WARRANTY &

MAINTENANCE GUIDE

CAMRY

2017

T

hank you for purchasing a Toyota

vehicle. We know you have many

options when considering which

vehicle to buy, and we appreciate your

decision to select Toyota.

We want you to enjoy owning your Toyota

as much as you enjoy driving it. This

booklet is designed to help. Here you’ll

find information on Toyota’s warranty

coverage and maintenance

recommendations for your vehicle. There

are two easy-to-follow sections: one for

warranty and one for maintenance. The tab

on the side of each page identifies the

section you are in.

For more information about our vehicles,

our company or the products and services

available for your vehicle, please visit

Toyota’s official Web site,

www.toyota.com.

We wish you many miles of safe and

pleasurable driving, and we look forward

to serving you in the years ahead.

Welcome to the Toyota family!

Welcome to the Toyota Family

1

WARRANTY INFORMATION

Introduction

Satisfaction Down the Road 4

If You Need Assistance 5

The Immobilizer Key 7

Transportation Assistance 9

Your Warranties in Detail

General Warranty Provisions 10

New Vehicle Limited Warranty 13

Federal Emission Control Warranty 17

California Emission Control Warranty 23

Tire Limited Warranty 29

Your Responsibilities

Operation and Maintenance 30

Obtaining Warranty Service 32

Table of Contents

2

MAINTENANCE INFORMATION

Introduction

The Importance of Scheduled Maintenance 34

Maintaining Your Warranty 35

Maintenance Log

Using the Maintenance Log Charts 36

Maintenance Log 38

Explanation of Maintenance Items 54

Vehicle Identification 58

Table of Contents

3

A

t Toyota, our top priority is always

our customers. We know your

Toyota is an important part of your

life and something you depend on every

day. That’s why we’re dedicated to building

products of the highest quality and

reliability.

Our excellent warranty coverage is

evidence that we stand behind the quality

of our vehicles. We’re confident — as you

should be — that your Toyota will provide

you with many years of enjoyable driving.

To further demonstrate our commitment to

our customers’ satisfaction, occasionally

we may establish a special policy

adjustment to pay for specific repairs that

are no longer covered by warranty. When

we establish such a policy adjustment, we

mail details to all applicable owners we

have on record. That’s why it’s important

to send in the card at the back of this

booklet if you change your address or if

you’ve purchased this vehicle from a

previous owner.

To provide you with added protection

against unexpected service costs, we offer

Toyota Financial Services vehicle service

agreements and Toyota Auto Care and

Toyota Care Plus pre-paid maintenance

programs. Each offers plans to meet a

wide variety of needs. Your dealership can

help you select the plan that’s best for

you.

Our goal is for every Toyota customer to

enjoy outstanding quality, dependability

and peace of mind throughout their

ownership experience. We want you to be

a satisfied member of the Toyota family

for many miles to come.

This booklet describes the terms of

Toyota warranty coverage as well as

general owner responsibilities. The

scheduled maintenance section

describes your vehicle’s maintenance

requirements. Be sure to review this

information carefully, since proper

maintenance is required to ensure that

warranty coverage remains intact.

All information in this booklet is the latest

available at the time of publication and is

subject to change without notice.

Satisfaction Down the Road

INTRODUCTION

Introduction

4

B

oth Toyota and your Toyota dealer

are dedicated to serving your

automotive needs. Your complete

satisfaction is our first priority. Should you

have a problem or concern — either

during or after the warranty period —

please take the following steps to ensure

the quickest possible response:

Step 1

Discuss the situation with a dealership

manager, such as the service manager or

customer relations manager. In most

cases, a satisfactory solution can be

reached at this step.

Step 2

If the dealership does not address your

concern to your satisfaction, call the

Toyota Customer Experience Center at

(800) 331-4331.

Please have the following information

ready when you call:

•

Your Toyota’s vehicle identification

number (located on the driver’s side

corner of the dashboard, under the

window)

•

Current mileage on your vehicle

•

Name of your Toyota dealership

A Toyota customer relations representative

will assist you in working with the

dealership to find a satisfactory solution.

Step 3

If your concern has still not been resolved

to your satisfaction, Toyota offers

additional assistance through the Dispute

Settlement Program, a dispute resolution

program administered by the National

Center for Dispute Settlement. The

purpose of the Dispute Settlement

Program is to resolve disputes through

arbitration — a process by which two

parties authorize an independent third

party to hear and resolve a dispute. The

program is informal and free of charge. To

request that your case be reviewed

through the program, complete the

customer claim form in the

Owner’s

Warranty Rights Notification

booklet

(found in your glove box) and mail it to:

National Center for Dispute Settlement

P.O. Box 688

Mt. Clemens, MI 48046

If you would like to request a customer

claim form, call the Toyota Customer

Experience Center at (800) 331-4331.

When you call, please have your vehicle

identification number, the current mileage

on your Toyota and the names of your

selling and servicing dealerships.

If You Need Assistance

INTRODUCTION

Introduction

5

California residents: Toyota offers your

assistance through an informal dispute

settlement program called the California

Dispute Settlement Program (CDSP). A

brochure about the program is found in

your glove box. For additional information,

call the Toyota Customer Experience

Center at (800) 331-4331. You may also

contact the CDSP directly at (888)

300-6237. Failure to use the CDSP may

affect your rights and remedies under

California’s “Lemon Laws.”

This information about the Dispute

Settlement Programs is correct as of the

date of printing. However, the programs

may be changed without notice. For the

most current information about the

programs, call the Toyota Customer

Experience Center at (800) 331-4331.

If You Need Assistance

INTRODUCTION

Introduction

6

THE NEW WORLD OF

ANTI-THEFT TECHNOLOGY

This Toyota vehicle may be equipped with

an electronic “immobilizer” anti-theft

system. When the key is inserted into the

ignition switch it transmits an electronic

code to an immobilizer computer. The

engine will only start if the code in the key

matches the code in the immobilizer. If the

code does not match, the immobilizer

disables the ignition and fuel systems.

While an exact physical copy of the key

will open the door and allow retrieval of

items locked in the vehicle, it won’t start

the vehicle unless the key has the same

code as the immobilizer.

SECURITY

For security purposes, access to key

codes and service procedures for

electronically registering replacement keys

is restricted. Only a Toyota dealer or

certain bonded/registered independent

locksmiths can generate replacement keys.

The Immobilizer Key

INTRODUCTION

Introduction

7

REPLACING THE KEY

Upon purchase, each vehicle should have

two master keys and an aluminum tag

with a key-code imprinted on it.

To generate a fully functional replacement

key (one that will both open the doors and

start the engine), one of the master keys

is required. To make a key that will open

the door for retrieval of items locked

inside the vehicle, the aluminum key-code

tag can be used. If a master key or the

aluminum key-code tag is not available, a

Toyota dealer or certain registered

locksmiths can obtain the key code from a

restricted-access database. These

businesses can also access a service

utility to reprogram the immobilizer if all

registered master keys have been lost. If a

Toyota dealer is not available, please refer

to www.aloa.org to find a

bonded/registered locksmith who performs

high security key service.

KEEPING THE KEY SAFE

Replacing an immobilizer key may be

costly. It is advisable to keep a spare

master key and the aluminum key-code

tag in a safe place. If you record the

key-code in more than one place, do not

record it in a way that can be easily

identified and associated with the vehicle.

It is wise to keep a copy of the key-code

outside of the vehicle.

If the vehicle was delivered with less than

two keys and the aluminum key-code tag,

consider having the Toyota dealer or a

qualified independent automotive

locksmith make a duplicate key before you

need it.

