Toy State 94146F27 AQUASPLIT User Manual FAR 94146 AquaSplit ENG IM 042915
Toy State International Ltd. AQUASPLIT FAR 94146 AquaSplit ENG IM 042915
User Manual
8+
#94146
Important! Carefully read the Owners Manual before play!
x3 x4
CONTROLLER VEHICLE
BATTERIES NOT INCLUDED BATTERIES NOT INCLUDED
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 1 30/4/15 9:01 am
WARNING! CHOKING HAZARD
Small parts. Not for Children under 3 years.
PRECAUTION
1
• This product and its accessories are not suitable for children under the age of 36 months, because of small
parts that can be swallowed.
• Intended for children age 8 and older.
• Adult supervision strongly recommended.
• Drive your vehicle in a safe area away from people, pets, cars, etc.
• Do not drive after dark.
• Do not touch or try to pick up the vehicle when it is in motion. Wait until it has stopped completely.
• Keep hair, fingers, face and loose clothing away from vehicle wheels/rotors/propellers/motors while the
vehicle is switched on or while the transmitter is operating.
• Do not drive the vehicle toward walls or other hard objects.
• Be a responsible operator!
• Do not drop or give impact to the product and its accessories.
• Check if a near transmitter produces interference or signals with the same frequency. In such a case, move
to another location or try again after a while.
• Never attempt to disassemble or modify the product or its accessories.
• Regularly inspect the antennas for cracks or breaks. Do not bend the transmitter antenna. Do not use the
transmitter if the antenna is broken.
• The vehicle wire antenna is fragile. Never pull or tug on the antenna, as it may loosen or detach from the
vehicle. Never coil the antenna.
• Use extra caution when playing near water or ice.
• Do not use the product in salt water or water with strong currents.
• Do not drive your vehicle on streets or in a crowded place.
• When the batteries gets wet, dry completely before storing it.
• Do not store the vehicle in a place near a heater or where temperature rises. After use, remove the batteries
from the transmitter and vehicle to store.
• This vehicle can run in water but it is not fully water-proof! Immersing it into water may lead to a
malfunction.
• Dry vehicle well after operating in water.
• Adult supervision is strongly recommended when playing near water. Do not drive your vehicle in the sea
and wavy water surface, or where a rapid current flows. Stay away from areas where waves rise due to a
strong wind. Also avoid driving on dirty water surface or where waterweed grows dense, this can cause a
malfunction.
• Operate your vehicle in water with due care to the distance and battery life, since you need to get the vehicle
back before the battery power runs out.
• Donʼt play outdoors during thunderstorms.
• The boat shall not be operated in water without battery compartment cover.
• The toy is to be operated in water only when fully assembled in accordance with the instructions.
• If water has entered the body, remove at your earliest convenience.
Only operate the product and its accessories when fully assembled and in
accordance with this manual!
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 2 30/4/15 9:01 am
BATTERIES
2
IMPORTANT BATTERY SAFETY INFORMATION
CAUTION: TO AVOID BATTERY LEAKAGE:
• Make sure the batteries are inserted with correct polarity and follow the toy and battery manufacturer's
instructions.
• Use only battery type(s) recommended.
• Do not attempt to short-circuit, charge, disassemble or heat batteries.
• Do not dispose of batteries in fire or make them wet.
• Do not mix or use new and old batteries together.
• Do not mix or use different types of batteries together.
• Non-rechargeable batteries are not to be recharged because of the danger of eruption.
• Remove rechargeable batteries from the product before charging.
• Rechargeable batteries are only to be charged under adult supervision and follow the battery and charger
manufacturer's instructions.
• Battery replacement should be done in presence of an adult.
• Remove batteries from the product for storage. Batteries may be hot.
• After use, be sure to turn the switch off.
• Remove weak or exhausted batteries from the product.
• Dispose batteries safely and properly, according to your local requirements.
NOTE: BATTERIES MUST BE RECYCLED OR DISPOSED PROPERLY.
Contact your local area office of solid waste management or other appropriate
local agency for information.
WARNING!
THE ANTENNA IS NOT TO BE INSERTED INTO SOCKET-OUTLETS!
123
ANTENNA ASSEMBLY
1. Insert antenna wire from product into tube.
2. Slide tube down antenna wire and into hole
in product.
3. Tie knot with any remaining antenna wire
(Do not pull wire tight).
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 3 30/4/15 9:01 am
3
2
1
ON OFF
3
1.5V AAA
1.5V AAA
1.5V AAA
2
4
1
VEHICLE
3
1. Turn off vehicle.
2. Loosen screw to open battery lid.
3. Remove battery lid.
4. Insert 1.5V (AA/LR6) batteries x4
into battery compartment with
correct polarity (+/-). Place
battery lid back in position and
lock properly.
BATTERY INSTALLATION
1. To remove battery lid, loosen screw to open.
2. Slide open the battery lid in the direction as
shown in the figure, while lightly pressing its center.
