Whole Home Wi-Fi System

Mesh Wi-Fi System | Parental Controls | Antivirus

AC1300

Whole Home

Wi-Fi System

Deco M5

HomeCare ensures every device on your network remains protected, with a

threat database updated live by Trend MicroTM.

Powerful parental controls can limit online time and block inappropriate

content according to unique proles created for each family member.

TP-Link HomeCare™

Decos work together to form one unied Wi-Fi network. Walk through

your home and stay connected with the fastest possible speeds thanks

to Deco’s seamless coverage, powered by TP-Link Mesh Technology.

TP-Link Mesh Technology

Deco is the simplest way to guarantee a strong Wi-Fi signal in every corner of

your home. Enjoy fast, stable connections for an army of devices in a whole-

home coverage. Setup couldn’t be easier with the Deco app there to walk you

through every step.

Fast. Stable. Everywhere.

Highlights

Wi-Fi Dead-Zone Killer

Eliminate weak signal areas with whole home Wi-Fi. No more searching

around for a stable connection.

TP-Link AC1300 Whole Home Wi-Fi System Deco M5

Highlights

867Mbps 5GHz

400Mbps 2.4GHz

867Mbps 5GHz

400Mbps 2.4GHz

Internet

TP-Link AC1300 Whole Home Wi-Fi System Deco M5

· Proles – Create a prole for each family member, and manage

them individually

· Content Filter – Four levels are available for ltering content,

each catering to a specic age group

· Time Controls – Set daily time limits for the total time spent

online and block a person’s internet access between certain

times

· Pause the Internet – Pause a family member's internet and

resume it whenever you like

Features

Robust Parental Controls

Manage content and control when each

device can access the internet

· For Applications– Prioritize the online activity that's most

important to everyone on the network

· For Devices – Give high priority to the devices that need the

fastest internet connection

Quality of Service

Prioritize devices and applications for faster

performance when needed

· Auto Connection Test – Test the internet connection of your

Decos and helps to identify a suitable location for them

· Remote Management – Manage your Deco network from

a smartphone or tablet via the app, no matter where you

nd yourself

· Online Upgrade – Keep informed of the latest rmware updates

Assisted Setup

The Deco app helps you easily nd the ideal

spot to place each unit

· Time spent online – The three devices that spent the most time

online

· Highest speed – The highest internet speed tested this month

· Connected devices – Total number of devices connected to

Deco this month

· Malicious attacks blocked by Deco – Deco prevented these

attacks from infecting your network

Reporting

Review a monthly list of usage, blocked

content and security threats

· Malicious Content Filter – Block malicious websites that are

listed in Trend Micro's database to ensure you can surf the net

in safety

· Intrusion Prevention System – Protect your network and

applications against external attacks and eliminates

vulnerabilities

· Infected Device Quarantine – Prevent infected devices from

sending sensitive information or security threats to clients

outside your network

3-Year Built-In Antivirus

Protect all connected devices in your home

from viruses and malware

· Encryption for Secure Network – WPA/WPA2 encryption

provide active protection against security threats

· Firewall – Protect your network devices from malicious attacks

Security

Safeguard your home network with a rewall

and wireless encryption

www.tp-link.com ©2018 TP-Link

Hardware

· Ports: 2 LAN/WAN Gigabit Ethernet Ports, 1 Power Port

· Buttons: 1 Reset button on the underside

· Antenna Type: 4 internal antennas per Deco unit

· Wireless Onboarding: Bluetooth 4.2

· Flash: 32 MB

· SDRAM: 256 MB

· External Power Supply: 12 V/1.2 A

· Dimensions (Dia x H): 4.7 in. x 1.3 in. (120 mm x 38 mm)

Wireless

· Wireless Standards: IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz

· Frequency: 2.4 GHz and 5 GHz

· Signal Rate: 867 Mbps at 5 GHz, 400 Mbps at 2.4 GHz

· Transmit Power: FCC: <30 dBm, CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)

· Wireless Security: WPA-PSK/WPA2-PSK

Specications

Software

· Working Mode: Router, Access Point

· WAN Type: Dynamic IP/Static IP/PPPoE

· DHCP: Server, Client

· Quality of Service: WMM

· Firewall Security: SPI Firewall

· Protocols: Supports IPv4 and IPv6

· Guest Network: 2.4 GHz guest network x 1, 5 GHz guest

network x 1

· Features: Parental Controls, 3-Year Built-In Antivirus, QoS

(Quality of Service), Reporting, Assisted Setup, Address

Reservation, Port Forwarding, TP-Link DDNS

· Management: Local Management, Remote Management

Others

· Certication: CE, FCC, IC, NCC, BSMI, IDA,

RCM, JPA, JRF, VCCI, KC, RoHS

· Smartphone/Tablet Requirements:

iOS 8.0 or later

Android 4.3 or later

Bluetooth 4.0 or later

· Environment:

Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

· Package Contents for Whole-Home Wi-Fi System (3-pack):

3 Deco units

1 RJ45 Ethernet Cable

3 Power Adapters

· Package Contents for Whole Home Wi-Fi Unit (1-pack):

Installed independently or added to the existing system to provide greater coverage

1 Deco unit

1 RJ45 Ethernet Cable

1 Power Adapter

Reset

Power Ethernet

TP-Link AC1300 Whole Home Wi-Fi System Deco M5
