Toy State 37100F27 Blaze CrazeTM R/C – 3 Asstd User Manual 38721 CAT Instr 090204
Toy State International Ltd. Blaze CrazeTM R/C – 3 Asstd 38721 CAT Instr 090204
User Manual
RC
RCRC
RC
RADIO CONTROL
BLAZE CRAZE R/C
OWNER’S MANUAL
TM
CONTROLLER
VEHICLE
Batteries Not Included Included
AAA
/
R3
AA
/
LR6
x3 x4
4+
#37100
1
RC
RCRC
RC
MUTE SWITCH
NOTE: For best performance, always use alkaline batteries only.
CAUTION
Important Battery Information
• Dispose of batteries properly.
• Do not dispose of batteries in fire.
• Use only batteries of the type recommended.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Remove batteries from R/C vehicle and controller if vehicle will not be used for a long
period of time.
BATTERY INSTALLATION
This unit is equipped with a mute switch. Use the mute switch when
“Quiet Time” is needed. It is located on either the controller or the vehicle.
GETTING STARTED
Remove the R/C vehicle and controller from the package. Insert batteries into the R/C vehicle and
controller to begin full function play
(see “Battery Installation” section for further details).
ENG
CONTROLLER
1.5v
1.5v
1.5v
1. To remove battery cover, loosen screw
to open.
2. Insert 3 “AAA” batteries into the
controller. Be sure the + and – are
properly matched.
R/C VEHICLE
1.5v 1.5v
1.5v1.5v
1. To remove battery cover, loosen screw
to open.
2. Insert 4 “AA” batteries into the vehicle.
Be sure the + and – are properly
matched.
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Save the battery by turning off vehicle when not in use.
PLAYDEMO OFF
6
7
• Press button 6 on the vehicle to
drive forward with lights and sounds
• Press button 7 on the vehicle for
lights and sounds
• Press button 8 on the vehicle for
lights and sounds
2
OPERATING R/C VEHICLE
ENG
PLAYDEMO OFF
Toggle DEMO/OFF/PLAY
switch located on bottom
of R/C vehicle to the PLAY
position
Full-Function Radio Control Amazing Light Show
After play, always turn vehicle off. Remove batteries from controller and R/C vehicle when not in
use or when storing. Leakage may occur and cause damage if left for a long period of time.
PLAY!
TO
WAYS
PLAY!
TO
WAYS
WAYS
PLAY!
TO
WAYS
R/C OR PUSH BUTTON
• Hold button 1 and 2 on the
controller to drive forward
• Hold 3 and 4 to drive in reverse
• Hold 1 to turn right while going
forward
• Hold 2 to turn left while going
forward
• Hold 3 to turn right going in reverse
• Hold 4 to turn left going in reverse
• Press button 5 for lights and sounds
8
1
2
3
4
5
3
RC
RCRC
RC
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned on?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, replace the batteries in the R/C vehicle
and controller with new alkaline batteries.
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun!
Avoid water, heat, sand and high impact crashes!
TREAT YOUR R/C VEHICLE WELL
Store in safe place. No direct sunlight. No rain or water. No sand or dust.
No Collisions.
R/C vehicle may get stuck on
carpet or grass.
Avoid running 2 vehicles with the same radio control frequencies.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller high in
the air and direct vehicle back.
INTERFERENCE
Other radio signals may cause loss of control. Remove
vehicle from an area of interference.
ENG
www.toystate.com
Ford Motor Company Trademarks
and Trade Dress used under license
to Toy State Industrial Ltd.
www.fordmotorcompany.com
Dodge, SRT, HEMI, vehicle nameplates and trade
dress are trademarks of Chrysler Group LLC and
used under license by Toy State Industrial LTD.
© Chrysler Group LLC 2012.