3. Insert 1.5V (AAA/LR03) batteres x3 with the
polarity (+/-) as shown on the bottom of battery
compartment. Replace the battery lid, following the
removal procedure in reverse.
TRANSMITTER
STRONG BATTERY MEANS OPTIMUM PERFORMANCE
Save the battery by turning off vehicle when not in use.
NOTE:
There is no on/off switch on the Transmitter.
Moving the sticks turns it on automatically.
NOTE:
For best performance, always use alkaline
batteries only. To remove the batteries, reverse
the installation procedure.
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 4 30/4/15 9:01 am
OPERATING R/C VEHICLE
4
TURN VEHICLE
POWER ON
FORWARD BACKWARDS
LEFT TURN
- FORWARD
(Push at the same time)
LEFT TURN
- BACKWARD
(Push at the same time)
RIGHT TURN
- BACKWARD
(Push at the same time)
RIGHT TURN
- FORWARD
(Push at the same time)
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 5 30/4/15 9:01 am
VEHICLE ALIGNMENT
AFTER PLAYING
IMPORTANT SAFETY FEATURE
5
NOTE:
After playing, always turn vehicle off. Remove batteries from controller and R/C vehicle when not in use or
when storing. Mositure will cause damage to radio device and motors. Leakage may occur and cause damage if left
for a long period of time. If the control distance becomes noticeably short, or if the vehicle goes out of control, or
does not move properly, replace the batteries with new ones.
CAUTION:
After playing, remove all batteries from the boat and the transmitter, drain the water out of the hull,
and dry the boat well before storing. If water has entered the body, remove at your earliest convenience.
CAUTION!
This boat is designed so that the propeller will only work once the boat has been placed in water.
This is to prevent your hands from getting injured by the turning propeller when holding the boat.
CAUTION:
Keep out of reach of small children under 36 months old as there is danger of getting hurt.
Do not let children touch the screw (propeller) when it is spinning as there is danger of getting hurt.
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 6 30/4/15 9:01 am
6
TROUBLESHOOTING AND CARE FOR R/C VEHICLE
TREAT YOUR R/C VEHICLE WELL
R/C VEHICLE
DOES NOT MOVE
• Are the + and – contacts correctly matched in the controller?
• Are the metal contact tabs touching, rusty or dirty in controller?
• Are there batteries in the vehicle and controller?
• Is the power switch turned to play?
• Are the batteries weak or out of power?
R/C VEHICLE
MOVES BY ITSELF
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
R/C VEHICLE
RUNS SLOWLY
• There is radio interference in the area.
• Another R/C vehicle with the same frequency is close by.
• Are the batteries weak or out of power?
PERFORMANCE DROP,
INCONSISTENT MOVEMENT
OR FAILS TO RUN
Check batteries. If necessary, recharge battery pack and/or replace the
batteries in the R/C vehicle and controller with new alkaline batteries.
INTERFERENCE
Other radio signals may cause loss of control.
Remove vehicle from an area of interference.
LIMITED RADIO CONTROL RANGE
While R/C vehicle may be visible at a distance, full
operational control may be lost. Hold controller
high in the air and direct vehicle back.
Store in safe place. No direct sunlight. No Collisions.
Avoid running 2 vehicles with the same radio control
frequencies.
• Radio waves control the R/C vehicle. Care for your vehicle and it will provide
hours of fun! Avoid heat, sand and high impact crashes!
C
M
Y
CM
MY
CY
CMY
K
FAR_94146_AquaSplit_ENG_IM_042915.pdf 7 30/4/15 9:01 am
7
FEDERAL COMMUNICATIONS COMMISSION COMPLIANCE
This toy and all accessories need to be periodically examined for potential hazards and any
potentially hazardous parts be repaired or replaced.
MANUFACTURER’S NOTE
ATTENTION PARENTS
www.toystate.com
www.NikkoRC.com
For questions, e-mail our Consumer Service Dept. at
consumerservice@toystate.com
Or Call 1-877-473-8015
MADE IN SHENZHEN, CHINA
TOY STATE INTERNATIONAL LIMITED
66 MODY ROAD, KOWLOON, HONG KONG
WARNING:
Not suitable for children under 36 months due to
small parts. Choking hazard.
CLEANING AND MAINTAINING
“Modifications not authorized by the manufacturer may void users authority to operate the device.”
Brush areas where dirt and
dust get trapped.
Wipe body off with a soft rag
or tact cloth.
Do not clean vehicle with
chemicals or water.
NOTE:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void
the userʼs authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
IN THE INTEREST OF BETTER QUALITY AND VALUE, WE ARE CONSTANTLY IMPROVING AND UPDATING OUR PRODUCTS.
CONSEQUENTLY, PICTURES IN THIS INSTRUCTION
SHEET MAY SOMETIMES DIFFER FROM THE MODEL ENCLOSED.
