded every day on and after the
selected day.
Weekly The same time slot on the same channel
on the same day of the week is recorded
on and after the selected day.
Set Timer 10:50 Tue, 26 Apr
Repeat
Date
Start Time
End Time
Channel
Recording Device
Protect
Personal Grouping
USB HDD1
Once
Timer Type Recording
Off
None
Subtitle Off
—
Edit
Set Timer Delete Timer
30 CABC Channel
10:51
11:51
Tue, 26 Apr 2011
REC
D+
3D 2D
Change
6:00 Thu, 11 Oct
8888
ITV1 London
8888
ASTRA 19.2° E
ASTRA 19.2° E
Now
MLB Young’s two-run triple leads AL over NL
MLB Young’s two-run triple leads AL over NL
15 min left
News
8:00- 9:00
6:00- 8:00
Next
Also
HD AD 18
16:9
AD English
Side by Side
World News and Sports
USER Name 3
Set Timer
The Daily Politics
10:50 Tue, 26 Apr
Timer Type
Recording Device
Programme Tracking
Protect
USB HDD1
2 CABC Channel
11:30
-
12:30 Tue, 26 Apr
Recording
Change Time
On
Off
Off
Subtitle
Personal Grouping None
—
Edit
Set Timer Delete Timer
50
59
CONTROLS AND FEATURES
English
cPress B or b to highlight Timer Type and press C or
c to select Recording.
dPress B or b to highlight Recording Device and press
C or c to select the connected USB HDD.
ePress B and b to go through the list adding the
details of the programme by using the number
buttons and C and c to make selections.
Refer to step 6 on page 56 for details.
fPress B or b to highlight Set Timer and press OK.
The ORANGE LED will be lit.
You can check, edit or delete scheduling information.
aPress MENU / C c / B / C c to highlight TV
Programmes / Programme Timer icons and press
OK. Programme Timer screen will appear.
Recording List:
• Depending on the transmitter information, the
programme broadcast time or other information
may not be correctly displayed in the recording list.
• The programme does not appear in the recording
list immediately at the start of recording, but
appears a few minutes after recording starts.
• Up to 500 programmes can be displayed in the
recording list.
•If the channel settings are changed, the digital
channel number, or other information may not
appear correctly in the recording list.
• As the displayed programme time is calculated
from the actual recording information, it may not
match the recording time on the USB HDD.
To check a schedule
aPress B or b on the Programme Timer screen to
check the schedule.
To edit a schedule
aPress B or b on the Programme Timer screen to
select the title whose schedule you want to edit and
press OK.
The Set Timer screen will appear. Change the settings
as required, following the same procedure as for
setting the schedule.
bPress B or b to highlight Set Timer and press OK.
To delete a schedule
aPress B or b on the Programme Timer screen to
select the title whose schedule you want to delete.
bPress the RED button.
Press C or c in the displayed confirmation window to
select Yes and press OK. The selected schedule will be
deleted.
NOTE: You can also delete a schedule by selecting Delete
Timer from the Set Timer menu for each programming
method.
Display the Library screen and select the title of the recorded
programme from the list.
aPress MENU / C c / B / C c to highlight TV
Programmes / Library icons and press OK. Library
screen will appear.
bPress B or b to select the title you want to view.
The content of the title selected on the thumbnail
screen is played.
To change the order in which the titles are listed, press
the BLUE button to select New or Old.
To display the titles by week or by Personal Mode,
press the YELLOW button to select All, Weekly or
Personal Grouping.
To check, edit or delete scheduling
information
To view a recorded programme
Sort : New
Sun Mon Tue Thu Fri SatWed
WWWWWW
WWWWWWWWWWWW
WWWWW
14:15 Wed, 16 Feb
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
Library
Weekly
1235 ITV London
ASTRA 19.2°E
USB HDD3
Remaining Capacity:
86% (912.0GB)
10 July 2011 14:30(01:30)
Wed, 16 Feb 10:00
Wed, 16 Feb 10:00
Thu, 17 Feb 10:00
Thu, 17 Feb 10:00
Fri, 18 Feb 10:00
Fri, 18 Feb 10:00
Fri, 18 Feb 10:00
Sat, 18 Feb 10:00
Sun, 18 Feb 10:00
Sun, 18 Feb 10:00
Sun, 18 Feb 10:00
Mon, 18 Feb 10:00
Sort : New
Sun Mon Tue
WWWWWW
WWWWWWWWWWWW
WWWWW
WWWWWWW
WWWWWWW
Library
Weekly
We
We
Th
Th
60
CONTROLS AND FEATURES
English
Press C or c to select a day tab or Personal Mode tab.
NOTE: If no titles have been registered to Personal
Mode, Personal Grouping will be grayed out.
cPress OK.
Viewing starts.
● icon appears next to the title currently being
recorded.
When the title currently being recorded is selected
and OK is pressed, playback will start from the
beginning of the programme currently being
recorded.
Operations during viewing
The following operations can be performed using the remote
control buttons.
c
To PLAY ZTo SKIP-BACK
vTo STOP CC To REWIND
W/wTo PAUSE/STEP cc To FAST FORWARD
To start Time Shift zTo SKIP-FORWARD
Recording
As well as viewing the list of recorded titles on the Library screen,
you can protect or delete titles and register titles to Personal
Mode.
To display the Library screen
aPress MENU / C c / B / C c to highlight TV
Programmed / Programme Timers icons and press
OK.
bPress B or b to select Library and press OK. The
Library screen will appear.
To protect or unprotect a recorded programme
Protecting a programme prevents it from being accidentally
deleted.
Select the title of the programme you want to protect and
press the GREEN button. icon appears next to the title and
the programme is protected.
If Protect is set to On when the programme is recorded,
icon appears next to the title of the recorded programme.
When a title with icon is selected and the GREEN button is
pressed, icon disappears and the programme is
unprotected.
To delete a recorded programme
aPress the RED button. Check boxes will appear next to
the titles.
bPress B or b to select the title you want to delete and
press OK. A check mark will be inserted in the check
box.
To insert a check mark against all the titles, press the
GREEN button.
To uncheck all the check boxes, press the BLUE
button.
NOTE:
• A check mark will not be inserted against protected
titles.
• Note that once deleted, a title cannot be restored.
cPress the RED button.
Select Yes in the confirmation window and press OK.
All the titles with check marks will be deleted.
Operations from the Library screen
Sort : New
Sun Mon Tue Thu Fri SatWed
WWWWWW
WWWWWWWWWWWW
WWWWW
14:15 Wed, 16 Feb
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
Library
Weekly
1235 ITV London
ASTRA 19.2°E
USB HDD3
Remaining Capacity:
86% (912.0GB)
10 July 2011 14:30(01:30)
Wed, 16 Feb 10:00
Wed, 16 Feb 10:00
Thu, 17 Feb 10:00
Thu, 17 Feb 10:00
Fri, 18 Feb 10:00
Fri, 18 Feb 10:00
Fri, 18 Feb 10:00
Sat, 18 Feb 10:00
Sun, 18 Feb 10:00
Sun, 18 Feb 10:00
Sun, 18 Feb 10:00
Mon, 18 Feb 10:00
Sort : New
Sun Mon Tue
WWWWWW
WWWWWWWWWWWW
WWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
WWWWWWW
Library
Weekly
We
We
Th
Th
F
F
F
61
CONTROLS AND FEATURES
English
To register a recorded title to Personal Mode
aSelect the title you want to register to Personal
Mode.
bPress the QUICK button to display the Personal
Mode registration menu.
cPress C or c to select the Personal Mode to which
you want to register the title and press OK.
The title will be registered to the selected Personal
Mode.
You can remove a title from the registered Personal
Mode by selecting None.
To check the remaining USB HDD capacity
You can check the remaining capacity of the USB HDD using
Remaining Capacity.
NOTE: The remaining capacity displayed is only a guide; it is
not guaranteed.
If you move away from the TV for a while, such as when the
phone rings while you are watching TV, you can easily start
recording and then catch up with the programme later.
aPress W/w on the remote control while viewing
DTV.
The screen will switch to the Pause image and
recording will start automatically.
The recording time is the time set in One Touch
Recording (see page 56).
bPress
c
(play).
Catch-up viewing will start from where the
programme was paused.
You can set your preferences for One Touch Recording or for
scheduling recording.
To set the recording time for One Touch Recording
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Preferences icon and
press OK.
cPress B or b to select Recording Setup and press
OK.
dPress B or b to select One Touch Recording Time.
ePress C or c to select the recording time.
You can set the Programme End Time in 30-minute
increments in the range of 30 minutes to 360 minutes.
To set the padding time for programmed
recording start time and end time.
aIn the Recording Setup screen, press B or b to select
Start Padding Time.
bPress C or c to select a time.
You can select from None, 1 minute, 3 minutes, 5
minutes and 10 minutes. Recording will start at the
selected number of minutes prior to the recording
start time.
cPress B or b to select End Padding Time.
dPress C or c to select a time.
You can select from None, 1 minute, 3 minutes, 5
minutes and 10 minutes.
Recording will end at the recording end time plus the
selected number of minutes.
Other useful functions
(Time Shift Recording)
Quick Menu
Personal Grouping None
1235 ITV London
ASTRA 19.2°E
USB HDD3
Remaining Capacity:
86% (912.0GB)
10 July 2011 14:30(01:30)
Thu, 17 Feb 10:00
Fri, 18 Feb 10:00
Fri, 18 Feb 10:00
Fri, 18 Feb 10:00
Sat, 18 Feb 10:00
Sun, 18 Feb 10:00
Sun, 18 Feb 10:00
Sun, 18 Feb 10:00
Mon, 18 Feb 10:00
Recording Setup
Preferences
Personal TV Setup
REGZA-LINK Setup
Recording Setup
Photo Frame Setup
Network Setup
Camera Sensor Setup
Network Device Setup
Teletext Auto
Recording Setup
Start Padding Time
End Padding Time None
None
Programme End Time
Recording Devices
One Touch Recording Time
62
CONTROLS AND FEATURES
English
Setting USB HDD Energy-Saving Mode
aIn the Recording Setup screen, press B or b to select
Recording Devices and press OK.
bPress B or b to select Device Energy Saving Mode.
cPress C or c to select Normal or Energy Saving.
NOTE:
• When set to Energy Saving, it may take a while for the USB
HDD to function.
• When set to Energy Saving, depending on the type of USB
HDD, the USB HDD indicator lamp may not indicate standby
status even when in standby status.
To change the name of the USB HDD
aIn the Recording Setup screen, press B or b to select
Recording Devices and press OK.
bPress B or b to select Device List and press OK. The
Device List screen will appear.
cPress the GREEN button.
Edit the desired name by using the software keyboard
(page 53). The maximum number of characters is 10.
NOTE: If multiple USB HDD appear on the Device List screen
in Step 2, press B or b to select the USB HDD whose name
you want to change.
To perform a USB HDD operation test
aPress the YELLOW button on the Device List screen.
USB HDD operation test will start.
Wait until the test ends.
NOTE: The results of the device test are only a guide.
The device may not function as shown in the results.
To register a USB HDD
aPress OK on the Device List screen.
Press C or c to select Yes in the confirmation window
that will appear and press OK. USB HDD registration
will start. Wait until registration ends.
NOTE:
• If multiple USB HDD appear on the Device List screen, press
B or b to select the USB HDD you want to register.
• If a USB HDD is re-registered, it will not be formatted.
To format a USB HDD
aPress the BLUE button on the Device List screen.
Press C or c to select Yes in the confirmation window
that will appear and press OK. Formatting will start.
Wait until formatting ends.
NOTE:
• If multiple USB HDD appear on the Device List screen, press
B or b to select the USB HDD you want to format.
• When the USB HDD is formatted, all the data stored on the
USB HDD will be deleted.
aPress MENU / C c to highlight Setup icon.
bPress B / C c to highlight Preferences icon and
press OK.
cPress B or b to select Recording Setup and press
OK.
dPress B or b to select Recording Devices and press
OK. The Device List screen will appear.
ePress the RED button.
Press C or c to select Yes in the confirmation window
that will appear and press OK. The Connected check
mark will be removed. Disconnect the USB HDD.
NOTE: If multiple USB HDD appear on the Device List screen,
press B or b to select the USB HDD you want to disconnect.
Recording Devices
Normal
Device List
Device Energy Saving Mode
Device List
USB HDD 1
Device Name Connected
Registered
To disconnect a USB HDD
Device List
USB HDD 1
Device Name Connected
Registered
63
CONTROLS AND FEATURES
English
If programmed recording is not performed correctly or some
other error occurs, you can check the error content using
Recording Information. Up to 64 Recording Information
entries will be recorded and when the maximum is exceeded,
entries will be deleted starting from the oldest. You can delete
Recording Information after you have checked it.
aPress QUICK to open the Quick Menu.
bPress B or b to select Recording Information and
press OK. The Recording Information screen will
appear.
The recorded Recording Information list will appear.
(Yellow) icon will appear next to unread Recording
Information.
To check the content of Recording Information
aIn the Recording Information screen, press B or b
to select the title you want to display.
bPress OK. The content of Recording Information will
appear.
Display Example
When you have checked the content, press BACK. The
screen will return to the previous screen.
To delete Recording Information
aIn the Recording Information screen, press B or b
to select the Recording Information you want to
delete and press OK.
bPress the RED button.
Select Yes in the confirmation window that will
appear and press OK.
The selected Recording Information will be deleted.
If scheduled time slots are next to each other and there is
more than one minute between the end time of the first
schedule and the start time of the next schedule,
programmed recording will be performed correctly.
• When Start Padding Time and End Padding Time are set
(see page 61), the start time and end time will be the time
plus the additional minutes.
If scheduling times overlap, priority will be given to the
programmed recording which starts first. When the
programmed recording that started first ends, recording will
switch to the next scheduled programme. At this time,
depending on how far the scheduling times overlap, the
beginning section of the next scheduled programme may not
be recorded.
• When End Padding Time is set for the first programmed
recording (see page 61), depending on how far the
scheduling times overlap, the End Padding Time may be
ignored and recording of the next scheduled programme
may start. As priority is given to the time set in the Set Timer
menu over the Padding Time, recording will automatically
be triggered when the next scheduled programme start
time is reached during End Padding Time.
To confirm/delete Recording
Information
Recording Information
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
15
/
64
Recording Information
8888 ITV1 London Wed, 23 Feb 10:00
-
11:00
Scheduling Conflict
Could not record properly because there was a conflict with
another event of a higher priority
Scheduling priority
64
CONTROLS AND FEATURES
English
Camera Sensor Settings
The Camera Sensor can detect a person’s face or
movement and identify individuals by their
registered faces. The screen mute and the standby
mode functions by the face detection and motion
detection functions of the Camera Sensor operate,
and power consumption is saved as a result.
aIn the Preference menu, press B or b to select
Camera Sensor Setup and press OK.
bPress B or b to select Camera Sensor and press C or
c to select On (to activate the following settings).
cPress B or b to select Camera Sensor Mode and
press C or c to select Normal or Energy Saving.