The Immobilizer Key

INTRODUCTION

Introduction

8

W

e realize that your confidence in

the quality and reliability of our

products was a key factor in

your decision to buy a Toyota. We also

know how disruptive the loss of

transportation can be to your daily routine.

That’s why we’re pleased to offer you the

benefits of our Transportation Assistance

Policy.

Under this policy, you are eligible for

transportation assistance if your Toyota

must be kept overnight for

warranty-covered repairs. The policy

applies when your vehicle must be kept

overnight for any of the following reasons:

•

The warranty repairs will take longer

than one day to complete.

•

The warrantable condition requires

extensive diagnosis.

•

The parts needed for the warranty

repairs are not readily available and

your vehicle is inoperative or unsafe to

drive.

The policy does not apply when warranty

repairs can be completed in one day but

the vehicle must be kept overnight due to

dealer or owner scheduling conflicts.

The Transportation Assistance Policy

applies for the duration of the New Vehicle

Limited Warranty. The policy applies to all

2017 model-year Toyotas sold and

serviced by authorized Toyota dealerships

in the mainland United States and Alaska.

For further details, please consult your

Toyota dealer.

Transportation Assistance

INTRODUCTION

Introduction

9

Important: You must use the Dispute

Settlement Program (or, in California,

the CDSP) before seeking remedies

through a court action pursuant to the

Magnuson-Moss Warranty Act (the

“Act”). However, if you choose to

pursue rights and remedies not created

by the Act, you are not required to use

the Dispute Settlement Program

(CDSP). You may also be required to

use the Dispute Settlement Program or

CDSP before seeking remedies under

the “Lemon Laws” of your state. Please

check this booklet and the appropriate

page of the

Owner’s Warranty Rights

Notification

booklet for additional

information and the requirements

applicable to your state.

Who Is the Warrantor

The warrantor for these limited warranties

is Toyota Motor Sales, U.S.A., Inc.

(⬙Toyota⬙), a California corporation, c/o

Toyota Motor North America, Inc., P.O.

Box 259001, Plano, Texas 75025-9001.

Which Vehicles Are Covered

These warranties apply to all 2017 model

year Camry vehicles distributed by Toyota

that are originally sold by an authorized

dealer in the United States and normally

operated or touring in the United States,

U.S. territories or Canada. Warranty

coverage is automatically transferred at no

cost to subsequent vehicle owners.

Multiple Warranty Conditions

This booklet contains warranty terms and

conditions that may vary depending on the

part covered. A warranty for specific parts

or systems, such as the Powertrain

Warranty or Emission Performance

Warranty, is governed by the coverage set

forth in that warranty as well as the

General Warranty Provisions.

When Warranty Begins

The warranty period begins on the

vehicle’s in-service date, which is the first

date the vehicle is either delivered to an

ultimate purchaser, leased, or used as a

company car or demonstrator.

Repairs Made at No Charge

Repairs and adjustments covered by these

warranties are made at no charge for parts

and labor.

Parts Replacement

Any needed parts replacement will be

made using new or remanufactured parts.

The decision whether a part should be

repaired or replaced will be made by the

servicing Toyota dealership and/or Toyota.

Parts scheduled to be replaced as required

maintenance are warranted until their first

replacement only.

General Warranty Provisions

WARRANTY

Your Warranties in Detail

10

Informal Dispute Settlement

Program

Toyota offers assistance through an

informal dispute settlement program called

the Dispute Settlement Program. This

program is administered by an

independent third party:

National Center for Dispute Settlement

P.O. Box 688

Mt. Clemens, MI 48046

Further information about this program

can be found in this booklet and the

Owner’s Warranty Rights Notification

booklet.

California residents: Toyota offers you

assistance through an informal dispute

settlement program called the California

Dispute Settlement Program (CDSP). A

brochure about the program is found in

your glove box. For additional information,

call the Toyota Customer Experience

Center at (800) 331-4331. You may also

contact the CDSP directly at (888)

300-6237. Failure to use the CDSP may

affect your rights and remedies under

California’s “Lemon Laws.”

Limitations

The performance of necessary repairs and

adjustments is the exclusive remedy under

these warranties or any implied warranties.

Toyota does not authorize any person to

create for it any other obligation or liability

in connection with this vehicle.

Any implied warranty of merchantability

or fitness for a particular purpose is

limited to the duration of these written

warranties. Some states do not allow

restrictions on how long an implied

warranty lasts, so this limitation may not

apply to you.

Your Rights Under State Law

These warranties give you specific legal

rights. You may also have other rights that

vary from state to state.

General Warranty Provisions

WARRANTY

Your Warranties in Detail

11

WARRANTY COVERAGE AT A GLANCE

Specific components may have longer coverage under terms of the Powertrain Warranty.

Also applies to Connecticut, Delaware, Maine, Maryland, Massachusetts, New Jersey, New York, Oregon,

Pennsylvania, Rhode Island, Vermont and Washington vehicles equipped with a California Certified

Emission Control System. Vehicles covered by this warranty are also covered by the Federal Emission Control Warranty.

General Warranty Provisions

WARRANTY

Your Warranties in Detail

12

WHAT IS COVERED AND

HOW LONG

Basic Warranty

This warranty covers repairs and

adjustments needed to correct defects in

materials or workmanship of any part

supplied by Toyota, subject to the

exceptions indicated under “What Is Not

Covered” on pages 14-15.

Coverage is for 36 months or

36,000 miles, whichever occurs first, with

the exception of wheel alignment and

wheel balancing, which are covered for

12 months or 12,000 miles, whichever

occurs first.

Powertrain Warranty

This warranty covers repairs needed to

correct defects in materials or

workmanship of any component listed

below and in the next column and

supplied by Toyota, subject to the

exceptions indicated under “What Is Not

Covered” on pages 14-15.

Coverage is for 60 months or

60,000 miles, whichever occurs first.

Engine

Cylinder block and head and all internal

parts, timing gears and gaskets, timing

chain/belt and cover, flywheel, valve

covers, oil pan, oil pump, engine mounts,

turbocharger housing and all internal

parts, supercharger housing and all

internal parts, engine control computer,

water pump, fuel pump, seals and gaskets.

Transmission and Transaxle

Case and all internal parts, torque

converter, clutch cover, transmission

mounts, transfer case and all internal

parts, engine control computer, seals and

gaskets.

Front-Wheel-Drive System

Final drive housing and all internal parts,

axle shafts, drive shafts, constant velocity

joints, front hub and bearings, seals and

gaskets.

Rear-Wheel-Drive System

Axle housing and all internal parts,

propeller shafts, U-joints, axle shafts, drive

shafts, bearings, supports, seals and

gaskets.

Restraint Systems Warranty

This warranty covers repairs needed to

correct defects in materials or

workmanship of any seatbelt or air bag

system supplied by Toyota, subject to the

exceptions indicated under “What Is Not

Covered” on pages 14-15.

Coverage is for 60 months or

60,000 miles, whichever occurs first.

For vehicles sold and registered in the

state of Kansas, the warranty for seatbelts

and related components is 10 years,

regardless of mileage.

New Vehicle Limited Warranty

WARRANTY

Your Warranties in Detail

13

Corrosion Perforation Warranty

This warranty covers repair or replacement

of any original body panel that develops

perforation from corrosion (rust-through),

subject to the exceptions indicated under

“What Is Not Covered” on pages 14-15.

Coverage is for 60 months, regardless of

mileage.

For information on how to protect your

vehicle from corrosion, refer to sections

related to maintenance and care in the

Owner’s Manual

.

