Toy State 60065F27 ROLLING RING - The Rock User Manual FAR 60065 Rolling Ring ENG IM 060815
Toy State International Ltd. ROLLING RING - The Rock FAR 60065 Rolling Ring ENG IM 060815
User Manual
8+
ASST
#60065
Important! Carefully read the Owners Manual before play!
CONTROLLER VEHICLE
BATTERIES NOT INCLUDED BATTERIES NOT INCLUDED
x3 x4
C
M
Y
CM
MY
CY
CMY
K
FAR_60065_Rolling Ring_ENG_IM_060815.pdf 1 8/6/15 9:27 am
C
M
Y
CM
MY
CY
CMY
K
FAR_60065_Rolling Ring_ENG_IM_060815.pdf 2 8/6/15 9:27 am
1
PRECAUTION
BATTERIES
• Do not use this vehicle in water, mud, or sand.
• This product and its accessories are not suitable for children under the age of 36 months, because of small
parts that can be swallowed.
• Intended for children age 8 and older.
• Adult supervision strongly recommended.
• Drive your vehicle in a safe area away from people, pets, cars, etc.
• Do not drive on streets or after dark.
• Do not touch or try to pick up the vehicle when it is in motion. Wait until it has stopped completely.
• Keep hair, fingers, face and loose clothing away from front and rear wheels while the vehicle is switched on
or while the transmitter is operating.
• Do not drive the vehicle toward walls or other hard objects.
• Be a responsible operator!
• Do not drop or give impact to the product and its accessories.
• Check if a near transmitter produces interference or signals with the same frequency. In such a case, move
to another location or try again after a while.
• Never attempt to disassemble or modify the product or its accessories.
• Regularly inspect the antennas for cracks or breaks. Do not bend the transmitter antenna. Do not use the
transmitter if the antenna is broken.
• Make sure the batteries are inserted with correct polarity and follow the toy and battery manufacturer's
instructions.
• Use only battery type(s) recommended.
• Do not attempt to short-circuit, charge, disassemble or heat batteries.
• Do not dispose of batteries in fire or make them wet.
• Do not mix or use new and old batteries together.
• Do not mix or use different types of batteries together.
• Non-rechargeable batteries are not to be recharged because of the danger of eruption.
• Remove rechargeable batteries from the product before charging.
• Rechargeable batteries are only to be charged under adult supervision and follow the battery and charger
manufacturer's instructions.
• Battery replacement should be done in presence of an adult.
• Remove batteries from the product for storage. Batteries may be hot.
• After use, be sure to turn the switch off.
• Remove weak or exhausted batteries from the product.
• Dispose batteries safely and properly, according to your local requirements.
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Save the battery by turning off vehicle when not in use.
WARNING! CHOKING HAZARD
Small parts. Not for Children under 3 years.
IMPORTANT BATTERY SAFETY INFORMATION
CAUTION: TO AVOID BATTERY LEAKAGE:
NOTE: BATTERIES MUST BE RECYCLED OR DISPOSED PROPERLY.
Contact your local area office of solid waste management or other appropriate
local agency for information.
Only operate the product and its accessories when fully assembled and in
accordance with this manual!
C
M
Y
CM
MY
CY
CMY
K
FAR_60065_Rolling Ring_ENG_IM_060815.pdf 3 8/6/15 9:27 am
1.5V AAA
1.5V AAA
1.5V AAA 3
2
1
2
1
ON
OFF
3
4
2
VEHICLE
BATTERY INSTALLATION
TRANSMITTER
1. To remove battery lid, loosen screw to open.
2. Slide open the battery lid in the direction as
shown in the figure, while lightly pressing its center.
3. Insert 1.5V (AAA/LR03) batteries x3 with the
polarity (+/-) as shown on the bottom of battery
compartment. Replace the battery lid, following the
removal procedure in reverse.
NOTE:
There is no on/off switch on the Transmitter. Moving the sticks turns it on automatically.
3
21
ANTENNA ASSEMBLY
1. Insert antenna wire from product into
tube.
2. Slide tube down antenna wire and into
hole in product.
3. Tie knot with any remaining antenna
wire (Do not pull wire tight).
WARNING!
THE ANTENNA IS NOT TO
BE INSERTED INTO SOCKET-OUTLETS!
1. Turn off vehicle.
2. Loosen screw to unlock battery lid.
3. Open battery lid.
4. Insert 1.5V (AA/LR6) batteries x4 into battery
compartment with correct polarity (+/-). Place battery
lid back in position and lock properly.
NOTE:
For best performance, always use
alkaline batteries only. To remove the
batteries, reverse the installation procedure.
C
M
Y
CM
MY
CY
CMY
K
FAR_60065_Rolling Ring_ENG_IM_060815.pdf 4 8/6/15 9:27 am
L R
ON
OFF
3
TURN ON VEHICLE WHEEL ALIGNMENT
FORWARD BACKWARDS
LEFT TURN
- FORWARD
(Push at the same time)
LEFT TURN
- BACKWARD
(Push at the same time)
RIGHT TURN
- BACKWARD
(Push at the same time)
RIGHT TURN
- FORWARD
(Push at the same time)
NOTE:
After play, always turn vehicle off. Remove batteries from controller and R/C vehicle when not in
use or when storing. Leakage may occur and cause damage if left for a long period of time.
OPERATING R/C VEHICLE
C
M
Y
CM
MY
CY
CMY
K
FAR_60065_Rolling Ring_ENG_IM_060815.pdf 5 8/6/15 9:27 am
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
TREAT YOUR R/C VEHICLE WELL
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned to play?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, recharge battery pack and/or replace the
in the R/C vehicle and controller with new alkaline batteries.
4
INTERFERENCE
Other radio signals may cause loss of control.
Remove vehicle from an area of interference.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller
high in the air and direct vehicle back.
Store in safe place. No direct sunlight. No sand or dust.
No Collisions. R/C vehicle may get stuck
on carpet or grass.
Avoid running 2 vehicles with the same radio control
frequencies.
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun!
Avoid heat, sand and high impact crashes!
No rain or water.
C
M
Y
CM
MY
CY
CMY
K
FAR_60065_Rolling Ring_ENG_IM_060815.pdf 6 8/6/15 9:27 am
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURER’S NOTE
ATTENTION PARENTS
www.toystate.com
www.NikkoRC.com
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
66 MODY ROAD, KOWLOON, HONG KONG
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS.
CONSEQUENTLY, PICTURES IN THIS INSTRUCTION
SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
WARNING:
Not suitable for children under 36 months due to
small parts. Choking hazard.
CLEANING AND MAINTAINING
“Modifications not authorized by the manufacturer may void users authority to operate the device.”
5
Brush areas where dirt and
dust get trapped.
Wipe body off with a soft rag
or tact cloth.
Do not clean vehicle with
chemicals or water.
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the userʼs authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