•Normal
If the Camera doesn't detect the person for
60 seconds, the screen brightness decreases. In
addition, after the time set with Time until Picture
Off, the picture disappears. In addition, after the
time set with Time until Standby, the TV turns off
(standby mode).
•Energy Saving
If the Camera doesn't detect the person for 60
seconds, after the time set with Time until Picture
Off, the picture disappears. In addition, after the
time set with Time until Standby, the TV turns off
(standby mode).
dPress B or b to select Time until Picture Off and
press C or c to select 10min, Test (5sec.)....60min.
(5min.intervals).
NOTE: If the Camera Sensor Mode is in Energy
Saving mode, this feature will be grayed out.
ePress B or b to select Time until Standby and press
C or c to select 5min....60min. (5min.intervals).
fPress B or b to select Test Sensor and press OK to
display Test Sensor screen.
The Camera will detect Face or Motion.
The detected icon will be highlighted.
gIf the Camera doesn't detect the person easily, press
C or c to select the Gamma Adjustment options
Auto, 1, 2, 3, 4 or 5 watching the camera image on
screen until the camera detect the person.
Test Sensor
Gamma Adjustment
Face Detected Motion Detected
Edit
Auto
65
CONTROLS AND FEATURES
English
Using Toshiba Places
A new cloud based service, where content
(movies, photos, etc.) can be viewed and shared
across the web through a simple user interface
called “Toshiba Places”.
NOTE: You need to configure a home network before using
this feature (see page 16).
aPress on the remote control, or press MENU / B /
Cc to highlight Connected TV / Toshiba Places
icons and press OK.
bPress BbC c to select the desired place and press
OK.
NOTE:
• Some features require an always-on broadband internet
connection, firmware update and/or additional bandwidth
dedicated to this product. Third party internet services may
change or be discontinued or restricted at any time. Toshiba
makes no warranties, representations, or assurances about
the content, availability or functionality of third-party
content or services. Use of third party internet services may
require registration by a computer and/or payment of
charges and membership. Not all services or content may
be available on this product, in your country or with your
language. In order to experience the full capabilities of this
product, fully compatible devices may be required. For
more information, visit
http://www.toshibaplaces.com/about.
• This service may be forcibly blocked according to the
situation of CSP service.
Using YouTube™
YouTube is a video-sharing service managed by
YouTube, LLC.
This TV allows you to view YouTube content.
NOTE:
• You need to configure a home network before using this
feature (see page 16).
•If Network Lock is set to On, it will be necessary to enter
your four-digit PIN code in order to access network features
(see page 83).
aPress MENU / B / Cc to highlight Connected TV /
YouTube icons and press OK.
The YouTube top page will appear.
bPress BbC c to select the file you want to view, and
press OK.
To close YouTube:
aPress EXIT.
NOTE:
• This TV may not be able to perform all of the same
operations as a computer.
• Depending on the network environment and use case, you
may experience difficulty viewing content.
• Though the same volume value, actual volume might be
greatly different depending on contents.
• It may take time for the TV to load and begin playing back
content.
• Service content and the look and feel of the interface may
be changed at any time without prior notice.
66
CONTROLS AND FEATURES
English
The Function Menu provides easy access to functions that are
commonly used.
aPress the BLUE button while displaying YouTube.
The Function menu window will appear.
bPress C or c to select the desired icon and press OK.
Switching the pointer
The tool that operates the screen can be changed to pointer
or drag mode.
aFrom the Function menu, press C or c to select
Pointer, and then press OK.
bIf you select , see “To use the Pointer: ON:” on this
page. If you select , see “To use the Drag Mode:”
on this page.
To use the Pointer: ON:
aPress B or b to select Pointer: ON and press OK.
• will appear.
bPress BbC c to the place where changes to ,
and then press OK.
NOTE: When Pointer: OFF is selected and BbC c is pressed,
the highlight moves to linked areas.
To use the Drag Mode:
aPress B or b to select Pointer: ON and press OK.
bPress the BLUE button.
cFrom the Function menu, press C or c to select
Pointer, and then press OK.
dPress B or b to select Drag Mode and press OK.
• will appear.
ePress OK, and then changes to .
fPress BbC c to move the selected item in the
desired place.
Switching the frame
aFrom the Function menu, press C or c to select
Menu, and then press OK.
bPress C or c to select Page Tasks.
cHighlight Switch Frames and press OK.
Setting the view feature
aFrom the Function menu, press C or c to select
Menu, and then press OK.
bPress C or c to select View.
cPress B or b to select the desired item and press OK.
dPress B or b to select the desired setting and press
OK.
Using the Function Menu
Item Description
Back Returns to the previous page.
Forward Moves to the forward page.
Reload/
Abort
Updates the displayed page.
Aborts update
( is displayed while reading, and is
displayed in other case.)
Home Returns to the top page of YouTube.
Pointer Switches the pointer On/Off or drag mode.
Menu Switches the frame or sets various settings.
http://www.youtube.com/xl
Back Forward Pointer Menu
Reload Home
Item Settings
Display
Mode
Normal: Displays YouTube page with the
size as it is.
Just-Fit Rendering: Displays YouTube page
at a size that has been adjusted to precisely
fit the width of your TV.
Text Size Changes the font size of the screen. Select
from Largest, Large, Medium, Small or
Smallest.
NOTE: This font size is effective only for the
page.
Advanced
Settings
See the next column.
Page
Information
Displays the information of the page you are
viewing.
Server
Certificates
Displays the server certification.
67
CONTROLS AND FEATURES
English
If you select Advanced Settings:
aPress BbC c to select the setting items, and press
OK. A check will appear in the box. To remove the
check, press OK again.
bPress BbC c to select OK field and press OK.
Setting other features
aFrom the Function menu, press C or c to select
Menu, and then press OK.
bPress C or c to select Settings.
cPress B or b to select the desired item and press OK.
dPress B or b to select the desired setting and press
OK.
NOTE:
• Cookie is the technical information that a website leaves in
this TV so that the website will recognize you when you use
it again.
• Cache is a system used to shorten the display time by
checking the past data preserved in this television when a
page that you viewed before is seen again.
To confirm Root Certificates or CA Certificates:
aPress B or b to select Security in step 3 in Setting
other features.
bPress BbC c to select Root Certificates or CA
Certificates and press OK.
cPress B or b to select the desired certificate.
• When OK is pressed, a detailed information window
will appear.
• When the BLUE button is pressed, Disable or
Enable bar will appear. It changes whenever BLUE
button is pressed.
dPress BACK.
Item Description
Image Sets display/non-display of images.
Table Sets effect/non-effect of tables.
CSS Sets effect/non-effect of CSS.
Pop-up
window
Sets effect/non-effect of pop-up windows.
Animation Sets display/non-display of animations.
JavaScript Sets effect/non-effect of JavaScript.
Word wrap Sets effect/non-effect of Word Wrap. If Word
Wrap is enabled, a word not finished at the
end of a line is shifted to the next line.
Rapid-
Render
Sets effect/non-effect of Rapid-Render. If
Rapid-Render is enabled, texts and links are
displayed first, and the images and the
tables, etc. are displayed afterward. The
highlight can be moved with the text and
the link displayed.
Item Settings
Security When jumping from a protected page to an
unprotected page, the message is displayed
when the check is applied to Notify of
secure/non-secure page changes.
Apply the check to select SSL version from
SSL Version to use (SSL2.0, SSL3.0,
TSL1.0).
A content confirmation of the certification
and a setting effect/non-effect can be done
in Root Certificates and CA Certificates
shown below.
Cookies Accept all: Cookie is received, and it records
in this TV.
Reject all: Cookie is not received.
Prompt before accepting: When Cookie is
received, a message window will be
displayed.
Delete
Cookies
Deletes all recorded Cookies.
Cache Use cache: When the check is applied to
this, cache is used.
Delete All Cache Data: Deletes all the cache
data preserved in the television.
Browser
Information
Displays the information on a browser.
68
CONTROLS AND FEATURES
English
Using Hybrid TV Standard
(if available)
Hybrid TV Standard enables the TV to receive
HbbTV services. TV services which support this
feature often show “press RED” on the screen.
NOTE: You need to configure a home network before using
this feature (see page 16).
aPress MENU / C c / B / C c to highlight Setup /
Preferences icon and press OK.
bPress b to select Hybrid TV Standard.
cPress C or c to change from Disabled to Enabled.
When changing from Disabled to Enabled, a
Network Connection Test is performed. If the result
is OK, then the setting changes to Enabled. If not, the
setting remains Disabled.
When “press RED” is indicated on the screen, press
the RED button to access HbbTV service site, and then
press B b C c to select the desired contents.
NOTE:
• This service is not available outside Germany.
• The HbbTV service indication or required key operations
may not be possible depending on the service contents. In
this case, set the Hybrid TV Standard setting to Disabled.
• Toshiba makes no warranties, representations, or
assurances about the content.
Using the Media Player
This TV allows you to enjoy movie, music and
photo files stored on a USB device connected to
the USB port.
Moreover, you can also play photos, movies or
music files from your PC by connecting the TV to
your home network.
Terminology:
DMP: DLNA CERTIFIED™ Player
DMS: DLNA CERTIFIED™ Server
DMR: DLNA CERTIFIED™ Renderer
DMC: DLNA CERTIFIED™ Controller
• DMP: The TV can control and play content from a DMS.
- A DMS is a device that can function as a server for DMP or
DMR.
• DMR: The TV can play content from a DMS. Playback is
controlled by a DMC.
- A DMC is a device that can instruct the TV to display
content.
NOTE:
• Do not insert/remove USB device while in use.
• MENU is not available during playback.
• When you want to use your TV as a DMR, set Media Renderer
to On (see “Media Renderer” on page 54).
Media Player Specifications
Device
USB device
Interface version: USB2.0 HS
USB Mass Storage Class devices (MSC)
NOTE:
• Connectivity is not guaranteed for all devices.
• A USB hub can not be used.
File system: FAT16 and FAT32
Maximum memory size: Unlimited
DLNA CERTIFIED™ Server: Your PC (for example)
You must obtain any required permission from
copyright owners to download or use copyrighted
content. TOSHIBA cannot and does not grant such
permission.
69
CONTROLS AND FEATURES
English
Using Media Player with USB
When Auto Start is enabled, you will be asked if you
want to start the Media Player whenever a USB device
is inserted. If Auto Start is disabled (or if you want to
connect to a DMS on the network), you must manually
start the Media Player from the menu.
To change the Auto Start setting:
aPress MENU / Cc / B / Cc to highlight Media
Player / Media Player Setup icons and press OK.
bPress B or b to select USB Auto Start, and then press
C or c to select On or Off.
Auto Start:
aInsert USB device into the USB socket on the left side
of the TV. A prompt will appear.
bPress C or c to select Yes, and then press OK.
cPress B or b to select Photo, Movie, or Music and
press OK.
NOTE: If Auto Start is set to Off, you can start the Media
Player manually.
Manual Start:
aInsert USB device into the USB socket on the left side
of the TV.
bPress MENU / Cc to highlight Media Player icon.
cPress B / Cc to highlight Photo, Movie or Music
icon and press OK. The contents list will appear.
To select a file in the list of contents:
aPress Bb (C c) to select a file or folder.
bPress OK to move to the next layer, or press BACK to
return to the previous layer.
To close the Media Player:
aPress EXIT.
Using the Media Player with a DLNA CERTIFIED™
Server
You need to configure a home network before using
this feature (see page 16).
aPress MENU / Cc to highlight Media Player icon.
bPress B / Cc to highlight Photo, Movie, or Music
icon and press OK. The thumbnail (for Photo) or list of
files (for Movie and Music) will appear.
NOTE: If there is more than one media server on the
network, a list of all media servers will be displayed.
Highlight the server you want to use, and press OK.
cPress B or b to select a DMS if the selection window
is displayed.
To select a file in the list of contents:
aPress B or b to select a file or folder.
bPress OK to move to the next layer, or press BACK to
return to the previous layer.
To close the Media Player:
aPress EXIT.
Basic operation
USB Auto Start On
Media Player Setup
DivX
®
VOD
Media Server Setup
70
CONTROLS AND FEATURES
English
To display the device information:
aPress QUICK to open the Quick Menu in list mode or
Multi View mode.
bPress B or b to select Device Information.
Setting DLNA CERTIFIED™ Server waking up:
You only need to complete the Media Server Setup if
you wish to use the “Wake-on-LAN” feature.
aPress MENU / Cc / B / Cc to highlight Media
Player / Media Player Setup icons and press OK.
bPress B or b to select Media Server Setup and press
OK. A list of currently available DMSs will appear.
cPress B or b to select the desired device, and press
OK. A check will appear in the box. To remove the
check, press OK again.
dPress c to highlight Done, and then press OK to save.
NOTE:
• Up to 8 DMSs can be selected.
• Even if the device checked is powered off, it will be
displayed but grayed out in the Select Device window.
When OK is pressed on a highlighted grayed out item, a
confirmation of Wake-on-LAN is displayed. The TV tries to
wake up the DMS if Yes is pressed. The Server will start if it
supports Wake-on-LAN feature.
• When some DMSs are connected, it may take time until the
list is displayed. The list may be refreshed by the following
operation.
- The device selection window is closed once and it is
displayed again.
-The RED button is pressed.
USB 2 Port Setup (if available)
aPress MENU / Cc to highlight Setup icon.
bPress B / Cc to highlight System Setup icon and
press OK.
cPress B or b to select USB 2 Port Setup and press C
or c to select Recorder or Media Player.
There are three types of viewing modes.
Multi View
This view allows you to search for photos in a grid format.
The pictures are displayed using thumbnail data in each
image file.
The initial highlighted position will be on the top left
thumbnail in the Multi View.
aPress B b C c to move the highlight in one window.
If all of the photos will not fit in one screen, when
pressing C at the top left thumbnail, the screen will
move to the previous page. Conversely, when
pressing c at the bottom right thumbnail, the screen
will move to the next page.
PU Pu buttons can be used to page up/down the
photo list when there are more photos than will fit
onto one screen. When the PU Pu buttons are
pressed, the highlight shall be on the photo at the top
left of Previous/Next list.
bWhen you select a folder, press OK to move to the
next layer. Press BACK to move back to the previous
layer.
cPress OK to view the selected photo in Single View
mode.
NOTE: When the TV is used as a DMR, this feature is not
available.
Single View
In this mode, only files located in the selected directory will be
displayed. This view allows you to change the photo content
manually. When moving from Multi View to Single View, the
currently selected photo will be displayed.
