AC2300
Wireless MU-MIMO
Gigabit Router
A2300
Best for Simultaneous
4K Streaming and Gaming
Range
Boost
Smart
Connect
MU-MIMO
1.8GHz
Dual-Core CPU
1625Mbps + 600Mbps
Dual Band Wi-Fi
TP-Link AC2300 Wireless MU-MIMO Gigabit Router A2300
MU-MIMO for 3× Faster Connections Range Boost for Better Whole Coverage
Highlights
MU-MIMO technology serves up to three devices at once, reducing wait time,
increasing Wi-Fi throughput for every device, and making each stream more
ecient.
Range Boost greatly improves the routers ability to detect devices that are
further away or low-powered, giving your network even greater coverage.
MU-MIMO Router
Simultaneously sends data to multiple devices
Traditional Router
Sends data to one device at a time
without Range Boost
Can not receive weak signals
with Range Boost
Greatly expands receive coverage
receive coverage receive coverage
1.8GHz Dual-Core CPU coordinates every process to ensure fast transmission
speed, supporting more devices and high-speed applications simultaneously.
NitroQAMTM Powered by Broadcom 1.8GHz Dual-Core CPU
Highlights
NitroQAMTM (1024QAM) boosts speeds on all Wi-Fi bands by 25% to
signicantly improve performance.
25%
Faster
TP-Link AC2300 Wireless MU-MIMO Gigabit Router A2300
1.8GHz
Dual-Core
CPU
Co-processor
· Ultimate Wireless Speed – Combined wireless speeds up to
600Mbps (over 2.4GHz) and 1625Mbps (over 5GHz)
· NitroQAMTM Technology – Use NitroQAMTM Technology
modulation scheme for higher data throughput, boosting
wireless speeds up to 25%
· MU-MIMO Technology – Simultaneously exchanges data with
several devices, achieving speeds which are 3x faster than
standard AC routers
· Support 802.11 ac – Provides a data transfer rate 3 times faster
than 802.11n for each stream
· Dual-core CPU – 1.8GHz dual-core CPU and 2 co-processor
make multi-tasking easy and boost data transfer rate
· Ultimate Range Wi-Fi – 3 dual band high-performance antennas
with a high-powered amplier ensure the widespread Wi-Fi
coverage and a stable connection
· Wi-Fi with Beamforming – Beamforming technology locates the
connected devices and further improves the Archer A2300’s
range and the signal strength to each mobile device, delivering a
more reliable and ecient wireless connection
Speed Wi-Fi Range Reliability
· Simultaneous Dual Band – Separate Wi-Fi bands enable more
devices to connect to your network without a drop in
performance
· Easy Bandwidth Management – Advanced QoS makes it easier
for you to manage the bandwidth of connected devices
Features
TP-Link AC2300 Wireless MU-MIMO Gigabit Router A2300
· Intuitive Web UI – Ensures quick and simple Installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Wi-Fi On/O – Turn on/o wireless radio as needed using the
Wi-Fi On/O button
· Power On/O – Conveniently power on or o your router as
required
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android and iOS device
· Online Upgrade – Keeps you informed of the latest rmware
updates, ensuring your router stays at its best
· Guest Network – Keep your main network secure by creating a
separate network for friends and visitors
· Access Control – Establish a whitelist or blacklist to allow or
restrict certain devices to access the internet
· Parental Controls – Restrict internet access time and contents
for children devices
· VPN Server – PPTP VPN and OpenVPN are supported, making it
easy to set up a secure connection between your private
network and the internet
· Encryptions for Secure Network – WPA-PSK and WPA2-PSK
encryptions provide active protection against security threats
Ease of Use Security
· Dual USB Ports for Fast Sharing – With one ultra-fast USB 3.0
port and one USB 2.0 port, you can access and share a printer
as well as your les and media locally. Through the router's FTP
server, you can also access your les and media from network
devices remotely
· 10x Faster Transfer Speed – The USB 3.0 port provides up to
10x faster USB hard drive access than previous generation USB
2.0 connections
· Built-in Print Server – Allows wireless printing from multiple
computers (works in conjunction with a USB printer)
· Built-in Media Server – Allows you to play music, watch videos
and view photos from any device on your network
Easy Sharing
Features
TP-Link AC2300 Wireless MU-MIMO Gigabit Router A2300
Hardware
· Ethernet Ports: 4 10/100/1000Mbps LAN Ports, 1 10/100/1000Mbps
WAN Port
· USB Ports: 1 USB 3.0 Port, 1 USB 2.0 Port
· Buttons: Wireless On/O Button, Power On/O Button, Reset Button, WPS
Button
· Antennas: 3 Dual Band Antennas
· External Power Supply: 12VDC/3.3A
· Dimensions (W x D x H): 215.8 X 163.8 X 38.5mm
Wireless
· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
· Frequency: 2.4GHz and 5GHz
· Signal Rate: 1625Mbps at 5GHz, 600Mbps at 2.4GHz
· Transmit Power:
FCC: <25dBm(2.4GHz), <24dBm(5GHz)
· Reception Sensitivity:
5GHz:
11ac80M MCS11: -58dBm, 11ac80M MCS0: -88dBm
11ac40M MCS11: -61dBm, 11ac40M MCS0: -91dBm
11ac20M MCS11: -63dBm, 11ac20M MCS0: -95dBm
54M: -76dBm, 6M: -95dBm
2.4GHz:
11n40M MCS9: -63dBm, 11n40M MCS0: -89dBm
11n20M MCS8: -67dBm, 11n20M MCS0: -92dBm
54M: -75dBm, 11M : -90dBm, 6M: -93dBm, 1M: -98dBm
· Wireless Function: Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
· Wireless Security: Enable/Disable SSID Broadcast, 64/128-bit WEP,
WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, QSS, Wireless MAC
Filter
Specications
TP-Link AC2300 Wireless MU-MIMO Gigabit Router A2300
Gigabit Ethernet Ports
Power On/OffPower
USB 2.0 USB 3.0WPSResetWi-Fi On/Off
Specications
· Certication:
FCC, RoHS
· System Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
· Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
AC2300 Wireless MU-MIMO Gigabit Router Archer A2300
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
OthersSoftware
· Quality of Service: WMM, Bandwidth Control
· WAN Type: Dynamic IP, Static IP, PPPoE, PPTP(Dual Access), L2TP(Dual Access),
Bigpond
· Management: Access Control, Local Management, Remote Management
· DHCP: Server, DHCP Client List, Address Reservation
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP, TP-Link
· Access Control: Parental Control, Local Management Control, Blacklist, Whitelist
· Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· USB Sharing: Supports Samba(Storage), FTP Server, Media Server, Printer Server
· Guest Network: 2.4GHz guest network x 1, 5GHz guest network x 1
Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2017 TP-Link Technologies Co., Ltd. All rights reserved.
*NitroQAM™ technology by Broadcom®
*Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specications. Range and coverage specications are based on test results under normal usage conditions. Actual wireless transmission rate and wireless coverage are not guaranteed, and will vary as a result of 1)
environmental factors, including building materials, physical objects and obstacles, 2) network conditions, including local interference, volume and density of trac, product location, network complexity, and network overhead and 3) client limitations, including rated performance, location, connection quality, and
client condition.
*Three or more 1×1 MU-MIMO-enabled client devices must be connected to achieve up to three (3) times faster performance.