Towing

When your vehicle is inoperable due to

failure of a warranted part, towing service

to the nearest authorized Toyota dealership

is covered.

WHAT IS NOT COVERED

This warranty does not cover damage or

failures resulting directly or indirectly from

any of the following:

•

Fire, accidents or theft

•

Abuse or negligence

•

Misuse — for example, racing or

overloading

•

Improper repairs

•

Alteration or tampering, including

installation of non-Genuine Toyota

Accessories

•

Lack of or improper maintenance,

including use of fluids and fuel other

than those specified in the

Owner’s

Manual

•

Installation of non-Genuine Toyota Parts

•

Airborne chemicals, tree sap, road

debris (including stone chips), rail dust,

salt, hail, floods, wind storms, lightning

and other environmental conditions

•

Water contamination

This warranty also does not cover the

following:

Tires

Tires are covered by a separate warranty

provided by the tire manufacturer. See

page 29.

Normal Wear and Tear

Noise, vibration, cosmetic conditions and

other deterioration caused by normal wear

and tear.

New Vehicle Limited Warranty

WARRANTY

Your Warranties in Detail

14

Maintenance Expense

Normal maintenance services such as:

•

Engine tune-ups

•

Replacement of fluids and filters

•

Lubrication

•

Cleaning and polishing

•

Replacement of spark plugs and fuses

•

Replacement of worn wiper blades,

brake pads/linings and clutch linings

Vehicles With Altered Odometer

Failure of a vehicle on which the odometer

has been altered so that actual vehicle

mileage cannot be readily determined.

Salvage or Total-Loss Vehicles

Any vehicle that has ever been issued a

“salvage” title or similar title under any

state’s law; or has ever been declared a

“total loss” or equivalent by a financial

institution or insurer, such as by payment

for a claim in lieu of repairs because the

cost of repairs exceeded the cash value of

the vehicle. This exclusion does not apply

to the emission control warranties.

Incidental Damages

Incidental or consequential damages

associated with a vehicle failure. Such

damages include but are not limited to

inconvenience; the cost of transportation,

telephone calls and lodging; the loss of

personal or commercial property; and the

loss of pay or revenue.

Disclaimer of Extra Expenses and

Damages

The performance of necessary repairs

and adjustments is the exclusive

remedy under this warranty or any

implied warranty. Toyota does not

authorize any person to create for it any

other obligation or liability in connection

with this vehicle. Toyota shall not be

liable for incidental or consequential

damages resulting from breach of this

written warranty or any implied

warranty. Any implied warranty of

merchantability or fitness for a

particular purpose is limited to the

duration of this written warranty, except

in states where this limitation is not

allowed.

New Vehicle Limited Warranty

WARRANTY

Your Warranties in Detail

15

DISPUTE RESOLUTION

If a dispute arises regarding your warranty

coverage, please follow the steps

described under “If You Need Assistance”

on page 5. Please note that you must use

the Dispute Settlement Program (or, in

California, the CDSP) before seeking

remedies through a court action pursuant

to the Magnuson-Moss Warranty Act. You

may also be required to use the Dispute

Settlement Program or CDSP before

seeking remedies under the “Lemon Laws”

of your state. Please check the appropriate

page of the

Owner’s Warranty Rights

Notification

booklet (located in your glove

box) for the requirements applicable to

your state.

New Vehicle Limited Warranty

WARRANTY

Your Warranties in Detail

16

WHAT IS COVERED AND

HOW LONG

Emission Defect Warranty

Toyota warrants that your vehicle:

•

Was designed, built and equipped to

conform at the time of sale with

applicable federal emissions standards.

•

Is free from defects in materials and

workmanship that may cause the

vehicle to fail to meet these standards.

Federal regulations require that this

warranty be in effect for two years or

24,000 miles from the vehicle’s in-service

date, whichever occurs first. However,

under the terms of the Basic Warranty,

Toyota provides coverage of three years or

36,000 miles, whichever occurs first.

Specific components may have longer

coverage under the terms of the

Powertrain Warranty. Additionally,

components marked “8/80” in the parts

list on pages 18–19 have coverage of

eight years or 80,000 miles, whichever

occurs first.

Emission Performance Warranty

Some states and localities have

established vehicle inspection and

maintenance (I/M) programs to encourage

proper vehicle maintenance. If an

EPA-approved I/M program is in force in

your area, you are eligible for Emission

Performance Warranty coverage.

Under the terms of the Emission

Performance Warranty and federal

regulations, Toyota will make all necessary

repairs if both of the following occur:

•

Your vehicle fails to meet applicable

emissions standards as determined by

an EPA-approved emissions test.

•

This failure results or will result in

some penalty to you — such as a fine

or denial of the right to use your

vehicle — under local, state or federal

law.

This warranty is in effect for two years or

24,000 miles from the vehicle’s in-service

date, whichever occurs first. Additionally,

components marked “8/80” in the parts

list on pages 18–19 have coverage of

eight years or 80,000 miles, whichever

occurs first.

Federal Emission Control Warranty

WARRANTY

Your Warranties in Detail

17

WHAT IS NOT COVERED

These warranty obligations do not apply to

failures or noncompliance caused by:

•

The use of replacement parts not

certified in accordance with aftermarket

parts certification regulations.

•

The use of replacement parts not

equivalent in quality or design to

original equipment parts.

Provisions under the “What Is Not

Covered” section of the New Vehicle

Limited Warranty also apply to this

warranty.

WARRANTY PARTS LIST

Air/Fuel Metering System

•

Air/fuel ratio feedback control system

•

Cold-start enrichment system

•

Deceleration control system

•

Electronic fuel injection system

components

–

Airflow sensor

–

Engine control module (8/80)

–

Throttle body

–

Other components

Air Induction System

•

Intake manifold and intake air surge

tank

Catalyst System

•

Catalytic converter and protector (8/80)

•

Constricted fuel filler neck

•

Exhaust manifold

•

Exhaust pipe (manifold to catalyst

and/or catalyst to catalyst)

Evaporative Control System

•

Charcoal canister

•

Diaphragm valve

•

Fuel filler cap

•

Fuel tank

•

Vapor liquid separator

8/80 = Covered for eight years or 80,000 miles, whichever occurs first.

Federal Emission Control Warranty

WARRANTY

Your Warranties in Detail

18

Exhaust Gas Recirculation

(EGR) System

•

EGR gas temperature sensor

•

EGR valve

•

Associated parts

Ignition System

•

Distributor and internal parts

•

Ignition coil and ignitor

•

Ignition wires

•

Spark plugs

*

Positive Crankcase Ventilation

(PCV) System

•

Oil filler cap

•

PCV valve or orifice

Other Parts Used in Above

Systems

•

Data link connector (8/80)

•

Hoses, clamps, fittings, tubing and

mounting hardware

•

Malfunction indicator light and bulb

(8/80)

•

Pulleys, belts and idlers

•

Sealing gaskets and devices

•

Sensors, solenoids, switches and valves

MAINTENANCE

You are responsible for performance of

the required maintenance indicated in the

Owner’s Manual

and this booklet. Toyota

will not deny a warranty claim solely

because you do not have records to show

that you maintained your vehicle. However,

any failure or noncompliance caused by

lack of maintenance is not covered by this

warranty.

When maintenance and repairs are paid

for by you, these services may be

performed by you or by any automotive

service provider you choose. Toyota will

not deny a warranty claim solely

because you used a service provider

other than a Toyota dealership for

maintenance and repairs. However, any

failure or noncompliance caused by

improper maintenance or repairs is not

covered by this warranty.

*Warranted until first required maintenance under terms of the California Emission Control Warranty.

