AC2800 Wireless
MU-MIMO VDSL/ADSL
Modem Router
VR2800
Wave 2 Wi-Fi to Connect
Faster on More Devices
1GHz Dual-
Core CPU
MU-MIMO
Technology
NitroQAMTM
(1024QAM)
VDSL/ADSL/Fiber/
Cable Compatible Beamforming
MU-MIMO technology serves up to four devices at once, reducing wait time,
increasing Wi-Fi throughput for every device, and making each stream more
ecient.
TP-Link AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router VR2800
MU-MIMO: Ecient Wi-Fi for Every Device
Highlights
Archer VR2800
Simultaneously sends data to multiple devices
Traditional Router
Sends data to one device at a time
The 5GHz band is enhanced with NitroQAMTM (1024QAM), boosting Wi-Fi
speeds by 25% to signicantly improve performance.
4-Stream technology runs 4 data streams on 5GHz band to increase overall
speed by 33% compared to standard routers.
NitroQAMTM and 4-Stream
25%
Faster 2167Mbps
5GHz
As a powerful DSL modem router, the Archer VR2800 supports super fast
VDSL or ADSL broadband of up to 100Mbps, as well a variety of other
connection types. The LAN/WAN port accepts connections from Cable
Modem or Fiber Modem, and both of the two USB 3.0 ports support 3G/4G
dongle connections for a perfect main or backup internet connection.
Versatile Connectivity
Highlights
Ethernet Cable
DSL Cable
DSL Port Back-up 1
Back-up 2
Fiber/Cable Modem
3G/4G Dongle
TP-Link AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router VR2800
The Archer VR2800 adds a dedicated processor for each band to manage Wi-Fi
trac, freeing up the router's 1GHz dual-core CPU to tackle more consuming
tasks.
1 GHz Dual-Core CPU + 2 Co-Processors
1 GHz
dual-core
CPU
Co-processor 1
Co-processor 2
· Ultimate Wireless Speed – Combined wireless speeds of up to
600 Mbps (over 2.4GHz) and 2167 Mbps (over 5GHz)
· NitroQAM Technology – Uses NitroQAM (1024 QAM) modulation
scheme for higher data throughput, boosting wireless speeds by
up to 25%
· MU-MIMO Technology – Simultaneously exchange data with
several devices, achieving speeds which are 4x faster than
standard AC routers
· 802.11 ac – Provides a data transfer rate 3 times faster than
802.11n for each stream
· Dual-core CPU – 1GHz dual-core CPU and 2 co-processors
make multi-tasking easy and boost data transfer rate
· Ultimate Range Wi-Fi – 4 dual band detachable antennas ensure
widespread Wi-Fi coverage and a stable connection
· Wi-Fi with Beamforming – Beamforming technology locates the
connected devices and further improves the Archer VR2800’s
range and the signal strength to each mobile device, delivering a
more reliable and ecient wireless connection
Speed Wi-Fi Range Reliability
· Simultaneous Dual Band – Separate Wi-Fi bands enable more
devices to connect to your network without a drop in
performance
· QoS – Device/Application-based QoS makes it easier for you to
prioritize the internet trac
Features
TP-Link AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router VR2800
· Intuitive Web UI– Ensures quick and simple installation without
hassle
· Fast Connection – Connect wireless devices securely with the
press of WPS button
· Easy On/O – Turn On/O power, wireless radio and LEDs
separately using the Power On/O, Wi-Fi On/O and LED On/O
buttons
· Remote Management with TP-Link ID – Manage your home
network from your smartphone or tablet via a single TP-Link ID,
no matter where you nd yourself
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android or iOS device
· Online Upgrade – Keeps you informed of the latest rmware and
allows online updating
· Guest Network – Keep your main network secure by creating a
separate network for friends and visitors
· Access Control – Establish a whitelist or blacklist to allow or
block certain devices from accessing the internet
· Parental Controls – Manage when and how connected devices
can access the internet
· VPN Server – OpenVPN, PPTP VPN and IPSec VPN are
supported, making it easy to set up a secure connection
between your private network and the internet
· Encryptions for Secure Network – WPA-PSK/WPA2- PSK
encryptions provide active protection against security threats
Ease of Use Security