Viewing photo files (on a DLNA
CERTIFIED™ Server or USB device)
Photo list example
/Folder Sort: Title
1/54
10:00 Fri, 21 Feb 2010
1920x1080
PageOK P
QUICK FeaturesSelect
71
CONTROLS AND FEATURES
English
a Press c to view the next photo. Press C to view the
previous photo.
bPress B to rotate the image 90° clockwise. Press b to
rotate the image 90° counterclockwise.
cPress to display file status information (file
number, photo title, date and time taken, resolution
etc.).
NOTE:
• The information may not be correctly displayed depending
on the content, DMC or DMS.
• You can not rotate in 3D (2D to 3D) mode.
Slide Show
This view allows you to watch a slide show of your photos. In
this mode, only files located in the selected directory will be
played.
aTo start slideshow, press OK in the Single View mode.
bPress C or c to view the previous/next photo.
cPress B or b to rotate the photo.
dPress to display file status information.
To set Interval Time and Repeat settings:
aPress QUICK to open the Quick Menu while in the
Single View mode or Slide Show mode.
bPress B or b to select either Interval Time or Repeat.
cPress C or c to adjust the setting and press OK.
To set Background Music
aPress QUICK to open the Quick Menu while in the
Slide Show mode.
bPress b to select Select Music and press OK.
cPress B or b to select Background Music and press
OK.
dPress B or b to select Background Music and press
C or c to select On.
eSelect a music file.
NOTE:
• The music must be selected from the same media (USB)
device or DMS from which the picture files will be played.
• This feature is not available when there is no music that can
be selected.
To zoom in/out photos
During the Single View mode or Slide Show mode, the zoom
function can be used.
RED button: x1 S x2 S x4 S x8 S x16 zoom
GREEN button: x16 S x8 S x4 S x2 S x1 zoom
BACK button: Normal playback
B b C c buttons: Vertical or Horizontal scrolling
To set the shuffle mode (USB only):
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Shuffle.
cPress C or c to select On or Off.
To sort the folders and files
aPress QUICK to open the Quick Menu from Multi
View mode.
bPress B or b to select Sort.
cPress C or c to select Title / File Name, New or Old
to set the sorting rule.
NOTE: Sorting may not be supported by some DMSs.
Item Description
Title (DMS) File sorting rules:
1. Unicode priority
2. (0, 1, ..., 9), capital alphabet (A, B, ..., Z),
small alphabet (a, b, ..., z)
3. Increasing order
File Name
(USB)
File sorting rules:
1. Unicode priority
2. (0, 1, ..., 9), capital alphabet (A, B, ..., Z),
small alphabet (a, b, ..., z)
3. Increasing order
New From new to old according to the date and
time when the picture was taken.
Old From old to new according to the date and
time when the picture was taken.
72
CONTROLS AND FEATURES
English
Selecting the Playback Mode
You can view 3D photos in 3D and you can also view 2D
photos in 3D.
Select the playback mode from the Quick Menu or switch
playback modes using the 3D button on the remote control.
The current Playback Mode is displayed at the top left of the
list mode.
To select the playback mode from the Quick Menu
aPress QUICK to open the Quick Menu in Multi View
mode.
bPress B or b to select Playback Mode and press C
or c to select 2D Mode, 3D Mode 1 or 3D Mode 2.
2D Mode
All photos are displayed in 2D.
3D Mode 1
3D photos are displayed in 3D and 2D photos in 2D.
3D Mode 2
All photos are displayed in 3D.
2D photos are converted and displayed in 3D, and 3D
photos are displayed in 3D.
To switch playback modes using the remote control
aPress 3D while in Single View mode.
The mode switches between 2D Mode, 3D Mode 1
and 3D Mode 2 each time 3D is pressed.
To display the device information
aPress QUICK to open the Quick Menu from Multi
View mode.
bPress B or b to select Device Information and press
OK.
NOTE: When the photos on the USB device are used, or the TV
is used as a DMR, this feature is not available.
To close the Photo Viewer
aPress EXIT. The television will return to the last viewed
channel or external input.
File Compatibility
See page 106.
You can select movies from a list of available files.
aPress B or b to select a file or folder. PU Pu buttons
can be used to page up/down the movie list when
there are more files than will fit onto one screen.
bWhen you select a folder, press OK to move to the
next layer. Press BACK to move back to the previous
layer.
cWith the desired file selected, press OK or
c
(play) to
start playback.
NOTE:
• On preview screen, if you highlight the file without
pressing OK, the content is played on a preview
screen. When OK is pressed, it is played in full screen
mode.
• Depending on the file size, it may take some time to
start playback.
dPress v to stop playback.
NOTE:
• If playback finishes before v is pressed, the screen will
return to the list.
• Depending on the file size, it may take some time for
playback to begin.
Viewing movie files (on a DLNA
CERTIFIED™ Server or USB device)
Movie list example
/Folder
Sort :File Name
1/9
PageOK P
QUICK FeaturesPlay
movie
MOVIE
Unprotected
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
WWWWWWWWWWWWW.mp4
00:00:20 / 00:04:00
73
CONTROLS AND FEATURES
English
During playback:
• Press W/w to pause.
You can move to the desired replay position by pressing C
or c during PAUSE.
PAUSE and operations during PAUSE may not be available
depending on the contents, DMC or DMS.
• To resume normal playback, press
c
(play).
• To play in fast reverse or fast forward directions, press CC
or cc during playback. Each time you press the CC or cc,
the playback speed will change.
PAUSE and operations during PAUSE may not be available
depending on the contents, DMC or DMS.
• To locate a specific file, press Z or z repeatedly.
• Press to display the file status information (content
number, movie title, progress time etc.).
NOTE:
• The information may not be correctly displayed
depending on the contents, DMC or DMS.
• During playback, you can adjust the Picture, Picture Size
and Sound menu functions from the Quick Menu.
To select subtitle and audio languages
• Press SUBTITLE repeatedly to select your preferred subtitle
language.
• Press s repeatedly to select your preferred audio
language.
NOTE: This feature may not be available depending on the
contents.
To set the repeat mode
aPress QUICK to open the Quick Menu.
bPress C or c to select Off, All or 1.
cPress BACK.
NOTE: When the TV is used as a DMR, this feature is not
available.
To sort the folders and files
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Sort.
cPress C or c to select Title / File Name, New or Old
to set the sorting rule.
NOTE: Sorting may not be supported by some DMSs.
To display the device information
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Device Information and press
OK.
NOTE: When movies on a USB device are used, or the TV is
used as a DMR, this feature is not available.
To close the Movie Viewer
aPress EXIT.
File Compatibility
See page 106.
Mode Description
Off The file is played back only once.
All Files in the same folder are repeatedly
played back.
1The same file is repeatedly played back.
Item Description
Title (DMS) File sorting rules:
1. Unicode priority
2. (0, 1, ..., 9), capital alphabet (A, B, ...,Z),
small alphabet (a, b, ..., z)
3. Increasing order
File Name
(USB)
File sorting rules:
1. Unicode priority
2. (0, 1, ..., 9), alphabet (A, B, ...,Z)
3. Increasing order
New From new to old according to the date and
time when the contents were updated.
Old From old to new according to the date and
time when the contents were updated.
74
CONTROLS AND FEATURES
English
To register your TV to a DivX® account
This TV allows you to play back files purchased or rented from
DivX® Video-On Demand (VOD) services. When you purchase
or rent DivX® VOD files on the internet, you will be asked to
enter a registration code.
aIn the Media Player Setup menu, press B or b to
select DivX® VOD and press OK.
bPress B or b to select DivX® VOD Registration and
press OK.
cThe DivX® VOD window will appear and you will see
the registration code. For details on registration,
please visit the DivX® website at
http://vod.divx.com
dCopy the activation file to a memory device and play
it on the TV.
To deactivate your device
aIn step 2 above, highlight DivX® VOD Deactivation,
and then press OK.
bA confirmation message will appear. Select Yes and
press OK.
cThe DivX® VOD window will appear and you will see
the deactivation code. For details on registration,
please visit the DivX® website at
http://vod.divx.com
ABOUT DIVX VIDEO: DivX® is a digital video format created by
DivX, Inc. This is an official DivX Certified® device that plays
DivX video. Visit divx.com for more information and software
tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device
must be registered in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your registration code,
locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your
registration.
DivX Certified® to play DivX® and DivX Plus™ HD (H.264/MKV)
video up to 1080p HD including premium content.
To playback DivX Plus HD content:
• To play in fast reverse or fast forward directions, press CC
or cc during playback. Each time you press the CC or cc,
the playback speed will change.
• This TV generates original chapter point in 10% increments
for 10 chapters in total, that are accessible by using the
Number buttons on the remote control.
During playback, press z to skip to the beginning of the next
chapter. When z is pressed twice in succession, it will repeat
two times of above. If z is pressed at the last chapter,
playback will skip to the beginning of the next content.
Press Z to skip to the beginning of the current chapter.
When Z is pressed twice in succession, it will skip to the
beginning of the previous chapter. If Z is pressed twice in
succession at the first chapter, stop playing the current
content and skip to the beginning of the previous content.
The Number button is used for direct jump. If the 3 button is
pressed, playback will jump to the beginning of 3rd chapter.
Even if the playback content have authored chapters, the
Number button is used to jump directly to Auto Generated
Chapter.
If the content has Authored Chapters, Z / z are using for
Authored Chapters.
NOTE: Depending on the content data will not be operated.
Using Multi Title and Alternative Timelines Multi
Title
DivX Plus HD files may contain up to 100 titles.
You can change the title (It contains same video file) by
pressing the RED button.
When the RED button is pressed, it will display the title
change window at the bottom on the screen (same as Subtitle
or Audio change window).
The title is changed cyclically each time the RED button is
pressed. Playback will start from start time of selected title
each time you press B or b.
NOTE: Depending on the content data will not be operated.
DivX
®
VOD Registration
DivX
®
VOD Deactivation
DivX
®
VOD
75
CONTROLS AND FEATURES
English
You can listen to music from a list of available files.
aPress B or b to select a file or folder. PU Pu buttons
can be used to page up/down the music list when
there are more files than will fit onto one screen.
bWhen you select a folder, press OK to move to the
next layer. Press BACK to move back to the previous
layer.
cWith the desired file selected, press OK or
c
(play) to
start playback.
NOTE: OK takes to you full screen playback. Playback
in preview start without pressing OK.
Moving cursor up/down plays music.
dPress v to stop playback.
NOTE:
• Depending on the file size, it may take some time for
playback to begin.
• During playback, you can adjust the Sound menu functions
from the Quick Menu.
During playback in full screen:
• Press W/w to pause.
• To resume normal playback, press
c
(play).
• You can move to the desired replay position by pressing C
or c during PAUSE.
PAUSE and operations during PAUSE may not be available
depending on the contents, DMC or DMS.
• To play in fast reverse or fast forward directions, press CC
or cc. Each time you press CC or cc, the playback speed
will change.
PAUSE and operations during PAUSE may not be available
depending on the contents, DMC or DMS.
To set the repeat mode:
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Repeat.
cPress C or c to select Off, All or 1.
dPress BACK.
NOTE: When the TV is used as a DMR, this feature is not
available.
To set the shuffle mode (USB only):
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Shuffle.
cPress C or c to select On or Off.
To sort the folders and files
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Sort.
cPress C or c to select Title / File Name, New or Old
to set the sorting rule.
NOTE: Sorting may not be supported by some DMSs.
Playing music files (on a DLNA
CERTIFIED™ Server or USB device)
Music list example
Title WWWWWWWWW
:
Artist WWWWWWWWW
:
00:00:34 / 00:05:19
/Folder
Sort :File Name
1 / 10
music
Unprotected
WWWWWWW.mp3
WWWWWWW.mp3
WWWWWWW.mp3
WWWWWWW.mp3
WWWWWWW.mp3
WWWWWWW.mp3
WWWWWWW.mp3
WWWWWWW.mp3
Page Full screenOK P
QUICK FeaturesPlay
MUSIC
Mode Description
Off Files in the same folder are played back
once.
All Files in the same folder are repeatedly
played back.
1The same file is repeatedly played back.
Item Description
Title (DMS) File sorting rules:
1. Unicode priority
2. (0, 1, ..., 9), alphabet (A, B, ...,Z)
3. Increasing order
File Name
(USB)
File sorting rules:
1. Unicode priority
2. (0, 1, ..., 9), alphabet (A, B, ...,Z)
3. Increasing order
New From new to old according to the date and
time when the contents were updated.
Old From old to new according to the date and
time when the contents were updated.
76
CONTROLS AND FEATURES
English
To display the device information
aPress QUICK to open the Quick Menu in list mode.
bPress B or b to select Device Information and press
OK.
NOTE: When music files on a USB device are used, or the TV is
used as a DMR, this feature is not available.
To display the file status information
aPress during playback. The information will be
displayed on the bottom of the screen.
bPress again to remove the information.
NOTE: The information may not be correctly displayed
depending on the content, DMC or DMS.
To close the Music Player:
aPress EXIT.
File Compatibility
See page 106.
Using the Photo Frame feature
You can use the TV screen as a digital photo frame. One image
(pre-installed or user-installed) can be displayed. Date info
can also be superimposed, if desired.
You can overwrite the photo file with a file from a USB storage
device or DLNA CERTIFIED™ Server.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select Photo Frame Setup and press
OK.
The preview screen will appear.
To open Photo Frame
Preferences
Personal TV Setup
REGZA-LINK Setup
Recording Setup
Network Device Setup
MHL Setup
Camera Sensor Setup
Network Setup
Photo Frame Setup
Photo Frame Setup
Photo Select
Photo Edit
Settings
Start
EnterOK
77
CONTROLS AND FEATURES
English
cPress c to select Start and press OK to open Photo
Frame.
To open from the Quick Menu
aPress QUICK to open the Quick Menu.
bPress B or b to select Photo Frame and press OK to
open Photo Frame.
To close Photo Frame:
aPress EXIT.
In the preview screen, you can set various settings for Photo
Frame.
Photo Select
aIn the Photo Frame Setup menu, press B or b to
select Photo Select and press OK.
bIf the device selection screen appears, press B or b to
select the appropriate device and press OK.
cPress B b C c to select the photo you want to copy
from the USB storage device or DLNA CERTIFIED™
server to the TV’s flash memory, and then press OK.
Photo Edit
aPress B or b to select Photo Edit and press OK.
bPress B or b to select Rotate or Delete.
cSet the following items as required.
•Rotate — Press OK to rotate the image
90°clockwise.
•Delete — Press OK. A confirmation window will
appear. Press C or c to select Yes, and then press
OK.
dPress BACK.
Setting the features
Photo Frame Setup
Photo Select
Photo Edit
Settings
Start
EnterOK
/Folder Sort: Title
1/54
10:00 Fri, 21 Feb 2010
1920x1080
PageOK P
QUICK FeaturesSelect
OK
Photo Edit
Rotate
Delete
Enter
78
CONTROLS AND FEATURES
English
Settings
aPress B or b to select Settings and press OK.
bPress B or b to select Clock, Position or Auto Power
Off.
cSet the following items as required.