8/80 = Covered for eight years or 80,000 miles, whichever occurs first.

Federal Emission Control Warranty

WARRANTY

Your Warranties in Detail

19

REPLACEMENT PARTS

To ensure optimum performance and

maintain the quality built into your

vehicle’s emission control systems, Toyota

recommends the use of Genuine Toyota

Parts when servicing or repairing the

systems.

Warranty coverage is not dependent upon

the use of any particular brand of

replacement parts and you may elect to

use non-Genuine Toyota Parts for

maintenance and repairs. However, use

of replacement parts that are not

equivalent in quality to Genuine Toyota

Parts may impair the effectiveness of the

emission control systems.

If you use replacement parts that have

maintenance or replacement schedules

different from those of Genuine Toyota

Parts, you must follow the maintenance

and replacement schedules for the parts

you are using. In addition, you should

ensure that such parts are warranted by

their manufacturers to be equivalent to

Genuine Toyota Parts.

IF YOUR VEHICLE FAILS

AN EMISSIONS TEST

If your vehicle fails an EPA-approved

emissions test, you may make a claim

under the Emission Performance Warranty.

To do so, take your vehicle to an

authorized Toyota dealership and present a

copy of the emissions test report. Also,

take your maintenance records in case

they are needed.

If your claim qualifies for coverage, the

dealership will repair your vehicle within

30 days (unless a shorter period is

required by law). If your claim is denied,

Toyota will notify you in writing of the

reason within the same period. If we fail

to do so, we will repair your vehicle free

of charge. The only exceptions allowed are

when you request or agree to a delay, or

when a delay is caused by factors beyond

the control of Toyota or the dealership.

For information on how to obtain service

under the Emission Defect Warranty, see

page 32,“Obtaining Warranty Service.”

Federal Emission Control Warranty

WARRANTY

Your Warranties in Detail

20

IF YOU HAVE QUESTIONS

If you have questions or concerns about

your federal emission warranty coverage,

please refer to “If You Need Assistance”

on page 5. In the case of the Emission

Performance Warranty, you may also

request information from or report

complaints to:

U.S. Environmental Protection Agency

Vehicle Programs & Compliance Division

(6405J)

Attn: Warranty Complaints

401 M Street SW

Washington, D.C. 20460

Vehicles equipped with a California

Certified Emission Control System that

are sold, registered and operated in

California or any state that adopts

California emission warranty provisions

are also covered by the California

Emission Control Warranty (see page

23). Currently, Connecticut, Delaware,

Maine, Maryland, Massachusetts, New

Jersey, New York, Oregon,

Pennsylvania, Rhode Island, Vermont

and Washington are the other states to

which the California Emission Control

Warranty applies.

Federal Emission Control Warranty

WARRANTY

Your Warranties in Detail

21

DEALER CERTIFICATE

We (the dealership) want you to know that

at the time your new Toyota vehicle is

being delivered:

1)

On the basis of written notification

furnished by Toyota, we have

knowledge that the vehicle is covered

by an EPA Certificate of Conformity.

2)

We have visually inspected those

emission control devices or portions

thereof that are visible without

removing or adjusting any components

or systems, emissions-related or

otherwise. On the basis of this

inspection, there are no apparent

deficiencies in the installation of

emission control devices by Toyota.

(For purposes of this certificate,

“emission control devices” is limited to

devices installed on a vehicle for the

sole or primary purpose of controlling

emissions and which were not in

general use before 1968.)

3)

We have performed all emission

control system preparations required

by Toyota prior to the sale of the

vehicle as set forth in Toyota’s current

pre-delivery service manual.

4)

Except as may be provided in

Paragraph 5, if this vehicle fails an

EPA-approved emissions test within

three months or 4,000 miles

(whichever comes first) of delivery to

the ultimate purchaser, and the vehicle

has been maintained and used in

accordance with the written

instructions for proper maintenance

and use, Toyota will remedy the

nonconformity free of charge under the

terms of the Emission Performance

Warranty.

5)

If the vehicle was used as a company

car or demonstrator, check the box and

complete the following:

❑

The vehicle with which this

statement is delivered was placed

into service as a company car or

demonstrator prior to delivery. The

Emission Performance Warranty

period commenced on the date the

vehicle was first placed into service,

which was:

Note: The dealership makes no

representation or warranty that the

emission control system or any part

thereof is without defect or that the

system will perform properly. The

Emission Performance Warranty referred

to in Paragraph 4 and furnished with the

vehicle is solely that of the manufacturer.

This statement is required by section

207 of the Clean Air Act (42 U.S.C. 7541)

and the EPA regulations issued thereunder.

Month Day Ye a r

Dealership Name

Federal Emission Control Warranty

WARRANTY

Your Warranties in Detail

22

Vehicles equipped with a California

Certified Emission Control System that

are sold, registered and operated in

California or any state that adopts

California emission warranty provisions

are covered by this warranty. Currently,

Connecticut, Delaware, Maine,

Maryland, Massachusetts, New Jersey,

New York, Oregon, Pennsylvania, Rhode

Island, Vermont and Washington are the

other states to which this warranty

applies. Vehicles covered by this

warranty are also covered by the

Federal Emission Control Warranty (see

page 17).

YOUR WARRANTY RIGHTS

AND OBLIGATIONS

The California Air Resources Board (CARB)

and Toyota are pleased to explain the

emission control system warranty for your

2017 vehicle. In California, new motor

vehicles must be designed, built and

equipped to meet the state’s stringent

anti-smog standards. CARB regulations

require that Toyota must warrant the

emission control system on your vehicle

for the time periods indicated on the next

page, provided there has been no abuse,

neglect or improper maintenance of your

vehicle.

Your emission control system may include

parts such as the fuel injection system,

ignition system, catalytic converter and

engine computer. Also included may be

hoses, belts, connectors and other

emissions-related assemblies.

Where a warrantable condition exists,

Toyota will repair your vehicle at no cost

to you, including diagnosis, parts and

labor.

California Emission Control Warranty

WARRANTY

Your Warranties in Detail

23

MANUFACTURER’S

WARRANTY COVERAGE

1)

For three years or 50,000 miles,

whichever occurs first:

–

If your vehicle fails a smog-check

test, all necessary repairs and

adjustments will be made by Toyota

to ensure that your vehicle passes

the test. This is your Emission

Control System PERFORMANCE

WARRANTY.

–

If an emissions-related part listed on

pages 18-19 is defective, the part will

be repaired or replaced by Toyota.

This is your SHORT-TERM Emission

Control System DEFECT WARRANTY.

Specific components may have

longer coverage under the terms of

the Powertrain Warranty.

2)

For seven years or 70,000 miles,

whichever occurs first:

–

If an emissions-related part listed on

page 25 is defective, the part will be

repaired or replaced by Toyota. This

is your LONG-TERM Emission

Control System DEFECT WARRANTY.

OWNER’S WARRANTY

RESPONSIBILITIES

You are responsible for performance of

the required maintenance indicated in the

Owner’s Manual

and this booklet. Toyota

recommends that you retain all receipts

covering maintenance on your vehicle, but

Toyota cannot deny warranty coverage

solely for the lack of receipts or your

failure to ensure the performance of all

scheduled maintenance.

You are responsible for presenting your

vehicle to a Toyota dealership as soon as

a problem exists. The warranty repairs

should be completed in a reasonable

amount of time, not to exceed 30 days.

You should also be aware that Toyota may

deny you warranty coverage if your vehicle

or a part has failed due to abuse, neglect,

improper maintenance or unapproved

modifications.

