Toy State 62070F27 Top Secret R/C User Manual

Toy State International Ltd. Top Secret R/C

User Manual

AAA/LR03
AA
/
LR6
LR44
AG13
LR14
x5
AAA
/
LR03
AA
/
LR6
BUTTON
CELL
LR44
AG13
LR14
/
62070_007_IM_070215.indd 1 2/7/15 3:39 pm
1,5V
1,5V
1,5V
1,5V
1,5V
1,5V
1,5V
1,5V
NOTE: For best performance, always use alkaline batteries only.
CAUTION
Important Battery Information
• Dispose of batteries properly.
• Donotdisposeofbatteriesinre.
• Use only batteries of the type recommended.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Remove batteries from R/C vehicle and controller if vehicle will not be used for a long
period of time.
BATTERY INSTALLATION
GETTING STARTED
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Savethebatteriesbyturningovehiclewhennotinuse.
Remove the R/C vehicle and controller from the package. Insert batteries into the R/C vehicle and
controller to begin full function play
(see “Battery Installation” section for further details).
CONTROLLER
1. To remove battery cover, loosen screw
to open.
2. Insert 3 “AAA” batteries into the
controller. Be sure the + and – are
properly matched.
R/C VEHICLE
1. To remove battery cover, loosen screw
to open.
2. Insert 5 “AA” batteries into the vehicle.
Be sure the + and – are properly
matched.
ON OFF
ON OFF
PLAYDEMO OFF
PLAYDEMO OFF
1,5V
1,5V
1,5V
1,5V
1,5V
1,5V
1,5V
1,5V
62070_007_IM_070215.indd 2 2/7/15 3:39 pm
1. Insert antenna wire from product into
tube.
2. Slide tube down antenna wire and into
hole in product.
3. Tie knot with any remaining antenna
wire (Do not pull wire tight).
WARNING! THE ANTENNA IS NOT TO BE
INSERTED INTO SOCKET OUTLETS!
Afterplay,alwaysturnR/Cvehicleo.
Remove batteries from controller and vehicle when not in use or when storing.
Leakage may occur and cause damage if left for a long period of time.
ANTENNA ASSEMBLY
OPERATING R/C VEHICLE
Forward and Reverse Action! Vehicles are on separate channels
allowing you to race or chase
your friends!
Turns In All Directions!
ON OFF
ON OFF
PLAYDEMO OFF
PLAYDEMO OFF
Adjust Trim Switch on
bottom of R/C vehicle to
ensure precision driving.
Toggle OFF/ON switch
located on bottom of R/C
vehicle to the ON position.
Drive
Forward/Reverse
Music
Turn
Left/Right
3
21
62070_007_IM_070215.indd 3 2/7/15 3:39 pm
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned on?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, replace the batteries in the R/C vehicle
and controller with new alkaline batteries.
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun!
Avoid water, heat, sand and high impact crashes!
TREAT YOUR R/C VEHICLE WELL
Store in safe place. No direct sunlight. No rain or water. No sand or dust.
No Collisions.
R/C vehicle may get stuck on
carpet or grass.
Avoid running 2 vehicles with the same radio control frequencies.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller high in
the air and direct vehicle back.
INTERFERENCE
Other radio signals may cause loss of control. Remove
vehicle from an area of interference.
62070_007_IM_070215.indd 4 2/7/15 3:39 pm
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS.
CONSEQUENTLY, PICTURES IN THIS INSTRUCTION SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1). This device may not cause harmful interference.
2). This device must accept any interference received including interference that may cause undesired operation.
Warning: Changes or to this unit not expressly approved by the party responsible for compliance could void the userʼs authority
to operate the equipment. Note: this equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These Limits are designed to provide reasonable protection against harmful interference in a residential installation.
This
equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment and on, the
user is encouraged to try and correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
not authorized by the manufacturer may void users authority to operate the device.”
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURERʼS NOTE
ATTENTION PARENTS
CLEANING AND MAINTAINING
Brush areas where dirt and dust
get trapped.
Wipe body with a soft rag or
tact cloth.
Do not clean vehicle with
chemicals or water.
WARNING: Not suitable for children
under 36 months due to small parts.
Choking hazard.
www.toystate.com
www.nikkorc.com
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
66 MODY ROAD, KOWLOON, HONG KONG
62070_007_IM_070215.indd 5 2/7/15 3:39 pm
www.toystate.com
Aston Martin, the Aston Martin Wings logo and the model
names DBS and DB10 are trademarks owned, licensed or
used by Aston Martin Lagonda Limited. All rights reserved.
and related James Bond Trademarks © 1962-2015
Danjaq, LLC and United Artists Corporation.
and related James Bond Trademarks are trademarks
of Danjaq, LLC. QUANTUM OF SOLACE © 2008
Metro-Goldwyn-Mayer Studios Inc. and Danjaq, LLC.
SPECTRE © 2015 Danjaq, LLC, Metro-Goldwyn-Mayer
Studios Inc., and Columbia Pictures Industries, Inc.
2015 © EON Productions Limited and Danjaq, LLC.
All rights reserved.
62070_007_IM_070215.indd 6 2/7/15 3:39 pm
