Portégé R500-S5006X Page 1 of 5
Portégé R500-S5006X Detailed Product Specification1
Model Name Description Part Number UPC
R500-S5006X Genuine Windows® XP Professional, Intel® Core™ 2 Duo Processor U7700, 2048MB
DDR2, 160GB 5400rpm SATA, DVD-SuperMulti, 12.1” widescreen WXGA, Intel®
Wireless WiFi Link 4965AGN, Bluetooth v2.0 + EDR, 3 year standard limited warranty
PPR50U-07X020 883974078455
Operating System C1 2
• Genuine Windows® XP Professional
Processor and Chipset3
Intel® Centrino® processor technology featuring:
o Intel® Core™ 2 Duo Processor U7700
1.33GHz, 2MB L2, 533MHz FSB with 64-bit C1
• Chipset
o Mobile Intel® 945GMS Express Chipset
• Integrated Wi-Fi® compliant wireless LAN
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n) 4
Memory5
• Configured with 2048MB PC2-5300 DDR2 SDRAM (single memory slot
occupied)
• 2048MB (Min)/2048MB (Max), 1024MB on motherboard with single
available memory slot occupied with 1024MB PC2-5300 memory
module
Hard Disk Drive6
• 160GB (5400 RPM); Serial ATA hard disk drive; 9.5mm height
Fixed Optical Disk Drive7
• DVD SuperMulti (+/-R) drive supporting 9 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (10x), DVD-ROM (8x), DVD-R (8x), DVD-RW (4x),
DVD+R (8x), DVD+RW (4x), DVD-RAM (3x)
Display8
• 12.1” diagonal widescreen high brightness display at 1280 x 800
resolution(WXGA) - Transreflective type
o LED backlight
Graphics9
• Intel® Graphics Media Accelerator 950
Sound
• Built-in monaural speaker
• Sound Volume Control Dial
• Built-in microphone
Input Devices
• 85 key US keyboard
• TouchPad™ pointing device
• Control Buttons:
o Toshiba Assist button
o Toshiba Outdoor Display Switch
Communications
• Intel® PRO/1000 - 10/100/1000 Ethernet
• Integrated Wi-Fi® compliant wireless:10
o Intel® Wireless WiFi Link 4965AGN (802.11a/g/n) 11
• Bluetooth® version 2.0 plus Enhanced Data Rate (EDR)
Expandability
• One PCMCIA – Type II/Type I Card Slot
• Secure Digital slot (supports SDIO)
Ports
• Video
o RGB (monitor) output port
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK(tm) IEEE-1394
o USB v2.0 – 3 ports
o 64-pin docking connector
• Security
o Fingerprint reader
Physical Description
• Dimensions (WxDxH Front/H Rear): 11.1” x 8.5” x .77”(f)/1.0”(r) with
feet
• Weight: Starting at 2.4 lbs depending upon configuration12
• LCD Cover Color: Aluminum Silver
Power
• 45W (15V x 3A) 100-240V AC Adapter.