•Clock — Press C or c to select Off, Digital Clock,
Analogue Clock or Analogue + Digital.
•Position — Press C or c to select Left or Right.
•Auto Power Off — Press C or c to select Off,
00:30, 01:00, 02:00, 04:00, 06:00 or 12:00.
If the Photo Frame window is left open, the TV will
automatically turn off after the set length of time
(maximum 12 hours).
dPress BACK.
eSelect Start and press OK.
NOTE:
• The clock display will only appear when time from a digital
broadcast is available.
• The photo and clock displays are moved by 4 dots every 5
minutes to minimize the risk of screen burn-in.
• The pre-installed photo file is stored in the TV’s flash
memory before shipment.
• Picture Size selection (Normal/ Dot by Dot) is available by
pressing the QUICK button. However when the resolution is
1920 x 1080 or above, the Picture Size selection menu will
be grayed out.
Other features
Panel Lock disables the buttons on the television. All buttons on
the remote control can still be used.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
When Panel Lock is On, a reminder will appear when the
buttons on the television are pressed. If the standby button
is pressed, the television will switch off and can only be
brought out of standby by using the remote control.
OK
Settings
Clock Off
Left
Off
Position
Auto Power Off
Enter
--/-- (---)
-- 10:10
Apr/26 (Tue)
AM 10:53
Panel Lock
Preferences
Network Setup
Network Device Setup
REGZA-LINK Setup
Network Lock
Photo Frame Setup
MHL Setup
Teletext Auto
Panel Lock Off
79
CONTROLS AND FEATURES
English
The timers
This feature will set the television to go to a specific channel at a
certain time. It can be used to view a particular programme, or by
setting the mode to daily or weekly, can be used to view a series
of programmes.
aPress MENU / Cc / B / Cc to highlight TV
Programmes / Programme Timers icons and press
OK.
bPress b to select Programme Timers and press OK.
cPress b if necessary to select an open timer position,
then press OK. The Set Timer menu will now appear
on screen.
dPress B and b to go through the list adding the
details of the programme by using the number
buttons and C and c to make selections.
eWhen all of the details have been entered, highlight
Set Timer and press OK to save the timer.
The ORANGE/RED programme timer indicator on the
front of the television will be lit (see page 101 for
details).
PLEASE NOTE: When a timed programme is about to start, an
information screen will appear offering the option of
watching or cancelling the programme. The menus and other
channels will not be available during the timed programme
unless the programme timer is cancelled.
It will only be possible to create or edit programme timers for
the currently tuned DTV input.
The feature allows you to set the television to turn on
automatically to a preset channel at a certain time of day or after
a certain length of time.
aPress MENU / Cc / B / Cc to highlight Function /
On Timer icons and press OK.
bPress B or b to select Enable On Timer and press C
or c to select On.
cPress b to select Enable DTV Clock, and then press C
or c to select On or Off.
dPress B or b to go through the list adding the details
of the On Timer by using the number buttons and C
and c to make selections.
Power On Time (only for DTV Clock On mode): Set
the time you prefer with the number buttons.
Repeat (only for DTV Clock On mode): Select the
desired On Timer operation (Once, Every Day, Mon-
Fri, Mon-Sat, Sat-Sun).
Input: Select a video input source (ATV, DTV, EXT 1,
EXT 2, EXT 3, HDMI 1, HDMI 2, HDMI 3, HDMI 4 or PC).
Channel: Set the channel that will be tuned when the
television turns on.
NOTE: When an external input is selected in the Input
field, a channel cannot be selected.
Volume: Set the volume that will be applied when
the television turns on.
Time until Power On (only for DTV Clock Off mode):
Set the amount of time from now until the TV turns on
using the number buttons (maximum of 12 hours).
ePress B or b to highlight Done and press OK.
To cancel the On Timer
aIn the On Timer menu, select Enable On Timer.
bPress C or c to select Off.
Programme Timers – digital only
Set Timer 10:50 Tue, 26 Apr
Repeat
Date
Start Time
End Time
Channel
Recording Device
Protect
Personal Grouping
—
Once
Timer Type Reminder
Off
None
Subtitle Off
—
Edit
Set Timer Delete Timer
30 CABC Channel
10:51
11:51
Tue, 26 Apr 2011
On Timer
On Timer
Enable On Timer
Enable DTV Clock
Volume
Time Until Power On
20
00:00
Done
Channel 12 ABC
Repeat Once
Input DTV
Power On Time 00:00
On
On
80
CONTROLS AND FEATURES
English
The television can be set to turn itself Off after a certain length of
time.
aPress MENU / Cc / B / Cc to highlight Function /
Sleep Timer icons and press OK.
bUse the number buttons to set the desired time. For
example, to switch the television off in one and a half
hours enter 01:30, or press c / C to increase/decrease
in steps of 10 minutes. (Maximum time setting is 12
hours)
cPress EXIT to finish.
dTo cancel the Sleep Timer, enter all zeros for the
above setting.
Energy Saving Settings
The TV will automatically turn itself off (standby) after 4 hours, if
you do not operate the TV either from the remote control or the
TV control panel.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select Energy Saving Settings and
press OK.
cPress B or b to select Automatic Power Down.
dPress C or c to select On or Off, and press OK.
NOTE:
• This feature is set to On when Location is set to Home.
• 1 minute before switching to standby, a Warning message
will appear.
• When the following features are set, the feature that is set
for the nearest time will function.
-Automatic Power Down
- Sleep Timer
- Photo Frame/Auto Power Off
- Auto shutdown after 1 hour of inactivity (after power on
by On Timer)
- No signal auto power off (after 15 minute of no signal)
The TV will automatically turn itself off after 15 minutes when no
signal is detected. You can change the setting to Off for the
following purposes:
• Low signal strength of analog channel (no signal detection)
• Only Audio L/R is connected to external input to listen to
music through the TV speakers.
aIn the Energy Saving Settings menu, press B or b to
select No Signal Power Down and press OK.
bPress B or b to select the item you want to change
and press C or c to select On or Off.
NOTE:
• Default setting is all On.
• A warning message will appear 1 minute before turning off.
Sleep Timer
Automatic Power Down
No Signal Power Down
81
CONTROLS AND FEATURES
English
Digital on-screen information
and Programme Guide
When viewing in digital mode, the on-screen
information and programme guide provide access
to programme details for all available channels.
aPress , the information screen will appear giving
details of the channel and programme currently
being viewed.
Display Example
bPress B or b to select the “Now”, “Next” or “Also”
information guide.
cTo record the next scheduled programme, select
“Next” and press OK. The Set Timer screen will
appear.
dThe details of the programme will already have been
added to the timer. Highlight Set Timer and press OK
to save.
To indicate that a Recording Timer has been set, a
clock icon will be displayed in the Next and Also fields
of the information screen. A check mark will appear if
the timer is a Reminder Timer.
ePress b to select Also. Details of programmes that
have started on other channels will be provided. Use
C or c to change the display contents.
To display More Information
aPress QUICK to open the Quick Menu.
bPress b to highlight More Information and press OK.
On-screen Information icons
Information
REC
D+
3D 2D
Change
6:00 Thu, 11 Oct
8888
ITV1 London
8888
ASTRA 19.2° E
ASTRA 19.2° E
Now
MLB Young’s two-run triple leads AL over NL
MLB Young’s two-run triple leads AL over NL
15 min left
News
8:00- 9:00
6:00- 8:00
Next
Also
HD AD 18
16:9
AD English
Side by Side
World News and Sports
USER Name 3
Set Timer
The Daily Politics
10:50 Tue, 26 Apr
Timer Type
Recording Device
Programme Tracking
Protect
—
2 CABC Channel
11:30
-
12:30 Tue, 26 Apr
Reminder
Change Time
On
Off
Off
Subtitle
Personal Grouping None
—
Edit
Set Timer Delete Timer
50
Icon Description
Service info Service type
(TV, Radio, Text)
Skip
Audio info Mono
Stereo
Dual mono
Multichannel
Dolby Digital
Dolby Digital+
HE-AAC Audio Coding
AD Audio Description
Audio/Subtitle
info For Hard of Hearing
Recording info ●REC Recording + Service
info
3D info 3D
3D→2D
2D→3D
Frame Packing
Side by Side
Top and Bottom
Personal Mode
info
Personal Mode
(Personal Name)
Event info HD, SD Video format (HD, SD)
16:9, 4:3 Video Aspect
Teletext
Subtitle (Single, Multi)
Multi-audio track
0, 4 – 18 Parental rating
Encrypted
Timer info Recording
Reminder
D
D+
82
CONTROLS AND FEATURES
English
aSelect the on-screen guide by pressing GUIDE, and
the Guide screen will appear highlighting details of
the channel and programme currently being viewed.
This may take a few moments to appear.
You can switch the time scale to 1.25 or 2.5 hours by
pressing the GREEN button.
NOTE: Channels are displayed in groups by service
type (TV, Radio, Text). Pressing the TV button will
switch the service type.
bPress C or c for information on other programmes
scheduled for the channel selected. To highlight the
first programme in the genre grid, press the RED
button.
cFor details of other programmes currently available,
press B and b to scroll up and down the channel list.
As channels are selected, details of the programme
currently being broadcast will appear. Press C or c to
view information for future programmes.
dFor information on a highlighted programme, press
.
eTo set the timer for that programme, press the BLUE
button to bring up the Programme Timers menu.
NOTE: In order for the recording operation to work
properly, the media recorder must be set to the same
time as the TV. Regarding the process for recording,
please refer to the owner’s manual of the recording
equipment.
fPress Pu to advance to the next page, or press PU to
go back to the previous page.
From the Guide screen, you can use the genre selection and
search features.
aIn the Guide screen, press QUICK.
bPress B or b to highlight Genre Colour in the Quick
Menu and press OK.
cWith the focus on a particular genre, press the desired
coloured button to assign. Four colours will be
available to set. Press BACK to go back to the Guide
screen.
dPress the YELLOW button to access the Genre
Search screen.
ePress C or c to select the genre. Programmes listed
will change for the new genre. Press B or b to
highlight a particular programme.
fWhen a current programme is selected, pressing OK
will tune to that programme. When a future
programme is selected, pressing OK will open the Set
Timer menu.
gFor information on a highlighted programme, press
.
hTo exit the Genre Search and go back to the Guide
screen, press the YELLOW button.
Guide
6 M6
11 NT1
806 ITV1
807 ITV3
808 ITV2
809 ITV4
34 AB1
804 Codec 4:3
31 PARIS PREMIERE
800 FlowerGd 6Mbs
801 FlowerGd 4Mbs
802 FlowerGd 2Mbs
9 W9
10:50 Tue, 6 Apr
Thu
6
TV
18:00 18:30 19:00 19:30 20:00
Evamag
00
MA SORCIE...
06
Nicky La...
SUMMERLAND
08
Street fight...
32
Dragon B...
59
Dragon B...
24
K 2000
48
10
LES SIM...
44
SUMMERLAND
53
LES SIM...
09
TOP MODEL
06
LES SIM...
33
HAPPY DAYS
39
HAPPY DAYS
39
21 jump street
27
Jerry Springer Show
14
City guys
54
L...
17
LES SIMPSON
09
Genre selection/searching
Genre Colour
Movies
Colour Setup
34 AB1
11 NT1
9 W9
34 AB1
11 NT1
31 PARIS PREMIERE
9 W9
11 NT1
31 PARIS PREMIERE
11 NT1
11 NT1
34 AB
31 PARIS PREMIERE
Indiana Jones and the Temple of Doom
Red Corner
The Lawnmower Man
A Vow to Kill
Parenthood
Body and Soul
The Nun’s Story
Red Corner
The Real Blonde
Critters
The jackal
Coup De Ville
Hard Rain
Wed,27 Apr 22:15- 23:55
Wed,27 Apr 0:15- 1:45
Thu,28 Apr 1:20- 3:00
Fri,29 Apr 1:30- 3:00
Sat,30 Apr 0:45- 2:40
Sat,30 Apr 1:15- 3:00
Sat,30 Apr 15:00- 17:30
Sat,30 Apr 23:20- 1:15
Sun,1 May 0:40- 2:00
Sun,1 May 0:40- 2:20
Sun,1 May 21:10- 23:20
Sun,1 May 23:20- 1:15
Mon,1 May 1:10- 3:00
Genre Search
10:50 Tue, 6 Apr
Movies
83
CONTROLS AND FEATURES
English
Digital settings – parental control
In order to prevent viewing of unsuitable films and
programmes, channels and menus can be locked
in digital mode. These can then only be accessed
with a security code PIN.
aPress MENU / Cc / B / Cc to highlight Setup /
System Setup icons and press OK.
bPress B or b to select DTV Settings and press OK.
cPress B or b to highlight Parental PIN Setup and
press OK.
dUsing the number buttons enter a four digit number.
Once entered you will be prompted to confirm by
entering again.
The PIN number is now set.
If the PIN code has been set, when Auto Tuning and
Reset TV are executed, entering the PIN will be
necessary. “0000” is not acceptable.
The Parental Control feature allows you to block programmes
according to their rating levels. If a PIN has been set, you will need
to enter it before adjusting the level.
aIn the DTV Settings menu, press B or b to select
Parental Control and press OK.
bPress B or b to select Parental Setup or Playback
Setup (if available).
Parental Setup: Select when you want to set viewing
restrictions on broadcast programmes.
Playback Setup: Select when you want to set
viewing restrictions on playback of programmes
recorded to the USB HDD.
cUse C or c to choose an option (None or an age
setting (4-17 or 4-18 depending on the Country
setting)).
To view blocked programmes, enter the PIN. To
reactivate the Parental Control, turn the TV off and
then on again.
You can use the Network Lock feature to prevent the Web
browser from launching. When this feature is set to On, PIN input
will be necessary to use YouTube.
This feature will be grayed out until a PIN is set.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or bto select Network Lock.
cPress C or c to select On.
To unlock the Network:
aSelect Off in step 3 above.