If you have any questions regarding your

warranty rights and responsibilities, you

should contact the Toyota Customer

Experience Center at (800) 331-4331 or

the California Air Resources Board, Mobile

Source Control Division, at 9480 Telstar

Avenue, Suite 4, El Monte, CA 91731,

(800) 242-4450.

California Emission Control Warranty

WARRANTY

Your Warranties in Detail

24

WHAT IS NOT COVERED

These warranty obligations do not apply to

failures or noncompliance caused by:

•

The use of replacement parts not

certified in accordance with aftermarket

parts certification regulations.

•

The use of replacement parts not

equivalent in quality or design to

original equipment parts.

Provisions under the “What Is Not

Covered” section of the New Vehicle

Limited Warranty also apply to this

warranty.

PARTS LIST: LONG-TERM

EMISSION DEFECT

WARRANTY

The parts listed here are covered for seven

years or 70,000 miles from the vehicle’s

in-service date, whichever occurs first.

Air/Fuel Metering System

•

Engine control computer (engine

control module)

•

Throttle body

•

Transmission control computer

(transmission control module) on

models equipped with 2GR-FE

Air Induction System

•

Intake manifold

•

Intake air surge tank on models

equipped with 2GR-FE

Catalyst System

•

Exhaust front pipe (including catalytic

converter)

•

Exhaust manifold (including manifold

converter)

Evaporative Control System

•

Charcoal canister

•

Fuel tank

Other Parts Used in Systems

Listed

•

Transmission solenoid

•

Wire transmission (including

temperature sensor)

California Emission Control Warranty

WARRANTY

Your Warranties in Detail

25

MAINTENANCE

You are responsible for performance of

the required maintenance indicated in the

Owner’s Manual

and this booklet. Toyota

will not deny a warranty claim solely

because you do not have records to show

that you maintained your vehicle. However,

any failure or noncompliance caused by

lack of maintenance is not covered by this

warranty.

When maintenance and repairs are paid

for by you, these services may be

performed by you or by any automotive

service provider you choose. Toyota will

not deny a warranty claim solely

because you used a service provider

other than a Toyota dealership for

maintenance and repairs. However, any

failure or noncompliance caused by

improper maintenance or repairs is not

covered by this warranty.

REPLACEMENT PARTS

To ensure optimum performance and

maintain the quality built into your

vehicle’s emission control systems, Toyota

recommends the use of Genuine Toyota

Parts when servicing or repairing the

systems.

Warranty coverage is not dependent upon

the use of any particular brand of

replacement parts and you may elect to

use non-Genuine Toyota Parts for

maintenance and repairs. However, use

of replacement parts that are not

equivalent in quality to Genuine Toyota

Parts may impair the effectiveness of the

emission control systems.

If you use replacement parts that have

maintenance or replacement schedules

different from those of Genuine Toyota

Parts, you must follow the maintenance

and replacement schedules for the parts

you are using. In addition, you should

ensure that such parts are warranted by

their manufacturers to be equivalent to

Genuine Toyota Parts.

California Emission Control Warranty

WARRANTY

Your Warranties in Detail

26

IF YOUR VEHICLE FAILS A

SMOG-CHECK TEST

If your vehicle fails a smog-check test,

you may make a claim under the Emission

Performance Warranty. To do so, take your

vehicle to an authorized Toyota dealership

and present a copy of the smog-check test

report. Also, take your maintenance

records in case they are needed.

If your claim qualifies for coverage, the

dealership will repair your vehicle within

30 days (unless a shorter period is

required by law). If your claim is denied,

Toyota will notify you in writing of the

reason within the same period. If we fail

to do so, we will repair your vehicle free

of charge. The only exceptions allowed are

when you request or agree to a delay, or

when a delay is caused by factors beyond

the control of Toyota or the dealership.

For information on how to obtain service

under the Emission Defect Warranty, see

page 32, “Obtaining Warranty Service.”

REPAIR DELAYS

If a Toyota dealership is unable to

complete repairs on your vehicle within

30 days, you may have the repairs made

under Toyota’s provisions for emergency

warranty repairs. See page 32 for details.

California Emission Control Warranty

WARRANTY

Your Warranties in Detail

27

IF YOU HAVE QUESTIONS

If you have questions or concerns about

your vehicle’s California emission warranty

coverage, please follow the steps

described under “If You Need Assistance”

on page 5. You may also request

information from or report complaints to:

California Air Resources Board

Mobile Source Control Division

9480 Telstar Avenue

Suite 4

El Monte, CA 91731

(800) 242-4450

California Emission Control Warranty

WARRANTY

Your Warranties in Detail

28

OBTAINING WARRANTY

SERVICE

The tires that come as original equipment

on your vehicle are warranted by their

manufacturer and not Toyota. A separate

warranty statement for the tires is in your

glove box.

To obtain service for a tire defect, take the

tire to an authorized dealer of the tire

manufacturer. (Refer to your local phone

directory for dealer locations.) Your Toyota

dealer may also be able to assist you in

obtaining warranty service from the

manufacturer.

For additional warranty information or

service assistance, contact the tire

manufacturer directly.

ORIGINAL EQUIPMENT

TIRE MANUFACTURERS

American Kenda Rubber

7095 Americana Parkway

Reynoldsburg, OH 43068

(866) 536–3287

Bridgestone/Firestone

535 Marriott Drive

Nashville, TN 37214

Bridgestone: (800) 847-3272

Firestone: (800) 356-4644

Continental Tire of North America

1800 Continental Blvd.

Charlotte, NC 28273

(800) 847-3349

Dunlop Tires

1144 East Market Street

Akron, OH 44316

(800) 321–2136

Goodyear Tire and Rubber Co.

1144 East Market Street

Akron, OH 44316

(800) 321-2136

Hankook Tire America Corporation

1450 Valley Road

Wayne, NJ 07470

(800) 426-5665

Michelin North America

One Park Way South

P.O. Box 19001

Greenville, SC 29602

(800) 847-3435

Toyo Tire (U.S.A.) Corporation

6261 Katella Ave., Suite 2B

Cypress, CA 90630

(800) 442-8696

Yokohama Tire Corporation

1 MacArthur Place, Suite 800

Santa Ana, CA 92707

(800) 722-9888

Tire Limited Warranty

WARRANTY

Your Warranties in Detail

29

GENERAL INFORMATION

You are responsible for ensuring that your

Toyota is operated and maintained

according to the instructions in the

Owner’s Manual

and this booklet.

You should keep detailed records of

vehicle maintenance, since under some

circumstances they may be required for

warranty coverage. These records should

include date of service, mileage at time of

service and a description of service

performed and/or parts installed. For your

convenience, a maintenance log is

included in this booklet. If you sell your

vehicle, you should give your maintenance

records to the new owner.

Toyota will not deny a warranty claim

solely because you do not have records to

show that you maintained your vehicle.

However, damage or failures caused by

lack of proper maintenance are not

covered under warranty.

WHERE TO GO FOR

MAINTENANCE

You may have maintenance performed on

your vehicle by any qualified person or

facility. However, Toyota recommends

having maintenance performed by an

authorized Toyota dealership.

Toyota dealership technicians are specially

trained to maintain and repair Toyota

vehicles. They stay current on the latest

service information through Toyota

technical bulletins, service publications

and training courses. Many are also

certified through the Toyota Certification

Program, which involves a series of

rigorous written examinations. Feel free to

ask any Toyota dealership to show you

their technicians’ credentials.

You can be confident you’re getting the

best possible service for your vehicle

when you take it to a Toyota dealership.