• Dimensions (WxDxH): 3.66” x 1.09” x 1.57”
• Weight: starting at 0.4 lbs
Battery13
• (5800mAh) Lithium Ion battery pack
• Dimensions (WxDxH): 8.1” x .79” x 1.72”
• Weight: starting at 0.69 lbs
Toshiba EasyGuard®14
• Protect & Fix
o Shock Absorbing Design15
HDD Shock Absorber
LCD Panel Shock Absorber
Chassis Shock Protector
o Hard Disk Drive Protection
3D Accelerometer
HDD Dome Shock Protector
HDD Shock Absorber
o Spill-Resistant Keyboard16
o Magnesium Alloy Casework
• Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad® TruePrint® technology
o Infineon TPM Software Professional Package
o Trusted Platform Module (TPM v1.2)
o TOSHIBA Secure Digital Token Utility
o Execute Disable Bit
o Optional Services and Accessories (additional purchase required)
CompuTrace®
• Connect
o Diversity Antenna
o TOSHIBA ConfigFree®
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth® Stack
• Optimize
o TOSHIBA Zooming Utility
o One-touch Resolution Change
o TOSHIBA Power Saver Utility
o TOSHIBA Optical Disc Drive Power On/Off Utility
o Wireless On/Off Switch
o TOSHIBA Fn-esse® Shortcut Utility
o TOSHIBA Mouse Utility
o FN Shortcut Keys
BIOS
• ACPI v2.0, PNP, VESA, DPMS, DDC, SM BIOS v2.4, PCI BIOS v2.1
support
Software C1 17
• Toshiba Software and Utilities
o Electronic User’s Guide
o Bluetooth Stack for Windows by Toshiba
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R500-S5006X Page 2 of 5
o TOSHIBA ConfigFree®
o TOSHIBA Management Console
o TOSHIBA Assist
o TOSHIBA Security Assist
o TOSHIBA Disc Creator
o TOSHIBA Recovery Disc Creator
o
• Third-party Software
o Sun® Java™ 2 Runtime Environment
o Adobe® Acrobat® Reader
o InterVideo® WinDVD®
o Google™ Desktop
o Google™ Toolbar
o Infineon TPM Software Professional Package
o AuthenTec EntréPad® TruePrint® technology
o Ulead® DVD MovieFactory®
• Trial Software
o Microsoft Office Ready with Microsoft Office Professional 2007
Edition (60-day trial)
o Norton 360TM All-In-One SecurityTM 2007 (60 day trial)
• Special Offers
o Microsoft Office Live
o Skype™
o Computrace® LoJack® for Laptops
Environmental Specifications
Operating Non-operating
Temperature18 5° to 30°/35° C
(41° to 86°/95° F) -20° to 65° C
(-4° to 149° F)
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Relative Humidity
(non-condensing) 20% to 80% 10% to 95%
Altitude
(relative to sea level) -60 to 3,000 meters -60 to 10,000 meters
Shock 7G 60G
Vibration 0.2G 1.0G
• Energy Star Compliant
• EPEAT™ Gold
• This product is RoHS19 compatible
TECRA / PORTEGE / LIBRETTO – 3 YEAR STANDARD
LIMITED WARRANTY20
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
Extended Service Plan
Provides an extended service plan for up to 4 total years from the original
notebook purchase date. Must be purchased within the first 6 months of
notebook purchase.
Part Number Description
WSN-PTQQ4V 4th Year Extended Service Plan
SystemGuard Accidental Damage Service w/ ServiceExpress21
Provides advanced protection from damage caused from handling. Select
your express repair service with either Depot Express or Carry-In Express
and go to the front of the line. Extended Service Plan included with 4 Year
plan. Must be purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PQGP3V 1st/2nd/3rd Year
WSN-PTGP4V 1st/2nd/3rd/4th Year + Extended Service Plan
SystemGuard Accidental Damage Service + On-Site Repair22
Combines SystemGuard and On-Site Repair coverage. Extended Service
Plan included with 4 Year plan. Must be purchased within the first 30 days
of notebook purchase.
Part Number Description
WSN-PQGN3V 1st/2nd/3rd Year
WSN-PTGN4V 1st/2nd/3rd/4th Year + Extended Service Plan
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Extended Service Plan included with 4 Year plan.
Must be purchased within the first 30 days of notebook purchase.
Part Number Description
WSN-PQQP3V 1st/2nd/3rd Year
WSN-PTQP4V 1st/2nd/3rd/4th Year + Extended Service Plan
On-Site Repair Service
On-site service will be provided at the customer’s home or business location
(excluding weekends and holidays) to perform the necessary hardware
repairs. Extended Service Plan included with 4 Year plan. Must be
purchased within the first 6 months of notebook purchase.
