AC1200 Wireless
Dual Band Router
Archer C50 Easy Setup
300Mbps + 867Mbps
Dual Band Wi-Fi
4 × 5dBi
Antennas
Four Antennas for Faster AC
Wi-Fi and Greater Coverage
Highlights
TP-Link AC1200 Wireless Dual Band Router Archer C50
Household Wi-Fi at Streaming Speeds
Press play and forget about buering with the Archer C50. The Wireless AC router
creates high-speed AC1200 Wi-Fi so you can game online and watch movies in
HD at the same time. Thanks to dual Wi-Fi bands, you can run more of your
devices at the same time without interruption. The strong 2.4GHz (300Mbps) Wi-Fi
band is perfect for sending emails, browsing the web, and listening to music. The
crystal 5GHz Wi-Fi band reaches 867Mbps so you can game online and stream in
HD simultaneously.
Strong, Far-Reaching Wi-Fi
AC1200 (300Mbps on 2.4GHz + 867Mbps on 5GHz) Wi-Fi for reliable connections.
5GHz 867Mbps
2.4GHz 300Mbps
300Mbps 2.4GHz
300Mbps 2.4GHz
867Mbps 5GHz
Highlights
TP-Link AC1200 Wireless Dual Band Router Archer C50
Innovative Antenna Design for Maximum
Coverage
Four antennas make all of your connections more ecient and stable. Apart
from that, LNA (Low Noise Amplier) of 5GHz wireless band increases the
receiving sensitivity to enlarge Wi-Fi converage for your home.
Fast Ethernet
Enjoy fast, reliable wired connections for gaming and streaming in the best
quality.
Ethernet PortsPower
On/O
WPS/
Wi-Fi
On/O
Internet
Access
Power
Reset
Archer C50
Reliability
· Intuitive Web UI – Ensure quick and simple installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Easy On/O – Turn On/O wireless radio using the Wi-Fi On/O
button
· Power On/O – Conveniently power on or o your router as
required
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android or iOS device
· Guest Network – Keep your main network secure by creating a
separate network for friends and visitors
· Access Control – Establish a whitelist or blacklist to allow or
block certain devices from accessing the internet
· Parental Controls – Manage when and how connected devices
can access the internet
· Encryptions for Secure Network – WPA-PSK/WPA2- PSK
encryptions provide active protection against security threats
Ease of Use Security
· Wireless N Speed – 300Mbps Wi-Fi speed on 2.4GHz and
867Mbps Wi-Fi speed on 5GHz meet your daily internet needs
· Easy Bandwidth Management – Bandwidth Control allocates
necessary speed of each connected device to ensure quality of
multimedia streaming
Features
TP-Link AC1200 Wireless Dual Band Router Archer C50
Hardware
· Ethernet Ports: 4*10/100Mbps LAN Ports, 1*10/100Mbps WAN Port
· Buttons: Reset Button, Power On/O Button, WPS/Wi-Fi On/O Button
· Antennas: 4 xed Omni Directional Antennas
· External Power Supply: 9VDC/0.85A
· Dimensions (W x D x H): 9.1 x 5.7 x 1.4 in. (230 x 144 x 35mm)
Wireless
· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n
2.4GHz
· Frequency: 2.4GHz and 5GHz
· Signal Rate:
5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps
· Reception Sensitivity:
5G:
11a 54M:-77dBm;
11ac VHT20 MCS8:-72dBm;
11ac VHT40 MCS9:-68 dBm;
11ac VHT80 MCS9:-63 dBm;
2.4G:
11g 54M:-76 dBm;
11n HT20 MCS7:-74 dBm;
11n HT40 MCS7:-71 dBm;
· Wireless Function: Enable/Disable Wireless Radio, WDS Bridge,
WMM, Wireless Statistics
· Wireless Security: 64/128-bit WEP,WPA / WPA2,WPA-PSK/
WPA2-PSK encryption
Specications
TP-Link AC1200 Wireless Dual Band Router Archer C50
Ethernet PortsPower
On/O
WPS/
Wi-Fi
On/O
Internet
Access
Power
Reset
TP-Link AC1200 Wireless Dual Band Router Archer C50
Specications
· Certication
CE, FCC, RoHS, Wi-Fi
· System Requirements
Microsoft Windows 10/8.1/8/7/Vista/XP/2000/NT/98SE, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an internet service provider (for internet access)
· Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
Wireless Router Archer C50
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
OthersSoftware
· WAN Type: Dynamic IP, Static IP, PPPoE, PPTP(Dual Access), L2TP(Dual
Access), Bigpond
· DHCP: Server, DHCP Client List, Address Reservation
· Quality of Service: WMM, Bandwidth Control
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP, Comexe
· Access Control: Parental Controls, Local Management Control, Host List,
White List, Black List
· Firewall Security: DoS, SPI Firewall, IP Address Filter/MAC Address Filter, IP and
MAC Address Binding
· Protocols: IPv4, IPv6
· Management: Access Control, Local Management, Remote Management
· Guest Network: 2.4GHz guest network, 5GHz guest network
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specications may be reproduced in any form or by any means or used
to make any derivative such as translation, transformation, or adaptation without permission from TP-Link Technologies Co., Ltd.
For more information, please visit
http://www.tp-link.com/en/products/details/Archer-C50.html