Operation and Maintenance

WARRANTY

Your Responsibilities

30

REPLACEMENT PARTS

Warranty coverage is not dependent upon

the use of any particular brand of

replacement parts. However, Toyota

recommends using only Genuine Toyota

Parts when you need to replace a part on

your vehicle. Like all Toyota products,

Genuine Toyota Parts are built to the

highest standards of quality, durability and

performance. They are also designed to fit

your vehicle’s exact specifications.

Your Toyota dealership maintains an

extensive inventory of Genuine Toyota

Parts to meet your vehicle service needs.

And because it is linked electronically to

Toyota’s Parts Distribution Centers, the

dealership has quick access to any parts it

may not have in stock.

Genuine Toyota Parts are covered by their

own warranty (see your dealer for details)

or the remainder of any applicable New

Vehicle Limited Warranty, whichever is

longer. Non-Genuine Toyota Parts, or any

damage or failures resulting from their

use, are not covered by any Toyota

warranty.

Operation and Maintenance

WARRANTY

Your Responsibilities

31

BY GEOGRAPHIC REGION

In the United States, U.S.

Territories, Canada and Mexico

To obtain warranty service in the United

States, U.S. territories, Canada or Mexico,

take your vehicle to an authorized Toyota

dealership. If your vehicle cannot be

driven, contact your nearest Toyota

dealership for towing assistance. You do

not have to pay for towing to the nearest

Toyota dealership if your vehicle is

inoperable due to failure of a warranted

part.

Outside the United States, U.S.

Territories, Canada and Mexico

If you are using your vehicle outside the

United States, U.S. territories, Canada and

Mexico and need warranty service, contact

a local Toyota dealership. Please note,

however, that your vehicle may not be

repaired free of charge because the local

Toyota distributor may have no obligation

to provide warranty service for your

vehicle, and/or your vehicle may not

comply with local regulatory or

environmental requirements.

EMERGENCY REPAIRS

If your vehicle is inoperable or unsafe to

drive and there is no Toyota dealership

reasonably available to make repairs, you

may perform the repairs yourself or have

them performed by another automotive

service provider. Toyota will reimburse you

for any of the repairs that are covered by

warranty. To receive reimbursement,

present to an authorized Toyota dealership

your paid repair invoices and any parts

that were removed from the vehicle. You

will be reimbursed for warranted parts at

the manufacturer’s suggested retail price

and warranted labor at a geographically

appropriate hourly rate multiplied by

Toyota’s recommended time allowance for

the repair.

If your vehicle requires emergency repair,

Toyota assumes no liability for subsequent

failures caused by improper repairs or the

use of non-Genuine Toyota Parts unless

you have the vehicle properly repaired in a

timely manner. To ensure that warranty

coverage remains intact, have your vehicle

inspected by an authorized Toyota

dealership as soon as possible after an

emergency repair.

Obtaining Warranty Service

WARRANTY

Your Responsibilities

32

Notes

WARRANTY

Your Responsibilities

33

R

egular maintenance is essential to

obtaining the highest level of

performance, safety and reliability

from your Toyota. It can also increase

your vehicle’s resale value. The following

pages are designed to help you make sure

your vehicle receives proper and timely

maintenance. Along with other important

information related to vehicle service,

you’ll find factory-recommended

maintenance guidelines and a log in which

to document your vehicle’s maintenance

history.

In addition to scheduled maintenance,

your vehicle requires ongoing general

maintenance such as fluid checks and

visual inspections. These procedures are

explained in the “Maintenance and Care”

section of the Owner’s Manual. Be sure to

perform these procedures regularly to

ensure the most trouble-free operation of

your vehicle.

With proper maintenance and care, your

vehicle will last longer and deliver more

dependable, economical performance.

Follow this booklet’s recommendations

and you’ll enjoy maximum reliability and

peace of mind from your Toyota for many

years to come.

The Importance of Scheduled Maintenance

Maintenance Log

34

MAINTENANCE

IMPORTANT MAINTENANCE

INFORMATION

It is especially important to both

routinely check your vehicle’s engine oil

level (once a month) and regularly

replace the engine oil and oil filter (see

the Maintenance Log section of this

booklet to determine how often you

should change your vehicle’s oil and

filter). Failure to do so can cause oil

starvation and or oil gelling, which can

result in severe damage to your vehicle

and require costly repairs that are not

covered by the New Vehicle Limited

Warranty.

Maintenance Records

Maintaining your vehicle according to the

recommendations in this booklet is

required to ensure that your warranty

coverage remains intact. You should keep

detailed records of vehicle maintenance,

including date of service, mileage at time

of service and a description of service

and/or parts installation performed. The

scheduled maintenance log in this booklet

can help you document this information. If

you sell your vehicle, be sure to give your

maintenance records to the new owner.

Toyota will not deny a warranty claim

solely because you do not have records to

show that you maintained your vehicle.

However, damage or failure caused by lack

of proper maintenance are not covered

under warranty.

Maintenance Providers

Maintenance and repair services may be

performed by you or by any automotive

service provider you choose. Toyota will

not deny a warranty claim solely because

you used a service provider other than a

Toyota dealership for maintenance and

repairs. However, damage or failure

caused by improper maintenance or

repairs are not covered under warranty.

Dealer-Recommended

Maintenance

Your dealer may recommend more

frequent maintenance intervals or more

maintenance services than those listed in

the scheduled maintenance log. These

additional services are not required to

maintain your warranty coverage. Ask your

dealer to explain any recommended

maintenance not included in the scheduled

maintenance log.

For a complete description of Toyota

warranty coverages, see the Warranty

Information portion of this booklet.

Maintaining Your Warranty

Maintenance Log

35

MAINTENANCE

R

egular maintenance is essential to

obtaining the highest level of

performance from your Toyota. It

can also increase your vehicle’s resale

value. This booklet presents Toyota’s

maintenance recommendations in

convenient checklists, so you can easily

see what type of maintenance your vehicle

needs and document that the work was

performed.

To ensure that your vehicle receives

first-quality service and parts, Toyota

recommends having maintenance

performed by an authorized Toyota

dealership. Toyota dealership technicians

are experts on Toyota vehicles, and they

use Genuine Toyota Parts designed to your

vehicle’s exact specifications. When you

go to a Toyota dealership, you can be

confident that they will use Genuine Toyota

parts and have Toyota-trained technicians.

Miles or Months?

Toyota recommends obtaining scheduled

maintenance for your vehicle every

5,000 miles or six months, whichever

comes first.

For example:

•

If you drive 5,000 miles in less than six

months, you should obtain maintenance

at 5,000 miles - don’t wait until six

months.

•

If at six months you have driven less

than 5,000 miles, you should obtain

maintenance at six months - don’t wait

until 5,000 miles.

Be sure to keep an eye on your mileage so

that you obtain maintenance when

recommended. If you are a low-mileage

driver, mark your calendar to remind

yourself to obtain maintenance every six

months.

Documenting Your Investment

To help you verify that you’ve invested in

proper maintenance, each maintenance

checklist includes space for your Toyota

dealership to certify that you obtained

Genuine Toyota Service for your vehicle.

The dealership may mark the dealer

service verification area with the following

stamp (which may be customized with the

dealership’s name):

Using the Maintenance Log Charts

Maintenance Log

36

MAINTENANCE

Special Operating Conditions

In addition to standard maintenance items,

the maintenance log indicates services that

should be performed on vehicles that are

driven under especially demanding

conditions. These “special operating

conditions” and their required maintenance

items are clearly indicated in each chart.