Part Number Description
WSN-PQQN3V 1st/2nd/3rd Year
WSN-PTQN4V 1st/2nd/3rd/4th Year + Extended Service Plan
4 YEAR STANDARD LIMITED WARRANTY 23
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as SystemGuard®,
On-Site Repair, and ServiceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Recommended Services
SystemGuard Accidental Damage Service w/ ServiceExpress24
Provides advanced protection from damage caused from handling. Select
your express repair service with either Depot Express or Carry-In Express
and go to the front of the line. Must be purchased within the first 30 days of
notebook purchase.
Part Number Description
WSN-PMGP4V 1st/2nd/3rd/4th Year
SystemGuard Accidental Damage Service + On-Site Repair25
Combines SystemGuard and On-Site Repair coverage. Must be purchased
within the first 30 days of notebook purchase.
Part Number Description
WSN-PMGN4V 1st/2nd/3rd/4th Year
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Your notebook will be repaired and returned via
overnight shipment (excluding weekends and holidays). Carry-In Express:
Take your notebook into a Premier ASP and go to the front of the line for
expedited repair service. Must be purchased within the first 30 days of
notebook purchase.
Part Number Description
WSN-PMQP4V 1st/2nd/3rd/4th Year
On-Site Repair Service
On-site service will be provided at the customer’s home or business location
(excluding weekends and holidays) to perform the necessary hardware
repairs. Must be purchased within the first 6 months of notebook purchase.
Part Number Description
WSN-PMQN4V 1st/2nd/3rd/4th Year
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R500-S5006X Page 3 of 5
Power
Part Number Description
PA3282U-2ACA Toshiba 60W Global AC Adapter
PA3612U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3091U-2CHG Toshiba Battery Charger w/Integrated AC Adapter
Expansion
Part Number Description
PA3603U-1PRP Toshiba Slim Port Replicator II
PA3438U-2CD2 Toshiba UltraSlim External CD-RW/DVD-ROM Drive
(USB 2.0)
PA3454U-2CD2 Toshiba UltraSlim External DVD SuperMulti Drive (USB
2.0)
PA3579U-1ETC Toshiba Universal Notebook/Projector Stand
Security & Protection
Part Number Description
PA410U Targus DEFCON CL Notebook Cable Lock
Storage
Part Number Description
PA3556U-1M2G Toshiba 2GB USB Hi-Speed Flash Drive
PA3556U-1M4G Toshiba 4GB USB Hi-Speed Flash Drive
PA3556U-1M8G Toshiba 8GB USB Hi-Speed Flash Drive
Article I. Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Article II. Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, SelectBay, ConfigFree and SystemGuard are registered trademarks of Toshiba America Information Systems, Inc. and/or Toshiba
Corporation. All other trademarks and names are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating System
- 64-bit CPU, Chipset and BIOS (Basic Input/Output System)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. A 32-bit version of the operating system is preinstalled
on your computer unless explicitly stated that the operating system is 64-bit. See "Detailed Specs" for more information.
1 Product Series Legal Footnote. The product specifications and configuration information are designed for a product Series. Your particular model may not have all the features
and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
pcsupport.toshiba.com.
Product Offering Legal Footnote. Toshiba America Information Systems, Inc. reserves the right to modify or withdraw this offer at anytime without notice.
2 Operating System.
Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3 Processor (Central Processing Unit).
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R500-S5006X Page 4 of 5
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed Specs.” Contact Toshiba Technical
Service and Support for more information.
4 Wireless-N. The 802.11a/g/n wireless adapter is based on a draft release version of the IEEE 802.11n specification, which may not be compatible with, or support all features
(e.g., security) of, certain Wi-Fi®.
5 Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. For PC's configured with 4 GB of system memory, the full system memory space for computing activities will be considerably less
and will vary by model and system configuration.
6 Hard Disk Drive (HDD) Capacity.
1 Gigabyte (GB) means 109 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1
GB = 230 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating
systems, such as Microsoft Operating System and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7 Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8 Display. Small bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9 Graphics (Graphics Processing Unit).
