Archer T2UHP V1 Datasheet
2017-03-23
: Tp-Link Archer T2Uhp V1 Datasheet Archer T2UHP_V1_Datasheet
Open the PDF directly: View PDF
.
Page Count: 4
Highlights
· 150 + 433Mbps Dual Band Speed – Ideal for online gaming, ultra HD streaming
and large le downloads
· Dual Band Wireless – 2.4GHz and 5GHz band for exible connectivity
· Maximized Range – Higher power and sensitivity maintain the wireless speed
and strength throughout your home or ofce
· Stronger Penetrability – Sustains reliable wireless connection even across
multiple walls or oors
· WPS Button – Easy wireless security encryption at a push of the WPS button
· Backward Compatibility – With support for 802.11 a/b/g/n standards
AC 600
High Power Wireless Dual Band USB Adapter
T2UHP
150Mbps+
433Mbps
USB
2.0 Port
High
Power
· TP-LINK Utility – Utility bundle makes
management easier than ever
· Backwards Compatibility – Supports routers
utilizing 802.11 a/b/g/n Wi-Fi standards
· Active Defense – WPA/WPA2 encryption
provides your Wi-Fi network with advanced
protection against security threats
· WPS Button – Easy wireless security encryption
at a push of the WPS button
Ease of Use Security
· Fast Wi-Fi – Ultra-fast 150 + 433Mbps wireless
speeds are ideal for streaming video, online
gaming and internet calls
· 802.11ac Support – Wi-Fi technology that is
3 times faster than 802.11n
· Broad Wireless Range – Higher power and
sensitivity deliver maximized performance for
wireless connections
· Dual Band – Selectable 2.4GHz and 5GHz
bands to avoid wireless signal interference
· Strong Penetrability – Signal remains strong
and reliable, even after passing through
multiple walls or floors
· Soft AP Function – Provides additional options
when developing your local wireless network
Speed Wi-Fi Range Reliability
Features
AC600 High Power Wireless Dual Band USB Adapter T2UHP
Hardware
· Dimensions (W x D x H): 2.8 x 2.0 x 0.7 in. (71.3 x 50.7 x 18.4 mm)
· Antenna: Detachable Omni Directional (RP-SMA)
· Interface: Micro USB 2.0
Wireless
· Wireless Standards: IEEE 802.11b/g/n 2.4GHz, IEEE 802.11a/n/ac 5GHz
· Frequency: 2.4GHz or 5GHz
· Signal Rate: 150Mbps at 2.4GHz, 433Mbps at 5GHz
· Wireless Modes: Ad-Hoc / Infrastructure mode
· Wireless Security: Support 64/128/152 bit WEP, WPA/WPA2,
WPA-PSK/WPA2-PSK, 802.1x
Specifications
Package Contents
· AC600 High Power Wireless Dual Band USB Adapter Archer T2UHP
· Quick Installation Guide
· USB Extension Cable
· Resource CD
Certification
· CE, FCC, RoHS
System Requirements
· Windows XP/7/8/8.1/10, Mac 10.7-10.11, Linux
Environment
· Operating Temperature: 0℃~40℃ (32℉~104℉)
· Storage Temperature: -40℃~70℃ (-40℉~158℉)
· Operating Humidity: 10%~90% non-condensing
· Storage Humidity: 5%~90% non-condensing
Others
AC600 High Power Wireless Dual Band USB Adapter T2UHP
Diagram
Laptops with High Power
Wireless USB Adapter
T2UHP
Laptops with Normal
Wireless USB Adapter
Dual Band Router
For more information, please visit
http://www.tp-link.com/en/products/details/?model=Archer+T2UHP
or scan the QR code left
Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright © 2016 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
www.tp-link.com
AC600 High Power Wireless Dual Band USB Adapter T2UHP