NOTE:

You should perform these additional

maintenance services only if the

majority of your driving is done under

the special operating conditions

indicated. If you only occasionally drive

under these circumstances, it is not

necessary to perform the additional

services.

Engine Oil Selection

Please refer to your Owner’s Manual for

the specific oil viscosity rating

recommended for your vehicle/engine

type.

Additional Maintenance

In addition to scheduled maintenance,

your Toyota requires ongoing general

maintenance such as fluid checks and

visual inspections. These procedures are

explained in the “Maintenance and Care”

section of the

Owner’s Manual

. Be sure to

perform these procedures regularly to

ensure the most trouble-free operation of

your vehicle.

SuperChrome and Alloy Wheel

Care

If you purchased genuine Toyota

accessory Aluminum Alloy Wheels, follow

these cleaning guidelines to maintain the

appearance of your alloy wheels:

•

If wheels are hot, wait for them to cool

before washing.

•

Use a soft sponge or cotton cloth to

apply the same mild car-wash soap as

used for the vehicle body. Quickly rinse

off with water. Use a soft cloth to apply

the same car wax as used for the

vehicle body.

•

DO NOT USE: Any kind of chemical

based cleaners, alcohol, solvents,

gasoline, steam cleaners, scouring

pads, wire brushes, or coarse abrasives

to clean your wheels.

Using the Maintenance Log Charts

Maintenance Log

37

MAINTENANCE

5,000 miles or 6 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

4

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

10,000 miles or 12 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

4

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

38

15,000 miles or 18 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at the last oil change, replace engine oil and oil

filter.

1

Inspect the following:

_ Ball joints and dust covers

_ Brake lines and hoses

_ Drive shaft boots

_ Engine coolant

3

_ Exhaust pipes and mountings

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect engine air filter

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

4

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Repeated trips of less than five miles in temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving for a long distance such as police, taxi or

door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

4Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

39

20,000 miles or 24 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

5

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

25,000 miles or 30 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

5

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

40

30,000 miles or 36 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine air filter

Replace engine oil and oil filter

1

Rotate tires

Inspect the following:

_ Automatic transmission for signs of

leakage

_ Ball joints and dust covers

_ Brake lines and hoses

_ Brake linings/drums and brake

pads/discs

3

_ Drive shaft boots

_ Engine coolant

4

_ Exhaust pipes and mountings

_ Fuel lines and connections, fuel tank

band and fuel tank vapor vent system

hoses

_ Fuel tank cap gasket

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

5

:

Tighten nuts and bolts on chassis and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Inspect thickness measurement and disc runout.

4Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

5Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

41

35,000 miles or 42 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

4

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

40,000 miles or 48 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

4

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

42

45,000 miles or 54 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at the last oil change, replace engine oil and oil

filter.

1

Inspect the following:

_ Ball joints and dust covers

_ Brake lines and hoses

_ Drive shaft boots

_ Engine coolant

3

_ Exhaust pipes and mountings

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect engine air filter

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

4

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Repeated trips of less than five miles in temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving for a long distance such as police, taxi or

door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

4Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

43

50,000 miles or 60 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

6

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

55,000 miles or 66 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

6

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

44

60,000 miles or 72 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine air filter

Replace engine oil and oil filter

1

Rotate tires

Inspect the following:

_ Automatic transmission for signs of

leakage

_ Ball joints and dust covers

_ Brake lines and hoses

_ Brake linings/drums and brake

pads/discs

_ Drive belts

4

_ Drive shaft boots

_ Engine coolant

5

_ Exhaust pipes and mountings

_ Fuel lines and connections, fuel tank

band and fuel tank vapor vent system

hoses

_ Fuel tank cap gasket

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

6

:

Replace automatic transmission fluid

Tighten nuts and bolts on chassis and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Inspect thickness measurement and disc runout.

4Initial inspection at 60,000 miles/72 months. Inspect every 15,000 miles/18 months thereafter.

5Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

6Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

45

65,000 miles or 78 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

4

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

70,000 miles or 84 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

4

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

46

75,000 miles or 90 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at the last oil change, replace engine oil and oil

filter.

1

Inspect the following:

_ Ball joints and dust covers

_ Brake lines and hoses

_ Drive belts

_ Drive shaft boots

_ Engine coolant

3

_ Exhaust pipes and mountings

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect engine air filter

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

4

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Repeated trips of less than five miles in temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving for a long distance such as police, taxi or

door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

4Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

47

80,000 miles or 96 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

5

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

85,000 miles or 102 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

5

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

48

90,000 miles or 108 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine air filter

Replace engine oil and oil filter

1

Rotate tires

Inspect the following:

_ Automatic transmission for signs of

leakage

_ Ball joints and dust covers

_ Brake lines and hoses

_ Brake linings/drums and brake

pads/discs

3

_ Drive belts

_ Drive shaft boots

_ Engine coolant

4

_ Exhaust pipes and mountings

_ Fuel lines and connections, fuel tank

band and fuel tank vapor vent system

hoses

_ Fuel tank cap gasket

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

5

:

Tighten nuts and bolts on chassis and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Inspect thickness measurement and disc runout.

4Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

5Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

49

95,000 miles or 114 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

5

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

100,000 miles or 120 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine coolant

3

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

5

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

50

105,000 miles or 126 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at the last oil change, replace engine oil and oil

filter.

1

Inspect the following:

_ Ball joints and dust covers

_ Brake lines and hoses

_ Drive belts

_ Drive shaft boots

_ Engine coolant

4

_ Exhaust pipes and mountings

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect engine air filter

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

5

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis and body

Repeated trips of less than five miles in temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving for a long distance such as police, taxi or

door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Initial replacement at 100,000 miles/120 months. Replace every 50,000 miles/60 months thereafter. Refer to “Engine Coolant”

in the “Explanation of Maintenance Items” section in the back of this guide for more information.

4Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

5Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

51

110,000 miles or 132 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine oil and oil filter

1

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

6

:

Tighten nuts and bolts on chassis

and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

115,000 miles or 138 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Rotate tires

Visually inspect brake linings/drums

and brake pads/discs

NOTE:

If 0W-20 oil WAS NOT used at

the last oil change, replace engine oil

and oil filter.

1

Additional Maintenance Items for

Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Inspect ball joints and dust covers

Inspect drive shaft boots

Inspect engine air filter

Inspect steering linkage and boots

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Driving while towing, using a car-top

carrier, or heavy vehicle loading

6

:

Replace engine oil and oil filter

1

Tighten nuts and bolts on chassis

and body

Repeated trips of less than five miles in

temperatures below 32°F / 0°C:

Replace engine oil and oil filter

1

Extensive idling and/or low speed driving

for a long distance such as police, taxi

or door-to-door delivery use:

Replace engine oil and oil filter

1

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

Maintenance Log

MAINTENANCE

Maintenance Log

52

120,000 miles or 144 months

Check installation of driver’s floor mat

Inspect and adjust all fluid levels

Inspect wiper blades

Replace cabin air filter

Replace engine air filter

Replace engine oil and oil filter

1

Replace spark plugs

3

Rotate tires

Inspect the following:

_ Automatic transmission for signs of

leakage

_ Ball joints and dust covers

_ Brake lines and hoses

_ Brake linings/drums and brake

pads/discs

4

_ Drive belts

_ Drive shaft boots

_ Engine coolant

5

_ Exhaust pipes and mountings

_ Fuel lines and connections, fuel tank

band and fuel tank vapor vent system

hoses

_ Fuel tank cap gasket

_ Radiator and condenser

_ Steering gear

_ Steering linkage and boots

Additional Maintenance Items for Special Operating Conditions

2

Driving on dirt roads or dusty roads:

Tighten nuts and bolts on chassis and body

Driving while towing, using a car-top carrier, or heavy vehicle loading

6

:

Replace automatic transmission fluid

Tighten nuts and bolts on chassis and body

DEALER SERVICE VERIFICATION:

DATE:

MILEAGE:

1Reset the oil replacement reminder light (“MAINT REQD”) or the message “OIL MAINTENANCE REQUIRED” on the

multi-information display after maintenance at every 5,000 miles.

