Toy State 94140R49 NANO VAPORIZR 2 User Manual FAR 94140 Nikko IM ENG 032615
Toy State International Ltd. NANO VAPORIZR 2 FAR 94140 Nikko IM ENG 032615
User Manual
x3 x4
8+
#94140
CONTROLLER VEHICLE
Important! Carefully read the Owners Manual before play!
BATTERIES NOT INCLUDED BATTERIES NOT INCLUDED
GETTING STARTED
Remove the R/C vehicle and controller from the package. Insert batteries into the controller
to begin full function play
(see “Battery Installation” section for further details).
Important Battery Information
• Dispose of batteries properly.
• Do not dispose of batteries in fire.
• Use only batteries of the type recommended.
• Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Remove batteries from R/C vehicle and controller if vehicle will not be used for a long period of time.
This product and its accessorries are not suitable for children under the age of 36 months, because of small
parts that can be swallowed.
Intended for children age 8 and older.
Adult supervision strongly recommended.
Drive your vehicle in a safe area away from people, pets, cars, etc.
Do not drive on streets or after dark.
Do not touch or try to pick up the vehicle when it is in motion. Wait until it has stopped completely.
Keep hair, fingers, face and loose clothing away from front and rear wheels while the vehicle is switched on or
while the transmitter is operating.
Do not drive the vehicle toward walls or other hard objects.
Be a responsible operator!
Do not drop or give impact to the product and its accessories.
Check if a near transmitter produces interference or signals with the same frequency. In such a case, move to
another location or try again after a while.
Never attempt to disassemble or modify the product or its accessories.
Regularly inspect the antennas for cracks or breaks. Do not bend the transmitter antenna. Do not use the
transmitter if the antenna is broken.
The vehicle wire antenna is fragile. Never pull or tug on the antenna, as it may loosen or detach from the
vehicle.
Use extra caution when playing near water or ice.
Intended to be used on land and in water.
Do not use the product in salt water or water with strong currents.
WARNING! CHOKING HAZARD
Small parts. Not for Children under 3 years.
Only operate the product and its accessories when fully
assembled and in accordance with this manual!
Insert antenna
wire from product
into tube
Tie knot with any
remaining antenna wire
(Do not pull wire tight)
Slide tube down
antenna wire and into
hole in product
CAUTION
ANTENNA ASSEMBLY
1
EN
2
EN
BATTERY INSTALLATION
CONTROLLER
1. To remove battery cover, loosen screw to open.
2. Insert 3 “AAA” batteries into the controller.
Be sure the + and – are properly matched.
R/C VEHICLE
NOTE:
For best performance, always use alkaline batteries only.
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Save the battery by turning off vehicle when not in use.
ONOFF
ONOFF
1,5V
1,5V
1,5V
1,5V
3
4
1,5V
6
5
ONOFF
ONOFF
PLA
Y
DEMO OFF
PLA
Y
DEMO OFF
2
1
Unscrew the vehicle's
top cover and
remove it as
shown in
the illustration.
Unscrew the battery
cover and open it.
Insert 4xAA batteries
and pay attention to place
them with the correct
polarity (+/-).
Open
Open
3EN
OPERATING R/C VEHICLE
RIGHT TURN
(FORWARD) (Push left stick forward)
LEFT TURN
(BACKWARDS) (Pull left stick backwards)
FORWARD
(Push both sticks forward)
BACKWARDS
(Pull both sticks backwards)
RIGHT SPIN
(At the same time, pull right stick back and
push left stick forward)
LEFT SPIN
(At the same time, pull left stick back and
push right stick forward)
LEFT TURN
(FORWARD) (Push right stick forward)
RIGHT TURN
(BACKWARDS) (Pull right stick backwards)
After play, always turn vehicle off. Remove batteries from controller
and R/C vehicle when not in use or when storing. Leakage may occur
and cause damage if left for a long period of time.
This vehicle can run on land and in water but it is not fully water-proof!
Immersing it into water may lead to a malfunction. Dry vehicle well after
operating in water.
Adult supervision is strongly recommended when playing near water.
Do not drive your vehicle in the sea and wavy water surface, or where a
rapid current flows. Stay away from areas where waves rise due to a
strong wind. Also avoid driving on dirty water surface or where
waterweed grows dense, this can cause a malfunction. Operate your
vehicle in water with due care to the distance and battery life, since you
need to get the vehicle back before the power of the batteries is
drained.
Radio waves control the R/C vehicle. Care for your vehicle and it will provide hours of fun!
No Collisions. R/C vehicle may get stuck on
carpet or grass.
Avoid running 2 vehicles with the same radio control frequencies.
Store in safe place. No direct sunlight. No sand or dust.
4
EN
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
INTERFERENCE
Other radio signals may cause loss of control.
Remove vehicle from an area of interference.
SAFETY CIRCUIT
TREAT YOUR R/C VEHICLE WELL
R/C VEHICLE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned to play?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
Check batteries. If necessary, replace the batteries in the R/C
vehicle and controller with new alkaline batteries.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller
high in the air and direct vehicle back.
DOES NOT MOVE
Avoid heat, sand and high impact crashes!
During use, the internal power in the electric circuit can get quite high (for example during a 360 spin).
In such a case a safety circuit will shut down the vehicle for approximately 10-15 seconds. During this period the car will
not respond to signals from the transmitter. This is not a defect but a safety measure to protect the electronic circuits.
After this period, the car will resume normal operation.
OR FAILS TO RUN
5EN
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Consult the dealer or an experienced radio/TV technician for help.
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURER’S NOTE
ATTENTION PARENTS
For questions, e-mail our Consumer Service Dept.at
consumerservice@toystate.com
Or Call 1-877-473-8015
www.toystate.com
www.NikkoRC.com
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
66 MODY ROAD, KOWLOON, HONG KONG
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS.
CONSEQUENTLY, PICTURES IN THIS INSTRUCTION
SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
WARNING:
Not suitable for children under 36 months due to
small parts. Choking hazard.
CLEANING AND MAINTAINING
Brush areas where dirt and dust get
trapped.
Wipe body off with a soft rag or tact
cloth. Do not clean vehicle with chemicals.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the userʼs
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
“Modifications not authorized by the manufacturer may void users authority to operate the device.”