· Dual USB Ports for Fast Sharing – With two ultra-fast USB 3.0
ports, you can access and share a printer as well as your les
and media locally. Through the modem router's FTP server, you
can also access your les and media from network devices
remotely
· 10x Faster Transfer Speed – The USB 3.0 port provides up to
10x faster USB hard drive access than previous generation USB
2.0 connections
· Built-in Print Server – Allows wireless printing from multiple
computers (works in conjunction with a USB printer)
· Built-in Media Server – Allows you to play music, watch videos
and view photos from any device on your network
Easy Sharing
Features
TP-Link AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router VR2800
Hardware
· Ethernet Ports: 3 10/100/1000Mbps RJ45 LAN Ports, 1 10/100/1000Mbps
RJ45 WAN/LAN Port, 1 RJ11 Port
· USB Port: 2 USB 3.0
· Button: WPS Button, Wi-Fi Button, Reset Button, LED On/O Button, Power
On/O Button
· External Power Supply: 12V/3.3A
· Dimensions (W x D x H): 10.4 × 7.8 × 1.5 in (263.8 × 197.8 × 37.3 mm)
· IEEE Standards: IEEE 802.3, IEEE 802.3u, 802.3ab
· VDSL2 Standards: ITU G.993.2, Up to 17a prole (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP）
· ADSL Standards: Full-rate ANSI T1.413 Issue 2,
ITU-T G.992.1(G.DMT),
ITU-T G.992.2(G.Lite),
ITU-T G.994.1 (G.hs),
· ADSL2 Standards: ITU-T G.992.3 (G.DMT.bis),
· ADSL2+ Standards: ITU-T G.992.5
· Antenna Type: 4 external detachable dual band antennas (RP-SMA)
· Antenna Gain: 3 x 2dBi for 2.4GHz and 4 x 3dBi for 5GHz
Wireless
· Wireless Standards: IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
· Frequency: 2.4GHz and 5GHz (Supports DFS)
· Signal Rate: 2167Mbps at 5GHz, 600Mbps at 2.4GHz
· Transmit Power: <20dBm (2.4GHz), <23dBm (5GHz Band1 & Band2),
<30dBm (5GHz Band3)
· Wireless Function: Enable/Disable Wireless Radio, WMM, Wireless
Statistics
· Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2
encryptions
· Wireless Schedule: Support 2.4GHz and 5GHz Wireless Schedule
Specications
TP-Link AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router VR2800
WPS Wi-Fi USB 3.0
Power
3 LAN Ports
1 LAN/WAN Port
Power On/O
Reset
DSL Port
Connect to Fiber or Cable Modems
Connect with hard disk, printer or 3G/4G modem
Specications
· Certication: CE, RCM, RoHS
· System Requirements:
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10,
Mac OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Subscription with an internet service provider (for internet access)
· Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
AC2800 Wireless MU-MIMO VDSL/ADSL Modem Router Archer VR2800
External Splitter
RJ11 DSL Cable
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
OthersSoftware
· Operation Modes: VDSL/ADSL Modem Router, Wireless Router, 3G/4G Router
· DHCP: Server, Client, DHCP Client List, Address Reservation, DHCP Relay
· Quality of Service: ATM QoS, Trac Control (IP QoS)
· Port Forwarding: Virtual Server, Port Triggering, DMZ, ALG, UPnP
· Dynamic DNS: DynDns, NO-IP, TP-Link
· VPN: OpenVPN, PPTP VPN, IPSec VPN
· ATM/PPP Protocols: ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over
Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge
(RFC1483 Bridge), PVC – Up to 8 PVCs
· Security: NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service
(DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding
· Advanced Functions: Parental Controls, Network Address Translation(NAT), Port Mapping
(Grouping), Static Routing, RIP v1/v2 (optional), DNS Relay, DDNS, IGMP V1/V2/V3
· USB Sharing: Support Samba (Storage) / FTP Server / Media Server / Printer Server, 3G/4G
Modem / SFTP Server / Web Storage
· Management: Web Based Conguration (HTTP / HTTPS ), Remote management,
Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic
Tools, Free Online Firmware Update
· Guest Network: 2.4GHz guest network, 5GHz guest network
· IPSec VPN: Support up to 10 IPSec VPN tunnels
· Protocols: Support IPv4 and IPv6
Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are
trademarks or registered trademarks of their respective holders. Copyright ©2017 TP-Link Technologies Co., Ltd. All rights reserved.