2Perform these service items only if you drive primarily under the conditions indicated.

3Maintenance services of spark plugs are required under the terms of the Emissions Control Warranty.

4Inspect thickness measurement and disc runout.

5Refer to “Engine Coolant” in the “Explanation of Maintenance Items” section in the back of this guide for more information.

6Not all vehicles are designed for towing. Refer to your Vehicle Owner’s Manual for details.

Maintenance Log

MAINTENANCE

Maintenance Log

53

T

he following descriptions are

provided to give you a better

understanding of the maintenance

items that should be performed on your

vehicle. The scheduled maintenance log

indicates at which mileage/time intervals

each item should be performed. Please

note that many maintenance items should

be performed only by a qualified

technician.

For further information on maintenance

items you can perform yourself, see the

“Maintenance and Care” section of the

Owner’s Manual

.

Automatic Transmission Fluid

Inspect or replace at specified intervals.

When performing inspections, check each

component for signs of leakage. If you

discover any leakage, have it repaired by a

qualified technician immediately.

Ball Joints and Dust Covers

Check the suspension and steering linkage

ball joints for looseness and damage.

Check all dust covers for deterioration and

damage. Replace any deteriorated or

damaged parts. A qualified technician

should perform these operations.

Brake Lines and Hoses

Visually inspect for proper installation.

Check for chafing, cracks, deterioration

and signs of leakage. Replace any

deteriorated or damaged parts. A qualified

technician should perform these

operations.

Brake Linings/Drums and Brake

Pads/Discs

Check the brake linings (shoes) and

drums for scoring, burning, fluid leakage,

broken parts and excessive wear. Check

the pads for excessive wear and the discs

for runout, excessive wear and fluid

leakage. Replace any deteriorated or

damaged parts. A qualified technician

should perform these operations.

Cabin Air Filter

Replace at specified intervals. Driving in

heavy traffic, on dirt roads or in urban,

desert or dusty areas may shorten filter’s

life. More frequent replacement may be

necessary.

Drive Belts

Inspect for cracks, excessive wear and

oiliness. Check the belt tension and adjust

if necessary. Replace the belts if they are

damaged.

Explanation of Maintenance Items

Maintenance Log

54

MAINTENANCE

Drive Shaft Boots

Check the drive shaft boots and clamps

for cracks, deterioration and damage.

Replace any deteriorated or damaged parts

and, if necessary, repack the grease. A

qualified technician should perform these

operations.

Driver’s Floor Mat

•

Only use the driver’s floor mat

designed specifically for the model and

model year of your vehicle.

•

Always properly secure the driver’s

floor mat using the retaining hooks.

•

Never install another floor mat on top

of the existing driver’s floor mat.

•

Never install the driver’s floor mat

upside down.

Engine Air Filter

Replace at specified intervals. When

performing inspections, check for damage,

excessive wear and oiliness, and replace if

necessary.

Engine Coolant

Drain the cooling system and refill with an

ethylene-glycol type coolant. Inspect hoses

and connections for corrosion and leaks.

Tighten connections and replace parts

when necessary. A qualified technician

should perform these operations. (For

further details, refer to “Radiator,

Condenser and Hoses” in the

“Maintenance and Care” section of the

Owner’s Manual

).

Your Toyota is equipped with Genuine

Toyota Super Long-Life Coolant. The

replacement intervals for engine coolant

recommended in this booklet are based

on replacement with Genuine Toyota

Super Long-Life Coolant or similar

high-quality non-silicate, non-amine,

non-borate ethylene-glycol coolant with

long-life hybrid organic acid technology

(i.e., a combination of low phosphates

and organic acids). If another type of

ethylene-glycol coolant is used,

replacement intervals may be different.

Explanation of Maintenance Items

Maintenance Log

55

MAINTENANCE

Engine Oil and Oil Filter

Replace the oil filter and drain and refill

the engine oil at specified intervals. For

recommended oil grade and viscosity,

refer to the

Owner’s Manual

.

NOTE: Your vehicle is certified with

Genuine Toyota 0W20 motor oil. For

VEHICLES CERTIFIED FOR 0W20 motor

oil, the oil change interval is 10,000 miles

or 12 months IF 0W20 MOTOR OIL IS

BEING USED. If 0W20 is not available,

5W20 mineral oil may be used. However,

it must be replaced at A 5,000 miles or

6 month INTERVAL with 0W20 motor oil.

For customers who primarily drive their

vehicle under any of the listed Special

Operating Conditions, the motor oil and

filter should be replaced at 5,000 miles or

6 months, REGARDLESS OF THE OIL

USED (OR CERTIFICATION OF THE

VEHICLE).

Exhaust Pipes and Mountings

Visually inspect the exhaust pipes, muffler

and hangers for cracks, deterioration and

damage. Start the engine and listen

carefully for any exhaust gas leakage.

Tighten connections or replace parts as

necessary.

Fuel Lines and Connections,

Fuel Tank Band and Fuel Tank

Vapor Vent System Hoses

Visually inspect for corrosion, damage,

cracks, and loose or leaking connections.

Tighten connections or replace parts as

necessary.

Fuel Tank Cap Gasket

Visually inspect for cracks, deterioration

and damage and replace if necessary.

Nuts and Bolts on Chassis and

Body

Re-tighten the seat-mounting bolts and

front/rear suspension member retaining

bolts to specified torque.

Radiator and Condenser

Inspect for debris, corrosion and signs of

damage. Have any problem repaired

immediately by a qualified technician.

Spark Plugs

Replace at specified intervals. Install new

plugs of the same type as originally

equipped. A qualified technician should

perform this operation.

Steering Gear

Inspect for signs of leakage. If you

discover any leakage, have it repaired

immediately by a qualified technician.

Explanation of Maintenance Items

Maintenance Log

56

MAINTENANCE

Steering Linkage and Boots

With the vehicle stopped, check for

excessive freeplay in the steering wheel.

Inspect the linkage for bending and

damage and the dust boots for

deterioration, cracks and damage. Replace

any damaged parts. A qualified technician

should perform these operations.

Tire Rotation

Tires should be rotated according to the

instructions in the

Owner’s Manual

. When

rotating tires, check for damage and

uneven wear. Replace if necessary.

Wiper Blades

The wiper blades should not show any

signs of cracking, splitting, wear,

contamination or deformation. The wiper

blades should clear the windshield without

streaking or skipping.

Explanation of Maintenance Items

Maintenance Log

57

MAINTENANCE

Model

In-service date

Selling dealership

Key number

Body style

Mileage at delivery

Selling dealership phone number

Vehicle Identification Number

Vehicle Identification

MAINTENANCE

Maintenance Log

58

Notes

MAINTENANCE

Maintenance Log

59

Notes

MAINTENANCE

Maintenance Log

60

Notes

MAINTENANCE

Maintenance Log

61

Notes

MAINTENANCE

Maintenance Log

62

Notes

MAINTENANCE

Maintenance Log

63

Notes

MAINTENANCE

Maintenance Log

64

www.toyota.com

0050517WMGCAM

Printed in U.S.A. 4/16

16 -T C S - 0 9 40 1