Parental PIN Setup
System Setup
Menu Language English
Country
Ant/Cable/Satellite
ATV Manual Tuning
DTV Manual Tuning
Quick Setup
DTV Settings
Germany
Auto Tuning
DTV Settings
Channels
Parental PIN Setup
Subtitle and Audio
Parental Control
Local Time Setting
DVB Character Set
Dynamic Scan
Standby Channel Update
Standard
Off
On
* * * *
New PIN:
Confirm PIN:
Parental PIN Setup
Parental Setup
Network Lock
Parental Setup
Playback Setup
None
Parental Control
Preferences
MHL Setup
Network Setup
Teletext
Network Lock
Network Device Setup
REGZA-LINK Setup
Photo Frame Setup
Auto
Panel Lock Off
Off
84
CONTROLS AND FEATURES
English
Digital settings – Channel
Options
Favourite Channels creates a list of the digital channels that
are watched most. Four lists can be created, they can be a
mixture of television, radio and text channels.
aSelect a channel you want to add to your favourite list.
bPress QUICK to open the Quick Menu.
cPress b to select Channel Options and press OK.
dPress c repeatedly to select the favourite list (Fav.1-4).
ePress OK to select the ones required. A tick will appear
in the box as they are selected.
fRepeat steps 1 through 5 for other channels.
gWhen all favourites have been selected, press EXIT.
aPress LIST to display Channel List.
bPress C or c to select Favourites 1-4. The number of
favourites available depends on how many lists have
been created.
cPress B or b to highlight a channel and press OK to
watch.
This feature allows you to set channels that will be skipped when
Pu or PU are used to tune.
aSelect the channel you want to skip in your channel
list.
bFrom the Quick Menu, press b to select Channel
Options and press OK.
cPress c repeatedly to highlight the skip (8) box.
dPress OK to select. A tick will appear in the box.
eRepeat steps 1 through 4 for other channels.
fPress EXIT.
NOTE: Skipped channels cannot be selected by Pu or
PU but still be accessed by direct number entry
(when tuned a 8 icon will be displayed in the
banner to indicate as a skipped channel).
Locking Channels stops the viewing of digital channels, and
they can only be accessed by entering the PIN.
aSelect the channel you want to lock in your channel
list.
bFrom the Quick Menu, press b to select Channel
Options and press OK.
cPress c repeatedly to highlight the lock ( ) box.
dPress OK to select. A tick will appear in the box.
If a PIN has already been set, PIN entry will be required
to set the locked channels.
eRepeat steps 1 through 4 for other channels.
fPress EXIT.
gFrom this point on, when any of the channels in the
Locked Channel list are selected, the PIN must be
entered before they can be accessed.
Selecting favourite channels
Favourite Channel Lists
Fav.
Channel Options
1234
Channel List
Favourites 1
6 M6
9 W9
11 NT1
31 PARIS PREMIERE
34 AB1
51 ITV1
Skip channels
Locking channels
85
CONTROLS AND FEATURES
English
Digital settings – other settings
In digital mode, this feature will show subtitles on the screen in
the selected language provided they are being broadcast.
aIn the DTV Settings menu, press B or b to select
Subtitle and Audio and press OK.
bPress b to select Subtitle Display and use C or c to
select On or Off.
cPress B or b to select Primary Subtitle Language or
Secondary Subtitle Language and press C or c to
select an option.
The SUBTITLE button can be used to select subtitle on or off
for the current channel only and to select the subtitle
language if more than one subtitle is available.
This feature allows a programme or film to be viewed with a
choice of soundtrack language, provided multiple language
tracks are being broadcast.
aIn the Subtitle and Audio menu, press B or b to
select Audio Type and press C or c to select Normal
or For Hard of Hearing.
bPress B or b to select Primary Audio Language or
Secondary Audio Language and press C or c to
select an option.
If more than one soundtrack is available, use the s
button to select between them.
The Common Interface Slot, situated on the side of the television,
enables the insertion of a CAM (Conditional Access Module) and
card. These are purchased from a service provider and allow
additional subscription broadcasts to be viewed. For
information, see a service provider.
aInsert the CAM and card into the Common Interface
Slot, following the instructions provided with the
CAM. A box will appear on screen to confirm that the
CAM has been inserted.
bPress MENU / Cc / B / Cc to highlight Setup /
System Setup icons and press OK.
cPress B or b to select DTV Settings and press OK.
dPress B or b to select Common Interface and press
OK.
eDetails of the CAM should now be available.
NOTE:
• Software update of a CI Plus CAM may occur automatically
if instigated by the broadcaster. This could cause the
cancellation of any Reminders/Recordings during this
process.
• Some CI or CI+ CAM may not be supported.
• CI+ operation is not guaranteed except for Canal Ready DTT
services on suffix FC models.
Subtitles
Audio languages
Subtitle and Audio
Subtitle Type
Secondary Subtitle Language
Primary Subtitle Language
Audio Type
Primary Audio Language
Secondary Audio Language English
English
English
Normal
English
Normal
Subtitle Display Off
Common Interface
86
CONTROLS AND FEATURES
English
Software Upgrade and Licences
When Auto Upgrade is set to On, the television will
automatically upgrade while in standby if new software is
available.
aIn the System Setup menu, press B or b to select
Software Upgrade and press OK.
bPress B or b to select Over-the-air Upgrade and
press OK.
cPress B or b to select Auto Upgrade.
dUse C or c to select On or Off.
If preferred, software upgrades can be searched for manually
using Search for New Software.
aIn the System Setup menu, press B or b to select
Software Upgrade and press OK.
bPress B or b to select Over-the-air Upgrade and
press OK.
cPress B or b to select Search for New Software.
dPress OK. The television will automatically start
searching for a software upgrade, the progress bar
will move along the line.
If an upgrade is found, the television will
automatically start downloading. If not, a screen will
appear stating that an upgrade is unavailable.
TOSHIBA may offer upgrades for the TV’s software in the future.
The TV’s software is upgraded via the Network.
Before downloading software:
Configure your TV to connect to the Internet.
NOTE: While the upgrade is being performed, you will not be
able to watch the TV.
aIn the System Setup menu, press B or b to select
Software Upgrade and press OK.
bPress B or b to select Network Upgrade and press
OK.
NOTE: If the network is not available, a warning
message will appear.
cThe TV software upgrade will start when download
succeeds.
The licences for the software used in this television are available
for viewing.
aIn the System Setup menu, press B or b to select
Software Licences and press OK.
A screen will appear displaying all the licensing
information required for the televisions software.
Auto Upgrade
Searching for New Software
SEARCHING FOR NEW SOFTWARE
Searching for a new software upgrade for this TV.
Searching
Network Upgrade
Software Licences
87
CONTROLS AND FEATURES
English
System Information and Reset TV
This feature can be used to check the version of software
currently installed. When in DTV mode, it includes additional
diagnostic information such as signal strength, signal quality,
centre frequency, modulation, etc.
aIn the System Setup menu, press B or b to select
System Information.
bPress OK to display the System Information.
cFor information about the signal quality of a particular
multiplex, press B or b to select that multiplex.
dPress OK for a screen showing detailed technical
information about the selected multiplex.
Selecting Reset TV will reset all TV settings, including saved
channels, to their original factory values.
aIn the System Setup menu, press B or b to select
Reset TV.
bPress OK to select. A screen will appear warning that
all settings will be lost. Press OK to continue.
When the set powers back on, the Quick Setup
screen will appear. Press OK to advance the setup and
perform an auto tune. (See “Quick Setup” section on
page 20.)
PC Settings
Connect the PC (as shown in the ‘Connecting a computer’
section) and ensure that a picture is showing on the television
screen. The picture position may now be adjusted to suit
personal preference.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select Display Settings and press OK.
cPress B or b to select PC Settings and press OK.
dPress B or b to select an option and press C or c to
adjust the settings.
The Clock Phase matches the PC signal with the LCD display.
Adjusting this can clear horizontal stripes and picture blur.
aIn the Display Settings menu, press B or b to select
PC Settings and press OK.
bPress B or b to select Clock Phase.
cPress C or c to adjust until the picture clears.
System Information
Reset TV
System Information
2011
2.1.26.0 Feb 19 2011 - 15:56:50 FW:13
WEAK
Ch25 GOOD
AVERAGE STRONG
TOSHIBA
Horizontal and Vertical Position
Clock Phase
Auto Format On
4:3 Stretch Off
Picture Position
PC Settings
Display Settings
0
0
0
0
PC Settings
Horizontal Position
Reset
Sampling Clock
Vertical Position
Clock Phase
88
CONTROLS AND FEATURES
English
Adjusting the Sampling Clock alters the number of pulses per
scan, this will clear vertical lines on the screen.
aIn the Display Settings menu, press B or b to select
PC Settings and press OK.
bPress B or b to select Sampling Clock.
cPress C or c to adjust until the picture clears.
Use Reset to return all items to the original factory settings.
aIn the Display Settings menu, press B or b to select
PC Settings and press OK.
bPress B or b to select Reset and press OK.
NOTE: When a PC is connected using HDMI, none of these
functions will be available.
The screen is disrupted momentarily when adjusting PC
Settings. This is not a sign of malfunction.
The default settings and adjustment ranges may vary
depending on the input signal format.
Input selection and AV
connections
See page 12 for a detailed image showing
recommended connections.
Most media recorders and decoders send a signal through the
SCART lead to switch the television to the correct Input socket.
Alternatively, press the external source selection button o
until the picture from connected equipment is shown.
Use the Input Selection window if the television does not switch
over automatically.
aBy pressing o on the remote control or TV, a list will
appear on screen showing all inputs and external
equipment.
HDMI® displays equipment connected to Input HDMI
on the back or side of the television.
PC displays a computer connected to Input RGB/PC on
the back of the television.
Sampling Clock
Reset Input selection
Pressing o on the
remote control
Pressing o on the TV
* If radio or text channels
are currently available
for DTV.
Inputs
TV
1
2
3
HDMI 2
HDMI 1
PC
HDMI 3
HDMI 4
Inputs
DTV Sat TV *
DTV Sat Radio *
DTV Sat Text *
DTV Ant (or Cable) TV *
DTV Ant (or Cable) Radio *
DTV Ant (or Cable) Text *
1
2
3
HDMI 3
HDMI 2
ATV
HDMI 4
PC
HDMI 1
89
CONTROLS AND FEATURES
English
This feature is designed to make input selection more convenient
by allowing you to skip unused inputs.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select AV Connection.
cPress OK to display the AV Connection menu.
dPress B or b to highlight Input Labeling and press
OK.
ePress B or b to select the input you want to skip, and
then press the RED button to turn on the skip.
fTo turn off the skip, press the RED button again.
The input set to Skip is grayed out in the Input
Selection window and is skipped over when you press
o on the remote control.
These input labels are shown in the input selector. You can label
video inputs according to the devices you have connected to the
TV.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select AV Connection and press OK.
cPress B or b to select Input Labeling and press OK.
dPress B or b to highlight the item you want to label,
and then press C or c to select --, Amplifier, Cable,
DVD, Game, PC, Recorder, Satellite or VCR, or press
the GREEN button to select User Input.
NOTE: When User Input is selected by pressing the
GREEN button, the Software Keyboard window will
appear. Input the desired characters (10 characters or
less) by using the Software Keyboard (see page 53)
or using the number buttons for a number input. To
save your settings, press the BLUE button.
eRepeat step 4 for other video inputs.
External input skip
Preferences
Network Setup
Network Device Setup
Display Settings
Network Lock
AV Connection
Photo Frame Setup
Teletext Auto
Panel Lock Off
AV Connection
Input Labeling
PC/HDMI 3 Audio PC
Side Shared Audio EXT 2
HDMI 3 Audio Digital
HDMI Settings
Digital Audio Output
Input Label
--
--
--
--
--
--
--
--
Input Labeling
EXT 1
EXT 2
EXT 3
HDMI 1
HDMI 2
HDMI 3
HDMI 4
PC
Labeling video input sources
Input Label
--
--
--
--
--
--
--
--
Input Labeling
EXT 1
EXT 2
EXT 3
HDMI 1
HDMI 2
HDMI 3
HDMI 4
PC
90
CONTROLS AND FEATURES
English
In order to receive sound from a connected PC, plug the audio
cable into the back of the television (as shown in the ‘Connecting
a computer’ section), and then use the PC/HDMI 3 Audio
setting.
aIn the Preferences menu, press B or b to select AV
Connection and press OK.
bPress B or b to select PC/HDMI 3 Audio and press C
or c to select the PC option.
NOTE: Selecting the PC option will force HDMI 3
Audio to Digital mode.
The AUDIO terminals for the COMPONENT VIDEO INPUT (EXT 2)
and VIDEO INPUT (EXT 3) are shared.
Select an appropriate option (EXT 2 or EXT 3) for the input that
you are using.
aIn the Preferences menu, press B or b to select AV
Connection and press OK.
bPress B or b to highlight Side Shared Audio, and
then press C or c to select EXT 2 or EXT 3.
If the connected HDMI source does not support digital audio,
plug the audio cable into PC/HDMI 3 (AUDIO) on the back of
the television (as shown in the ‘Connecting an HDMI® or DVI
device to the HDMI input’ section on page 13), then use the
HDMI 3 Audio setting.
aIn the Preferences menu, press B or b to select AV
Connection and press OK.
bPress B or b to select HDMI 3 Audio and press C or
c to select Auto or Analogue.
If the sound is absent, try selecting a different setting.
NOTE: HDMI 3 supports digital and analogue sound,
HDMI 1, HDMI 2 and HDMI 4 are digital sound only.
Certain DVD disk formats may not output from this TV
(32/44.1/48kHz and 16/20/24 bits are acceptable).
Some early HDMI equipment may not work properly with your
HDMI TV. Please try setting the Enable Content Type and
INSTAPORT™ options to Off. Adjusting these settings should
allow your early HDMI source to operate properly with your
television.
aIn the Preferences menu, press B or b to select AV
Connection and press OK.
bPress B or b to select HDMI Settings and press OK.
NOTE: HDMI Settings is grayed out on non-HDMI
inputs.
cPress B or b to select an item and press C or c to
select a setting.
• Enable Content Type: On
This feature is part of the HDMI standard.
When set to On, the TV will automatically adjust
settings according to the content type data sent
from the connected HDMI device.
• INSTAPORT™: On
This feature reduces the lag time when switching
HDMI sources.
•RGB Range: Auto
This feature adjusts RGB full range signal
automatically. When Limited is selected, RGB signal
is output in the range from 16 to 235. When Full is
selected, RGB signal is output in the range from 0 to
255.
NOTE:
• If your HDMI connection is capable of 1080p and/or your
television is capable of refresh rates greater than 50Hz or
supports Deep Colour, you will need a Category 2 cable.
Conventional HDMI/DVI cables may not work properly with
this mode.
• All of the above HDMI settings need proper HDMI source
devices.
If the HDMI source products do not support these features,
the television may not work properly by activating these
features.
When connecting a surround sound amplifier to the digital audio
output (Sony/Philips Digital Interface Format [S/PDIF]), the
following options can be selected or adjusted.
aIn the Preferences menu, press B or b to select AV
Connection and press OK.
PC Audio
Side Shared Audio
HDMI 3 Audio
AV Connection
Input Labeling
PC/HDMI 3 Audio PC
Side Shared Audio EXT 2
HDMI 3 Audio Auto
HDMI Settings
Digital Audio Output
HDMI Settings
Digital Audio Output
HDMI Settings
Enable Content Type
INSTAPORTTM
On
On
RGB Range Auto
91
CONTROLS AND FEATURES
English
bPress B or b to select Digital Audio Output.
cPress OK to display Digital Audio Output menu and
press B or b to select an option.
