Highlights
· Concurrent AC5400 Wi-Fi – Achieves Wi-Fi experience with 802.11ac to the
extreme
· Tri-Band Wi-Fi – Delivers more Wi-Fi to more devices
· 4 x 4 Stream – Delivers up to 4 data streams for each Wi-Fi band
· Nitro-QAM Technology – Delivers 25% higher speeds on each bands with the
latest Nitro-QAM (1024-QAM) technology
· MU-MIMO – Achieves up to 4X efciency by communicating with four devices
at once
· 8 External Antennas – Maximize the Wi-Fi coverage and enhance the wireless
connections
AC 5400
Wireless Tri-Band MU-MIMO Gigabit Router
· 4-Stream and NitroQAM – Advanced 4-Stream
and NitroQAM (1024-QAM) technology increase
maximum Wi-Fi speeds on all bands by 25%,
achieving combined Wi-Fi speeds of up to
5334Mbps
· MU-MIMO – MU-MIMO allows the router to
achieve up to 4X efciency by communication
with four devices at once
· Dual-core CPU & 3 co-processors – 1.4GHz
dual-core CPU and three co-processors handle
simultaneous connections without interruption
· Maximized Range & Reliable Wi-Fi – Eight
high-performance external antennas greatly
increase the Archer C5400’s range and signal
stability.
· Laser-Focused Wi-Fi – Beamforming technology
further improves the router’s coverage by helping
it locate wireless devices to form stronger, more
reliable connections.
· Tri-band technology – Creates three separate
Wi-Fi bands for connecting more devices to your
network without a drop in performance
· Smart Connect – Helps devices run faster by
assigning them to the best channel to balance
network demand
· IP QoS – Advanced QoS automatically recognizes
& prioritizes streaming & gaming applications
Speed Wi-Fi Range Reliability
Features
AC5400 Wireless Tri-Band MU-MIMO Gigabit Router
· Dual USB Ports for Fast Sharing – With one
ultra-fast USB 3.0 port and one USB 2.0 port, you
can access and share a printer as well as your les
and media locally. Via the router’s FTP server, you
can also have access to your les & media with
networked devices remotely
· 10x Faster Transfer Speed – The USB 3.0 port
provides up to 10x faster USB hard drive access
than earlier USB 2.0 connections
· Built-in Print Server – Supports wireless printing
from multiple computers (works in conjunction
with a USB Printer)
· Built-in Media Server – Allows users to play
music, video and view photos
· 3-Step Quick Installation – Easy Setup Assistant
supporting multiple languages provides a quick &
hassle free installation
· Fast Encryption – Easy one-touch WPA wireless
security encryption with the WPS button
· Easy On/Off – Wi-Fi On/Off Button allows users
to turn wireless radio on or off
· Power On/Off – Convenient power saving
· Hassle-free Management with Tether App –
Tether App allows easy network management at
your ngertips
Easy Sharing Ease of Use Security
Features
· Access Control – Guest Network Access provides
secure Wi-Fi access for guests
· Parental Control – Establish restricted access
policies for all connected devices
· Easy Bandwidth Management – IP-based
Bandwidth Control makes it easier for you to
manage the bandwidth of connected devices
· VPN Support – Secure access to your home or
ofce network from remote devices
· Encryptions for Secure Network –
WPA-PSK/WPA2- PSK encryptions provide active
defense against security threats for user networks
AC5400 Wireless Tri-Band MU-MIMO Gigabit Router
The Archer C5400 does more than just create faster Wi-Fi, it helps
your devices achieve optimal performance by making
communication more efcient. With MU-MIMO technology, the
Archer C5400 can provide four simultaneous data streams, allowing
all connected devices to achieve speeds up to 4X faster than
standard AC routers.
Run All Your Devices At Once
Awesome Speed for More Devices
The Archer C5400 gets a performance boosts of up to 25%, thanks to
NitroQAM (1024-QAM) and 4-Stream, establishing a network that can
connect more devices without slowing down.
