Smart Home Mesh Wi-Fi System
Whole Home Wi-Fi | Seamless Roaming | Parental Controls | Antivirus
AC2200 Smart Home
Mesh Wi-Fi System
Seamless coverage
up to 6,500sq.ft.
Deco M9 Plus
TP-Link AC2200 Smart Home Mesh Wi-Fi System Deco M9 Plus
HomeCare ensures every device on your network remains protected, with a
threat database updated live by Trend MicroTM.
Powerful parental controls can limit online time and block inappropriate
content according to unique proles created for each family member.
TP-Link HomeCare™
Decos work together to form one unied Wi-Fi network. Walk through
your home and stay connected with the fastest possible speeds thanks
to Deco’s seamless coverage, powered by TP-Link Mesh Technology.
TP-Link Mesh Technology
Deco is the simplest way to guarantee a strong Wi-Fi signal in every corner of
your home. Enjoy fast and secure tri-band Wi-Fi no matter how many devices
you have. Deco M9 Plus is much more than just a Wi-Fi system, able to act as a
hub for all your smart home devices. Simply works with a variety of Zigbee,
Bluetooth, Wi-Fi devices.
Fast. Smart. Everywhere.
Highlights
Three separate Wi-Fi bands deliver super-fast, stable connections to
devices in every room of your home. More bandwidth is freed up thanks
to dedicated wireless links between Deco units. Say goodbye to lag with
Deco M9 Plus AC2200 Smart Home Mesh Wi-Fi system.
Superior Tri-Band Speeds
Wi-Fi Dead-Zone Killer
Eliminate weak signal areas with whole home Wi-Fi. No more searching
around for a stable connection.
Dedicated wireless connection
Smart
Switch
Smart
Plug
Smart
Sensor
Camera
Smart
Bulb
Internet
Dedicated wireless connection
TP-Link AC2200 Smart Home Mesh Wi-Fi System Deco M9 Plus
· Proles – Create a prole for each family member, and manage
them individually
· Content Filter – Four levels are available for ltering content,
each catering to a specic age group
· Time Controls – Set daily time limits for the total time spent
online and block a person’s internet access between certain
times
· Pause the Internet – Pause a family member's internet and
resume it whenever you like
Features
Robust Parental Controls
Manage content and control when each
device can access the internet
· For Applications– Prioritize the online activity that's most
important to everyone on the network
· For Devices – Give high priority to the devices that need the
fastest internet connection
Quality of Service
Prioritize devices and applications for faster
performance when needed
· Auto Connection Test – Test the internet connection of your
Decos and helps to identify a suitable location for them
· Remote Management – Manage your Deco network from
a smartphone or tablet via the app, no matter where you
nd yourself
· Online Upgrade – Keep informed of the latest rmware updates
Setup and Control
The Deco app helps you easily set up Decos, and
aslo acts as a smart home control point
· Time spent online – The three proles that spent the most time
online
· Highest speed – The highest internet speed tested this month
· Connected devices – Total number of devices connected to
Deco this month
· Malicious attacks blocked by Deco – Deco prevented these
attacks from infecting your network
Reporting
Review a monthly list of usage, blocked
content and security threats
· Malicious Content Filter – Block malicious websites that are
listed in Trend Micro's database to ensure you can surf the net
in safety
· Intrusion Prevention System – Protect your network and
applications against external attacks and eliminates
vulnerabilities
· Infected Device Quarantine – Prevent infected devices from
sending sensitive information or security threats to clients
outside your network
3-Year Free Built-In Antivirus
Protect all connected devices in your home
from viruses and malware
· Smart Hub - Cconnect Wi-Fi, ZigBee and Bluetooth devices to
your network and let you manage them from the Deco App. Set
Automation to set interactions between your smart devices
Smart Home Devices Support
Connect smart home devices without an
additional hub and control from the Deco app
TP-Link AC2200 Smart Home Mesh Wi-Fi System Deco M9 Plus
www.tp-link.com ©2018 TP-Link
Hardware
· Ports: 2 LAN/WAN Gigabit Ethernet Ports, 1 USB 2.0 Port (reserved), 1.
Power Port
· Buttons: 1 Reset button on the underside
· Antenna Type: 8 internal antennas per Deco unit
· External Power Supply: 12 V/2 A
· Dimensions (Dia x H): 144 mm x 64 mm,
Wireless
· Wireless Standards: IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz,
Bluetooth 4.2, ZigBee HA1.2
· Frequency: 2.4 GHz and 5 GHz
· Signal Rate: 867 Mbps at 5 GHz (1), 867 Mbps at 5 GHz (2), 400 Mbps at 2.4 GHz
· Transmit Power: FCC: <30 dBm, CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
· Wireless Security: WPA-PSK/WPA2-PSK
Specications
Software
· WAN Type: Dynamic IP/Static IP/PPPoE
· DHCP: Server, Client
· Quality of Service: WMM
· Firewall Security: SPI Firewall
· Protocols: Supports IPv4 and IPv6
· Guest Network: 2.4 GHz guest network x 1, 5 GHz guest
network x 1
· Features: Parental Controls, 3-Year Free Built-In Antivirus, QoS
(Quality of Service), Reporting, Assisted Setup, Works with
Alexa & IFTTT, Automation (for smart home devices)
· Management: Local Management, Remote Management
Others
· Smartphone/Tablet Requirements:
iOS 8.0 or later
Android 4.3 or later
Bluetooth 4.2 or later
· Environment:
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents for Deco M9 Plus (3-pack):
3 Deco units
1 RJ45 Ethernet Cable
3 Power Adapters
· Package Contents for Deco M9 Plus (2-pack):
2 Deco units
1 RJ45 Ethernet Cable
2 Power Adapters
· Package Contents for Deco M9 Plus (1-pack):
1 Deco unit
1 RJ45 Ethernet Cable
1 Power Adapter
Reset
Power Ethernet
USB Port (reserved)