Audio Format:
Press C or c to select PCM or Auto.
PCM: This mode outputs PCM format to the digital
audio output socket.
Auto: This mode outputs Dolby Digital (if available)
or PCM to the digital audio output socket.
Dolby Digital S Dolby Digital
Dolby Digital Plus S Dolby Digital
MPEG S PCM
HE-AAC S Dolby Digital
Audio Delay:
Press C or c to select Auto or Manual.
Auto: This mode automatically adjusts the audio
timing to meet the video timing.
NOTE: The time lag might be large between
the image and sound depending on the
connected equipment (amplifier etc.). In that
case, select Manual.
Manual:You can manually adjust the audio signal
timing to meet the video signal timing.
Delay Adjustment:
Press C or c to adjust the audio signal timing
(0 – 250ms) to meet the video signal timing.
NOTE:
• This feature is grayed out when Audio Delay is in
Auto.
• A time lag will occur when the video signal or audio
signal is changed. Adjust the timing accordingly.
• When adjusting the timing, turn down the volume
of the AV equipment used as far as possible.
Depending on the equipment, noise etc. may occur
when the signal is changed.
• Depending on the connected equipment (amplifier,
etc.), adjustment may not be possible.
• When the optical digital output setting (AutotPCM)
is changed, it may be necessary to adjust the timing
again.
• Do not use other than for audio output from the AV
amplifier, etc. (Malfunction may occur)
Using Personal TV Mode
You can customize some TV functions as desired
and those settings can be saved in one of 4
Personal Modes (A to D). The Personal Mode can
be selected from the Quick Menu (manual
switching), or when individual Facial Recognition
is performed with the camera, at the Welcome
Window, press the coloured button corresponding
to each Personal Mode.
Manual Switching
aPress QUICK to open the Quick Menu.
bPress B or b to select Personal Mode and press OK.
cPress Bb or corresponding coloured button to select
individual Personal Mode from Normal, Personal
Mode A, Personal Mode B, Personal Mode C and
Personal Mode D. The mode will default to Normal
every the TV is turned off and on.
NOTE: If the Personal PIN has been set, the Lock icon
will be displayed. If the Personal PIN entry screen is
displayed, enter the correct Personal PIN.
Facial Recognition
After registering faces beforehand for each Personal Mode,
the Welcome Window will be displayed when the camera
detects a corresponding face. The Personal Name
corresponding to the detected face will be displayed in the
Welcome Window.
Change Personal Modes by pressing the corresponding
Coloured button while the Welcome Window is being
displayed. Switch at this time to the Personal Mode
corresponding to the Coloured button that was pressed, even
if it is the Coloured button for a Personal Mode that
corresponds to a face other than the one recognized.
NOTE: If the Personal PIN has been set, the Personal PIN entry
screen will be displayed. Enter the correct Personal PIN.
AV Connection
Input Labeling
PC/HDMI 3 Audio PC
Side Shared Audio EXT 2
HDMI 3 Audio Auto
HDMI Settings
Digital Audio Output
Normal
Personal Mode B
Personal Mode C
Personal Mode D
Personal Mode A
Personal Mode
BACK Return
Mr. AAAAA aaaaa
Welcome!
Personal Mode
92
CONTROLS AND FEATURES
English
Personal TV Setup
aPress MENU / C c / B / C c to highlight Setup /
Preferences icons and press OK.
bPress B or b to select Personal TV Setup and press
OK.
cPress B or b (or corresponding coloured button) to
select the individual Personal Mode and press OK.
Facial Recognition
Press B or b to select Facial Recognition and press C or c
to select On or Off to activate or deactivate this function.
My Face
My face is the facial registration necessary for performing
Facial Recognition.
aPress B or b to select My Face and press OK.
The My Face screen will appear.
bDisplay the video image currently being taken by the
camera. If a face is detected, the camera sensor will
place a focus around that face. When a face is
detected within the “OK to register” frame on the My
Face screen, press OK to register.
NOTE:
• It will be impossible to register a face if there are multiple
faces detected inside of the video image.
• It will be impossible to register a face if there is no face
detected inside of the video image.
• It will be impossible to register a face if the face was already
registered for another personal mode.
• It will be impossible to register a face if the TV is recording
status. At this time, the video from camera cannot be
displayed.
•If the above Facial Recognition is Off, My Face will be
grayed out.
• If you have already registered 10 faces, a new face cannot be
registered.
Registered Faces
This feature is to confirm a face that has already been
registered.
aPress B or b to select Registered Faces and press
OK.
The Registered Faces screen will appear.
bPress B b C c to select each registered face.
cPress the RED button if you want to delete the face.
dPress C or c to select Yes in the confirmation window
and press OK.
NOTE: When the Reset TV is executed, all registered
faces will be reset.
Edit Name
You can edit the name of your Personal Mode.
Press B or b to select Edit Name and press OK.
Edit the desired name by using the software keyboard (see
page 53). The maximum number of characters is 25.
Personal PIN Setup
Press B or b to select Personal PIN Setup and press OK.
Enter your personal PIN in same manner as “Parental PIN
Setup” on page 83.
Personal Mode B
Personal Mode C
Personal Mode D
Personal Mode A
Personal TV Setup
Personal TV Setup
Personal Mode A
Facial Recognition
Personal PIN Setup
My Face
Registered Faces
Edit Name
Preset Volume
Preset
On
30
Volume Type
Display Example
My Face
Are you sure you want to register?
Edit
Yes
OK Enter
93
CONTROLS AND FEATURES
English
Volume Type
Press B or b to select Volume Type and press C or c to
select Preset or Last.
Last — The last volume level in your Personal Mode.
Preset — The Preset volume level is selected whenever the
Personal Mode is switched.
Preset Volume
Press B or b to select Preset Volume and press B or b to
adjust your desired volume level. When the Volume Type is
set to Last, this feature will be grayed out.
Behaviour in Personal Mode
• Personal Favourite Channel List (Fav5 -Fav8):
Normal Mode: Fav1 / Fav2 / Fav3 / Fav4
Personal Mode A:Fav5
Personal Mode B:Fav6
Personal Mode C:Fav7
Personal Mode D:Fav8
Press the LIST button to display Channel List and press C or
c to select All or your Personal Mode (Fav5 – Fav8)
• Personal Picture Mode:
The Picture Mode you selected is stored in your Personal
Mode.
• Personal Volume:
The sound volume you set is stored in your Personal Mode.
Personal Grouping of Recorded Programmes
When switching between Personal Modes, recordings (OTR,
TimeShift, Timer Recording) will be displayed categorically in
the Library by Personal Mode.
Programmes recorded in Personal Mode A/B/C/D with OTR or
TimeShift will be saved remembering the Personal Grouping
corresponding to each respective mode.
When user performs a Timer Recording while in Personal
Mode A/B/C/D, after the transition to Set Timer, make the
Default for Personal Grouping (a Set Timer setting item) be a
selection item corresponding to whatever mode you are in.
When you perform OTR, TimeShift, or Timer Recording while
in Normal Mode, the Personal Grouping for recorded
programmes will be remembered as “None.”
Using REGZA-LINK
This is a new feature that uses CEC technology and
allows you to control Toshiba REGZA-LINK
compatible devices from the television remote
control via HDMI connection (page 14).
When the Enable REGZA-LINK item in the REGZA-LINK
Setup menu is set to On, individual functions also set to On
will be activated.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select REGZA-LINK Setup and press
OK.
cPress b to select Enable REGZA-LINK and press C or
c to select On.
NOTE: If you set Enable REGZA-LINK to Off, all other
items will be grayed out.
The TV Auto Power setting allows the television to be
automatically switched on if a REGZA-LINK device is turned on.
aIn the REGZA-LINK Setup menu, press b to highlight
TV Auto Power.
bPress C or c to select On or Off.
Enable REGZA-LINK
TV Auto Power
REGZA-LINK Setup
Enable REGZA-LINK On
TV Auto Power
Position Key Pass Through
On
Auto Standby On
Initial Speaker Setting TV Speakers
Amplifier Control On
94
CONTROLS AND FEATURES
English
When Auto Standby is enabled, the television, when switched
off, will automatically switch off (standby mode) all connected
REGZA-LINK equipment.
aIn the REGZA-LINK Setup menu, press b to highlight
Auto Standby.
bPress C or c to select On or Off.
When Amplifier Control is set to On, it allows the “Initial
Speaker Setting” feature to become available.
aIn the REGZA-LINK Setup menu, press b to highlight
Amplifier Control.
bPress C or c to select On or Off.
This feature allows the audio output preference to be set to the
TV speakers or AV amplifier speakers. The AV Amplifier option lets
the television’s remote control adjust or mute the volume of the
audio.
aIn the REGZA-LINK Setup menu, press b to highlight
Initial Speaker Setting.
bPress C or c to select TV Speakers or Amplifier.
When Position Key Pass Through for the selected HDMI input
mode is set to On, the PU Pu and number (0-9) keys on the
remote control will pass through. When in Off, those operate as
TV programme selection keys.
aIn the REGZA-LINK Setup menu, press b to highlight
Position Key Pass Through and press OK.
bPress B or b to select the appropriate HDMI mode.
cPress C or c to select On.
If a REGZA-LINK device with HDMI switching capability (e.g. AV
amplifier) is connected to the HDMI input, you can select another
REGZA-LINK device that is connected to the master HDMI device
on the input source list.
aPress o and a list will appear on screen showing
available input sources.
bPress b to select the desired input source with
REGZA-LINK icon.
cPress c and a second selection screen will appear
showing all connected REGZA-LINK equipment.
dPress B or b to select the desired input source, and
then press OK.
NOTE:
• These functions depend on the device connected.
• If you select the REGZA-LINK input source from the popup
window, some REGZA-LINK devices may automatically turn
on.
• When the television is switched on it will take a few minutes
for the REGZA-LINK icon to appear in the list. When an HDMI
cable is removed, it will take a few minutes for the icon to
disappear.
• If the HDMI cable from connected equipment is changed,
Enable REGZA-LINK in the REGZA-LINK Setup menu may
need to be reset to On.
• If you change the HDMI lead to a connected device or
change an HDMI device setting, reset the Enable REGZA-
LINK item on the REGZA-LINK Setup menu from Off to On.
Auto Standby
Amplifier Control
Initial Speaker Setting
Position Key Pass Through
REGZA-LINK input source selection
Inputs
TV
1
2
3
HDMI 2
HDMI 1
PC
HDMI 3
HDMI 4
1 DVD
2 VCR/DVR
3 CBL/SAT
4 GAME/TV
5 AUX
REGZA-LINK
95
CONTROLS AND FEATURES
English
With the REGZA-LINK mode on your television’s remote
control, you can control the connected REGZA-LINK device
you are watching.
To control the REGZA-LINK input source first select the
equipment by REGZA-LINK input source selection.
aPress QUICK to open the Quick Menu.
bPress B or b to select REGZA-LINK Device Control
and press OK.
cPress B or b to select a control option and press OK.
NOTE: The available functions depend on the equipment
connected. Please refer to the operation manual for each
piece of equipment connected.
When connected equipment is switched on, REGZA-LINK will
automatically detect the television through the input
selection. If the television is in standby, it will be switched on
automatically.
These functions can be enabled or disabled from the REGZA-
LINK Setup (see page 93).
NOTE:
• Even if the equipment is showing a menu, the television
may automatically show the input source.
• This feature depends on the connected equipment and
television state.
If the television is turned off (standby mode), the television
will send a message to turn off (standby mode) all of the
REGZA-LINK devices connected to the television.
These functions can be enabled or disabled from the REGZA-
LINK Setup (see page 93).
NOTE: This feature depends on the connected equipment
and television state.
With your television’s remote control, you can adjust or mute the
sound volume of the speakers connected to the television via an
AV amplifier.
aSet the Initial Speaker Setting to Amplifier in the
REGZA-LINK Setup menu.
bConfirm that a connected REGZA-LINK device (such as
a DVD player, etc) is selected for the AV amplifier input
source.
NOTE:
• These functions depend on the device connected.
• When you turn on the AV amplifier, change its input source,
or adjust the sound volume, the sound will be output from
the AV amplifier’s speakers even if TV Speakers has been
selected. Turn the television off and on again to output the
sound from the TV Speakers.
• This feature may not work if the AV amplifier is operated.
This feature automatically adjusts the suitable widescreen
formats and picture preferences when connected to a
Toshiba PC compatible with REGZA-LINK.
NOTE: This feature depends on the connected equipment
state.
REGZA-LINK Device Control
REGZA-LINK one touch play
REGZA-LINK system standby
Root Menu
Recorder
REGAZA
-
LINK Device Control
Eject
Power
Contents Menu
Setup Menu
Top Menu
DVD Menu
Audio
REGZA-LINK system audio control
Toshiba PC compatible with REGZA-LINK
96
CONTROLS AND FEATURES
English
Using MHL TV function
You can use the following functions by connecting
between the TV HDMI 4 port and an USB port of
mobile phones etc. with a MHL cable.
• Charge with mobile phone from TV
• Two-way remote operation between TV and mobile phone
• Video/Audio output from mobile phone
NOTE: These functions may not be available depending on
the connected equipment.
Connect the device to the HDMI 4 port on the TV using an MHL
cable (not supplied).
• When you connect an MHL-compatible device to the HDMI
4 port on the TV with the MHL cable, charging starts
automatically.
NOTE: Do not connect an MHL-compatible device to any port
other than the HDMI 4 port.
When an MHL-compatible device is connected to the HDMI 4
port on the TV, input automatically switches to the HDMI 4
port.
Operate the device using the remote controller for the TV.
To display photos, select the photos using BbCc and
press OK. To play a video, press
c
(play).
Depending on the connected MHL-compatible device, it may
be possible to perform operations from the device.
Select whether or not input automatically switches to the HDMI
4 port when an MHL-compatible device is connected.
aPress MENU / Cc to highlight Setup icon.
bPress B / Cc to highlight Preferences icon and
press OK.
cPress B or b to select MHL Setup and press OK.
dPress C or c to select On or Off.
Connecting an MHL-compatible Device
Operating an MHL-compatible Device
MHL Setup
HDMI 4
MHL cable (not supplied)
97
English
TEXT SERVICES
Text services
This television has a multi-page text memory,
which takes a few moments to load. It offers two
Modes of viewing text – Auto will display Fastext,
if available. List will save your four favourite pages.
The text character set will be automatically chosen by the
language setting in the Setup menu.
aPress MENU / Cc / B / Cc to highlight Setup /
Preferences icons and press OK.
bPress B or b to select Teletext, and then press C or
c to select Auto or List.
The TEXT button:
To view text services press TEXT. Press again to superimpose
the text over a normal broadcast picture and again to return
to normal viewing. Channels cannot be changed until text is
cancelled.