Smart Connect helps devices run even faster by assigning them to
the best available channel to balance network demand.
HD
AC5400 Wireless Tri-Band MU-MIMO Gigabit Router
MU-MIMO (Multi-User MIMO) Router
simultaneously sends data to multiple devices for 4X faster speed
2.4GHz Shopping online, streaming music, and
browsing on laptops, tablets, and smartphones
5GHz Gaming online and watching 4K video on consoles,
performance PCs, and smart TVs
Hardware Wireless
· Ethernet Ports: 4＊10/100/1000Mbps LAN Ports & 1＊10/100/1000Mbps
WAN Port
· USB Port: 1 USB 3.0 Port + 1 USB 2.0 Port
· Button: Wireless On/Off Button, Power On/Off Button, LED On/Off Button,
WPS Button, Reset Button
· External Power Supply: 12V/5A
· Dimensions (W x D x H): 9.1 X 9.1 X 1.7 in. (230 X 230 X 43mm)
· Antenna: 8 high-performance antennas
· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
· Frequency: 2.4GHz and 5GHz Band1/Band4
· Signal Rate: 5GHz Band1- Up to 2167Mbps, 5GHz Band2- Up to 2167Mbps,
2.4GHz- Up to 1000Mbps
· Transmit Power: CE: <20dBm(2.4GHz), <23dBm(5.15GHz to 5.35GHz),
<30dBm (5.47GHz to 5.725GHz)
FCC: <30dBm
· Reception Sensitivity:
5GHz: 11a 6Mbps: -94dBm
11a 54Mbps: -76dBm
11ac HT20 (MCS8): -68dBm, 11ac HT20 (MCS11): -61dBm
11ac HT40 (MCS9): -64dBm, 11ac HT40 (MCS11): -57dBm
2.4GHz: 11g 54Mbps: -77dBm
11n HT20 (MCS8): -73dBm, 11ac HT20 (MCS11): -63dBm
11ac HT40 (MCS9): -67dBm, 11ac HT40 (MCS11): -62dBm
· Wireless Function: Enable/Disable Wireless Radio, WMM, Wireless Statistics
· Wireless Security:64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryption
· Guest Network: 2.4GHz guest network × 1, 5GHz guest network × 2
Specications
Gigabit
Ethernet
USB
2.0
USB
3.0
Power
On/Off
Reset Power
AC5400 Wireless Tri-Band MU-MIMO Gigabit Router
Package Contents
· AC5400 Wireless Tri-Band MU-MIMO Gigabit Router Archer C5400
· Power supply unit
· Ethernet Cable
· Quick Installation Guide
Certication
· CE, FCC, RoHS
System Requirements
· Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, MAC
OS, NetWare, UNIX or Linux
· Operating Temperature: 0℃~40℃ (32℉ ~104℉)
· Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
· Subscription with an Internet Service Provider (for Internet access)
Environment
· Operating Temperature: 0℃~40℃ (32℉ ~104℉)
· Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
· Operating Humidity: 10%~90% non-condensing
· Storage Humidity: 5%~90% non-condensing
Software
· WAN Type: Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual
Access)
· DHCP: Server, Client, DHCP Client List, Address Reservation
· Quality of Service: WMM, Bandwidth Control
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: DynDns, NO-IP
· VPN Server: PPTP, Open VPN
· Access Control: Parental Control, Local Management Control, Host list,
Access Schedule, Rule Management
· Firewall Security: DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and
MAC Address Binding
· Protocols: Supports IPv4 and IPv6
· USB Sharing: Supports Samba(Storage)/FTP Server/Media Server/Printer
Server
· Management: Access Control, Local Management, Remote Management
Others
Specications
AC5400 Wireless Tri-Band MU-MIMO Gigabit Router
Specications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies CO., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. No part of the specications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies CO., Ltd.
For more information, please visit
http://www.tp-link.com/en/products/details/?categoryid=&model=Archer+C5400
or scan the QR code left
Similar ProductsIdeal to use with
