Toy State 91810F27 Master Blaster RC Turbo Turret User Manual

Toy State International Ltd. Master Blaster RC Turbo Turret

User Manual

RADIO CONTROL
MASTER BLASTER
6+
#91810
x4x2
CONTROLLER
BATTERIES NOT INCLUDED BATTERIES NOT INCLUDED
VEHICLE
OWNER’S MANUAL
91810_HW15_IM_111414.indd 1 15/12/14 1:50 pm
2
ENG
OPERATING R/C VEHICLE
NOTE: For best performance, always use alkaline batteries only.
CAUTION
Important Battery Information
• Dispose of batteries properly.
• Donotdisposeofbatteriesinre.
• Use only batteries of the type recommended.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Remove batteries from R/C vehicle and controller if vehicle will not be used for a long
period of time.
BATTERY INSTALLATION
GETTING STARTED
Remove the R/C vehicle and controller from the package.Insert batteries into the controller
to begin full function play
(see “Battery Installation” section for further details).
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Savethebatteriesbyturningovehicleandcontroller
when not in use.
ONOFF
IO
ONOFF
IO
1,5V
1,5V
1,5V
1,5V
LOOSEN
SCREW
TO OPEN
ONOFF
IO
ONOFF
IO
Turn
O
/
I
switch located on bottom of R/C vehicle to the
I
position (as shown).
1. To remove battery cover, loosen screw
to open.
2. Insert 2 “AA” batteries into the
controller. Be sure the + and – are
properly matched.
1. To remove battery cover, loosen screw
to open.
2. Insert 4 “AA” batteries into the vehicle.
Be sure the + and – are properly
matched.
CONTROLLER
V
EHICLE
91810_HW15_IM_111414.indd 2 15/12/14 1:50 pm
3
ENG
Afterplay,alwaysturnvehicleo.RemovebatteriesfromcontrollerandR/Cvehiclewhennotin
use or when storing. Leakage may occur and cause damage if left for a long period of time.
Drive Forward
& Reverse
Turn Left
& Right
Turns In All Directions!
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full operational control may be lost. Hold controller high in the air and direct
vehicle back.
INTERFERENCE
Other radio signals may cause loss of control. Remove vehicle from an area of interference.
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned on?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, replace the batteries in the R/C vehicle
and controller with new alkaline batteries.
91810_HW15_IM_111414.indd 3 15/12/14 1:50 pm
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun! Avoid water, heat,
sand and high impact crashes!
TREAT YOUR R/C VEHICLE WELL
• Store in safe place. • No direct sunlight. • No rain or water. • No sand or dust.
• No Collisions.
• R/C vehicle may get stuck on
carpet or grass.
• Avoid running 2 vehicles with the same radio control frequencies.
CLEANING AND MAINTAINING
• Brush areas where dirt and dust
get trapped.
•Wipebodyowithasoftragor
tact cloth.
• Do not clean vehicle with
chemicals or water.
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Warning:Changesormodicationstothisunitnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser’s
authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferenceby
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.
- Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
“Modicationsnotauthorizedbythemanufacturermayvoidusersauthoritytooperatethedevice.”
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURER’SNOTE
ATTENTION PARENTS
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
www.toystate.com
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
66 MODY ROAD, KOWLOON, HONG KONG
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS.
CONSEQUENTLY, PICTURES IN THIS INSTRUCTION SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
WARNING: Not suitable for children under 36 months
due to small parts. Choking hazard.
HOT WHEELS and associated trademarks and
trade dress are owned by, and used under license
from Mattel. ©2014 Mattel. All Rights Reserved.
91810_HW15_IM_111414.indd 4 15/12/14 1:50 pm