The first text page shown will be the initial page.
Any text page can be accessed by entering the 3 digit page
number using the numbered buttons, pressing the coloured
buttons or pressing PU to advance to the next page and Pu
to go back to the previous page.
Sub-pages
The pages on the screen will dynamically update as sub-
pages are received.
If you open a page containing sub-pages, the sub-pages are
automatically displayed in sequence. To quit automatic sub-
page change, press C or c.
Once selected, the sub-page you are viewing will be
highlighted and, as the television loads any additional sub-
pages, the colour of the numbers will change, indicating that
these pages have been loaded.
These sub-pages will remain available to view until another
page is chosen or, in normal TV mode, the channel is changed.
If Fastext is available, four coloured titles will appear at the
base of the screen.
To access one of the four given subjects, press the relevant
coloured button on the remote control.
For further information on your particular text system(s), see
the broadcast text index page or consult your local Toshiba
dealer.
The four coloured choices at the bottom of the screen are
numbers – 100, 200, 300 and 400, which have been
programmed into the television’s memory. To view these
pages, press the relevant coloured buttons.
To change these saved pages, press the relevant coloured
button and enter the 3 digit number. This number will change
in the top left of the screen and in the coloured highlight.
Press OK to save. Whenever OK is pressed, all four page
numbers showing at the bottom will be saved and the
previous ones will be lost.
If OK is not pressed, the selection will be forgotten when the
channel is changed.
Other pages may be viewed by entering the 3 digit page
number – but DO NOT press OK or these pages will be saved.
Selecting modes
Text information
Preferences
MHL Setup
Network Setup
Teletext
Network Device Setup
REGZA-LINK Setup
Photo Frame Setup
Network Lock
Panel Lock Off
Teletext Auto
Navigating pages using Auto
Navigating pages using LIST
98
TEXT SERVICES
English
Below is a guide to the functions of the remote control text
buttons.
k To display the index/initial page:
Press k to access the index/initial page. The one displayed is
dependant on the broadcaster.
TEXT To display a page of text:
Press TEXT to display text. Press again to superimpose text
over a normal picture. Press again to return to normal
television viewing. Channels cannot be changed until this has
been done.
A To reveal concealed text:
To discover the solutions on quiz and joke pages press the A
button.
B To hold a wanted page:
At times it is convenient to hold a page of text. Press B and
B will appear in the top left of the screen. The page will be
held on screen until the button is pressed again.
C To enlarge the text display size:
Press C once to enlarge the top half of the page, press again
to enlarge the bottom half of the page. Press again to revert
to normal size.
D To select a page whilst viewing normal
picture:
Enter the page number then press D, normal picture
will be displayed. The television will indicate when the page is
ready by changing the colour of the page number at the top
of the screen. Press TEXT to view the page.
To display news flashes:
Select the news flash page for the chosen text service (see the
index page of text service). The news flashes will be displayed
as and when they are broadcast.
Control buttons
Remember to cancel text before
changing channels - press the TEXT
button twice.
99
English
PROBLEM SOLVING
Questions and Answers
Below are the answers to some of the most
common queries.
To check that you have the best colour:
aWith the external source playing, select Colour
System from the System Setup menu.
bWith C or c choose between Auto, PAL, SECAM,
NTSC 4.43 or NTSC 3.58.
aSelect the ATV Manual Tuning menu. Highlight the
station and press OK. Then press c to select Manual
Fine Tuning.
bUsing B or b adjust to get the best picture and
sound. Press OK and then EXIT.
QWhy is there no sound or picture?
ACheck the television is not in standby mode. Check
the mains plug and all mains connections.
QThere is a picture, but why is there little or no
colour?
AWhen using an external source, for instance, a poor
quality video tape, if there is little or no colour,
improvements may sometimes be achieved. The
colour is factory set to Auto to automatically display
the best colour system.
QWhy doesn’t the video/DVD being played show
on screen?
AMake sure the media recorder or DVD player is
connected to the television as shown on page 12,
and then select the correct input by pressing o.
QWhy is there a picture but no sound?
ACheck all lead connections.
No sound or unacceptable format sound may be
received.
Check the volume has not been turned down or that
sound mute has not been selected.
Check shared audio settings.
System Setup
Country Germany
Colour System Auto
Menu Language English
QWhat else can cause a poor picture?
AInterference or a weak signal. Try a different
television station. Manual Fine Tuning may help.
QWhy don’t the controls of the television work?
ACheck that Panel Lock is not On.
QWhy doesn’t the remote control work?
ACheck that the batteries aren’t dead or inserted
incorrectly.
QWhy is the digital channel locked?
AThe channel has been locked in Channel Options
(see ’Digital settings – Channel Options’ section).
QWhy are some of the digital subscription channels
unavailable?
AYour subscription needs upgrading. Contact your
service provider.
QWhy is the soundtrack in English when a different
audio language has been selected?
AThe programme is currently being broadcast with an
English soundtrack only.
QWhy is there incorrect or no sound when in DTV
mode?
APress s to ensure the hard of hearing option has
not been selected.
ATV Manual Tuning
Manual Fine Tuning
1 A C 9
0 I
100
PROBLEM SOLVING
English
aSet the Colour to Auto and exit.
bGo to the Picture menu and adjust the tint.
QWhat is DVB-T?
ADigital Video Broadcast via an aerial/antenna.
QWhat is DVB-C?
ADigital Video Broadcast via a cable connection.
QHow are radio channels selected?
APress TV on the remote control and select DTV
Radio. Alternatively select from the GUIDE.
QWhat can be done if the PIN number has been
forgotten?
AUse the Master PIN code of 1276, then change to a
number of your choice. Select Parental PIN Setup
from the DTV Settings menu to enter PIN. Ensure
that no-one else can use the Master PIN by removing
the Owner’s Manual.
QWhy are there vertical stripes on the screen when
in PC mode?
AThe Sampling Clock may need adjustment. Select PC
Settings from the Display Settings menu, highlight
Sampling Clock and adjust until the lines clear.
QWhy are there horizontal stripes and/or blurred
images on the screen when in PC mode?
AThe Clock Phase may need adjustment. Select PC
Settings from the Display Settings menu, highlight
Clock Phase and adjust until the picture clears.
QWhy when digital subtitles have been selected are
they not showing on screen?
ASubtitles are not currently being transmitted by the
broadcaster.
QWhy are there problems with analogue text?
AGood performance of text depends on a good strong
broadcast signal. This normally requires a roof or loft
aerial. If the text is unreadable or garbled, check the
aerial. Go to the main index page of the text service
and look for the User Guide. This will explain the basic
operation of text in some detail. If further information
is needed on how to use text see the text section.
QWhy is a page number visible at the top of the
screen but no text?
AText has been selected but Teletext information is
currently unavailable on the current source.
QWhy are the colours wrong when an NTSC source
is played?
AConnect the source via a SCART lead and play.
Select Colour System from the System Setup menu.
QWhy don’t the devices connected via HDMI
operate properly?
AMake sure to use cables with the HDMI logo
(see page 13).
Some early HDMI equipment may not work properly
with the latest HDMI TV products, due to new
standard adoption. Try switching the HDMI settings
(Enable Content Type and INSTAPORT™) to Off.
QWhy don’t the devices connected via MHL operate
properly?
ATurn off your TV and unplug the power cord, and then
plug and turn on again.
Turn the MHL Source Power Off and On again.
QWhy don’t the REGZA-LINK devices work?
AWhen the connected REGZA-LINK device does not
work correctly after you have changed the settings of
the device, turn off your television and unplug the
power cord, and then plug and turn on again.
Unplug the HDMI cable of the REGZA-LINK device
and lead again.
QWhy is the REGZA-LINK logo still showing when
the equipment has been disconnected?
AIf the REGZA-LINK device is disconnected, the logo
will disappear after approximately one minute.
QWhy don’t the networked devices work?
AThe LAN cables are not connected properly or at all.
Connect all cables (see page 16).
Make sure your network address is set up correctly
(see page 51).
101
PROBLEM SOLVING
English
Other problems
If your TV’s problem is not addressed in this Questions and
Answers section or the recommended solution has not
worked, do one of the following:
1Turn off your TV. After 30 seconds, turn it on.
2Turn off the TV and unplug the power cord. After
1 minute, plug the power cord in and turn on the TV.
3Perform the Reset Factory Defaults procedure (see
page 87).
QWhy doesn’t the Media Player feature operate?
AMake sure that devices are connected correctly.
Incorrect behaviour may occur with a USB Hub
connection.
Check your network setup if using DLNA CERTIFIED™
Server.
QWhy are not 3D images displayed?
AEnsure that there is no object blocking the infrared
signals in the infrared reception part of television and
3D glasses.
If the infrared data communication between the
television and 3D glasses is lost for 5 minutes, the
power of 3D glasses is turned off.
QWhy doesn’t the power of 3D glasses turn on?
ACharge the battery.
QWhy doesn’t the USB HDD work?
ARegister your USB HDD.
Use the USB 2 port to connect the USB HDD.
Your country/area may not support the USB HDD
function.
QWhat do the LEDs on the front of the television
indicate?
ACheck the table below.
LED 2 LED 1
LED indication Condition Solution
LED-1 LED-2
Blue Orange Power ON
Programme Timer is set
Both Programme Timer
(Recording) and Recording are
NOT working
–
Blue Red Power ON
Programme Timer (Recording)
or Recording is working
–
Blue OFF Power ON
Programme Timer is NOT set
Both Programme Timer
(Recording) and Recording are
NOT working
–
Red Orange Power OFF (Standby)
Programme Timer is set
Both Programme Timer
(Recording) and Recording are
NOT working
–
Red Red Power OFF (Standby)
Programme Timer (Recording)
or Recording is working
–
Red OFF Power OFF (Standby)
Programme Timer is NOT set
Both Programme Timer
(Recording) and Recording are
NOT working
–
OFF Green
(Blinks)
Abnormal operation of BUS
line. Turn OFF the TV
and unplug the
power cord. Plug
the power cord in
again and turn ON
the TV.
Red
(Blinks)
OFF Abnormal operation of WDT.
Blue
(Blinks)
OFF Fan stopped.
(if applicable)
Orange Green For Service
SW Upgrade in Progress –
Red OFF For Service
SW Upgrade Failed –
Blue OFF For Service
SW Upgrade Successful –
LED indication Condition Solution
LED-1 LED-2
102
English
INFORMATION
License Information
• This product achieved the European Eco label
award issued by the European Commission.
You can get more information in following link:
http://ec.europa.eu/environment/ecolabel/
• Manufactured under license from Dolby
Laboratories.
Dolby and the double-D symbol are trademarks
of Dolby Laboratories.
• HDMI, the HDMI logo, and High-Definition
Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing, LLC.
• INSTAPORT™ and INSTAPORT logo are trademarks of Silicon
Image, Inc. in the United States and other countries.
• YouTube and the YouTube Logo are trademarks of Google Inc.
• This product contains NetFront Browser of ACCESS CO., LTD.
• ACCESS, the ACCESS logo and NetFront are
trademarks or registered trademarks of ACCESS
CO., LTD. in the United States, Japan and other
countries.
© 2010 ACCESS CO., LTD. All rights reserved.
This software is based in part on the work of the
Independent JPEG Group.
• Opera® Browser from Opera Software ASA.
Copyright 1995-2010 Opera Software ASA. All
rights reserved.
For further information, please see
http://www.opera.com
• This product contains Adobe® Flash® Player software under
license from Adobe Systems Incorporated.
Copyright © 1995-2009 Adobe Systems Incorporated. All rights
reserved. Adobe and Flash are trademarks of Adobe Systems
Incorporated.
• DivX®, DivX Certified®, DivX Plus™ HD and
associated logos are trademarks of DivX, Inc. and
are used under license.
Covered by one or more of the following U.S.
patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274
• MHL, the MHL logo, and Mobile High-Definition
Link are trademarks or registered trademarks of
MHL licensing, LLC.
• DVB is a registered trademark of the DVB Project.
• DLNA®, DLNA® Certification Logo and DLNA CERTIFIED™ are
registered trademarks, service marks, or certification marks of
the Digital Living Network Alliance.
• THIS PRODUCT IS LICENSED UNDER THE AVC PATENT
PORTFOLIO LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO
IN COMPLIANCE WITH THE AVC STANDARD (AVC VIDEO) AND/
OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A PERSONAL AND
NONCOMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A
VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER
USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM
MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
•THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL
PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A CONSUMER FOR (i) ENCODING
VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD
("MPEG-4 VIDEO") AND/OR (ii) DECODING MPEG-4 VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA
TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR
SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND
LICENSING MAY BE OBTAINED FROM MPEG LA,L.L.C.
SEE HTTP://WWW.MPEGLA.COM
• MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
• Audyssey EQ technology
• Manufactured under license from Audyssey Laboratories. U.S.
and foreign patents pending. Audyssey EQ is a registered
trademark of Audyssey Laboratories.
Audyssey EQ is based on the same core technology as Audyssey
MultEQ that is used for automatic correction of room
acoustics. Audyssey EQ uses time-domain filters to correct
problems that arise from speaker drivers and enclosures and is
calibrated to account for the acoustical problems in a typical
listening environment.
• Hybrid TV Standard is implemented according to
ETSI TS 102 796 v1.1.1.
103
INFORMATION
English
Cleaning the screen and cabinet…
Turn off the power, and clean the screen and cabinet with a soft, dry cloth. We recommend that you do not use
any proprietary polishes or solvents on the screen or cabinet as this may cause damage.
Disposal…
The following information is only for EU-member states:
Disposal of products
The crossed out wheeled dust bin symbol indicates that products must be collected and disposed of separately
from household waste. Integrated batteries and accumulators can be disposed of with the product. They will be
separated at the recycling centres.
The black bar indicates that the product was placed on the market after August 13, 2005.
By participating in separate collection of products and batteries, you will help to assure the proper disposal of
products and batteries and thus help to prevent potential negative consequences for the environment and human
health.
For more detailed information about the collection and recycling programmes available in your country, please
contact your local city office or the shop where you purchased the product.
Disposal of batteries and/or accumulators
The crossed out wheeled dust bin symbol indicates that batteries and/or accumulators must be collected and
disposed of separately from household waste.
If the battery or accumulator contains more than the specified values of lead (Pb), mercury (Hg), and/or cadmium
(Cd) defined in the Battery Directive (2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or
cadmium (Cd) will appear below the crossed out wheeled dust bin symbol.
By participating in separate collection of batteries, you will help to assure the proper disposal of products and
batteries and thus help to prevent potential negative consequences for the environment and human health.
For more detailed information about the collection and recycling programmes available in your country, please
contact your local city office or the shop where you purchased the product.
104
INFORMATION
English
Information
Before connecting any external equipment, turn off all main power switches. If there is no switch,
remove the mains plug from the wall socket.
