Toy State 37030R49 ARENA ROCKER (RAMINATOR) RX User Manual 38721 CAT Instr 090204
Toy State International Ltd. ARENA ROCKER (RAMINATOR) RX 38721 CAT Instr 090204
USER MANUAL
RADIO CONTROL
ARENA ROCKER
OWNER’S MANUAL
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
1 PEKING ROAD, KOWLOON, HONG KONG
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY
IMPROVING AND UPDATING OUR PRODUCTS. CONSEQUENTLY, PICTURES IN THIS
INSTRUCTION SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
Call for Help!
If you have questions about this toy
Call Toll-Free: 1-877-473-8015
Between 9:00 a.m. – 5:00 p.m. E.S.T. Monday thru Friday
Contact via e-mail: consumerservice@toystate.com
www.toystate.com
BIGFOOT® and Snake Bite® are registered trademarks of BIGFOOT
4x4, Inc., St. Louis Missouri, U.S.A. 63042
©2010 BIGFOOT 4x4 Inc. All Rights Reserved.
Firestone is a trademark of Bridgestone/Firestone, Inc.
http://www.raminator.com
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
PROBLEM! ROAD RIPPERS R/C VEHICLE RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PROBLEM? PERFORMANCE DROP, INCONSISTENT MOVEMENT OR FAILS TO RUN
Check batteries. If necessary, replace the batteries in the Road Rippers R/C vehicle and controller
with new alkaline batteries.
Call 1-877-473-8015 for help!
Have Fun - Play Games @ www.toystate.com
BATTERY REQUIREMENTS:
3 “AAA” Batteries (for Controller)
4 “AA” Batteries (for Vehicle)
Dodge, Ram and HEMI are trademarks
of Chrysler Group LLC.
Dodge Raminator and its trade dress are used
under license by Toy State Industrial LTD.
© Chrysler Group LLC 2010
61
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
“Modifications not authorized by the manufacturer may void users authority to operate the device.”
CAUTION
Important Battery Information
•Dispose of batteries properly.
•Do not dispose of batteries in fire.
•Use only batteries of the type recommended.
•Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
•Do not mix old and new batteries.
•Remove batteries from Road Rippers R/C Vehicle and Controller if vehicle will not be used for a
long period of time.
PROBLEM! ROAD RIPPERS R/C VEHICLE DOES NOT MOVE
PROBLEM! ROAD RIPPERS R/C VEHICLE MOVES BY ITSELF
TROUBLESHOOTING AND CARE FOR R/C VEHICLES
• Are the + and –’s contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned on?
• Are the batteries weak or out of power?
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
ATTENTION PARENTS
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURERS NOTE TIPS & TRICKS
STRONG BATTERY MEANS OPTIMUM
PERFORMANCE
Save the battery by turning off vehicle when not in use.
LIMITED RADIO CONTROL RANGE
While Road Rippers R/C vehicle may be visible at a
distance, full operational control may be lost. Hold
controller high in the air and direct vehicle back.
INTERFERENCE
Other radio signals may cause loss of control.
Remove vehicle from an area of interference.
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1). This device may not cause harmful interference. 2). This device must accept any interference received including
interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment. Note: this equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These Limits are designed
to provide reasonable protection against harmful interference in a residential installation. This generates, uses and
can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on , the user is encouraged to try and correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.
5 2
Remove the Road Rippers R/C vehicle and controller from the box. Insert 3 “AAA” batteries in the
controller. Add 4 “AA” batteries into the Road Rippers R/C vehicle to begin full function play
(see “Battery Installation” section for further details).
TREAT YOUR ROAD RIPPERS R/C VEHICLE WELL
Radio waves control the Road Rippers R/C vehicle. Care for your vehicle and it will provide hours of fun!
Avoid water, heat, sand and high impact crashes!
Store in safe place. No direct sunlight. No rain or water.
No sand or dust. No Collisions. Road Rippers R/C vehicle may get
stuck on carpet or grass.
Avoid running 2 vehicles with the same
radio control frequencies.
CLEANING AND MAINTAINING
Brush areas where dirt and dust
get trapped. Wipe body off with a soft rag or
tact cloth. Do not clean vehicle with
chemicals or water.
GETTING STARTED
BATTERY INSTALLATION IN CONTROLLER
LOOSEN SCREW
TO OPEN
3 "AAA" BATTERIES REQUIRED
(NOT INCLUDED)
TO REPLACE THE BATTERIES
NOTE:
For best performance, always use alkaline batteries only.
BATTERY INSTALLATION IN ROAD RIPPERS R/C VEHICLE
4 "AA" BATTERIES REQUIRED (NOT INCLUDED)
TO REPLACE THE BATTERIES
LOOSEN
SCREW
TO OPEN
2. Insert 3 “AAA”
batteries into
the Controller.
Be sure the +
and – are
properly
matched.
2. Insert 4 “AA”
batteries into
the Vehicle.
Be sure the +
and – are
properly
matched.
1. To remove battery cover, loosen
screw to open.
1. To remove battery cover, loosen
screw to open.
43
OPERATING ROAD RIPPERS R/C VEHICLE
Turn ON/OFF switch
(on bottom of Road
Rippers R/C vehicle)
to the ON position
(as shown.)
After play, always turn vehicle off. Remove batteries from controller and Road Rippers R/C vehicle when
not in use or when storing. Leakage may occur and cause damage if left for a long period of time.
• Install batteries in Road Rippers R/C vehicle and controller.
• Learn function of controller.
• Enjoy!
QUICK START GUIDE
Forward Action! Reverse Action!
Turns Left or Right in Forward and Reverse Pop a Wheelie
Pop a Wheelie and Spin
ROAD RIPPERS R/C VEHICLE FEATURES
• Hold button 1and 2on the controller to
drive forward
•3and 4to drive in reverse
•1to turn right while going forward
•2to turn left while going forward
•3to turn right going in reverse
•4to turn left going in reverse
•1and 4to spin clockwise
•2and 3to spin counter-clockwise
• To pop a wheelie hold 3and 4to go in
reverse, then abruptly hold down 1and 2
• While in a wheelie position, drive forward
or spin freely using any of the turning
button combinations listed above
• Drop form wheelie position by pressing 3
and 4
Refer To Controller Diagram For Full Function Play