GPU performance may vary depending on product model, design configuration, applications, power management settings and features utilized. GPU performance is only optimized
when operating in AC power mode and may decrease considerably when operating in battery power mode.
10 Wireless. Wireless connectivity and some features may require you to purchase additional software, external hardware or services. Availability of public wireless LAN access
points may be limited. The transmission speed over the wireless LAN and the distance over which wireless LAN can reach may vary depending on surrounding electromagnetic
environment, obstacles, access point design and configuration, and client design and software/hardware configurations. The actual transmission speed will be lower than the
theoretical maximum speed. To use the Atheros SuperAG™ or SuperG™ wireless function, if available, your client and access point must support the corresponding feature.
Performance of these functions may vary depending on the format of data transmitted.
11 Wireless-N. The 802.11a/g/n wireless adapter is based on a draft release version of the IEEE 802.11n specification, which may not be compatible with, or support all features
(e.g., security) of, certain Wi-Fi®.
12 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
13 Battery Life. Battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features utilized, as
well as the natural performance variations produced by the design of individual components. Published battery life numbers are achieved on select models and configurations
tested by Toshiba at the time of publication. See “Detailed Specs” for specific battery measurement test. Recharge time varies depending on usage. Battery may not charge while
computer is consuming full power. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
To purchase a new battery pack, see the accessories information that shipped with your computer or visit the Toshiba web site at www.accessories.toshiba.com.
Battery life will be less than when using similar applications in the Windows Operating System
14 EasyGuard. Toshiba EasyGuard™ technology comprises a number of features some of which may or may not be available on a particular Toshiba notebook depending on the
model selected. See www.easyguard.toshiba.com for detailed information.
15 Shock Protection. Toshiba’s shock absorption technology provides higher impact protection for your system as compared to Toshiba systems without similar shock protection
features based on Toshiba’s drop tests. Toshiba’s standard limited warranty terms and limitations apply. Visit www. warranty.toshiba.com for details.
16 Spill-Resistant Keyboard. Under Toshiba testing conditions, the spill-resistant keyboard delayed the time for a water spill to reach the PC's main board to allow more time to
properly close down the machine. Toshiba’s standard limited warranty terms and limitations apply. Visit www.warranty.toshiba.com for details.
17 Software. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software products (including Microsoft Office Small Business Accounting if applicable) included with this computer may use technological measures for copy
protection. IN SUCH EVENT, YOU WILL NOT BE ABLE TO USE THE PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION
PROCEDURES. Product activation procedures and Microsoft’s privacy policy will be detailed during initial launch of the product, or upon certain reinstallations of the software
products or reconfigurations of the computer, and may be completed by Internet or telephone (toll charges may apply).
Internet access is required to enable certain functionality of certain Microsoft products which may be included with this computer.
The Microsoft Office 2007 60-Day Trial software (if applicable) is intended for evaluation purposes only. You must activate the software before you can use it. Product activation
© Copyright 2007 – 2008 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portégé R500-S5006X Page 5 of 5
procedures will be detailed during initial launch of the software; activation requires Internet access. This software has an expiration date of 60 days from date of first use, at which
time the software will operate under reduced-functionality mode, limiting end-user options and operations. The Microsoft Office 2007 60-Day Trial software is distributed without
charge to the End User Customer but if the End User wants to continue to use such product after the trial period, then the End User Customer will have to pay a fee for the
perpetual version of such Office Product.
18 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
19 RoHS. This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment
(RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoHS requirements
and verifies its suppliers' commitment to meeting RoHS requirements by conducting component sampling inspections during the product design approval process.
20 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
21 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
22 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
23 Warranty: The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
24 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
25 Service Plans: The terms and conditions of service upgrade and extension plans offered by Toshiba are available at www.pcsupport.toshiba.com.