Signal information for Mini D-sub 15 pin connector
* NC = not connected
Acceptable PC signals through the PC terminal
The PC input on this TV only accepts signal formats which are compliant with VESA-DMT as shown in the
table below. Since some PCs input signals which are different from the resolution and frequency described
in the table below, the following phenomenon may occur; incorrect display, false format detection, picture
position failure, blur, or judder. In this case, set the monitor output format on your PC to conform to a
signal in the table below.
Pin No. Signal name Pin No. Signal name Pin No. Signal name
1 R 6 Ground 11 NC
2 G 7 Ground 12 NC
3 B 8 Ground 13 H-sync
4NC*9 NC14V-sync
5 Ground 10 Ground 15 NC
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA Standard (DMT)
VGA 640 × 480 59.940Hz 31.469kHz 25.175MHz
72.809Hz 37.861kHz 31.500MHz
75.000Hz 37.500kHz 31.500MHz
SVGA 800 × 600 56.250Hz 35.156kHz 36.000MHz
60.317Hz 37.879kHz 40.000MHz
72.188Hz 48.077kHz 50.000MHz
75.000Hz 46.875kHz 49.500MHz
XGA 1024 × 768 60.004Hz 48.363kHz 65.000MHz
70.069Hz 56.476kHz 75.000MHz
75.029Hz 60.023kHz 78.750MHz
WXGA 1280 × 768 59.995Hz 47.396kHz 68.250MHz
59.870Hz 47.776kHz 79.500MHz
74.893Hz 60.289kHz 102.250MHz
1360 × 768 60.015Hz 47.712kHz 85.500MHz
SXGA 1280 × 1024 60.020Hz 63.981kHz 108.000MHz
75.025Hz 79.976kHz 135.000MHz
105
INFORMATION
English
Acceptable video or PC signals through the HDMI terminals
The HDMI inputs on this TV only accept VGA, SVGA, XGA, WXGA, and SXGA signal formats which are
compliant with VESA as shown in the table below. Since some PCs and HDMI or DVI devices input signals
which are different from the resolution and frequency described in the table below, the following
phenomenon may occur; incorrect display, false format detection, picture position failure, blur, or judder.
In this case, set the monitor output format on your PC, HDMI or DVI device to conform to a signal in the
table below.
Format Resolution V. Frequency H. Frequency Pixel Clock Frequency VESA
Standard
480i 720 × 480i 59.940/60.000Hz 15.734/15.750kHz 27.000/27.027MHz
576i 720 × 576i 50.000Hz 15.625kHz 27.000MHz
480p 720 × 480p 59.940/60.000Hz 31.469/31.500kHz 27.000/27.027MHz
576p 720 × 576p 50.000Hz 31.250kHz 27.000MHz
1080i 1920 × 1080i 59.940/60.000Hz 33.716/33.750kHz 74.176/74.250MHz
1080i 1920 × 1080i 50.000Hz 28.125kHz 74.250MHz
720p 1280 × 720p 59.940/60.000Hz 44.955/45.000kHz 74.176/74.250MHz
720p 1280 × 720p 50.000Hz 37.500kHz 74.250MHz
1080p 1920 × 1080p 59.940/60.000Hz 67.433/67.500kHz 148.352/148.500MHz
1080p 1920 × 1080p 50.000Hz 56.250kHz 148.500MHz
1080p 1920 × 1080p 24.000Hz 27.000kHz 74.250MHz
VGA 640 × 480 59.940/60.000Hz 31.469/31.500kHz 25.175/25.200MHz
72.809Hz 37.861kHz 31.500MHz
75.000Hz 37.500kHz 31.500MHz
SVGA 800 × 600 56.250Hz 35.156kHz 36.000MHz
60.317Hz 37.879kHz 40.000MHz
72.188Hz 48.077kHz 50.000MHz
75.000Hz 46.875kHz 49.500MHz
XGA 1024 × 768 60.004Hz 48.363kHz 65.000MHz
70.069Hz 56.476kHz 75.000MHz
75.029Hz 60.023kHz 78.750MHz
WXGA 1280 × 768 59.995Hz 47.396kHz 68.250MHz
59.870Hz 47.776kHz 79.500MHz
74.893Hz 60.289kHz 102.250MHz
1360 × 768 60.015Hz 47.712kHz 85.500MHz
SXGA 1280 × 1024 60.020Hz 63.981kHz 108.000MHz
75.025Hz 79.976kHz 135.000MHz
106
INFORMATION
English
Media Player Supported Format
Media
Player
Media
Format
File
Extension
Video/Audio codec USB DMS Note
Photo JPEG .jpg
.jpeg
JPEG Yes Yes <USB>
Data compatibility: JPEG Exif ver 2.2
Maximum viewable resolution:
4096 x 4096 (HW decode)
16384 x 16384 (SW decode)
Maximum photo size: 9MB
Maximum number of files: 2000 / folder
<DMS>
Data compatibility: JPEG EXIF Ver.1.x or
later, JFIF 1.02a
Maximum photo resolution: 4096 x 4096
Maximum photo size: 6 MB
Maximum number of files: 2000 / folder
MPO .mpo JPEG Yes No
Movie MPEG-2 PS
MPEG-2 TS
.mpg
.mpeg
.ts
Video) MPEG-1 Video Yes No <USB>
Maximum number of files: 2000 / folder
<DMS>
Maximum number of files: 2000 / folder
*)Some files may not be played.
*)Normal playing and trick playing may
not be available depending on the
contents.
*)Div X external subtitles are not
supported.
Video) MPEG-2 Video
H.264 (MPEG-4 AVC)
Yes Yes
Audio) MPEG-1 Layer1
MPEG-1 Layer2
MPEG-2 Layer2
Dolby Digital (AC-3)
L-PCM (MPEG-2 PS only)
Yes Yes
Audio) Dolby Digital Plus
AAC
HE AAC
Yes No
MP4 .mp4
.m4v
Video) H.264 (MPEG-4 AVC) Yes Yes
Audio) AAC Yes Yes
Audio) HE AAC
Dolby Digital (AC-3)
Dolby Digital Plus
Yes No
AVI
DivX
DivX Plus HD
.avi
.divx
.div
Video) DivX (3,4,5,6) Yes No
Audio) Dolby Digital (AC-3)
MPEG-1 Layer2
MPEG-1 Layer3
Yes No
MKV
DivX Plus HD
.mkv Video) H.264 Yes No
Audio) AAC
HE AAC
Dolby Digital (AC-3)
MPEG-1 Layer 3
Yes No
ASF .asf
.wmv
Video) VC-1 Yes No
Audio) WMA Yes No
AVCHD .mts
.m2ts
Video) H.264 (MPEG-4 AVC) Yes Yes
Audio) Dolby Digital (AC-3) Yes Yes
Music MP3 .mp3 Audio) MPEG-1 Audio Layer-3
MPEG-2 Audio Layer-3
MPEG-2.5 Audio Layer-3
Yes Yes <USB>
Maximum number of files: 2000 / folder
<DMS>
Maximum number of files: 2000 / folder
*)Some files may not be played.
MP4 .mp4
.m4a
Audio) AAC Yes No
Audio) HE AAC Yes No
WMA .wma Audio) WMA Yes No
L-PCM Audio) L-PCM No Yes
107
INFORMATION
English
3D Support Format (HDMI)
Resolution Aspect ratio V.Frequency H.Frequency Pixel Clock Frequency 3D Structure
720 × 480p 16:9 59.940/60.000Hz 31.469/31.500kHz 27.000/27.027MHz Side by Side (Full)
Side by Side (Half)
Top and Bottom
720 × 576p 16:9 50.000Hz 31.250kHz 27.000MHz Side by Side (Full)
Side by Side (Half)
Top and Bottom
1280 × 720p 16:9 59.940/60.000Hz 90.0/89.91kHz 148.352/148.500MHz Frame Packing
44.955/45.000kHz 74.176/74.250MHz Side by Side (Half)
Top and Bottom
50.000Hz 75.000kHz 148.500MHz Frame Packing
37.500kHz 74.250MHz Side by Side (Half)
Top and Bottom
1920 × 1080i 16:9 59.940/60.000Hz 33.716/33.750kHz 74.176/74.250MHz Side by Side (Half)
Top and Bottom
50.000Hz 28.125kHz 74.250MHz Side by Side (Half)
Top and Bottom
1920 × 1080p 16:9 24.000Hz 54.000kHz 148.500MHz Frame Packing
27.000kHz 74.250MHz Side by Side (Half)
Top and Bottom
30.000Hz 67.433/67.500kHz 148.352/148.500MHz Frame Packing
33.716/33.750kHz 74.176/74.250MHz Side by Side (Half)
Top and Bottom
50.000Hz 56.250kHz 148.500MHz Side by Side (Half)
Top and Bottom
59.940/60.000Hz 67.433/67.500kHz 148.352/148.500MHz Side by Side (Half)
Top and Bottom
108
INFORMATION
English
3D Support Format (DTV)
* Side by Side (Full) is composed of left and right stereoscopic pictures that each size is equal to 2D.
Video Format Aspect ratio V.Frequency 3D Structure
480i, 480p 16:9 59.940/60.000Hz Side by Side (Half)
Top and Bottom
576i, 576p 16:9 50.000Hz Side by Side (Half)
Top and Bottom
720p 16:9 59.940/60.000Hz Side by Side (Half)
Top and Bottom
50.000Hz Side by Side (Half)
Top and Bottom
1080i 16:9 59.940/60.000Hz Side by Side (Half)
Top and Bottom
50.000Hz Side by Side (Half)
Top and Bottom
1080p 16:9 24.000Hz Side by Side (Half)
Top and Bottom
30.000Hz Side by Side (Half)
Top and Bottom
50.000Hz Side by Side (Half)
Top and Bottom
59.940/60.000Hz Side by Side (Half)
Top and Bottom
2D Video
Side by Side (Full)
3D Video
Side by Side (Half)
L
2D Video 3D Video
R
LR
109
INFORMATION
English
Specifications and accessories
Receiving systems
DVB-C Broadcast systems
DVB-S/DVB-S2 Broadcast systems
Specification is subject to change without notice.
DVB-T Broadcast systems/channels
Broadcast systems/channels
UK UHF 21-68 PAL-I UHF UK21-UK69
France VHF 05-10 (VHF 01-05)
UHF 21-69
PAL-B/G UHF E21-E69
VHF E2-E12, S1-S41
Germany VHF 05-12
UHF 21-69
SECAM-L UHF F21-F69
VHF F1-F10, B-Q
Austria VHF 05-12
UHF 21-69
SECAM-D/K UHF R21-R69
VHF R1-R12
Switzerland VHF 05-12
UHF 21-69
Italy VHF 05-12 (D,E,F,G,H,H1,H2)
UHF 21-69
Spain UHF 21-69
Nederlands VHF 05-12
UHF 21-69
Greece VHF 05-12
UHF 21-69
Video Input PAL, SECAM, NTSC 3.58/4.43
External connections
EXT 1 Input/Output 21-pin SCART RGB, A/V input
AV out, TV out
EXT 2 Input Phono jacks
Phono jacks
Y, PB/CB, PR/CR
Audio L + R
EXT 3 Input Phono jacks Video/Audio L + R
HDMI 1/2/3/4 Input HDMI® compliant
HDCP compliant
(Enable Content Type, INSTAPORT™,
RGB Range, supported)
HDMI 4 is compatible with MHL
PC Input Analog RGB
PC/HDMI 3 Audio input 3.5mm mini jack Audio
Digital Audio Output (S/PDIF) Optical
LAN port RJ-45
USB 1/USB 2 port Media Player
Interface version: USB 2.0
USB class: Mass Storage
File system: FAT16 and FAT32
Maximum output: 500mA (specified to
charge the 3D glasses FPT-AG02G)
USB 2 port USB HDD connection compatible
Headphone socket 3.5mm stereo
Stereo A2, Nicam
2 carrier system
Visible Screen Size
(approx.)
42
46
55
107cm
117cm
139cm
Display 16:9
Sound output
(at 10% distortion)
Main:
Woofer:
10W + 10W
10W
Power consumption
(approx.)
42WL/42YL
46WL/46YL
55WL/55YL
140W
152W
184W
Standby power
consumption
(approx.)
0.3W
On-mode power
consumption* (approx.)
42WL/42YL
46WL/46YL
55WL/55YL
94.1W
115W
138W
Average annual energy
consumption** (approx.)
42WL/42YL
46WL/46YL
55WL/55YL
137.4kWh/y
167.9kWh/y
201.5kWh/y
* Tested in accordance with IEC 62087-BD Ed. 2.0:2008.
** Operating 4 hours a day and 365 days a year.
Dimensions
(approx.)
42WL/42YL 69cm (H) 101cm (W) 29cm (D)
46WL/46YL 72cm (H) 107cm (W) 29cm (D)
55WL/55YL 84cm (H) 127cm (W) 36cm (D)
(Height dimension includes foot stand)
Weight (approx.) 42WL/42YL
46WL/46YL
55WL/55YL
17.5kg
18.5kg
25.5kg
Operating condition Temperature 5°C - 35°C (41°F - 94°F)
Humidity 20 - 80% (non-condensing)
Wireless connection • Standard: IEEE 802.11a/b/g/n
• Frequency Range: 5.15-5.35 GHz,
5.47-5.725 GHz, 5.725-5.850 GHz,
2.400-2.4835 GHz
• Security: WEP64/128, TKIP, AES,
WPA/WPA2-PSK, WPS, None
Supplied accessories • Remote control CT-90378
2 batteries (AAA, IEC R03 1.5V)
• Toshiba 3D glasses : FPT-AG02G (for YL86
and YL87 series)
• SCART Adaptor cable
• Component Adaptor cable
• AV Adaptor cable
• AV-SCART Adaptor cable
• RGB/PC-D-sub15pin(mini) Adaptor
cables(w/audio)
• ‘P’ Clip/Screw (for TV mounting)
See page 6.
•Two cable clamps
Optional accessories • Toshiba 3D glasses : FPT-AG02G
•USB HDD
For available USB HDD, see “Product
Information” on the website.
© TOSHIBA Television Central Europe Sp. z o.o.
All rights reserved.
Reproduction in whole or part without written permission is strictly prohibited.
TOSHIBA Television Central Europe Sp. z o.o.
ul. Pokoju 1, Biskupice Podgórne, 55-040 Kobierzyce, Poland
EU Ecolabel : PL/22/002
For those products that have been awarded the
European Eco Label, TOSHIBA gives a minimum of
2 years guarantee for this LCD TV and 7 years
availability for replacement of electronic parts.
For warranty repairs, please contact the retailer where
you purchased the product.
Please see the Toshiba website or European Eco Label
website (www.ecolabel.eu) for details of those
products.
T 2

Navigation menu
