Toy State 60510R49 DUB Freakz RC 49MHz Rx User Manual 38721 CAT Instr 090204
Toy State International Ltd. DUB Freakz RC 49MHz Rx 38721 CAT Instr 090204
Users Manual
RADIO CONTROL
CONTROL FREAKZ
OWNER’S MANUAL
TM
CONTROLLER
VEHICLE
Batteries Not Included Included
AA
/
LR6
AA
/
LR6
x3 x6
7+
#60510
1
MUTE SWITCH
NOTE: For best performance, always use alkaline batteries only.
CAUTION
Important Battery Information
• Dispose of batteries properly.
• Do not dispose of batteries in fire.
• Use only batteries of the type recommended.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Remove batteries from R/C vehicle and controller if vehicle will not be used for a long
period of time.
BATTERY INSTALLATION
This unit is equipped with a mute switch. Use the mute switch when
“Quiet Time” is needed. It is located on either the controller or the vehicle.
GETTING STARTED
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Save the battery by turning off vehicle when not in use.
ONOFF
Remove the R/C vehicle and controller from the package. Insert batteries into the R/C vehicle and
controller to begin full function play
(see “Battery Installation” section for further details).
ENG
CONTROLLER
1.5v
1.5v
1.5v
1. To remove battery cover, loosen screw
to open.
2. Insert 3 “AA” batteries into the
controller. Be sure the + and – are
properly matched.
R/C VEHICLE
1.5v
1.5v
1.5v
1.5v
1.5v
1.5v
1. To remove battery cover, loosen screw
to open.
2. Insert 6 “AA” batteries into the vehicle.
Be sure the + and – are properly
matched.
Sounds
Turbo
Boost
Turn
Right/Left
Drive
Forward/Reverse
2
After play, always turn vehicle off. Remove batteries from controller and R/C vehicle when not in
use or when storing. Leakage may occur and cause damage if left for a long period of time.
OPERATING R/C VEHICLE
ONOFF
Turns in All Directions!
Adjust Trim Switch on
bottom of R/C vehicle to
ensure precision driving
Turn ON/OFF switch
located on bottom of R/C
vehicle to the ON position
(as shown)
ENG
Win the Race with a Turbo Boost!
Drive Forward
/ Turbo Boost
Sounds Drive
Reverse
TWO GREAT WAYS TO PLAY!
3
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned on?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, replace the batteries in the R/C vehicle
and controller with new alkaline batteries.
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun!
Avoid water, heat, sand and high impact crashes!
TREAT YOUR R/C VEHICLE WELL
Store in safe place. No direct sunlight. No rain or water. No sand or dust.
No Collisions.
R/C vehicle may get stuck on
carpet or grass.
Avoid running 2 vehicles with the same radio control frequencies.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller high in
the air and direct vehicle back.
INTERFERENCE
Other radio signals may cause loss of control. Remove
vehicle from an area of interference.
ENG
4
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
1 PEKING ROAD, KOWLOON, HONG KONG
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS.
CONSEQUENTLY, PICTURES IN THIS INSTRUCTION SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
www.toystate.com
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1). This device may not cause harmful interference.
2). This device must accept any interference received including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment. Note: this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These Limits are designed to provide reasonable protection against harmful interference in a residential installation. This
generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on , the user is
encouraged to try and correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
This radiocommunication device complies with all the requirements of Industry Canada Standard RSS-310.
Operation is subject to the follwing two conditions: 1). This device may not cause harmful interference. 2). This device must accept any
interference received, including interference that may cause undesired operation.
Field Strength and measurement distance: 27.195MHz - 60.49 dBµ V/m at 3 meter. 49.890MHz - 61.61 dBdB V/m at 3 meter.
This device complies with the limits of standard RSS-310 issue 1.
INDUSTRY CANADA NOTICE: CANADA ONLY
“Modifications not authorized by the manufacturer may void users authority to operate the device.”
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURER’S NOTE
ATTENTION PARENTS
CLEANING AND MAINTAINING
Brush areas where dirt and dust
get trapped.
Wipe body off with a soft rag or
tact cloth.
Do not clean vehicle with
chemicals or water.
ENG
General Motors Trademarks used under
license to Toy State Industrial.
Ford Oval and nameplates are registered trademarks
owned and licensed by Ford Motor Company.
Manufactured by Toy State Industrial Ltd.
www.ford.com
"DUB," "DUB Edition," "DUB Garage" and their logos are trademarks or registered trademarks of
DUB Publishing, Inc. in the United States and/or other countries and are used under license.
www.toystate.com
